Wiring diagram: Computer data lines — Computer data lines circuit Audi A4 B8
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft
- Body control modules 3
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering 2
- Electronic suspension
- Engine performance 2.0l turbo
- Exterior lights 3
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 3
- Interior lights 2
- Memory systems
- Navigation 8
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 6
- Power top/sunroof 2
- Power windows
- Radio 11
- Shift interlock 3
- Starting/charging 2
- Supplemental restraints
- Transmission 4
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer 2
Computer data lines circuit (1 of 3) Audi A4 B8
Components on the diagram
Computer data lines circuit (2 of 3) Audi A4 B8
Components on the diagram
Computer data lines circuit (3 of 3) Audi A4 B8
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
