Wiper/washer Systems (avant) Audi A4 B8

CONTACT CORROSION

Contact corrosion can occur if incorrect fasteners (bolts, nuts, washers, etc.) are used.

For this reason, only fasteners with a special surface coating are used.

In addition, rubber or plastic parts and adhesive consist of non-conductive materials.

If there are doubts as to whether parts are suitable or not, use new parts.

1. We only recommend original replacement parts, they have been tested and are compatible with aluminum.
2. We recommend using Audi accessories.
3. Damage resulting from contact corrosion is not covered by warranty.

FLUID HOSES

The following descriptions can be found in the General Information .

1. Washer fluid line hose connections, disconnecting and connecting
2. Corrugated hose washer fluid line, repairing

Scheme 64

1. Headlamp Washer System Spray Nozzle Overview, refer to «RESERVOIR, HOSES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «SPRAY NOZZLES»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzles) .
2. Spray Nozzle Overview, refer to «WASHER FLUID RESERVOIR, HOSES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «SPRAY NOZZLES»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
3. Wiper Arm Overview, refer to «WIPER SYSTEM OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-system-overview) . Removing and installing, refer to «WIPER ARMS»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arms) .
4. Windshield Wiper Motor -V- With the wiper motor control module -J400-. Overview, refer to «WIPER SYSTEM OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-system-overview) . Removing and installing, refer to «WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-motor-with-wiper-motor-control) .
5. Rain/Light Recognition Sensor -G397- Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/windows/#glass-window-regulators-avant) .
6. Grommet For the windshield washer fluid hose inside the hood.
7. Washer Fluid Reservoir Overview, refer to «WASHER FLUID RESERVOIR, HOSES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «WASHER FLUID RESERVOIR»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
8. Filler Tube For the washer fluid reservoir. Overview, refer to «WASHER FLUID RESERVOIR, HOSES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «WASHER FLUID RESERVOIR FILLER NECK»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__washer-fluid-reservoir-filler-neck) .

Scheme 65

1. Right Washer Nozzle Removing and installing, refer to «SPRAY NOZZLES»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzles) .
2. Right Mount For the spray nozzle and headlamp.
3. Washer Fluid Hose For the right spray nozzle. Secured on the bumper with cable ties.
4. Left Mount For the spray nozzle and headlamp.
5. Washer Fluid Reservoir
6. Headlamp Washer System Pump -V11- Removing and installing, refer to «HEADLAMP WASHER PUMP»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__headlamp-washer-pump) .
7. Sealing Grommet For the headlamp washer pump.
8. Washer Fluid Hose From the headlamp washer pump.
9. Washer Fluid Hose To the spray nozzles
10. Left Washer Nozzle Removing and installing, refer to «SPRAY NOZZLES»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzles) .
11. Washer Fluid Hose For the left spray nozzle.
12. Bumper

SPRAY NOZZLE, ADJUSTING

Note. The spray nozzles are already adjusted by the manufacturer and must not be adjusted after installation.

WIPER SYSTEM OVERVIEW

Observe the notes on the contact corrosion. Refer to CONTACT CORROSION .

Scheme 66

1. Bolt Tightening sequence, refer to «Windshield Wiper Motor - Tightening Specification and Sequence»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
2. Windshield Wiper Motor -V- With the wiper motor control module -J400-. Removing and installing, refer to «WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-motor-with-wiper-motor-control) .
3. Bolt Tightening sequence, refer to «Windshield Wiper Motor - Tightening Specification and Sequence»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
4. Nut 17 Nm
5. Cap
6. Windshield Wiper Arm, Passenger's Side Different lengths. Removing and installing, refer to «WIPER ARMS»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arms) . Adjusting, refer to «WIPER ARM, ADJUSTING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arm-adjusting) .
7. Windshield Wiper Blade, Passenger's Side Different lengths. Replacing, refer to «WIPER BLADE, REPLACING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-blade-replacing) .
8. Windshield Wiper Blade, Driver's Side Different lengths. Replacing, refer to «WIPER BLADE, REPLACING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-blade-replacing) .
9. Windshield Wiper Arm, Driver's Side Different lengths. Removing and installing, refer to «WIPER ARMS»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arms) . Adjusting, refer to «WIPER ARM, ADJUSTING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arm-adjusting) .
10. Cap
11. Nut 17 Nm
12. Bolt Tightening sequence, refer to «Windshield Wiper Motor - Tightening Specification and Sequence»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
13. Water Drain Channel

Scheme 67

Tighten the bolts -1, 2, 3- in sequence in 2 stages as follows

Tighten the bolts by hand until seated.

Tighten the bolts to 8 Nm.

Scheme 68

1. Bolt Tightening sequence, refer to «Windshield Wiper Motor - Tightening Specification and Sequence»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
2. O-ring Replace if damaged.
3. Sealing Grommet Replace if damaged.
4. Filler Tube For the washer fluid reservoir. Removing and installing, refer to «WASHER FLUID RESERVOIR FILLER NECK»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__washer-fluid-reservoir-filler-neck) .
5. Support Ring
6. Nut Threaded connection shared with tower brace. Tightening specification, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/suspension-front/#front-suspension-avant) .
7. Cover For the filler neck.
8. Washer Fluid Line For the windshield washer system.
9. Right Washer Nozzle Depending on equipment, with the right washer nozzle heater -Z21-. Removing and installing, refer to «SPRAY NOZZLES»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Adjusting, refer to «SPRAY NOZZLES, ADJUSTING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzles-adjusting) .
10. Left Washer Nozzle Depending on equipment, with the left washer nozzle heater -Z20-. Removing and installing, refer to «SPRAY NOZZLES»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Adjusting, refer to «SPRAY NOZZLES, ADJUSTING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzles-adjusting) .
11. Washer Fluid Reservoir Removing and installing, refer to «WASHER FLUID RESERVOIR»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
12. Headlamp Washer System Pump -V11
13. Sealing Grommet
14. Washer Fluid Line For the headlamp washer system.
15. Retaining Ring For the windshield washer pump.
16. Windshield Washer Pump -V5- Removing and installing, refer to «WINDSHIELD WASHER PUMP -V5»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__windshield-washer-pump-v5) .
17. Sealing Grommet
18. Bolt Tightening sequence, refer to «Windshield Wiper Motor - Tightening Specification and Sequence»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
19. Sealing Grommet
20. Windshield Washer Fluid Level Sensor -G33- Removing and installing, refer to «WASHER FLUID LEVEL SENSOR -G33»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__washer-fluid-level-sensor-g33) .

Scheme 69

Tighten the washer fluid reservoir bolts in the sequence specified

Tighten the bolt -3- to 7 Nm.

Tighten the bolt -4- to 7 Nm.

WIPERS, BRINGING INTO SERVICE POSITION

Note. If the windshield wiper motor is to be run during this procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Make sure the wiper blades are not frozen.

Turn on ignition.

Using the multimedia control head, activate the menu entry windshield wiper "on". Refer to the Owner's Manual.

1. The windshield wipers run into "service position".

Turn off the ignition.

WIPER ARM, ADJUSTING

Procedure

Note. If the windshield wiper motor is to be run during this procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Remove the wiper arms. Refer to WIPER ARMS .

Turn on the ignition.

Activate the "one-touch wiping" and let the wiper motor run to the end position.

Note. Every second time the wiper motor is turned off, it returns the wiper arms to a slightly lower rest position, thus tipping the wiper blade lips the other way. To do so, the wiper motor moves the wiper arms farther down than to the rest position and then a bit up again. This lower rest position must not be used to adjust the wiper crank. Only use the end position where the wiper arms run directly to the end position with no under stroke. Activate "one-touch wiping" again if necessary.

Turn off the ignition.

Position the wiper arm with wiper blade, installed at the wiper axis and align the wiper blade at the windshield as follows

Scheme 70

1. Dimension -a- = 0 + 10 mm.
2. Dimension -b- = 0 + 10 mm.

Note. The dimensions give the distance of the wiper blade tips to the cowl panel trim on the lower edge of the windshield.

Tighten the nuts -2- for the wiper arms -1-.

Scheme 71

1. Tightening specification, refer to «WIPER SYSTEM OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-system-overview) .

Turn on the ignition.

Operate the "one-touch wiping" and let the wiper arms run to the end position.

Turn off the ignition.

Check the adjustment of the wiper arms again, correct if necessary.

Install the caps -arrows- onto the wiper arms.

SPRAY NOZZLES, ADJUSTING

Special tools and workshop equipment required

1. Windshield Washer Aiming Tool T40187 equipped with Replacement Tip 3125/5A

Adjusting

Scheme 72

Note. The settings indicate the values for a moving vehicle, for example, the spray from the jets is slightly offset when the vehicle is stationary.

Mark the six points on the windshield using a water soluble marker

Scheme 73

Unlock the long cover -1- on the T40187 -arrow A- and push it back -arrow B-.

Scheme 74

Place adjusting pin -2- on the respective nozzle -arrow- of nozzle unit -1- and aim at the points on the windshield and adjust if necessary.

Scheme 75

If the spray field does not correspond to the specifications, clean the dirty spray nozzle.

Cleaning the Nozzle

Remove the nozzle. Refer to SPRAY NOZZLES .

Flush the nozzle opposite to the spray direction using clear water.

To remove any remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.

If the spray field still does not match the specifications, replace the spray nozzle.

Scheme 76

1. Rear Window Wiper Motor -V12- Overview, refer to «WIPER AND MOTOR OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «REAR WINDOW WIPER MOTOR -V12»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__rear-window-wiper-motor-v12) .
2. Spray Nozzle Overview, refer to «FLUID RESERVOIR, LINES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «SPRAY NOZZLE»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzle) .
3. Wiper Arm Overview, refer to «WIPER AND MOTOR OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «WIPER ARM»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arm) .
4. Washer Fluid Reservoir Overview, refer to «FLUID RESERVOIR, LINES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) . Removing and installing, refer to «WASHER FLUID RESERVOIR»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .

Scheme 77

1. Washer Fluid Hose For the rear window washer system.
2. Nut 8 Nm
3. Rear Window Wiper Motor -V12- Removing and installing, refer to «REAR WINDOW WIPER MOTOR -V12»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__rear-window-wiper-motor-v12) .
4. Rubber Seal Removing and installing, refer to «RUBBER SEAL»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__rubber-seal) .
5. Wiper Arm Removing and installing, refer to «WIPER ARM»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-arm) .
6. Nut 12 Nm
7. Spray Nozzle
8. Cap for Rear Wiper
9. Wiper Blade Replacing, refer to «WIPER BLADE»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__wiper-blade) .

Scheme 78

1. Washer Fluid Reservoir Removing and installing, refer to «WASHER FLUID RESERVOIR»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
2. Rear Window Wiper Motor -V12
3. Wiper Arm
4. Spray Nozzle Removing and installing, refer to «SPRAY NOZZLE»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant__spray-nozzle) . Adjusting, refer to «SPRAY NOZZLE, ADJUSTING»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
5. Washer Fluid Hose For the rear window washer system.
6. Retaining Ring For the windshield washer pump.
7. Windshield Washer Pump -V5- Removing and installing, refer to «WINDSHIELD WASHER PUMP -V5»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .
8. Sealing Grommet

Procedure

Scheme 79

Position the wiper arm with the wiper blade installed at the wiper axis and align the wiper blade at the rear window as follows

1. Dimension -a- = 19 + 5 mm.

Note. Dimension is the gap between the tip of the wiper blade and the lower edge of the window.

Tighten the wiper arm nut.

1. Tightening specification, refer to «WIPER AND MOTOR OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .

Turn on the ignition.

Activate the "rear wipe" and let the wiper arm run to the end position.

Check the adjustment of the wiper arm again, correct if necessary.

Special tools and workshop equipment required

1. Windshield Washer Aiming Tool T40187 equipped with Replacement Tip 3125/5A

Procedure

Unlock the short cover -1- on the T40187 -arrow A- and push it back -arrow B-.

Scheme 80

Adjust the spray nozzles with the T40187 so that the fluid is sprayed onto the places shown on the rear window.

Scheme 81

1. Dimension -a- = 150 mm
2. Dimension -b- = 10 mm
3. Dimension -c- = 300 mm

If the spray field does not correspond to the specifications, clean the dirty spray nozzle.

Cleaning the Nozzle

Remove the nozzle. Refer to SPRAY NOZZLE .

Flush the nozzle opposite to the spray direction using clear water.

To remove any remaining impurities, the nozzle must only be blown out opposite to spray direction using compressed air.

If the spray field still does not correspond to the specifications, replace the spray nozzle.

FASTENER TIGHTENING SPECIFICATIONS

Windshield Wiper Motor Bolt Tightening Specification and Sequence

Tighten the bolts -1, 2, 3- in sequence in 2 stages as follows

Tighten the bolts by hand until seated.

Tighten the bolts to 8 Nm.

Washer Fluid Reservoir Bolt Tightening Specifications and Sequence

Tighten the washer fluid reservoir bolts in the sequence specified

Tighten the bolt -3- to 7 Nm.

Tighten the bolt -4- to 7 Nm.

HEADLAMP WASHER PUMP

Special tools and workshop equipment required

1. Hose Clamp Pliers V.A.G 1921
2. Drip Tray

Removing

Scheme 82

Remove the washer fluid reservoir. Refer to WASHER FLUID RESERVOIR , but only pull it out until the headlamp washer pump -V11- is accessible.

Place a drip tray under the windshield washer fluid reservoir.

Disconnect the electrical connector -1-.

Remove the washer fluid hose -3- from the headlamp washer pump.

Remove the headlamp washer pump -item 2- upward out of the washer fluid reservoir.

Installing

Install in reverse order of removal, observing the following

Note. Secure all hose connections using standard hose clamps.

Check the sealing grommet for damage.

Install the washer fluid reservoir. Refer to WASHER FLUID RESERVOIR .

WASHER FLUID RESERVOIR

Note. The shared windshield and headlamp washer system washer fluid reservoir is located in the left rear wheel housing. Removing and installing, refer to WASHER FLUID RESERVOIR .

SPRAY NOZZLES

Special tools and workshop equipment required

1. Hose Clamps Up to 25 mm Diameter 3094

Removing

Scheme 83

Remove the air intake grille. Refer to Removal and Installation .

Open the cover -7- for the spray nozzle.

Press down the tension springs -4, 6- with a flathead screwdriver to release the spray nozzle -5-.

Remove the spray nozzle from the mount -3- towards the rear -arrow-.

Clamp off the windshield washer fluid hose -1- with hose clamps 3094.

Scheme 84

Note. Lay a cloth under the point of separation to catch any washer fluid.

Pull the release button -1- to remove the washer fluid hose -2-.

Note. If the spray nozzle cannot be removed depending on the vehicle equipment level, then remove the corresponding headlamp housing. Remove the headlamp housing

1. Halogen Headlamps: through MY 12, refer to «HEADLAMP»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant__headlamp) , from MY 13, refer to «HEADLAMP»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant) .
2. HID Headlamps: through MY 2012, refer to «HEADLAMP»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant) ; from MY 2013, refer to «HEADLAMP»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant) .

Installing

Scheme 85

Install in reverse order of removal, observing the following

The retaining springs -3 and 4- on the spray nozzle -2- can only engage audibly if the side guide -1- is seated correctly in the mount -5-.

Install the air intake grille. Refer to Removal and Installation .

WINDSHIELD WIPER AND WASHER SYSTEM

Observe the notes on contact corrosion. Refer to CONTACT CORROSION .

WIPER BLADE, REPLACING

Removing

Scheme 86

Bring windshield wiper into the service position. Refer to WIPERS, BRINGING INTO SERVICE POSITION .

Lift off the wiper arm from the front windshield.

Press the retaining clip -arrow A-.

Push the wiper blade -1- off the wiper arm -2- -arrow B-.

Remove the wiper blade.

Installing

Install in reverse order of removal, observing the following

Guide the wiper blade -1- parallel into the wiper arm -2- -arrow-. Slide the wiper blade on until the retaining clips engage in the wiper arm.

Scheme 87

If the windshield wiper switch is operated or a speed of 6 km/h (4 mph) is exceeded, the wipers leave the "service position".

WIPER ARMS

Special tools and workshop equipment required

1. Puller T10369

Removing

Note. If the windshield wiper motor is to be run during this procedure, the hood must be closed, otherwise the voltage supply of the wiper motor will be interrupted.

Bring the windshield wiper into the service position. Refer to WIPERS, BRINGING INTO SERVICE POSITION .

Turn off the ignition and remove the ignition key.

Using a screwdriver, pry the caps -arrows- off the wiper arms -1-.

Loosen the nut -2- several turns.

Install the T10369/1 on the wiper arm -1- as illustrated.

Scheme 88

Position the thrust piece -2- on the wiper axis.

Rotate the bolt -3- clockwise until the wiper arm is removed from the axis.

Remove the nut completely and remove the wiper arm.

Installing

Install in reverse order of removal, observing the following

Adjust the wiper arms. Refer to WIPER ARM, ADJUSTING .

WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE

Special tools and workshop equipment required

1. Removal Lever 80-200

Removing

Scheme 89

Remove the wiper arms. Refer to WIPER ARMS .

Vehicles through 05.08

Remove the seal -arrow-.

Unclip the plenum chamber cover -1 through 3- and remove it.

Vehicles from 06.08

Scheme 90

Remove the bolts -3-.

Remove the clips -2- from the mounts and remove the plenum chamber cover -1-.

Continuation for All Vehicles

Scheme 91

Remove the securing clips -2- -arrow A-.

Remove the cowl panel trim -1- by carefully removing it from the retainer on the windshield -B arrows-.

Disconnect the electrical connector -2-.

Scheme 92

Remove the drain channel -3- on the linkage -arrow A-.

Remove the bolts -4, 5 and 6-.

Rotate the wiper arm frame -1- with the linkage and wiper motor upward -arrow B- and pull it forward out of the plenum chamber.

Installing

1. Tightening specifications, refer to «Windshield Wiper Motor - Tightening Specification and Sequence»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .

Install in reverse order of removal, observing the following

Insert the wiper motor with wiper frame into vehicle.

Tighten the bolts, refer to WIPER SYSTEM OVERVIEW .

Position the water drain channel on the wiper motor.

Adjust the wiper arms. Refer to WIPER ARM, ADJUSTING .

WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE, REPLACING

Procedure

If the control module was replaced, select the "Replace" function for the respective control module in "Guided Fault Finding" or "Guided Functions" using the Vehicle Diagnostic Tester.

WASHER FLUID RESERVOIR FILLER NECK

Removing

Vehicles through 05.08

Remove the seal -arrow- near the windshield wiper fluid reservoir filler tube.

Unclip the plenum chamber cover -3- and remove it.

Note. Ignore items -1 and 2-.

Vehicles from 06.08

Remove the bolts -3-.

Remove the clips -2- from the mounts and remove the plenum chamber cover -1-.

Continuation for All Vehicles

Scheme 93

Remove the nut -1- and tilt the washer fluid reservoir filler neck back slightly -arrow A-.

Remove the filler neck -2- with filler tube from the washer fluid reservoir and the body opening -arrow B-.

Installing

Scheme 94

1. Tightening specifications, refer to «WASHER FLUID RESERVOIR, HOSES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .

Install in reverse order of removal, observing the following

Slide the sealing grommet -2- on the filler neck tube -1- as far as the stop.

1. The tab must lie in the opening on the filler tube -arrows-.

Slide the filler neck into the washer fluid reservoir.

Note. Make sure the O-ring is not crushed when sliding it into the washer fluid reservoir.

Special tools and workshop equipment required

1. Drip Tray

Removing

turn off the ignition and remove the ignition key.

Remove the washer fluid reservoir filler neck. Refer to WASHER FLUID RESERVOIR FILLER NECK .

Remove the left front wheel.

Remove the left front wheel housing liner. Refer to Removal and Installation .

Place a drip tray under the windshield washer fluid reservoir.

Scheme 95

Remove the hose coupling -1- from the headlamp washer system fluid line -3- by pulling the release button.

Cut through the cable ties -2 and 4-.

Remove the plastic wedge -5-.

Disconnect the electrical connectors -7 and 8-.

Scheme 96

Release the securing clip and remove the washer fluid lines from the windshield washer system washer fluid pump -9-.

Loosen the wiring harness -2- from the mounts on the washer fluid reservoir.

Remove the bolts -1 and 3-.

Pull the washer fluid reservoir forward slightly and out.

Disconnect the electrical connector -5-.

Loosen the headlamp washer system fluid hose -6- and wiring harness -4- from the mounts on the washer fluid reservoir.

Remove the washer fluid reservoir.

Installing

1. Tightening specifications and sequence, refer to «WASHER FLUID RESERVOIR, HOSES AND NOZZLES OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .

When installing the washer fluid reservoir, make sure the securing tab -1- engages in the mount -2- on the fender.

Install in reverse order of removal, observing the following

Install the left front wheel house liner. Refer to Removal and Installation .

Install the washer fluid reservoir filler neck. Refer to WASHER FLUID RESERVOIR FILLER NECK .

WASHER FLUID LEVEL SENSOR -G33

Special tools and workshop equipment required

1. Drip Tray

Removing

Scheme 97

Turn off the ignition and remove the ignition key.

Remove the left front wheel.

Remove the left front wheel housing liner. Refer to Removal and Installation .

Disconnect the electrical connector -1-.

Place a drip tray under the windshield washer fluid reservoir.

Remove the windshield washer fluid level sensor -item 3- from the washer fluid reservoir -4-.

Installing

Install in reverse order of removal, observing the following

Check the sealing grommet -2- for damage.

Install the left front wheel house liner. Refer to Removal and Installation .

WINDSHIELD WASHER PUMP -V5

Special tools and workshop equipment required

1. Drip Tray

Removing

Scheme 98

Turn off the ignition and remove the ignition key.

Remove the left front wheel.

Remove the left front wheel housing liner. Refer to Removal and Installation .

Disconnect the electrical connector -4-.

Place a drip tray under the windshield washer fluid reservoir.

Release the securing clip -2- in the -direction of the arrow- and remove the washer fluid line -1- from the windshield washer system washer fluid pump.

Remove the windshield washer pump -item 3- upward out of the washer fluid reservoir.

Note. Replace the windshield washer pump bracket if it is damaged. Press the damaged bracket -1- out of the mount in the washer fluid reservoir -2- toward the outside of the vehicle -arrow- using a screwdriver.

Installing

Install in reverse order of removal, observing the following

Check the sealing grommet for damage.

Install left front wheel house liner. Refer to Removal and Installation .

Removing

Scheme 99

Unclip the windshield washer spray nozzle -1- downward from the hood -arrow-.

Release the securing clip -3- in the -direction of the arrow- and remove the washer fluid line -1- from the windshield washer system spray nozzle.

Scheme 100

Disconnect the electrical harness connector -1-, if present.

Installing

Install in reverse order of removal, observing the following

Make sure the securing clip engages audibly in the washer line connection when connecting the line.

Install the spray nozzle into the hood.

WIPER BLADE

Removing

Scheme 101

Lift off the wiper arm from the rear window.

Pull the wiper blade -1- down out of the wiper arm -2- -arrow-.

Installing

Install in reverse order of removal, observing the following

Wiper blade must audibly engage in the wiper arm.

WIPER ARM

Special tools and workshop equipment required

1. Puller T10369

Removing

Turn on the ignition.

Activate the "rear wipe" and let the wiper arm run to the end position.

Turn off the ignition and remove the ignition key.

Carefully expand the cap -arrows- and remove it.

Scheme 102

Carefully pull off the nozzle -2-.

Scheme 103

Loosen the nut -1- one turn.

Place an M6 nut -4- on the nut.

Scheme 104

Position the T10369/1 on the wiper arm -1- as illustrated.

Position the thrust piece -2- on the wiper axis.

Rotate the bolt -3- clockwise until the wiper arm is removed from the axis.

Remove the nut completely and remove the wiper arm.

Installing

Install in reverse order of removal, observing the following

Adjust the wiper arm. Refer to WIPER ARM, ADJUSTING .

REAR WINDOW WIPER MOTOR -V12

Removing

Remove the wiper arm. Refer to WIPER ARM .

Remove the lower luggage compartment lid trim. Refer to Removal and Installation .

Disconnect the electrical connector -2-.

Scheme 105

Release the securing clip -arrow A- and remove the washer fluid line -3- from the spray nozzle connecting pipe.

Remove the nuts -B arrows- and the rear window wiper motor -item 1-.

Installing

1. Tightening specification, refer to «WIPER AND MOTOR OVERVIEW»(/audi/a4/b8-2007-2012/remont/wiperwasher-systems/#wiperwasher-systems-avant) .

Install in reverse order of removal, observing the following

1. Washer fluid hose must engage audibly into nozzle connection.

Install the lower rear lid trim. Refer to Removal and Installation .

Adjust the wiper arm. Refer to WIPER ARM, ADJUSTING .

RUBBER SEAL

Removing

Remove the windshield wiper motor. Refer to REAR WINDOW WIPER MOTOR -V12 .

Pry the rubber seal carefully out of the rear window.

Installing

Scheme 106

Install in reverse order of removal, observing the following

Install the rubber seal -2- into the rear window -1-.

1. The mark -3- must face upward.

Install the windshield wiper motor. Refer to REAR WINDOW WIPER MOTOR -V12 .

Special tools and workshop equipment required

1. Drip Tray

Removing

Scheme 107

Turn off the ignition and remove the ignition key.

Remove the left front wheel.

Remove the left front wheel housing liner. Refer to Removal and Installation .

Disconnect the electrical connector -5-.

Place a drip tray under the windshield washer fluid reservoir.

Release the securing clips -3- in the -direction of arrow- and remove the windshield washer fluid hoses -1 and 2- from the windshield washer pump.

Remove the windshield washer pump -item 4- upward out of the washer fluid reservoir.

Note. Replace the windshield washer pump bracket if it is damaged. Press the damaged bracket -1- out of the mount in the washer fluid reservoir -2- toward the outside of the vehicle -arrow- using a screwdriver.

Installing

Install in reverse order of removal, observing the following

Check the sealing grommet for damage.

Install the left front wheel house liner. Refer to Removal and Installation .

SPRAY NOZZLE

Removing

Carefully expand the cap -arrows- and remove it.

Carefully remove the spray nozzle -2- from the connecting pipe -arrow-.

Scheme 108

Installing

Install in reverse order of removal, observing the following

1. Insert the spray nozzle so the spray opening faces the opening in the wiper arm -1-.

Note. The combined washer fluid reservoir for the front and rear washer systems is located in the left rear wheel housing. Removing and installing, refer to WASHER FLUID RESERVOIR .

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. Windshield Washer Aiming Tool T40187 equipped with Replacement Tip 3125/5A
2. Replacement Tip 3125/5A
3. Hose Clamp Pliers V.A.G 1921
4. Hose Clamps Up to 25 mm Dia. 3094
5. Puller T10369
6. Removal Lever 80 - 200

See also:
• General Information
• Removal and Installation
• Removal and Installation
• Removal and Installation
• HEADLAMP
• HEADLAMP
• Removal and Installation
• Removal and Installation
• RESERVOIR, HOSES AND NOZZLES OVERVIEW
• SPRAY NOZZLES
• WIPER SYSTEM OVERVIEW
• WIPER ARMS
• WIPER MOTOR WITH WIPER MOTOR CONTROL MODULE
• WASHER FLUID RESERVOIR FILLER NECK
• HEADLAMP WASHER PUMP
• CONTACT CORROSION
• WIPER ARM, ADJUSTING
• WIPER BLADE, REPLACING
• SPRAY NOZZLES, ADJUSTING
• WINDSHIELD WASHER PUMP -V5
• WASHER FLUID LEVEL SENSOR -G33
• REAR WINDOW WIPER MOTOR -V12
• SPRAY NOZZLE
• WIPER ARM
• RUBBER SEAL
• WIPER BLADE
• WIPERS, BRINGING INTO SERVICE POSITION
