Rear Doors (sedan) Audi A4 B8

SPECIAL TOOLS AND WORKSHOP EQUIPMENT REQUIRED

1. Adjustment Gauge 3371
2. Template T40038 /8

Note. The >>min and max<< markings are used to check the lateral adjustment. The recess in the center of the template is used for checking the height. The 0.4 mm graduation is used for checking the recess of the front door to the fender, or of the rear door to the front door. the 0.6 mm graduation is used to check the recess of the trim on the B-pillar from the rear door to the front door.

Scheme 62

Note. All dimensions are given in mm. All dimension tolerances are ± 0.5 mm. The parallel alignment of the gap must not exceed 0.5 mm.

1. Dimension G = 5.5 mm
2. Dimension H = 4.5 mm
3. Dimension I= 3.5 mm

Remove the B-pillar trim. Refer to Removal and Installation .

Remove the B-pillar coupling station. Refer to [For engine(s) CAEB, CALA, CCBA] Removal and Installation .

Scheme 63

Loosen the bolts -arrows B- at the top and at the bottom of the hinge and on the A-pillar -1-.

Adjust the door -2- lengthwise.

Tighten the bolts -B arrows-.

1. Tightening specifications. Refer to item 7 .

Height Adjustment

Note. The hinge screws on the door (refer to item 8 ) are fitting screws, therefore it is not necessary to adjust the door using these screws. If it is necessary to make an adjustment using the bolts, the bolt can be replaced with one of the same length and strength category.

Use the T40038 /8 for adjusting.

Place the T40038 /8 in distance -a- = 150 mm and/or -b- = 50 mm.

Scheme 64

When correctly adjusted, the T40038 /8 must contact the roof and trim strip >>point 1<< (-arrows-) as illustrated.

At >>point 2<< the bottom of the window guide must be inside the groove.

2. ADJUSTMENT TO CENTER OF VEHICLE

Loosen the bolts -A arrows- ( 1. Adjustment in Longitudinal Direction ) on the top and bottom of the hinge.

Adjust the door -2- lengthwise.

Tighten the bolts -A arrows-.

For checking, use the T40038 /8

Place the T40038 /8 in distance -a- = 150 mm and/or -b- = 50 mm.

For the >>min<< position, >>points -1- and -3-<< must touch.

>>Point -2-<< may show a gap.

For the >>max<< position, >>points -2- and -3-<< must touch.

>>Point -1-<< may show a gap.

1. Tightening specifications: 45 Nm

Note. The bolt is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category.

Scheme 65

Note. Only work from the center of the vehicle out when adjusting at the striker pin. Do not adjust the door height using the striker pin because the door lock will be damaged.

Loosen the bolts -2-.

Slide the striker pin -1- until the door is flush with the body contours.

Striker pin must align in door lock center for correct adjustment.

Tighten the bolts -2-.

Scheme 66

1. Door Check
2. Rubber Grommet
3. Bolt 8 Nm
4. Cover
5. Grommet
6. Bolt 8 Nm

Removing

Scheme 67

Close the window.

Remove the door trim. Refer to Removal and Installation .

Remove the lower speaker. Refer to Removal and Installation .

Remove the door arrester bolt -arrow-.

Remove the door check seal -1- on the door opening.

Scheme 68

Remove the bolt -arrows- and remove the door check -2- inward.

Pull the rubber grommet -1- on the door check to the side -arrows A-.

Scheme 69

Remove the rubber grommet from the door check -2- -arrow B-.

Installation

1. Tightening specifications, refer to item 3 .

To install, perform the steps used in removal in reverse order.

Scheme 70

1. Outside Door Handle NOTE: On vehicles with "keyless entry system" rear outside door handle touch sensors >>G 417/418<< are located in outside door handle. Before installation, front and rear backing installed in door outer panel. Removing and installing, refer to «OUTER DOOR HANDLE»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__outer-door-handle) .
2. Bolt 2.5 Nm
3. Front Backing
4. Rear Backing
5. Cover Unclip prior to removing the door handle.
6. Bolt 19 Nm
7. Door Lock Removing and installing, refer to «DOOR LOCK»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__door-lock) .
8. Mounting Bracket Rear backing -5- slid into outer door panel. To install, engage mounting bracket with loosely installed screw -10- in door, slide forward and tighten screw to 2.5 Nm.
9. Actuating Link Engage in door lock.
10. Housing Before installing, attach cover cap -7-. Removing, refer to «OUTER DOOR HANDLE»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__outer-door-handle) .
11. Magnet For vehicles with the "keyless entry system".
12. Cover Removing and installing, refer to «REMOVE THE HOUSING CAP»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) .
13. Outer Door Handle Trim For vehicles without the "keyless entry system". Removing and installing, refer to «OUTER DOOR HANDLE TRIM»(/audi/a4/b8-2007-2012/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-sedan__outer-door-handle-trim) .
14. Door Handle Sensor For vehicles with the "keyless entry system". Removing and installing, refer to «REAR OUTSIDE DOOR HANDLE TOUCH SENSOR»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__rear-outside-door-handle-touch-sensor) .

Scheme 71

1. Door Lock Removing and installing, refer to «DOOR LOCK»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__door-lock) .
2. Door
3. Door Opener Actuating Link
4. Electrical Connection
5. Bolt Torque specification, refer to item 3 .
6. Cover

Scheme 72

1. Door
2. Outer Window Shaft Strip Removal: Door trim removed, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . -- Run door window all the way up. -- Remove shaft strip upward.
3. Inner Window Shaft Strip Removal: Door trim removed, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . -- Remove shaft strip upward.
4. Clip 3x

Scheme 73

1. Door
2. Bolt 8 Nm
3. Door Check Removing and installing, refer to «DOOR CHECK OVERVIEW»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) .
4. Cover Mount on the stud bolt.
5. Stud Bolt 30 Nm
6. Upper Door Hinge
7. Bolt 32 Nm
8. Bolt NOTE: The bolt is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category. 45 Nm
9. Bolt 32 Nm
10. Bottom Door Hinge

Scheme 74

1. Striker Pin Removing and Installing, refer to «STRIKER PIN»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__striker-pin) .
2. Bolt 25 Nm
3. Bolt 19 Nm
4. Door Lock Actuating Link CAUTION: There is a risk of malfunctions. The door lock must be removed and installed together with the bracket to prevent overbending the cable when disengaging and engaging it. The cable must be disconnected from/attached to the Lever on the door lock outside of the door.
5. Door Lock Removing and installing, refer to «DOOR LOCK»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__door-lock) .
6. Door Opener Actuating Link Removing and installing, refer to «DOOR OPENER ACTUATING LINK»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__door-opener-actuating-link) .
7. Grommet Cannot be replaced separately.

Scheme 75

1. Door
2. Window Regulator Removing and installing, refer to «WINDOW REGULATOR»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) .
3. Clip
4. Door Window Removing and installing, refer to «FRONT DOOR WINDOW»(/audi/a4/b8-2007-2012/remont/windows/#glass-window-regulators-sedan) .
5. Nut 9 Nm
6. Window Regulator Motor Removing and installing, refer to «WINDOW REGULATOR MOTOR»(/audi/a4/b8-2007-2012/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-sedan) .
7. Bolt 3.5 Nm Quantity: 3

Removing

Scheme 76

Disconnect the connectors on the A-pillar. Refer to [For engine(s) CAEB, CALA, CCBA] Removal and Installation .

Remove the door arrester bolt -2-.

Remove the cover caps -1- and -3- from the stud bolts.

Remove the stud bolts -4- on the upper and lower door hinge.

Carefully remove the door upward out of the door hinges.

Installation

Note. Do not make any adjustments after installing the door.

Scheme 77

1. Cover -- Remove the door trim. Refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . -- Remove the electrical wiring harness -4- from the bracket -5-. -- When removing the cover, always start at the top.
2. Grommet When installing, it must fit correctly -arrows-.
3. Door Inner Panel
4. Cable
5. Electrical Wiring Disengage from the bracket -6-.
6. Bracket

DOOR LOCK

Removing

Remove housing. Refer to HOUSING .

Remove the door trim. Refer to Removal and Installation .

Remove the inner door panel cover. Refer to DOOR INNER PANEL COVER .

Scheme 78

Turn the operating cable on the Lever -1- 90° in the -direction of arrow A- and remove it from the bracket -2-.

Rotate the actuating link on the door lock operating Lever -3- in the -direction of arrow B-.

1. The actuating link must be aligned with the opening on the operating Lever.

Disengage the actuating link from the operating Lever.

Remove the bolts -arrows-.

Scheme 79

Remove the door lock -1- and disconnect the electrical connector -2-.

Installation

Scheme 80

To install, perform the steps used in removal in reverse order.

Engage the actuating link -3- in the door lock operating Lever -2-.

Insert the operating cable into the cable mounting bracket -1- and rotate the Lever -4- 90° -arrow-.

1. The Lever must engage audibly with the locking tab on the cable mounting bracket.

REMOVING

Remove the door trim. Refer to Removal and Installation .

Remove the inner door panel cover. Refer to DOOR INNER PANEL COVER .

Turn the actuating link on the Lever -1- 90° in the -direction of arrow A- and remove it from the cable bracket -2-.

Rotate the actuating link on the door lock operating Lever -3- in the -direction of arrow B-.

1. The actuating link must be aligned with the opening on the operating Lever.

Disengage the actuating link -1- on the operating Lever by pressing the bracket -3- out of the mount on the cable mounting bracket -2- -arrow-.

Scheme 81

Remove the operating shaft.

INSTALLATION

To install, perform the steps used in removal in reverse order.

Engage the actuating link -3- in the door lock operating Lever -2-.

Insert the operating cable into the cable mounting bracket -1- and rotate the Lever -4- 90° -arrow-.

1. The Lever must engage audibly with the locking tab on the cable mounting bracket.

DOOR OPENER ACTUATING LINK

Removing

Remove housing. Refer to HOUSING .

Remove the door trim. Refer to Removal and Installation .

Remove the inner door panel cover. Refer to DOOR INNER PANEL COVER .

Remove the bolts -arrows-.

Press the door lock -1- to the side and disconnect the electrical connector -2- if necessary.

Disengage the actuating link -3- at the door lock cable bracket -2- -arrow A-.

Scheme 82

Turn the nipple -1- 90° in the -direction of arrow B- and remove it from the door opener release Lever -4-.

Installation

Scheme 83

Installation is reverse of removal, but note the following

Insert the nipple -2- in the door opener release Lever -3- -bottom arrow-.

Rotate the nipple 90° -top arrow- and press the actuating link into the cable mounting bracket on the door lock -1- until it engages audibly.

1. Roller 3356
2. Adhesive Strip Remover VAS 6349
3. Adjustment Gauge 3371
4. Template T40038 /8

Scheme 84

1. Inner Door Seal Remove the window frame trim. Refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . Loosen door arrester on the B-pillar. Connected all around on body flange To remove, remove from body flange. When installing, align the seal with the center of the vulcanized joint on the lower hinge and press it by hand onto the body flange.
2. Door

REPLACING OUTER DOOR SEAL

Note. The door outer seal is completely bonded and can only be replaced. Adhesion surfaces must be free of dust and grease. Both the vehicle and the seal must be room temperature.

Scheme 85

1. Outer Door Seal NOTE: Before removing, mark the position on the door, for example, with adhesive tape. Make sure there is no adhesive left on the door, first pull the seal lengthwise and then pull it off the door. -- Slightly lift the seal at the top of the window frame and cut it with scissors. Removing -- First pull the seal lengthwise, then remove it. Refer to «REMOVING DOOR SEAL»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) . Installation -- Clean the surface with cleaning solutionD 009 401 04. Use an adhesive strip remover VAS 6349 to remove any adhesive still remaining if necessary. -- Loosen the door check on the body. Refer to «REMOVE DOOR CHECK»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__remove-door-check) . -- Pull the door seal behind the door check. -- Secure the door check again. -- Secure the door outer seal to the top of the window frame on the left and on the right correctly with tape, refer to item 2 . -- The water drain (2x) is in the correct position when it is found in the lower outer door seal on the underside of the door. NOTE: It is necessary to press the door outer seal starting in the center and the working outward left and right in steps. -- Remove the peel-off backing near the bottom of the door. -- Press the door outer seal starting in the center and working outward left and right. -- Continue to remove the peel-off backing little by little and press the door outer seal onto the door. -- Press the door outer seal upward along the A-pillar and B-pillar. -- Press the door outer seal along the window frame. CAUTION: Do not stretch or crush the seal when installing it. The seal will come off wherever it is stretched or crushed along the bottom or on the A- or B-pillar. The door outer seal can be bent or crushed only in the are around the top of the window frame because window frame cover will hold it place. -- Press the end of the door outer seal, item 2 with a 3356. CAUTION: Do not close the door for at least 2 hours to prevent loosening or moving the door outer seal. The vehicle must be at room temperature.
2. Door

REMOVE DOOR CHECK

Remove the door check bolt -arrow-.

Pull the seal behind the door check and tighten the screw to the tightening specification, refer to item 6 .

Scheme 86

Mark the location of the door seal and adhesive strips on the window frame...

Scheme 87

... and to the door lock as illustrated.

Scheme 88

Note. Pulling the seal laterally will loosen the adhesive and then it is possible to remove the door outer seal from the window frame without any left over adhesive on it.

Bend and remove the door seal laterally as illustrated -arrow-.

Proceed the same way all around and remove the door seal completely.

Remove any left over adhesive on the window frame with VAS 6349.

MARK THE POSITION OF THE DOOR SEAL

Mark the position of the seal on the window frame with adhesive tape and...

... around the door lock

Remove Seal

Bend the seal -1- and then remove it from the door.

Note. By bending the seal, the adhesive will be loosened and then the seal can be removed free of any adhesive.

DOOR OUTER SEAL ON A NEW DOOR

Note. The seal must be pressed over the complete radius (inner and outer) as illustrated -arrows-. To make it easier to install, mark these positions and then press the seal on. Adhesive areas on the inner and outer radius. Refer to ADHESIVE AREA FOR THE DOOR SEAL .

Scheme 89

1. Outer Door Seal After marking the radius run-out, continue to install in the previously described manner, refer to «REPLACING OUTER DOOR SEAL»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan__replacing-outer-door-seal) . Starting from the lower rear edge of the door toward the front lower door edge, mount the door seal with the rear edge on the inner radius run-out, as illustrated. The front edge of the seal must be placed on the run-out of the outer radius at the bottom of the door up to the imprint. -- Press the seal secure with a 3356 refer to item 2 .
2. Door

Scheme 90

1. The rear edge of the seal must be placed on the run-out of the inner radius starting in area -A- from the door lock up to the lower door hinge.
2. In area -B- the front edge of the seal must be placed on the run-out of the outer radius.
3. The seal must be laid evenly from the run-out of the inner radio to the run-out of the outer radio in area -C-.

Scheme 91

1. Rear Door
2. Outer Door Seal -- Tape the door outer seal to the top of the window frame first -arrows-. CAUTION: Only use 3356 to press the door outer seal onto the seal base. -- Fold up the door outer seal as illustrated and then press it onto the seal base using force and 3356 all the way around.

Scheme 92

1. Cover Removing from the housing. Refer to «REMOVE THE HOUSING CAP»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) .
2. Magnet For vehicles with the "keyless entry system".
3. Housing Remove the screw from the clip. -- Using a screwdriver, press the retaining bracket and then remove the lock cylinder and cap.

Removing

Scheme 93

Press the door seal to the side and remove the protective film over the hole -arrow A-.

Remove the locking bolt -4- as far as the stop using a screwdriver -1-.

Press the housing retaining bracket -3- inward.

Remove the housing -2- from the mounting bracket -arrow B-.

Installation

To install, perform the steps used in removal in reverse order.

Scheme 94

Remove housing. Refer to HOUSING .

Spread the clips -arrows- and remove the cover cap -1- from the housing -2- using an awl if necessary.

Installation

Installation is reverse of removal, but note the following

Press the housing cover cap on until it engages audibly.

OUTER DOOR HANDLE

Removing

Press the door outer seal to the side and remove the protective film over the hole -arrow A-.

Remove the locking bolt -4- as far as the stop using a screwdriver -1-.

Pull the outer door handle outward and hold it in the "opened" position.

Press the housing retaining bracket -3- inward, the outer door handle is secured in the "opened" position.

Remove the housing -2- from the mounting bracket -arrow B-.

Pull the outer door handle -1- in the -direction of the arrow-. This disengages the handle from the operating Lever in the mounting bracket.

Scheme 95

Tilt the outer door handle -1- outward -arrow- and remove it from the mount on the mounting bracket.

Scheme 96

In vehicles with the "keyless entry system", disconnect the electrical connector -2- on the outer door handle.

Installation

Scheme 97

Installation is reverse of removal, but note the following

Replace the outer door handle washers -1- and -2- if damaged or brittle.

Insert the outer door handle -1- -arrow A-. It must engage in the mount -2- on the mounting bracket -3-.

Scheme 98

Tilt the outer door handle -1- in the -direction of arrow B- and slide the >>coupling plate<< -5- into the mounting bracket in front of the operating Lever -4-.

Press the housing retaining bracket onto the outer door handle.

Install housing. Refer to HOUSING .

OUTER DOOR HANDLE TRIM

In vehicles without "keyless entry", trim installed instead of the outer door handle touch sensor.

Removing

Scheme 99

Remove the outer door handle.

Pry the outer door handle trim -2- out using an awl -1- at the location shown in the illustration -arrow-.

Remove the outer door handle trim from the handle -3-.

Installation

Installation is reverse of removal, but note the following

Slide the outer door handle trim in until it engages audibly.

Install the outer door handle.

Install housing. Refer to HOUSING .

REAR OUTSIDE DOOR HANDLE TOUCH SENSOR

Remove the outer door handle -2- and sensor -1-. Refer to OUTER DOOR HANDLE .

Scheme 100

Using a small screwdriver, carefully release the latches at the arrows - A and B- and push the connector -3- and the wiring guide to the side.

Scheme 101

Insert a screwdriver in front of the sensor as illustrated.

With light force on the screwdriver, pry out the sensor form the outer door handle.

Remove the sensor from the door outer handle.

STRIKER PIN

Removing

Remove the bolts -2- and the striker pin -1-.

Installation

To install, perform the steps used in removal in reverse order.

Note. The striker pin backing must be position with the pins -arrows- exactly in the hole. The striker pins must be sheared off cleanly after sliding the striker pin. If a new part is being installed, then remove the sheared off pins from the striker pin.

Adjust the striker pin (Scheme 65).

1. Pry Lever 80 -200

Remove the door trim. Refer to Removal and Installation .

Remove the inner door panel cover. Refer to DOOR INNER PANEL COVER .

Turn the actuating link on the Lever -1- 90° in the -direction of arrow A- and remove it from the cable bracket -2-.

Rotate the actuating link on the door lock operating Lever -3- in the -direction of arrow B-.

1. The actuating link must be aligned with the opening on the operating Lever.

Disengage the actuating link from the operating Lever.

Remove the outside door handle. Refer to OUTER DOOR HANDLE .

Disengage the electrical wire on the mounting bracket -arrow- if applicable.

Scheme 102

Free up the electrical wire spiral clip -1- using the 80-200.

Note. Use a soapy solution if necessary make removal easier.

Remove the bolt -3- and the mounting bracket -2-.

Installation is reverse of removal, but note the following

Engage the actuating link -3- in the door lock operating Lever -2-.

Insert the operating cable into the cable mounting bracket -1- and rotate the Lever -4- 90° -arrow-.

1. The Lever must engage audibly with the locking tab on the cable mounting bracket.

Scheme 103

1. Window Guide Remove the door trim panel and the window frame trim. Refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . B-pillar and C-pillar trim removed, refer to «REAR B-PILLAR AND C-PILLAR TRIM»(/audi/a4/b8-2007-2012/remont/mirrors/#exterior-equipment-sedan) . Door window removed. Refer to «REAR DOOR WINDOW»(/audi/a4/b8-2007-2012/remont/windows/#glass-window-regulators-sedan) . -- Beginning at the window guide on the window frame, remove the side B-pillar and C-pillar from the door. -- Remove the window guide from the door. For easier installation, coat window guide with a soap solution. Push the window guide into the guide shafts as illustrated. Press the window guide with the latching tabs into the door.
2. Door
3. Door Window Removing and installing. Refer to «REAR DOOR WINDOW OVERVIEW»(/audi/a4/b8-2007-2012/remont/windows/#glass-window-regulators-sedan) .

Scheme 104

1. Electrical Connection -- Disconnect the connector on the door control module.
2. Window Regulator Motor NOTE: The window regulator motor can be removed or installed with the motor or door window in any position. Removing -- Remove the door trim. Refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . -- Remove the screws -6- and remove the window regulator motor from the window regulator. Installation Tightening specifications, refer to «WINDOW REGULATOR MOTOR AND WINDOW REGULATOR OVERVIEW»(/audi/a4/b8-2007-2012/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-sedan) . Installation is reverse of removal, but note the following: The clips -arrow- for the window regulator threaded pins must be latched into the inner door panel. -- Mount the window regulator motor on the threaded pins and tighten the screws -6-. NOTE: With the window regulator motor switches connected, switch the ignition on and run the door windows up to the stop. Continue holding the window regulator switch for approximately 2 seconds so the basic setting and one-touch up/down function are activated.
3. Threaded Pins
4. Window Regulator
5. Bolt

Scheme 105

1. Window Regulator Removing Door trim removed. Refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exteriorinterior-trim/#interior-trim-sedan) . Window regulator motor removed. Refer to «WINDOW REGULATOR MOTOR»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) . Door glass removed. Refer to «FRONT DOOR WINDOW»(/audi/a4/b8-2007-2012/remont/windows/#glass-window-regulators-sedan) . The door inner panel cover is removed. Refer to «DOOR INNER PANEL COVER»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) . -- Release the window regulator motor threaded pins and push it through the inside panel. Refer to «THREADED PIN RELEASES»(/audi/a4/b8-2007-2012/remont/windows/#rear-doors-sedan) . -- Only loosen the upper nut. -- Remove the lower nut and lift the window regulator upward and out of the door.
2. Door
3. Nut Loosen only for removing the window regulator.
4. Nut Remove when removing the window regulator.

Scheme 106

Release the clips -arrow- on the window regulator threaded pins -3- using an 11 mm socket by sliding the socking onto the threaded pins.

Remove the clip -1- for the cable -2- from the inner side of the cable guide -1-.

Upper connecting point for the window regulator

Scheme 107

To remove the window regulator -1- only remove the nut -2-.

WINDOW SHAFT STRIP

Special tools and workshop equipment required

1. 3 x Removal hook T40219

Removing

Open the window.

Door trim removed. Refer to Removal and Installation .

Remove the C-pillar trim.

Before the window shaft strip -1- can be removed, first disconnect it from the door hook s -arrows-.

Scheme 108

Insert the first T40219 between the door window and the window shaft strip at the C-pillar trim between the outer window shaft strip and the door window.

Scheme 109

Move the T40219 toward the rear to -dimension a-.

Pull the T40219 upward and slide it into place into the window shaft strip.

Note. The mark on the removal hook T40219 must line up with the upper edge of the window shaft strip.

Insert the second T40219 between the door window and the window shaft strip at the C-pillar trim.

Move the second T40219 to -dimension b- and fit it in from underneath.

Insert the third T40219 at the C-pillar trim and move it to -dimension c-.

1. The specified dimensions on the window shaft strip are measured starting at the B-pillar.

1. Dimension -a- = 605 to 640 mm.
2. Dimension -b- = 425 to 460 mm.
3. Dimension -c- = 605 ••• 640 mm.

Gently push the T40219 outward and release the window shaft strip.

Scheme 110

Release the window shaft strip in stages and then remove it from the door flange.

Scheme 111

Installation

1. Beginning at the B-pillar, press the window shaft strip into the retaining hook s in the door.

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

1. Roller 3356
2. Adhesive Strip Remover VAS 6349
3. Adjustment Gauge 3371
4. Template T40038 /8
5. Removal Hook T40219
6. Pry Lever 80 - 200

See also:
• Removal and Installation
• [For engine(s) CAEB, CALA, CCBA] Removal and Installation
• Removal and Installation
• OUTER DOOR HANDLE TRIM
• FRONT DOOR WINDOW
• WINDOW REGULATOR MOTOR
• REAR B-PILLAR AND C-PILLAR TRIM
• 1. Adjustment in Longitudinal Direction
• OUTER DOOR HANDLE
• DOOR LOCK
• REAR OUTSIDE DOOR HANDLE TOUCH SENSOR
• STRIKER PIN
• DOOR OPENER ACTUATING LINK
• INSTALLATION
• REMOVE DOOR CHECK
• REPLACING OUTER DOOR SEAL
