Engine Controls - on Board Diagnostic (OBD) -1.8l 5v Turbo, Amb Audi A4 B7

Features

1. Data transfer between control module and vehicle diagnostic, testing and information system VAS 5051 is carried out in "self-diagnosis" mode.
2. Diagnostic Trouble Code (DTC) memory: Non-volatile and volatile memories.
3. Display of stored DTCs occurs after initiation of display mode. Go to «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .
4. DTC memory must be erased after malfunction is repaired. Go to «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, ERASING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb__diagnostic-trouble-code-dtc-memory-erasing) .

Malfunction Indicator Lamp (MIL) -K83- in instrument cluster

If the engine control module (ECM) detects malfunctions which result in deterioration of exhaust emissions, these malfunctions will be indicated by illumination of exhaust gas warning lamp.

After switching on the ignition the ECM switches on the Malfunction Indicator Lamp (MIL) -K83-. Shortly after starting the engine, the MIL goes out if the ECM does not detect a malfunction through a deterioration of the exhaust emissions, and if the ECM activation of the lamp is ok.

If DTCs which cause the exhaust emission to deteriorate are detected when operating the engine, the ECM switches on the MIL. (These DTCs are listed in the DTC table). At the same time, an entry is made in the ECM DTC memory.

When switched on, the MIL may flash or illuminate constantly. In any case the DTC memory must be checked. Go to DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING .

Continuous illumination

A malfunction is present which causes deterioration of the exhaust emission. Check DTC memory for ECM or automatic transmission (if available).

If there is a drive problem or a customer concern and the MIL is not illuminated the DTC memory must be checked. DTCs which do not switch on the MIL immediately, but only after recognizing the malfunction after restarting the engine, can also be stored.

Flashing

A malfunction is present which under these driving conditions will cause damage to the Three Way Catalytic Converter (TWC) (e.g. misfiring). In this case driving may only continue at reduced power.

Functional check on MIL

1. Switch ignition on. The Malfunction Indicator Lamp (MIL) -K83- for self-diagnosis must illuminate.
2. Start engine. Shortly after starting the engine the MIL goes out if no exhaust emission related DTC is stored in the DTC memory.

Note. The switch-on signal for the MIL is transferred via CAN-bus to the instrument cluster by the ECM. Check the data exchange between ECM and other CAN-bus control modules. Go to DATA EXCHANGE, MOTRONIC / ABS (CAN-BUS), CHECKING .

Safety precautions

Note the following points if testers and measuring instruments have to be used during a road test

Test requirements

1. Fuses for engine electronics OK See appropriate System Wiring Diagrams article.
2. Battery voltage at least 12.7 V
3. Ground (GND) connections at engine and transmission OK.

Procedure

1. Switch ignition off.
2. Connect VAS 5051 with diagnostic wire VAS 5051/1.

Note. A malfunction message appears on the display

Display on VAS 5051

Scheme 1

1. Press "vehicle self-diagnosis" button.

Display on VAS 5051

Scheme 2

Note. The automatic test sequence is carried out by pressing "00 - Check Diagnostic Trouble Code (DTC) memory - Total system" in selection -1-, i.e. the Diagnostic Trouble Code (DTC) memories of all vehicle systems with self-diagnosis capability are checked.

Display on VAS 5051

Scheme 3

Depending on which function is required. Go to DIAGNOSTIC FUNCTIONS REFERENCE .

1. Switch ignition on.

or

1. Start engine.
2. Select vehicle system "01 - Engine electronics" in selection -1-.
3. Wait until next display appears.

Display on VAS 5051

Scheme 4

1. Control module identification of the Engine Control Module (ECM). Go to «CONTROL MODULE IDENTIFICATION ENGINE CONTROL MODULE (ECM)»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .
2. Control module identification of the Immobilizer. Go to «CONTROL MODULE IDENTIFICATION, IMMOBILIZER»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb)

CONTROL MODULE IDENTIFICATION ENGINE CONTROL MODULE (ECM) - EXAMPLE

CONTROL MODULE IDENTIFICATION, IMMOBILIZER (EXAMPLE)

1. Press > button.

Display on VAS 5051

Scheme 5

1 - Selection of diagnostic functions

DIAGNOSTIC FUNCTIONS REFERENCE

Diagnostic Trouble Code (DTC) memory, checking

1. Connect vehicle diagnostic, testing and information system VAS 5051. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics" in selection. Engine should be idling.

Note. If the engine will not start, crank it for at least 5 seconds with the starter and then always leave the ignition on.

Display on VAS 5051

Scheme 6

1. Under -1- select diagnostic function "02 - Check Diagnostic Trouble Code (DTC) memory".

Display on VAS 5051

Scheme 7

1. Content of the Diagnostic Trouble Code (DTC) memory: 0 Faults recognized or X Faults recognized
2. DTCs DTC code DTC location DTC type

Scheme 8

1. If malfunctions were recognized: Print out screen content or self-diagnosis report. Exit function "02 - Check Diagnostic Trouble Code (DTC) memory" by pressing < button. Display on VAS 5051: Repair malfunction(s) as specified in DTC table. Go to «DIAGNOSTIC TROUBLE CODES (DTC): P0011 TO P1228, VAG 16395 TO 17636»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb__diagnostic-trouble-codes-dtc-p0011-to) . Reselect diagnostic function "02 - Check Diagnostic Trouble Code (DTC) memory" and erase DTC memory. Go to «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, ERASING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb__diagnostic-trouble-code-dtc-memory-erasing) . Select diagnostic function "06 - End output" in selection. Go to «ENDING OUTPUT»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb__ending-output) .
2. If no malfunction was recognized: Select diagnostic function "06 - End output" in selection. Go to «ENDING OUTPUT»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb__ending-output) .

Diagnostic Trouble Code (DTC) memory, erasing

Note. If it is not possible to erase DTC memory, check it once again and repair malfunctions.

Preconditions

1. Diagnostic Trouble Code (DTC) memory checked. Go to «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .
2. All malfunctions repaired.

After DTC memory has been successfully checked

Display on VAS 5051

Scheme 9

1. Under -1- select diagnostic function "05 - Erase Diagnostic Trouble Code (DTC) memory".

Display on VAS 5051

Scheme 10

1. No display (before erasing) or Diagnostic Trouble Code (DTC) memory erased NOTE: The following message appears in display zone -1-: "Diagnostic Trouble Code (DTC) memory not yet checked", if the operational sequence was not exactly performed. The Diagnostic Trouble Code (DTC) memory can only be erased, if the Diagnostic Trouble Code (DTC) memory has been checked beforehand.
2. Note: Is the function to be carried out? Note: Data will be erased!

1. Press -OK- button in display -2-.
2. Exit function "05 - Erase Diagnostic Trouble Code (DTC) memory" by pressing < button.
3. Check Diagnostic Trouble Code (DTC) memory again after performing repairs.

Note. This erases malfunctions that have been stored while the malfunction was being repaired, for example, malfunctions that have arisen as a result of connectors being disconnected.

Ending output

Display on VAS 5051

Scheme 11

1. Under -1- select diagnostic function "06 - End output".

Display on VAS 5051

Scheme 12

1. Switch off ignition when this display appears and disconnect diagnostic connector.

Diagnostic Trouble Code (DTC) Table

Note. If malfunctions occur in the monitored sensors and components, these are stored in the Diagnostic Trouble Code (DTC) memory together with an indication of type of malfunction. Malfunctions related to EPC are additionally indicated by the warning lamp for the electronic throttle control ("EPC warning lamp") which is situated in the instrument cluster. Notes on EPC system. Go to ELECTRONIC POWER CONTROL (EPC) SYSTEM, CHECKING . Malfunctions that worsen emissions are indicated by an exhaust warning lamp (MIL) that is also located in the instrument cluster. There are malfunctions that cause the exhaust warning lamp to light up immediately after recognition. Malfunctions can also occur that cause the exhaust MIL to light up, but only if malfunction is recognized again after repeated engine starts. Notes for exhaust warning lamp (MIL). Go to MALFUNCTION INDICATOR LAMP (MIL) -K83- IN INSTRUMENT CLUSTER . Malfunctions which cause the exhaust emission to deteriorate are displayed with an exhaust warning lamp in the instrument cluster. Notes on exhaust warning lamp. Go to MALFUNCTION INDICATOR LAMP (MIL) -K83- IN INSTRUMENT CLUSTER . The malfunction table is sorted according to the 5-digit DTC on the left. Sporadic malfunctions (malfunction occurring from time to time) are indicated as "sporadic" on the display. The word "sporadic" signifies individually occurring, random malfunctions. Do not immediately replace components indicated as faulty by the VAS 5051 but: first check the wiring and connectors of these components against the wiring diagram. Also check the ground (GND) connections against wiring diagram. This is particularly relevant for DTCs recorded as "sporadic." If the connector is pulled off the engine control module or if the battery is disconnected, all the stored values in the control module will be erased. However, the contents of the Diagnostic Trouble Code (DTC) memory are retained. If the engine is then started, it may run rough for a short period. In this case, the engine should be run at idle for a few minutes until the adaptation process is concluded. After erasing the Diagnostic Trouble Code (DTC) memory. Go to DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING . The readiness code must be regenerated. Go to READINESS CODE, GENERATING .

Diagnostic Trouble Codes (DTC): P0011 to P1228, VAG 16395 to 17636

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0011-P0106

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0112-P0133

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0136-P0238

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0300-P0322

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0327-P0411

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0420-P0507

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0420-P0563

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P0571-P1103

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1105-P1116

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1117-P1128

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1136-P1137

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1147-P1150

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1171-P1204

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1213-P1228

Diagnostic Trouble Codes (DTC): P1237 to P3081, VAG 17645 to 18339

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1237-P1250

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1287-P1291

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1292-P1298

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1325-P1336

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1340-P1358

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1359-P1366

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1386-P1426

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1427-P1435

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1471-P1476

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1479-P1523

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1529-P1544

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1545-P1557

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1558-P1569

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1570-P1609

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1610-P1624

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1626-P1640

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1648-P1672

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1682-P1698

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P1699-P1931

DIAGNOSIS TROUBLE CODE (DTC) REFERENCE P2181-P3081

Output Diagnostic Test Mode (DTM)

Note. The Output Diagnostic Test Mode (DTM) can only be performed with the engine stopped and the ignition switched on. During actuator diagnosis, the individual actuators (with the exception of the injectors) are operated in turn for about one minute unless the next actuator is selected by pressing the > button. The control elements can be checked acoustically or by way of touch. The Output Diagnostic Test Mode (DTM) is terminated, if after 1 minute actuation time the next control element is not switched to, or the engine is started or an engine speed pulse is detected. Before restarting the Output Diagnostic Test Mode (DTM) the engine must be started and the ignition switched off and on again.

The Output Diagnostic Test Mode (DTM) activates the following components in the stated order

OUTPUT DIAGNOSTIC TEST MODE ACTIVATION SEQUENCE

1. Fuses for engine electronics OK

See appropriate System Wiring Diagrams article.

Test sequence

1. Connect vehicle diagnostic, testing and information system VAS 5051 and select vehicle system "01 - Engine electronics" in selection list. Ignition must be switched on.

Display on VAS 5051

Scheme 13

1. Under -1- select diagnostic function "03 - Output Diagnostic Test Mode (DTM)".

Activating Evaporative Emission (EVAP) Canister Purge Regulator Valve -N80

Display on VAS 5051

Scheme 14

A - control element test running advance necessary

1 - Activating Evaporative Emission (EVAP) Canister Purge Regulator -N80

1. Press the > button.

Display on VAS 5051

A - control element test running advance permitted

1. This valve is activated (clicks) for approx. 1 minute if the operation is not switched to the next control element by pressing the > button.

Note. Fuel pump must run during actuation time, the flow noise at fuel pressure regulator must be clearly audible If fuel pump does not run, check activation

See FUEL SUPPLY .

If the valve is not activated (does not click).

1. Check Activating Evaporative Emission (EVAP) Canister Purge Regulator -N80-. Go to «EVAPORATIVE EMISSION (EVAP) CANISTER PURGE REGULATOR VALVE -N80-, CHECKING»(/audi/a4/b7-2004-2009/remont/fuel-system/#multiport-fuel-injection-mfi-18l-5v-turbo-amb) .

Activating secondary air inlet valve -N112

1. Press > button.

Display on VAS 5051

Scheme 15

A - control element test waiting advance necessary

2 - Secondary Air Injection (AIR) Solenoid Valve -N112

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

1. This valve (-Pos. 2- under intake manifold) is activated (clicks) for approx. 1 minute if the operation is not switched to the next control element by pressing the > button.

Note. The fuel pump must run during the activation time.

If the valve is not activated (does not click).

1. Check Secondary Air Injection (AIR) Solenoid Valve -N112

See SECONDARY AIR INJECTION (AIR) SOLENOID VALVE -N112-, CHECKING .

Activating Secondary Air Injection (AIR) Pump Relay -J299

1. Press > button.

Display on VAS 5051

Scheme 16

A - control element test running advance permitted

3 - Secondary Air Injection (AIR) Pump Relay -J299

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

The Secondary Air Injection (AIR) Pump Relay -J299- (in relay carrier in electronics box, plenum chamber, position 3) switches the engine for the Secondary Air Injection (AIR) Pump Motor -V101- on and off at approx. 1 minute intervals if the operation has not been switched to the next control element by pressing the > button.

Scheme 17

Note. The fuel pump must run during the activation time.

If secondary air pump does not run intermittently

1. Check Secondary Air Injection (AIR) Pump Relay -J299

See SECONDARY AIR INJECTION (AIR) PUMP RELAY -J299- AND SECONDARY AIR INJECTION (AIR) PUMP MOTOR -V101-, CHECKING .

Activating Wastegate Bypass Regulator Valve -N75

1. Press > button.

Display on VAS 5051

Scheme 18

A - control element test running advance permitted

4 - Wastegate Bypass Regulator Valve -N75

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

1. This valve is activated (clicks) for approx. 1 minute if the operation is not switched to the next control element by pressing the > button.

Note. The fuel pump must run during the activation time.

If the valve is not activated (does not click).

See TURBOCHARGER, G-CHARGER .

Activating camshaft adjustment valves

1. Press > button.

Display on VAS 5051

Scheme 19

A - control element test waiting advance necessary

5 - Camshaft timing control

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

1. This valve is activated (clicks) for approx. 1 minute if the operation is not switched to the next control element by pressing the > button.

Note. The fuel pump must run during the activation time.

If the valve is not activated (does not click).

1. Check camshaft adjustment valves

See CAMSHAFT ADJUSTMENT VALVE, CHECKING .

Activating Leak detection pump (LDP) -V144

1. Press > button.

Display on VAS 5051

Scheme 20

A - control element test waiting advance necessary

6 - Leak Detection Pump (LDP) -V144- tank ventilation system

1. Press > button again.

Display on VAS 5051

A - control element test running advance permitted

1. Leak Detection Pump (LDP) -V144- is activated (clicks) in intervals for approx. 1 minute, unless the > button is pressed to switch to the next actuator.

Note. Operating noise of Leak Detection Pump (LDP) is softly audible at left rear wheelhouse.

If Leak Detection Pump (LDP) for tank ventilation system is not activated (no operating noise is audible)

1. Check Leak Detection Pump (LDP) for tank ventilation system

See LEAK DETECTION PUMP (LDP) -V144-, CHECKING .

Activating Recirculation Valve for turbocharger -N249

1. Press > button.

Display on VAS 5051

Scheme 21

A - control element test waiting advance necessary

7 - Recirculating valve for turbocharger -N249

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

1. This valve (-Pos. 1- under intake manifold) is activated (clicks) for approx. 1 minute if the operation is not switched to the next control element by pressing the > button.

Note. The fuel pump must run during the activation time.

If the valve is not activated (does not click).

See TURBOCHARGER, G-CHARGER

Activating brake vacuum pump

Only on vehicles with automatic transmission.

1. Press > button.

Display on VAS 5051

Scheme 22

A - Control element test waiting advance necessary

8 - Activation of brake vacuum pump

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

1. The brake servo vacuum pump, front left in engine compartment, must start up for a short time, unless the operation has been switched to the next control element by pressing the > button.

If the brake servo vacuum pump does not start up

1. Check brake servo vacuum pump

See BRAKE SYSTEM VACUUM PUMP -V192-, REMOVING AND INSTALLING .

Activating Coolant Fan Control 1 -J293

1. Press > button.

Display on VAS 5051

Scheme 23

A - control element test waiting advance necessary

9 - Coolant Fan activation 1

1. Press > button.

Display on VAS 5051

A - control element test running advance permitted

1. The Coolant Fan Control 1 -J293- (top right on radiator cowl -arrow-) switches the coolant fan on once slowly to full speed, if the operation has not been switched to the next control element by pressing the > button.

Note. The fuel pump must run during the actuation time.

If the fan does not start

1. Check coolant fan and Coolant Fan Control 1 -J293-.

Activating fuel injectors

Note. Fuel injectors are activated according to ignition sequence: Cyl. 1, Cyl. 3, Cyl 4, Cyl. 2.

1. Press > button

Display on VAS 5051

Scheme 24

A - control element test waiting advance necessary

10 - Cylinder 1 fuel injector -N30

1. Press > button again.

Display on VAS 5051

A - control element test running advance permitted

1. Fuel injector must click 5 times after > button is pressed.

Note. Fuel pump must run during activation time.

1. Press > button

Display on VAS 5051

Scheme 25

A - control element test waiting advance necessary

11 - Cylinder 3 Fuel Injector -N32

1. Press > button again.

Display on VAS 5051

A - control element test running advance permitted

1. Fuel injector must click 5 times after > button is pressed.

Note. Fuel pump must run during activation time.

1. Press > button

Display on VAS 5051

Scheme 26

A - control element test waiting advance necessary

12 - Cylinder 4 Fuel Injector -N33

1. Press > button again.

Display on VAS 5051

A - control element test running advance permitted

1. Fuel injector must click 5 times after > button is pressed.

Note. Fuel pump must run during activation time.

1. Press > button

Display on VAS 5051

Scheme 27

A - control element test waiting advance necessary

13 - Cylinder 2 Fuel Injector -N31

1. Press > button again.

Display on VAS 5051

A - control element test running advance permitted

1. Fuel injector must click 5 times after > button is pressed.

Note. Fuel pump must run during activation time.

If one of the fuel injectors is not activated (does not click).

1. Check fuel injectors. Go to «FUEL INJECTORS, CHECKING»(/audi/a4/b7-2004-2009/remont/fuel-system/#multiport-fuel-injection-mfi-18l-5v-turbo-amb) .
2. Press > button

Display on VAS 5051

Scheme 28

A - Actuator test has ended

1. End function "03 - output Diagnostic Test Mode (DTM)" by pressing < button.

Note. Before re-initiating output Diagnostic Test Mode (DTM), engine must be started and the ignition must be switched off and on again.

Basic setting

With engine stopped and ignition switched on, the following operation can be carried out with the "Function 04" basic setting

1. Adaptation of the Throttle Drive Control to the Engine Control Module (ECM) Display group 060 (Go to «THROTTLE VALVE CONTROL MODULE -J338-, ADAPTING»(/audi/a4/b7-2004-2009/remont/fuel-system/#multiport-fuel-injection-mfi-18l-5v-turbo-amb__throttle-valve-control-module-j338-adapting) )
2. Vehicles with automatic transmission: Adaptation of kick-down function of Throttle Position (TP) Sensor to Engine Control Module (ECM) Display group 063 (Go to «KICK-DOWN FUNCTION, ADAPTING»(/audi/a4/b7-2004-2009/remont/fuel-system/#multiport-fuel-injection-mfi-18l-5v-turbo-amb__kick-down-function-adapting) )

With the engine running, the following operations can be performed with the basic setting function

1. Generation of readiness code. Go to «READINESS CODE, GENERATING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .
2. Performance of Oxygen Sensor (O2S) and Oxygen Sensor control, go to «OXYGEN SENSOR SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#multiport-fuel-injection-mfi-18l-5v-turbo-amb)

Test conditions for operations with engine running

1. No DTCs stored in Diagnostic Trouble Code (DTC) memory
2. Coolant temperature at least 80 °C.
3. Electrical devices switched off (radiator fan must not run during the test).
4. Air conditioning switched off.
5. Vehicles with automatic transmission: Selector lever in position P or N.

1. Connect VAS 5051 tester. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics". Ignition must be switched on for this.

or, depending on desired operation

1. Start engine.

Display on VAS 5051

Scheme 29

1. In selection -1-, click on diagnostic function "04 - Basic Setting".

Display on VAS 5051

Scheme 30

1 - Enter display group

1. Enter desired 3-digit display group number in button field -2- and press -Q- button to confirm input.

Example

1. Press buttons -0-, -0- and -1- to select "display group number 001" and press -Q- button to confirm input.

Display on VAS 5051

Scheme 31

1. Measured values not in basic setting
2. Measured values in basic setting
3. Display group X

1. Activating basic setting

Note. Basic setting is initiated after button -A- is pressed.

Display on VAS 5051

Scheme 32

1. Display field 1
2. Display field 2
3. Display field 3
4. Display field 4

1. End function "04 - Basic setting" by pressing < button.

Encoding II Engine Control Module (ECM)

1. Connect vehicle diagnostic, testing and information system VAS 5051. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics" in selection. Ignition must be switched on.

Display on VAS 5051

Scheme 33

1. Under -1- select diagnostic function "07 - Encode Engine Control Module".

Display on VAS 5051

Scheme 34

1 - Enter code max. input value = 32767

1. Enter 7-digit control module Coding II in button field -2- according to Coding II table. Go to «CODING II»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .
2. Enter Engine Control Module code in zone -2- in line with encoding II table. Go to «CODING II»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .

KEY TO CODE REFERENCE

CODING II EXAMPLE

Coding II table

CODING II

1. Confirm entry with -Q- button.

Display on VAS 5051

1 - Coding II being carried out

1. Wait until next display appears.

Display on VAS 5051

Scheme 35

1. Coding II being carried out in vehicle system
2. Control module identification with new code (previous code in brackets)

1. Exit function "07 - Encode Engine Control Module" by pressing the < button.
2. Switch ignition off and then switch on again after 15 seconds.

Note. The next time the ignition is switched on the newly entered code will be activated. If the ignition is not switched off and on after the correct code has been entered, it will not be possible to erase DTC "01044 Control module incorrectly coded".

1. Coolant temperature at least 80 °C.
2. Electrical devices switched off (radiator fan must not run during the test).
3. Air conditioning switched off.

1. Connect vehicle diagnostic, testing and information system VAS 5051. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics" in selection. Engine must be run at idle.

Display on VAS 5051

Scheme 36

1. Under -1- select diagnostic function "08 - Read measured value block".

Display on VAS 5051

Scheme 37

1 - Enter display group

1. Enter desired display group number (three figures) in zone -2- and confirm entry by pressing -Q- button.

Note. The choice of display group depends on the particular functions and components to be tested.

Display on VAS 5051

Scheme 38

1. Display group X
2. Display zone 1 Display zone 2 Display zone 3 Display zone 4
3. Display group X

Note. If no display follows, a display field is not assigned. To switch to a different display group, proceed as follows

Scheme 39

1. Press < button to end function "08 - Read measuring value block".

Coding II

With ignition switched on and engine at standstill, the following operations can be performed using function "11 - Coding II"

1. Activating and deactivating cruise control system. Go to «CRUISE CONTROL SYSTEM, ACTIVATING/DEACTIVATING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb__cruise-control-system-activatingdeactivating) .

Cruise control system, activating/deactivating

Note. For vehicles equipped with cruise control system, the cruise control system must be activated after replacing Engine Control Module (ECM). If cruise control system is activated in Engine Control Module (ECM) in a vehicle without the cruise control system, a DTC entry follows. In this case, the cruise control system function must be deactivated.

1. Connect VAS 5051 tester. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics". Ignition must be switched on for this.

Display on VAS 5051

Scheme 40

1. In selection -1-, select diagnostic function "11 - Coding II".

Display on VAS 5051

Scheme 41

1 - Enter code word

Activating cruise control system

1. Select "11463" in button field -2- and press -Q- button to confirm input.

Deactivating cruise control system

1. Select "16167" in button field -2- and press -Q- button to confirm input.
2. End function "11 - Coding II" by pressing < button.

Display on VAS 5051

Scheme 42

1. Select diagnostic function "08 - read measured value block" in selection -1-.

Display on VAS 5051

Scheme 43

1 - Enter display group

1. Select function "066" in button field -2- for "Display group number 066" and press -Q- button to confirm input.

Display on VAS 5051

Scheme 44

1. Check indication in display field -2-.

DISPLAY GROUP 066: SIGNALS TO ENGINE CONTROL MODULE (ECM)

1. Press < button to end function "08 - Read measuring value block".
2. Select "06 - End Output"
3. Switch ignition off.

Readiness code

The readiness code appears as an 8-digit display on measured value block 086, display zone 1. Each of the 8 digits is allocated to a particular emission-related system.

The function of each of these systems is checked by the self-diagnosis and the relevant position for the system in the 8-digit display is changed from "1" to "0" in a test sequence which must be fully completed.

The readiness code produced after successful completion of the test sequence is then "0 0 0 0 0 0 0 0" (measured value block 086, display zone 1).

If an individual test has been completed, but is "not OK", a DTC is entered in the Diagnostic Trouble Code (DTC) memory. Checking Diagnostic Trouble Code (DTC) memory. Go to DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING .

The readiness code is reset to "0 1 1 0 1 1 0 1" if

1. Diagnostic Trouble Code (DTC) memory has been erased
2. Voltage supply to the ECM has been interrupted (e.g. the connector disconnected, battery disconnected).
3. A new Engine Control Module has been installed

Generate readiness code. Go to READINESS CODE, GENERATING .

Note. When driving with varying loads the exhaust relevant tests are initiated by the control module and the readiness code produces itself. In this case the concluding control possibility is omitted, i.e. it is not obvious whether the vehicle was handed over to the customer without any DTCs.

1. Connect vehicle diagnostic, testing and information system VAS 5051. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics" in selection.

Engine must be run at idle.

Display on VAS 5051

Scheme 45

1. Under -1- select diagnostic function "08 - Read measured value block".

Display on VAS 5051

Scheme 46

1 - Enter display group

1. Enter "086" for "display group number 086" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 47

1. Check indication in display field -1-.
2. Check readiness code in display zone -1-. Specified value: 0 0 0 0 0 0 0 0

DISPLAY GROUP 086: READINESS CODE

Note on display zone 1

Display zone 1 is the most important. This display indicates which system has been checked by the self-diagnosis since the last time the Diagnostic Trouble Code (DTC) memory was erased or since installation of a new control module. After erasing the Diagnostic Trouble Code (DTC) memory, all testable values are set to "1" and then to "0" after successful completion of the test.

Scheme 48

Note. In the previous graphic, for generating readiness code, go to READINESS CODE, GENERATING .

Note. The readiness code is only produced when all display digits in display zone 1 are set to "0".

If the specification "0 0 0 0 0 0 0 0" is achieved in display zone 1

1. Press < button.
2. Check Diagnostic Trouble Code (DTC) memory to check. Go to «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) (there must not be any stored DTCs).

If specified value is not obtained

1. Generate readiness code. Go to «READINESS CODE, GENERATING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .

1. Vehicle stationary.
2. Electrical devices switched off (radiator fan must not run during the test).
3. Air conditioning switched off.
4. Vehicles with automatic transmission: Selector lever in position P or N.

Note. If the test result is immediately displayed as "OK" after selecting a display group during an operation, the test has already been performed and you can continue with the next operation.

Operation 1: Checking Diagnostic Trouble Code (DTC) memory

Test conditions

1. Engine stopped, ignition switched on

1. Connect vehicle diagnostic, testing and information system VAS 5051. Go to «VAS 5051 VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) . Select vehicle system "01 - Engine electronics" in selection. Ignition must be switched on.

Display on VAS 5051

Scheme 49

1. Under -1- select diagnostic function "02 - Check Diagnostic Trouble Code (DTC) memory".

Display on VAS 5051

Scheme 50

1. Content of the Diagnostic Trouble Code (DTC) memory: 0 DTCs recognized or X DTCs recognized
2. DTCs DTC code DTC location DTC type

If a DTC is stored

1. Repair DTC and erase Diagnostic Trouble Code (DTC) memory. Perform a road test and check DTC memory again.

If no DTC is stored

1. Press < button.
2. Perform next operation.

Operation 2: Erasing Diagnostic Trouble Code (DTC) memory

Test conditions

1. Engine stopped, ignition switched on

Display on VAS 5051

Scheme 51

1. Under -1- select diagnostic function "05 - Erase Diagnostic Trouble Code (DTC) memory".

Note. The readiness code is reset when the Diagnostic Trouble Code (DTC) memory is erased and must therefore be reproduced.

Display on VAS 5051

Scheme 52

1. No display (before erasing) or Diagnostic Trouble Code memory erased
2. Note: Is the function to be carried out? Note: Data will be erased! Press "OK" button in display -2-. Press < button. Perform next operation.

Operation 3: Adapting the Throttle Valve Control Module -J338- to the Engine Control Module (ECM)

Test conditions

1. Engine stopped, ignition switched on

Display on VAS 5051

Scheme 53

1. Under -1- select diagnostic function "04 - Basic setting".

Display on VAS 5051

Scheme 54

1 - Enter display group

1. Enter "060" for "display group number 060" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 55

1. Activate basic setting by pressing -A- button.
2. Check specifications in display zones -3- and -4-.
3. Check indication in display fields -3- and -4-.

DISPLAY GROUP 060: ADAPTATION OF THROTTLE VALVE CONTROL MODULE

Note on display zone 3

During adaptation, various digits are displayed in display zone 3 which represent the relevant adaptation status. The most crucial factor is not the way in which the adaptation stage counter (display zone 3) behaves during the adaptation process, but that the specification "ADP OK" is displayed after adaptation in display zone 4.

If specification "ADP OK" is obtained

1. Press < button and perform next operation.

Operation 4: Adapting kick-down function

Only on vehicles with automatic transmission.

Test conditions

1. Engine stopped, ignition switched on

Display on VAS 5051

Scheme 56

1 - Enter display group

1. Enter "063" for "display group number 063" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 57

1. Activate basic setting by pressing -A- button.

Note. You will now be instructed to: "Operate kick down".

1. Fully depress accelerator pedal beyond kick-down point and keep it pressed.

Note. During the kick-down point adaptation process, "Kick-down ADP is running" is shown on the display. After successful adaptation of the kick-down point "Kick-down ADP OK" appears on the display.

1. Check indication in display field -4-.

DISPLAY GROUP 063: ADAPTATION OF KICKDOWN FUNCTION

Note on display zone 4

"ERROR" may be displayed, if e.g. accelerator pedal is not pressed immediately when instructed by tester, or if accelerator pedal was released while adaptation was already running but process was not yet complete. In both cases exit "basic setting" mode and perform adaptation again.

If specification "ADP OK" is obtained

1. Press < button then perform next operation.

Operation 5: Checking operating status of oxygen sensor control

1. Start engine (for vehicles with manual transmission: press clutch pedal).

Note. If necessary, after the engine starts reselect vehicle system "01 - Engine electronics" and diagnostic function "04 - Basic setting".

Test conditions

1. Engine at idle

Display on VAS 5051

Scheme 58

1 - Enter display group

1. Enter "030" for "display group number 030" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 59

1. Activate basic setting by pressing -A- button.
2. Check indication in display fields -1- and -2-.

Note. By increasing the engine speed (RPM) the specified values are achieved quicker. The "Oxygen sensor status" indicates the condition of the oxygen sensor control and the oxygen sensor (O2S).

DISPLAY GROUP 030: OXYGEN SENSOR STATUS

SIGNIFICANCE OF 3-DIGIT READOUT OF DISPLAY GROUP 030

Note. The first digit of the 3-digit display (heating) fluctuates between 0 and 1 at certain operating points. The oxygen sensor control of oxygen sensor (O2S) after Three Way Catalytic Converter (TWC) (bank 1, sensor 2) is not active without engine load, i.e. the display of the 3-digit display is 0.

1. Only continue with test if displays have reached "111" in display zone 1 and "110" in display zone 2 at least once.
2. Press < button.
3. Perform next operation.

Operation 6: Diagnosis of oxygen sensor control system before Three Way Catalytic Converter (TWC)

Test conditions

1. Engine at idle

Display on VAS 5051

Scheme 60

1 - Enter display group

1. Enter "107" for "display group number 107" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 61

1. Check indication in display field -4-.

DISPLAY GROUP 107: DIAGNOSIS, OXYGEN SENSOR CONTROL SYSTEM (BANK 1, SENSOR 1)

If specification "Syst. OK" is obtained

1. Press < button.
2. Abruptly floor accelerator pedal and release again (brief burst of throttle). 3000 rpm, then perform next operation

Operation 7: Diagnosis of aging of oxygen sensor (O2S) before Three Way Catalytic Converter (TWC)

Display on VAS 5051

Scheme 62

1 - Enter display group

1. Enter "034" for "display group number 034" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 63

1. Activate basic setting by pressing -A- button.
2. Press accelerator and brake pedal simultaneously, engine speed increases to approx. 2300 rpm.

Test conditions

1. Accelerator and brake pedal pressed simultaneously, engine runs at approx. 2300 rpm.

1. Check indication in display field -4-.

DISPLAY GROUP 034: DIAGNOSIS, OXYGEN SENSOR AGING (BANK 1, SENSOR 1)

If specification "B1-P1 OK" is obtained

1. Press < button.
2. Perform next operation.

Operation 8: Diagnosis of oxygen sensor (O2S) condition after Three Way Catalytic Converter (TWC).

Test conditions

1. Engine at idle

Display on VAS 5051

Scheme 64

1 - Enter display group

1. Enter "036" for "display group number 036" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 65

1. Activate basic setting by pressing -A- button.
2. Check indication in display field -2-.

DISPLAY GROUP 036: OXYGEN SENSOR CONDITION (BANK 1, SENSOR 2)

If specification "B1-P2 OK" is obtained

1. Press < button.
2. Perform next operation.

Operation 9: Diagnosis of oxygen sensor control system after Three Way Catalytic Converter (TWC)

Test conditions

1. Engine at idle

Display on VAS 5051

Scheme 66

1 - Enter display group

1. Enter "037" for "display group number 037" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 67

1. Activate basic setting by pressing -A- button.
2. Check indication in display field -4-.

DISPLAY GROUP 037: DIAGNOSIS, OXYGEN SENSOR CONTROL SYSTEM (BANK 1, SENSOR 2)

If specification "Syst. OK" is obtained

1. Press < button.
2. Perform next operation.

Operation 10: Diagnosis of oxygen sensor (O2S) aging after Three Way Catalytic Converter (TWC)

Display on VAS 5051

Scheme 68

1 - Enter display group

1. Enter "043" for "display group number 043" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 69

1. Activate basic setting by pressing -A- button.
2. Press accelerator and brake pedal simultaneously, engine speed increases to approx. 2300 rpm.

Test conditions

1. Accelerator and brake pedal pressed simultaneously, engine runs at approx. 2300 rpm.

1. Check indication in display field -4-.

DISPLAY GROUP 043: DIAGNOSIS, OXYGEN SENSOR AGING (BANK 1, SENSOR 2)

If specification "B1-P2 OK" is obtained

1. Press < button.
2. Perform next operation.

Operation 11: Three Way Catalytic Converter (TWC) diagnosis

Display on VAS 5051

Scheme 70

1 - Enter display group

1. Enter "046" for "display group number 046" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 71

1. Activate basic setting by pressing -A- button.
2. Press accelerator and brake pedal simultaneously, engine speed increases to approx. 2000 rpm.

Test conditions

1. Accelerator and brake pedal pressed simultaneously, engine runs at approx. 2000 rpm.

1. Check specifications in display zones -2- and -4-.
2. Check indication in display fields -2- and -4-.

DISPLAY GROUP 046: CATALYTIC CONVERTER DIAGNOSIS (BANK 1)

If specification "Cat. B1 OK" is obtained

1. Press < button.
2. Perform next operation.

Operation 12: Diagnosis of Activating Evaporative Emission (EVAP) Canister Purge Regulator -N80

Test conditions

1. Engine run at idle

Display on VAS 5051

Scheme 72

1 - Enter display group

1. Enter "070" for "display group number 070" in zone -2- and confirm entry by pressing -Q- button.

Display on VAS 5051

Scheme 73

1. Activate basic setting by pressing -A- button.
2. Check indication in display field -4-.

DISPLAY GROUP 070: DIAGNOSIS OF EVAPORATIVE EMISSION (EVAP) CANISTER PURGE REGULATOR

If specification "EVAP OK" is obtained

1. Press < button.
2. Perform next operation.

Operation 13: Diagnostic of tank seal and Secondary Air Injection (AIR) system

Observe

1. Engine running at idle

Display on VAS 5051

Scheme 74

1 - Enter display group

1. Select function "191" in button field -2- for "display group number 191" and press Q button to confirm input.

Display on VAS 5051

Scheme 75

1. Activate basic setting by pressing button -A-.

Note. During diagnostic of the Secondary Air Injection (AIR) system, the Secondary Air Injection (AIR) pump will run for several seconds. In case diagnostic leak test is not started, open fuel filler cap briefly (to release pressure).

1. Check indication in display fields -2- and -4-.

DISPLAY GROUP 191: TANK SEAL AND SECONDARY AIR INJECTION (AIR) SYSTEM (BANK 1) DIAGNOSTIC

If specified values "Syst. OK" are obtained

1. Click on < button
2. Perform next work step.

Operation 14: Read readiness code

1. Read readiness code. Go to «READINESS CODE, READING»(/audi/a4/b7-2004-2009/remont/testing-diagnostics/#engine-controls-on-board-diagnostic-obd-18l-5v-turbo-amb) .

See also:
• DATA EXCHANGE, MOTRONIC / ABS (CAN-BUS), CHECKING
• ELECTRONIC POWER CONTROL (EPC) SYSTEM, CHECKING
• MASS AIR FLOW (MAF) SENSOR -G70-, CHECKING
• CHARGE AIR PRESSURE SYSTEM WITH TURBOCHARGER CHECKING
• INTAKE AIR TEMPERATURE (IAT) SENSOR -G42-, CHECKING
• ENGINE COOLANT TEMPERATURE (ECT) SENSOR -G62-, CHECKING
• OXYGEN SENSOR (O2S) AND OXYGEN SENSOR CONTROL BEFORE THREE WAY CATALYTIC CONVERTER (TWC), CHECKING
• FUEL PUMP (FP) RELAY -J17- AND RELAY ACTIVATION, CHECKING
• MISFIRE RECOGNITION, CHECKING
• SYSTEM PRESSURE, FUEL PRESSURE REGULATOR AND RESIDUAL PRESSURE, CHECKING
• ENGINE SPEED (RPM) SENSOR -G28-, CHECKING
• KNOCK SENSORS, CHECKING
• CAMSHAFT POSITION (CMP) SENSOR -G40-, CHECKING
• INTAKE AIR SYSTEM FOR LEAKS (UNMETERED AIR), CHECKING
• WASTEGATE BYPASS REGULATOR VALVE -N75-, CHECKING
• EVAP CANISTER/LEAK DETECTION SYSTEM (FRONT AND ALL WHEEL DRIVE)
• THROTTLE VALVE CONTROL MODULE -J338-, CHECKING
• THROTTLE VALVE CONTROL MODULE -J338-, ADAPTING
• BRAKE LIGHT SWITCH -F- AND BRAKE PEDAL SWITCH -F47
• ENGINE CONTROL MODULE (ECM) (WITHOUT METAL ANTI-THEFT HOUSING), REPLACING
• MOTRONIC ECM POWER SUPPLY RELAY -J271-, CHECKING
• ANGLE SENSORS FOR THROTTLE DRIVE -G187- AND -G188-, CHECKING
• KNOCK RECOGNITION CONTROL LIMIT, CHECKING
• SECONDARY AIR SYSTEM, CHECKING
• CLUTCH VACUUM VENT VALVE SWITCH -F36-, CHECKING
• CRUISE CONTROL SYSTEM (CCS) SWITCH -E45-, TESTING
• THROTTLE POSITION (TP) SENSOR 1 -G79- AND THROTTLE POSITION SENSOR 2 -G185-, CHECKING
• THROTTLE VALVE CONTROL MODULE, CLEANING
• KICK-DOWN FUNCTION, ADAPTING
• DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING
• DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, ERASING
• MALFUNCTION INDICATOR LAMP (MIL) -K83- IN INSTRUMENT CLUSTER
• SAFETY PRECAUTIONS
• ENCODING II ENGINE CONTROL MODULE (ECM)
• OUTPUT DIAGNOSTIC TEST MODE (DTM)
• BASIC SETTING
• ENDING OUTPUT
• CODING II
• DIAGNOSTIC TROUBLE CODES (DTC): P0011 TO P1228, VAG 16395 TO 17636
• CRUISE CONTROL SYSTEM, ACTIVATING/DEACTIVATING
