Maintenance Reminder Light Reset Procedures Audi A4 B7

Reset Procedures 13 illustrations ~2795 words

EGR WARNING LIGHT

On models equipped with EGR warning light, warning light will come on every 15,000 miles. After EGR system has been checked, and any faults have been corrected, reset mileage counter. (Scheme 1)

Scheme 1

Scheme 1: EGR WARNING LIGHT

OXYGEN SENSOR WARNING LIGHT

Note. To determine appropriate reset procedure, refer to OXYGEN SENSOR WARNING LIGHT RESET PROCEDURE INDEX . Only vehicles listed in this index have an OXYGSEN SENSOR warning light.

Note. The O2S counter on Coupe GT models with electronic dash is solid state circuitry and cannot be reset. At 30,000 miles, replace oxygen sensor, remove and discard earning light bulb from cluster.

OXYGEN SENSOR WARNING LIGHT RESET PROCEDURE INDEX

OXYGEN SENSOR WARNING LIGHT RESET - PROCEDURE 1

Every 30,000 miles an oxygen sensor service reminder light in dash will illuminate. This indicates emissions system should be checked and oxygen sensor should be replaced.

  1. To reset counter, remove 2 upper and/or 2 lower instrument cluster cover screws.
  2. Pull cover toward steering wheel.
  3. Lift upper instrument cluster cover off of cluster.
  4. Break off square plastic switch cover at top center near imprinted OXS. (Scheme 1)
  5. Using a screwdriver, push switch to reset light. On some models, remove instrument cluster if necessary to access switch.
  6. To turn off reminder light on all models except Coupe GT with electronic dash: Trace speedometer cable to reset box (in-line with cable). (Scheme 1) Press White button on box. Turn ignition on, and ensure indicator is out.

OXYGEN SENSOR WARNING LIGHT RESET - PROCEDURE 2

Every 60,000 miles an oxygen sensor service reminder light in dash will illuminate. This indicates emissions system should be checked and oxygen sensor should be replaced.

  1. To reset counter, lift rear seat and push button marked OXS on reset box.
  2. Turn ignition on, and ensure indicator is out.
  3. To turn off reminder light on all models except Coupe GT with electronic dash: Trace speedometer cable to reset box (in-line with cable). (Scheme 1) Press White button on box. Turn ignition on, and ensure indicator is out.

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY

Note. To determine appropriate reset procedure, refer to SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET PROCEDURE INDEX . Only vehicles listed in this index have a service reminder indicator or a service interval display.

Note. DO NOT reset display between required service intervals, otherwise service interval will be incorrect. Service display information will remain intact even when battery is disconnected.

Model & YearReset Procedure
100
1992-94Service Reminder Indicator/Service Interval Display Reset - Procedure 1
A3
2006-07Service Reminder Indicator/Service Interval Display Reset - Procedure 6
2008-12Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 9
A4
1996-97Service Reminder Indicator/Service Interval Display Reset - Procedure 1
1998-01Service Reminder Indicator/Service Interval Display Reset - Procedure 2
2002-05Service Reminder Indicator/Service Interval Display Reset - Procedure 4
2006-08Service Reminder Indicator/Service Interval Display Reset - Procedure 6
2009-14Service Reminder Indicator/Service Interval Display Reset - Procedure 7 or 8
Allroad (A4)
2001-05Service Reminder Indicator/Service Interval Display Reset - Procedure 2
A5
2008-09Service Reminder Indicator/Service Interval Display Reset - Procedure 6
2008-14Service Reminder Indicator/Service Interval Display Reset - Procedure 7 or 8
A6
1995-97Service Reminder Indicator/Service Interval Display Reset - Procedure 1
1998-04Service Reminder Indicator/Service Interval Display Reset - Procedure 3
2005-08Service Reminder Indicator/Service Interval Display Reset - Procedure 1
2009-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
A6 Avant Quattro
1999-04Service Reminder Indicator/Service Interval Display Reset - Procedure 3
Allroad (A6)
2013-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
A7
2012-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
A8
1997-02Service Reminder Indicator/Service Interval Display Reset - Procedure 1
2003-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 10
Q5
2009-12Service Reminder Indicator/Service Interval Display Reset - Procedure 7 or 8
2013-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
Q7
2010-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
RS 4
2007-08Service Reminder Indicator/Service Interval Display Reset - Procedure 6
RS 5
2013-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
RS 6
2003Service Reminder Indicator/Service Interval Display Reset - Procedure 3
RS 7
2014-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
R8
2008-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 9
S4
1992-94Service Reminder Indicator/Service Interval Display Reset - Procedure 1
2000-02Service Reminder Indicator/Service Interval Display Reset - Procedure 2
2004-05Service Reminder Indicator/Service Interval Display Reset - Procedure 4
2009-07Service Reminder Indicator/Service Interval Display Reset - Procedure 6
2010-14Service Reminder Indicator/Service Interval Display Reset - Procedure 7 or 8
S5
2008-09Service Reminder Indicator/Service Interval Display Reset - Procedure 6
2010-14Service Reminder Indicator/Service Interval Display Reset - Procedure 7 or 8
S6
1995Service Reminder Indicator/Service Interval Display Reset - Procedure 1
2009-11Service Reminder Indicator/Service Interval Display Reset - Procedure 8
2013-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
S7
2013-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
S8
2002-09Service Reminder Indicator/Service Interval Display Reset - Procedure 1
2011-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 11
TT
2000-06Service Reminder Indicator/Service Interval Display Reset - Procedure 5
2008-14Service Reminder Indicator/Service Interval Display Reset - Procedure 8 or 9

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET PROCEDURE INDEX

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 1

Note. Factory scan tool, VAG 1551/1552 or VAS 5051, is required to reset service reminder indicator.

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 2

  1. Switch ignition off.
  2. Press odometer and instrument cluster reset buttons while switching ignition on. (Scheme 2) Trip recorder display (3) will read "service OIL".
  3. Release buttons.
  4. Pull clock adjuster button (1) on instrument cluster and hold for approximately 2 seconds. This resets "service OIL" display.
  5. Press trip recorder reset button again to advance to next type of service.
  6. Release button. Trip recorder display will read "service INSP".
  7. Pull clock adjuster button on instrument cluster and hold for approximately 2 seconds. This resets "service INSP" display.
  8. Switch ignition off.

Scheme 2

Scheme 2

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 3

Factory scan tool, VAG 1551, can be used to reset SRI or perform the following

  1. Turn ignition off.
  2. Press reset button for trip recorder (2) in instrument cluster and switch ignition on at same time. (Scheme 2) "Service OIL" will appear on trip recorder display (3).
  3. Pull out clock adjuster knob(1) in instrument cluster and hold in position until message "Service OIL" is cancelled. Trip recorder display will now read "Service - - - ".
  4. Press trip recorder reset button again to call up next service message. The message "Service INSP" will appear on trip recorder display.
  5. Pull out clock adjuster knob in instrument cluster and hold in position until message "Service INSP" is cancelled. Trip recorder display will now read "Service - - -".
  6. Turn ignition off.

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 4

To display remaining distance to service, with ignition on, press button (marked with wrench symbol) on right side of instrument cluster. A function test can be performed with the engine idling or when vehicle speed has reached at least 3 MPH. If there is a priority 1 malfunction (Red symbol), distance remaining will not display. Distance remaining will be updated every 310 miles.

On a new vehicles or immediately after a service has been performed, a "SERVICE IN ---- MI (KM) --- DAYS" message will be displayed for the first 310 miles. As soon as less than 1200 miles of driving are left before the next service is due, a "SERVICE IN 1,200 MI (2,000 KM) --- DAYS" message will be displayed when ignition switch is turned to ON position. The display will return to normal after 5 seconds. If service is due immediately, a "SERVICE!" message will be displayed when ignition switch is turned to ON position. Display will return to normal after 5 seconds. To reset interval display after performing required service, perform the following

Note. Service reminder can be reset manually or by using VAS 5051 factory scan tool. If resetting without VAS 5051, the service is automatically set to a fixed interval 9942 miles (16 000 km).

  1. Turn ignition off.
  2. Press button (1) on right side of instrument cluster and turn ignition switch to ON position. (Scheme 3) Either "SERVICE IN ---- MI (KM)" or "SERVICE!" message will be displayed.
  3. Press reset button (2) on right side of instrument cluster until the following message "SERVICE IN ---- MILES --- DAYS" and "SERVICE!" is displayed. Display will return to normal after 5 seconds.

Scheme 3

Scheme 3

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 5

To display remaining distance to service, turn ignition on. Press button on left side of instrument cluster display (lower right side of tachometer). A system function test can be performed with the engine idling or when vehicle speed has reached at least 3 MPH. If there is a priority "1" malfunction (Red symbol), distance remaining will not display. If service is needed soon, "SERVICE IN 1200 MLS" will be displayed. If service is now due, "SERVICE!" will appear. The display will return to normal after 5 seconds. To reset interval display after performing required service

  1. Turn ignition off.
  2. Turn ignition on while pressing trip recorder reset button (3). (Scheme 4) "SERVICE!" will appear in the display (2).
  3. Press button on left side of instrument cluster display (1) until "SERVICE!" is cleared from the display. Display should now show next service event required. If there is a defect in the instrument cluster, dEF will appear in the trip odometer display area continuously. Vehicle must be serviced.

Scheme 4

Scheme 4

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 6

  1. Ensure ignition is off.
  2. Press in the wrench button on instrument cluster, and at the same time rotate the ignition key forward (without starting).
  3. While still pressing the "wrench" button in, press the "0,0" button and hold until the "SERVICE!" notification clears (about 2-3 seconds). "Service!" Indicator Reset Procedure/Service Indicator Reset Complete

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 7

To reset service reminder: Using CAR button on radio, select "Service interval display" (or Sevicing & Checks), then select "Reset oil change interval".

Service Interval Display Reset

Follow these steps in sequential order

  1. Connect the Vehicle Diagnosis, Testing and Information System (VAS).
  2. Select "Guided Functions".
  3. Select "Service Work".
  4. Now follow guided program.

Oil Quality Adapting

Follow these steps in sequential order

  1. Connect VAS.
  2. Select "Guided Fault Finding or Guided Functions".
  3. Go to "function/component selection".
  4. Select "Service Work".
  5. Select "Combination Processor, changing oil quality".
  6. Now follow guided program.

Note. It is necessary to change oil quality if changed between inspection. Inspection Service = Oil quality 1. WIV = Maintenance Interval Extension. Please follow guided program function description.

Maximum Values Adapting

Follow these steps in sequential order

  1. Connect VAS.
  2. Select "Guided Fault Finding or Guided Functions".
  3. Go to - function/component selection.
  4. Select "Service Work".
  5. Select "Combination Processor, adjusting maximum WIV value".
  6. Now follow guided program.

Fixed Interval Maximum Values

Minimum mileage in Km15000
Maximum mileage in Km15000
Maximum time interval in days365

Note. WIV = Maintenance Interval Extension Please follow guided program function description

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 9

Note. If the service display is reset manually via the instrument cluster, it automatically sets itself to fixed interval.

  1. Switch ignition on.
  2. With button (1) pressed, the message "SERVICE" appears.
  3. Pull the knob one more time within 5 seconds until "SERVICE IN .... KM... DAYS" appears.
  4. Service has been reset.

Scheme 5

Scheme 5

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 10

To reset service reminder: Using CAR button on radio, select "Car Systems" control button, select "Servicing & Checks", select "Service interval display", then select "Reset oil change interval".

SERVICE REMINDER INDICATOR/SERVICE INTERVAL DISPLAY RESET - PROCEDURE 11

To reset service reminder: Using CAR button on radio, select "Systems", select "Service interval display", then select "Reset oil change interval".

Or

To reset service reminder: Using CAR button on radio, select "Car Systems" control button, select "Servicing & Checks", select "Service interval display", then select "Reset oil change interval".

TIRE PRESSURE MONITOR SYSTEM (TPMS)

Note. To determine appropriate TPMS reset procedure, refer to STORING TIRE INFLATION PRESSURES INDEX . Only vehicles listed in this index have a TPMS display or a reset procedure.

Note. In order for the tire pressure monitoring system to work, the specified pressures (provided on tire pressure label) must be reprogrammed after every change in air pressure.

Note. Whenever tire pressure is adjusted (i.e., when readjusting tire pressure for a load condition), or after every wheel change, the adjusted pressure has to be stored again. See appropriate STORING TIRE INFLATION PRESSURES procedure.

Model & YearReset Procedure
A3
2006-07Storing Tire Inflation Pressures - Procedure 4
2008-10Storing Tire Inflation Pressures - Procedure 8
2011-13Storing Tire Inflation Pressures - Procedure 5
A4
2005Storing Tire Inflation Pressures - Procedure 1
2006-08Storing Tire Inflation Pressures - Procedure 5
2009-14Storing Tire Inflation Pressures - Procedure 2
Allroad (A4)
2005Storing Tire Inflation Pressures - Procedure 3
A5
2008Storing Tire Inflation Pressures - Procedure 6
2009-14Storing Tire Inflation Pressures - Procedure 2
A6
2005-14Storing Tire Inflation Pressures - Procedure 2
Allroad (A6)
2013-14Storing Tire Inflation Pressures - Procedure 2
A7
2012-14Storing Tire Inflation Pressures - Procedure 2
A8
2005-14Storing Tire Inflation Pressures - Procedure 2
Q5
2009-14Storing Tire Inflation Pressures - Procedure 2
Q7
2007-14Storing Tire Inflation Pressures - Procedure 2
R8
2008-14Storing Tire Inflation Pressures - Procedure 7
RS 4
2007Storing Tire Inflation Pressures - Procedure 5
RS 5
2013-14Storing Tire Inflation Pressures - Procedure 2
S4
2005Storing Tire Inflation Pressures - Procedure 1
2006-09Storing Tire Inflation Pressures - Procedure 5
2010-14Storing Tire Inflation Pressures - Procedure 2
S5
2008Storing Tire Inflation Pressures - Procedure 6
2009-14Storing Tire Inflation Pressures - Procedure 2
S6
2007-14Storing Tire Inflation Pressures - Procedure 2
S8
2007-09Storing Tire Inflation Pressures - Procedure 2
2013-14Storing Tire Inflation Pressures - Procedure 2
TT
2008-10Storing Tire Inflation Pressures - Procedure 8
2011-13Storing Tire Inflation Pressures - Procedure 5
TTS
2013-14Storing Tire Inflation Pressures - Procedure 5

STORING TIRE INFLATION PRESSURES INDEX

STORING TIRE INFLATION PRESSURES - PROCEDURE 1

  1. Ensure air pressure in all tires (including spare tire) is properly adjusted to specification.
  2. On the center instrument cluster display, press the MENU button. (Scheme 6)
  3. Push the turn-switch to select "SET" option. (Scheme 7)
  4. Turn the switch to scroll to "TYRE PRESSURE", then push switch. (Scheme 8)
  5. Push the switch again to select "STORE PRESSURES". (Scheme 9) After the tire pressures have been saved, the system will measure the actual pressures once again, and then save these as the new pressures.

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

STORING TIRE INFLATION PRESSURES - PROCEDURE 2

  1. Ensure air pressure in all tires is properly adjusted to specification.
  2. On the center instrument cluster display (on some models, in MMI), press the CAR function button. (Scheme 10) NOTE: On some newer models start menu selection with SERVICING & CHECKS.
  3. Select TIRE PRESSURE MONITORING.
  4. Select STORE TIRE PRESSURES or STORE NOW.

or

  1. Press the CAR function button.
  2. Select CAR SYSTEMS control button.
  3. Then SERVICING & CHECKS.
  4. Select TIRE PRESSURE MONITORING.
  5. Select STORE TIRE PRESSURES.

Scheme 10

Scheme 10

STORING TIRE INFLATION PRESSURES - PROCEDURE 3

Note. In order for the tire pressure monitoring system to work, the specified pressures (provided on tire pressure label located on driver's side door pillar) must be reprogrammed after every change in air pressure or after every wheel change.

  1. Turn ignition switch to ON position.
  2. Press the MENU button to open the start menu.
  3. Move the selection arrow to "SET" by rotating the turn/push knob.
  4. Press the turn/push knob. The settings menu will appear.
  5. Move the selection arrow to "TIRE PRESSURE" by rotating the turn/push knob.
  6. Press the turn/push knob. The sub-menu TIRE PRESSURE will appear.
  7. Move the selection arrow to "STORE PRESSURES!". (Scheme 11) When this is initiated, the system automatically starts the learning procedure. NOTE: The learning procedure is launched by storing the air pressures. It takes several minutes while you are driving. The system will learn the tire pressures set on the vehicle, and will check to see if any tires were changed. During the learning phase, the system is operable, but will only issue a warning when the pressure in one or more tires (including the spare) deviates from the specified pressure by more than 6 psi (41 kPa). If this occurs, the Red tire warning symbol and "CHECK TIRE PRESSURE" message will appear. NOTE: If a tire symbol with a slash through it appears in the display at the end of a learning phase, it means that the system cannot recognize which wheels are mounted on the vehicle. This may be because one or more wheels were mounted lacking a wheel sensor. NOTE: During the learning phase, if the system determines that there is a difference of more than 6 psi (41 kPa) between the air pressures on one axle, a message will be displayed showing both affected wheels.
  8. Press the turn/push knob. A check mark will appear. The system reports that the store request was saved with "THE CURRENT TIRE PRESSURES WILL BE SAVED".
  9. Move the selection arrow to "BACK".
  10. Press the turn/push knob to leave the tire pressure menu.

Scheme 11

Scheme 11

STORING TIRE INFLATION PRESSURES - PROCEDURE 4

With vehicle stationary and ignition switch turned to ON position, press and hold TPMS and ESP/ASR buttons until a signal sounds. No further calibration (tire pressure re-adaptation) is required after basic calibration.

STORING TIRE INFLATION PRESSURES - PROCEDURE 5

Note. In order for the tire pressure monitoring system to work, the specified pressures (provided on tire pressure label located on driver's side door pillar) must be reprogrammed after every change in air pressure or after every wheel change.

  1. Ensure air pressure in all tires (including spare tire) is properly adjusted to specification.
  2. On the windshield wiper lever, push the RESET button (Scheme 12) until the menu shown in in the illustration is displayed. (Scheme 7)
  3. Push the rocker switch at the end of the lever to select the "SET" option.
  4. Push RESET button.
  5. Push the rocker switch to select the "TYRE PRESSURE" option. (Scheme 8)
  6. Push RESET button.
  7. Push the rocker switch to select "STORE PRESSURES" option. (Scheme 9)
  8. After the tire pressures have been saved, the system will measure the actual pressures once again, and then save these as the new pressures.

Scheme 12

Scheme 12

STORING TIRE INFLATION PRESSURES - PROCEDURE 6

Note. The correct saving of the specified values is a basic requirement for accurate tire pressure monitoring.

  1. Adjust air pressure in all tires to specifications (provided on tire pressure label located inside fuel filler door or B pillar).
  2. Turn ignition ON.
  3. Select "CAR", "SYSTEMS", "TIRE PRESSURES MONITORING".
  4. Press the multimedia control button on the center console when in the Tire Pressure Monitoring menu. (Scheme 13)
  5. The saving takes place while driving.

Scheme 13

Scheme 13

STORING TIRE INFLATION PRESSURES - PROCEDURE 7

Note. The correct saving of the specified values is a basic requirement for accurate tire pressure monitoring.

CAUTIONOnly use the VAS 5051B on this vehicle.
  1. Adjust air pressure in all tires to specifications.
  2. Connect Vehicle Diagnosis and Service System VAS 5051B with corresponding diagnostic cable to vehicle.
  3. Turn ON Vehicle Diagnosis and Service System.
  4. Vehicle Diagnosis and Service System is ready when it displays operating modes in the button fields.
  5. Turn ignition ON.
  6. Select "GUIDED FUNCTIONS" on screen.
  7. Select "TIRE PRESSURE MONITORING SYSTEM J502", and then "CODING CONTROL MODULE".
  8. Follow the on screen instructions.

STORING TIRE INFLATION PRESSURES - PROCEDURE 8

Note. The correct saving of the specified values is a basic requirement for accurate tire pressure monitoring.

Basic Procedure

  1. Adjust air pressure in all tires to specifications (provided on tire pressure label located inside fuel filler door/B pillar).
  2. Turn ignition ON.
  3. Vehicle must be stationary.
  4. Press the Tire Pressure Monitoring button on the center console switch strip for approximately 5 seconds or until a signal tone is heard and the Yellow malfunction light in the instrument cluster flashes several times, this confirms the calibration procedure.

Replacing A Tire Or Tire Pressure Sensor

Each time a tire is changed or a tire pressure sensor is replaced, the tire pressure monitoring button in the center console must be pressed for approximately 5 seconds with the ignition switched on and vehicle still under a signal tone is heard and the yellow system malfunction diagram in the instrument cluster blinks several times.

If the tire pressure monitoring button is not pressed, the system learns the new sensors but still activates the malfunction lamp to request active operation.

The vehicle must now stand for 20 minutes and then be driven on a 10 minute adaptation drive at speeds greater than 25 km/h. If the standing time is not followed, control module is not in learning mode so system recognizes a malfunction and can only automatically learn wheel electronics after standing 20 minutes.
