BUZZERS, RELAYS & TIMERS
| Component | Location |
|---|---|
| Brake Booster Relay | Left side of dash. (Scheme 10) |
| Convertible Top Hydraulic Pump Relay | Right side of luggage compartment. (Scheme 120) |
| Convertible Top Hydraulic Pump Relay 2 | Right side of luggage compartment. (Scheme 121) |
| Coolant Circulation Pump Relay | Left rear of engine compartment. (Scheme 21) |
| Front Parking Warning Buzzer | Behind center of dash. (Scheme 30) |
| Fuel Pump (FP) 2 Relay | Left side of dash. (Scheme 31) |
| Horn Relay | On relay & fuse panel at left side of dash. (Scheme 48) |
| Load Reduction Relay | Left side of dash. (Scheme 56) |
| Locking Relay For Starter (Clutch Pedal Switch) | Left rear of engine compartment. (Scheme 61) |
| Motronic Engine Control Module (ECM) Power Supply Relay | Left rear of engine compartment. (Scheme 64) |
| Park/Neutral Position (PNP) Relay | Left rear of engine compartment. (Scheme 67) |
| Secondary Air Injection (AIR) Pump Relay | Left rear of engine compartment. (Scheme 75) |
| Starter Interlock Alarm System Relay (A/T) | Left rear of engine compartment. (Scheme 83) |
| Warning Buzzer (Parking) (Avant) | Left side of cargo area. (Scheme 91) |
| Warning Buzzer (Parking) (Sedan) | Under package shelf. (Scheme 92) |
BUZZERS, RELAYS & TIMERS LOCATION
CIRCUIT PROTECTION DEVICES
| Component | Location |
|---|---|
| Fuse Strip | Rear of engine compartment, in plenum. (Scheme 98) |
| Rear Shade Circuit Breaker | Left side of dash. (Scheme 69) |
CIRCUIT PROTECTION DEVICES LOCATION
CONTROL UNITS
| Component | Location |
|---|---|
| ABS Control Module (W/EDL) | At left side of engine compartment. (Scheme 2) |
| Air Bag Control Module | Below center console. (Scheme 4) |
| Antenna Module (Left) | Under left side of luggage compartment lid. (Scheme 131) |
| Antenna Module (Right) | Under right side of luggage compartment lid. (Scheme 143) |
| Central Control Module (Comfort System) | Below driver's seat. (Scheme 14) |
| Convertible Top Control Module | Behind right quarterpanel. (Scheme 116) |
| Coolant FC (Fan Control) Control Module | Front of engine compartment. (Scheme 22) |
| Door Control Module (Driver Side) | Integrated in driver's door window regulator motor. (Scheme 25) |
| Door Control Module (Left Rear) | Integrated in left rear door window regulator motor. (Scheme 27) |
| Door Control Module (Passenger Side ) | Integrated in right front door window regulator motor. (Scheme 26) |
| Door Control Module (Right Rear) | Integrated in right rear door window regulator motor. (Scheme 28) |
| Entry Assistance Control Module (Left) | Under driver's seat. (Scheme 132) |
| Entry Assistance Control Module (Right) | Under front passenger's seat. (Scheme 144) |
| Fresh Air Blower Control Module | Below right side of dash. (Scheme 15) |
| Garage Door Opener Control Module | Behind right side of front bumper. (Scheme 99) |
| Headlight Range Control Module | Behind right side of dash. (Scheme 45) |
| Heated Seat Control Module (Left Rear) | Rear of center console. (Scheme 53) |
| Heated Seat Control Module (Right Rear) | Rear of center console. (Scheme 73) |
| Heated Windshield Control Module | Rear center of engine compartment. (Scheme 46) |
| High-Intensity Gas Discharge Lamp Control Module (Left) | At left headlight assembly. (Scheme 100) |
| High-Intensity Gas Discharge Lamp Control Module (Right) | At right headlight assembly. (Scheme 104) |
| Instrument Cluster Control Module | Behind instrument cluster. (Scheme 20) |
| Memory Seat Control Module | Under driver's seat. (Scheme 62) |
| Motronic Engine Control Module (ECM) | Left rear of engine compartment, in plenum chamber. (Scheme 63) |
| Navigation Control Module W/CD (Avant) | Left rear of cargo area. (Scheme 16) |
| Navigation Control Module W/CD (Convertible) | Left side of luggage compartment. (Scheme 111) |
| Navigation Control Module W/CD (Sedan) | Left side of trunk. (Scheme 17) |
| Parking Aid Control Module (Avant) | Left side of cargo area. (Scheme 18) |
| Parking Aid Control Module (Sedan) | Left side of trunk. (Scheme 19) |
| Power Sunroof Control Module | Under roof console. (Scheme 102) |
| Radar Interior Monitoring Control Module 1 | Under center console. (Scheme 141) |
| Radar Interior Monitoring Control Module 2 | Under center of rear seat. (Scheme 142) |
| Rear Window Shade Control Module | Under package shelf. (Scheme 70) |
| Servotronic Control Module | At left side of dash. (Scheme 82) |
| Steering Column Electronic Systems Control Module | On steering column, behind steering wheel. (Scheme 85) |
| Telephone/Telematic Control Module | Under passenger's seat. (Scheme 87) |
| Throttle Valve Control Module (1.8L) | On intake manifold. (Scheme 210) |
| Throttle Valve Control Module (3.0L) | Behind intake manifold, on throttle valve housing. (Scheme 211) |
| Transmission Control Module (TCM) (CVT) | At rear of transmission. (Scheme 88) |
| Vehicle Electrical System Control Module | At left side of dash. (Scheme 90) |
CONTROL UNITS LOCATION
MOTORS
| Component | Location |
|---|---|
| ABS Hydraulic Unit | Left side of engine compartment. (Scheme 3) |
| Brake System Vacuum Pump (A/T) | Left side of engine compartment. (Scheme 13) |
| Convertible Top Compartment Cover Locking Motor | Center rear of convertible top compartment. (Scheme 113) |
| Convertible Top Hydraulic Pump | Right side of luggage compartment. (Scheme 119) |
| Convertible Top Locking Motor | Center Front Of Convertible Top. (Scheme 125) |
| Driver's Seat Seatback Adjustment Motor | In driver's seat back. (Scheme 135) |
| Front Passenger's Backrest Adjusting Motor | In front passenger's seat back. (Scheme 130) |
| Headlight Beam Adjusting Motor (Left) | In left headlight assembly. (Scheme 133) |
| Headlight Beam Adjusting Motor (Right) | In right headlight assembly. (Scheme 145) |
| Leak Detection Pump (LDP) | In left rear wheel well. (Scheme 50) |
| Lock Unit For Central Locking (Driver's) | Rear of driver's door. (Scheme 57) |
| Lock Unit For Central Locking (Left Rear) | Rear of left rear door. (Scheme 59) |
| Lock Unit For Central Locking (Passenger's) | Rear of passenger's door. (Scheme 58) |
| Lock Unit For Central Locking (Right Rear) | Rear of right rear door. (Scheme 60) |
| Power Sunroof Motor | Under roof console. (Scheme 103) |
| Seat Lumbar Support Curvature Adjustment Motor (Driver's) | In driver's seat back. (Scheme 94) |
| Seat Lumbar Support Curvature Adjustment Motor (Front Passenger's) | In front passenger's seat back. (Scheme 97) |
| Seat Lumbar Support Height Adjustment Motor (Driver's) | In driver's seat back. (Scheme 95) |
| Seat Lumbar Support Height Adjustment Motor (Front Passenger's) | In front passenger's seat back. (Scheme 96) |
| Secondary Air Injection (AIR) Pump Motor | Right front of engine compartment. (Scheme 206) |
| Window Regulator Motor (Left Rear) | Behind left quarterpanel. (Scheme 136) |
| Window Regulator Motor (Right Rear) | Behind right quarterpanel. (Scheme 137) |
MOTORS LOCATION
SENDING UNITS/SENSORS
| Component | Location |
|---|---|
| Accelerator Pedal Position Sender 2 | At accelerator pedal. (Scheme 76) |
| Air Quality Sensor (6) | Right side of engine compartment. see scheme 214 |
| Brake Booster Pressure Sensor | On right side of brake booster. (Scheme 93) |
| Brake Pressure Sensor 1 | Left side of engine compartment. (Scheme 12) |
| Camshaft Position (CMP) Sensor (1.8L) | Left front of engine. (Scheme 163) |
| Camshaft Position (CMP) Sensor 2 | Left rear of engine. (Scheme 165) |
| Camshaft Position (CMP) Sensor 3 | Right rear of engine. (Scheme 166) |
| Camshaft Position (CMP) Sensor (3.0L) | Right rear of engine. (Scheme 164) |
| Camshaft Position (CMP) Sensor 4 | Left rear of engine. (Scheme 167) |
| Convertible Top Frame Position Sensor | At right convertible top main mount. (Scheme 117) |
| Engine Coolant Temperature (ECT) Sensor (1.8L) | Lower rear of engine. (Scheme 178) |
| Engine Coolant Temperature (ECT) Sensor (3.0L) | Lower right rear of engine. (Scheme 179) |
| Front Air Bag Crash Sensor (Driver's Side) | Left front of engine compartment. (Scheme 29) |
| Front Air Bag Crash Sensor (Passenger's Side) | Right front of engine compartment. (Scheme 68) |
| Heated Oxygen Sensor (HO2S) (1.8L) | In exhaust, before catalytic converter. (Scheme 184) |
| Heated Oxygen Sensor (HO2S) (3.0L) | Right rear of engine compartment, in exhaust. (Scheme 185) |
| High Pressure Sensor | Left side of A/C condenser. (Scheme 47) |
| Intake Air Temperature (IAT) Sensor | On intake manifold. (Scheme 196) |
| Knock Sensor (KS) 1 (1.8L) | Top of cylinder head. (Scheme 198) |
| Knock Sensor (KS) 2 (1.8L) | Top of cylinder head. (Scheme 199) |
| Light Recognition Sensor | Top of windshield, in rearview mirror assembly. (Scheme 55) |
| Mass Air Flow (MAF) Sensor (1.8L) | Right front of engine compartment. (Scheme 200) |
| Mass Air Flow (MAF) Sensor (3.0L) | On air intake duct. (Scheme 201) |
| Outside Air Temperature Sensor | Behind front bumper. (Scheme 66) |
| Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) | In exhaust, downstream of catalytic converter. (Scheme 202) |
| Parking Aid Sensor (Left Front) | In front bumper. (Scheme 52) |
| Parking Aid Sensor (Left Front Center) | In front bumper. (Scheme 51) |
| Parking Aid Sensor (Left Rear) | On rear bumper. (Scheme 78) |
| Parking Aid Sensor (Left Rear Center) | On rear bumper. (Scheme 79) |
| Parking Aid Sensor (Right Front) | Front bumper. (Scheme 72) |
| Parking Aid Sensor (Right Front Center) | On front bumper. (Scheme 71) |
| Parking Aid Sensor (Right Rear) | On rear bumper. (Scheme 80) |
| Parking Aid Sensor (Right Rear Center) | On rear bumper. (Scheme 81) |
| Rotation Rate Sender | Under front of center console. (Scheme 77) |
| Side Air Bag Crash Sensor (Driver's Side) (Convertible) | At left "B" pillar. (Scheme 128) |
| Side Air Bag Crash Sensor (Driver's Side) (Except Convertible) | At left "B" pillar. (Scheme 23) |
| Side Air Bag Crash Sensor (Left Rear) | At bottom of left "C" pillar. (Scheme 54) |
| Side Air Bag Crash Sensor (Passenger's Side) (Convertible) | At right "B" pillar. (Scheme 129) |
| Side Air Bag Crash Sensor (Passenger's Side) (Except Convertible) | At right "B" pillar. (Scheme 24) |
| Side Air Bag Crash Sensor (Right Rear) | At bottom of right "C" pillar. (Scheme 74) |
| Steering Angle Sensor | Behind steering wheel. (Scheme 84) |
| Sunlight Photo Sensor | Under center of dash. (Scheme 147) |
| Throttle Position Sensor | On accelerator pedal. (Scheme 209) |
| Ultra-Sound Sensor For Anti-Theft | In roof console. (Scheme 89) |
SENDING UNITS & SENSORS LOCATION
SOLENOIDS & SOLENOID VALVES
| Component | Location |
|---|---|
| ABS Hydraulic Unit | Left side of engine compartment. (Scheme 3) |
| A/C Compressor Regulator Valve (12) | On air conditioner compressor. see scheme 214 |
| Camshaft Adjustment Valve 1 (1.8L) | Rear of cylinder head. (Scheme 160) |
| Camshaft Adjustment Valve 1 (3.0L) | Front of right cylinder head. (Scheme 161) |
| Camshaft Adjustment Valve 2 | Front of left cylinder head. (Scheme 162) |
| Evaporative Emissions (EVAP) Canister Purge Regulator Valve (1.8L) | On intake air box. (Scheme 180) |
| Evaporative Emissions (EVAP) Canister Purge Regulator Valve (3.0L) | Above air intake box. (Scheme 181) |
| Fuel Injector No. 1 (1.8L) | Top front of engine. (Scheme 168) |
| Fuel Injector No. 1 (3.0L) | Top of right cylinder bank. (Scheme 169) |
| Fuel Injector No. 2 (1.8L) | Top center of engine. (Scheme 170) |
| Fuel Injector No. 2 (3.0L) | Top of right cylinder bank. (Scheme 171) |
| Fuel Injector No. 3 (1.8L) | Top center of engine. (Scheme 172) |
| Fuel Injector No. 3 (3.0L) | Top of right cylinder bank. (Scheme 173) |
| Fuel Injector No. 4 (1.8L) | Top rear of engine. (Scheme 174) |
| Fuel Injector No. 4 (3.0L) | Top front of left cylinder bank. (Scheme 175) |
| Fuel Injector No. 5 (3.0L) | Top center of left cylinder bank. (Scheme 176) |
| Fuel Injector No. 6 (3.0L) | Top rear of left cylinder bank. (Scheme 177) |
| Intake Manifold Change-Over Valve | Left front of engine. (Scheme 197) |
| Power Convertible Top Valve 1 | Right side of luggage compartment. (Scheme 138) |
| Power Convertible Top Valve 2 | Right side of luggage compartment. (Scheme 139) |
| Power Convertible Top Valve 3 | Right side of luggage compartment. (Scheme 140) |
| Rollover Solenoid (Left) | Behind left rear seat back. (Scheme 134) |
| Rollover Solenoid (Right) | Behind right rear seat back. (Scheme 146) |
| Secondary Air Injection (AIR) Solenoid Valve (1.8L) | Left side of engine. (Scheme 207) |
| Secondary Air Injection (AIR) Solenoid Valve (3.0L) | Rear of engine. (Scheme 208) |
| Turbocharger Recalculating Valve | Left rear of engine. (Scheme 212) |
| Wastegate Bypass Regulator Valve | Right front of engine. (Scheme 213) |
SOLENOIDS & SOLENOID VALVES LOCATION
SWITCHES
| Component | Location |
|---|---|
| Ambient Temperature Switch | Front of vehicle. (Scheme 5) |
| Brake Fluid Level Warning Switch | On brake fluid reservoir. (Scheme 11) |
| Compartment Cover Locked Right Switch 1 | Right side of convertible top compartment. (Scheme 108) |
| Compartment Cover Open Position Switch | Right side of convertible top compartment. (Scheme 109) |
| Compartment Left Locked Switch | Left side of convertible top compartment. (Scheme 110) |
| Convertible Top Closed Position Switch | Right side of convertible top compartment. (Scheme 112) |
| Convertible Top Compartment Enclosure Position Switch | Right side of luggage compartment. (Scheme 114) |
| Convertible Top Compartment Latch Switch (Unlock) | Center rear of convertible top compartment. (Scheme 115) |
| Convertible Top Front Lock Switch | Top center of windshield header. (Scheme 118) |
| Convertible Top Left Lock Switch | Left side of windshield header. (Scheme 122) |
| Convertible Top Lock Switch (Closed) | Center front of convertible top. (Scheme 123) |
| Convertible Top Lock Switch (Open) | Center front of convertible top. (Scheme 124) |
| Convertible Top Open Position Switch (Stored) | Right side of convertible top compartment. (Scheme 126) |
| Convertible Top Right Lock Switch | Right side of windshield header. (Scheme 127) |
| Multi-Function Transmission Range (TR) Switch | Left side of transmission. (Scheme 65) |
SWITCHES LOCATION
MISCELLANEOUS
| Component | Location |
|---|---|
| Alarm Horn | Right side of convertible top compartment. (Scheme 106) |
| Amplifier (Avant) | Right side of cargo area. (Scheme 6) |
| Amplifier (Sedan) | Right side of trunk. (Scheme 7) |
| Antenna (Central Locking & Anti-Theft Alarm System) | Under left side of luggage compartment lid. (Scheme 107) |
| Antenna Splitter | Below front passenger's seat. (Scheme 9) |
| Antenna (Telephone) | Right front of vehicle. (Scheme 8) |
| Antenna 2 (Telephone) | Under right rear of vehicle. (Scheme 86) |
| Diagnostic Connector (DLC) | Under left side of dash. (Scheme 1) |
| Ignition Coil 1 W/Power Output Stage (1.8L) | Top front of engine. (Scheme 186) |
| Ignition Coil 1 W/Power Output Stage (3.0L) | Right side of engine. (Scheme 187) |
| Ignition Coil 2 W/Power Output Stage (1.8L) | Top of engine. (Scheme 188) |
| Ignition Coil 2 W/Power Output Stage (3.0L) | Right side of engine. (Scheme 189) |
| Ignition Coil 3 W/Power Output Stage (1.8L) | Top of engine. (Scheme 190) |
| Ignition Coil 3 W/Power Output Stage (3.0L) | Right side of engine. (Scheme 191) |
| Ignition Coil 4 W/Power Output Stage (1.8L) | Top of engine. (Scheme 192) |
| Ignition Coil 4 W/Power Output Stage (3.0L) | Left side of engine. (Scheme 193) |
| Ignition Coil 5 W/Power Output Stage (3.0L) | Left side of engine. (Scheme 194) |
| Ignition Coil 6 W/Power Output Stage (3.0L) | Left side of engine. (Scheme 195) |
| Induction Coil (Anti-Theft Immobilizer) | Right side of steering column. (Scheme 49) |
| Oxygen Sensor (O2S) Heater 1 (Behind Three Way Catalytic Converter (TWC)) | Integral to oxygen sensor (O2S) behind three way catalytic converter (TWC). (Scheme 205) |
| Oxygen Sensor (O2S) Heater (1.8L) | Integral to oxygen sensor (O2S). (Scheme 203) |
| Oxygen Sensor (O2S) Heater (3.0L) | Integral to oxygen sensor (O2S). (Scheme 204) |
| Washer Nozzle Heater (Left) | Under left rear of engine compartment lid. (Scheme 101) |
| Washer Nozzle Heater (Right) | Under right rear of engine compartment lid. (Scheme 105) |
MISCELLANEOUS LOCATION
CONNECTORS
| Component | Location |
|---|---|
| T3a (3 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 152) |
| T3b (1.8L) (3 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 150) |
| T3b (3.0L) (3 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 151) |
| T3e (3 Pin) | Right rear of engine compartment, on bulkhead. (Scheme 153) |
| T3 (1.8L) (3 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 148) |
| T3 (3.0L) (3 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 149) |
| T4a (4 Pin) | Right rear of engine compartment, on bulkhead. (Scheme 155) |
| T4c (4 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 156) |
| T4 (4 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 154) |
| T6a (6 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 159) |
| T6 (1.8L) (6 Pin) | Left rear of engine compartment, on bulkhead. (Scheme 157) |
| T6 (3.0L) (6 Pin) | Right rear of engine compartment, on bulkhead. (Scheme 158) |
CONNECTORS LOCATION
GROUNDS
| Component | Location |
|---|---|
| G3 | Right side of engine compartment. (Scheme 44) |
| G11 | Right rear of engine compartment. (Scheme 42) |
| G12 | Left rear of engine compartment. (Scheme 43) |
| G18 (1.8L) | Left front of engine. (Scheme 182) |
| G18 (3.0L) | Rear of left cylinder head. (Scheme 183) |
| G26 | Left side of engine compartment. (Scheme 41) |
| G32 | Left kick panel. (Scheme 40) |
| G43 | Above right kick panel. (Scheme 38) |
| G44 | Above left kick panel. (Scheme 37) |
| G50 | Left side of luggage compartment. (Scheme 32) |
| G73 | Rear of roof. (Scheme 35) |
| G77 | Left "B" pillar. (Scheme 34) |
| G78 | Right "B" pillar. (Scheme 33) |
| G347 | Front of center console. (Scheme 39) |
| G610 | Under front of center console. (Scheme 36) |
GROUNDS LOCATION
COMPONENT LOCATION GRAPHICS
Note. Figures may show multiple component locations. Refer to appropriate table for proper figure references.
