Fuel Supply System

For all Fuel Supply system component locations. Refer to --> 20 - FUEL SUPPLY SYSTEM

For all Fuel supply system removal/installation procedures and torque specifications. Refer to --> 20 - FUEL SUPPLY SYSTEM

Check the Technical Bulletins for information that may supersede any information included in this article.

Note. All manufacturers special tools as well as common tools may contain a manufacturer specific part number. These tools may be substituted with an equivalent aftermarket tool or are available for purchase through Audi. Manufacturers special tools as well as common tools that contain a manufacturer specific part number may be referenced in the test procedure illustrations showing the tool use or installation. If the manufacturer specific tool is not being used, an equivalent aftermarket tool may be installed in the same manner as the manufacturers special tool.

Safety Precautions

CAUTIONThe fuel system is under pressure! Before opening the system, place rags around the connection area. Then release the pressure by carefully loosening the connection. The engine section of the fuel system, after the high pressure pump, is under extremely high pressure! When working on the engine or the fuel injection system, the pressure must be relieved to residual pressure before opening the high pressure components --> 24 - FUEL INJECTION SYSTEM . Place sources of flame, e.g. cigarette lighters, as well as those sources of others in the area, out of reach. These can ignite fuel vapors. The use of nails, paper clips, or another unauthorized materials to back-probe electrical harness connectors is strictly prohibited and may cause damage to the electrical harness connectors, terminal ends or damage to a component. Use only the manufacturers test lead kit or an equivalent aftermarket test lead kit for back-probing all electrical harness connectors.

Perform the following steps before beginning work on the fuel supply system

  1. Disconnect the battery Ground (GND) cable with the ignition switched off --> «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment) 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET .
  2. Open the fuel filler flap briefly and then close again.

When removing and installing components from full or partially full fuel tanks, observe the following

  1. The fuel tank must only be partially full. How much fuel can remain in the fuel tank may be read in the respective work description. Empty the fuel tank if necessary.
  2. Before starting work, switch on the exhaust extraction system and place an extraction hose close to the installation opening of the fuel tank to extract escaping fuel fumes. If no exhaust extraction system is available, a radial fan (as long as motor is not in air flow) with a displacement greater than 15 m 3 /h can be used.
  3. Prevent fuel from contacting the skin! Wear fuel-resistant gloves!

Observe the following when removing and installing the fuel tank

  1. Empty the fuel tank for weight reasons.

Rules for Cleanliness

When working on the fuel supply/injection system, pay careful attention to the following rules of cleanliness

  1. Thoroughly clean all connections and the surrounding area before disconnecting.
  2. Place parts that have been removed on a clean surface and cover them. Do not use fluffy cloths!
  3. Carefully cover over opened components or seal, if repairs are not performed immediately.
  4. Only install clean components: Only unpack replacement parts immediately prior to installation. Do not use parts that have been stored unpacked (e.g. in tool boxes etc.).
  1. When the system is open: Do not work with compressed air. Do not move vehicle unless absolutely necessary.

Fuel System, Bleeding

To prevent damage to the catalytic converter the fuel system must be bled after repair work on fuel lines or on the fuel filter.

Fuel system, bleeding --> 24 - FUEL INJECTION SYSTEM .

Fuel Pump Delivery Quantity, Checking

Special tools, testers and auxiliary items required

  1. Hand held remote control (jumper).
  2. Multimeter.
  3. Electrical connector test lead set.
  4. Pressure gauge (High pressure)
  1. Measuring container (fuel resistant).

Test conditions

  1. Battery voltage at least 12.5 V.
  2. The fuel filter OK
  3. Fuse S228 OK.
  4. Fuel Pump (FP) Control Module J538 OK --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#fuel-supply-system) .
  1. Fuel tank at least 1 / 4 filled.
  2. The ignition switched off.

Test sequence

  1. Remove the rear seat bench --> «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Scheme 988

Scheme 988
Scheme 988
  1. Remove the right locking flange cover and bolts - arrows -.

Scheme 989

Scheme 989
Scheme 989
  1. Disconnect the electrical harness connector - arrow - at the right locking flange.
  2. Connect a Hand held remote control (jumper) to terminal - 1 - of the fuel delivery unit and to vehicle battery (+).

Scheme 990

Scheme 990
Scheme 990
  1. Connect a jumper cable from a Electrical connector test lead set to terminal - 4 - of the fuel delivery unit and to vehicle Ground (GND).
  2. Remove the fuel filler cap.

Scheme 991

Scheme 991
Scheme 991
  1. Remove the rear engine cover - arrows -.
CAUTIONThe fuel system is under pressure! Before opening system, place rags around the connection area. Then release pressure by carefully loosening the connection.

Scheme 992

Scheme 992
Scheme 992
  1. Disconnect the fuel line - arrow -.
  2. Connect a Pressure gauge (High pressure) to the fuel line.
  3. Connect the extension hose - arrow - to the pressure gauge and hold it in a measuring container.
  4. Open the pressure gauge shut-off valve. The lever points in the direction of flow.
  1. Create fuel system pressure by pressing the switch on the Hand held remote control (jumper) in and slowly closing the shut-off valve of the pressure gauge.

Scheme 993

Scheme 993
Scheme 993
  1. Pump the fuel
  1. Specification: 4 bar positive pressure.
  1. Do not move the position of the shut-off valve.
  2. Empty the measuring container.

Scheme 994

Scheme 994
Scheme 994
  1. Press the switch on the Hand held remote control (jumper) in for 15 seconds.
  2. Compare the quantity of fuel delivered with the minimum delivery rate in the diagram (cm 3 /15s).

Note. Voltage at the fuel pump with the engine stopped and the pump running is approx. 2 volts less than the battery voltage.

If the minimum delivery quantity is not obtained, the following malfunctions may be present

  1. Fuel lines pinched.
  2. Fuel filter clogged.
  3. Fuel pump faulty.

Installation

  1. Connect the fuel line - arrow -.
  1. Install the rear engine cover - arrows -.
  1. Connect the electrical harness connector - arrow - at the right locking flange.
  1. Install the right locking flange cover and bolts - arrows -.
  2. Install the rear seat bench --> «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Torque specifications

ComponentNm
Fuel line to fuel rail22

Fuel Pump Electrical, Checking

Special tools, testers and auxiliary items required

  1. Hand held remote control (jumper).
  2. Multimeter.
  3. Electrical connector test lead set.
  4. Pressure gauge (High pressure)

Test conditions

  1. Battery voltage at least 12.5 V.
  2. The fuel pump fuse OK.
  3. The Fuel Pump (FP) Control Module J538 OK.
  4. The fuel filter OK
  1. The ignition switched off.

Test sequence

  1. Remove the rear seat bench --> «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
  1. Remove the right locking flange cover and bolts - arrows -.
  1. Disconnect the electrical harness connector - arrow - at the right locking flange.
  2. Connect a Hand held remote control (jumper) to terminal - 1 - of the fuel delivery unit and to vehicle battery (+).
  1. Connect a jumper cable from a Electrical connector test lead set to terminal - 4 - of the fuel delivery unit and to vehicle Ground (GND).
  2. Press the switch on the Hand held remote control (jumper) in.

Note. The Fuel Pump (FP) runs quietly. Avoid surrounding noises while testing the fuel pump.

The fuel pump must run and an audible noise of the fuel pump running should be heard.

If no operating noise can be heard

Scheme 995

Scheme 995
Scheme 995
  1. Using a Multimeter , check the electrical circuit between terminals - 1 - and - 5 - of the fuel delivery unit for continuity.

Specified value: 0 ohms.

If a malfunction is detected in the electrical circuit

  1. Check the wiring for a short circuit to Battery positive (+) or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the electrical circuit.

If no malfunction is detected in the wiring, replace the fuel pump. --> 20 - FUEL SUPPLY SYSTEM .

  1. Install the fuel delivery unit --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#fuel-supply-system) .

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory.
  3. If the DTC memory was erased, generate readiness code.
  1. End of diagnosis.

Evaporative Emissions (EVAP) System

EVAP System, Leak Detection

Function

The leak detection system recognizes leaks in the complete fuel system, including the fuel tank, EVAP canister and the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80.

On the mechanical side, the leak detection system consists mainly of a vacuum-driven diaphragm pump equipped with a reed contact on the actuation rod of the pump diaphragm. The pump is supplied with vacuum via the engine intake stroke.

  1. When leak detection is activated, the diaphragm pump pumps the fuel system up to 20 - 30 mbar. The pump diaphragm is then moved out so that the reed contact at the operating rod remains in the "open" position.
  2. During the leak diagnosis, the reed contact is monitored to check if it remains open within 10 seconds. This indicates the system is sealed.
  3. If the pressure falls (indicating a leak), the diaphragm moves back and the reed contact closes.
  4. If the reed contact closes within 10 seconds of leak detection time, a further test is performed: In this case the diaphragm pump pumps four times again. The Engine Control Module (ECM) J623 measures the time for each of the four pumps until the reed contact is closed again. From that, the control module can recognize a "small leak" (greater than 1 mm in diameter) or a "large leak".

Leak diagnosis is activated automatically shortly following every engine start. If a malfunction is determined, an entry is made to the Diagnostic Trouble Code (DTC) memory. The Malfunction Indicator Lamp (MIL) K83 in the instrument cluster lights up if the malfunction is recognized for two subsequent starts.

EVAP System, Checking for Leaks

Special tools, testers and auxiliary items required

  1. Smoke tester.
  2. EVAP and Fuel Supply System Vacuum hose and line routing diagram.

Note. Secure all hose connections using hose clamps appropriate for the model type . Replace seals and gaskets when performing repair work.

Leak checking

  1. Using a Smoke tester , check the Evaporative Emission (EVAP) canister system for leaks.

Note. Always follow the manufacturers directions for the proper installation and operation of the Smoke tester being used.

If a leak is found

  1. Check the fuel filler cap seal for damage and for proper installation. Replace if necessary.
  2. Check the seals under the locking flanges and the union nuts are properly tightened on the fuel tank.
  3. Check all hose connections of the fuel supply system and replace or repair any leaking lines.
  4. Check all hose connections of the EVAP system and replace or repair any leaking lines.
  1. Repair or replace any damaged component.

If no leaks are found in the EVAP and Fuel Supply System

  1. Erase the DTC memory if a DTC was set. Refer to --> «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  2. Perform a road test to verify repair.

If a DTC was set and does not return

Repair complete, Generate readiness code. Refer to --> Readiness Code .

  1. End diagnosis.

If the DTC returns and no leaks are found in the EVAP and Fuel Supply System

  1. Check the DTC memory for any DTC codes pertaining to the EVAP and Fuel Supply Systems. If a DTC is stored, perform the diagnostic test procedure for the suspected component. Refer to --> «Diagnostic Mode 03: Interrogating Fault Memory»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-03-interrogating-fault-memory) .

End diagnosis.

Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 fuse OK.
  2. The ignition switched off.

Note. Voltage for the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 is supplied via the Engine Component Power Supply Relay J757.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.

Scheme 996

Scheme 996
Scheme 996
  1. Disconnect the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 electrical harness connector - 3 -.

Checking internal resistance

Scheme 997

Scheme 997
Scheme 997
  1. Using a Multimeter , check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 terminals 1 and 2 for resistance.

Specified value: 22,0 to 30,0 ohms.

Engine Component Power Supply Relay J757

  1. Replace the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80.

If the specification is obtained

Checking voltage supply

Scheme 998

Scheme 998
Scheme 998
  1. Using a Multimeter , check the electrical harness connector terminal 1 to 2 for voltage.
  2. Operate the starter briefly.

Specified value: battery voltage.

If the specified value was not obtained

  1. Using a Multimeter , check the electrical harness connector terminal 1 to Ground (GND) for voltage.
Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 electrical harness connector terminalMeasure to
1Engine Ground (GND)
  1. Operate the starter briefly.

Specified value: battery voltage.

If the specified value is not obtained

  1. Check the wiring connection from the electrical harness connector terminal 1 to the Engine Component Power Supply Relay J757 terminal 2/87 for an open circuit or short to Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the wiring connection.

If the specified value was obtained

Check Ground (GND) activation

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 electrical connector terminal 2 to Engine Control Module (ECM) J623 electrical connector T94 terminal 49 for an open circuit.
Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 electrical harness connector terminalEngine Control Module (ECM) J623 electrical connector T60 terminal test box socket
249

Specified value: 1.5 ohms max.

If the specification is not obtained

  1. Check the wiring for a short circuit to Battery positive (+), Ground (GND) or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the wiring connection.

If the specification was obtained

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Leak Detection Pump (LDP) V144 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Leak Detection Pump (LDP) V144 fuse OK.
  2. The ignition switched off.

Procedure

  1. Remove the left rear wheel housing liner. --> «66 EXTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/door-locks-anti-theft-systems/#body-exterior) «66 - EXTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) for BODY EXTERIOR - CABRIOLET .

Scheme 999

Scheme 999
Scheme 999
  1. Disconnect the Leak Detection Pump (LDP) V144 electrical harness connector - 2 -.

Checking internal resistance

Scheme 1000

Scheme 1000
Scheme 1000
  1. Using a Multimeter , check the Leak Detection Pump (LDP) V144 for resistance as follows
Leak Detection Pump (LDP) V144 electrical harness connector terminalsSpecified values
1 - + - 3640 to 720 ohms
2 - + - 315 to 17 ohms

If any of the specifications are not obtained

  1. Replace the Leak Detection Pump (LDP) -V144-. --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#fuel-supply-system) .

If the specified values are obtained

Checking voltage supply

Note. The voltage for the Leak Detection Pump (LDP) -V144- is supplied by the Engine Component Power Supply Relay J757.

Scheme 1001

Scheme 1001
Scheme 1001
  1. Using a Multimeter , check the Leak Detection Pump (LDP) -V144- electrical harness connector terminal 3 to Ground (GND) for voltage.
Leak Detection Pump (LDP) -V144- electrical harness connector terminalMeasure to
3Engine Ground (GND)
  1. Operate the starter briefly.

Specified value: battery voltage.

  1. Switch the ignition off.

If the specified value was not obtained

  1. Using a Multimeter , check the Leak Detection Pump (LDP) -V144- electrical harness connector terminal 3 to the Engine Component Power Supply Relay J757 terminal 2/87 for resistance.

Specified value: 1.5 Ohms

If the specified value was not obtained

  1. Check the wiring for a short circuit to Ground (GND) or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring and if the voltage supply was OK

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a Multimeter , check the Leak Detection Pump (LDP) -V144- electrical connector terminal 1 to Engine Control Module (ECM) J623 electrical connector T94 terminal 20 for an open circuit.
  1. Using a Multimeter , check the Leak Detection Pump (LDP) -V144- electrical connector terminal 2 to Engine Control Module (ECM) J623 electrical connector T94 terminal 24 for an open circuit.
Leak Detection Pump (LDP) -V144- electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
120
224

Specified value: 1.5 ohms max.

If the specification was not obtained

  1. Check the wiring for a short circuit to Battery positive (+), or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Electronic Power Control (EPC)

Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram

Test requirement

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. Battery voltage at least 12.5 volts.
  3. All electrical consumers such as, lights and rear window defroster, switched off.
  4. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.

Note. Use only gold-plated terminals when servicing the electrical harness connector terminals in Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. The Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 is located in the accelerator pedal module and communicate the drivers intensions to the Engine Control Module (ECM) J623 completely independently of each other. Both sensors are located in the accelerator pedal module and replaced as an entire assembly.

Test sequence

  1. Remove the left knee panel --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Scheme 1002

Scheme 1002
Scheme 1002
  1. Disconnect the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 electrical harness connector - 2 -.

Checking voltage supply

  1. Switch the ignition on.

Scheme 1003

Scheme 1003
Scheme 1003
  1. Using a Multimeter , check the following wiring connections for voltage.
Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 electrical harness connector terminalsSpecified value
1 to Ground (GND)About 5 V
1 to 5About 5 V
2 to Ground (GND)About 5 V
2 to 3About 5 V
  1. Switch the ignition off.

If the specification was not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical connector T94 for an open circuit.
Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
158
280
356
457
578
679

Specified value: 1.5 ohms max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring and if the voltage supply was OK

  1. Replace the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#fuel-supply-system) .

If no malfunction is detected in the wiring and if the voltage supply was not OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Install the left knee panel --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End diagnosis and switch the ignition off.

Simos Fuel Injection System, Servicing

For all fuel injection system component locations. Refer to --> 24 - FUEL INJECTION SYSTEM

For all Fuel supply system removal/installation procedures and torque specifications. Refer to --> 24 - FUEL INJECTION SYSTEM

Check the Technical Bulletins for information that may supersede any information included in this article.

Note. All manufacturers special tools as well as common tools may contain a manufacturer specific part number. These tools may be substituted with an equivalent aftermarket tool or are available for purchase through Audi. Manufacturers special tools as well as common tools that contain a manufacturer specific part number may be referenced in the test procedure illustrations showing the tool use or installation. If the manufacturer specific tool is not being used, an equivalent aftermarket tool may be installed in the same manner as the manufacturers special tool. The manufacturers test box Test Box 105 Pin VAG1598/42 is available for purchase or rental.

To reduce the risk of personal injury and/or damage to the fuel injection and ignition system. Note the following

CAUTIONThe fuel system is under high pressure! Before opening high pressure components of the fuel injection system, pressure must be relieved to residual pressure. Wrap a clean rag around the connection and relieve residual pressure by carefully loosening the connection.
  1. Always switch off ignition before disconnecting or connecting lines of the fuel injection and ignition system, including test leads.
  2. During some of the tests, a Diagnostic Trouble Code (DTC) may be recognized and stored by the control module. At the end of all tests and repairs, the DTC memory should be checked and, if necessary, erased. After erasing the DTC memory, a readiness code must be generated.
  3. Always switch the ignition off before cleaning engine.
CAUTIONThe battery must only be disconnected and connected with the ignition switched off, since the Engine Control Module (ECM) J623 can otherwise be damaged. Observe procedures for disconnecting the battery --> 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET .

Observe the following if test and measuring instruments are required during a test drive

CAUTIONTest and measuring equipment must always be secured to the rear seat and be operated from there by a second person. If test and measuring instruments are operated from the front passengers seat and the vehicle is involved in an accident, there is a possibility that the person sitting in this seat may receive serious injuries when the airbag is deployed.

Even minor contaminations can lead to malfunctions in the fuel injection system. When working on the fuel supply/injection system, pay careful attention to the following rules for cleanliness

  1. Thoroughly clean all unions and adjacent areas with engine or brake cleaner and dry before disconnecting.
  2. Plug open lines and connections immediately with appropriate protective caps.
  3. Place removed parts on a clean surface and cover. Use lint-free cloths.
  4. Install clean components: Remove replacement parts immediately prior to installation. Do not use parts that have been stored unpackaged (e.g. in tool boxes etc.).
  1. When the system is open: Do not work with compressed air. Do not move vehicle unless absolutely necessary.
  2. Separated electrical connectors: Protect from dirt and moisture. Make sure connections are dry when reconnecting.

Technical Data

Engine codeBKH (3.2 l/4V/188 kW engine)
Engine idle speed (Not adjustable)650 to 750 RPM
Fuel pressure after high-pressure pumpApprox. 35 bar positive pressure
Fuel pressure before high-pressure pumpApprox. 6 bar positive pressure

Components, Checking

Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking

This procedure is used to check Oxygen Sensor (O2S) Heater Z19 or Oxygen Sensor (O2S) Heater Z28.

Note. When servicing terminals in harness connector of Heated Oxygen Sensors (HO2S) , use only gold-plated terminals.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Heated Oxygen Sensor (HO2S) G39 fuse OK.
  2. The Heated Oxygen Sensor (HO2S) 2 G108 fuse OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  2. A/C switched off.
  3. Ground (GND) connections between engine/transmission/chassis OK.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

Scheme 1004

Scheme 1004
Scheme 1004
  1. Disconnect the Oxygen Sensor (O2S) Heater Z19 electrical harness connector - 1 -.

To disconnect the Oxygen Sensor (O2S) Heater -Z28- , perform the following steps

Scheme 1005

Scheme 1005
Scheme 1005
  1. Remove the screw - arrow - retaining the coolant reservoir.
  2. Disconnect the Engine Coolant Level (ECL) Warning Switch F66 electrical connector from the bottom of the coolant reservoir and set aside the coolant reservoir with the coolant hoses - 1 - and - 2 - connected.

Scheme 1006

Scheme 1006
Scheme 1006
  1. Disconnect the Oxygen Sensor (O2S) Heater -Z28- electrical harness connector - 2 -.

Checking internal resistance

Scheme 1007

Scheme 1007
Scheme 1007
  1. Using a multimeter , check the Heated Oxygen Sensor (HO2S) terminals 3 to 5 for resistance.

Specified value: 2.5 to 10.0 ohms (at approx. 20°C)

If the specification was not obtained

  1. Replace the faulty Heated Oxygen Sensor (HO2S) before the catalytic converter. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the specification was obtained

Checking voltage supply

Switch the ignition on.

  1. Using a multimeter , check the Heated Oxygen Sensor (HO2S) electrical harness connector terminal 5 to the Engine Component Power Supply Relay J757 terminal 2/87 for voltage.
Heated Oxygen Sensor (HO2S) electrical harness connector terminalEngine Component Power Supply Relay J757 electrical harness connector terminal
52

Switch the ignition off.

Specified value: Battery voltage.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Ground (GND), or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If the specification was obtained

Checking Ground (GND) activation

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Scheme 1008

Scheme 1008
Scheme 1008
  1. Using a multimeter , check the Oxygen Sensor (O2S) Heater electrical harness connector terminal to the Engine Control Module (ECM) J623 electrical harness connector T94 for an open circuit.
Oxygen Sensor (O2S) Heater Z19 electrical harness connector terminalEngine Control Module (ECM) J623 electrical connector T94 terminal or test box socket
351
Oxygen Sensor (O2S) Heater Z28 electrical harness connector terminalEngine Control Module (ECM) J623 electrical connector T94 terminal or test box socket
373

Specified value: 1.5 ohms max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring and if the voltage supply was OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in reverse order of removal, note the following

Final procedures

After repair work, the following work steps must be performed in the mentioned sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking

This procedure is used to check Oxygen Sensor (O2S) Heater Z29 or Oxygen Sensor (O2S) Heater Z30.

Note. When servicing terminals in harness connector of Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , use only gold-plated terminals.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 fuse OK.
  2. The Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131 fuse OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  2. A/C switched off.
  3. Ground (GND) connections between engine/transmission/chassis OK.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Oxygen Sensor (O2S) Heater Z29 electrical harness connector - 2 -.

To disconnect the Oxygen Sensor (O2S) Heater Z30 , perform the following steps

  1. Remove the screw - arrow - retaining the coolant reservoir.
  2. Disconnect the Engine Coolant Level (ECL) Warning Switch F66 electrical connector from the bottom of the coolant reservoir and set aside the coolant reservoir with the coolant hoses - 1 - and - 2 - connected.
  1. Disconnect the Oxygen Sensor (O2S) Heater Z30 electrical harness connector - 1 -.

Checking internal resistance

Scheme 1009

Scheme 1009
Scheme 1009
  1. Using a multimeter , check the Oxygen Sensor (O2S) Heater terminals 1 to 2 for resistance.

Specified value: 1.0 to 20.0 ohms (at approx. 20°C)

If the specification was not obtained

  1. Replace the faulty Heated Oxygen Sensor (HO2S) behind the Three Way Catalytic Converter (TWC). Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the specification was obtained

Checking voltage supply

  1. Switch the ignition on.
  2. Using a multimeter , check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) electrical harness connector terminal 1 to Engine Component Power Supply Relay J757 terminal 2/87 for voltage.
Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 electrical harness connector terminalEngine Component Power Supply Relay J757 electrical harness connector terminal
12
  1. Switch the ignition off.

Specified value: Battery voltage.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Ground (GND), or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If the specification was obtained

Checking Ground (GND) activation

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Scheme 1010

Scheme 1010
Scheme 1010
  1. Using a multimeter , check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) electrical harness connector terminal 2 to the Engine Control Module (ECM) J623 electrical harness connector T94 for an open circuit.
Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 electrical harness connector terminalEngine Control Module (ECM) J623 electrical connector T94 terminal or test box socket
275
Heated Oxygen Sensor (HO2S) -G131- electrical harness connector terminalEngine Control Module (ECM) J623 electrical connector T94 terminal or test box socket
291

Specified value: 1.5 ohms max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring and if the voltage supply was OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in reverse order of removal, note the following

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Throttle Valve Control Module J338 , Checking

Note. Use only gold-plated terminals when servicing terminals in harness connector of Throttle Valve Control Module J338.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. Battery voltage at least 12.5 volts.
  3. All electrical consumers such as, lights and rear window defroster, switched off.
  4. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Throttle valve must not be damaged or dirty.
  4. Coolant Temperature at least 80°C.

Function

Throttle valve operation occurs by an electric motor (Throttle Drive (for Electronic Power Control (EPC)) G186) in the Throttle Valve Control Module J338. It is operated by the Engine Control Module (ECM) J623 and the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185.

The Throttle Valve Control Module J338 is made up of the following components

  1. Throttle Drive (for Electronic Power Control (EPC)) G186
  2. Throttle Drive Angle Sensor 1 (for Electronic Power Control (EPC)) G187
  3. Throttle Drive Angle Sensor 2 (for Electronic Power Control (EPC)) G188

The Throttle Valve Control Module J338 cannot be serviced separately and must be serviced as a unit.

Function test

  1. Connect the scan tool.
  2. Switch ignition on.
  3. Using the scan tool, check the throttle valve position (absolute) at idle stop
Diagnostic textSpecified value
Throttle valve position (absolute)
Idle stop3.0 to 25.0%
  1. Slowly depress the accelerator pedal to Wide Open Throttle (WOT) stop while observing the percentage display. The percentage display must increase uniformly.
  2. Using the scan tool, check the throttle valve position (absolute) at Wide Open Throttle (WOT) stop
Diagnostic textSpecified value
Throttle valve position (absolute)
Wide Open Throttle (WOT) stop84.0 to 97.0%
  1. End diagnosis and switch ignition off.

If the specified values are not obtained

  1. Remove the rear engine cover - arrows -.

Scheme 1011

Scheme 1011
Scheme 1011
  1. Disconnect the Throttle Valve Control Module J338 electrical harness connector - 1 -.

Checking resistance

Scheme 1012

Scheme 1012
Scheme 1012
  1. Using a multimeter , check the Throttle Drive (for Electronic Power Control (EPC) G186 at the Throttle Valve Control Module J338 terminals 3 to 5 for resistance.

Specified value: 1.0 to 5.0 ohms (at 20°C)

If the specification was not obtained

  1. Replace the Throttle Valve Control Module J338. Refer to «Throttle Valve Control Module J338 , Checking»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__throttle-valve-control-module-j338) .

If the specification was obtained

  1. Check the voltage supply of the Throttle Valve Control Module J338 to the Engine Control Module (ECM) J623.
  2. > «Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__throttle-position-tp-sensor-g79accelerator-pedal) .

Checking voltage supply and wiring

  1. Switch the ignition on.

Scheme 1013

Scheme 1013
Scheme 1013
  1. Using a Multimeter , check the Throttle Drive (for Electronic Power Control (EPC)) G186 at the Throttle Valve Control Module J338 electrical harness connector terminals 2 to 6 for voltage.

Specified value: at least 4.5 V

  1. Switch the ignition off.

If the specification was not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Scheme 1014

Scheme 1014
Scheme 1014
  1. Using a Multimeter , check the Throttle Drive (for Electronic Power Control (EPC)) G186 at Throttle Valve Control Module J338 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.
Throttle Valve Control Module J338 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T60 terminals or test box socket
113
214
315
428
530
612

Specified value: 1.5 ohms max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring and if the voltage supply was OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Engine Speed (RPM) Sensor G28 , Checking

Note. Use only gold-plated terminals when servicing terminals in the electrical harness connector of the Engine Speed (RPM) Sensor G28.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. Battery voltage at least 12.5 volts.
  3. All electrical consumers such as, lights and rear window defroster, switched off.
  4. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Ignition switched off.

Function

The Engine Speed (RPM) Sensor G28 detects RPM and reference marks. Without an engine speed signal, the engine will not start. If the engine speed signal fails while the engine is running, the engine will stop immediately.

Function test

  1. Connect the scan tool.
  2. Switch the ignition on.
  3. Using the scan tool, check the engine speed
Diagnostic textSpecified value
Engine rotations per minute (RPM)Idle speed
  1. End diagnosis and switch ignition off.

If the specified value was not obtained

Procedure

Scheme 1015

Scheme 1015
Scheme 1015
  1. Disconnect the Engine Speed (RPM) Sensor G28 electrical harness connector - arrow -.

Checking internal resistance

Scheme 1016

Scheme 1016
Scheme 1016
  1. Using a multimeter , check the Engine Speed (RPM) Sensor G28 terminals 1 to 2 - B - for resistance.

Specified value: 0.7 to 1000 kOhm

If the specified value was not obtained

  1. Replace the Engine Speed (RPM) Sensor G28.

If the specified value is obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Engine Speed (RPM) Sensor G28 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.
Engine Speed (RPM) Sensor G28 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T60 terminals or test box socket
153
238

Specified value: Wire resistance max 1.5 ohms.

If the specification is not obtained

  1. Check the wiring for a short circuit to Battery positive (+) or an open circuit.
  2. If necessary, repair the wiring connection.

If no malfunctions are detected

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in reverse order of removal, note the following

Final procedures

After repair work, the following work steps must be performed in the mentioned sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End diagnosis and switch the ignition off.

Intake Air Temperature (IAT) Sensor G42 , Checking

The Intake Air Temperature (IAT) Sensor G42 and the Manifold Absolute Pressure (MAP) Sensor G71 are integrated into one unit and cannot be serviced separately.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram

Test requirements

  1. Fuses for engine electronics OK.
  2. Battery voltage at least 12.5 V.
  3. The ignition switched off.

Checking function

  1. Connect the scan tool.
  2. Switch the ignition on.
  3. Using the scan tool, check the intake air temperature
Diagnostic textSpecified value
Intake Air Temperature (IAT)Approx. ambient air temperature

If the specified value is not obtained

  1. End diagnosis and switch the ignition off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.

Checking voltage supply

  1. Disconnect the Intake Air Temperature (IAT) Sensor G42 electrical harness connector - 4 -.

Switch the ignition on

  1. Using a Multimeter , check the Intake Air Temperature (IAT) Sensor G42 electrical harness connector for voltage.
Intake Air Temperature (IAT) Sensor G42 electrical harness connectorSpecified value
1 to B+Battery voltage (+)
2 to Ground (GND)Battery voltage (+)
3 to Ground (GND)About 5 V
4 to Ground (GND)Battery voltage (+)

Switch the ignition off

If the specified values are obtained

  1. Replace the Intake Air Temperature (IAT) Sensor G42.

If specified values are not obtained

Checking wiring connections

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Intake Air Temperature (IAT) Sensor G42 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector terminals for an open circuit.
Intake Air Temperature (IAT) Sensor G42 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector terminals or test box sockets
140
239
329
444

Specified value: 1.5 ohms max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring and if the voltage supply was OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Engine Coolant Temperature (ECT) Sensor G62 , Checking

CAUTIONCooling system is under pressure. Danger of scalding when opening!

Note. Use only gold-plated terminals when servicing terminals in the electrical harness connector of Engine Coolant Temperature (ECT) Sensor G62.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Jumper wire.
  3. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. Battery voltage at least 12.5 volts.
  3. All electrical consumers such as, lights and rear window defroster, switched off.
  4. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Ignition switched off.
  4. Engine cold.

Function test

  1. Connect the scan tool.
  2. Switch the ignition on.
  3. Using the scan tool, check the coolant temperature
Diagnostic textSpecified value
Coolant temperatureApprox. coolant temperature

If the specified value is not obtained

  1. Continue test according to the following table
IndicatedCauseTest
Approx. - 40.0°COpen circuit or short circuit to (B+)TESTING IF DISPLAY IS APPROX. - 40.0°C
Approx. 140.0°CShort circuit to Ground (GND)TESTING IF DISPLAY APPROX. 140.0°C

If the specified value was obtained

  1. Start the engine and let it run at idle.

The temperature value must increase uniformly in increments of 1.0°C.

If the engine shows problems in certain temperature ranges and if the temperature does not climb uniformly, the temperature signal is intermittent.

  1. Replace the Engine Coolant Temperature (ECT) Sensor G62.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

Scheme 1017

Scheme 1017
Scheme 1017
  1. Remove the front engine cover - arrows -.

Checking internal resistance

Scheme 1018

Scheme 1018
Scheme 1018
  1. Disconnect the Engine Coolant Temperature (ECT) Sensor G62 electrical harness connector - arrow -.
  1. Using a multimeter , check the Engine Coolant Temperature (ECT) Sensor G62 terminals 1 to 2 for resistance.

Use the chart below for the specified values

  1. Area A: Resistance values 0 to 50°C.
  2. Area B: Resistance values 50 to 100°C.

Scheme 1019

Scheme 1019
Scheme 1019

Specified values

  1. Range A, 30°C equals a resistance of 1.5 to 3.2 kohms
  2. Range B, 80°C equals a resistance of 275 to 375ohms

If any of the specified values was not obtained

  1. Replace the Engine Coolant Temperature (ECT) Sensor G62 ADD LINK.

Testing if display is approx. - 40.0°C

  1. Disconnect the Engine Coolant Temperature (ECT) Sensor G62 electrical harness connector - arrow -.
  2. Using a jumper wire , connect the Engine Coolant Temperature (ECT) Sensor G62 electrical harness connector terminals 1 to 2.

Scheme 1020

Scheme 1020
Scheme 1020
  1. Check the value indicated on the scan tool display.

If the value jumps to approx. 140.0°C

  1. End diagnosis and switch the ignition off.
  2. Replace the Engine Coolant Temperature (ECT) Sensor G62 ADD LINK.

If indication remains at approx. -40.0°C

Testing if display approx. 140.0°C

  1. Disconnect the Engine Coolant Temperature (ECT) Sensor G62 electrical harness connector - arrow -.

If indication jumps to approx. -40.0°C

  1. End diagnosis and switch ignition off.
  2. Replace the Engine Coolant Temperature (ECT) Sensor G62 ADD LINK.

If indication remains at approx. 140.0°C

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Engine Coolant Temperature (ECT) Sensor G62 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.
Engine Coolant Temperature (ECT) Sensor G62 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T60 terminals or test box socket
140
243

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the front engine cover - arrows -.

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Fuel pressure and residual pressure before high pressure pump , Checking

Special tools, testers and auxiliary items required

  1. Hand held remote control (jumper).
  2. Electrical connector test lead set.
  3. Fuel pressure test set (high pressure).
  4. Measuring container, fuel-resistant.

Test requirements

  1. The Fuel Pump (FP) Control Module J538 OK.
  2. The fuel filter OK.
  3. The parking brake engaged.
  4. Battery voltage at least 12.5 V.
  1. The selector lever of automatic transmission in position "P" or "N".
  2. All electrical consumers switched off (radiator fan must NOT run during test).
  3. A/C switched off.
  4. The fuel tank at least 1 / 4 filled.
  1. The ignition switched off.

Checking system pressure

  1. Remove the rear seat bench --> «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Scheme 1021

Scheme 1021
Scheme 1021
  1. Remove the cover for the right locking flange - arrows -.

Scheme 1022

Scheme 1022
Scheme 1022
  1. Disconnect the electrical harness connector - arrow - from the fuel delivery unit.
  2. Connect a Hand held remote control (jumper) to terminal - 1 - of the fuel delivery unit and to vehicle battery (+).

Scheme 1023

Scheme 1023
Scheme 1023
  1. Connect a jumper cable from a Electrical connector test lead set to terminal - 5 - of the fuel delivery unit and to vehicle Ground (GND).
  1. Remove the rear engine cover - arrows -.
CAUTIONThe fuel system is under high pressure! Before opening high pressure components of the fuel injection system, pressure must be relieved to residual pressure. Then wrap a clean rag around the connection and relieve residual pressure by carefully loosening the connection.
  1. Disconnect the fuel line - arrow -.
  2. Connect the Fuel pressure test set (high pressure) to the fuel line.
  1. Connect the assisting hose - arrow - to the pressure gauge and hold in the measuring container.
  2. Open the pressure gauge shut-off valve. The lever points in direction of flow.
  3. Press the switch on the Hand held remote control (jumper) briefly to bleed the fuel system

Scheme 1024

Scheme 1024
Scheme 1024
  1. Close the pressure gauge shut-off valve. The lever is perpendicular to the direction of flow - arrow -.
  2. Press the switch on the Hand held remote control (jumper) until no more pressure increase is observed on the fuel pressure gauge.
  1. Specification: approx. 6 bar positive pressure

If the specification was not obtained

  1. Check the delivery rate of the fuel pump. Refer to --> «Fuel Pump Delivery Quantity, Checking»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__fuel-pump-delivery-quantity-checking) .

Checking residual pressure

  1. Check for leaks and residual pressure by observing the pressure loss on the pressure gauge.
  1. After 10 minutes there must be a residual pressure of at least 3.75 bar.

The holding pressure drops below 3.75 bar

  1. Check the connection between the fuel pressure gauge and the fuel line for leaks.
  2. Check the pressure gauge for leaks.
  3. Check the fuel lines and their connections for leaks.
  4. Replace the fuel filter with integrated fuel pressure regulator --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#fuel-supply-system) .
  1. Replace the fuel pump. Refer to --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b7-2004-2009/remont/fuel-system/#fuel-supply-system) .

Assembly is performed in the reverse order of removal. Note the following

Note. Before disconnecting the pressure gauge, release the fuel pressure by opening the shut-off valve. Hold a container under the connection.

Torque specifications

ComponentNm
Fuel line to fuel rail22

Fuel Pressure Sensor G247 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Fuel Pump (FP) Control Module J538 OK.
  2. The Engine Control Module (ECM) J623 fuses OK.
  3. The fuel filter OK.
  4. The battery voltage at least 12.5 V.
  1. All electrical consumers switched off (radiator fan must NOT run during test).
  2. A/C switched off.
  3. The fuel tank at least 1 / 4 filled.
  4. The ignition switched off.

Procedure

  1. Remove the rear engine cover - arrows -.

Checking voltage

Scheme 1025

Scheme 1025
Scheme 1025
  1. Disconnect the 14 pin electrical harness connector - 3 - on the left rear side of the engine.
  2. Switch the ignition on.
  3. Using a Multimeter , check the Fuel Pressure Sensor G247 for voltage at the 14 pin electrical harness connector.
Fuel Pressure Sensor G247 electrical harness connector terminalsSpecified value
1 to Battery positive (+)Battery voltage (+)
2 to Ground (GND)Battery voltage (+)
3 to Ground (GND)About 5 V
  1. Switch the ignition off.

If the specified values are obtained

  1. Replace the Fuel Pressure Sensor G247.

If the specified values are not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a Multimeter , check the Fuel Pressure Sensor G247 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.
14 pin electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T60 terminals or test box socket
140
259
329

Specified value: 1.5 ohms Max.

If the specification is not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Low Fuel Pressure Sensor G410 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Fuel Pump (FP) Control Module J538 OK.
  2. The Engine Control Module (ECM) J623 fuses OK.
  3. The fuel filter OK.
  4. The battery voltage at least 12.5 V.
  1. All electrical consumers switched off (radiator fan must NOT run during test).
  2. A/C switched off.
  3. The fuel tank at least 1 / 4 filled.
  4. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the front engine cover - arrows -.

Checking voltage

Scheme 1026

Scheme 1026
Scheme 1026
  1. Disconnect the Low Fuel Pressure Sensor G410 electrical harness connector - 1 -.
  2. Switch the ignition on.
  1. Using a multimeter , check the Low Fuel Pressure Sensor G410 electrical harness connector for voltage.
Low Fuel Pressure Sensor G410 electrical harness connector terminalsSpecified value
1 to Battery positive (+)Battery voltage (+)
2 to Ground (GND)Battery voltage (+)
3 to Ground (GND)About 5 V
  1. Switch the ignition off.

If the specified values are obtained

  1. Replace the Low Fuel Pressure Sensor G410 , note the following

Note. The 3.2L 6-Cyl. 4V (BKH) engine is equipped with two different Low Fuel Pressure Sensors G410 designs. One design is integrated into the high pressure fuel pump and must be replaced as a complete assembly. --> 24 - FUEL INJECTION SYSTEM . The second design is not integrated into the high pressure fuel pump and may be replaced separately.

If the specified values are not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Low Fuel Pressure Sensor G410 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit according to the wiring diagram.
Low Fuel Pressure Sensor G410 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T60 terminals or test box socket
140
249
329

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the front engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Fuel Metering Valve N290 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Fuel Pump (FP) Control Module J538 OK.
  2. The Engine Component Power Supply Relay J757 OK.
  3. The fuel filter OK.
  4. The parking brake engaged.
  1. The battery voltage at least 12.5 V.
  2. The selector lever of automatic transmission in position "P" or "N".
  3. All electrical consumers switched off (radiator fan must NOT run during test).
  4. A/C switched off.
  1. The fuel tank at least 1 / 4 filled.
  2. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the front engine cover - arrows -.

Scheme 1027

Scheme 1027
Scheme 1027
  1. Remove three screws - arrows - and the engine lifting eye to gain access to the Fuel Metering Valve N290 electrical harness connector.
  1. Disconnect the Fuel Metering Valve N290 electrical harness connector - 2 -.

Checking internal resistance

  1. Using a Multimeter , check the Fuel Metering Valve N290 terminals for resistance

Specified value: 450 to 1000 ohms.

If the specified value was not obtained

  1. Replace the Fuel Metering Valve N290.

If the specified value was obtained

Checking voltage

Switch the ignition on.

  1. Using a Multimeter , check the Fuel Metering Valve N290 electrical harness connector terminal 1 to Ground (GND) for voltage.
  2. Switch the ignition off.

Specified value: battery voltage.

If the specified value was not obtained

  1. Check the wiring from the Fuel Metering Valve N290 electrical harness connector terminal 1 to the Engine Component Power Supply Relay J757 terminal 2/87 for a short circuit to Ground (GND), or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the wiring connection.

If no malfunctions are found in the wiring

Checking wiring connections

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a multimeter , check the Fuel Metering Valve N290 electrical harness connector terminal 2 to the Engine Control Module (ECM) J623 electrical harness connector T60 terminal 45 for an open circuit.
Fuel Metering Valve N290 electrical harness connector terminalEngine Control Module (ECM) J623 electrical connector T60 terminal or test box socket
245

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the front engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Intake Manifold Tuning (IMT) Valve Position Sensor G513 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. The parking brake engaged.
  3. The battery voltage at least 12.5 V.
  4. The selector lever of automatic transmission in position "P" or "N".
  1. All electrical consumers switched off (radiator fan must NOT run during test).
  2. A/C switched off.
  3. The fuel tank at least 1 / 4 filled.
  4. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the front engine cover - arrows -.

Checking voltage supply

  1. Disconnect the Intake Manifold Tuning (IMT) Valve Position Sensor G513 electrical harness connector - 3 -.

Switch the ignition on.

  1. Using a Multimeter , check the Intake Manifold Tuning (IMT) Valve Position Sensor G513 electrical harness connector for voltage.
Intake Manifold Tuning (IMT) Valve Position Sensor G513 electrical harness connectorSpecified value
1 to Ground (GND)Battery positive (+)
2 to Ground (GND)About 5 V
3 to Battery positive (+)Battery positive (+)

Switch the ignition off.

If the specified values are obtained

  1. Replace the Intake Manifold Tuning (IMT) Valve Position Sensor G513.

If specified values are not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a multimeter , check the Intake Manifold Tuning (IMT) Valve Position Sensor G513 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T94 terminals for an open circuit.
Intake Manifold Tuning (IMT) Valve Position Sensor G513 electrical harness connectorEngine Control Module (ECM) J623 electrical harness connector T94 terminals or test box socket
163
252
39

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the front engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Intake Manifold Runner Position Sensor 2 G512 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. The parking brake engaged.
  3. The battery voltage at least 12.5 V.
  4. The selector lever of automatic transmission in position "P" or "N".
  1. All electrical consumers switched off (radiator fan must NOT run during test).
  2. A/C switched off.
  3. The fuel tank at least 1 / 4 filled.
  4. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.

Checking voltage supply

Note. The Intake manifolds have been removed for clarity.

Scheme 1028

Scheme 1028
Scheme 1028
  1. Disconnect the Intake Manifold Runner Position Sensor 2 G512 electrical harness connector - 1 -.

Switch the ignition on.

  1. Using a Multimeter , check the Intake Manifold Runner Position Sensor 2 G512 electrical harness connector for voltage.
Intake Manifold Runner Position Sensor 2 G512 electrical harness connectorSpecified value
1 to Ground (GND)About 5 V
2 to Battery positive (+)Battery voltage (+)
3 to Ground (GND)Battery voltage (+)

Switch the ignition off.

If the specified values are obtained

  1. Replace the Intake Manifold Runner Position Sensor 2 G512.

If specified values are not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a multimeter , check the Intake Manifold Runner Position Sensor 2 G512 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.
Intake Manifold Runner Position Sensor 2 G512 electrical harness connectorEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box socket
129
250
340

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Intake Manifold Runner Control (IMRC) Valve N316 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Intake Manifold Runner Control (IMRC) Valve N316 fuse OK.
  2. The Engine Component Power Supply Relay J757 OK.
  3. The parking brake engaged.
  4. The battery voltage at least 12.5 V.
  1. The selector lever of automatic transmission in position "P" or "N".
  2. All electrical consumers switched off (radiator fan must NOT run during test).
  3. A/C switched off.
  4. The fuel tank at least 1 / 4 filled.
  1. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.
  1. Disconnect the Intake Manifold Runner Control (IMRC) Valve N316 electrical harness connector - 5 -.

Checking internal resistance

  1. Using a Multimeter , check the Intake Manifold Runner Control (IMRC) Valve N316 terminals 1 to 2 for resistance
Intake Manifold Runner Control (IMRC) Valve N316 terminals
1 to 2

Specified value: 450 to 1000 ohms.

If the specified value was not obtained

  1. Replace the Intake Manifold Runner Control (IMRC) Valve N316.

If the specified value was obtained

Checking voltage

Switch the ignition on.

  1. Using a Multimeter , check the Intake Manifold Runner Control (IMRC) Valve N316 electrical harness connector terminal 1 to ground (GND) for voltage.

Specified value: battery voltage.

  1. Switch the ignition off.

If the specified value was not obtained

  1. Check the wiring from the Intake Manifold Runner Control (IMRC) Valve N316 electrical harness connector terminal 1 to the Engine Component Power Supply Relay J757 terminal 2/87 for a short circuit to Ground (GND), or an open circuit.
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the wiring connection.

If no malfunctions are found in the wiring

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a multimeter , check the Intake Manifold Runner Control (IMRC) Valve N316 electrical harness connector terminal 2 to the Engine Control Module (ECM) J623 electrical harness connector T60 terminal 35 for an open circuit.
Intake Manifold Runner Control (IMRC) Valve N316 electrical harness connector terminalEngine Control Module (ECM) J623 electrical harness connector T60 terminal or test box socket
235

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Intake Manifold Runner Position Sensor G336 , Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Intake Manifold Runner Position Sensor G336 fuse OK.
  2. The Engine Component Power Supply Relay J757 OK.
  3. The parking brake engaged.
  4. The battery voltage at least 12.5 V.
  1. The selector lever of automatic transmission in position "P" or "N".
  2. All electrical consumers switched off (radiator fan must NOT run during test).
  3. A/C switched off.
  4. The fuel tank at least 1 / 4 filled.
  1. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.

Note. The Intake manifolds have been removed for clarity.

Scheme 1029

Scheme 1029
Scheme 1029
  1. Disconnect the Intake Manifold Runner Position Sensor G336 electrical harness connector - 1 -.

Checking voltage supply

Switch the ignition on.

  1. Using a Multimeter , check the Intake Manifold Runner Position Sensor G336 electrical harness connector for voltage.
Harness connector TerminalSpecified value
1 to Ground (GND)About 5 V
2 to Battery positive (+)Battery voltage (+)
3 to Ground (GND)Battery voltage (+)

Switch the ignition off.

If the specified values are obtained

  1. Replace the Intake Manifold Runner Position Sensor G336.

If the specified values are not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a multimeter , check the Intake Manifold Runner Position Sensor G336 electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.
Intake Manifold Runner Position Sensor G336 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box Socket
129
255
340

Specified value: 1.5 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

The Intake Manifold Runner Position Sensor G336 must be adapted to the Engine Control Module (ECM) J623.

To adapt the Intake Manifold Runner Position Sensor G336 to the Engine Control Module (ECM) J623 perform the following steps

Test requirements

  1. The battery voltage at least 12.5 V.
  2. Coolant temperature must be between 20°C and 80°C.
  3. No DTCs stored in DTC memory.
  1. Start the engine and let run at idle for at least 70 seconds.
  2. The Engine Control Module (ECM) J623 will automatically adept the Intake Manifold Runner Position Sensor G336.
  1. Install the rear engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Fuel Injectors , Checking

The following procedure is used to diagnose N30, N31, N32, N33, N83, N84

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Diode test lamp (12V).
  3. Wiring diagram.

Test requirements

  1. The Fuel Injectors N30, N31, N32, N33,N83,N84 fuses OK.
  2. The Engine Speed (RPM) Sensor G28 OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  2. A/C switched off.
  3. Ground (GND) connections between engine/transmission/chassis OK.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.

Right bank

Scheme 1030

Scheme 1030
Scheme 1030
  1. Disconnect the 6 pin electrical harness connector - 1 - for Fuel Injectors N30, N31, N32 from the right rear of the engine.

Left bank

  1. Disconnect the 14 pin electrical harness connector - 3 - for Fuel Injectors N33, N83, N84 from the left rear of the engine.

Checking internal resistance

  1. Using a Multimeter , check the Fuel Injectors for resistance.

Right bank

Fuel Injector6 pin electrical harness connector terminal
N30 Cyl. 11 to 2
N31 Cyl. 23 to 4
N32 Cyl. 35 to 6

Left bank

Fuel Injector14 pin electrical harness connector terminal
N33 Cyl. 45 to 6
N83 Cyl. 57 to 8
N84 Cyl. 69 to 10

Specified value: 12 to 13 ohms (at room temperature).

Note. With an engine at operating temperature, the resistance of the fuel injectors increases by approx. 4 to 6 ohms.

If any of the specified values are not obtained

  1. Replace the malfunctioning Fuel Injector.

If the specified values are obtained

Checking activation

  1. Connect a diode test lamp (12V) to the electrical harness connector terminals of the Fuel Injector to be tested.

Right bank

Fuel Injector6 pin electrical harness connector terminal
N30 Cyl. 11 to 2
N31 Cyl. 23 to 4
N32 Cyl. 35 to 6

Left bank

Fuel Injector14 pin electrical harness connector terminal
N33 Cyl. 45 to 6
N83 Cyl. 57 to 8
N84 Cyl. 69 to 10
  1. Operate the starter briefly.

Note. Voltage testers do not go out completely during low current pick-up between activations by the ECM, but rather continue to glow a little and then get slightly brighter during activation.

The LED must light up.

  1. Switch the ignition off.

If the LED does not light up

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a Multimeter , check the Fuel Injector electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T60 terminals for an open circuit.

Right bank

Fuel injector6 pin electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box socket
N30 Cyl. 1133
21
N31 Cyl. 2346
416
N32 Cyl. 3532
63

Left bank

Fuel injector14 pin electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box socket
N33 Cyl. 4531
618
N83 Cyl. 5747
817
N84 Cyl. 6948
102

Specified value: 1.5 ohms Max.

If any of the specified values are not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Install the rear engine cover - arrows -.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Checking Intake System for Leaks

Special tools, testers and auxiliary items required

  1. Engine Leak Detection Spray.

Note. Vacuum in the intake system sucks in the leak detection spray with false air. Leak detection spray decreases ignition quality of the fuel mixture. This causes a reduction in engine speed and a sharp increase of CO content. It is absolutely necessary to follow the safety precautions listed on the can.

Test requirements

  1. Coolant temperature at least 80°C.
  2. The parking brake engaged.
  3. The selector lever of automatic transmission in position "P" or "N".
  4. The ignition switched off.

Test sequence

  1. Connect the scan tool.
  2. Start the engine and let run at idle.
  3. Select "Mode 1: Checking measured values".
  4. Select the following measured values
PIDDiagnostic textSpecified value
06Short time gasoline-air ratio bank 17.00 to 7.00%
08Short time gasoline-air ratio bank 27.00 to 7.00%
12Engine rotations per minute (RPM)640 to 720 RPM
  1. Spray the intake system parts with engine leak detection spray in a systematic manner.

If the engine speed drops or if the short-term gasoline-air ratio changes

  1. End diagnosis and switch the ignition off.
  2. Check the sprayed part of intake system for leaks, and repair the malfunction.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Functions, Checking

Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking

This procedure is used to diagnose Heated Oxygen Sensor (HO2S) G39 or Heated Oxygen Sensor (HO2S) 2 G108.

Note. Use only gold-plated terminals when servicing terminals in the electrical harness connector of the Heated Oxygen Sensor (HO2S).

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Heated Oxygen Sensor (HO2S) G39 fuse OK.
  2. The Heated Oxygen Sensor (HO2S) 2 G108 fuse OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Exhaust system between catalytic converter and cylinder head properly sealed.
  4. Coolant Temperature at least 80°C.

Function test

Perform a function test of the Heated Oxygen Sensors (HO2S). Refer to Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking

If specified values are obtained

  1. End diagnosis and switch the ignition off.

If the specified values are not obtained

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Heated Oxygen Sensor (HO2S) G39 electrical harness connector - 1 -.

To disconnect the Heated Oxygen Sensor (HO2S) 2 G108 , perform the following steps

  1. Remove the screw - arrow - retaining the coolant reservoir.
  2. Disconnect the Engine Coolant Level (ECL) Warning Switch F66 electrical connector from the bottom of the coolant reservoir and set aside the coolant reservoir with the coolant hoses - 1 - and - 2 - connected.
  1. Disconnect the Oxygen Sensor (O2S) Heater -Z28- electrical harness connector - 2 -.

Checking primary voltage

  1. Using a multimeter , check the Heated Oxygen Sensor (HO2S) electrical harness connector terminals 1 to 2 for voltage.

Specified value: 0.400 to 0.500 Volts

  1. Switch the ignition off.

If the specified value was obtained

  1. Replace the faulty Heated Oxygen Sensor (HO2S). Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the specified value was not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Heated Oxygen Sensor (HO2S) electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T94 terminals for an open circuit.
Heated Oxygen Sensor (HO2S) G39 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
183
261
482
684
Heated Oxygen Sensor (HO2S) -G108- electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
181
259
460
662

Specified value: 1.5 ohms Max.

If any of the specified values are not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking

This procedure is used to diagnose Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 or Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131.

Note. When servicing the electrical harness connector of the Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) , use only gold-plated terminals.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 fuse OK.
  2. The Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131 fuse OK. Refer to --> «Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__oxygen-sensor-o2s-1-behind-three) .
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. Vehicles with automatic transmission, selector lever in position "P" or "N".
  2. A/C switched off.
  3. Ground (GND) connections between engine/transmission/chassis OK.
  4. Exhaust system between catalytic converter and cylinder head properly sealed.
  1. Coolant Temperature at least 80°C.

Function test

Perform a function test of the Heated Oxygen Sensors (HO2S). Refer to Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking

If specified values are obtained

  1. End diagnosis and switch the ignition off.

If the specified values are not obtained

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 electrical harness connector - 2 -.

To disconnect the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131 , perform the following steps

  1. Remove the screw - arrow - retaining the coolant reservoir.
  2. Disconnect the Engine Coolant Level (ECL) Warning Switch F66 electrical connector from the bottom of the coolant reservoir and set aside the coolant reservoir with the coolant hoses - 1 - and - 2 - connected.
  1. Disconnect the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131 electrical harness connector - 2 -.

Checking primary voltage

  1. Using a Multimeter , check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) electrical harness connector terminals 3 to 4 for voltage.
  2. Switch the ignition on.

Specified value: 0.400 to 0.500 V.

  1. Switch the ignition off.

If the specified value was obtained

  1. Replace the faulty Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC). Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the specified value was not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) electrical harness connector terminals to the Engine Control Module (ECM) J623 electrical harness connector T94 terminals for an open circuit.
Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T94 terminals or test box sockets
376
477
Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T94 terminals or test box sockets
354
455

Specified value: 1.5 ohms Max.

If any of the specified values are not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is detected in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Engine Control Module (ECM) J623

Function

The Engine Control Module (ECM) J623 regulates fuel injection, Throttle Valve Control Module J338 , oxygen sensor regulation, ignition, knock control, Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , engine speed limitation through On Board Diagnostic (OBD).

Engine Control Module (ECM) J623 Voltage Supply, Checking

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. Battery voltage at least 12.5 volts.
  3. All electrical consumers such as, lights and rear window defroster, switched off.
  4. Vehicles with automatic transmission, selector lever in position "P" or "N".
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Ignition switched off.

Test sequence

  1. Remove the Engine Control Module (ECM) Power Supply Relay J271.

Checking voltage

  1. Using a Multimeter , check the Engine Control Module (ECM) Power Supply Relay J271 socket 1/30 to Ground (GND).

Specified value: battery voltage.

If the specified value was not obtained

  1. Check the wiring connections from the Battery to the Engine Control Module (ECM) Power Supply Relay J271 socket 1/30 for an open circuit or a short circuit.
  2. Check the wiring connections for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If the specified value was obtained

  1. Switch the ignition on.
  2. Using a Multimeter , check the Engine Control Module (ECM) Power Supply Relay J271 socket 3/86 to Ground (GND).

Specified value: battery voltage.

If the specified value was obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a Multimeter , check the Engine Control Module (ECM) Power Supply Relay J271 socket 3/86 to the Engine Control Module (ECM) J623 electrical harness connector T94 terminal 92 for resistance.
Engine Control Module (ECM) Power Supply Relay J271 socket terminalEngine Control Module (ECM) J623 electrical connector T94 terminal or test box socket
3/8692

Specified value: 3.2 ohms Max.

If the specification was not obtained

  1. Check the wiring for a short circuit to each other, Battery (+), and Ground (GND).
  2. Check the electrical harness connector for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring

Checking activation

  1. Switch the ignition on.
  2. Using a Multimeter , check the Engine Control Module (ECM) Power Supply Relay J271 socket 4/85 to the Engine Control Module (ECM) J623 electrical harness connector T94 terminal 69 for voltage.
Engine Control Module (ECM) Power Supply Relay J271 socket terminalEngine Control Module (ECM) J623 electrical connector T94 terminal or test box socket
4/8569
  1. Switch the ignition off.

Specified value: 0.5 V Max.

If the specified value was obtained

  1. Replace the Engine Control Module (ECM) Power Supply Relay J271.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring and voltage supply was not OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Engine Control Module (ECM) J623 , Removing and Installing

Special tools, testers and auxiliary items required

  1. Heat gun.

Note. When the Engine Control Module (ECM) J623 electrical harness connectors are disconnected, the adaptation values are erased and the DTC memory content remains intact.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

Check the identification of the previous Engine Control Module (ECM) J623 as follows

  1. Connect the scan tool.
  2. Switch the ignition on.
  3. Using the scan tool, select "Mode 09: Vehicle information".
  4. Select " Calibration Identification".

The Engine Control Module (ECM) J623 identification number will be displayed, e.g.: 06A906032NA 4983

  1. Record the Engine Control Module (ECM) J623 identification number.
  2. End diagnosis and switch the ignition off.

Removing

  1. Remove the rubber seal - arrow - from the plenum chamber cover - 1 -.

Scheme 1031

Scheme 1031
Scheme 1031
  1. Remove the plenum chamber cover - 1 -.

Scheme 1032

Scheme 1032
Scheme 1032
  1. Using a screwdriver, remove the wiper arms caps - 3 -.
  2. Loosen the wiper arm nuts - 4 - several turns.
  3. Loosen the wiper arms - 2 - by gently rocking.
  4. Remove the wiper arm nuts and wiper arms - 2 -.
  1. Disconnect the retaining clips - 1 - and remove the cowl panel grille - 5 -.

Scheme 1033

Scheme 1033
Scheme 1033
  1. Remove the screws - arrows - and electronics box cover from the electronics box.

Scheme 1034

Scheme 1034
Scheme 1034
  1. Using a screwdriver, carefully pry off mounting bracket - arrow - and remove the Engine Control Module (ECM) J623 from the electronics box.

Note. The Engine Control Module (ECM) J623 remains connected at the wiring harnesses.

CAUTIONTo prevent damage (burning) to wire and harness connections, insulation and control modules, perform the following work steps exactly! Observe operating instructions for heat gun.

Note. The threads in the protective housing, into which the shear bolts are threaded, are then heated with the heat gun. During this step, the holding effect that the locking compound has on the shear bolt threads is reduced, thereby allowing the shear bolts to be removed easier.

Scheme 1035

Scheme 1035
Scheme 1035
  1. Using a Heat gun set at its lowest setting, heat the shear bolt for approx. 20 to 25 seconds.
  2. Remove the shear bolt with locking pliers. Discard the used shear bolts.

Scheme 1036

Scheme 1036
Scheme 1036

Repeat the previous steps for the second shear bolt.

Scheme 1037

Scheme 1037
Scheme 1037
  1. Remove the electrical harness connector retaining brackets - 2 - and - 5 - and the electrical harness connectors from the Engine Control Module (ECM) J623.
  2. Remove the Engine Control Module (ECM) J623.

Installing

Installation is performed in reverse order of the removal. Note the following

Note. New shear bolts must be used when reinstalling the electrical harness connector retaining brackets to the Engine Control Module (ECM) J623. After installing a new Engine Control Module (ECM) J623 it must be adapted. ADD LINK

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Additional Signals, Checking

Speed Signal, Checking

The following procedure requires a test drive. Observe all safety precautions.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Speedometer G21 OK.
  2. The Engine Control Module (ECM) J623 fuses OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Ignition switched off.

Function test

  1. Connect the scan tool.
  2. Perform a road test with a vehicle speed greater than 5 Km/h.
  3. Using the scan tool, Check the vehicle speed
Diagnostic textSpecified value
Vehicle SpeedApprox. Vehicle Speed
  1. Compare the vehicle speed on the scan tool to the Speedometer G21.

Specified value: a difference of no greater than 10%.

If the specified value was not obtained or no speed was displayed

  1. Check the wiring from the Engine Control Module (ECM) J623 to the Instrument Cluster Control Module J285 for an open circuit, Short to Battery (+), or to Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Brake Light Switch F/Brake Pedal Switch F47 , Checking Signal

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Brake Light Switch F fuse OK.
  2. The Brake Pedal Switch F47 fuse OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  2. A/C switched off.
  3. Ground (GND) connections between engine/transmission/chassis OK.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the drivers side storage compartment. Refer to --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Checking internal resistance

  1. Disconnect the Brake Light Switch F/Brake Pedal Switch F47 electrical harness connector.

Scheme 1038

Scheme 1038
Scheme 1038
  1. Using a Multimeter , check the Brake Pedal Switch F47 terminals 1 to 4 for a internal short.

Specified value: infinity (infinity).

If the specified value was not obtained

  1. Replace the Brake Light Switch F/Brake Pedal Switch F47 --> «46 - BRAKES - MECHANICAL COMPONENTS»(/audi/a4/b7-2004-2009/remont/anti-locktraction-control/#brake-system) .

If the specified value was obtained

  1. Using a Multimeter , check the Brake Pedal Switch F47 terminals 1 to 4 for resistance.
  2. Press the brake pedal switch plunger in.

Specified value: approx. 0 ohms

If the specified value was obtained

  1. Check the voltage supply of the Brake Light Switch F/Brake Pedal Switch F47 «Checking voltage supply»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__checking-voltage-supply) .

If the specified value was not obtained

  1. Replace the Brake Light Switch F/Brake Pedal Switch F47 --> «46 - BRAKES - MECHANICAL COMPONENTS»(/audi/a4/b7-2004-2009/remont/anti-locktraction-control/#brake-system) .

Checking voltage supply

  1. Switch the ignition on.

Scheme 1039

Scheme 1039
Scheme 1039
  1. Using a Multimeter , check the Brake Pedal Switch F47 electrical harness connector terminal 1 to Ground (GND).

Specified value: battery voltage.

If the specified value was not obtained

  1. Using a Multimeter , check the Brake Pedal Switch F47 electrical harness connector terminal 3 to Ground (GND).

Specified value: battery voltage.

  1. Switch the ignition off.

If the specified value was not obtained

  1. Check the wiring «Checking wiring»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__checking-wiring) .

If the specified value was obtained

  1. Replace the Brake Light Switch F/Brake Pedal Switch F47 --> «46 - BRAKES - MECHANICAL COMPONENTS»(/audi/a4/b7-2004-2009/remont/anti-locktraction-control/#brake-system) .

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , check the Brake Light Switch F/Brake Pedal Switch F47 electrical harness connector to the Engine Control Module (ECM) J623 electrical harness connector T94 for open an circuit.
Brake Light Switch F/Brake Pedal Switch F47 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
243
416

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring and voltage supply was not OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Install the drivers side storage compartment. Refer to --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Terminal Resistance for Can-Bus, Checking

The Engine Control Module (ECM) J623 communicates with all databus capable control modules via a CAN databus.

These databus capable control modules are connected via two data bus wires which are twisted together (CAN_High and CAN_Low), and exchange information (messages). Missing information on the databus is recognized as a malfunction and stored.

Trouble-free operation of the CAN-bus requires that it have a terminal resistance. The central terminal resistor is located in the Engine Control Module (ECM) J623.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirement

  1. A CAN-Bus malfunction was recognized.
  2. The Engine Control Module (ECM) J623 fuses OK.
  3. Battery voltage at least 12.5 V.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Instrument Cluster Control Module J285 electrical harness connector.

Note. The Engine Control Module (ECM) J623 must remain connected for the following step.

  1. Using a Multimeter , check the Instrument Cluster Control Module J285 electrical harness connector terminals 12 to 13 for resistance.

Specified value: 60 to 72 ohms (at approx. 20°C)

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

If the specified value was obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a Multimeter , check the Instrument Cluster Control Module J285 electrical harness connector to the Engine Control Module (ECM) J623 electrical harness connector T94 for resistance.
Instrument Cluster Control Module J285 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
12 (Can_Bus Low)67
13 (Can_Bus High)68

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring

  1. Replace the Instrument Cluster Control Module J285.

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Exhaust System Components, Removing and Installing

For all Exhaust System, Emission control component locations. Refer to --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS

For all Exhaust System, Emission control removal/installation procedures and torque specifications. Refer to --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS

Check the Technical Bulletins for information that may supersede any information included in this article.

Note. All manufacturers special tools as well as common tools may contain a manufacturer specific part number. These tools may be substituted with an equivalent aftermarket tool or are available for purchase through Audi. Manufacturers special tools as well as common tools that contain a manufacturer specific part number may be referenced in the test procedure illustrations showing the tool use or installation. If the manufacturer specific tool is not being used, an equivalent aftermarket tool may be installed in the same manner as the manufacturers special tool.

Three Way Catalytic Converter (TWC), checking

Test requirements

  1. Battery voltage at least 12.5 volts.
  2. Oxygen Sensors OK.
  3. No leaks or damage to exhaust system.

Function test

  1. Perform the function test in Diagnostic Mode 06. Refer to --> «Diagnostic Mode 06: Checking Test Results of Components that are not Continuously Monitored»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-06-checking-test-results) .
  2. End diagnosis and switch the ignition off.

If the specified values are exceeded

  1. Check the exhaust system for leaks.
  2. If necessary, repair the leak in the exhaust system.
  3. Erase the DTC memory. Refer to --> «Diagnostic Mode 03: Interrogating Fault Memory»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-03-interrogating-fault-memory) .
  4. Perform a road test to verify Repair.

If the DTC does not return

Repair complete, Generate readiness code. Refer to --> Readiness Code .

  1. End diagnosis.

If no leaks are found in the exhaust system

  1. Replace the catalytic converter including front exhaust pipe. Refer to «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-engine-mechanical-engine-codes-bkh) .

Final procedures

After the Repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

End of diagnosis

Ignition System, Servicing

To reduce the risk of personal injury and/or damage to the fuel injection and ignition system, always observe the following

CAUTIONObserve the following for all installations, especially in the engine compartment due to lack of room: Route lines of all types (e.g. for fuel, hydraulic, EVAP canister system, coolant and refrigerant, brake fluid, vacuum) and electrical wiring so that the original path is followed. Watch for sufficient clearance to all moving or hot components. Fuel system is under pressure! Before opening system, place rags around the connection point. Then release pressure by carefully loosening connection. Test equipment must always be secured to the rear seat and operated by a second person. Test and measuring equipment that is operated from the passenger seat, the person seated could be injured in the event of an accident involving deployment of the passenger-side airbag. Do not touch or disconnect ignition wires when engine is running or turning at starting RPM. Only disconnect and reconnect wires for injection and ignition system, including test leads, if the ignition is turned off. The use of nails, paper clips, or another unauthorized materials to back-probe electrical harness connectors is strictly prohibited and may cause damage to the electrical harness connectors, terminal ends or damage to a component. Use only the manufacturers test lead kit or an equivalent aftermarket test lead kit for back-probing all electrical harness connectors.

Test Data, Spark Plugs

Engine codeBKH (3.2 l/4V/188 kW engine)
Engine Control Module (ECM) System identificationSiemens Simos 6
Engine idle speed650 to 750 RPM (not adjustable)
Engine speed (RPM) limitationStarting at approx. 6500 RPM
Ignition sequence1-5-3-6-2-4
Ignition timingNot adjustable, regulated by Electronic control module
Ignition systemSingle coil ignition system with 6 ignition coils (output stages integrated) that are connected directly to the spark plugs.

General Information

For all Ignition/Glow plug system component locations. Refer to --> 28 - IGNITION SYSTEM

For all Ignition/Glow plug system removal/installation procedures and torque specifications. Refer to --> 28 - IGNITION SYSTEM

Check the Technical Bulletins for information that may supersede any information included in this article.

Note. All manufacturers special tools as well as common tools may contain a manufacturer specific part number. These tools may be substituted with an equivalent aftermarket tool or are available for purchase through Audi. Manufacturers special tools as well as common tools that contain a manufacturer specific part number may be referenced in the test procedure illustrations showing the tool use or installation. If the manufacturer specific tool is not being used, an equivalent aftermarket tool may be installed in the same manner as the manufacturers special tool. The manufacturers test box Test Box 105 Pin VAG1598/42 is available for purchase or rental.

Camshaft Position (CMP) Sensors , Checking

This procedure is used to check Camshaft Position (CMP) Sensors G40, G300, G163, G301.

Note. The following procedure is used to diagnose all Camshaft Position (CMP) Sensors.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirements

  1. The Engine Control Module (ECM) J623 fuses OK.
  2. Battery voltage at least 12.5 volts.
  3. All electrical consumers such as, lights and rear window defroster, switched off.
  4. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  1. A/C switched off.
  2. Ground (GND) connections between engine/transmission/chassis OK.
  3. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

Checking activation

  1. Remove the front engine cover - arrows -.
  1. Remove the rear engine cover - arrows -.
  2. Disconnect the electrical harness connector of the Camshaft Position (CMP) Sensor G40 to be tested.
  3. Switch the ignition on.

Scheme 1040

Scheme 1040
Scheme 1040
  1. Using a Multimeter , Check the Camshaft Position (CMP) Sensor electrical harness connector terminals 1 to 3 for voltage.

Specified value: about 5.0 V

  1. Switch the ignition off.

If the specification was not obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Scheme 1041

Scheme 1041
Scheme 1041
  1. Using a Multimeter , Check the Camshaft Position (CMP) Sensor electrical harness connector to the Engine Control Module (ECM) J623 electrical harness connector T60 for an open circuit.
Camshaft Position (CMP) Sensor G40 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box sockets
1 Battery positive (+)11
2 (signal)25
3 Ground (GND)40
Camshaft Position (CMP) Sensor 3 G300 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box sockets
1 Battery positive (+)11
2 (signal)54
3 Ground (GND)40
Camshaft Position (CMP) Sensor 2 G163 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box sockets
1 Battery positive (+)11
2 (signal)9
3 Ground (GND)40
Camshaft Position (CMP) Sensor 4 G301 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical harness connector T60 terminals or test box sockets
1 Battery positive (+)11
2 (signal)24
3 Ground (GND)40

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring and voltage supply was OK

  1. Replace the Camshaft Position (CMP) Sensor G40 --> «15 - ENGINE - CYLINDER HEAD, VALVETRAIN»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-engine-mechanical-engine-codes-bkh) .

If no malfunction is found in the wiring and voltage supply was not OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in the reverse order of removal, note the following

Final procedures

After repair work, the following work steps must be performed in the mentioned sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End diagnosis and switch ignition off.

Camshaft Adjustment Valve , Checking

This procedure is used to check the Camshaft Adjustment Valves N205, N208, N318, N319.

Special tools, testers and auxiliary items required

  1. Multimeter V.A.G 1526 A or equivalent.
  2. Voltage Tester VAG1527B or equivalent.
  3. Test Box 105 Pin VAG1598/42.
  4. Adapter Lead VAG1598/39 VAG1598/39-1.

Test requirements

  1. The Camshaft Adjustment Valves fuses OK.
  2. Ignition switched off.
  3. The Engine Control Module (ECM) Power Supply Relay J271 OK.

Note. Voltage for camshaft adjustment solenoid valves is supplied by the Engine Control Module (ECM) Power Supply Relay J271.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the front engine cover - arrows -.
  1. Remove the rear engine cover - arrows -.

Cylinder bank 1 (right)

Scheme 1042

Scheme 1042
Scheme 1042
  1. Disconnect the Camshaft Adjustment Valve 1 (exhaust) N318 electrical harness connector or - 1 - the Camshaft Adjustment Valve 1 N205 - 2 -.

Cylinder bank 2 (left)

  1. Remove the screw - arrow - retaining the coolant reservoir.

Scheme 1043

Scheme 1043
Scheme 1043
  1. Disconnect the Engine Coolant Level (ECL) Warning Switch F66 electrical harness connector from the bottom of the coolant reservoir and set aside the coolant reservoir with the coolant hoses - 1 - and - 2 - connected.
  2. Disconnect the Camshaft Adjustment Valve 2 N208 electrical harness connector - 2 - or the Camshaft Adjustment Valve 2 (exhaust) N319 - 3 -.

Checking internal resistance

  1. Using a Multimeter , check the Camshaft Adjustment Valve for resistance.

Specified value: 5.0 to 8.0 ohms (at approx. 20°C)

If the specified value was not obtained

  1. Replace the faulty Camshaft Adjustment Valve --> «15 - ENGINE - CYLINDER HEAD, VALVETRAIN»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-engine-mechanical-engine-codes-bkh) .

If the specified value was obtained

Checking voltage

  1. Switch the ignition on.
  2. Using a Multimeter , Check the Camshaft Adjustment Valve electrical harness connector terminal 1 to the Engine Control Module (ECM) Power Supply Relay J271 terminal 2/87 for voltage.
  3. Switch the ignition off.

Specified value: battery voltage.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit or a short circuit Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If the specified value was obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , Check the Camshaft Adjustment Valve electrical harness connector terminal 2 to the Engine Control Module (ECM) J623 electrical harness connector T60 terminal for an open circuit.
Camshaft Adjustment Valve 1 N205 electrical harness connector terminalEngine Control Module (ECM) electrical harness connector T60 terminal or test box socket
251
Camshaft Adjustment Valve 2 N208 electrical harness connector terminalEngine Control Module (ECM) electrical harness connector T60 terminal or test box socket
274
Camshaft Adjustment Valve 1 (exhaust) N318 electrical harness connector terminalEngine Control Module (ECM) electrical harness connector T60 terminal or test box socket
227
Camshaft Adjustment Valve 2 (exhaust) N319 electrical harness connector terminalEngine Control Module (ECM) electrical harness connector T60 terminal or test box socket
239

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring and voltage supply was not OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in the reverse order of removal.

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Knock Sensor (KS) , Checking

The following procedure is used to check Knock Sensor (KS) 1 G61 and Knock Sensor (KS) 2 G66.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Note. Cylinders 1, 2, and 3 (bank 1) are monitored by Knock sensor (KS) 1 -G61-. Cylinders 4, 5, and 6 (bank 2) are monitored by Knock sensor (KS) 2 -G66-. Knock sensors themselves cannot be checked electrically. When servicing terminals in the harness connector of knock sensors, use only gold-plated terminals. For the knock sensors to function properly, it is important that the tightening torque be exactly 20 Nm. Contact surfaces between Knock Sensor (KS) 1 G61 and Knock Sensor (KS) 2 G66 and cylinder block must be free of corrosion, dirt and grease.

Test requirements

  1. The mounting bolt of Knock Sensor (KS) 1 G61/Knock Sensor (KS) 2 G66 tightened to 20 Nm.
  2. The Engine Control Module (ECM) J623 fuses OK.
  3. Battery voltage at least 12.5 volts.
  4. All electrical consumers such as, lights and rear window defroster, switched off.
  1. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  2. A/C switched off.
  3. Ground (GND) connections between engine/transmission/chassis OK.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Remove the rear engine cover - arrows -.

Checking knock sensor and wiring

Note. The knock sensor electrical connectors can be identified by color. Knock Sensor (KS) 1 -G61- (Bank 1) is green. Knock Sensor (KS) 2 -G66- (Bank 2) is gray.

  1. Disconnect the electrical harness connector - 1 - or - 2 - of the respective knock sensor.

1 - Knock Sensor (KS) 1 -G61-.

2 - Knock sensor (KS) 2 -G66-.

Checking internal resistance

Scheme 1044

Scheme 1044
Scheme 1044
  1. Using a Multimeter , check the Knock Sensor terminals for an internal short.
Knock Sensor (KS) Electrical harness connector terminals
1 + 2
1 + 3
2 + 3

Specified value: infinity (Infinity).

If the specified values are not obtained

  1. Replace the faulty Knock Sensor (KS). Refer to --> «15 - ENGINE - CYLINDER HEAD, VALVETRAIN»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-engine-mechanical-engine-codes-bkh) .

If the specified values are obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Scheme 1045

Scheme 1045
Scheme 1045
  1. Using a Multimeter , Check the Knock Sensor electrical harness connector to the Engine Control Module (ECM) J623 electrical harness connector T60 for an open circuit.
Knock Sensor (KS) 1 G61 electrical harness connector terminalsEngine Control Module (ECM) electrical harness connector T60 terminals or test box sockets
141
258
342
Knock Sensor (KS) 2 G66 electrical harness connector terminalsEngine Control Module (ECM) electrical harness connector T60 terminals or test box sockets
156
257
342

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring and the resistance was not OK

  1. Replace the faulty Knock Sensor (KS). Refer to --> «15 - ENGINE - CYLINDER HEAD, VALVETRAIN»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-engine-mechanical-engine-codes-bkh) .

If no malfunction is found in the wiring and the resistance was OK

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in the reverse order of removal, note the following

Final procedures

After repair work, the following work steps must be performed in the mentioned sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End diagnosis and switch ignition off.

Ignition Coil with Power Output Stage , Checking

The following procedure is used to diagnose all Ignition Coil with Power Output Stage N70, N127, N291, N292, N323, N324.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Diode test lamp.
  3. Wiring diagram.

Test requirements

  1. The Ignition Coils with Power Output Stage fuses OK.
  2. The Engine Component Power Supply Relay J757 OK.
  3. The Engine Speed (RPM) Sensor G28 OK.
  4. The Camshaft Position (CMP) Sensor G40 OK.
  1. Battery voltage at least 12.5 volts.
  2. All electrical consumers such as, lights and rear window defroster, switched off.
  3. Vehicles with automatic transmission, shift selector lever into position "P" or "N".
  4. A/C switched off.
  1. Ground (GND) connections between engine/transmission/chassis OK.
  2. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

Recognize a nonfunctional or misfiring cylinder as follows

  1. Compare the spark plugs of all the cylinders to each other. Check the electrodes for carbon fouling.

If faulty a cylinder is recognized

  1. Switch the spark plug from the faulty cylinder with one from another cylinder.

If the malfunction follows the spark plug

  1. Replace the spark plug.

If the malfunction remains at the original cylinder

  1. Switch the ignition coil from the faulty cylinder with one from another cylinder.

If the malfunction follows the ignition coil

  1. Replace the ignition coil.

Removal

  1. Remove the front engine cover - arrows -.
  1. Remove the rear engine cover - arrows -.

Cylinder bank 1 (right)

Scheme 1046

Scheme 1046
Scheme 1046
  1. Remove the air duct screws - arrows -.
  2. Remove the air ducts - 1 - and - 2 -.

Scheme 1047

Scheme 1047
Scheme 1047
  1. Remove the check valve - 1 - from the air duct hose.
  2. Loosen the hose clamp - 2 - , release the retaining clips - arrows - , and remove the air duct hose.
  1. Disconnect the electrical harness connectors from the following
  1. Engine Coolant Temperature (ECT) Sensor G62
  2. Intake Manifold Flap Change-over Valve N239
  3. Intake Manifold Tuning (IMT) Valve Position Sensor (P2076) G513
  1. Disconnect the electrical harness connectors from the following
  1. Camshaft Adjustment Valve 1 (exhaust) N318.
  2. Camshaft Adjustment Valve 1 N205.
  3. Camshaft Position (CMP) Sensor G40.
  4. Intake Manifold Runner Position Sensor G336.
  5. Camshaft Position (CMP) Sensor 3 G300.
  1. Remove the screws - arrows - and disconnect the electrical connections at the ignition coils.

Cylinder bank 2 (left)

  1. Remove the screw - arrow - retaining the coolant reservoir.
  2. Disconnect the electrical connector from the Engine Coolant Level (ECL) Warning Switch F66 at the bottom of the coolant reservoir and set aside the coolant reservoir with the coolant hoses - 1 - and - 2 - connected.

Scheme 1048

Scheme 1048
Scheme 1048
  1. Disconnect the electrical connector from the high pressure fuel pump - 2 -.
  1. Disconnect the electrical harness connectors from the following
  1. Camshaft Position (CMP) Sensor 2 G163.
  2. Camshaft Adjustment Valve 2 N208.
  3. Camshaft Adjustment Valve 2 (exhaust) N319.
  4. Camshaft Position (CMP) Sensor 4 G301.
  1. Remove the screws - arrows - and disconnect the electrical connections at the ignition coils.

Checking voltage supply

  1. Switch the ignition on.
  1. Using a Multimeter , check the Ignition Coil electrical harness connector terminals 1 to 4 for voltage.

Specified value: battery voltage.

  1. Switch the ignition off.

If the specified value was not obtained

  1. Check the Ignition Coil electrical harness connector terminal 1 to the Engine Component Power Supply Relay J757 socket 4/85 for an open circuit.

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If the specified values were obtained

Checking activation

CAUTIONDo not touch the Ignition Coils connecting parts or adapter cables during the following test.
  1. Disable the power supply to the Fuel Injectors N30, N31, N32, N33 by removing the necessary fuse.
  1. Using a diode test lamp , check the Ignition Coil electrical harness connector terminals 2 to 3 for voltage.
  2. Operate the starter.

The LED should flicker.

  1. Switch the ignition off.

If the LED flickers and the voltage was OK

  1. Replace the faulty Ignition Coils with Power Output Stage N70, N127, N291, N292 --> «28 - IGNITION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the LED does not flicker

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  1. Using a Multimeter , Check the Ignition Coil electrical harness connector to the Engine Control Module (ECM) J623 electrical harness connector T60 for an open circuit.
Ignition Coils with Power Output Stage electrical harness connector terminalEngine Control Module (ECM) electrical harness connector T60 terminal or test box socket
N70 38
N127 36
N291 37
N292 323
N323 321
N324 322

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If the specified values were obtained

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

Assembly is performed in the reverse order of removal, note the following

Final procedures

After repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End diagnosis and switch ignition off.

Electrical Components for Regulating Transmission O9L, Checking

For all Automatic Transmission- Gears, Hydraulic controls component locations. Refer to --> 38 GEARS, CONTROL

For all Automatic Transmission- Gears, Hydraulic controls removal/installation procedures and torque specifications. Refer to --> 38 GEARS, CONTROL

Check the Technical Bulletins for information that may supersede any information included in this article.

Note. All manufacturers special tools as well as common tools may contain a manufacturer specific part number. These tools may be substituted with an equivalent aftermarket tool or are available for purchase through Audi. Manufacturers special tools as well as common tools that contain a manufacturer specific part number may be referenced in the test procedure illustrations showing the tool use or installation. If the manufacturer specific tool is not being used, an equivalent aftermarket tool may be installed in the same manner as the manufacturers special tool. The manufacturers test box Test Box 105 Pin VAG1598/42 is available for purchase or rental. Certainly you have received an electrical shock once before when touching something made out of metal. The reason for this is the electrostatic charge of the human body. This charge can lead to functional problems by touching the electrical components of the transmission and selector lever mechanism. Touch a grounded object, e.g. a water pipe or a hoist, before working on the electrical components! Do not make direct contact on electrical harness connector terminals! If special testing equipment is required during road test, note the following

Safety precautions

CAUTIONObserve the following for all installations, especially in engine compartment due to lack of room: Route lines of all types (e.g. for fuel, hydraulic, EVAP canister system, coolant and refrigerant, brake fluid, vacuum) and electrical wiring so that the original path is followed. Watch for sufficient clearance to all moving or hot components. Shift selector lever into position -P- and engage parking brake before working with the engine running.
CAUTIONTest equipment must always be secured to the rear seat and operated by a second person. If test and measuring equipment is operated from the passenger seat, the person seated could be injured in the event of an accident involving deployment of the passenger-side airbag. The use of nails, paper clips, or another unauthorized materials to back-probe electrical harness connectors is strictly prohibited and may cause damage to the electrical harness connectors, terminal ends or damage to a component. Use only the manufacturers test lead kit or an equivalent aftermarket test lead kit for back-probing all electrical harness connectors.

Multi-Function Transmission Range (TR) Switch F125 , Checking

Note. The Multi-Function Transmission Range (TR) Switch F125 is a component of the Mechatronic unit and cannot be replaced separately.

Requirements

  1. Control Module with indicator unit in the Instrument Cluster Control Module J285 must be OK.
  2. The battery voltage must be at least 12.5 Volts.
  3. All electrical consumers must be switched off.
  4. The parking brake must be engaged.
  1. The elector lever must be in the "P" position.
  2. The Ground (GND) connections to transmission must be OK.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Switch the ignition on.
  2. Depress the brake pedal and maintain depressed.
  3. Shift the selector lever into all positions.

The selector lever position must correspond to the display of the Control Module with the indicator unit in the Instrument Cluster Control Module J285.

  1. Switch the ignition off.

If the selector lever position does not correspond to the display of the Control Module with indicator unit in the Instrument Cluster Control Module J285

Scheme 1049

Scheme 1049
Scheme 1049
  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Observe safety precautions.
  3. Check the electrical harness connector for contact corrosion and ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction and repeat the test sequence.

If the electrical harness connector is OK

  1. Check the wiring according to the wiring diagram

If no malfunctions are found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Note. The Transmission Control Module (TCM) J217 is a component of the Mechatronic unit and cannot be replaced separately.

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Transmission Input Speed (RPM) Sensor G182 , Checking

Note. The Transmission Input Speed (RPM) Sensor G182 is a component of the Mechatronic unit in the transmission.

Requirements

  1. The battery voltage must be at least 12.5 Volts.
  2. All electrical consumers must be switched off.
  3. The parking brake must be engaged.
  4. The elector lever must be in the "P" position.
  1. The Ground (GND) connections to transmission must be OK.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Observe safety precautions.
  3. Check the electrical harness connector for contact corrosion and ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction.

If the electrical harness connector is OK

  1. Check the wiring according to the wiring diagram

If no malfunctions are found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Note. The Transmission Input Speed (RPM) Sensor G182 is a component of the Mechatronic unit and cannot be replaced separately.

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Transmission Output Speed (RPM) Sensor G195 , Checking

Note. The Transmission Output Speed (RPM) Sensor G195 is a component of the Mechatronic unit in the transmission.

Requirements

  1. The battery voltage must be at least 12.5 Volts.
  2. All electrical consumers must be switched off.
  3. The parking brake must be engaged.
  4. The elector lever must be in the "P" position.
  1. The Ground (GND) connections to transmission must be OK.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Observe safety precautions.
  3. Check the electrical harness connector for contact corrosion and ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction.

If the electrical harness connector is OK

  1. Check the wiring according to the wiring diagram

If no malfunctions are found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Note. The Transmission Output Speed (RPM) Sensor G195 is a component of the Mechatronic unit and cannot be replaced separately.

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Transmission Fluid Temperature Sensor G93 , Checking

Note. The Transmission Fluid Temperature Sensor G93 is a component of the Mechatronic unit and cannot be replaced separately.

Requirements

  1. The battery voltage must be at least 12.5 Volts.
  2. All electrical consumers must be switched off.
  3. The parking brake must be engaged.
  4. The elector lever must be in the "P" position.
  1. The Ground (GND) connections to transmission must be OK.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Observe safety precautions.
  3. Check the electrical harness connector for contact corrosion and ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction.

If the electrical harness connector is OK

  1. Check the wiring according to the wiring diagram

If no malfunctions are found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Note. The Transmission Fluid Temperature Sensor G93 is a component of the Mechatronic unit and cannot be replaced separately.

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Solenoid Valve 1 N88 , Checking

Note. The Solenoid Valve 1 N88 is a component of the Mechatronic unit and cannot be replaced separately.

Requirements

  1. The battery voltage must be at least 12.5 Volts.
  2. All electrical consumers must be switched off.
  3. The parking brake must be engaged.
  4. The elector lever must be in the "P" position.
  1. The Ground (GND) connections to transmission must be OK.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Observe safety precautions.
  3. Check the electrical harness connector for contact corrosion and ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction.

If the electrical harness connector is OK

  1. Check the wiring according to the wiring diagram

If no malfunctions are found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Note. The Solenoid Valve 1 N88 is a component of the Mechatronic unit and cannot be replaced separately.

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Automatic Transmission Pressure Regulating Valves , Checking

Note. The Automatic Transmission Pressure Regulating Valve 1 N215 , Automatic Transmission Pressure Regulating Valve 2 N216 , Automatic Transmission Pressure Regulating Valve 3 N217 , Automatic Transmission Pressure Regulating Valve 4 N218 , Automatic Transmission Pressure Regulating Valve 5 N233 , and the Automatic Transmission Pressure Regulating Valve 6 N371 are components of the Mechatronic unit in the transmission.

Requirements

  1. The battery voltage must be at least 12.5 Volts.
  2. All electrical consumers must be switched off.
  3. The parking brake must be engaged.
  4. The elector lever must be in the "P" position.
  1. The Ground (GND) connections to transmission must be OK.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Observe safety precautions.
  3. Check the electrical harness connector for contact corrosion and ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction.

If the electrical harness connector is OK

  1. Check the wiring according to the wiring diagram

If no malfunctions are found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Note. The Automatic Transmission Pressure Regulating Valve 1 N215 , Automatic Transmission Pressure Regulating Valve 2 N216 , Automatic Transmission Pressure Regulating Valve 3 N217 , Automatic Transmission Pressure Regulating Valve 4 N218 , Automatic Transmission Pressure Regulating Valve 5 N233 , and the Automatic Transmission Pressure Regulating Valve 6 N371 are components of the Mechatronic unit in the transmission and cannot be replaced separately.

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Transmission Control Module (TCM) J217

The Transmission Control Module (TCM) J217 receives information from the components that affect the shifts and forwards this information to the pressure regulator valves of the mechatronic, which control the slide valves in the valve body.

Transmission Control Module (TCM) J217 , Voltage Supply, Checking

Note. The Transmission Control Module (TCM) J217 is a component of the mechatronic unit in the transmission and cannot be replaced separately.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Requirements

  1. The Transmission Control Module (TCM) J217 fuses OK.
  2. The battery voltage must be at least 12.5 volts.
  3. The Ground (GND) connections at the transmission OK.
  4. The parking brake engaged.
  1. The selector lever of automatic transmission in position "P".
  2. All electrical consumers switched off.
  3. The ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.
  2. Check the electrical harness connector for damage, contact corrosion, or ingress of water.

If the electrical harness connector is not OK

  1. Repair the malfunction.

If the electrical harness connector is OK

Checking voltage

  1. Switch the ignition on.
  2. Using a Multimeter , check the Power Supply Relay (terminal 15) J329 socket 2/87 to Ground (GND).

Specified value: battery voltage.

  1. Switch the ignition off.

If the specified value was not obtained

  1. Check the wiring from the Power Supply Relay (terminal 15) J329 socket 2/87 to the Transmission Control Module (TCM) J217 electrical harness connector terminal 9 for an open circuit or a short circuit.
  2. If necessary, repair the faulty wiring connection.

If the specified value was obtained

  1. Using a Multimeter , check the Transmission Control Module (TCM) J217 electrical harness connector terminal 14 to Ground (GND).

Specified value: battery voltage.

If the specified value was obtained

  1. Check the wiring from the Battery to the Transmission Control Module (TCM) J217 electrical harness connector terminal 14 for an open circuit or a short circuit.
  2. If necessary, repair the faulty wiring connection.

If the specified value was obtained

Checking Ground (GND)

  1. Using a Multimeter , check the Transmission Control Module (TCM) J217 electrical harness connector terminals 13 and 16 to Ground (GND) for resistance.

Specified value: 1.5 ohms

If the specification was not obtained

  1. Check the wiring for a an open circuit.
  2. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Final procedures

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Transmission Control Module (TCM) J217 , Replacing

Note. The Transmission Control Module (TCM) J217 is a component of the mechatronic unit in the transmission and cannot be replaced separately. To achieve optimal anti-theft protection for the vehicle, an anti-theft immobilizer was installed. The anti-theft immobilizer is a system for enabling/locking the Transmission Control Module (TCM) J217. To perform adaptation of the anti-theft immobilizer.

Work procedure

Check the identification of the previous Transmission Control Module (TCM) J217 as follows

  1. Connect the scan tool.
  2. Switch the ignition on.
  3. Select "Diagnostic mode 9: Vehicle information."
  4. Select the "Test-ID 04: Calibration identification".
  1. The Transmission Control Module (TCM) J217 identification will be displayed, e.g.: 09G27750 L 0301
  2. End diagnosis and switch the ignition off.
  3. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .
  4. Check the identification of the new Transmission Control Module (TCM) J217 to ensure it matches the old Transmission Control Module (TCM) J217.
  1. Code the Transmission Control Module (TCM) J217.
  2. Generate a readiness code. Refer to --> «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Additional signals (Automatic Transmission), Checking

CAN-Bus terminal resistance, Transmission Control Module (TCM) J217 to Engine Control Module (ECM) J623 , checking

The Engine Control Module (ECM) J623 communicates with all databus capable control modules via a CAN databus.

These databus capable control modules are connected via two data bus wires which are twisted together (CAN_High and CAN_Low), and exchange information (messages). Missing information on the databus is recognized as a malfunction and stored.

Trouble-free operation of the CAN-bus requires that it have a terminal resistance. The central terminal resistor is located in the Engine Control Module (ECM) J623.

Special tools, testers and auxiliary items required

  1. Multimeter.
  2. Wiring diagram.

Test requirement

  1. A CAN-Bus malfunction was recognized.
  2. The Engine Control Module (ECM) J623 fuses OK.
  3. Battery voltage at least 12.5 V.
  4. Ignition switched off.

Test procedure

  1. Perform a preliminary check to verify the customers complaint. Refer to --> «General Diagnosis»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .

Start diagnosis

  1. Disconnect the Transmission Control Module (TCM) J217 electrical harness connector - direction of the arrow -.

Note. The Engine Control Module (ECM) J623 must remain connected for the following step.

  1. Using a Multimeter , check the Transmission Control Module (TCM) J217 electrical harness connector terminals 2 to 6 for resistance.

Specified value: 60 to 72 ohms (at approx. 20°C)

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring

  1. Replace the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .

If the specified value was obtained

Checking wiring

If the manufacturers test box is being used. Perform the following step.

  1. Install the test box. Refer to --> «24 - FUEL INJECTION SYSTEM»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-fuel-injection-ignition-engine-codes-bkh) .

If the manufacturers test box is not being used. Perform the following step.

  1. Remove the Engine Control Module (ECM) J623. Refer to --> «Engine Control Module (ECM) J623 , Removing and Installing»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__engine-control-module-ecm-j623) .
  2. Using a Multimeter , check the Transmission Control Module (TCM) J217 electrical harness connector to the Engine Control Module (ECM) J623 electrical harness connector T94 for resistance.
Transmission Control Module (TCM) J217 electrical harness connector terminalsEngine Control Module (ECM) J623 electrical connector T94 terminals or test box sockets
2 (Can_Bus Low)67
6 (Can_Bus High)68

Specified value: 1.5 ohms Max.

If the specified value was not obtained

  1. Check the wiring connection for an open circuit, short circuit to Battery (+) or Ground (GND).
  2. Check the wiring connection for damage, corrosion, lose or broken terminals.
  3. If necessary, repair the faulty wiring connection.

If no malfunction is found in the wiring

  1. Replace the Mechatronic unit in the transmission: --> «38 GEARS, CONTROL»(/audi/a4/b7-2004-2009/remont/differentials-drive-axles/#6-speed-automatic-transmission-09l-all-wheel-drive) .

Final procedures

After the repair work, the following work steps must be performed in the following sequence

  1. Check the DTC memory.
  2. If necessary, erase the DTC memory. Refer to «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  3. If the DTC memory was erased, generate readiness code. Refer to «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. End of diagnosis.

Continuously Variable Transmission (CVT) 01J, Checking

For electrical diagnosis of the Continuously Variable Transmission (CVT) 01J, refer to the --> 38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS .

On Board Diagnostic (OBD)

Generic Scan Tool Manual Contents

GST is an acronym for Generic Scan Tool Manual.

Included in the contents of this GST manual is a summary table of the vehicle specific OBD II Emission Related Engine and Transmission DTCs. This table contains all necessary Malfunction Criteria, Threshold Values, Secondary Parameters, Enabling Conditions, Monitoring Time Length, Frequency of Checks, and MIL Illumination to accurately monitor and diagnose the Engine Emissions and Transmission and perform all functions required to run Modes 01 through 09 with a hand held scan tool. For a further description of the monitor strategies, a document reference has been provided throughout this GST manual to the applicable OBD System Strategy document.

This GST manual also contains the step by step pin point test procedures to accurately diagnose the suspected component or system once a DTC has been set. All references to repair procedures and wiring diagrams will be found within the diagnostic test procedure.

OBD Systems

OBD II

OBD is an acronym for the On Board Diagnostic System.

California OBD II applies to all gasoline engine vehicles up to 14,000 lbs. Gross Vehicle Weight Rating (GVWR) starting in the 1996 MY and all diesel engine vehicles up to 14,000 lbs. GVWR starting in the 1997 MY.

Several states in the Northeastern United States have chosen to adopt the California emission regulations starting in the 1998 MY and are known as "Green States".

Green States receive California-certified vehicles for passenger cars and light trucks up to 6,000 lbs. GVWR. Starting in the 2004 MY, Federal vehicle over 8,500 lbs. will start phasing in OBD II.

Starting in 2004 MY, gasoline-fueled Medium Duty Passenger Vehicles (MDPVs) are required to have OBD II. Federal OBD II applies to all gasoline engine vehicles up to 8,500 lbs. GVWR starting in the 1996 MY and all diesel engine vehicles up to 8,500 lbs. GVWR starting in the 1997 MY.

OBD II system implementation and operation is described in the remainder of this document.

Malfunction Indicator Lamp Illumination

MIL is an acronym for the Malfunction Indicator Lamp.

If the ECM recognizes a malfunction that leads to increased emissions values, it indicates them by lighting the MIL which is located in the instrument cluster.

The ECM switches on the MIL after the ignition is switched on. Shortly after the engine is started, The MIL goes out if the ECM does not detect a malfunction that increases the emissions values.

If the ECM recognizes a malfunction that leads to increased emissions during the operation of the engine, the ECM switches on the MIL and an entry is stored in the DTC memory of the ECM.

CAN Data Link

CAN is an acronym for Controller Area Network.

The ECM communicates with all databus capable control modules by a CAN Data Link.

The databus capable control modules (i.e. Engine Coolant temperature Sensor) are connected by two data bus wires which are twisted together (CAN_High and CAN_Low), and exchange information (messages) to the ECM. Missing information on the databus is then recognized and stored as a malfunction.

The ECM illuminates the MIL through the CAN data link and tells the MIL to turn on, turn off, or blink.

Electronic Power Control Warning Lamp

EPC is an acronym that stands for the Electronic Power Control (E-gas).

The ECM monitors all EPC components after the ignition is switched on.

If a malfunction is recognized in the EPC system during the operation of the engine, the ECM switches on the EPC which is located in the instrument cluster and an entry is stored in the DTC memory of the ECM.

Diagnostic Modes

Diagnostic Modes Description

The information provided in Modes 01 through 09 displays the various levels of emission related data that may be monitored, as well as the ability to retrieve and read stored DTC trouble codes , erase stored DTC trouble codes, generate readiness codes, and select the various PIDs and Test-IDs used within the modes to monitor the engine, and emission related component parameters.

The following table provides a link to all diagnostic modes that monitor all components and systems which influence the emission quality.

Note. Depending on scan tool and protocol used, the information displayed may be referred to by different names such as Test-ID (TID), Hex-ID, Component-ID (CID), On-Board Diagnostic Monitor Identifier (OBDMID), or contain no name at all and be referenced by only a number.

Selectable diagnostic modes
Mode 1: Obtain data --> Diagnostic Mode 01: Obtain Data .
Mode 2: Obtain operating conditions --> Diagnostic Mode 02: Obtain Operating Conditions .
Mode 3: Interrogating fault memory --> Diagnostic Mode 03: Interrogating Fault Memory .
Mode 4: Reset/delete diagnostic data --> Diagnostic Mode 04: Reset/delete Diagnostic Data .
Mode 6: Checking test results of components that are not continuously monitored --> Diagnostic Mode 06: Checking Test Results of Components that are not Continuously Monitored .
Mode 7: Checking test results of components that are continuously monitored --> Diagnostic Mode 07: Check Test Results of Components that are Continuously Monitored .
Mode 8: Tank leak test --> Diagnostic Mode 08: Tank Leak Test .
Mode 9: Vehicle information --> Diagnostic Mode 09: Vehicle Information .

Diagnostic Mode 01: Obtain Data

Diagnostic Mode 01 is used to display and monitor all emissions related measured values.

Test requirement

  1. Coolant temperature at least 80°C.

Procedure

  1. Connect the diagnostic tester.
  2. Start the engine and run at idle.
  3. Select "Diagnostic Mode 1: Obtain data.".
  4. From the following table, select the desired the "PID" that is to be monitored, e.g. "PID 05-Coolant temperature".

Note. More than one "PID" may be selected and monitored.

The current values of the component or system that is being monitored will be displayed on the diagnostic tester screen.

PIDComponent or System
01Monitoring status since erasing DTC memory
03Condition of fuel system
04Calculated load condition value
05Coolant temperature
06Short term gasoline-air ratio bank 1
07Gasoline-air ratio bank 1
12Engine rotations per minute (RPM)
13Vehicle speed
14Ignition timing adjustment at 1. cyl. in direction
15Intake air temperature (IAT)
16Air flow quantity at Mass Air Flow (MAF) sensor
17Throttle valve position (absolute)
19Existing oxygen B1 to B2-S2 to (exist./nonexist.)
21Bank 1 - sensor 2
28OBD request is designed for diagnostic of this vehicle
31Time after engine on
33Driven distance after MIL on
35Fuel Rail Pressure
46Commanded Evaporative Purge
48Number of warm ups since diagnostic trouble codes
49Distance since diagnostic trouble codes cleared
51Barometric Pressure
52Bank 1 - sensor 1
56Bank 2- sensor 1
60Catalyst Temperature Bank 1, Sensor 1
65Monitor status this driving cycle
66Control module voltage
67Absolute Load Value
68Commanded Equivalence Ratio
69Relative Throttle Position
70Ambient air temperature
71Absolute Throttle Position B
73Accelerator Pedal Position D
74Accelerator Pedal Position E
76Commanded Throttle Actuator Control
  1. Switch the ignition off.
  2. End of diagnosis.

Diagnostic Mode 02: Obtain Operating Conditions

Diagnostic Mode 02 is used to monitor the operating conditions under which the Engine Control Module (ECM) has detected and stored an emissions related DTC.

Procedure

  1. Connect the diagnostic tester.
  2. Start the engine and run at idle.

Note. If the engine does not start, crank the engine using starter for at least 5 seconds, do not switch the ignition off afterward under any circumstances.

  1. Select "Diagnostic Mode 2: Obtain operating conditions.".
  2. From the following table, select the desired the "PID" , e.g. "PID 05-Coolant temperature" that is to be monitored.

Note. More than one "PID" may be selected and monitored.

The current values of the component or system that is being monitored will be displayed on the diagnostic tester screen.

PIDComponent or System
02DTC which triggered the current reception of all control module information
03Condition of fuel system
04Calculated load condition value
05Coolant temperature
06Short term gasoline-air ratio bank 1
07Gasoline-air ratio bank 1
12Engine rotations per minute (RPM)
13Vehicle speed
14Ignition timing adjustment at 1. cyl. in direction
15Intake air temperature (IAT)
16Air stream amount at Mass Air Flow (MAF) sensor
17Throttle valve position (absolute)
31Time after engine on
35Fuel Rail Pressure
46Commanded Evaporative Purge
51Barometric Pressure
66Control module voltage
67Absolute Load Value
68Commanded Equivalence Ratio
69Relative Throttle Position
70Ambient air temperature
71Absolute Throttle Position B
73Accelerator Pedal Position D
74Accelerator Pedal Position E
76Commanded Throttle Actuator Control
  1. Switch the ignition off.
  2. End of diagnosis.

Diagnostic Mode 03: Interrogating Fault Memory

Description

When the Engine Control Module (ECM) recognizes an emission related fault it turns on the Malfunction Indicator Lamp (MIL) or if a Electronic Throttle Malfunction is recognized, the Engine Control Module (ECM) turns on the Electronic Power Control (EPC) Warning Lamp which are both located in the instrument cluster.

Diagnostic Mode 03 is used to retrieve and view any DTC which may be stored in the Engine Control Module (ECM).

The DTCs are sorted by SAE code with the DTC tables consisting of a 5-digit alpha-numeric value.

The following tables provide a breakdown and explanation of the DTC code.

P-Codes

Component group
PXXXXDTC for the drivetrain
Norm-Code
P0XXXTrouble codes defined by SAE with specified malfunction texts
P1XXXAdditional emission relevant DTCs provided by the manufacturer
P2XXXDTCs defined by SAE with specified texts, from MY 2000
P3XXXAdditional emission relevant DTCs provided by the manufacturer from MY 2000
Component group
PX0XXFuel and air mixture and additional emission regulations
PX1XXFuel and air ratios
PX2XXFuel and air ratios
PX3XXIgnition system
PX4XXAdditional exhaust system
PX5XXSpeed and idle control
PX6XXControl module and output signals
PX7XXTransmission
PX8XXTransmission
PX9XXControl modules, input and output signals

U-Codes

Component group
UXXXXDTC for network (CAN bus)
Norm-Code
U0XXXTrouble codes defined by SAE with specified malfunction texts

Interrogating Fault Memory

Procedure

  1. Connect the diagnostic tester.
  2. Switch the ignition to the "ON" position.
  3. Select "Diagnostic Mode 03: Interrogating fault memory ".
  4. The stored DTC or DTCs will be displayed on the diagnostic tester screen.

The following table is an example of the DTC information that may be displayed on the diagnostic tester screen

Indication exampleExplanation
P0444SAE Diagnostic Trouble Code (DTC)
Evaporative Emission (EVAP) Canister Purge Regulator ValveMalfunctioning wiring path or malfunctioning component
Circuit OpenMalfunction type as next
  1. Refer to the following DTC tables for the diagnostic repair procedure
  1. SAE P0xxxDTCs. --> «SAE P0xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  2. SAE P1xxx-DTCs --> «SAE P1xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  3. SAE P2xxxDTCs. --> «SAE P2xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  4. SAE P3xxxDTCs. --> «SAE P3xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. SAE U0xxxDTCs, --> «SAE U0xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. Switch the ignition off.
  2. End of diagnosis.

Diagnostic Mode 04: Reset/delete Diagnostic Data

Diagnostic Mode 04 is used to reset or delete the following stored information

  1. All emission related malfunctions in the DTC memory.
  2. The operating conditions at which a malfunction was stored will be reset.
  3. All adaptation values.
  4. The test results of all diagnostic functions.

Procedure

  1. Connect the diagnostic tester.
  2. Switch the ignition to the "ON" position.
  3. Select "Diagnostic Mode 03: Interrogating fault memory ".
  4. Then select "Mode 4: Reset/delete diagnostic data".

The diagnostic tester will display: "Diagnostic data are being erased".

  1. Switch the ignition off.
  2. End of diagnosis.

Diagnostic Mode 06: Checking Test Results of Components that are not Continuously Monitored

Diagnostic Mode 06 displays the test results of emission related components and systems which are not continuously monitored.

The values of the individual test results must reach the specified value or must be within the min. and max. limits.

Note. Depending on diagnostic tester and protocol used, the information displayed in diagnostic mode 06 may be referred to by different names such as Test-ID (TID), Hex-ID, Component-ID (CID), or On-Board Diagnostic Monitor Identifier (OBDMID).

Test requirements

  1. Exhaust system must be properly sealed between catalytic converter and cylinder head.
  2. No DTCs in the DTC memory.
  3. Coolant temperature at least 80°C.

Work procedure

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select the desired "Test-ID".

The current minimum and maximum values will be displayed on the diagnostic tester screen.

Test-ID (Hex-ID)Component or System
01 ($01): Test-ID 01 ($01): Oxygen Sensor Monitor Bank 1 - Sensor 1Oxygen Sensor Monitor Bank 1 - Sensor 1
02 ($02): Test-ID 02 ($02): Oxygen Sensor Monitor Bank 1- Sensor 2Oxygen Sensor Monitor Bank 1 - Sensor 2
05 ($05): Test-ID 05 ($05): Oxygen Sensor Monitor Bank 2 - Sensor 1Oxygen Sensor Monitor Bank 2 - Sensor 1
06 ($06): Test-ID 06 ($06): Oxygen Sensor Monitor Bank 2 - Sensor 2Oxygen Sensor Monitor Bank 2 - Sensor 2
33 ($21): Test-ID 33 ($21): Catalyst Monitor Bank 1Catalyst Monitor Bank 1
34 ($22): Test-ID 34 ($22): Catalyst Monitor Bank 2Catalyst Monitor Bank 2
$3A (58): $3A (58): Fuel Tank EVAP System Leak Test (0.090)Fuel Tank EVAP System Leak Test (0.090)
59 (3B): Test-ID 59 (3B): EVAP Monitor (0.040)EVAP Monitor (0.40)
60 (3C): Test-ID 60 (3C): EVAP Monitor (0.020)EVAP Monitor (0.20)
61 (3D): Test-ID 61 (3D): Purge Flow MonitorPurge Flow Monitor
65 ($41): Test-ID 65 ($41): Oxygen Sensor Heater Monitor Bank 1 - Sensor 1Oxygen Sensor Heater Monitor Bank 1 - Sensor 1
66 ($42): Test-ID 66 ($42): Oxygen Sensor Heater Monitor Bank 1 - Sensor 2Oxygen Sensor Heater Monitor Bank 1 - Sensor 2
69 ($45): Test-ID 69 ($45): Oxygen Sensor Heater Monitor Bank 2 - Sensor 1Oxygen Sensor Heater Monitor Bank 2 - Sensor 1
70 ($46): Test-ID 70 ($46): Oxygen Sensor Heater Monitor Bank 2 - Sensor 2Oxygen Sensor Heater Monitor Bank 2 - Sensor 2
162 ($A2): Test-ID 162 ($A2): Mis-Fire Cylinder 1 DataMis-Fire Cylinder 1 Data
163 ($A4): Test-ID 163 ($A4): Mis-Fire Cylinder 2 DataMis-Fire Cylinder 2 Data
164 ($A4): Test-ID 164 ($A4): Mis-Fire Cylinder 3 DataMis-Fire Cylinder 3 Data
165 ($A5): Test-ID 165 ($A5): Mis-Fire Cylinder 4 DataMis-Fire Cylinder 4 Data
166 ($A4): Test-ID 166 ($A4): Mis-Fire Cylinder 5 DataMis-Fire Cylinder 5 Data
167 ($A7): Test-ID 167 ($A7): Mis-Fire Cylinder 6 DataMis-Fire Cylinder 6 Data

Test-ID 01 ($01): Oxygen Sensor Monitor Bank 1 - Sensor 1

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 01 ($01)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
131 ($83)P0133Response Check.0.205Refer to DTC P0133 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 02 ($02): Oxygen Sensor Monitor Bank 1- Sensor 2

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 02 ($02)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
01 ($01)Voltage barrier from rich to lean (fixed value) Oxygen sensor behind cat., bank 1.708 mV708 mV
02 ($02)Voltage barrier from lean to rich (fixed value) Oxygen sensor behind cat., bank 1.708 mV708 mV
07 ($07)Minimum sensor voltage in this driving cycle Oxygen sensor behind cat., bank 1.1.0 V5 V
08 ($08)Maximum sensor voltage in this driving cycle Oxygen sensor behind cat., bank 1.0 V0.009 V
129 ($81)P0136Signal activity check.0.542 V5 VRefer to DTC P0136 in Fuel and air ratios .
130 ($82)P0136Signal activity check.0 V1.039 VRefer to DTC P0136 in the DTC table Fuel and air ratios .
131 ($83)P0136Fuel cut off Check.0 V200.0 mVRefer to DTC P0136 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 05 ($05): Oxygen Sensor Monitor Bank 2 - Sensor 1

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 05 ($05)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
131 ($83)P0153Response Check.0.205Refer to DTC P0153 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 06 ($06): Oxygen Sensor Monitor Bank 2 - Sensor 2

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 06 ($06)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
01 ($01)Voltage barrier from rich to lean (fixed value) Oxygen sensor behind cat., bank 2.708 mV708 mV
02 ($02)Voltage barrier from lean to rich (fixed value) Oxygen sensor behind cat., bank 2.708 mV708 mV
07 ($07)Minimum sensor voltage in this driving cycle Oxygen sensor behind cat., bank 2.1.0 V5 V
08 ($08)Maximum sensor voltage in this driving cycle Oxygen sensor behind cat., bank 2.0 V0.009 V
129 ($81)P0156Signal activity check.0.542 V5 VRefer to DTC P0156 in Fuel and air ratios .
130 ($82)P0156Signal activity check.0 V1.039 VRefer to DTC P0156 in Fuel and air ratios .
131 ($83)P0156Fuel cut off Check.0 V200.0 mVRefer to DTC P0156 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 33 ($21): Catalyst Monitor Bank 1

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 33 ($21)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
132 ($84)P0421Conversion Capability (storage) Check.00.797Refer to DTC P0421 in Additional exhaust regulation .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 34 ($22): Catalyst Monitor Bank 2

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 34 ($22)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
132 ($84)P0431Catalytic converter monitoring, Bank 1.00.797Refer to DTC P0431 in Additional exhaust regulation .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

$3A (58): Fuel Tank EVAP System Leak Test (0.090)

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 59 ($3B)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
129 ($81)P0455Tank leak test: Large leak.700 msRefer to DTC P0455 in Additional exhaust regulation .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 59 (3B): EVAP Monitor (0.040)

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 59 ($3B)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
129 ($81)P0442Tank leak test: Small leak (1.0 mm).1210 msRefer to DTC P0442 in Additional exhaust regulation .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 60 (3C): EVAP Monitor (0.020)

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 60 ($3C)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
130 ($82)P0456Tank leak test: Small leak (0.5 mm).4280 msRefer to DTC P0456 in Additional exhaust regulation .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 61 (3D): Purge Flow Monitor

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 61 ($3D)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
128 ($80)P0441Function Check.04.849%Refer to DTC P0441 in Additional exhaust regulation .
130 ($82)Function Check.3.5%
131 ($83)Function Check.0.04
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 65 ($41): Oxygen Sensor Heater Monitor Bank 1 - Sensor 1

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 65 ($41)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
133 ($85)P0135Oxygen sensor heating in front of catalytic converter, diagnosis, Bank 1.680°C> 860°CRefer to DTC P0135 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 69 ($45): Oxygen Sensor Heater Monitor Bank 2 - Sensor 1

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 69 ($45)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
129 ($81)P0155Oxygen sensor heating behind catalytic converter, diagnosis, Bank 2 Nernst cell internal resistance test.680°C> 860°CRefer to DTC P0155 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 66 ($42): Oxygen Sensor Heater Monitor Bank 1 - Sensor 2

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 66 ($42)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
129 ($81)P0141Oxygen sensor heating behind catalytic converter, diagnosis, Bank 1 Nernst cell internal resistance test.0 ohms43320 ohmsRefer to DTC P0141 in Fuel and air ratios .
  1. If any component or system fails to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 70 ($46): Oxygen Sensor Heater Monitor Bank 2 - Sensor 2

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 70 ($46)".

  1. Select the desired "Test-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
129 ($81)P0161Oxygen sensor heating behind catalytic converter, diagnosis, Bank 2 Nernst cell internal resistance test.0 ohms43320 ohmsRefer to DTC P0161 in Fuel and air ratios .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 162 ($A2): Mis-Fire Cylinder 1 Data

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 162 ($A2)".

  1. Select the desired "Test-ID (TID)" or "Hex-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
11 ($0B)P0301Burn misfire cylinder 1 average value over 10 driving cycles.065535 (counts)Refer to DTC P0301 in Ignition system .
12 ($0C)P0301Burn misfire cylinder 1 during this driving cycle.065535 (counts)Refer to DTC P0301 in Ignition system .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 163 ($A4): Mis-Fire Cylinder 2 Data

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 163 ($A4)".

  1. Select the desired "Test-ID (TID)" or "Hex-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
11 ($0B)P0302Burn misfire cylinder 2 average value over 10 driving cycles.065535 (counts)Refer to DTC P0302 in Ignition system .
12 ($0C)P0302Burn misfire cylinder 2 during this driving cycle.065535 (counts)Refer to DTC P0302 in Ignition system .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 164 ($A4): Mis-Fire Cylinder 3 Data

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 164 ($A4)".

  1. Select the desired "Test-ID (TID)" or "Hex-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
11 ($0B)P0303Burn misfire cylinder 3 average value over 10 driving cycles.065535 (counts)Refer to DTC P0303 in Ignition system .
12 ($0C)P0303Burn misfire cylinder 3 during this driving cycle.065535 (counts)Refer to DTC P0303 in Ignition system .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 165 ($A5): Mis-Fire Cylinder 4 Data

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 165 ($A5)".

  1. Select the desired "Test-ID (TID)" or "Hex-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
11 ($0B)P0304Burn misfire cylinder 4 average value over 10 driving cycles.065535 (counts)Refer to DTC P0304 in Ignition system .
12 ($0C)P0304Burn misfire cylinder 4 during this driving cycle.065535 (counts)Refer to DTC P0304 in Ignition system .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 166 ($A4): Mis-Fire Cylinder 5 Data

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 166 ($A4)".

  1. Select the desired "Test-ID (TID)" or "Hex-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
11 ($0B)P0305Burn misfire cylinder 5 average value over 10 driving cycles.065535 (counts)Refer to DTC P0305 in Ignition system .
12 ($0C)P0305Burn misfire cylinder 5 during this driving cycle.065535 (counts)Refer to DTC P0305 in Ignition system .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Test-ID 167 ($A7): Mis-Fire Cylinder 6 Data

  1. Connect the diagnostic tester.
  2. Start the engine and let run at idle speed.
  3. Select "Mode 6: Check test the results of components that are not continuously monitored".

Select "Test-ID 167 ($A7)".

  1. Select the desired "Test-ID (TID)" or "Hex-ID".
  2. Check specified values at idle.
Test-ID (TID) (Hex-ID)DTCComponent or SystemMin.Max.Additional Information
11 ($0B)P0306Burn misfire cylinder 6 average value over 10 driving cycles.065535 (counts)Refer to DTC P0306 in Ignition system .
12 ($0C)P0306Burn misfire cylinder 6 during this driving cycle.065535 (counts)Refer to DTC P0306 in Ignition system .
  1. If any of the components or systems fail to meet the specified values, refer to Diagnostic "Mode 03: Interrogating Fault Memory" to check for stored DTCs or the corresponding diagnostic repair procedure.
  2. Switch the ignition off.
  3. End of diagnosis.

Diagnostic Mode 07: Check Test Results of Components that are Continuously Monitored

Diagnostic Mode 07 displays all stored DTCs of emission related components and systems which are continuously monitored.

Test requirements

  1. No DTCs stored in the DTC memory.
  2. Coolant temperature at least 80°C.

Procedure

  1. Connect the diagnostic tester.
  2. Start the engine and run at idle.

Note. If the engine does not start, crank the engine using starter for at least 5 seconds, do not switch the ignition off afterward under any circumstances.

  1. Select "Mode 7: Check test results of components that are continuously monitored".

The number of stored DTCs or "0 malfunctions detected" will be displayed diagnostic tester screen.

  1. Switch the ignition off.
  2. Refer to the following DTC tables for the diagnostic repair procedure
  1. SAE P0xxxDTCs. --> «SAE P0xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  2. SAE P1xxx-DTCs --> «SAE P1xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  3. SAE P2xxxDTCs. --> «SAE P2xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  4. SAE P3xxxDTCs. --> «SAE P3xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. SAE U0xxxDTCs, --> «SAE U0xxx DTCs»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  1. Switch the ignition off.
  2. End of diagnosis.

Diagnostic Mode 08: Tank Leak Test

Diagnostic Mode 08 is used to determine if the fuel system may be leaking.

Depending on the scan tool being used, the function test in Diagnostic Mode 08 may or may not be able to be performed.

If the scan tool being used will operate Diagnostic Mode 08, perform the test below Function test .

If the scan tool being used will not operate Diagnostic Mode 08, refer to --> EVAP System, Leak Detection .

Note. Always follow the manufacturers instructions for the scan tool being used.

Test requirements

  1. No DTCs stored in the DTC memory.
  2. Intake Air Temperature (IAT) maximum 60°C.
  3. Coolant temperature 80 -110°C.
  4. Throttle valve angle 12.0 - 16.0%.

Function test

Note. If the accelerator pedal is depressed during the test, the test will be aborted.

  1. Connect the scan tool.
  2. Start the engine and run at idle for at least 15 minutes.
  3. Select "Diagnostic Mode 08 - Tank Leak Test".
  4. Select " Tank Leak Test".
  1. Check the specified value of the tank leak test at idle.
  2. The following may be displayed on the scan tool screen
Tank leak testSpecified value
Test function active Test function is being initiated, please wait Test off Test abortedTest OK
  1. Switch the ignition off.

If the specified result is obtained

System OK.

If the specified result is not obtained

  1. Repeat the tank leak test, switch the ignition off and start the engine again and let run for 15 minutes at idle.
  2. Switch the ignition off.

If the specified result is again not obtained

  1. A leak may be present. Refer to --> «EVAP System, Leak Detection»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__evap-system-leak-detection) .

End of diagnosis.

Diagnostic Mode 09: Vehicle Information

Note. For all calibration and immobilizer information.

Diagnostic Mode 09 is used to display vehicle specific information, e.g. the different Engine Control Module (ECM) versions.

Test requirement

  1. No DTCs stored in the DTC memory.

Procedure

  1. Connect the diagnostic tester.
  2. Switch the ignition on.
  3. Select "Mode 09: Vehicle information".
  4. Select the desired "Test-ID".
  1. The information requested will be displayed on the diagnostic tester screen.

The following table is a numerical list of all "Test-IDs" that may be selected.

Test-IDDiagnostic text
02Vehicle identification number e.g.
A different 17 digit number will be displayed for each vehicle
04Calibration identification e.g.
Engine Control Module (ECM)
Transmission Control Module (TCM)
06CVN (check sum) e.g.
EC5AE460 the check sum is different for every control module version
000D105
  1. Switch the ignition off.
  2. End of diagnosis.

General Diagnosis

The following table provides quick links to all chapters in this section.

Preliminary Check

Before performing any pin point test or component diagnosis, a preliminary check must be performed.

Check the Technical Bulletins for information that may supersede any information included in this article.

  1. Connect the scan tool.
  2. Switch the ignition on.
  3. Using the scan tool, check for any stored or related DTCs.

If other DTCs are stored

  1. Repair these DTCs first before performing the following procedure.

If no other DTCs are stored

  1. Using the scan tool, erase the DTC memory. Refer to --> «Diagnostic Mode 04: Reset/delete Diagnostic Data»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh__diagnostic-mode-04-resetdelete-diagnostic-data) .
  2. Perform a road test to attempt to duplicate the customers complaint.

If the DTC returns

  1. Perform the diagnostic procedure.

If the DTC does not return

  1. The fault is intermittent or a sporadic condition may exist.
  2. Check the suspected component, electrical harness and electrical harness connectors for damage, corrosion, loose or broken terminals.
  3. If necessary, repair the faulty wiring connection.
  4. Perform a road test to verify the repair.

If the DTC returns

  1. Perform the diagnostic procedure.

If the DTC does not return

The fault may have been the result of a loose electrical connection.

  1. Generate readiness code. Refer to --> «Readiness Code»(/audi/a4/b7-2004-2009/remont/cooling-fan/#32l-v6-4v-generic-scan-tool-engine-code-bkh) .
  2. End of diagnosis.

Readiness Code

Readiness Code Description

Diagnostics are performed at regular intervals during normal vehicle operation. After repairing an emissions related system, a readiness code is generated by road testing the vehicle.

If a malfunction is recognized during the drive cycle, it will be stored in the DTC memory.

The OBD drive cycle operation will be monitored with a hand held diagnostic tool. Consult the manufacturers instruction manual for correct tool operation.

The readiness code is erased every time the DTC memory is erased or any time the battery is disconnected. If the DTC memory has been erased or the battery is disconnected, a new readiness code must be generated.

Only erase the DTC memory if a DTC has been stored.

General Recommendations

Most monitors will complete easier and quicker using a steady-foot and smooth acceleration during the drive cycle operation, cruise, and acceleration modes.

Operating Conditions

For the EVAP monitor test, the coolant temperature and the ambient air temperature must be between 10°C and 35°C with a difference between them no greater than 4°C. The ambient air temperature must not change more than 4°C during the drive cycle procedure (e.g. when driving out of a heated workshop in the winter).

Test requirements

  1. Erase the DTC memory.
  2. Coolant temperature must be between 80°C and 110°C.
  3. The Intake Air Temperature (IAT) must be between 10°C and 35°C.
  4. Battery voltage must be a minimum of 12.5 volts.
  1. Fuel tank level 1/4 to 3/4 full.
CAUTIONWhen performing the drive cycle operation, pay strict attention to driving conditions and please observe and obey all posted speed limits. Failure to follow these instructions may result in personal injury or possible death.

Drive Cycle Procedure

  1. Connect the diagnostic tester.
  2. Switch the ignition on and start the vehicle.
  3. Idle the vehicle for 2-3 minutes. This executes the O2S Heater, Misfire, Secondary AIR, Fuel Trim, and Purge system monitors.
  4. Drive the vehicle at 45-55 mph for a continuous 7-minute period, avoid stopping. This executes the EVAP, O2S, Fuel Trim, and Misfire monitors.
  1. Accelerate the vehicle to an engine speed of 5000 RPM (with automatic transmission use the tip-tronic mode); lift off the throttle until the engine speed is around 1200 rpm. This executes the fuel cut off
  2. Accelerate the vehicle smoothly to 60-65 mph, cruise constantly for 5 min, this executes the Catalyst; O2S, Misfire, Fuel Trim, and Purge System monitors.
  3. Decelerate and idle the vehicle again for 3 minutes. This executes the Misfire, Secondary AIR, Fuel Trim, and Purge system monitors.
  4. Check the status of the readiness code.

Note. Depending on the diagnostic tester used. The readiness code status may be displayed as complete, passed or OK.

  1. If any engine monitor fails the drive cycle test. Repeat the drive cycle test until all engine monitors have successfully run through and passed.

Note. When repeating the drive cycle operation for a failed EVAP monitor or thermostat-monitor, allow the engine to cool until the coolant temperature and the ambient air temperature are be between 10°C and 35°C with a difference between them no greater than 4°C is observed and repeat the drive cycle operation.

If the drive cycle operation fails again.

  1. Check the DTC memory for stored DTCs.

Repair the vehicle if necessary.

  1. Repeat the drive cycle operation until all engine monitors have successfully run through and passed.
  2. Remove the diagnostic tester and switch the ignition off.
  3. End of operation.

Diagnostic Trouble Code (DTC) tables

Fuel, air mixture, and additional emissions regulations

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P000AIntake (A) Camshaft Position Slow Response Bank 1Check the Camshaft Position (CMP) Sensor G40. Refer to --> Camshaft Position (CMP) Sensors , Checking . Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking . Check the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .Signal change, 10°CA Number of checks, 15Engine speed, >700 rpm Set point change behavior check, 3°CA for 1.2 sec. Set point change, >15°CA1 SecondContinuous 2 DCY
P000BIntake (B) Camshaft Position Slow Response Bank 1Check the Camshaft Position (CMP) Sensor 3 G300. Refer to --> Camshaft Position (CMP) Sensors , Checking . Check the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .Signal change, 10°CA Number of checks, 15Engine speed, >700 rpm Set point change behavior check, 3°CA for 1.2 sec. Set point change, >15°CA1 SecondContinuous 2 DCY
P000CIntake (A) Camshaft Position Slow Response Bank 2Check the Camshaft Position (CMP) Sensor 2 G163. Refer to --> Camshaft Position (CMP) Sensors , Checking . Check the Camshaft Adjustment Valve 2 N208. Refer to --> Camshaft Adjustment Valve , Checking . Check the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .Signal change, 10°CA Number of checks, 15Engine speed, >700 rpm Set point change behavior check, 3°CA for 1.2 sec. Set point change, >15°CA1 SecondContinuous 2 DCY
P000DIntake (B) Camshaft Position Slow Response Bank 2Check the Camshaft Position (CMP) Sensor 4 G301. Refer to --> Camshaft Position (CMP) Sensors , Checking . Check the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .Signal change, 10°CA Number of checks, 15Engine speed, >700 rpm Set point change behavior check, 3°CA for 1.2 sec. Set point change, >15°CA1 SecondContinuous 2 DCY
P0010Intake (A) Camshaft Position Actuator Circuit/Open (Bank 1)Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking .Signal current, > 0.8 mACamshaft valve, commanded on2 SecondsContinuous 2 DCY
P0011(A) Camshaft Position - Timing Over-Advanced or System Performance, Bank 1Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking .Adjustment Angle difference, > 12°CA for more than 3 seconds Number of checks, 3 timesEngine speed 700 rpm Oil temperature 15 -130°C Delta set point 3°CA, than wait 3 - 6 seconds3 SecondsContinuous 2 DCY
P0013B Camshaft Position Actuator Circuit/Open, Bank 1Check the Camshaft Adjustment Valve 1 (exhaust) N318. Refer to --> Camshaft Adjustment Valve , Checking .Signal current, > 0.8 mACamshaft valve, Commanded on2 SecondsContinuous 2 DCY
P0014B Camshaft Position - Timing Over-Advanced or System Performance, Bank 1Check the Camshaft Adjustment Valve 1 (exhaust) N318. Refer to --> Camshaft Adjustment Valve , Checking .Adjustment Angle difference, > 12°CA for more than 3 seconds Number of checks, 3 timesEngine speed 700 rpm Oil temperature 15 -130°C Delta set point 3°CA, then wait 3 - 6 seconds3 SecondsContinuous 2 DCY
P0020Intake (A) Camshaft Position Actuator Circuit/Open (Bank 1)Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking .Signal current, > 0.8 mACamshaft valve, Commanded on2 SecondsContinuous 2 DCY
P0021(A) Camshaft Position - Timing Over-Advanced or System Performance, Bank 2)Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking .Adjustment Angle difference, > 12°CA for more than 3 seconds Number of checks, 3 timesEngine speed 700 rpm Oil temperature 15 -130°C Delta set point 3°CA, than wait 3 - 6 seconds3 SecondsContinuous 2 DCY
P0023B Camshaft Position Actuator Circuit/Open, Bank 2Check the Camshaft Adjustment Valve 2 (exhaust) N319. Refer to --> Camshaft Adjustment Valve , Checking .Signal current, > 0.8 mACamshaft valve, Commanded on2 SecondsContinuous 2 DCY
P0024B Camshaft Position - Timing Over-Advanced or System Performance, Bank 2Check the Camshaft Adjustment Valve 2 (exhaust) N319. Refer to --> Camshaft Adjustment Valve , Checking .Adjustment Angle difference, > 12°CA for more than 3 seconds Number of checks, 3 timesEngine speed 700 rpm Oil temperature 15 -130°C Delta set point 3°CA, than wait 3 - 6 seconds3 SecondsContinuous 2 DCY
P0030HO2S Heater control circuit, Bank 1 Sensor 1Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .Heater current, 8 - 40 mAHeater, Commanded on Duty cycle, 0.4 - 99.6%5.2 SecondsContinuous 2 DCY
P0031HO2S Heater control circuit low, Bank 1 Sensor 1Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .Heater voltage, 1.9 - 2.22 VHeater, Commanded off Duty cycle, 99.6%5.2 SecondsContinuous 2 DCY
P0032HO2S Heater control circuit high, Bank 1 Sensor 1Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .Heater current >8 - 11 AHeater, Commanded off Duty cycle, >0.4%5.2 SecondsContinuous 2 DCY
P0036HO2S Heater control circuit, Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Heater Z29. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater current, 8 - 40 mAHeater, Commanded on Duty cycle, 0.4 - 99.6%5.2 SecondsContinuous 2 DCY
P0037HO2S Heater control circuit low, Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Heater Z29. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater voltage, 1.9-2.22 VHeater, Commanded off Duty cycle, 99.6%5.2 SecondsContinuous 2 DCY
P0038HO2S Heater control circuit high, Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Heater Z29. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater current bank 1, > 8-11 AHeater, Commanded off Duty cycle, >0.4%5.2 SecondsContinuous 2 DCY
P004002 Sensor Signals Swapped Bank 1 Sensor 1, Bank 2 Sensor 1Check the oxygen sensors for swapping.Deviation lambda control Sensor 1 > 24% and sensor 2 -24% or Sensor 1 - 24% and sensor 2 > 24%Lambda control, active50 SecondsContinuous 2 DCY
P004102 Sensor Signals Swapped Bank 1 Sensor 2, Bank 2 Sensor 2Check the oxygen sensors for swapping.Sensor 1 > 0.830 V and sensor 2 0.156 V or Sensor 1 0.156 and sensor 2 > 0.830 VMass air flow integrated, > 400 G O2S rear, no other faults O2S rear, closed loop50 SecondsContinuous 2 DCY
P0050HO2S Heater control circuit, Bank 1 Sensor 1Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .Heater current, 8 - 40 mAHeater, Commanded on Duty cycle, 0.4 - 99.6%5.2 SecondsContinuous 2 DCY
P0051HO2S Heater control circuit low, Bank 1 Sensor 1Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .Heater voltage, 1.9 - 2.22 VHeater, commanded off Duty cycle, 99.6%5.2 SecondsContinuous 2 DCY
P0052HO2S Heater control circuit high, Bank 1 Sensor 1Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .Heater current >8 - 11 AHeater, commanded off Duty cycle, >0.4%5.2 SecondsContinuous 2 DCY
P0056HO2S Heater control circuit, Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Heater Z29. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater current, 8 - 40 mAHeater, commanded on Duty cycle, 0.4 - 99.6%5.2 SecondsContinuous 2 DCY
P0057HO2S Heater control circuit low, Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Heater Z29. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater voltage, 1.9-2.22 VHeater, commanded off Duty cycle, 99.6%5.2 SecondsContinuous 2 DCY
P0058HO2S Heater control circuit high, Bank 2 Sensor 2Check the Oxygen Sensor (O2S) Heater Z30. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater current bank 2, > 35 AHeater, commanded off Duty cycle, >0.4%5.2 SecondsContinuous 2 DCY
P0068MAP/MAF Throttle Position CorrelationCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .Deviation throttle excitations -43 or >43% -33 or >33% Deviation throttle exitations -39 - >21% or 2% -40 - >28% or 2%Pressure quotient, 0.53 Time after engine start, >70 seconds Fuel cut off, Not active Fuel trim activity, -23->23% Pressure quotient, 0.633 SecondsContinuous 2 DCY
P0069Manifold Absolute Pressure (MAP) - Barometric Pressure CorrelationCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .Altitude sensor signal vs IM pressure >27 kPaModeled pressure ratio at throttle 0.05 or Throttle position, 28-81° Engine speed, 600 - 4000 RPM3 SecondsContinuous 2 DCY
P0087Fuel/Rail System Pressure - Too LowCheck the Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Deviation fuel rail pressure control, 0.025 G Deviation lambda control, -10 +10%Fuel cut off, Not active Engine speed, 640-3480 RPM Time after engine start, >250 seconds High pressure pump set point, 0.005-0.05 G Lambda control, Closed loop EVAP canister load, 25%5 SecondsContinuous 2 DCY
P0088Fuel/Rail System Pressure - Too HighCheck the Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Actual pressure, >13.5 PSIEngine speed, 640-6000 RPM Time after engine start, >250 seconds5 SecondsContinuous 2 DCY
P0089Fuel Pressure Regulator 1 PerformanceCheck the Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Deviation fuel pressure control (LP), 28% - >35%Engine speed, 500-3000 RPM Time after engine start, >30 seconds ECT, 70-95°C Delta fuel pressure low, 25 kPa Fuel cut off, Not active5 SecondsContinuous 2 DCY
P0090Fuel Pressure regulator 1 Control CircuitCheck the Fuel pressure and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal voltage, 3 VCamshaft valve, Commanded off2 SecondsContinuous 2 DCY
P0091Fuel Pressure regulator 1 Control Circuit LowCheck the Fuel pressure and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal current, >1 AmpCamshaft valve, Commanded on2 SecondsContinuous 2 DCY
P0094Fuel System Leak Detected - Small LeakCheck the Fuel pressure and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal voltage, 3 VCamshaft valve, Commanded off2 SecondsContinuous 2 DCY
P0095Intake Air Temperature Sensor 2 CircuitCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .Signal current, >1 AmpCamshaft valve, Commanded on2 SecondsContinuous 2 DCY

Fuel and air ratios

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P0106Manifold Absolute Pressure/BARO Sensor Range/PerformanceCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .Altitude sensor signal vs. IM pressure, >20 kPa Boost pressure signal, >23 kPaEngine speed, 0 RPM Time after engine start, 0 sec. Throttle position, 28-81° Engine speed, 600-4000 RPM3 SecondsContinuous 2 DCY
P0107Manifold absolute pressure/Barometric pressure circuit low inputCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .Signal voltage, 0.2 V2 SecondsContinuous 2 DCY
P0108Manifold absolute pressure/Barometric pressure circuit high inputCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .Signal voltage, > 4.8 V2 SecondsContinuous 2 DCY
P0112Intake Air Temperature Sensor 1 Circuit Low InputCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .IAT, > 141.0°C2 SecondsContinuous 2 DCY
P0113Intake Air Temperature Sensor 1 Circuit High InputCheck the Intake Air Temperature (IAT) Sensor G42. Refer to --> Intake Air Temperature (IAT) Sensor G42 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks .IAT, 45.75°C2 SecondsContinuous 2 DCY
P0116Engine Coolant Temperature Sensor 1 Circuit Range/PerformanceCheck the Engine Coolant Temperature (ECT) Sensor G62. Refer to --> Engine Coolant Temperature (ECT) Sensor G62 , Checking . Check the coolant regulator --> 19 - ENGINE - COOLING SYSTEM .Delta ECT, 77°CECT at start- 75 - 141°C Driving condition 1 >22 sec. Vehicle speed, >12.5 mph Engine speed, >2500 rpm Mass air flow, >60 kg/h and Driving condition 2 >22 sec. Fuel cut off, Active Or Vehicle speed, >65 mph Engine speed, Idle And if no pass cond. 1 2400 sec. Ignition, off >400 sec. ECT at start, 80-110°C Delta modeled ECT, 13 K ECT T start, 40-75°C155 Seconds 400 sec. after DCY 30 SecondsContinuous 2 DCY
P0117Engine Coolant Temperature Sensor 1 Circuit Low InputCheck the Engine Coolant Temperature (ECT) Sensor G62. Refer to --> Engine Coolant Temperature (ECT) Sensor G62 , Checking . Check the coolant regulator --> 19 - ENGINE - COOLING SYSTEM .ECT, >141°C2 SecondsContinuous 2 DCY
P0118Engine Coolant Temperature Sensor 1 Circuit High InputCheck the Engine Coolant Temperature (ECT) Sensor G62. Refer to --> Engine Coolant Temperature (ECT) Sensor G62 , Checking . Check the coolant regulator --> 19 - ENGINE - COOLING SYSTEM .ECT, 43.5°C2 SecondsContinuous 2 DCY
P0121Throttle/Pedal Position Sensor A Circuit Range/PerformanceCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .TPS 1-TPS 2, >5.79% Relative mass air integral, >100 at 0.45 sec.Engine start, Completed TPS, No fault0.2 SecondsMultiple 2 DCY
P0122Throttle/Pedal Position Sensor A Circuit Low InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage, 0.117 V0.2 SecondsContinuous 2 DCY
P0123Throttle/Pedal Position Sensor A Circuit High InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage, > 4.88 V0.2 SecondsContinuous 2 DCY
P0131O2 Circuit Low Voltage (Bank 1, Sensor 1)Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Short to ground, 0.13 V3 SecondsContinuous 2 DCY
P0132O2 Circuit High Voltage (Bank 1, Sensor 1)Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Short to battery + >5.5 V3 SecondsContinuous 2 DCY
P0133O2 Circuit Slow Response (Bank 1, Sensor 1)Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Lambda value vs. modeled lambda value >0.8Modeled temp, 500 - 950°C ECT, >60°C Engine speed, 700 - 3000 rpm Engine speed deviation, 518 rpm Mass air flow, 0.426 - 1.2 g/rev Delta mass air flow, 0.264 g/rev EVAP canister load, 40%65 SecondsOnce/DCY 2 DCY
P0135O2 Heater Circuit (Bank 1, Sensor 1)Check the Oxygen Sensor (O2S) Heater Z19. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .O2S not ready after dew-point exceeded >40 sec. UEGO ceramic temperature 680 or > 860°CO2S front dew-point, Exceeded Heater control, Active O2S front, No other faults O2S front dew-point, Exceeded Heater control, Active Lambda control, Active O2S front, No other faults40 Seconds 120 SecondsOnce/DCY 2 DCY Continuous 2 DCY
P0136O2 Circuit (Bank 1, Sensor 2)Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .O2S signal rear 0.708 V Not oscillating at reference Signal voltage >0.2 VO2S rear, Ready Trim control post cat, Closed loop Integrated mass air flow, 20 - 150 g Fuel cut off- Active5 SecondsContinuous 2 DCY
P0137O2 Circuit Low Voltage (Bank 1, Sensor 2)Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage-20 mV and Internal resistance-10 OhmsO2S rear dewpoint, exceeded O2S rear, fully heated up Mass air flow, >12 kg/h5 SecondsContinuous 2 DCY
P0138O2 Circuit High Voltage (Bank 1, Sensor 2)Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage 1.5 V5 SecondsContinuous 2 DCY
P0140O2 Circuit No Activity Detected (Bank 1, Sensor 2)Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage, 0.370.47mVModeled exhaust gas temp. >555°C5 SecondsContinuous 2 DCY
P0141O2 Heater Circuit (Bank 1, Sensor 2)Check the Oxygen Sensor (O2S) Heater Z29. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Heater resistance, >10K OhmModeled exhaust gas temp, 300-400°C Heater duty cycle, 0.8 - 99.2%60 SecondsContinuous 2 DCY
P0151Bank 2 sensor 1 Voltage too lowCheck the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Short to ground-0.13 V3 SecondsContinuous 2 DCY
P0152O2 Sensor Circuit, Bank 2 - Sensor 1 High VoltageCheck the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Short to battery+>5.5 V3 SecondsContinuous 2 DCY
P0153O2 Sensor Circuit, Bank 2 - Sensor 1 Slow ResponseCheck the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Lambda value vs. modeled lambda value, >0.8Modeled temp, 500 - 950°C ECT, >60°C Engine speed, 700 - 3000 rpm Engine speed deviation, 518 rpm Mass air flow, 0.426 - 1.2 g/rev Delta mass air flow, 0.264 g/rev EVAP canister load, 40%65 SecondsContinuous 2 DCY
P0155O2 Sensor Heater Circuit, Bank 2 Sensor 1 Electrical FaultCheck the Oxygen Sensor (O2S) 2 Heater Z28. Refer to --> Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking .O2S not ready after dew-point exceeded->40 sec. UEGO ceramic temperature-680 or > 860°CO2S front dew-point, Exceeded Heater control, Active O2S front, No other faults O2S front dew-point, Exceeded Heater control, Active Lambda control, Active O2S front, No other faults40 Seconds 120 SecondsOnce/DCY 2 DCY Continuous 2 DCY
P0156O2 Sensor Circuit, Bank 2 - Sensor 2 MalfunctionCheck the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .O2S signal rear 0.708 V Not oscillating at reference Signal voltage >0.2 VO2S rear, Ready Trim control post cat, Closed loop Integrated mass air flow, 20-150 g Fuel cut off, Active5 SecondsContinuous 2 DCY
P0157O2 Sensor Circuit, Bank 2 - Sensor 2 Low VoltageCheck the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage-20 mV And Internal resistance 10 OhmsO2S rear dew point, Exceeded O2S rear, Fully heated up Mass air flow, >12 kg/h5 SecondsContinuous 2 DCY
P0158O2 Sensor Circuit, Bank 2 - Sensor 2 High VoltageCheck the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage >1.5 V5 SecondsContinuous 2 DCY
P0160O2 Sensor Circuit No Activity Detected (Bank 2 Sensor 2)Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage 0.376 - 0.474 VModeled exhaust temperature >555°C5 SecondsContinuous 2 DCY
P0161HO2S Heater Control Circuit (Bank 2 Sensor 2)Check the Oxygen Sensor (O2S) 2 (behind Three Way Catalytic Converter (TWC)) Heater Z30. Refer to --> Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking .Internal resistance >10K OhmsModeled exhaust gas temp, 300 - 400°C Heater duty cycle, 0.8 - 99.2%60 SecondsOnce/DCY 2 DCY
P0171System Too Lean (Bank 1)Check the fuel pump delivery and quantity. Refer to --> Fuel Pump Delivery Quantity, Checking . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check Fuel Pressure Sensor G247 --> Fuel Pressure Sensor G247 , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking . Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check exhaust system for proper seal. Check vacuum lines for leaksAdditive system too rich Adaptive value->25% Multiplicative system too rich Adaptive value->22%Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Mass fuel flow, 0.04 g/rev Engine speed, 864 RPM Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Engine speed, 9924500 RPM Mass air flow, 34450 kg/h Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g35 SecondsContinuous 2 DCY
P0172System Too Rich (Bank 1)Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Additive system too rich Adaptive value -25% Multiplicative system too rich Adaptive value -25%Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Mass fuel flow, 0.04 g/rev Engine speed, 864 RPM Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Engine speed, 9924500 RPM Mass air flow, 34450 kg/h Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g35 SecondsContinuous 2 DCY
P0174System too Lean, Bank 2Check the fuel pump delivery and quantity. Refer to --> Fuel Pump Delivery Quantity, Checking . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check Fuel Pressure Sensor G247 --> Fuel Pressure Sensor G247 , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking . Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check exhaust system for proper seal. Check vacuum lines for leaksAdditive system too rich Adaptive value >22% Multiplicative system too rich Adaptive value >22%Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Mass fuel flow, 0.04 g/rev Engine speed, 864 RPM Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Engine speed, 9924500 RPM Mass air flow, 34450 kg/h Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g35 SecondsContinuous 2 DCY
P0175System too Rich, Bank 2Check the fuel pump delivery and quantity. Refer to --> Fuel Pump Delivery Quantity, Checking . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check Fuel Pressure Sensor G247 --> Fuel Pressure Sensor G247 , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking . Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check exhaust system for proper seal. Check vacuum lines for leaksAdditive system too rich Adaptive value -25% Multiplicative system too rich Adaptive value -25%Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Mass fuel flow, 0.04 g/rev Engine speed, 864 RPM Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g Lambda control, Closed loop EVAP purge valve, Closed ECT or Sub. ECT, >70°C Engine speed, 9924500 RPM Mass air flow, 34450 kg/h Delta mass air flow, 7.5 kg/h Accelerator PP value, 250%/sec. Integrated mass air flow, >25 g35 SecondsContinuous 2 DCY
P0190Fuel Rail Pressure Sensor A CircuitCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal voltage > 4.8 V2 SecondsContinuous 2 DCY
P0192Fuel Rail Pressure Sensor A Circuit Low InputCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal voltage 0.2 V2 SecondsContinuous 2 DCY
P0201Injector Circuit/Open - Cylinder 1Check the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0202Injector Circuit/Open - Cylinder 2Check the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0203Injector Circuit/Open - Cylinder 3Check the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0204Injector Circuit/Open - Cylinder 4Check the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0205Injector Circuit/Open - Cylinder 5Check the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0206Injector Circuit/Open - Cylinder 6Check the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0219Engine Overspeed ConditionInspect and repair mechanical damage as necessary.Engine speed, >6750 RPMRange position, Not P,R,N Position sensor, Status OK Engine speed, Status OK Time since range position not P,R,N, 2 Sec.0.5 SecondsContinuous 2 DCY
P0221Throttle/Pedal Position Sensor/Switch B Circuit Range/PerformanceCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .TPS 1-TPS 2, >5.79° And Relative mass air integral >100 at 0.45 sec.Engine start, Completed TPS, No fault0.2 SecondsContinuous 2 DCY
P0222Throttle/Pedal Position Sensor/Switch B Circuit Low InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage, 0.117 V0.2 SecondsContinuous 2 DCY
P0223Throttle/Pedal Position Sensor/Switch B Circuit High InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage, > 4.88 V0.2 SecondsContinuous 2 DCY
P0261Cylinder 1 Injector Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0262Cylinder 1 Injector Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, >16 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P0264Cylinder 2 Injector Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0265Cylinder 2 Injector Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, >16 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P0267Cylinder 3 Injector Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0268Cylinder 3 Injector Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, >16 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P0270Cylinder 4 Injector Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0271Cylinder 4 Injector Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, >16 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P0273Cylinder 5 Injector Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0274Cylinder 5 Injector Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, >16 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P0276Cylinder 6 Injector Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, 10 A And Signal voltage, >3.5 VInjection valve, Commanded on Injection valve, Commanded off3 SecondsContinuous 2 DCY
P0277Cylinder 6 Injector Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current, >16 AInjection valve, Commanded on3 SecondsContinuous 2 DCY

Ignition system

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P0300Random Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0301Cylinder 1 Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0302Cylinder 2 Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0303Cylinder 3 Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0304Cylinder 4 Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0305Cylinder 5 Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0306Cylinder 6 Misfire DetectedCheck the Spark plugs. Check the intake system for leaks (false air). Refer to --> Checking Intake System for Leaks . Check the Fuel pressure regulator and residual pressure. Refer to --> Fuel pressure and residual pressure before high pressure pump , Checking . Check the fuel injectors. Refer to --> Fuel Injectors , Checking . Check the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Emission threshold 1st interval %(MR), >1.3% Emission threshold misfire rate (MR), > 1.3% Catalyst damage misfire rate (MR), > 1.315%Time after engine start, idle-150 RPM Camshaft revolutions, 1 Engine speed range, idle, 6850 RPM Engine torque, > 0 torque (Nm) Fuel cut off, not active1000 Rev. 200 Rev.Continuous 2 DCY Immed.
P0326Knock Sensor 1 Circuit Range/PerformanceCheck the Knock Sensor (KS) 1 G61. Refer to --> Knock Sensor (KS) , Checking .Lower threshold, 0.03 VEngine speed, > 2656 RPM Mass air flow, >0.75 g/rev40 TimesContinuous 2 DCY
P0327Knock Sensor 1 Circuit Low Input (Bank 1)Check the Knock Sensor (KS) 1 G61. Refer to --> Knock Sensor (KS) , Checking .Lower threshold, 0.18 VEngine speed, > 2656 RPM Mass air flow, >0.75 g/rev40 TimesContinuous 2 DCY
P0328Knock Sensor 1 Circuit High Input (Bank 1)Check the Knock Sensor (KS) 1 G61. Refer to --> Knock Sensor (KS) , Checking .Upper threshold, 4.8 VEngine speed, > 2656 RPM Mass air flow, >0.75 g/rev40 TimesContinuous 2 DCY
P0331Knock Sensor 2 Circuit Range/PerformanceCheck the Knock Sensor (KS) 2 G66. Refer to --> Knock Sensor (KS) , Checking .Upper threshold, >1.99 VEngine speed, > 2656 RPM Mass air flow, >0.75 g/rev40 TimesContinuous 2 DCY
P0332Knock Sensor 2 Circuit Low Input (Bank 2)Check the Knock Sensor (KS) 2 G66. Refer to --> Knock Sensor (KS) , Checking .Lower threshold, 0.18 VEngine speed, > 2656 RPM Mass air flow, >0.75 g/rev40 TimesContinuous 2 DCY
P0333Knock Sensor 2 Circuit High Input (Bank 2)Check the Knock Sensor (KS) 2 G66. Refer to --> Knock Sensor (KS) , Checking .Upper threshold, 4.8 VEngine speed, > 2656 RPM Mass air flow, >0.75 g/rev40 TimesContinuous 2 DCY
P0335Crankshaft Position Sensor (A) Circuit-G28 MalfunctionCheck the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .Delta signal voltage > 1 V Internal signal voltage 1.5 V Internal voltage >3.5 VRPM signal- no signalEngine speed, > 32 RPM0.4 SecondsContinuous 2 DCY
P0336Crankshaft Position Sensor (A) Circuit Range/PerformanceCheck the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .RPM signal comparison with phase sensor-not synchronous Counted versus reference teeth->1 Actual time value vs. modeled time value->1.375Engine speed, >32 rpm Engine speed, >416 rpm Engine speed, >480 rpm0.4 Seconds 0.3 Seconds 25 SecondsContinuous 2 DCY
P0340Camshaft Position Sensor A Circuit (Bank 1 or single sensor)Check the Camshaft Position (CMP) Sensor G40. Refer to --> Camshaft Position (CMP) Sensors , Checking .Signal voltage, no altering at 4 revsEngine speed, >416 rpm0.4 SecondsContinuous 2 DCY
P0341Camshaft Position Sensor A Circuit Range/Performance (Bank 1 or single sensor)Check the Camshaft Position (CMP) Sensor G40. Refer to --> Camshaft Position (CMP) Sensors , Checking .Actual time value-1 vs. min time value Adaptive value vs. target value >21°CA Actual time value vs. modeled time value 1-3.5Engine speed, >416 rpm Duty cycle, Commanded off0.1 Seconds 2 Seconds 3 SecondsContinuous 2 DCY
P0345Camshaft Position Sensor (A) CircuitCheck the Camshaft Position (CMP) Sensor G40. Refer to --> Camshaft Position (CMP) Sensors , Checking .Signal voltage, no altering at 4 revsEngine speed, >416 rpm0.4 SecondsContinuous 2 DCY
P0346Camshaft Position Sensor A Circuit Range/PerformanceCheck the Camshaft Position (CMP) Sensor G40. Refer to --> Camshaft Position (CMP) Sensors , Checking .Actual time value-1 vs. min time value Adaptive value vs. target value >21°CA Actual time value vs. modeled time value 1-3.5Engine speed, >416 rpm Duty cycle, Commanded off0.1 Seconds 2 Seconds 3 SecondsContinuous 2 DCY
P0351Ignition Coil A Primary/Secondary CircuitCheck the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Open circuit 0.05 - 0.2 mA Short to ground/B+ >0.04-0.2 mAEngine speed, 512 RPM2 SecondsContinuous 2 DCY
P0352Ignition Coil B Primary/Secondary CircuitCheck the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Signal current, 4.95-8.82 mA Internal fault, changing errorEngine speed, 5000 RPM2 SecondsContinuous 2 DCY
P0353Ignition Coil C Primary/Secondary CircuitCheck the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Signal current, 4.95-8.82 mA Internal fault, changing errorEngine speed, 5000 RPM2 SecondsContinuous 2 DCY
P0354Ignition Coil D Primary/Secondary CircuitCheck the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Signal current, 4.95-8.82 mA Internal fault, changing errorEngine speed, 5000 RPM2 SecondsContinuous 2 DCY
P0355Ignition Coil E Primary/Secondary CircuitCheck the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Signal current, 4.95-8.82 mA Internal fault, changing errorEngine speed, 5000 RPM2 SecondsContinuous 2 DCY
P0356Ignition Coil F Primary/Secondary CircuitCheck the Ignition Coil with Power Output Stage. Refer to --> Ignition Coil with Power Output Stage , Checking .Signal current, 4.95-8.82 mA Internal fault, changing errorEngine speed, 5000 RPM2 SecondsContinuous 2 DCY
P0365Camshaft Position Sensor (B) Circuit (Bank 1) MalfunctionCheck the Camshaft Position (CMP) Sensor 2 G163. Refer to --> Camshaft Position (CMP) Sensors , Checking .Signal voltage, no altering at 4 revsEngine speed, >416 rpm0.4 SecondsContinuous 2 DCY
P0366Camshaft Position Sensor (B) Circuit (Bank 1) Range/PerformanceCheck the Camshaft Position (CMP) Sensor 2 G163. Refer to --> Camshaft Position (CMP) Sensors , Checking .Actual time value-1 vs. min time value Adaptive value vs. target value >21°CA Actual time value vs. modeled time value 1-3.5Engine speed, >416 rpm Duty cycle, Commanded off0.1 Seconds 2 Seconds 3 SecondsContinuous 2 DCY
P0390Camshaft Position Sensor (B) Circuit (Bank 2) MalfunctionCheck the Camshaft Position (CMP) Sensor 4 G301. Refer to --> Camshaft Position (CMP) Sensors , Checking .Signal voltage, no altering at 4 revsEngine speed, >416 rpm0.4 SecondsContinuous 2 DCY
P0391Camshaft Position Sensor (B) Circuit (Bank 2) Range/PerformanceCheck the Camshaft Position (CMP) Sensor 4 G301. Refer to --> Camshaft Position (CMP) Sensors , Checking .Actual time value-1 vs. min time value Adaptive value vs. target value >21°CA Actual time value vs. modeled time value 1-3.5Engine speed, >416 rpm Duty cycle, Commanded off0.1 Seconds 2 Seconds 3 SecondsContinuous 2 DCY

Additional exhaust regulation

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P0421Catalyst System Efficiency Below Threshold (Bank 1)Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking . Check the catalytic converter. Refer to --> Exhaust System Components, Removing and Installing .Amplitude ratio O2S >0.8Modeled exhaust temp, 630 - 900°C ECT, >60°C Engine speed, 1100 - 3500 rpm Delta engine speed, 350 rpm Mass air flow, 0.36 - 1.4 g/rev Delta mass air flow , 2.25 g/rev/s EVAP canister load, low70 Sec.Once/DCY 2 DCY
P0431Catalyst System Efficiency Below Threshold (Bank 2)Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking . Check the catalytic converter. Refer to --> Exhaust System Components, Removing and Installing .Amplitude ratio O2S >0.8Modeled exhaust temp, 630 - 900°C ECT, >60°C Engine speed, 1100 - 3500 rpm Delta engine speed, 350 rpm Mass air flow, 0.36 - 1.4 g/rev Delta mass air flow , 2.25 g/rev/s EVAP canister load, low70 Sec.Once/DCY 2 DCY
P0441Evaporative Emission System Incorrect Purge FlowCheck the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Deviation lambda control 7% Deviation idle control 9.7%Engine speed, Idle Engine speed deviation, 80 RPM ECT, >69.75°C Sub. ECT, >69.75°C IAT, >5°C IAT, at engine start->5°C Altitude, 2500 M25 SecondsOnce/DCY 2 DCY
P0442Evaporative Emission System Leak Detected (Small Leak)Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Time for pressure drop 1.0-1.3 Sec.EVAP purge valve, Closed LDP, Activated Altitude, 2500 M Number of diagnostic attempts, 2 IAT, >5.25°C Delta ambient pressure, 0.3 kPa IAT drop after engine start, 9.75 K Time after engine start, >2101200 Sec. ECT at start, 4.5-35°C Vehicle speed, >6 MPH140 SecondsOnce/DCY 2 DCY
P0444Evaporative Emission System Purge Control Valve Circuit OpenCheck the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Open circuit >0.8 mAEVAP purge valve, Commanded off Engine start, Completed2 SecondsContinuous 2 DCY
P0455Evaporative Emission System Leak Detected (gross leak/no flow)Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Time for pressure drop 0.65-0.8 Sec.EVAP purge valve, Closed LDP, Activated Altitude, 2500 M Number of diagnostic attempts, 2 IAT, >5.25°C Delta ambient pressure, 0.3 kPa IAT drop after engine start, 9.75 K Time after engine start, >2101200 Sec. ECT at start, 4.5-35°C Vehicle speed, >6 MPH140 SecondsOnce/DCY 2 DCY
P0456Evaporative Emission System Leak Detected (very small leak)Check the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Time for pressure drop 4.5 5.5 sec.EVAP purge valve, Closed LDP, Activated Altitude, 2500 M Number of diagnostic attempts, 10 IAT, >5.25°C Delta ambient pressure, 0.2 kPa IAT drop after engine start, 9.75 K Time after engine start, >2101200 Sec. ECT at start, 4.5-35°C Vehicle speed, 680.7 MPH Vehicle acceleration, 2.1 m/s2140 SecondsOnce/DCY 2 DCY
P0458Evaporative Emission System Purge Control Valve Circuit LowCheck the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Signal voltage, 3.2 VEVAP purge valve, Commanded off Engine start, Completed2 SecondsContinuous 2 DCY
P0459Evaporative Emission System Purge Control Valve Circuit HighCheck the Evaporative Emission (EVAP) Canister Purge Regulator Valve N80. Refer to --> Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking . Check the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Signal current, > 1.0 AEVAP purge valve, Commanded on Engine start, Completed2 SecondsContinuous 2 DCY

Speed and idle control

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P0501Vehicle Speed Sensor A Range/PerformanceCheck the vehicle speed signal. Refer to --> Speed Signal, Checking .VSS signal, >184 MPHTime after start, 3 sec.5 SecondsMultiple 2 DCY
P0506Idle Air Control System RPM Lower Than ExpectedCheck the Throttle Valve Control Module J338. Refer to --> Throttle Valve Control Module J338 , Checking .Engine speed deviation, -80 RPMEngine speed, Idle Vehicle speed, 0 MPH Mass air flow, 0.05 g/rev EVAP purge flow, 1 kg/h ECT, 60 - 110°C13 SecondsMultiple 2 DCY
P0507Idle Air Control System RPM Higher Than ExpectedCheck the Throttle Valve Control Module J338. Refer to --> Throttle Valve Control Module J338 , Checking .Engine speed deviation >80 RPMEngine speed, Idle Vehicle speed, 0 MPH Mass air flow, 0.05 g/rev EVAP purge flow, 1 kg/h ECT, 60 - 110°C13 SecondsMultiple 2 DCY
P0562System Voltage LowCheck the Transmission Control Module (TCM) J217 voltage supply. Refer to --> Transmission Control Module (TCM) J217 , Voltage Supply, Checking .Battery voltage to low 78.4 V Battery voltage to low to operate solenoids, but able to maintain the present solenoid state 9 VEngine speed or input speed, > 1400 RPM And position, N or P Or Engine speed, >500 RPM And position, Not (P or N) FET, Enabled0.05 Seconds 2.5 SecondsContinuous 2 DCY
P0563System Voltage HighCheck the Transmission Control Module (TCM) J217 voltage supply. Refer to --> Transmission Control Module (TCM) J217 , Voltage Supply, Checking .Battery voltage to high >16 VFET, Enabled Engine speed, >400 RPM Jump start, No2.5 SecondsContinuous 2 DCY

Control module and output signals

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P0600Serial Communication LinkEliminate malfunction in Can-bus components according to the wiring diagram --> Electrical Wiring Diagrams, Troubleshooting and Component LocationsCAN Bus no message0.51 SecondsContinuous 2 DCY
P0601Internal Control Module Memory Check Sum ErrorReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Internal check sum, incorrect2 SecondsOnce/DCY 2 DCY
P0603Internal Control Module Keep Alive Memory (KAM) ErrorReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .SPI communication-lost1.5 SecondsOnce/DCY 2 DCY
P0604Internal Control Module Random Access Memory (RAM) ErrorReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Write ability check, failed Check, Failed SW verify of EEPROM emulation Negative2 Seconds 0 SecondsOnce/DCY 2 DCY Continuous 2 DCY
P0605Internal Control Module Read Only Memory (ROM) ErrorReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .ROM Check, failed2 SecondsOnce/DCY 2 DCY Continuous 2 DCY
P0606ECM/PCM ProcessorReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .SPI communication lost Signal voltage 4.5 V Signal voltage 0.5 V Boost voltage-30 or 75 V EEPROM check-failed Drive by wire module check-failed Engine torque-out of range Engine operation-out of range CAN bus no message10 ms 2 Seconds 0.2 Seconds 2 Seconds 0.51 SecondsContinuous 2 DCY Once/DCY 2 DCY Continuous 2 DCY
P0607Control Module PerformanceReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .SW functions actuating solenoid valves colliding of 2 substitute functions same priority driven solenoid valves have short circuit to supply or interruption0.02 SecondsContinuous 2 DCY
P060AWatchdogReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Check Failed CAN Feedback, IncorrectCAN Bus, Status OK0 Seconds 0.2 SecondsContinuous 2 DCY
P0613TCM ProcessorReplace the Transmission Control Module (TCM) J217. Refer to --> Transmission Control Module (TCM) J217 , Replacing .Check Failed0 SecondsContinuous 2 DCY
P0614ECM/TCM IncompatibleReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing . Replace the Transmission Control Module (TCM) J217. Refer to --> Transmission Control Module (TCM) J217 , Replacing .CAN level engine does not fit to CAN level transmissionCAN Bus, No error and ready to transmit Ignition, Status on0 SecondsContinuous 2 DCY
P0634PCM/ECM/TCM Internal Temperature Too HighReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing . Replace the Transmission Control Module (TCM) J217. Refer to --> Transmission Control Module (TCM) J217 , Replacing .Maximum TCU temperature dependent on battery voltage V1.5 SecondsContinuous 2 DCY
P0638Throttle Actuator Control Range/Performance - Bank 1Check the Throttle Valve Control Module J338. Refer to --> Throttle Valve Control Module J338 , Checking . Check the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Duty cycle>0.4 sec. at >98 ° Actual TPS ref point 1.5 ° Open to 15°>1.275 sec. Then close to ref. point->1.28 sec. Gradient- 7 °/s Close to 1.99°>1.275 sec. Then open to ref. point >1.28 sec. Gradient 7 °/s TPS 1 signal voltage 0.208 - 0.852 V OR TPS 2 signal voltage 4.158 - 4.802 VEngine start- not active ECT- 6 - 105°C IAT- >5°C Engine speed- 320 rpm Vehicle speed- 1 mph0.45 SecondsContinuous 2 DCY
P0641Sensor Reference Voltage A Circuit/OpenCheck the Transmission Control Module (TCM) J217 voltage supply. Refer to --> Transmission Control Module (TCM) J217 , Voltage Supply, Checking .Sensor supply voltage to high >10 VBattery voltage, >6.51 + 1.3 V0.1 SecondContinuous 2 DCY
P0642Sensor Reference Voltage A Circuit LowCheck the Transmission Control Module (TCM) J217 voltage supply. Refer to --> Transmission Control Module (TCM) J217 , Voltage Supply, Checking .Short to ground 4.898 V Sensor supply voltage to low 6.51 VBattery voltage, >6.51 + 1.3 V2 Seconds 0.1 SecondContinuous 2 DCY
P0643Sensor Reference Voltage A Circuit HighReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Short to battery + >5.102 V2 SecondsContinuous 2 DCY
P0652Sensor Reference Voltage B Circuit LowReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Short to ground 4.898 V2 SecondsContinuous 2 DCY
P0653Sensor Reference Voltage B Circuit HighReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Short to battery + >5.102 V2 SecondsContinuous 2 DCY
P0657Actuator Supply Voltage A Circuit/OpenCheck the Engine Control Module (ECM) Power Supply Relay J271. Refer to --> Engine Control Module (ECM) J623 Voltage Supply, Checking .Signal voltage >0.8 mARelay, commanded on1.5 SecondsContinuous 2 DCY
P0658Actuator Supply Voltage A Circuit LowCheck the Engine Control Module (ECM) Power Supply Relay J271. Refer to --> Engine Control Module (ECM) J623 Voltage Supply, Checking .Signal voltage >3.2 VRelay, commanded off1.5 SecondsContinuous 2 DCY
P0659Supply voltage for engine components to largeCheck the Engine Control Module (ECM) Power Supply Relay J271. Refer to --> Engine Control Module (ECM) J623 Voltage Supply, Checking .Signal current >1 AEngine relay, commanded off1.5 SecondsContinuous 2 DCY
P0686ECM/PCM Power Relay Control Circuit LowCheck the Engine Control Module (ECM) Power Supply Relay J271. Refer to --> Engine Control Module (ECM) J623 Voltage Supply, Checking .Sense voltage >4.0 VMain relay, commanded off0.1 SecondOnce/DCY 2 DCY
P0687ECM/PCM Power Relay Control Circuit HighCheck the Engine Control Module (ECM) Power Supply Relay J271. Refer to --> Engine Control Module (ECM) J623 Voltage Supply, Checking .Sense voltage 6.0 VMain relay, commanded on0.1 SecondContinuous 2 DCY

Transmission O9L

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P0705Transmission Range Sensor Circuit Malfunction (PRNDL Input)Check Multi-Function Transmission Range (TR) Switch F125 --> Multi-Function Transmission Range (TR) Switch F125 , Checking .Sensor supply, > 6.5110 V Status, OK0.1 SecondsContinuous 2 DCY
P0706Transmission Range Sensor A Circuit Range/PerformanceCheck Multi-Function Transmission Range (TR) Switch F125 --> Multi-Function Transmission Range (TR) Switch F125 , Checking .4 bit position code, incorrectSensor supply, > 6.5110 V Status, OK0.1 SecondsContinuous 2 DCY
P0707Transmission Range Sensor Circuit LowCheck Multi-Function Transmission Range (TR) Switch F125 --> Multi-Function Transmission Range (TR) Switch F125 , Checking .Sensor supply, > 6.5110 V Status, OK0.1 SecondsContinuous 2 DCY
P0708Transmission Range Sensor Circuit HighCheck Multi-Function Transmission Range (TR) Switch F125 --> Multi-Function Transmission Range (TR) Switch F125 , Checking .Sensor supply, > 6.5110 V Status, OK0.1 SecondsContinuous 2 DCY
P0710Transmission Fluid Temperature Sensor A CircuitCheck ATF level: --> 37 CONTROLS, HOUSING Check the Transmission Fluid Temperature Sensor G93. Refer to --> Transmission Fluid Temperature Sensor G93 , Checking .Sensor short circuit: U_sensor (+), and U_sensor (-) diagnosis by ASIC1.5 SecondsContinuous 2 DCY
P0711Transmission Fluid Temperature Sensor A Circuit Range/PerformanceCheck ATF level: --> 37 CONTROLS, HOUSING Check the Transmission Fluid Temperature Sensor G93. Refer to --> Transmission Fluid Temperature Sensor G93 , Checking .Discontinual temperature: ATF temperature delta T between 2 measurements, >20°C Sensor stuck: Comparison ATF vs. chip temperature, ATF temp. must follow chip temp. in certain ranges, 25-40°CTemperature fault, no other fault detected Chip temperature, status OK Engine speed or input speed, > 400 RPM Signal status, status, OK1.5 SecondsContinuous 2 DCY
P0712Transmission Fluid Temperature Sensor A Circuit LowCheck ATF level: --> 37 CONTROLS, HOUSING Check the Transmission Fluid Temperature Sensor G93. Refer to --> Transmission Fluid Temperature Sensor G93 , Checking .Circuit low: U_sensor (+), and U_sensor (-) diagnosis by ASIC1.5 SecondsContinuous 2 DCY
P0713Transmission Fluid Temperature Sensor A Circuit HighCheck ATF level: --> 37 CONTROLS, HOUSING Check the Transmission Fluid Temperature Sensor G93. Refer to --> Transmission Fluid Temperature Sensor G93 , Checking .Circuit high: U_sensor (+), and U_sensor (-) diagnosis by ASIC1.5 SecondsContinuous 2 DCY
P0714Transmission Fluid Temperature Sensor A Circuit IntermittentCheck ATF level: --> 37 CONTROLS, HOUSING Check the Transmission Fluid Temperature Sensor G93. Refer to --> Transmission Fluid Temperature Sensor G93 , Checking .Circuit high: U_sensor (+), and U_sensor (-) diagnosis by ASIC1.5 SecondsContinuous 2 DCY
P0716Input/Turbine Speed Sensor A Circuit Range/PerformanceCheck the Transmission Input Speed (RPM) Sensor G182. Refer to --> Transmission Input Speed (RPM) Sensor G182 , Checking .Signal higher or lower than threshold Higher, > + 8000 RPM Lower, 20 RPMHigher: Sensor supply, OK Sensor, no electrical error Lower: Sensor supply, OK Engine speed, >600 RPM Status engine speed, OK Output speed, >500 RPM Status output speed, OK or substitute value Range position, OK or substitute value Sensor, no electrical error Transmission condition, friction-locked Error flag fnabvra_err, not set0.6 SecondsContinuous 2 DCY
P0717Input/Turbine Speed Sensor A Circuit No SignalCheck the Transmission Input Speed (RPM) Sensor G182. Refer to --> Transmission Input Speed (RPM) Sensor G182 , Checking .Hardware detectionSensor supply, OK0.6 SecondsContinuous 2 DCY
P0721Output Speed Sensor Circuit Range/PerformanceCheck the Transmission Output Speed (RPM) Sensor G195. Refer to --> Transmission Output Speed (RPM) Sensor G195 , Checking .Signal> threshold, > 10000 RPM Difference between last and actual value >threshold, -1000 RPM Difference to wheel speeds, > 500 RPM and input speed, > 200 RPMSensor supply, OK Sensor, no electrical error Transmission condition, friction-locked Input speed sensor, OK Difference between output speed and input speed, > 200 RPM Transmission condition, friction-locked backwards or forwards Shift flag, = 0 (no shift) Input speed, OK Sensor supply, OK Wheel speeds, OK0.8 Seconds 1 SecondContinuous 2 DCY
P0722Output Speed Sensor Circuit No SignalCheck the Transmission Output Speed (RPM) Sensor G195. Refer to --> Transmission Output Speed (RPM) Sensor G195 , Checking .Hardware detectionSensor supply, OK0.6 SecondsContinuous 2 DCY
P0727Engine Speed Input Circuit No SignalCheck the wiring connection Between Engine Control Module (ECM) J623 and the Transmission Control Module (TCM) J217. Check the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking .CAN message signal error flag, =1Ignition, on CAN Bus, OK DME CAN connection, OK1 SecondContinuous Immediate
P0741Torque Converter Clutch Circuit Performance or Stuck OffCheck the Engine Speed (RPM) Sensor G28. Refer to --> Engine Speed (RPM) Sensor G28 , Checking . Check the Transmission Input Speed (RPM) Sensor G182. Refer to --> Transmission Input Speed (RPM) Sensor G182 , Checking . Check the Automatic Transmission Pressure Regulating Valve 6 N371. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .Rate of (setting of nominal value) - actual value, > 50 RPMStatus of clutch, closed or closed loop control15 SecondsContinuous 2 DCY
P0746Pressure Control Solenoid 'A Performance or Stuck OffCheck the Automatic Transmission Pressure Regulating Valve 1 N215. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P0747Pressure Control Solenoid 'A Stuck OnCheck the Automatic Transmission Pressure Regulating Valve 1 N215. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P0748Pressure Control Solenoid 'A ElectricalCheck the Automatic Transmission Pressure Regulating Valve 1 N215. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .Current higher or lower than threshold, > 220 mA EDS output voltage at short to ground or open circuit ~ 0,5 V smaller than EDS supply voltage Static leakage current flowOff operation mode0.05 SecondsContinuous 2 DCY
P0751Shift Solenoid A Performance or Stuck OffCheck the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .If PWM = 0%, diagnosis by ASIC if 0% = PWM , 7.6% voltage return lead (low), 0.75 V if 7.6% = PWM , 92.4% voltage return lead (high), 0.75 V if 7.6% = PWM , 92.4% voltage return lead (low), 0.75 VHigh side FET voltage drop, = 1 V High side FET, enabled Low side FET, enabled0.05 SecondsContinuous 2 DCY
P0752Shift Solenoid Stuck OnCheck the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .If PWM = 100%, diagnosis by ASIC if 7.6% = PWM = 100% voltage return lead (high), >0.3 VHigh side FET voltage drop, = 1 V High side FET, enabled Low side FET, enabled0.05 SecondsContinuous 2 DCY
P0754Shift Solenoid "A" IntermittentCheck the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .If PWM = 0%, diagnosis by ASIC if 0% = PWM , 7.6% voltage return lead (low), 0.75 V if 7.6% = PWM , 92.4% voltage return lead (high), 0.75 V if 7.6% = PWM , 92.4% voltage return lead (low), 0.75 VHigh side FET voltage drop, = 1 V High side FET, enabled Low side FET, enabled0.05 SecondsContinuous 2 DCY
P0776Pressure Control Solenoid B Performance or Stuck OffCheck ATF level: --> 37 CONTROLS, HOUSING Check the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P0777Pressure Control Solenoid B Stuck OnCheck ATF level: --> 37 CONTROLS, HOUSING Check the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P0778Pressure Control Solenoid B ElectricalCheck ATF level: --> 37 CONTROLS, HOUSING Check the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .Current higher or lower than threshold, 730 mA EDS output voltage at short to ground or open circuit ~ 0,5 V smaller than EDS supply voltage Static leakage current flowOff operation mode0.05 SecondsContinuous 2 DCY
P0796Pressure Control Solenoid C Performance or Stuck OffCheck the Automatic Transmission Pressure Regulating Valve 3 N217. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P0797Pressure Control Solenoid C Stuck OnCheck the Automatic Transmission Pressure Regulating Valve 3 N217. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P0798Pressure Control Solenoid C ElectricalCheck the Automatic Transmission Pressure Regulating Valve 3 N217. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .Current higher or lower than threshold, >220 mA EDS output voltage at short to ground or open circuit ~ 0,5 V smaller than EDS supply voltage Static leakage current flowOff operation mode0.05 SecondsContinuous 2 DCY
P0889TCM Power Relay Sense Circuit Range/PerformanceCheck the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking . Check the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .FET drive, not possibleFiltered battery voltage, >6.75 V High side and low side FET, enabled Status counter initialization, 0 or 10.03 SecondsContinuous 2 DCY
P0890TCM Power Relay Sense Circuit LowCheck the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking . Check the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .Solenoid power supply voltage, 1.4 V Drop voltage over high side FET, > 1 VFiltered battery voltage, >6.75 V High side and low side FET, enabled Status counter initialization, 0 or 10.03 SecondsContinuous 2 DCY
P0891TCM Power Relay Sense Circuit HighCheck the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking . Check the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .Hardware detectionFiltered battery voltage, >6.75 V High side and low side FET, enabled Status counter initialization, 0 or 10.03 SecondsContinuous 2 DCY
P0892TCM Power Relay Sense Circuit IntermittentCheck the Automatic Transmission Pressure Regulating Valves. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking . Check the Solenoid Valve 1 N88. Refer to --> Solenoid Valve 1 N88 , Checking .Hardware detectionFiltered battery voltage, >6.75 V High side and low side FET, enabled Status counter initialization, 0 or 10.03 SecondsContinuous 2 DCY

Fuel and Air Ratios, Control Module

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P12A1Fuel Rail Pressure Sensor Inappropriately HighCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Deviation fuel rail pressure control -0.015 g And Deviation lambda control -25%Fuel cut off, Not active Engine speed, 640-3480 rpm Time after engine start, >250 sec. High pressure pump set point, 0.005-0.05 g Lambda control, Closed loop EVAP canister load, 25%5 SecondsContinuous 2 DCY
P12A2Fuel Rail Pressure Sensor Inappropriately HighCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Deviation fuel rail pressure control -0.01 g And Deviation lambda control >30%Fuel cut off, Not active Engine speed, 640-3480 rpm Time after engine start, >250 sec. High pressure pump set point, 0.005-0.05 g Lambda control, Closed loop EVAP canister load, 25%5 SecondsContinuous 2 DCY
P12A4Fuel Rail Pump Control Valve Stuck ClosedCheck the Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Deviation fuel rail pressure control -0.025 g And Deviation lambda control -1010%Fuel cut off, Not active Engine speed, 640-3480 rpm Time after engine start, >250 sec. High pressure pump set point, 0.005-0.05 g Lambda control, Closed loop EVAP canister load, 25%5 SecondsContinuous 2 DCY
DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P1702Impossible combination of substitute functions or not allowed actuating of valvesReplace the Transmission Control Module (TCM) J217. Refer to --> Transmission Control Module (TCM) J217 , Replacing .SW functions: actuating solenoid valves colliding with 2 substitute functions with same priority as driven solenoid valves that have short circuit to supply or interruption0.02 SecondsContinuous 2 DCY

Fuel and air mixture, additional emissions regulations

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P2004Intake Manifold Runner Control Stuck Open (Bank 1)Check the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal voltage 2.65 VTime after engine start, 15 sec. Duty cycle, Commanded open8 SecondsContinuous 2 DCY
P2005Intake manifold flap for air stream regulation, (Bank 2) Stuck openCheck the Intake Manifold Runner Position Sensor 2 G512. Refer to --> Intake Manifold Runner Position Sensor 2 G512 , Checking .Signal voltage 2.65 VTime after engine start, 15 sec. Duty cycle, Commanded open8 SecondsContinuous 2 DCY
P2006Intake manifold flap for air stream regulation, bank 1 Stuck closedCheck the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal voltage > 4 VTime after engine start, 15 sec. Duty cycle, Commanded closed8 SecondsContinuous 2 DCY
P2007Intake manifold flap for air stream regulation, bank 2 Stuck closedCheck the Intake Manifold Runner Position Sensor 2 G512. Refer to --> Intake Manifold Runner Position Sensor 2 G512 , Checking .Signal voltage > 4 VTime after engine start, 15 sec. Duty cycle, Commanded closed8 SecondsContinuous 2 DCY
P2008Intake Manifold Runner Control Circuit/Open Bank 1Check the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal current >0.8 mADuty cycle, Commanded On2 SecondsContinuous 2 DCY
P2009Intake Manifold Runner Bank 1 Short to groundCheck the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal voltage >2 VDuty cycle, Commanded Off2 SecondsContinuous 2 DCY
P2010Intake Manifold Runner Bank 1 Short to Battery +Check the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal current >1 ADuty cycle, Commanded On2 SecondsContinuous 2 DCY
P2014Intake Manifold Runner Position Sensor/Switch Circuit Bank 1Check the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal voltage, 0.2 V2 SecondsContinuous 2 DCY
P2015Intake Manifold Runner Position Sensor/Switch Circuit Range/Performance Bank 1Check the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal voltage 4.5 - 4.8 V 0.5 - 0.2 VECT, >6°C IAT, >6°C0.5 SecondsContinuous 3 DCY
P2017Intake Manifold Runner Position Sensor Short to B+Check the Intake Manifold Runner Position Sensor G336. Refer to --> Intake Manifold Runner Position Sensor G336 , Checking .Signal voltage >4.8 V2 SecondsContinuous 2 DCY
P2019Sensor for intake manifold flap position 2 Electrical MalfunctionCheck the Intake Manifold Runner Position Sensor 2 G512. Refer to --> Intake Manifold Runner Position Sensor 2 G512 , Checking .Signal voltage, 0.2 V2 SecondsContinuous 2 DCY
P2020Sensor for intake manifold flap position 2 Range/PerformanceCheck the Intake Manifold Runner Position Sensor 2 G512. Refer to --> Intake Manifold Runner Position Sensor 2 G512 , Checking .Signal voltage 4.5 - 4.8 V 0.5 - 0.2 VECT, >6°C IAT, >6°C0.5 SecondsContinuous 3 DCY
P2022Intake Manifold Runner Position Sensor 2 Short to Battery +Check the Intake Manifold Runner Position Sensor 2 G512. Refer to --> Intake Manifold Runner Position Sensor 2 G512 , Checking .Signal voltage >4.8 V2 SecondsContinuous 2 DCY
P2088A Camshaft Position Actuator Control Circuit Low (Bank 1)Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking .Signal voltage, 3 VCamshaft valve, commanded off2 SecondsContinuous 2 DCY
P2089A Camshaft Position Actuator Control Circuit High (Bank 1)Check the Camshaft Adjustment Valve 1 N205. Refer to --> Camshaft Adjustment Valve , Checking .Signal current, >1 ACamshaft valve, commanded on2 SecondsContinuous 2 DCY
P2090"B" Camshaft Position Actuator Control Circuit Low (Bank 1)Check the Camshaft Adjustment Valve 1 (exhaust) N318. Refer to --> Camshaft Adjustment Valve , Checking .Short to ground 3 VCamshaft valve, commanded off2 SecondsContinuous 2 DCY
P2091"B" Camshaft Position Actuator Control Circuit High (Bank 1)Check the Camshaft Adjustment Valve 1 (exhaust) N318. Refer to --> Camshaft Adjustment Valve , Checking .Short to battery + >1 ACamshaft valve, commanded on2 SecondsContinuous 2 DCY
P2092A Camshaft Position Actuator Control Circuit Low (Bank 2)Check the Camshaft Adjustment Valve 2 N208. Refer to --> Camshaft Adjustment Valve , Checking .Signal voltage- 3 VCamshaft valve, commanded off2 SecondsContinuous 2 DCY
P2093A Camshaft Position Actuator Control Circuit High (Bank 2)Check the Camshaft Adjustment Valve 2 N208. Refer to --> Camshaft Adjustment Valve , Checking .Signal current > 1 AmpCamshaft valve, commanded on2 SecondsContinuous 2 DCY
P2094"B" Camshaft Position Actuator Control Circuit Low (Bank 2)Check the Camshaft Adjustment Valve 2 (exhaust) N319. Refer to --> Camshaft Adjustment Valve , Checking .Short to ground 3 VCamshaft valve, commanded off2 SecondsContinuous 2 DCY
P2095"B" Camshaft Position Actuator Control Circuit High (Bank 2)Check the Camshaft Adjustment Valve 2 (exhaust) N319. Refer to --> Camshaft Adjustment Valve , Checking .Short to battery + >1 ACamshaft valve, commanded on2 SecondsContinuous 2 DCY
P2096Post Catalyst Fuel Trim System Too Lean Bank 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Integral part of lambda control post cat, >10%Lambda control, Closed loop Lambda control post cat, Closed loop Engine speed, 640-4512 rpm Engine load, 15 - 70% Modeled catalyst temp, >400°C -Set value, 0.96 - 1.04 Delta engine speed, 7500 rpm/s Delta mass air flow, 15 g/rev/s Accelerator PP value, 1000%/s Mass air flow, 9.4-528 kg/h120 SecondsContinuous 2 DCY
P2097Post Catalyst Fuel Trim System Too Rich Bank 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Integral part of lambda control post cat, -10%Lambda control, Closed loop Lambda control post cat, Closed loop Engine speed, 640-4512 rpm Engine load, 15 - 70% Modeled catalyst temp, >400°C -set value, 0.96 - 1.04 Delta engine speed, 7500 rpm/s Delta mass air flow, 15 g/rev/s Accelerator PP value, 1000%/s Mass air flow, 9.4-528 kg/h120 SecondsContinuous 2 DCY
P2098Bank 2, oxygen sensor correction behind cat Lean control limit exceededCheck the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Integral part of lambda control post cat, >10%Lambda control, Closed loop Lambda control post cat, Closed loop Engine speed, 640-4512 rpm Engine load, 15 - 70% Modeled catalyst temp, >400°C -set value, 0.96 - 1.04 Delta engine speed, 7500 rpm/s Delta mass air flow, 15 g/rev/s Accelerator PP value, 1000%/s Mass air flow, 9.4-528 kg/h120 SecondsContinuous 2 DCY
P2099Bank 2, oxygen sensor correction behind cat Rich control limit exceededCheck the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking . Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Integral part of lambda control post cat, -10%Lambda control, Closed loop Lambda control post cat, Closed loop Engine speed, 640-4512 rpm Engine load, 15 - 70% Modeled catalyst temp, >400°C -set value, 0.96 - 1.04 Delta engine speed, 7500 rpm/s Delta mass air flow, 15 g/rev/s Accelerator PP value, 1000%/s Mass air flow, 9.4-528 kg/h120 SecondsContinuous 2 DCY

Fuel and air ratio

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P2101Throttle Actuator Control Motor Circuit Range/PerformanceCheck the Throttle Valve Control Module J338. Refer to --> Throttle Valve Control Module J338 , Checking .Duty cycle->0.4 sec. at >98% And Actual TPS-ref. point->1.5° Or Actual TPS-calc. value->0.4 at >8 °Engine start, Not active0.45 SecondsContinuous 2 DCY
P2106Throttle Actuator Control System - Forced Limited PowerCheck the Throttle Valve Control Module J338. Refer to --> Throttle Valve Control Module J338 , Checking .ECM power stage, FailureEngine start, Completed0.45 SecondsContinuous 2 DCY
P2122Throttle/Pedal Position Sensor/Switch D Circuit Low InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage 0.4 V0.2 Seconds.Continuous 2 DCY
P2123Throttle/Pedal Position Sensor/Switch D Circuit High InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage >4.84 V0.2 Seconds.Continuous 2 DCY
P2127Throttle/Pedal Position Sensor/Switch E Circuit Low InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage 0.2 V0.2 Seconds.Continuous 2 DCY
P2128Throttle/Pedal Position Sensor/Switch E Circuit High InputCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Signal voltage >2.8 V
P2138Throttle/Pedal Position Sensor/Switch D/E Voltage CorrelationCheck the Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185. Refer to --> Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking .Delta signal voltage sensor 1 vs. sensor 2 >0.244 V0.35 Seconds.Continuous 2 DCY
P2147Fuel Injector Group A Supply Voltage Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current >12 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P2148Fuel Injector Group A Supply Voltage Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current >33 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P2150Fuel Injector Group B Supply Voltage Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current >12 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P2151Fuel Injector Group "B" Supply Voltage Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current >33 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P2153Fuel Injector Group "C" Supply Voltage Circuit LowCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current >12 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P2154Fuel Injector Group "C" Supply Voltage Circuit HighCheck the fuel injectors. Refer to --> Fuel Injectors , Checking .Signal current >33 AInjection valve, Commanded on3 SecondsContinuous 2 DCY
P2181Cooling System PerformanceCheck the Engine Coolant Temperature (ECT) Sensor G62. Refer to --> Engine Coolant Temperature (ECT) Sensor G62 , Checking . Check Coolant Pump V50 --> 19 - ENGINE - COOLING SYSTEM Check Coolant Thermostat. --> 19 - ENGINE - COOLING SYSTEM .ECT 75°C Mass air integral 3.524.0 KgECT at start, -757°C Accum. fuel shut off, 120 Sec. Delta ambient pressure, 1.5 kPa Vehicle speed, 19 - 75 mph Mass air flow, 50200 kg/h500 SecondsOnce/DCY 2 DCY
P2195O2 Sensor Signal Biased/Stuck Lean - Bank 1, Sensor 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Lambda value >1.1Lambda control-Closed loop Lambda control post cat, Closed loop ECT, >60°C Engine speed, >992 rpm Engine speed deviation, 150 rev. Engine load, 30 - 300 kg/h Delta engine load, 0.15 g/rev Lambda deviation, 3% Integrated mass air flow, 150 g Modeled exhaust temp, 500 - 750°C O2S signal rear, >0.852 V Deviation lambda control, >35%100 seconds.Continuous 2 DCY
P2196O2 Sensor Signal Biased/Stuck Rich - Bank 1, Sensor 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Lambda value 0.9Lambda control-Closed loop Lambda control post cat, Closed loop ECT, >60°C Engine speed, >992 rpm Engine speed deviation, 150 rev. Engine load, 30 - 300 kg/h Delta engine load, 0.15 g/rev Lambda deviation, 3% Integrated mass air flow, 150 g Modeled exhaust temp, 500 - 750°C O2S signal rear, >0.049 V Deviation lambda control, >35%100 seconds.Continuous 2 DCY
P2197O2 Sensor Signal Stuck Lean Bank 2 Sensor 1Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Lambda value >1.1Lambda control-Closed loop Lambda control post cat, Closed loop ECT, >60°C Engine speed, >992 rpm Engine speed deviation, 150 rev. Engine load, 30 - 300 kg/h Delta engine load, 0.15 g/rev Lambda deviation, 3% Integrated mass air flow, 150 g Modeled exhaust temp, 500 - 750°C O2S signal rear, >0.852 V Deviation lambda control, >35%100 seconds.Continuous 2 DCY
P2198O2 Sensor Signal Stuck Rich Bank 2 Sensor 1Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Lambda value 0.9Lambda control-Closed loop Lambda control post cat, Closed loop ECT, >60°C Engine speed, >992 rpm Engine speed deviation, 150 rev. Engine load, 30 - 300 kg/h Delta engine load, 0.15 g/rev Lambda deviation, 3% Integrated mass air flow, 150 g Modeled exhaust temp, 500 - 750°C O2S signal rear, >0.049 V Deviation lambda control, >35%100 seconds.Continuous 2 DCY
P2237O2 Sensor Positive Current Control Circuit/Open - Bank 1, Sensor 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Signal activity check-failedO2S front-no other faults65 SecondsContinuous 2 DCY
P2240O2 Sensor Positive Current Control Circuit/Open - Bank 2, Sensor 1Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Signal activity check-failedO2S front-no other faults65 SecondsContinuous 2 DCY
P2243O2 Sensor Reference Voltage Circuit Open - Bank 1, Sensor 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Functional check, heater- failed And Intrusive check, heater-failed130 SecondsContinuous 2 DCY
P2247O2 Sensor Reference Voltage Circuit (Bank 2 Sensor 1) OpenCheck the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Functional check, heater- failed And Intrusive check, heater-failed130 SecondsContinuous 2 DCY
P2251O2 Sensor Negative Current Control Circuit (Bank 1 Sensor 1) OpenCheck the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Functional check, heater- failed And Intrusive check, heater-failed162 SecondsContinuous 2 DCY
P2254O2 Sensor Negative Current Control Circuit/Open (Bank 2 Sensor 1)Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .Functional check, heater- failed And Intrusive check, heater-failed162 SecondsContinuous 2 DCY
P2270O2 Sensor Signal Stuck Lean Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage-0.718 V While stet-value 0.85Fault code detected, P2096 or P2097 or P2098 or P2099 O2S rear, Ready Exhaust mass air integral, >0.1 kg25 SecondsOnce/DCY 2 DCY
P2271O2 Sensor Signal Stuck Rich Bank 1 Sensor 2Check the Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) G130. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage->0.298 V While set-value 1.15Fault code detected, P2096 or P2097 or P2098 or P2099 O2S rear, Ready Exhaust mass air integral, >0.1 kg25 SecondsOnce/DCY 2 DCY
P2272O2 Sensor Signal Stuck Lean Bank 2 Sensor 2Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage-0.718 V While stet-value 0.85Fault code detected, P2096 or P2097 or P2098 or P2099 O2S rear, Ready Exhaust mass air integral, >0.1 kg25 SecondsOnce/DCY 2 DCY
P2273O2 Sensor Signal Stuck Rich Bank 2 Sensor 2Check the Oxygen Sensor (O2S) 2 Behind Three Way Catalytic Converter (TWC) G131. Refer to --> Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking .Signal voltage->0.298 V While set-value 1.15Fault code detected, P2096 or P2097 or P2098 or P2099 O2S rear, Ready Exhaust mass air integral, >0.1 kg25 SecondsOnce/DCY 2 DCY
P2294Fuel Pressure Regulator 2 Control CircuitCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal current 0.8 mATime after engine start, 100 - 400 sec.2 SecondsContinuous 2 DCY
P2295Fuel Pressure Regulator 2 Control Circuit LowCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal voltage 3.2 VTime after engine start, 100 - 400 sec.2 SecondsContinuous 2 DCY
P2296Fuel Pressure Regulator 2 Control Circuit HighCheck the Fuel Pressure Sensor G247. Refer to --> Fuel Pressure Sensor G247 , Checking .Signal current >8 AmpsTime after engine start, 100 - 400 sec.2 SecondsContinuous 2 DCY

Additional emission regulations

DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P2400Evaporative Emission System Leak Detection Pump Control Circuit/OpenCheck the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Open circuit >0.8 mALDP, Commanded on Engine speed >416 RPM2 SecondsContinuous 2 DCY
P2401Evaporative Emission System Leak Detection Pump Control Circuit LowCheck the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Short to ground >2 VLDP, Commanded off Engine speed >416 RPM2 SecondsContinuous 2 DCY
P2402Evaporative Emission System Leak Detection Pump Control Circuit HighCheck the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Signal current > 1 ALDP, Commanded on Engine speed >416 RPM2 SecondsContinuous 2 DCY
P2403Evaporative Emission System Leak Detection Pump Sense Circuit/OpenCheck the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .Low signal voltage > 1 time Sec.LDP Commanded on EVAP purge valve, Closed LDP, Activated Altitude, 2500 M Number of diagnostic attempts, 2 IAT, >5.25°C Delta ambient pressure, 0.3 kPa IAT drop after engine start, 9.75 K Time after engine start, >2101200 Sec. ECT at start, 4.5-35°C Vehicle speed, >6 MPH10 SecondsOnce/DCY 2 DCY
P2404Evaporative Emission System Leak Detection Pump Sense Range/PerformanceCheck the Leak Detection Pump (LDP) V144. Refer to --> Leak Detection Pump (LDP) V144 , Checking Check the Evaporative Emission (EVAP) Canister System for proper seal. Refer to --> EVAP System, Checking for Leaks .High signal voltage > 0.36 time Sec.LDP Commanded on EVAP purge valve, Closed LDP, Activated Altitude, 2500 M Number of diagnostic attempts, 2 IAT, >5.25°C Delta ambient pressure, 0.3 kPa IAT drop after engine start, 9.75 K Time after engine start, >2101200 Sec. ECT at start, 4.5-35°C Vehicle speed, >6 MPH10 SecondsOnce/DCY 2 DCY
P2414O2 Sensor Exhaust Sample Error Bank 1, Sensor 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .O2S signal front >3.1 VLambda control, Active Engine torque, Positive Engine speed, No idle25 SecondsContinuous 2 DCY
P2415O2 Sensor Exhaust Sample Error Bank 2, Sensor 1Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .O2S signal front >3.1 VLambda control, Active Engine torque, Positive Engine speed, No idle25 SecondsContinuous 2 DCY
P2539Low Pressure Fuel System Sensor CircuitCheck Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Signal voltage > 4.8 V2 SecondsContinuous 2 DCY
P2540Low Pressure Fuel System Sensor Circuit Range/PerformanceCheck Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Actual pressure 0.08 or >0.8 MpaEngine speed, 500-6000 rpm Time after engine start, >30 sec.5 SecondsContinuous 2 DCY
P2541Low Pressure Fuel System Sensor Circuit LowCheck Low Fuel Pressure Sensor G410. Refer to --> Low Fuel Pressure Sensor G410 , Checking .Signal voltage 0.2 V5 SecondsContinuous 2 DCY
P2626O2 Sensor Pumping Current Trim Circuit/Open Bank 1 Sensor 1Check the Heated Oxygen Sensor (HO2S) G39. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .O2S signal front >4.7 VFuel cut off, >2 sec. Modeled exhaust gas temp, >380°C4 SecondsContinuous 2 DCY
P2629O2 Sensor Pumping Current Trim Circuit/Open Bank 2 Sensor 1Check the Heated Oxygen Sensor (HO2S) 2 G108. Refer to --> Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking .O2S signal front >4.7 VFuel cut off, >2 sec. Modeled exhaust gas temp, >380°C4 SecondsContinuous 2 DCY
DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P2637Torque management Feedback Signal ACheck the CAN-Bus terminal resistance, Transmission Control Module (TCM) J217 to Engine Control Module (ECM) J623. Refer to --> Terminal Resistance for Can-Bus, Checking .CAN message signal error flag, = 1Ignition, on CAN Bus, OK DME CAN connection, OK0.5 SecondsContinuous 2 DCY
P2714Pressure Control Solenoid D Performance or Stuck offCheck the Automatic Transmission Pressure Regulating Valve 4 N218. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P2715Pressure Control Solenoid D Stuck OnCheck the Automatic Transmission Pressure Regulating Valve 4 N218. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P2716Pressure Control Solenoid D ElectricalCheck the Automatic Transmission Pressure Regulating Valve 4 N218. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .Current higher or lower than threshold, 730 mA EDS output voltage at short to ground or open circuit ~ 0,5 V smaller than EDS supply voltage Static leakage current flowOff operation mode0.05 SecondsContinuous 2 DCY
P2723Pressure Control Solenoid E Performance or Stuck offCheck the Automatic Transmission Pressure Regulating Valve 5 N233. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P2725Pressure Control Solenoid "E" ElectricalCheck the Automatic Transmission Pressure Regulating Valve 5 N233. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .Current higher or lower than threshold, 730 mA EDS output voltage at short to ground or open circuit ~ 0,5 V smaller than EDS supply voltage Static leakage current flowOff operation mode0.05 SecondsContinuous 2 DCY
P2732Pressure Control Solenoid F Performance or Stuck offCheck the Automatic Transmission Pressure Regulating Valve 6 N371. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P2733Pressure Control Solenoid F Stuck OnCheck the Automatic Transmission Pressure Regulating Valve 6 N371. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
P2734Pressure Control Solenoid "F" ElectricalCheck the Automatic Transmission Pressure Regulating Valve 6 N371. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .EDS output voltage at short to ground or open circuit ~ 0,5 V smaller than EDS supply voltage Static leakage current flowOff operation mode0.05 SecondsContinuous 2 DCY
P2735Pressure Control Solenoid "F" IntermittentCheck the Automatic Transmission Pressure Regulating Valve 6 N371. Refer to --> Automatic Transmission Pressure Regulating Valves , Checking .PWM hardware detection, 0 or 100%Low side and high side FET, activated Power supply, > 8.7 V Voltage drop at FET, = 1 V Solenoid supply, > 9 V0.05 SecondsContinuous 2 DCY
DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
P3081Engine Temperature Too LowCheck the Engine Coolant Temperature (ECT) Sensor G62. Refer to --> Engine Coolant Temperature (ECT) Sensor G62 , Checking .Step 1 modeled ECT >40°C And ECT40°CStep 1 passed2 SecondsContinuous 2 DCY
DTCError MessageDiagnostic ProcedureMalfunction Criteria and Threshold ValueSecondary Parameters with Enable ConditionsMonitoring Time LengthFrequency of checks, MIL Illum
U0001High Speed CAN Communication BusCheck the CAN-Bus terminal resistance. Refer to --> Terminal Resistance for Can-Bus, Checking .CAN message, No feedback CAN level, IncorrectBattery voltage, >9 V Delay after ignition on, 0.5 Sec. Ignition status, On0.3 Seconds 0.06 SecondsContinuous Immed.
U0100Lost Communication With ECM/PCM ACheck the CAN-Bus terminal resistance. Refer to --> Terminal Resistance for Can-Bus, Checking .No message received from DME, TimeoutCAN Bus, No error and ready to transmit Delay after ignition on, 0.53 Sec. Battery voltage, >9 V0.5 SecondsContinuous 2 DCY
U0101Lost Communication with TCMCAN-Bus terminal resistance, Transmission Control Module (TCM) J217 to Engine Control Module (ECM) J623. Refer to --> Terminal Resistance for Can-Bus, Checking .CAN message, No message0.51 SecondsContinuous 2 DCY
U0302Software Incompatibility with Transmission Control ModuleReplace the Transmission Control Module (TCM) J217. Refer to --> Transmission Control Module (TCM) J217 , Replacing .AT vehicle ECM coded as MT vehicle5 sec.Continuous 2 DCY
U0401Invalid Data Received From ECM/PCMReplace the Engine Control Module (ECM) J623. Refer to --> Engine Control Module (ECM) J623 , Removing and Installing .Invalid data.CAN Bus, No error and ready to transmit Delay after ignition on, 0.53 Sec. Battery voltage, >9 V0.5 SecondsContinuous 2 DCY
U0402Invalid Data Received from Transmission Control ModuleCAN-Bus terminal resistance, Transmission Control Module (TCM) J217 to Engine Control Module (ECM) J623. Refer to --> Terminal Resistance for Can-Bus, Checking .AT vehicle ECM coded as MT vehicle CAN message Implausible message5 Sec.Continuous 2 DCY

See also:
• 20 - FUEL SUPPLY SYSTEM
• 24 - FUEL INJECTION SYSTEM
• 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL
• 72 - SEAT - FRAMES
• 72 - SEAT - FRAMES
• 66 EXTERIOR EQUIPMENT
• 66 - EXTERIOR EQUIPMENT
• 46 - BRAKES - MECHANICAL COMPONENTS
• 26 - EXHAUST SYSTEM, EMISSION CONTROLS
• 38 GEARS, CONTROL
• 38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS
• Safety Precautions
• Rules for Cleanliness
• Fuel System, Bleeding
• Fuel Pump Delivery Quantity, Checking
• Fuel Pump Electrical, Checking
• EVAP System, Leak Detection
• EVAP System, Checking for Leaks
• Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 , Checking
• Leak Detection Pump (LDP) V144 , Checking
• Diagnostic Mode 04: Reset/delete Diagnostic Data
• Readiness Code
• Diagnostic Mode 03: Interrogating Fault Memory
• Engine Control Module (ECM) J623 , Removing and Installing
• Throttle Position (TP) Sensor G79/Accelerator Pedal Position Sensor 2 G185 , Checking
• Technical Data
• Oxygen Sensor (O2S) Heaters before Catalytic Converter, Checking
• Oxygen Sensor (O2S) 1 (behind Three Way Catalytic Converter (TWC) Heater , Checking
• Throttle Valve Control Module J338 , Checking
• Engine Speed (RPM) Sensor G28 , Checking
• Intake Air Temperature (IAT) Sensor G42 , Checking
• Engine Coolant Temperature (ECT) Sensor G62 , Checking
• Fuel pressure and residual pressure before high pressure pump , Checking
• Fuel Pressure Sensor G247 , Checking
• Low Fuel Pressure Sensor G410 , Checking
• Fuel Metering Valve N290 , Checking
• Intake Manifold Tuning (IMT) Valve Position Sensor G513 , Checking
• Intake Manifold Runner Position Sensor 2 G512 , Checking
• Intake Manifold Runner Control (IMRC) Valve N316 , Checking
• Intake Manifold Runner Position Sensor G336 , Checking
• Fuel Injectors , Checking
• Checking Intake System for Leaks
• TESTING IF DISPLAY IS APPROX. - 40.0°C
• TESTING IF DISPLAY APPROX. 140.0°C
• Heated Oxygen Sensor (HO2S) before Catalytic Converter, Checking
• Oxygen Sensors (O2S) Behind Three Way Catalytic Converter (TWC) behind Catalytic Converter, Checking
• Function
• Engine Control Module (ECM) J623 Voltage Supply, Checking
• Speed Signal, Checking
• Brake Light Switch F/Brake Pedal Switch F47 , Checking Signal
• Terminal Resistance for Can-Bus, Checking
• Checking voltage supply
• Checking wiring
• Diagnostic Mode 06: Checking Test Results of Components that are not Continuously Monitored
• Test Data, Spark Plugs
• General Information
• Camshaft Position (CMP) Sensors , Checking
• Camshaft Adjustment Valve , Checking
• Knock Sensor (KS) , Checking
• Ignition Coil with Power Output Stage , Checking
• Multi-Function Transmission Range (TR) Switch F125 , Checking
• Transmission Input Speed (RPM) Sensor G182 , Checking
• Transmission Output Speed (RPM) Sensor G195 , Checking
• Transmission Fluid Temperature Sensor G93 , Checking
• Solenoid Valve 1 N88 , Checking
• Automatic Transmission Pressure Regulating Valves , Checking
• Transmission Control Module (TCM) J217 , Voltage Supply, Checking
• Generic Scan Tool Manual Contents
• OBD Systems
• Malfunction Indicator Lamp Illumination
• CAN Data Link
• Electronic Power Control Warning Lamp
• Diagnostic Modes Description
• Diagnostic Mode 01: Obtain Data
• Diagnostic Mode 02: Obtain Operating Conditions
• Diagnostic Mode 07: Check Test Results of Components that are Continuously Monitored
• Diagnostic Mode 08: Tank Leak Test
• Diagnostic Mode 09: Vehicle Information
• Test-ID 01 ($01): Oxygen Sensor Monitor Bank 1 - Sensor 1
• Test-ID 02 ($02): Oxygen Sensor Monitor Bank 1- Sensor 2
• Test-ID 05 ($05): Oxygen Sensor Monitor Bank 2 - Sensor 1
• Test-ID 06 ($06): Oxygen Sensor Monitor Bank 2 - Sensor 2
• Test-ID 33 ($21): Catalyst Monitor Bank 1
• Test-ID 34 ($22): Catalyst Monitor Bank 2
• $3A (58): Fuel Tank EVAP System Leak Test (0.090)
• Test-ID 59 (3B): EVAP Monitor (0.040)
• Test-ID 60 (3C): EVAP Monitor (0.020)
• Test-ID 61 (3D): Purge Flow Monitor
• Test-ID 65 ($41): Oxygen Sensor Heater Monitor Bank 1 - Sensor 1
• Test-ID 66 ($42): Oxygen Sensor Heater Monitor Bank 1 - Sensor 2
• Test-ID 69 ($45): Oxygen Sensor Heater Monitor Bank 2 - Sensor 1
• Test-ID 70 ($46): Oxygen Sensor Heater Monitor Bank 2 - Sensor 2
• Test-ID 162 ($A2): Mis-Fire Cylinder 1 Data
• Test-ID 163 ($A4): Mis-Fire Cylinder 2 Data
• Test-ID 164 ($A4): Mis-Fire Cylinder 3 Data
• Test-ID 165 ($A5): Mis-Fire Cylinder 4 Data
• Test-ID 166 ($A4): Mis-Fire Cylinder 5 Data
• Test-ID 167 ($A7): Mis-Fire Cylinder 6 Data
• Fuel and air ratios
• Additional exhaust regulation
• Ignition system
• Function test
• Exhaust System Components, Removing and Installing

More articles — Engine
