Communication Audi A4 B7

General information

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Only use Radio R and components from the Audi program because this is the only way to ensure problem-free installation and optimal reception.

All Radios R are coded to Comfort in the instrument cluster (anti-theft coding). When removing and installing the same Radio R , coding is not necessary after disconnecting voltage supply when removing and installing the same instrument cluster.

Radio generation II+ introduced from KW 45/06.

This used two tuners with "phase diversity" for reception.

Further removal steps are the same as with the "Symphony" radio.

If "Transport" appears in the display after switching on the Radio R , transport mode must be deactivated.

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Information on Radio R and CD Changer R41 retrofitting

The connectors for the original Audi Radio R are provided in the radio package. Commercial radio units with different connectors must be connected with adapter cable.

When connecting the speed signal, ensure it is not short circuited. Otherwise, malfunctions can occur in the vehicle.

Using commercially available radios can cause interference with the antenna amplifier because the original Audi Radio R has "remotely powered antennas" which receive voltage supply from the Radio R via the middle conductor of the high frequency cable. Use the remote power adapter from Audi.

For CD preparation, the CD changer R41 wiring harness is already installed in the vehicle. The connecting wire can only be used with genuine Audi CD-changers R41.

Antenna system with Diversity function

The "Symphony" / from MY04, "Concert" /from MY05 and "Chorus" systems have an antenna system with diversity function. This improves and optimizes reception quality.

In addition to the roof antenna and rear window antenna with amplifier, an antenna in the rear or side with an amplifier is also used.

Individual antennas with amplifier are controlled via the Antenna Selection Control Module J515 (Diversity box).

The signal going via the antenna wire (HF) from Antenna Selection Control Module J515 into Radio R is checked and the results is output back to the Antenna Selection Control Module J515 via an additional antenna connection (IF).

If the antenna signal is too weak, the Antenna Selection Control Module J515 switches to another antenna (diversity function).

This switching process is neither seen nor heard.

The procedure is the same as "switching diversity".

With "phase diversity" , the Radio R has two internal tuners with one input each (AM/FM1, FM2).

If the signal received is interrupted, both signals are digitalized and separated in the tuners in the Radio R so that the disrupted signals are blocked out as much as possible.

If the reception signal is not disrupted, the Radio R constantly compares which antenna (amplifier) has the strongest reception. This is then transferred

In this case, the second tuner checks the frequency band in the background for better reception frequencies for the selected station. If a better signal is found, this tuner switches to reception and the other to the background.

BOSE system with "AudiPilot"

On vehicles with BOSE sound from MY04, an additional microphone, the Inside Microphone R74 is installed in the Front Interior Light W1. The Inside Microphone R74 is switched directly with the Amplifier R12 (BOSE).

The Amplifier R12 (BOSE) is then in a position to the adapt the sound characteristics of the BOSE system to the changing interior noise. For example, if the interior noise becomes louder, the volume is then automatically increased according to prescribed sound curves.

The interior noise is less dominant, the sound experience improves.

Function test, see --> Inside Microphone R74 , function test

Transport mode in "Symphony II+"

The "Symphony" generation II+ has a special protection lock for the internal CD changer.

This is active when the unit is shifted and must be deactivated after installation.

In the same way, the transport protection must be activated before removing the unit.

Transport mode, activating/deactivating --> "Symphony II+" in transport mode, activating/deactivating

Scheme 1

1 - AM/FM window antennas

2 - Sedan Antenna Amplifier R24 : behind roof end trim

Avant Left Antenna Module R108 : Behind luggage compartment left side trim

3 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

4 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Sedan Bass Loudspeaker R100 : in rear shelf/ Avant: behind luggage compartment right side trim

8 - Amplifier R12 behind luggage compartment right side trim

9 - Inside Loudspeaker R70 in front center instrument panel

10 - CD Changer R41 in glove compartment

11 - Radio R in upper center console

Scheme 2

1 - AM/FM window antennas

2 - Sedan Antenna Amplifier R24 : behind roof end trim

Avant Left Antenna Module R108 : Behind luggage compartment left side trim

3 - Amplifier R12 behind luggage compartment right side trim

4 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

5 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

6 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

7 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

8 - Sedan Bass Loudspeaker R100 : in rear shelf/ Avant: behind luggage compartment right side trim

9 - Inside Loudspeaker R70 in front center instrument panel

10 - Inside Microphone R74 in Front Interior Light W1

11 - CD Changer R41 in glove compartment

12 - Radio R in upper center console

Scheme 3

1 - AM/FM rear window antennas

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

4 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Bass Loudspeaker R100 in parcel shelf

8 - Amplifier R12 behind luggage compartment right side trim

9 - Inside Loudspeaker R70 in front center instrument panel

10 - CD Changer R41 in glove compartment

11 - Radio R in upper center console

Scheme 4

1 - left rear AM/FM1 window antennas

2 - FM2 rear window antennas

3 - right rear FM3 window antennas

4 - Left Antenna Module R108 behind luggage compartment left side trim

5 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

6 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

7 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

8 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

9 - Bass Loudspeaker R100 behind luggage compartment right side trim

10 - Amplifier R12 behind luggage compartment right side trim

11 - Inside Loudspeaker R70 in front center instrument panel

12 - CD Changer R41 in glove compartment

13 - Radio R in upper center console

Scheme 5

1 - AM/FM rear window antennas

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

4 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Bass Loudspeaker R100 in parcel shelf

8 - Inside Loudspeaker R70 in front center instrument panel

9 - Inside Microphone R74 in Front Interior Light W1

10 - CD Changer R41 / iPod Baseplate R192 in glove compartment

11 - Radio R in upper center console

12 - Amplifier R12 behind luggage compartment right side trim

Scheme 6

1 - Left Antenna Module R108 behind luggage compartment left side trim

2 - left rear AM/FM1 window antennas

3 - FM2 rear window antennas

4 - right rear FM3 window antennas

5 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

6 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

7 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

8 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

9 - Bass Loudspeaker R100 behind the luggage compartment right side trim

10 - Inside Loudspeaker R70 in front center instrument panel

11 - Inside Microphone R74 in Front Interior Light W1

12 - CD Changer R41 / iPod Baseplate R192 in glove compartment

13 - Radio R in upper center console

14 - Amplifier R12 luggage compartment right side trim

Scheme 7

1 - Speaker connector (T8d, brown)

2 - Voltage supply connector (T8c, black)

3 - HF antenna connector

4 - Antenna Amplifier R24 behind roof end trim (sedan)/ Left Antenna Module R108 behind luggage compartment left side trim (Avant)

5 - Rear Window Antenna 1 R130

6 - left front speaker

7 - right front speaker

Scheme 8

Connectors

1 - HF connector (black) from Antenna Amplifier R24 / Left Antenna Module R108

2 - Multi-pin connector IV, 10-pin, (T10l) red

3 - Multi-pin connector III, 8-pin, (T8) black

4 - Multi-pin connector II, 8-pin, (T8a) brown

5 - Device fuse

6 - Multi-pin connector I, 20-pin, (T20d) black

Note. Unlisted connector terminals are not assigned.

Scheme 9

2 - Multi-pin connector IV, 10-pin, (T10l) red

1 - NF mute from Telephone Transceiver R36

3 - NF (+) from Telephone Transceiver R36 (not with Nav IV)

4 - NF (-) from Telephone Transceiver R36 (not with Nav IV)

5 - NF (+) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

6 - NF (-) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

7 - Navigation control wire from Navigation System with CD Drive Control Module J401 (only with Nav IV)

3 - Multi-pin connector III, 8-pin, (T8) black

1 - BOSE coding to ground (only with BOSE)

2 - Anti-theft warning system ground from Comfort System Central Control Module J393

3 - L-diagnostic

7 - Terminal 30

8 - Terminal 31

4 - Multi-pin connector II, 8-pin, (T8a) brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

6 - Multi-pin connector I, 20-pin, (T20d) black

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12 (only with BOSE)

5 - Right front signal to Amplifier R12 (only with BOSE)

6 - Positive switched to Amplifier R12

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer R41

14 - CD data out to CD Changer R41

15 - CD CLK from CD Changer R41

16 - Permanent positive to CD Changer R41

17 - Positive switched to CD Changer R41

18 - CD ground to CD Changer R41

19 - Left signal from CD Changer R41

20 - Right signal from CD Changer R41

Scheme 10

1 - Multi-pin connector IV, 10-pin, (T10l) red

2 - Multi-pin connector I, 20-pin, (T20d) black

3 - Device fuse

4 - Multi-pin connector III, 8-pin, (T8) black

5 - Multi-pin connector II, 8-pin, (T8a) brown

6 - IF connection (yellow) to Antenna Selection Control Module J515 / Left Antenna Module R108

7 - HF connection (black) to Antenna Selection Control Module J515 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

1 - Multi-pin connector IV, 10-pin, (T10l) red

1 - NF mute from Telephone Transceiver R36 /preliminary setup for cell phone package

3 - NF (+) from Telephone Transceiver R36 (not with Nav IV)/preliminary setup for cell phone package

4 - NF (-) from Telephone Transceiver R36 (not with Nav IV)/preliminary setup for cell phone package

5 - NF (+) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

6 - NF (-) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

7 - Navigation control wire from Navigation System with CD Drive Control Module J401 (only with Nav IV)

2 - Multi-pin connector I, 20-pin, (T20d) black

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12 (only with BOSE)

5 - Right front signal to Amplifier R12 (only with BOSE)

6 - Positive switched to Amplifier R12

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer R41

14 - CD data out to CD Changer R41

15 - CD CLK from CD Changer R41

16 - Permanent positive to CD Changer R41

17 - Positive switched to CD Changer R41

18 - CD ground to CD Changer R41

19 - Left signal from CD Changer R41

20 - Right signal from CD Changer R41

4 - Multi-pin connector III, 8-pin, (T8) black

1 - BOSE coding to ground (only with BOSE

2 - Anti-theft warning system ground from Comfort System Central Control Module J393

3 - L-diagnostic

7 - Terminal 30

8 - Terminal 31

5 - Multi-pin connector II, 8-pin, (T8a) brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

Scheme 11

1 - Multi-pin connector IV, 10-pin, (T10l) red

2 - Multi-pin connector I, 20-pin, (T20d) black

3 - Device fuse

4 - Multi-pin connector III, 8-pin, (T8) black

5 - Multi-pin connector II, 8-pin, (T8a) brown

6 - IF connection (yellow) to Antenna Selection Control Module J515 / Left Antenna Module R108

7 - HF connection (black) to Antenna Selection Control Module J515 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

1 - Multi-pin connector IV, 10-pin, (T10l) red

1 - NF mute from Telephone Transceiver R36 /preliminary setup for cell phone package

3 - NF (+) from Telephone Transceiver R36 (not with Nav IV)/preliminary setup for cell phone package

4 - NF (-) from Telephone Transceiver R36 (not with Nav IV)/preliminary setup for cell phone package

5 - NF (+) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

6 - NF (-) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

7 - Navigation control wire from Navigation System with CD Drive Control Module J401 (only with Nav IV)

2 - Multi-pin connector I, 20-pin, (T20d) black

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12 (only with BOSE)

5 - Right front signal to Amplifier R12 (only with BOSE)

6 - Positive switched to Amplifier R12

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer R41

14 - CD data out to CD Changer R41

15 - CD CLK from CD Changer R41

16 - Permanent positive to CD Changer R41

17 - Positive switched to CD Changer R41

18 - CD ground to CD Changer R41

19 - Left signal from CD Changer R41

20 - Right signal from CD Changer R41

4 - Multi-pin connector III, 8-pin, (T8) black

1 - BOSE coding to ground (only with BOSE)

2 - Anti-theft warning system ground from Comfort System Central Control Module J393

3 - L-diagnostic

7 - Terminal 30

8 - Terminal 31

5 - Multi-pin connector II, 8-pin, (T8a) brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

Scheme 12

1 - Connector block with 4 multi-pin connectors and fuse

2 - HF1 connector (white) from Antenna Amplifier R24 / Left Antenna Module R108

3 - HF21 connector (white) from Antenna Amplifier R24 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

Scheme 13

A - 8-pin multi-pin connector (T8h) black

2 - Right front speaker (+) (not with BOSE)

3 - Left front speaker (+) (not with BOSE)

6 - Right front speaker (-) (not with BOSE)

7 - Left front speaker (-) (not with BOSE)

B - Multi-pin connector, 12-pin (T12f) blue

1 - NF in left (not used)

2 - CD ground to CD Changer R41

3 - NF in ground (not used)

4 - Permanent positive to CD Changer R41

5 - BOSE coding to ground (only with BOSE)

6 - CD data out to CD Changer R41

7 - NF in right (not used)

8 - Left signal from CD Changer R41

9 - Right signal from CD Changer R41

10 - Positive switched to CD Changer R41

11 - CD data in from CD Changer R41

12 - CD CLK from CD Changer R41

C - multi-pin connector, 12-pin (T12) green

1 - Speed signal (not used)

3 - Left front signal to Amplifier R12 (only with BOSE)

5 - Left rear signal to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

6 - NF (-) from Telephone Transceiver R36 /preliminary setup for cell phone package

7 - K diagnostic (not used)

8 - Signal ground to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

9 - Right front signal to Amplifier R12 (only with BOSE)

10 - Audio Pilot in/out (not used)

11 - Right rear signal to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

12 - NF (+) from Telephone Transceiver R36 /preliminary setup for cell phone package

D - 8-pin multi-pin connector (T8h) black

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from preliminary setup for cell phone preparation

12 - Terminal 31

13 - Positive switched to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive connected with PIN 15 (anti-theft warning system)

CD Changer R41

Note. Unlisted connector terminals are not assigned.

Scheme 14

Black 12-pin multi-pin harness connector

1 - CD data out to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

2 - CD CLK out to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

3 - Ground from Radio R /terminal 31 (with RNS-E/radio generation II+)

4 - CD data in from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

6 - Permanent positive from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

7 - Right signal to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

8 - Positive switched from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

9 - Signal ground from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

10 - Left signal to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

iPod Baseplate R192

Note. Unlisted connector terminals are not assigned.

Scheme 15

Black 12-pin multi-pin harness connector (T12a)

1 - Data out to Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

2 - CLK out to Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

3 - Terminal 31

4 - Data in from Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

6 - Permanent positive from Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

7 - Right signal to Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

8 - Positive switched from Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

9 - Signal ground from Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

10 - Left signal to Radio R / Operating Electronics, Navigation Control Module J402 / Radio/Navigation Display Control Module J503

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

Digital Sound System Control Module R12

Note. Unlisted connector terminals are not assigned.

Scheme 16

Blue 23-pin multi-pin connector

1 - Right rear signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

2 - Signal ground from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

3 - Left rear signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

9 - Positive switched from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

14 - Bass Loudspeaker R100 (+)

15 - Bass Loudspeaker R100 (-)

17 - Loudspeaker, left rear (+)

18 - Loudspeaker, left rear (-)

20 - Loudspeaker, right rear (+)

21 - Loudspeaker, right rear (-)

22 - Terminal 31

23 - Terminal 30

Amplifier R12 BOSE (25-pin)

Note. Unlisted connector terminals are not assigned.

Scheme 17

Multi-pin connector, 25-pin

1 - Inside Loudspeaker R70 (+)

2 - Inside Loudspeaker R70 (-)

6 - Signal ground from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

7 - Right rear signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

8 - Left rear signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

9 - Right front signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

10 - Left front signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

11 - Terminal 31

13 - Terminal 30

14 - Bass Loudspeaker R100 (+)

15 - Bass Loudspeaker R100 (-)

16 - Loudspeaker, left rear (-)

17 - Loudspeaker, left rear (+)

18 - Loudspeaker, right rear (+)

19 - Loudspeaker, right rear (-)

20 - Loudspeaker, left rear (+)

21 - Loudspeaker, left rear (-)

22 - Loudspeaker, right rear (+)

23 - Loudspeaker, right rear (-)

25 - Positive switched from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

Amplifier R12 BOSE (32-pin)

Note. Unlisted connector terminals are not assigned.

Scheme 18

Multi-pin connector, 32-pin

1 - Terminal 30

2 - Terminal 31

3 - Bass Loudspeaker R100 (+)

4 - Loudspeaker, left rear (-)

5 - Loudspeaker, right rear (+)

6 - Positive switched from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

7 - Signal ground from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

13 - Inside Loudspeaker R70 (-)

14 - Inside Loudspeaker R70 (+)

15 - Bass Loudspeaker R100 (-)

16 - Loudspeaker, left rear (+)

17 - Loudspeaker, right rear (-)

19 - Left front signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

20 - Right front signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

21 - Left rear signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

22 - Right rear signal from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

26 - Loudspeaker, right rear (-)

27 - Loudspeaker, right rear (+)

29 - Microphone input (+) from Inside Microphone R74

30 - Microphone input (-) from Inside Microphone R74 (-)

31 - Loudspeaker, left rear (+)

32 - Loudspeaker, left rear (-)

Scheme 19

1 - TV1 connection to Navigation/TV Tuner J415

2 - TV2 connection to Navigation/TV Tuner J415

3 - TS connection to Auxiliary Heater Radio Receiver R64

4 - TV3 connection to Navigation/TV Tuner J415

5 - Ground connection

6 - TV4 connection to Navigation/TV Tuner J415

7 - HF connection (white) to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

8 - CLS connection (gray) to Comfort System Central Control Module J393

9 - HF connection (yellow) from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

Scheme 20

1 - AM/FM1 connection (white) to Radio R

2 - FM2 connection (yellow) to Radio R

3 - Ground connection

4 - CLS connection (gray) to Comfort System Central Control Module J393

Scheme 21

only "Chorus" through KW 21/04

1 - Connection for window antennas

1. 1 - CLS
2. 2 - FM/TS
3. 3 - AM

2 - CLS connection (gray) to Comfort System Central Control Module J393

3 - TS connection (yellow) to Auxiliary Heater Radio Receiver R64

4 - AM/FM connection (white) to Radio R

All without TV antennas

Scheme 22

1 - Connection for window antennas

1. 1 - CLS
2. 2 - FM1/TS
3. 3 - AM

2 - CLS connection (gray) to Comfort System Central Control Module J393

3 - TS connection (yellow) to Auxiliary Heater Radio Receiver R64

4 - HF/IF connection (yellow) to/from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

5 - FM3 connection (black) from Right Antenna Module R109

6 - FM2 connection (brown) from rear window antenna

All with TV antennas

Scheme 23

1 - Connection for window antennas

1. 1 - TV1/CLS
2. 2 - FM1/TS
3. 3 - AM

2 - CLS connection (gray) to Comfort System Central Control Module J393

3 - TS connection (yellow) to Auxiliary Heater Radio Receiver R64

4 - HF/IF connection (yellow) to/from Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

5 - FM3 connection (black) from Right Antenna Module R109

6 - FM2/TV2 connection (brown) from rear window antenna

7 - TV1/TV2 connection (green) to Navigation/TV Tuner J415

Scheme 24

1 - Connection for window antennas

1. 1 - CLS
2. 2 - FM1/TS
3. 3 - AM

2 - CLS connection (gray) to Comfort System Central Control Module J393

3 - TS connection (yellow) to Auxiliary Heater Radio Receiver R64

4 - AM/FM1 connection (yellow) to Radio R

5 - FM2 connection (yellow) to Radio R

6 - FM2 connection (brown) from rear window antenna

Scheme 25

Connectors

1 - Connection for window antennas

1. 1 - FM3/TV3
2. 2 - TV4

2 - FM3 connection (black) to Left Antenna Module R108

3 - TV3 connection (green) to Navigation/TV Tuner J415

4 - TV4 connection (brown) to Navigation/TV Tuner J415

Scheme 26

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Radio R

1. In center console, at top
2. "Chorus" connections /from KW 22/04
3. "Concert" connections
4. "Chorus" / "Concert" , removing and installing --> «"Chorus" / "Concert" , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__chorus-concert-removing-and)

1. "Symphony" connections
2. Radio generation II+ connections
3. "Symphony" , removing and installing --> «"Symphony" radio, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-radio-removing-and-installing)
4. "Symphony II+" transport protection, activating/deactivating --> «"Symphony II+" in transport mode, activating/deactivating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-ii-in-transport-mode-activatingdeactivating)

4 - Inside Microphone R74

1. In Front Interior Light W1
2. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
3. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

5 - Antenna Amplifier R24 / Antenna Selection Control Module J515

1. Behind roof end trim
2. Antenna Amplifier R24 connections --> «Antenna amplifier connections»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Antenna Selection Control Module J515 connections
4. Radio generation II+ connections

1. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

6 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing)

7 - Bass Loudspeaker R100

1. In parcel shelf
2. Removing and installing --> «Bass Loudspeaker R100 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-sedan-removing)

8 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. In bottom of rear doors
2. Removing and installing

9 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

10 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors
2. Removing and installing --> «Speakers in doors, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

11 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors
2. Removing and installing

Scheme 27

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Radio R

1. In center console, at top
2. "Chorus" connections /from KW 22/04
3. "Concert" connections
4. "Chorus" / "Concert" , removing and installing --> «"Chorus" / "Concert" , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__chorus-concert-removing-and)

1. "Symphony" connections
2. Radio generation II+ connections
3. "Symphony" , removing and installing --> «"Symphony" radio, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-radio-removing-and-installing)
4. "Symphony II+" transport protection, activating/deactivating --> «"Symphony II+" in transport mode, activating/deactivating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-ii-in-transport-mode-activatingdeactivating)

4 - Inside Microphone R74

1. In Front Interior Light W1
2. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
3. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

5 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing)

6 - Right rear window antennas

1. FM3

7 - Bass Loudspeaker R100

1. Behind luggage compartment right side trim
2. Removing and installing --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing)

8 - Rear window antennas

1. FM2

9 - Left Antenna Module R108

1. Behind luggage compartment left side trim
2. Connections
3. Only radio generation II+ connections «Only radio generation II+»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
4. Removing and installing --> «Left Antenna Module R108 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

10 - Left rear window antennas

1. AM/FM1

11 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. In bottom of rear doors
2. Removing and installing

12 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

13 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors
2. Removing and installing --> «Speakers in doors, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

14 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors
2. Removing and installing

"Chorus" / "Concert" , removing and installing

Special tools, testers and auxiliary items required

Scheme 28

1. Radio removal tool T10057

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Scheme 29

1. Insert two clips on Radio Release Tool T10057 in release slits on Radio R until they engage. Points on grip eyes face outward.
2. Remove Radio R from instrument panel.
3. Release connectors at radio R and remove.
4. Remove Radio Release Tool T10057 by pressing locking tabs on Radio R.

Installing

1. Connect all harness connectors.
2. Carefully slide radio R into instrument panel and let it engage in mounting frame.

"Symphony" radio, removing and installing

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Activate transport mode in "Symphony II+" --> «"Symphony II+" in transport mode, activating/deactivating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-ii-in-transport-mode-activatingdeactivating) .
2. Turn off all electrical components.
3. Remove ignition key.

Removing

Scheme 30

1. Insert Radio Release Tool T10057 in release slits on Radio R until they engage. Points on grip eyes face outward.
2. Remove Radio R from instrument panel.
3. Release connectors at radio R and remove.
4. Remove Radio Release Tool T10057 by pressing locking tabs on Radio R.

Installing

1. Connect all harness connectors.
2. Carefully slide radio R into instrument panel and let it engage in mounting frame.
3. Deactivate transport mode in "Symphony II+" --> «"Symphony II+" in transport mode, activating/deactivating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-ii-in-transport-mode-activatingdeactivating) .

"Symphony II+" in transport mode, activating/deactivating

Transport mode must be activated before sending every "Symphony II+" radio.

After activation, the internal CD changer drive is in transport position.

After replacing a "Symphony II+" , transport mode must be deactivated after installation.

Transport mode, activating

"Symphony" is connected and installed.

1. Press station buttons 3 and 5 and TONE button at the same time.

After about 5 seconds, "TRANSPORT" appears on the radio display.

Transport mode, deactivating

" II+Symphony" is connected and installed.

1. Press CANCEL button.

"TRANSPORT" display goes out.

Transport mode is deactivated.

CD Changer R41 , removing and installing

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open glove box.

Scheme 31

1. Insert two clips on Radio Release Tool T10057 in release slits on CD Changer R41 until they engage. Points on grip eyes face outward.
2. Pull CD Changer R41 out of mounting frame.
3. Release connectors on CD Changer R41 and remove.
4. Remove Radio Release Tool T10057 by pushing locking tabs on CD Changer R41 to do so.

Installing

1. Connect harness connector.
2. Slide CD Changer R41 into mounting frame until it engages.
3. Check wiring connection to Radio R (not radio generation II+).

Wiring connection to Radio R / CD Changer R41 (through KW 44/06), checking

1. Switch radio R off.

"Chorus"

1. Press CC/CD button on radio R and at the same time, switch radio R on.

"Concert"

1. Press CC button on radio R and at the same time, switch radio R on.

"Symphony"

1. Press station button 4 on radio R and simultaneously switch radio R on and hold down switch-on button.

All

Note. Data wire from radio R to CD changer R41 is not checked.

Wire connection OK

Indication on radio display

1. "CDC CONNECTED"

Wire connection not OK

Indication on radio display

1. "NO CDC"
2. Check electrical connector at radio R.
3. Repeat wiring check and if not OK, check wire connector according to wiring diagram --> Electrical Wiring Diagrams, Troubleshooting and Component Locations.

iPod Baseplate R192 , removing and installing

Special tools and workshop equipment required

1. Trim removal wedge 3409

Scheme 32

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open glove box.

Scheme 33

1. Remove iPod - 1 - from iPod Baseplate R192.
2. Using Trim Removal Wedge 3409 , carefully pry iPod Baseplate R192 out of retainer - arrows -.
3. Remove iPod Baseplate R192 from glove compartment and disconnect connection.

Installing

1. Install in reverse order.

Left Front Bass Speaker R21 , removing and installing

Removal and installation of Left Front Bass Speaker R21 and Right Front Bass Speaker R23 are the same.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove front door trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 34

1. Disconnect connectors - 2 - and - 3 - on Left Front Bass Speaker R21 - 5 -.
2. Remove bolts - 4 - (2 Nm) on Left Front Bass Speaker R21 - 5 - , disengage retaining tab on speaker in installation opening and remove speaker - 5 -.

Installing

1. Install in reverse order.

Left Front Midrange Speaker R26 , removing and installing

Removal and installation of Left Front Midrange Speaker R26 and Right Front Midrange Speaker R27 are identical.

Special tools, testers and auxiliary items required

Scheme 35

1. Special hook 3370

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Scheme 36

1. Remove speaker cover - 1 - at top of door trim upward with Special Hook 3370 - arrow -.

Scheme 37

1. Disconnect electrical connector - 2 - on Left Front Midrange Speaker R26 - 1 -.
2. Release retaining tabs - arrows - and remove Left Front Midrange Speaker R26 - 1 -.

Installing

1. Install in reverse order.

Left Rear Bass Speaker R15 , removing and installing

Removal and installation of Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17 are the same.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove rear door trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 38

1. Disconnect connectors - 2 - and - 3 - on Left Rear Bass Speaker R15 - 5 -.
2. Remove bolts - 4 - (2 Nm) on Left Rear Bass Speaker R15 - 5 - , disengage retaining tab on speaker in installation opening and remove speaker - 5 -.

Installing

1. Install in reverse order.

Left Rear Midrange Speaker R34 , removing and installing

Removal and installation of Left Rear Midrange Speaker R34 and Right Rear Midrange Speaker R35 are the same.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove rear door trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 39

1. Disconnect electrical connection - 1 - from Left Rear Midrange Speaker R34 - 2 -.
2. Release retaining tabs - arrows - and remove Left Rear Midrange Speaker R34 - 2 -.

Installing

1. Install in reverse order.

Inside Loudspeaker R70 , removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Scheme 40

1. Carefully pry off cover - A - on Sunlight Photo Sensor (3241) G107.
2. Remove bolt - B - (1 Nm).
3. Disconnect connector on Sunlight Photo Sensor (3241) G107 and remove it.

Scheme 41

1. Remove bolt - 1 - (1 Nm).
2. Remove defroster vent.

Scheme 42

1. Remove screws - 1 - (2 Nm) on Inside Loudspeaker R70.
2. Tip Inside Loudspeaker R70 out and disconnect connector on it.

Installing

1. Install in reverse order.

Bass Loudspeaker R100 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove rear parcel shelf --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior)

Scheme 43

1. Remove 2 screws - 4 - (2 Nm) from parcel shelf.
2. Remove two screws - 2 - (2 Nm) from luggage compartment.
3. Disconnect connector - 1 - on Bass Loudspeaker R100 - 3 - and remove speaker upward.

Installing

1. Install in reverse order.

Bass Loudspeaker R100 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove luggage compartment right side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 44

1. Disconnect connectors - 1 - and - 2 - on Amplifier R12.
2. Remove bolts - arrows - (2 Nm).
3. Remove Bass Loudspeaker R100 - 3 - together with Amplifier R12 - 4 -.
4. Remove Amplifier R12 --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and) or --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing) .

Installing

1. Install in reverse order.

Amplifier R12 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove luggage compartment right side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 45

1. Disconnect connector - 2 - on Amplifier R12 - 1 -.
2. Remove bolts (4 Nm) and remove Amplifier R12 - 1 -.

Installing

1. Install in reverse order.

Amplifier R12 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open right luggage compartment storage bin.

Scheme 46

1. Disconnect connector - 1 - on Amplifier R12 - 2 -.
2. Remove bolts - arrows - (3 Nm) and remove Amplifier R12 - 2 -.

Installing

1. Install in reverse order.

BOSE Amplifier R12 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove luggage compartment right side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 47

1. Disconnect connector - 2 - on Amplifier R12 - 1 -.
2. Remove bolts (4 Nm) and remove Amplifier R12 - 1 -.

Installing

1. Install in reverse order.

BOSE Amplifier R12 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open right luggage compartment storage bin.

Scheme 48

1. Disconnect connector - 1 - on Amplifier R12 - 2 -.
2. Remove bolts - arrows - (3 Nm) and remove Amplifier R12 - 2 -.

Installing

1. Install in reverse order.

Inside Microphone R74 , function test

With BOSE sound, and Inside Microphone R74 is installed to determine interior noise (AudioPilot). This is switched directly with the Amplifier R12. If interior noise increases, the Amplifer R12 (AudioPilot) automatically increases volume according to a predetermined pattern.

After switching on the Radio R , the Amplifier R12 determines the gauge of the Inside Microphone R74 voltage supply. If the result is OK, there is no reaction.

In contrast, if no Inside Microphone R74 is installed, three short tones sound one after another.

In case of short circuit, three individual tones are heard.

Function test

1. Switch the Radio R on and set it to a station (pop music, if possible).
2. Set the volume to approx. "20".
3. Now lightly tap on the Inside Microphone R74 ( Front Interior Light W1 ) several times.

The volume of the station selected on the Radio R must increase noticeably during the tapping. The procedure is done slowly.

1. Stop tapping.

The volume of the station selected on the Radio R must decrease noticeably.

Inside Microphone R74 , removing and installing

Special tools, testers and auxiliary items required

1. Special hook 3370

Removing

Scheme 49

1. Carefully remove cover on Front Interior Light W1 with Special Hook 3370.

Scheme 50

1. Remove bolts - arrows - (3 Nm).
2. Tip Front Interior Light W1 downward and out.

Scheme 51

1. If present, release retaining clips - arrows - and remove Radar Interior Monitoring Control Module 1 G303 - 1 - from Front Interior Light W1.

Scheme 52

1. Disconnect connector - 1 - on Inside Microphone R74 - 2 -.
2. Release retaining hooks - arrows - and remove Inside Microphone R74 - 2 -.

Installing

1. Install in reverse order.

Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 53

1. Disconnect ground wire - 1 -.
2. Release retaining tabs - arrows - and remove Antenna Amplifier R24 / Antenna Selection Control Module J515 - 3 -.
3. Disconnect electrical connectors - 2 -.

Installing

1. Install in reverse order.

"Chorus" (through KW 21/04)

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove left luggage compartment side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 54

1. If present, remove Towing Recognition Control Module J345 bracket - arrows - (2 Nm).

Scheme 55

1. Disconnect connectors on Left Antenna Module R108 - 1 -.
2. Remove bolts - arrows - (2 Nm) and remove Left Antenna Module R108 - 1 -.

Installing

1. Install in reverse order.

"Concert" / "Symphony" /from KW 22/04 "Chorus"

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove luggage compartment left side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. If present, remove Towing Recognition Control Module J345 bracket - arrows - (2 Nm).

Scheme 56

1. Disconnect connectors on Left Antenna Module R108 - 1 -.
2. Remove bolts - arrows - (2 Nm) and remove Left Antenna Module R108 - 1 -.

Installing

1. Install in reverse order.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Only use Radio R and components from the Audi program because this is the only way to ensure problem-free installation and optimal reception.

All Radios R are coded to Comfort in the instrument cluster (anti-theft coding). When removing and installing the same Radio R , coding is not necessary after disconnecting voltage supply when removing and installing the same instrument cluster.

Radio generation II+ introduced from KW 22/06.

This used two tuners with "phase diversity" for reception.

Further removal steps are the same as with the "Symphony" radio.

If "Transport" appears in the display after switching on the Radio R , transport mode must be deactivated.

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Information on Radio R / CD Changer R41 retrofitting

The connectors for the original Audi Radio R are provided in the radio package. Commercial radio units with different connectors must be connected with adapter cable.

When connecting the speed signal, ensure it is not short circuited. Otherwise, malfunctions can occur in the vehicle.

Using commercially available radios can cause interference with the antenna amplifier because the original Audi Radio R has "remotely powered antennas" which receive voltage supply from the Radio R via the middle conductor of the high frequency cable. Use the remote power adapter from Audi.

For CD preparation, the CD changer R41 wiring harness is already installed in the vehicle. The connecting wire can only be used with genuine Audi CD-changers R41.

The "Symphony" / from MY04, "Concert" /from MY05 and "Chorus" systems have an antenna system with diversity function. This improves and optimizes reception quality.

In addition to the roof antenna and rear window antenna with amplifier, an antenna in the rear or side with an amplifier is also used.

Individual antennas with amplifier are controlled via the Antenna Selection Control Module J515 (Diversity box).

The signal going via the antenna wire (HF) from Antenna Selection Control Module J515 into the Radio R is checked and the result is output back to the Antenna Selection Control Module J515 via an additional antenna connection (IF).

If the antenna signal is too weak, the Antenna Selection Control Module J515 switches to another antenna (diversity function).

This switching process is neither seen nor heard.

The procedure is the same as "switching diversity".

With "phase diversity" , the Radio R has two internal tuners with one input each (AM/FM1, FM2).

If the signal received is interrupted, both signals are digitalized and separated in the tuners in the Radio R so that the disrupted signals are blocked out as much as possible.

If the reception signal is not disrupted, the Radio R constantly compares which antenna (amplifier) has the strongest reception. This is then transferred

In this case, the second tuner checks the frequency band in the background for better reception frequencies for the selected station. If a better signal is found, this tuner switches to reception and the other to the background.

BOSE systems with "AudiPilot"

On vehicles with BOSE sound from MY04, an additional microphone, the Inside Microphone R74 is installed in the Front Interior Light W1. The Inside Microphone R74 is switched directly with the Amplifier R12 (BOSE).

The Amplifier R12 (BOSE) is then in a position to the adapt the sound characteristics of the BOSE system to the changing interior noise. For example, if the interior noise becomes louder, the volume is then automatically increased according to prescribed sound curves.

The interior noise is less dominant, the sound experience improves.

Function test, see --> Inside Microphone R74 , function test .

Transport protection in "Symphony II+"

The "Symphony" Radio R generation II+ has a special protection lock for the internal CD changer.

This is active when the unit is shifted and must be deactivated after installation.

In the same way, the transport protection must be activated before removing the unit.

Transport protection, activating/deactivating --> "Symphony II+" in transport mode, activating/deactivating

Scheme 57

1 - AM/FM rear window antennas

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Radio R in upper center console

4 - Amplifier R12 behind luggage compartment right side trim

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

8 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

9 - Bass Loudspeaker R100 in parcel shelf

10 - Inside Loudspeaker R70 in front center instrument panel

11 - Inside Microphone R74 in Front Interior Light W1

12 - CD Changer R41 / iPod Baseplate R192 in glove compartment

13 - Satellite Radio R146 behind luggage compartment left side trim

14 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Scheme 58

1 - left rear AM/FM1 window antennas

2 - FM2 rear window antennas

3 - right rear FM3 window antennas

4 - Left Antenna Module R108 behind luggage compartment left side trim

5 - Radio R in upper center console

6 - Amplifier R12 behind luggage compartment right side trim

7 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

8 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

9 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

10 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

11 - Bass Loudspeaker R100 behind luggage compartment right side trim

12 - Inside Loudspeaker R70 in front center instrument panel

13 - Inside Microphone R74 in Front Interior Light W1

14 - CD Changer R41 / iPod Baseplate R192 in glove compartment

15 - Satellite Radio R146 behind luggage compartment left side trim

16 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Scheme 59

1 - Satellite Radio R146 behind luggage compartment left side trim

2 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

3 - GPS Antenna Splitter R110 (Avant) behind luggage compartment left side trim

4 - Navigation System Antenna R50 (sedan) behind roof end trim

5 - Navigation System with CD Drive Control Module J401 behind luggage compartment left side trim

6 - Radio antennas

7 - Antenna Selection Control Module J515 / Left Antenna Module R108

8 - Sound system

9 - Radio R in upper center console

10 - CAN-BUS (Infotainment)

11 - CD Changer R41 / iPod Baseplate R192 in glove compartment

12 - Telephone Transceiver R36 / Telephone/Telematics Control Module J526 in electronics box under right front seat

"Concert "

1 - Multi-pin connector IV, 10-pin, (T10l) red

2 - Multi-pin connector I, 20-pin, (T20d) black

3 - Device fuse

4 - Multi-pin connector III, 8-pin, (T8) black

5 - Multi-pin connector II, 8-pin, (T8a) brown

6 - IF connection (yellow) to Antenna Selection Control Module J515 / Left Antenna Module R108

7 - HF connection (black) to Antenna Selection Control Module J515 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

1 - Multi-pin connector IV, 10-pin, (T10l) red

1 - NF mute from Telephone/Telematics Control Module J526

3 - NF (+) from Telephone/Telematics Control Module J526 (not with Nav IV)

4 - NF (-) from Telephone/Telematics Control Module J526 (not with Nav IV)

5 - NF (+) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

6 - NF (-) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

7 - Navigation control wire from Navigation System with CD Drive Control Module J401 (only with Nav IV)

2 - Multi-pin connector I, 20-pin, (T20d) black

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12 (only with BOSE)

5 - Right front signal to Amplifier R12 (only with BOSE)

6 - Positive switched to Amplifier R12

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer R41

14 - CD data out to CD Changer R41

15 - CD CLK from CD Changer R41

16 - Permanent positive to CD Changer R41

17 - Positive switched to CD Changer R41

18 - Signal ground from CD Changer R41 / Satellite Radio R146

19 - Left signal from CD Changer R41 / Satellite Radio R146

20 - Right signal from CD Changer R41 / Satellite Radio R146

4 - Multi-pin connector III, 8-pin, (T8) black

1 - BOSE coding to ground (only with BOSE)

2 - Anti-theft warning system ground from Comfort System Central Control Module J393

3 - L-diagnostic

7 - Terminal 30

8 - Terminal 31

5 - Multi-pin connector II, 8-pin, (T8a) brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

"Symphony"

1 - Multi-pin connector IV, 10-pin, (T10l) red

2 - Multi-pin connector I, 20-pin, (T20d) black

3 - Device fuse

4 - Multi-pin connector III, 8-pin, (T8) black

5 - Multi-pin connector II, 8-pin, (T8a) brown

6 - IF connection (yellow) to Antenna Selection Control Module J515 / Left Antenna Module R108

7 - HF connection (black) to Antenna Selection Control Module J515 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

1 - Multi-pin connector IV, 10-pin, (T10l) red

1 - NF mute from Telephone/Telematics Control Module J526

3 - NF (+) from Telephone/Telematics Control Module J526 (not with Nav IV)

4 - NF (-) from Telephone/Telematics Control Module J526 (not with Nav IV)

5 - NF (+) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

6 - NF (-) from Navigation System with CD Drive Control Module J401 (only with Nav IV)

7 - Navigation control wire from Navigation System with CD Drive Control Module J401 (only with Nav IV)

2 - Multi-pin connector I, 20-pin, (T20d) black

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12 (only with BOSE)

5 - Right front signal to Amplifier R12 (only with BOSE)

6 - Positive switched to Amplifier R12

7 - CAN-Bus High (Infotainment)

10 - CD ground to CD Changer R41

12 - CAN-Bus Low (Infotainment)

13 - CD data in from CD Changer R41

14 - CD data out to CD Changer R41

15 - CD CLK from CD Changer R41

16 - Permanent positive to CD Changer R41

17 - Positive switched to CD Changer R41

18 - Signal ground from CD Changer R41 / Satellite Radio R146

19 - Left signal from CD Changer R41 / Satellite Radio R146

20 - Right signal from CD Changer R41 / Satellite Radio R146

4 - Multi-pin connector III, 8-pin, (T8) black

1 - BOSE coding to ground (only with BOSE)

2 - Anti-theft warning system ground from Comfort System Central Control Module J393

3 - L-diagnostic

7 - Terminal 30

8 - Terminal 31

5 - Multi-pin connector II, 8-pin, (T8a) brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

"Concert" / "Symphony" (radio generation II+) from KW 22/06

1 - Connector block with 4 multi-pin connectors and fuse

2 - HF1 connector (white) from Antenna Amplifier R24 / Left Antenna Module R108

3 - HF21 connector (white) from Antenna Amplifier R24 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

A - 8-pin multi-pin connector (T8h) black

2 - Right front speaker (+) (not with BOSE)

3 - Left front speaker (+) (not with BOSE)

6 - Right front speaker (-) (not with BOSE)

7 - Left front speaker (-) (not with BOSE)

B - Multi-pin connector, 12-pin (T12f) blue

1 - NF in left (not used)

2 - Signal ground from CD Changer R41 / Satellite Radio R146

3 - NF in ground (not used)

4 - Permanent positive to CD Changer R41

5 - BOSE coding to ground (only with BOSE)

6 - CD data out to CD Changer R41

7 - NF in right (not used)

8 - Left signal from CD Changer R41 / Satellite Radio R146

9 - Right signal from CD Changer R41 / Satellite Radio R146

10 - Positive switched to CD Changer R41

11 - CD data in from CD Changer R41

12 - CD CLK from CD Changer R41

C - multi-pin connector, 12-pin (T12) green

1 - Speed signal (not used)

3 - Left front signal to Amplifier R12 (only with BOSE)

5 - Left rear signal to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

6 - NF (-) from Telephone Transceiver R36

7 - K diagnostic (not used)

8 - Signal ground to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

9 - Right front signal to Amplifier R12 (only with BOSE)

10 - Audio Pilot in/out (not used)

11 - Right rear signal to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

12 - NF (+) from Telephone Transceiver R36

D - 8-pin multi-pin connector (T8h) black

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from preliminary setup for cell phone preparation

12 - Terminal 31

13 - Positive switched to Amplifier/Woofer (in left rear luggage compartment) R44 / Amplifier R12

14 - Anti-theft warning system (not used)

15 - Terminal 30

16 - Permanent positive connected with PIN 15 (anti-theft warning system)

Scheme 60

Connectors

A - 8-pin connector

B - 8-pin connector

C - Ter connection (brown) from Radio, Telephone, Navigation System Antenna R52 (up to 10/06)

D - Sat connection (green) from Radio, Telephone, Navigation System Antenna R52

Note. Unlisted connector terminals are not assigned.

A - multi-pin connector, 8-pin

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

3 - Left signal from CD Changer R41 / iPod Baseplate R192

4 - Right signal from CD Changer R41 / iPod Baseplate R192

5 - Signal ground to Radio R / Navigation System with CD Drive Control Module J401

6 - Left signal to Radio R / Navigation System with CD Drive Control Module J401

7 - Right signal to Radio R / Navigation System with CD Drive Control Module J401

8 - Signal ground from CD Changer R41 / iPod Baseplate R192

B - Multi-pin connector, 8-pin

1 - Terminal 30

2 - Terminal 31

Note. Unlisted connector terminals are not assigned.

Multi-pin connector, 12-pin

1 - CD data out to Radio R / Navigation System with CD Drive Control Module J401

2 - CD CLK out to Radio R / Navigation System with CD Drive Control Module J401

3 - Ground from Radio R /terminal 31 (with RNS-E/radio generation II+)

4 - CD data in from Radio R / Navigation System with CD Drive Control Module J401

6 - Permanent positive from Radio R / Navigation System with CD Drive Control Module J401

7 - Right signal to Radio R / Navigation System with CD Drive Control Module J401 / Satellite Radio R146

8 - Positive switched from Radio R / Navigation System with CD Drive Control Module J401

9 - Signal ground to Radio R / Navigation System with CD Drive Control Module J401 / Satellite Radio R146

10 - Left signal to Radio R / Navigation System with CD Drive Control Module J401 / Satellite Radio R146

Note. Unlisted connector terminals are not assigned.

Black 12-pin multi-pin harness connector (T12a)

1 - Data out to Radio R / Navigation System with CD Drive Control Module J401

2 - CLK out to Radio R / Navigation System with CD Drive Control Module J401

3 - Terminal 31

4 - Data in from Radio R / Navigation System with CD Drive Control Module J401

6 - Permanent positive from Radio R / Navigation System with CD Drive Control Module J401

7 - Right signal to Radio R / Navigation System with CD Drive Control Module J401 / Satellite Radio R146

8 - Positive switched from Radio R / Navigation System with CD Drive Control Module J401

9 - Signal ground from Radio R / Navigation System with CD Drive Control Module J401 / Satellite Radio R146

10 - Left signal to Radio R / Navigation System with CD Drive Control Module J401 / Satellite Radio R146

11 - TOC Check Control (not used)

12 - Terminal 58 (not used)

Antenna Selection Control Module J515 , sedan

1 - not in use

2 - not in use

3 - not in use

4 - not in use

5 - Ground connection

6 - not in use

7 - HF connection (white) to Radio R / Navigation System with CD Drive Control Module J401

8 - IHF connection (white) from Radio R / Navigation System with CD Drive Control Module J401

9 - CLS connection (green) to Comfort System Central Control Module J393

Antenna Amplifier R24 , sedan only with radio generation II+

1 - AM/FM connection (white) to Radio R

2 - FM2 connection (yellow) to Radio R

3 - Ground connection

4 - CLS connection (gray) to Comfort System Central Control Module J393

Left Antenna Module R108 , Avant

1 - Left window antenna connection

1. 1 - CLS
2. 2 - FM1
3. 3 - AM

2 - CLS connection (gray) to Comfort System Central Control Module J393

3 - not in use

4 - HF/IF connection (yellow) to/from Radio R

5 - FM3 connection (black) from right side window antennas

6 - FM2 connection (brown) from rear window antennas

Left Antenna Module R108 , Avant, only radio generation II+

1 - Left window antennas connection

1. 1 - CLS
2. 2 - FM1/TS
3. 3 - AM

2 - CLS connection (gray) to Comfort System Central Control Module J393

3 - TS connection (yellow) to Auxiliary Heater Radio Receiver R64

4 - AM/FM1 connection (yellow) to Radio R

5 - FM2 connection (yellow) to Radio R

6 - FM2 connection (brown) from rear window antennas

Scheme 61

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. in Front Interior Light W1
2. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
3. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

4 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__radio-telephone-navigation-system-antenna-r52)

5 - Digital Sound System Control Module R12

1. behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing)

6 - Bass Loudspeaker R100

1. In parcel shelf
2. Removing and installing --> «Bass Loudspeaker R100 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-sedan-removing)

7 - Antenna Selection Control Module J515

1. behind roof end trim
2. Connections
3. Radio generation II+ connections
4. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

8 - Satellite radio R146

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing, activating --> «Satellite Radio R146 , removing and installing, activating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

9 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. in bottom of rear doors
2. Removing and installing

10 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. in top of rear doors
2. Removing and installing

11 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. in bottom of front doors
2. Removing and installing

12 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. in top of front doors
2. Removing and installing

13 - Radio R

1. in center console, at top
2. "Concert" connections
3. "Concert" , removing and installing --> «"Chorus" / "Concert" , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__chorus-concert-removing-and)
4. "Symphony" connections

1. Radio generation II+ connections
2. "Symphony" , removing and installing --> «"Symphony" radio, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-radio-removing-and-installing)
3. "Symphony II+" transport protection, activating/deactivating --> «"Symphony II+" in transport mode, activating/deactivating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-ii-in-transport-mode-activatingdeactivating)

Scheme 62

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Radio R

1. in center console, at top
2. "Concert" connections
3. "Concert" , removing and installing --> «"Chorus" / "Concert" , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__chorus-concert-removing-and)
4. "Symphony" connections

1. Radio generation II+ connections
2. "Symphony" , removing and installing --> «"Symphony" radio, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-radio-removing-and-installing)
3. "Symphony II+" transport protection, activating/deactivating --> «"Symphony II+" in transport mode, activating/deactivating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__symphony-ii-in-transport-mode-activatingdeactivating)

4 - Inside Microphone R74

1. in Front Interior Light W1
2. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
3. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

5 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing)

6 - Right rear window antennas

1. FM3

7 - Bass Loudspeaker R100

1. Behind luggage compartment right side trim
2. Removing and installing --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing)

8 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__radio-telephone-navigation-system-antenna-r52)

9 - Rear window antennas

1. FM2

10 - Satellite radio R146

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing, activating --> «Satellite Radio R146 , removing and installing, activating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

11 - Left Antenna Module R108

1. Behind luggage compartment left side trim
2. Connections
3. Only radio generation II+ connections
4. Removing and installing --> «Left Antenna Module R108 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

12 - Left rear window antennas

1. AM/FM1

13 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. In bottom of rear doors
2. Removing and installing

14 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

15 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors
2. Removing and installing

16 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors
2. Removing and installing

Satellite Radio R146 , sedan (through MY04), removing and installing

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove base mount --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 63

Adapter plate - 2 - with Satellite Radio R146 - 1 - is slid into top of base mount - 3 - on rear side and engaged.

1. Disconnect connectors on Satellite Radio R146 - 1 -.

The adapter plate must not be removed.

1. Press both catches on adapter plate - 2 - down in direction of arrow and remove Satellite Radio R146 - 1 - from plate - 2 -.

Installing

1. Install in reverse order.
2. Activate Satellite Radio R146.

Satellite Radio R146 , sedan (from MY05), removing and installing

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open luggage compartment.

Scheme 64

1. Remove bracket - 3 - from base mount - 4 - far enough so connectors can be reached.
2. Disconnect connectors on Satellite Radio R146 - 2 -.
3. Remove bracket - 3 - completely from base mount - 4 -.
4. Remove bolt - 1 - (3 Nm).

1. Remove Satellite Radio R146 - 2 - from bracket - 3 -.

Installing

1. Install in reverse order.
2. Activate Satellite Radio R146.

Satellite Radio R146 , Avant (through MY04), removing and installing

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove base mount --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 65

Adapter plate - 2 - with Satellite Radio R146 - 1 - is slid into top of base mount - 3 - on rear side and engaged.

1. Disconnect connectors on Satellite Radio R146 - 1 -.

The adapter plate must not be removed.

1. Press both catches on adapter plate - 2 - up in direction of arrow and remove Satellite Radio R146 - 1 - from plate - 2 -.

Installing

1. Install in reverse order.
2. Activate Satellite Radio R146.

Satellite Radio R146 , Avant (from MY05), removing and installing

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open luggage compartment.

Scheme 66

1. Remove bracket - 3 - from base mount - 4 - far enough so connectors can be reached.
2. Disconnect connectors on Satellite Radio R146 - 2 -.
3. Remove bracket - 3 - completely from base mount - 4 -.
4. Remove bolt - 1 - (3 Nm).

1. Remove Satellite Radio R146 - 2 - from bracket - 3 -.

Installing

1. Install in reverse order.
2. Activate Satellite Radio R146.

Satellite Radio R146 , activating

When using for first time or when replacing Satellite Radio R146 tuner, it must be enabled (activated) by the provider (XM or Sirius).

The subscription and application for activation can coincide with submission of all necessary data (US postal address, credit card number, radio ID (XM) or SID (Sirius)) to the providers call center.

Only SIRIUS

SIRIUS sends the activation sequence 6 times within the first hour after apply for the activation. If no successful activation results, another activation sequence must be requested at the SIRIUS call center.

Requirements

1. Customer has subscribed to XM or Sirius
2. Satellite Radio R146 is installed and connected
3. Radio R is adapted/coded accordingly
4. Ignition switched on

Procedure

1. Switch Radio R on and selection Satellite Radio R146 reception area.
2. Attempt to receive "free" channels in XM- (e.g. channel 1) or Sirius-band (only channel 184).
3. Change location if necessary.

If "free" channels can be received clearly, the activation information sent by the provider (XM or Sirius) can also be received clearly.

A poor reception situation can prevent a successful activation even though activation information is being broadcast. In this case, vehicle location must be changed (an activation is also possible while vehicle is moving). There are e.g. workshops, garages, parking buildings, underground garages, fuel filling stations with extensive roofs and all other parking areas with signal shadows must be avoided.

In built-up areas with terrestial radio system coverage and in inner-cities, it is possible to activate using a repeater instead of the satellite.

Radio, Telephone, Navigation System Antenna R52 , sedan, removing and installing

The antenna wires are placed on the left and right D-pillars.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove left and right D-pillar trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
3. Remove Rear Courtesy Light W43 --> - «96 LIGHTS, SWITCHES - INTERIOR, ANTI-THEFT»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment) .
4. Lower the rear molded headliner --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 67

1. Disconnect antenna wiring connection - arrow - at right of D-pillar.

Scheme 68

1. Disconnect antenna wiring connection - arrow - at left of D-pillar.
2. Loosen antenna wires up to Radio, Telephone, Navigation System Antenna R52.

Scheme 69

1. Remove nut - arrow - (6 Nm).
2. Remove Radio, Telephone, Navigation System Antenna R52 upward from roof.

Installing

1. Install in reverse order.

The washer under the Radio, Telephone, Navigation System Antenna R52 nut has a cut-out through which the antenna wires must be guided.

Radio, Telephone, Navigation System Antenna R52 , Avant, removing and installing

The Radio, Telephone, Navigation System Antenna R52 antenna wires are routed differently. The antenna wires for Navigation System with CD Drive Control Module J401 and Satellite Radio R146 are routed to the left up to the devices in the base mount at the left of the luggage compartment while the Telephone Antenna R65 is placed on the right D-pillar.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove left and right D-pillar trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
3. Remove Luggage Compartment Light W3 --> - «96 LIGHTS, SWITCHES - INTERIOR, ANTI-THEFT»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment) .
4. Remove left luggage compartment trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. Lower the rear molded headliner --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 70

1. Disconnect antenna wiring connection - arrow - at right of D-pillar.
2. Loosen antenna wires up to devices in base mount.

1. Remove nut - arrow - (6 Nm).
2. Remove Radio, Telephone, Navigation System Antenna R52 upward from roof.

Installing

1. Install in reverse order.

The washer under the Radio, Telephone, Navigation System Antenna R52 nut has a cut-out through which the antenna wires must be guided.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Telephone systems

1. Telephone fixed installation
2. Cellular telephone preparation

With the cell phone preparation with Bluetooth Antenna R152 , all Cellular Telephones R54 approved by Audi can be operated with the Bluetooth interface.

Information on operation and approved cellular phone types

1. www.audi.de/telefon

It is not possible to connect other devices via Bluetooth, for example headset, laptop, PDA, or similar.

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Scheme 71

1 - Telephone Handset R37 on top of instrument panel/in center armrest

2 - Inside Loudspeaker R70 (vehicles without radio) in front center of instrument panel

3 - Radio R in upper center console

4 - Sound system

5 - Telephone Transceiver R36 in electronics box under right front seat

6 - Telephone Antenna R65 , sedan: behind roof end trim/Avant: Roof antenna

7 - Fax Machine R73 (Fax/laptop connector) in bottom of center console

8 - Telephone Microphone R38 in Front Interior Light W1

Scheme 72

1 - Telephone Baseplate R126 with Cellular Telephone R54 on top of instrument panel

2 - Inside Loudspeaker R70 (vehicles without radio) in front center of instrument panel

3 - Radio R / in top of center console

4 - Sound system

5 - Operating Electronics and Telephone Control Module J412 in electronics box under right front seat

6 - Telephone Microphone R38 in Front Interior Light W1

7 - Telephone Amplifier R86 behind luggage compartment right side trim

8 - Telephone Antenna R65 , sedan: behind roof end trim/Avant: Roof antenna

Scheme 73

1 - Telephone Baseplate R126 on top of instrument panel/in center armrest

2 - Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503 in top of center console

3 - Sound system

4 - Bluetooth Antenna R152 at Telephone Transceiver R36

5 - Telephone Transceiver R36 in electronics box under right front seat

6 - Telephone Microphone R38 in Front Interior Light W1

7 - Telephone Amplifier R86 behind luggage compartment right side trim

8 - Telephone Antenna R65 , sedan: behind roof end trim/Avant: Roof antenna

Scheme 74

1 - Multi-pin connector, 18-pin (T18b) black, behind glove compartment

2 - Radio, Telephone, Navigation System Antenna R52

3 - Telephone Microphone R38

4 - Radio R

5 - Sound system

6 - Terminal 15

7 - Terminal 30

8 - Terminal 31

Scheme 75

Connectors

A - Operating Electronics and Telephone Control Module J412

B - Multi-pin connector, 20-pin (T20), red, to Telephone Baseplate R126

C - Black 18-pin multi-pin harness connector (T18)

Note. Unlisted connector terminals are not assigned.

Scheme 76

C - Black 18-pin multi-pin harness connector (T18)

1 - Terminal 31

3 - Speed signal

4 - NF mute to Radio R / Operating Electronics, Navigation Control Module J402

7 - Inside Loudspeaker R70 (-)

9 - Microphone input (-) from Telephone Microphone R38

10 - Terminal 15

11 - Terminal 30

12 - Terminal 58s

13 - Signal "cellular telephone ON" to Telephone Amplifier R86

16 - Inside Loudspeaker R70 (+)

18 - Microphone input (+) from Telephone Microphone R38 (+)

Scheme 77

Connectors

A - Bluetooth Antenna R152 connection (yellow)

B - Black 54-pin multi-pin harness connector

Note. Unlisted connector terminals are not assigned.

B - Black 54-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

3 - Signal "cellular telephone ON" to Telephone Amplifier R86

8 - NF (+) to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

9 - NF (-) to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

11 - Microphone input (+) Telephone Microphone R38 / Navigation System with CD Drive Control Module J401

12 - Microphone input (-) Telephone Microphone R38 / Navigation System with CD Drive Control Module J401

15 - K diagnostic

16 - NF mute to Radio R / Navigation System with CD Drive Control Module J401

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

37 - Terminal 30 to Telephone Baseplate R126

39 - Terminal 31 to Telephone Baseplate R126

41 - Terminal 30 to Telephone Baseplate R126

42 - Microphone output (+) to Telephone Baseplate R126

43 - Microphone output (-) to Telephone Baseplate R126

44 - Terminal 31 (screen ground)

45 - NF (+) from Telephone Baseplate R126

46 - NF (-) from Telephone Baseplate R126

47 - SNDREQ signal from Telephone Baseplate R126

49 - Ser-Tx (+) to Telephone Baseplate R126

50 - Ser-Tx (-) to Telephone Baseplate R126

51 - Ser-Rx (+) from Telephone Baseplate R126

52 - Ser-Rx (-) from Telephone Baseplate R126

Scheme 78

Connectors

1 - Black 46-pin multi-pin harness connector (T46)

2 - Black 10-pin multi-pin harness connector (T10m)

Note. Unlisted connector terminals are not assigned.

Scheme 79

1 - Black 46-pin multi-pin harness connector (T46)

1 - NF (-) Inside Loudspeaker R70 / Radio R / Speech Input Control Module J507

2 - NF (+) Inside Loudspeaker R70 / Radio R / Speech Input Control Module J507

3 - Telephone Handset R37 pin 8

4 - Telephone Handset R37 pin 7

5 - Telephone Handset R37 pin 5

6 - Telephone Handset R37 pin 4

12 - Screen ground to Fax Machine R73

13 - Fax Machine R73 pin 6 (CTS)

14 - Fax Machine R73 pin 3 (TXD)

18 - Telephone Handset R37 pin 9

19 - Telephone Handset R37 pin 1

20 - Telephone Handset R37 pin 3

27 - Fax Machine R73 pin 5 (RTS)

28 - Fax Machine R73 pin 2 (RXD)

29 - Fax Machine R73 pin 7 (ground)

30 - Microphone input (+) Telephone Microphone R38 / Speech Input Control Module J507

31 - Microphone input (-) Telephone Microphone R38 / Speech Input Control Module J507

32 - Telephone Handset R37 pin 10

33 - Telephone Handset R37 pin 6

34 - Telephone Handset R37 pin 2

35 - Telephone Handset R37 (screen ground)

38 - CAN-Bus High (Infotainment)

39 - CAN-Bus Low (Infotainment)

41 - K diagnostic

42 - Fax Machine R73 pin 4 (DTR)

43 - Fax Machine R73 pin 1 (DCD)

Scheme 80

2 - Black 10-pin multi-pin harness connector (T10m)

1 - Terminal 30

2 - NF mute to Radio R / Speech Input Control Module J507

3 - Terminal 15

4 - Terminal 31

5 - Terminal 31

6 - Terminal 30

7 - Terminal 30

10 - Terminal 31

A1 - GSM connection from Telephone Antenna R65

Scheme 81

Connectors

A - GSM connection (purple) from Telephone Antenna R65

B - Black 3-pin multi-pin harness connector

C - Antenna connection (purple) to Cellular Telephone R54

Note. Unlisted connector terminals are not assigned.

B - Black 3-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

3 - Signal "cellular telephone ON" from Telephone Transceiver R36

Cell phone preparation preliminary setup

Note. Unlisted connector terminals are not assigned.

Black 18-pin multi-pin harness connector (T18b)

1 - Terminal 31

4 - NF mute to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

7 - NF (-) to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

9 - Microphone input (-) from Telephone Microphone R38

10 - Terminal 15

11 - Terminal 30

16 - NF (+) to Radio R / Navigation System with CD Drive Control Module J401 / Radio/Navigation Display Control Module J503

18 - Microphone input (+) from Telephone Microphone R38

Scheme 82

Connectors

A - Black 12-pin multi-pin harness connector (T12)

B - GSM connection (purple) from Telephone Antenna R65 / Telephone Amplifier R86

Note. Unlisted connector terminals are not assigned.

Black 12-pin multi-pin harness connector (T12)

1 - Ser Tx (+) to Telephone Transceiver R36

2 - Terminal 30 from Telephone Transceiver R36

3 - Ser Rx (+) from Telephone Transceiver R36

4 - Terminal 31 from Telephone Transceiver R36

5 - Microphone input (+) from Telephone Transceiver R36

6 - NF (+) to Telephone Transceiver R36

7 - Ser Tx (-) to Telephone Transceiver R36

8 - Terminal 30 from Telephone Transceiver R36

9 - Ser Rx (-) from Telephone Transceiver R36

10 - SNDREQ signal to Telephone Transceiver R36

11 - Microphone input (+) from Telephone Transceiver R36

12 - NF (-) to Telephone Transceiver R36

Scheme 83

1 - Inside Loudspeaker R70

1. Vehicles without radio
2. In front instrument panel, center
3. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

2 - Telephone Base plate R126

1. On top of instrument panel
2. Connections
3. Removing and installing
4. in center armrest

1. Removing and installing

3 - Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Telephone Antenna R65

1. Behind roof end trim
2. Removing and installing --> «Telephone Antenna R65 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-antenna-r65-sedan-removing)

5 - Telephone Amplifier R86

1. Only with cell phone preparation
2. Behind luggage compartment right side trim
3. Connections
4. Removing and installing --> «Telephone Amplifier R86 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-amplifier-r86-sedan-removing)

6 - Telephone Transceiver R36

1. In electronics box under right front seat
2. Pin assignment for telephone (fixed installation)
3. removing and installing (fixed installation telephone) --> «Telephone Transceiver R36 (telephone, fixed installation), removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-transceiver-r36-telephone-fixed-installation)
4. Operating Electronics and Telephone Control Module J412 connectors.

1. Connectors (cell phone preparation)
2. Removing and installing --> «Telephone Transceiver R36 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-transceiver-r36-removing-and)

Scheme 84

1 - Inside Loudspeaker R70

1. Vehicles without radio
2. In front instrument panel, center
3. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

2 - Telephone Base plate R126

1. On top of instrument panel
2. Connections
3. Removing and installing
4. In center armrest

1. Removing and installing

3 - Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Telephone Amplifier R86

1. Only with cell phone preparation
2. Behind luggage compartment right side trim
3. Connections
4. Removing and installing --> «Telephone Amplifier R86 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-amplifier-r86-avant-removing)

5 - Telephone Antenna R65 , roof antenna

1. Removing and installing --> «Telephone Antenna R65 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-antenna-r65-avant-removing)

6 - Telephone Transceiver R36

1. In electronics box under right front seat
2. Pin assignment for telephone (fixed installation)
3. Removing and installing (fixed installation telephone) --> «Telephone Transceiver R36 (telephone, fixed installation), removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-transceiver-r36-telephone-fixed-installation)
4. Operating Electronics and Telephone Control Module J412 connectors.

1. Connectors (cell phone preparation)
2. Removing and installing --> «Telephone Transceiver R36 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-transceiver-r36-removing-and)

Scheme 85

1 - Mount

1. Placed in center console from behind

2 - Center console

1. With holes for base plate
2. Create holes --> - «68 - INTERIOR EQUIPMENT»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

3 - Mounting plate

4 - Base plate

1. For handset/cell phone mount

5 - 1 Nm

6 - 2 Nm

7 - Black 12-pin multi-pin harness connector (T12)

1. Ensure connector is seated correctly.

Black 12-pin multi-pin harness connector (T12)

1 - Ser Tx (+) to Telephone Transceiver R36

2 - Terminal 30 from Telephone Transceiver R36

3 - Ser Rx (+) from Telephone Transceiver R36

4 - Terminal 31 from Telephone Transceiver R36

5 - Microphone input (+) from Telephone Transceiver R36

6 - NF (+) to Telephone Transceiver R36

7 - Ser Tx (-) to Telephone Transceiver R36

8 - Terminal 30 from Telephone Transceiver R36

9 - Ser Rx (-) from Telephone Transceiver R36

10 - SNDREQ signal to Telephone Transceiver R36

11 - Microphone input (+) from Telephone Transceiver R36

12 - NF (-) to Telephone Transceiver R36

Telephone Baseplate R126 in center armrest

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove Cellular Telephone R54 from Telephone Baseplate R126 and unclip it.

Scheme 86

1. Beginning at front - arrow - , carefully pry storage compartment - 1 - out of trim - 2 -.

Scheme 87

1. Remove bolts - arrows - (2 Nm) from underside of storage compartment.

Scheme 88

1. Disconnect connector - 1 - and remove bolts - arrows - (1 Nm).
2. Disconnect remaining connectors and remove Telephone Baseplate R126.

Installing

1. Install in reverse order.

Telephone Transceiver R36 , removing and installing

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove right A-pillar trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove right front seat --> - «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Note. Safety belt on seat frame must not be loosened. Fold back the floor mat --> - 70 - INTERIOR TRIM .

Scheme 89

1. Release electronics box cover - arrows - and remove it.

Scheme 90

1. Disconnect connectors - 1 - and - 3 - on Telephone Transceiver R36 - 2 -.
2. Pry Telephone Transceiver R36 - 2 - out of E-box.
3. If present, remove Bluetooth Antenna R152.

Installing

1. Install in reverse order.

Telephone Transceiver R36 (telephone, fixed installation), removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove right A-pillar trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove right front seat --> - «72 - SEAT - FRAMES»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Note. Safety belt on seat frame must not be loosened. Fold back the floor mat --> - 70 - INTERIOR TRIM .

1. Release electronics box cover - arrows - and remove it.

Scheme 91

1. Disconnect connectors - 2 - on Telephone/Telematics Control Module J526 - 1 -.
2. Remove Telephone/Telematics Control Module J526 - 1 - from electronics box.

Installing

1. Install in reverse order.
2. Perform adaptations and coding on Telephone/Telematics Control Module J526 if necessary.

Telephone Amplifier R86 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove Amplifier R12 --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and) / BOSE Amplifier R12 --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing) .

Scheme 92

1. Disconnect connectors - 3 - on Telephone Amplifier R86 - 2 -.
2. Remove bolts - 1 - (2 Nm) and remove Telephone Amplifier R86 - 2 -.

Installing

1. Install in reverse order.

Telephone Amplifier R86 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Before removing Telephone Amplifier R86 , Bass Loudspeaker R100 must be removed.

1. Remove luggage compartment right side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove Bass Loudspeaker R100 --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing) .

Scheme 93

1. Remove nuts - 3 - (3 Nm) and remove Telephone Amplifier R86 - 2 - downward.
2. Disconnect connectors on Telephone Amplifier R86 - 2 -.
3. Remove bolts - 1 - (2 Nm) and remove Telephone Amplifier R86 - 2 - from bracket.

Installing

1. Install in reverse order.

Telephone Microphone R38 , removing and installing

Special tools, testers and auxiliary items required

1. Special hook 3370

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Carefully remove cover from Front Interior Light W1 in - direction of arrow - using Special Hook 3370.

Scheme 94

1. Disconnect connector - 1 - on Telephone Microphone R38.
2. Unclip Telephone Microphone R38 - 3 - from bracket in cover - 2 -.

Installing

1. Install in reverse order.

Telephone Antenna R65 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 95

1. Disconnect harness connector - 1 - at Telephone Antenna R65 - 2 -.
2. Pull off Telephone Antenna R65 - 2 - downward from edge of roof end trim - arrows -.

Installing

1. Install in reverse order.

Scheme 96

1. When installing, ensure retaining clips on Telephone Antenna R65 - arrows - engage in mounts in edge of roof end trim.

Telephone Antenna R65 , Avant, removing and installing

The roof antenna on the Avant consists of the Telephone Antenna R65 and Navigation System Antenna R50.

The wire for the Navigation System Antenna R50 is routed up to the devices in the left luggage compartment base mount.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove left and right D-pillar trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
3. Remove Luggage Compartment Light W3 --> - «96 LIGHTS, SWITCHES - INTERIOR, ANTI-THEFT»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment) .
4. Remove luggage compartment left side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. Lower the rear molded headliner --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Disconnect Navigation System Antenna R50 wire at control module in base mount.

1. Disconnect Telephone Antenna R65 wire - arrow - on right D-pillar.
2. Loosen antenna wires up to roof antenna.

1. Remove nut - arrow - (6 Nm).
2. Remove Telephone Antenna R65 upward from roof.

Installing

1. Install in reverse order.

The washer under the Telephone Antenna R65 nut has a cut-out through which the antenna lines must be guided.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Cellular telephone preparation

1. Telephone Transceiver R36
2. Radio, Telephone, Navigation System Antenna R52
3. Telephone Baseplate R126 with Cellular Telephone R54
4. Telephone Microphone R38

The Telephone Transceiver R36 is equipped with a Bluetooth Antenna R152. Using this, all Cellular Telephones R54 approved by Audi can be operated with the Bluetooth interface with the cell phone preparation installed in the vehicle.

It is not possible to connect other devices via Bluetooth, for example headset, laptop, PDA, or similar.

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Scheme 97

1 - Telephone Baseplate R126 with Cellular Telephone R54 on top of instrument panel/in center armrest

2 - Radio R / Navigation System with CD Drive Control Module J401 in top of center console

3 - Sound system

4 - Bluetooth Antenna R152 at Telephone Transceiver R36

5 - Telephone Transceiver R36 in electronics box under right front seat

6 - Telephone Microphone R38 in Front Interior Light W1

7 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Telephone Transceiver R36

Connectors

A - Bluetooth Antenna R152 connection (yellow)

B - Black 54-pin multi-pin harness connector

Note. Unlisted connector terminals are not assigned.

B - Black 54-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

8 - NF (+) out to Radio R / Navigation System with CD Drive Control Module J401

9 - NF (-) out to Radio R / Navigation System with CD Drive Control Module J401

10 - Terminal 31 (screen ground) (not used)

11 - Microphone input (+) Telephone Microphone R38 / Navigation System with CD Drive Control Module J401

12 - Microphone input (-) Telephone Microphone R38 / Navigation System with CD Drive Control Module J401

15 - K diagnostic

16 - NF mute to Radio R / Navigation System with CD Drive Control Module J401

17 - CAN-Bus High (Infotainment)

18 - CAN-Bus Low (Infotainment)

37 - Terminal 30 to Telephone Baseplate R126

39 - Terminal 31 to Telephone Baseplate R126

41 - Terminal 30 to Telephone Baseplate R126

42 - Microphone output (+) to Telephone Baseplate R126

43 - Microphone output (-) to Telephone Baseplate R126

44 - Terminal 31 (screen ground)

45 - LF input (+) from Telephone Baseplate R126

46 - LF input (-) from Telephone Baseplate R126

47 - SNDREQ signal from Telephone Baseplate R126

49 - Ser-Tx (+) to Telephone Baseplate R126

50 - Ser-Tx (-) to Telephone Baseplate R126

51 - Ser-Rx (+) from Telephone Baseplate R126

52 - Ser-Rx (-) from Telephone Baseplate R126

Telephone Base plate R126

Connectors

A - Black 12-pin multi-pin harness connector (T12)

B - GSM connection (purple) from Telephone Antenna R65

Note. Unlisted connector terminals are not assigned.

Black 12-pin multi-pin harness connector (T12)

1 - Ser Tx (+) to Telephone Transceiver R36

2 - Terminal 30 from Telephone Transceiver R36

3 - Ser Rx (+) from Telephone Transceiver R36

4 - Terminal 31 from Telephone Transceiver R36

5 - Microphone input (+) from Telephone Transceiver R36

6 - NF (+) to Telephone Transceiver R36

7 - Ser Tx (-) to Telephone Transceiver R36

8 - Terminal 30 from Telephone Transceiver R36

9 - Ser Rx (-) from Telephone Transceiver R36

10 - SNDREQ signal to Telephone Transceiver R36

11 - Microphone input (+) from Telephone Transceiver R36

12 - NF (-) to Telephone Transceiver R36

Total overview - Sedan component locations

1 - Inside Loudspeaker R70

1. Vehicles without radio
2. In front instrument panel, center
3. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

2 - Telephone Base plate R126

1. On top of instrument panel
2. Connections
3. Removing and installing
4. in center armrest

1. Removing and installing

3 - Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__radio-telephone-navigation-system-antenna-r52)

5 - not installed

6 - Telephone Transceiver R36

1. In electronics box under right front seat
2. Connections --> «Connectors and connector assignments»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Telephone Transceiver R36 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-transceiver-r36-removing-and)

General overview - Avant component locations

1 - Inside Loudspeaker R70

1. Vehicles without radio
2. In front instrument panel, center
3. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

2 - Telephone Base plate R126

1. on top of instrument panel
2. Connections
3. Removing and installing
4. In center armrest

1. Removing and installing

3 - Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - not installed

5 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__radio-telephone-navigation-system-antenna-r52)

6 - Telephone Transceiver R36

1. In electronics box under right front seat
2. Connections --> «Connectors and connector assignments»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Telephone Transceiver R36 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-transceiver-r36-removing-and)

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Description

BNS 4.0 (Nav IV) navigation system is an enhancement of the established navigation system III.

Important improvements are, e.g. connection to CAN BUS (Infotainment) and dynamic route guidance.

The navigation system receives the information for dynamic route guidance from the Radio R TMC function or via the Telephone Transceiver R36.

The system consists of

1. Function Selector Switch II E272
2. Instrument cluster (display unit)
3. Navigation System with CD Drive Control Module J401
4. Navigation System Antenna R50

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Scheme 98

1 - Instrument cluster in instrument panel

2 - Function Selector Switch II E272 in lower center console

3 - Inside Loudspeaker R70 (vehicles without radio) in front center of instrument panel

4 - Sound system

5 - Radio R in upper center console

6 - Navigation System Antenna R50 , sedan: behind roof end trim/Avant: in roof antenna

7 - Telephone Transceiver R36 in electronics box under right front seat

8 - Navigation System with CD Drive Control Module J401 behind luggage compartment left side trim

Scheme 99

Connectors

1 - GPS connection (blue) from Navigation System Antenna R50

2 - Antenna connection bracket

3 - Multi-pin connector I, 20-pin, (T20e) black

4 - Device fuse

5 - 8-pin multi-pin connector II (not used)

6 - 8-pin multi-pin connector III, black (T8e)

7 - 10-pin multi-pin connector IV (not used)

Note. Unlisted connector terminals are not assigned.

3 - Multi-pin connector I, 20-pin, (T20e) black

2 - CAN-Bus High (Infotainment)

5 - CAN-Bus Low (Infotainment)

13 - LF (+) to Radio R

14 - NF mute to Radio R

15 - LF (-) to Radio R

16 - NF (+) from Telephone Transceiver R36

17 - NF mute from Telephone Transceiver R36

19 - NF (-) from Telephone Transceiver R36

6 - Multi-pin connector III, 8-pin, (T8e) black

1 - Speed signal

2 - Signal from Back-Up Light Switch F4

3 - L-diagnostic

4 - Terminal 15

7 - Terminal 30

8 - Terminal 31

Scheme 100

1 - Radio R

1. In center console, at top

2 - Instrument cluster display

1. Instrument cluster, removing and installing --> - «90 INSTRUMENTS»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment)

3 - Function Selector Switch II E272

1. In center console, bottom
2. Removing and installing --> «Function Selector Switch II E272 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__function-selector-switch-ii-e272)

4 - Navigation System Antenna R50

1. Behind roof end trim
2. Removing and installing --> «Navigation System Antenna R50 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-sedan)

5 - Navigation System with CD Drive Control Module J401

1. Behind luggage compartment left side trim
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-with-cd-drive-control)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-with-cd-drive-control)

6 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors

7 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors

Scheme 101

1 - Radio R

1. In center console, at top

2 - Instrument cluster display

1. Instrument cluster, removing and installing --> - «90 INSTRUMENTS»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment)

3 - Function Selector Switch II E272

1. In center console, bottom
2. Removing and installing --> «Function Selector Switch II E272 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__function-selector-switch-ii-e272)

4 - Navigation System Antenna R50 roof antenna

1. Removing and installing --> «Navigation System Antenna R50 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-avant)

5 - Navigation System with CD Drive Control Module J401

1. Behind luggage compartment left side trim
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-with-cd-drive-control)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-with-cd-drive-control)

6 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors

7 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors

Navigation System with CD Drive Control Module J401 , removing and installing

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open left luggage compartment storage bin.

Scheme 102

1. Insert two clips on Radio Removal Tool T10057 into release slits on Navigation System with CD Drive Control Module J401 - 2 - until they engage. Points on grip eyes face outward.
2. Remove Navigation System with CD Drive Control Module J401 - 2 - from installation frame - 1 -.
3. Disconnect connectors on Navigation System with CD Drive Control Module J401 - 2 -.
4. Remove Radio Release Tool T10057 by pressing locking tabs on Navigation System with CD Drive Control Module J401.

Installing

1. Connect all harness connectors.
2. Slide Navigation System with CD Drive Control Module J401 in until it engages in mounting frame.
3. If necessary, perform adaptations on Navigation System with CD Drive Control Module J401.

Function Selector Switch II E272 , removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Scheme 103

1. Open cigarette lighter cover - 2 -.
2. Press Function Selector Switch II E272 - 1 - out of installation opening from below as shown in illustration.
3. Disconnect connector at Function Selector Switch II E272.

Installing

1. Install in reverse order.

Navigation System Antenna R50 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 104

1. Release retaining clips - arrows - and remove cover Navigation System Antenna R50 - 1 -.
2. Disconnect harness connector - 2 - on Navigation System Antenna R50 - 1 -.

Installing

1. Install in reverse order.

Navigation System Antenna R50 , Avant, removing and installing

The roof antenna on the Avant consists of the Telephone Antenna R65 and Navigation System Antenna R50.

The Navigation System Antenna R50 wire is routed up to the devices in the left luggage compartment base mount while the Telephone Antenna R65 is placed on the right D-pillar.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove roof end trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
2. Remove left and right D-pillar trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .
3. Remove Luggage Compartment Light W3 --> - «96 LIGHTS, SWITCHES - INTERIOR, ANTI-THEFT»(/audi/a4/b7-2004-2009/remont/cruise-control-systems/#electrical-equipment) .
4. Remove luggage compartment left side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. Lower the rear molded headliner --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. Disconnect Telephone Antenna R65 wire - arrow - on right D-pillar.
2. Disconnect connectors at Navigation System with CD Drive Control Module J401.
3. Loosen antenna wires up to roof antenna.

1. Remove nut - arrow - (7 Nm).
2. Remove Navigation System Antenna R50 upward from roof.

Installing

1. Install in reverse order.

The washer under the Navigation System Antenna R50 nut has a cut-out through which the antenna wires must be guided.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Description

The Radio Navigation System (RNS) combines the functions of a navigation system with those of a vehicle radio.

The system consists of

1. Radio receiver part
2. 5-inch color display
3. Navigation system with angular acceleration sensor
4. CD drive for navigation system

1. Navigation System Antenna R50 connection
2. Antenna Selection Control Module J515 / Left Antenna Module R108 connection

Enhancements

1. CD Changer R41 connection
2. Navigation/TV Tuner J415 connection

Notes

Additional information Navigation system plus operating instructions.

For CD preparation, the CD changer R41 wiring harness is already installed in the vehicle. The connecting wire can only be used with genuine Audi CD-changers R41.

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Error messages on screen

If there is a malfunction in the system, either a fault is saved in the DTC and/or an error message is given on the Operating Electronics, Navigation Control Module J402 display.

Indicator in display

This error message appears

1. No or faulty CAN communication between Operating Electronics, Navigation Control Module J402 and Navigation Interface R94 (wiring interruption or wiring not connected).
2. Navigation Interface R94 is faulty.

If this malfunction occurs, no RDS TMC traffic messages can be received and setting menu "Traffic jam function" cannot be called up.

Indicator in display

This error message appears

1. No or faulty CAN communication between Operating Electronics, Navigation Control Module J402 and Telephone/Telematics Control Module J256 (wiring interruption or wiring not connected).
2. Telephone/Telematics Control Module J256 is faulty.
3. Terminal 15 is off (ignition switched off).

If this malfunction occurs, telephone cannot receive TMC traffic messages. Dynamic route guidance is not possible and the "Traffic Jam Function" setting menu cannot be called up.

Indicator in display

This error message appears

1. No or faulty CAN communication between Operating Electronics, Navigation Control Module J402 and Chip Card Reader R99 (electronic route book)
2. Chip Card Reader R99 not connected or faulty.

If this malfunction occurs, data cannot be read from the Chip Card Reader R99 into the Operating Electronics, Navigation Control Module J402 and also cannot be collected on the chip card.

Indicator in display

This message appears

1. If the customer has not yet activated his electronic route book chip card on his PC after vehicle delivery.
2. This message in the navigation display is not a malfunction.

Make customer aware of this.

Indicator in display

This message appears

1. When no DX version navigation CD was inserted.

1. Inset navigation CD with DX logo.

Make customer aware of this.

Messages are shown until malfunction is corrected or confirmed by pressing RETURN button.

Scheme 105

1 - Navigation/TV Tuner J415 behind luggage compartment left side trim

2 - CD Changer R41 in glove compartment

3 - Operating Electronics, Navigation Control Module J402 in top of center console

4 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

5 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

6 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

7 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

8 - Inside Loudspeaker R70 in front center instrument panel

9 - Bass Loudspeaker R100 in parcel shelf

10 - Amplifier R12 behind luggage compartment right side trim

11 - Navigation System Antenna R50 behind roof end trim

12 - Navigation Interface R94 behind luggage compartment left side trim

13 - Antenna Selection Control Module J515 behind roof end trim

14 - Rear window antennas AM/FM/TV

Scheme 106

1 - Right rear FM3/TV3/TV4 window antennas

2 - left rear AM/FM1/TV1 window antennas

3 - FM2/TV2 rear window antennas

4 - Left Antenna Module R108 behind luggage compartment left side trim

5 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

6 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

7 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

8 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

9 - Amplifier R12 behind luggage compartment right side trim

10 - Bass Loudspeaker R100 behind luggage compartment right side trim

11 - Inside Loudspeaker R70 in front center instrument panel

12 - CD Changer R41 in glove compartment

13 - Navigation System Antenna R50 roof antenna

14 - Operating Electronics, Navigation Control Module J402 in top of center console

15 - Navigation/TV Tuner J415 behind luggage compartment left side trim

16 - Navigation Interface R94 , behind luggage compartment left side trim

17 - Right Antenna Module R109 behind luggage compartment right side trim

Scheme 107

1 - Navigation/TV Tuner J415 behind luggage compartment left side trim

2 - CD Changer R41 in glove compartment

3 - Operating Electronics, Navigation Control Module J402 in top of center console

4 - Amplifier R12 behind luggage compartment right side trim

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

8 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

9 - Bass Loudspeaker R100 in parcel shelf

10 - Inside Loudspeaker R70 in front center instrument panel

11 - Inside Microphone R74 in Front Interior Light W1

12 - Navigation System Antenna R50 behind roof end trim

13 - Navigation Interface R94 behind luggage compartment left side trim

14 - Antenna Selection Control Module J515 behind roof end trim

15 - AM/FM/TV rear window antennas

Scheme 108

1 - Right rear FM3/TV3/TV4 window antennas

2 - left rear AM/FM1/TV1 window antennas

3 - FM2/TV2 rear window antennas

4 - Left Antenna Module R108 behind luggage compartment left side trim

5 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

6 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

7 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

8 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

9 - Bass Loudspeaker R100 behind luggage compartment right side trim

10 - Inside Loudspeaker R70 in front center instrument panel

11 - Amplifier R12 behind luggage compartment right side trim

12 - Inside Microphone R74 in Front Interior Light W1

13 - CD Changer R41 in glove compartment

14 - Navigation System Antenna R50 roof antenna

15 - Operating Electronics, Navigation Control Module J402 in top of center console

16 - Navigation/TV Tuner J415 , behind luggage compartment left side trim

17 - Navigation Interface R94 behind luggage compartment left side trim

18 - Right Antenna Module R109 behind luggage compartment right side trim

Scheme 109

1 - HF connection (black) from Navigation Interface R94

2 - Fan

3 - IF connection (yellow) to Antenna Selection Control Module J515 / Left Antenna Module R108

4 - 11-pin multi-pin connector (T11) from Navigation/TV Tuner J415

5 - Ground connection

6 - Connector block with three multi-pin connectors and device fuse

7 - GPS connection (blue) from Navigation System Antenna R50

8 - Fan

9 - Black 26-pin multi-pin connector (T26)

Note. Unlisted connector terminals are not assigned.

Scheme 110

4 - 11-pin multi-pin connector (T11)

1 - Audio ground from Navigation/TV Tuner J415

2 - Left audio input from Navigation/TV Tuner J415

3 - Right audio input from Navigation/TV Tuner J415

4 - Video input sync. from Navigation/TV Tuner J415

5 - Video ground from Navigation/TV Tuner J415

6 - Switch A (NTSC=60Hz/PAL=50Hz) (not used)

7 - Switch B (Monitor On) (not used)

8 - Video input blue from Navigation/TV Tuner J415

9 - Video input green from Navigation/TV Tuner J415

10 - Video input red from Navigation/TV Tuner J415

11 - Screen ground from Navigation/TV Tuner J415

Scheme 111

6 - Multi-pin connector I, 20-pin, (T20d) black

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12 (only with BOSE)

5 - Right front signal to Amplifier R12 (only with BOSE)

6 - Positive switched to Amplifier R12

7 - NF (+) from Telephone Transceiver R36

10 - CD ground to CD Changer R41

12 - NF (-) from Telephone Transceiver R36

13 - CD data in from CD Changer R41

14 - CD data out to CD Changer R41

15 - CD CLK from CD Changer R41

16 - Permanent positive to CD Changer R41

17 - Positive switched to CD Changer R41

18 - CD ground to CD Changer R41

19 - Left signal from CD Changer R41

20 - Right signal from CD Changer R41

6 - Multi-pin connector II, 8-pin, (T8a) brown

3 - Right front speaker (+) (not with BOSE)

4 - Right front speaker (-) (not with BOSE)

5 - Left front speaker (+) (not with BOSE)

6 - Left front speaker (-) (not with BOSE)

6 - Multi-pin connector III, 8-pin, (T8) black

1 - Speed signal

2 - NF mute from Telephone Transceiver R36

3 - L-diagnostic

4 - Terminal 86s

5 - SAFE (terminal 30) connected with pin 7

6 - Terminal 58s

7 - Terminal 30

8 - Terminal 31

Scheme 112

9 - Black 26-pin multi-pin connector (T26)

1 - Anti-theft warning system ground from Comfort System Central Control Module J393

4 - Terminal 15

5 - Left speed sensor input

6 - FAW NF (+) (not used)

13 - CAN-BUS High (BOSCH)

14 - Positive switched (not used)

17 - Signal from Back-Up Light Switch F4

18 - Right speed sensor input (not used)

19 - FAW NF (-) (not used)

20 - FAW NF (screen) (not used)

26 - CAN-BUS Low (BOSCH)

Scheme 113

1 - TV4 connection (brown) from Antenna Selection Control Module J515 / Right Antenna Module R109

2 - TV3 connection (brown) from Antenna Selection Control Module J515 / Right Antenna Module R109

3 - TV2 connection (green) to Antenna Selection Control Module J515 / Left Antenna Module R108

4 - TV1 connection (green) to Antenna Selection Control Module J515 / Left Antenna Module R108

5 - Black 54-pin (T54) multi-pin connector to Operating Electronics, Navigation Control Module J402

Note. Unlisted connector terminals are not assigned.

Scheme 114

5 - Black 54-pin multi-pin harness connector (T54)

2 - CAN BUS Low (BOSCH) from RNS-E (Infotainment)

3 - CAN BUS High (BOSCH) from RNS-E (Infotainment)

4 - Front audio screen (not used)

5 - Right front audio output

6 - Audio ground (not used)

7 - Left front audio output

8 - Audio ground

9 - Front screen ground

10 - Front video screen

11 - Front sync. video output

12 - Video ground

13 - Front blue audio output

14 - Video ground

15 - Front green video output

16 - Video ground

17 - Front red video output

19 - Terminal 31

20 - Terminal 30

21 - L-diagnostic

22 - Right rear video output (-) (not used)

23 - Right rear video output (+) (not used)

24 - Rear audio screen (not used)

25 - Left rear video output (-) (not used)

26 - Left rear video output (+) (not used)

27 - Rear screen ground (not used)

28 - Rear com. sync. (-) (not used)

29 - Rear com. sync. (+) (not used)

30 - Rear blue signal (-) (not used)

31 - Rear blue signal (+) (not used)

32 - Rear green signal (-) (not used)

33 - Rear green signal (+) (not used)

34 - Rear red signal (-) (not used)

35 - Rear red signal (+) (not used)

36 - Rear video screen (not used)

40 - Left rear video input (-) (not used)

41 - Right rear video input (-) (not used)

42 - Rear A/V ground input (not used)

43 - Rear S-VHS (Y) input (not used)

44 - Rear S-VHS (C) input (not used)

45 - Rear CVBS input (not used)

46 - Rear A/V whole screen input

47 - Left front video input (-) (not used)

48 - Right front video input (-) (not used)

49 - Front A/V ground input (not used)

50 - Front S-VHS (Y) input (not used)

51 - Front S-VHS (C) input (not used)

52 - Front CVBS input (not used)

53 - Front A/V whole screen input

Scheme 115

Connectors

1 - HF connection (black) to Operating Electronics, Navigation Control Module J402

2 - HF connection (black) to Antenna Selection Control Module J515 / Left Antenna Module R108

3 - Black 12-pin multi-pin harness connector

Note. Unlisted connector terminals are not assigned.

Scheme 116

3 - Black 12-pin multi-pin harness connector

2 - CAN-Bus Low (Infotainment)

3 - CAN-Bus High (Infotainment)

6 - Terminal 30

8 - CAN-BUS Low (BOSCH)

9 - CAN-BUS High (BOSCH)

12 - Terminal 31

Scheme 117

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Operating Electronics, Navigation Control Module J402

1. In center console, at top
2. Connections
3. Removing and installing --> «Operating Electronics, Navigation Control Module J402 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__operating-electronics-navigation-control-module-j402)

4 - Navigation System Antenna R50

1. Behind roof end trim
2. Removing and installing --> «Navigation System Antenna R50 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-sedan)

5 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing)

6 - Bass Loudspeaker R100

1. In parcel shelf
2. Removing and installing --> «Bass Loudspeaker R100 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-sedan-removing)

7 - Antenna Selection Control Module J515

1. Behind roof end trim
2. Connections
3. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

8 - Navigation Interface R94

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Navigation Interface R94 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-interface-r94-sedan-removing)

9 - Navigation/TV Tuner J415

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Navigation/TV Tuner J415 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigationtv-tuner-j415-removing-and)

10 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

11 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. In bottom of rear doors
2. Removing and installing

12 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors
2. Removing and installing

13 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors
2. Removing and installing

Scheme 118

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Operating Electronics, Navigation Control Module J402

1. In center console, at top
2. Connections
3. Removing and installing --> «Operating Electronics, Navigation Control Module J402 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__operating-electronics-navigation-control-module-j402)

4 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing)

5 - Right rear window antennas

1. FM3/TV3/TV4

6 - Right Antenna Module R109

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Right Antenna Module R109 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__right-antenna-module-r109-avant)

7 - Bass Loudspeaker R100

1. Behind luggage compartment right side trim
2. Removing and installing --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing)

8 - Navigation System Antenna R50 roof antenna

1. Removing and installing --> «Navigation System Antenna R50 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-avant)

9 - Rear window antennas

1. FM2/TV2

10 - Left rear window antennas

1. AM/FM1/TV1

11 - Left Antenna Module R108

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Left Antenna Module R108 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

12 - Navigation Interface R94

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Navigation Interface R94 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-interface-r94-avant-removing)

13 - Navigation/TV Tuner J415

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Navigation/TV Tuner J415 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigationtv-tuner-j415-removing-and)

14 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

15 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. In bottom of rear doors
2. Removing and installing

16 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors
2. Removing and installing

17 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors
2. Removing and installing

Operating Electronics, Navigation Control Module J402 , removing and installing

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Scheme 119

1. Place Radio Release Tool T10057 in release slits on Operating Electronics, Navigation Control Module J402 until they engage. Points on grip eyes face outward.
2. Remove Operating Electronics, Navigation Control Module J402 from instrument panel.
3. Release connectors on Operating Electronics, Navigation Control Module J402 and remove it.
4. Remove Radio Release Tool T10057 by pressing locking tabs on Radio R.

Installing

1. Connect all harness connectors.
2. Carefully slide Operating Electronics, Navigation Control Module J402 into instrument panel and allow it to engage in installation frame.
3. Perform adaptations and coding on Operating Electronics, Navigation Control Module J402 if necessary.

Navigation Interface R94 , Sedan, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove left luggage compartment side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 120

1. Remove bolts - arrows - (14 Nm) and remove base mount - 1 -.

Scheme 121

1. Disconnect connectors at Navigation Interface R94 - 1 -.
2. Release Navigation Interface R94 - 1 - at catch - arrow - and remove from mounting plate - 2 -.

Installing

1. Install in reverse order.

Navigation Interface R94 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove luggage compartment left side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

Scheme 122

1. Remove bolts - arrows - (14 Nm) and remove base mount - 1 -.

1. Disconnect connectors at Navigation Interface R94 - 1 -.
2. Release Navigation Interface R94 - 1 - at catch - arrow - and remove from mounting plate - 2 -.

Installing

1. Install in reverse order.

Navigation/TV Tuner J415 , removing and installing

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Open left luggage compartment storage bin.

Scheme 123

1. Insert two clips on Radio Removal Tool T10057 into release slits on Navigation/TV Tuner J415 - 2 - until they engage. The points at the grasp eyes show outward.
2. Remove Navigation/TV Tuner J415 - 2 - from installation frame - 1 -.
3. Release connectors on Navigation/TV Tuner J415 and remove it.
4. Remove Radio Release Tool T10057 by pushing locking tabs on Navigation/TV Tuner J415 to do so.

Installing

1. Connect all harness connectors.
2. Slide Navigation/TV Tuner J415 into installation frame until it engages.
3. Perform adaptations and coding on Navigation/TV Tuner J415 if necessary.

Right Antenna Module R109 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove Bass Loudspeaker R100 --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing) .

Scheme 124

1. Remove bolts - arrows - (7 Nm) on Right Antenna Module R109 bracket.
2. Disconnect connectors on Right Antenna Module R109.

Scheme 125

1. Remove bolts - arrows - (2 Nm) and remove Right Antenna Module R109 from bracket.

Installing

1. Install in reverse order.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Description

RNS-E navigation system is an enhancement of the established navigation system II-D. The Board Computer Function Selector Switch E91 is integrated in the unit (MMI operation). A DVD (Europakarte) is used as a navigation CD.

Screen folds away. DVD drive and two card readers are located behind.

In addition to the navigation system, the RNS-E has a radio, two MP3 card readers and connections for Navigation/TV Tuner J415 and CD Changer R41. The DVD drive can play music CDs.

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

If there is a malfunction in the system, either a fault is saved in the DTC and/or an error message is given on the Navigation System with CD Drive Control Module J401 display.

At this time, the following error messages can be shown on the Navigation System with CD Drive Control Module J401 display.

Indicator in display

This error message appears

1. DVD cannot be read.
2. DVD is faulty.
3. DVD drive is faulty.

1. See if DVD drive can read a replacement DVD.

Same error

1. Perform in adaptation channel 41.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

Indicator in display

This error message appears

1. DVD drive cannot read DVD data.
2. DVD is faulty.
3. DVD drive is faulty.

1. See if DVD drive can read a replacement DVD.

Same error

1. Perform in adaptation channel 41.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

Scheme 126

1 - Rear window antennas AM/FM/TV

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Navigation System Antenna R50 behind roof end trim

4 - CD Changer R41 / iPod Baseplate R192 in glove compartment

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Inside Loudspeaker R70 in front center instrument panel

8 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

9 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

10 - Bass Loudspeaker R100 in parcel shelf

11 - Amplifier R12 behind luggage compartment right side trim

12 - Navigation System with CD Drive Control Module J401 in top of center console

13 - Telephone Microphone R38 in Front Interior Light W1 (from MY06 with RNS-E high)

14 - Telephone Transceiver R36 in electronics box under right front seat

15 - CAN-BUS (Infotainment)

16 - Navigation/TV Tuner J415 behind luggage compartment left side trim

Scheme 127

1 - Right rear FM3/TV3/TV4 window antennas

2 - FM2/TV2 rear window antennas

3 - left rear AM/FM1/TV1 window antennas

4 - Navigation System Antenna R50 in roof antenna

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Inside Loudspeaker R70 in front center instrument panel

8 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

9 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

10 - Bass Loudspeaker R100 behind luggage compartment right side trim

11 - Amplifier R12 behind luggage compartment right side trim

12 - Navigation System with CD Drive Control Module J401 in top of center console

13 - CD Changer R41 / iPod Baseplate R192 in glove compartment

14 - Telephone Microphone R38 in Front Interior Light W1 (from MY06 with RNS-E high)

15 - Telephone Transceiver R36 in electronics box under right front seat

16 - CAN-BUS (Infotainment)

17 - Navigation/TV Tuner J415 behind luggage compartment left side trim

18 - Left Antenna Module R108 behind luggage compartment left side trim

19 - Right Antenna Module R109 behind luggage compartment right side trim

Scheme 128

1 - Rear window antennas AM/FM/TV

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Navigation System Antenna R50 behind roof end trim

4 - CD Changer R41 / iPod Baseplate R192 in glove compartment

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Inside Loudspeaker R70 in front center instrument panel

8 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

9 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

10 - Bass Loudspeaker R100 in parcel shelf

11 - Amplifier R12 behind luggage compartment right side trim

12 - Inside Microphone R74 in Front Interior Light W1

13 - Navigation System with CD Drive Control Module J401 in top of center console

14 - Telephone Microphone R38 in Front Interior Light W1 (from MY06 with RNS-E high)

15 - Telephone Transceiver R36 in electronics box under right front seat

16 - CAN-BUS (Infotainment)

17 - Navigation/TV Tuner J415 behind luggage compartment left side trim

Scheme 129

1 - Right rear FM3/TV3/TV4 window antennas

2 - FM2/TV2 rear window antennas

3 - Rear left window antenna with AM/FM1/TV

4 - Navigation System Antenna R50 in roof antenna

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 in front doors

7 - Inside Loudspeaker R70 in front center instrument panel

8 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

9 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

10 - Bass Loudspeaker R100 behind luggage compartment right side trim

11 - Amplifier R12 behind luggage compartment right side trim

12 - Inside Microphone R74 in Front Interior Light W1

13 - Navigation System with CD Drive Control Module J401 in top of center console

14 - CD Changer R41 / iPod Baseplate R192 in glove compartment

15 - Telephone Microphone R38 in Front Interior Light W1 (from MY06 with RNS-E high)

16 - Telephone Transceiver R36 in electronics box under right front seat

17 - CAN-BUS (Infotainment)

18 - Navigation/TV Tuner J415 behind luggage compartment left side trim

19 - Left Antenna Module R108 behind luggage compartment left side trim

20 - Right Antenna Module R109 behind luggage compartment right side trim

Scheme 130

1 - Black 32-pin multi-pin connector (T32f) to Navigation/TV Tuner J415

2 - Navigation System Antenna R50 GPS connection (blue)

3 - Connection block with four multi-pin connectors and a fuse for unit

4 - IF connection (white) to Antenna Selection Control Module J515 / Left Antenna Module R108

5 - HF connection (white) to Antenna Selection Control Module J515 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

Scheme 131

1 - Black 32-pin multi-pin harness connector (T32f)

13 - Right audio input from Navigation/TV Tuner J415

15 - Video input sync. from Navigation/TV Tuner J415

16 - Video input green from Navigation/TV Tuner J415

27 - Screen ground from Navigation/TV Tuner J415

28 - Audio ground from Navigation/TV Tuner J415

29 - Left audio input from Navigation/TV Tuner J415

30 - Video ground from Navigation/TV Tuner J415

31 - Video input blue from Navigation/TV Tuner J415

32 - Video input red from Navigation/TV Tuner J415

A - Brown 8-pin multi-pin connector (T8q)

2 - Right front speaker (+) (not with BOSE)

3 - Left front speaker (+) (not with BOSE)

6 - Right front speaker (-) (not with BOSE)

7 - Left front speaker (-) (not with BOSE)

B - Blue 12-pin multi-pin connector (T12n)

2 - CD ground to CD Changer R41

3 - Speed signal

4 - Permanent positive to CD Changer R41

5 - L-diagnostic

6 - CD data out to CD Changer R41

7 - BOSE coding to ground (only with BOSE)

8 - Left signal from CD Changer R41

9 - Right signal from CD Changer R41

10 - Positive switched to CD Changer R41

11 - CD data in from CD Changer R41

12 - CD CLK from CD Changer R41

C - Green 12-pin multi-pin connector (T12m)

1 - Microphone input (-) from Telephone Microphone R38 (from MY06)

2 - Signal from Back-Up Light Switch F4 (not used)

3 - Left front signal to Amplifier R12 (only with BOSE)

4 - Microphone output (-) to Telephone Transceiver R36 (from MY06)

5 - Left rear signal to Amplifier R12

6 - NF (-) from Telephone Transceiver R36 /preliminary setup for cell phone package

7 - Microphone input (+) from Telephone Microphone R38 (from MY06)

8 - Signal ground to Radio R12

9 - Right front signal to Amplifier R12 (only with BOSE)

10 - Microphone output (+) to Telephone Transceiver R36 (from MY06)

11 - Right rear signal to Amplifier R12

12 - NF (+) from Telephone Transceiver R36 /preliminary setup for cell phone package

D - Black 8-pin multi-pin connector D (T16j)

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute from Telephone Transceiver R36 (through MY04)

12 - Terminal 31

13 - Positive switched to Amplifier R12

14 - Anti-theft warning system ground from Comfort System Central Control Module J393

15 - Terminal 30

16 - Permanent positive (not used)

Navigation/TV Tuner J415 connections

Connectors and connector assignments

Scheme 132

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. Only with BOSE
2. In Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Navigation System Antenna R50

1. Behind roof end trim
2. Removing and installing --> «Navigation System Antenna R50 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-sedan)

5 - Antenna Selection Control Module J515

1. Behind roof end trim
2. Connections
3. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

6 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing)

7 - Bass Loudspeaker R100

1. In parcel shelf
2. Removing and installing --> «Bass Loudspeaker R100 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-sedan-removing)

8 - Navigation/TV Tuner J415

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Navigation/TV Tuner J415 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigationtv-tuner-j415-removing-and)

9 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. In bottom of rear doors
2. Removing and installing

10 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

11 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. In bottom of front doors
2. Removing and installing

12 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. In top of front doors
2. Removing and installing

13 - Navigation System with CD Drive Control Module J401

1. In center console, at top
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

Scheme 133

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. Only with BOSE
2. In Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing)

5 - Right rear window antennas

1. FM3TV3/TV4

6 - Right Antenna Module R109

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Right Antenna Module R109 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__right-antenna-module-r109-avant)

7 - Bass Loudspeaker R100

1. Behind luggage compartment right side trim
2. Removing and installing --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing)

8 - Navigation System Antenna R50 roof antenna

1. Removing and installing --> «Navigation System Antenna R50 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-avant)

9 - Rear window antennas

1. FM2/TV2

10 - Navigation/TV Tuner J415

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Navigation/TV Tuner J415 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigationtv-tuner-j415-removing-and)

11 - Left Antenna Module R108

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Left Antenna Module R108 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

12 - Left rear window antennas

1. AM/FM1/TV1

13 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. in bottom of rear doors
2. Removing and installing

14 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. In top of rear doors
2. Removing and installing

15 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. in bottom of front doors
2. Removing and installing

16 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. in top of front doors
2. Removing and installing

17 - Navigation System with CD Drive Control Module J401

1. in center console, at top
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

1. Turn off all electrical components.
2. Remove ignition key.

Removing

Scheme 134

1. Place Radio Release Tool T10057 - arrows - in release slits on Operating Electronics, Navigation Control Module J402 until they engage. Points on grip eyes face outward.
2. Remove Operating Electronics, Navigation Control Module J402 from instrument panel.
3. Release connectors on Operating Electronics, Navigation Control Module J402 and remove it.
4. Remove Radio Release Tool T10057 by pushing locking tabs on Operating Electronics, Navigation Control Module J402 to do so.

Installing

1. Connect all harness connectors.
2. Carefully slide Operating Electronics, Navigation Control Module J402 into instrument panel and allow it to engage in installation frame.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL . Deactivate Telephone/Telematics Control Module J526 service mode --> Service mode, activating/deactivating .

Description

The navigation system RNS-E is an advancement. The function selection switch is integrated in the unit (MMI operation). A DVD is used as the navigation CD.

Screen folds away. DVD drive and two card readers are located behind.

In addition to the navigation system, the RNS-E contains a radio, two MP3 card readers and connections for Satellite Radio R146 , CD Changer R41 and cellular telephone. The DVD drive can play music CDs.

Diagnosis is performed using "Guided Fault-Finding".

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

If there is a malfunction in the system, either a fault is saved in the DTC and/or an error message is given on the Navigation System with CD Drive Control Module J401 display.

At this time, the following error messages can be shown on the Navigation System with CD Drive Control Module J401 display.

Indicator in display

This error message appears

1. DVD cannot be read.
2. DVD is faulty.
3. DVD drive is faulty.

1. See if DVD drive can read a replacement DVD.

Same error

1. Perform in adaptation channel 41.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

Indicator in display

This error message appears

1. DVD drive cannot read DVD data.
2. DVD is faulty.
3. DVD drive is faulty.

1. See if DVD drive can read a replacement DVD.

Same error

1. Perform in adaptation channel 41.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

Scheme 135

1 - AM/FM rear window antennas

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

4 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

5 - Inside Loudspeaker R70 in front center instrument panel

6 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

7 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

8 - Bass Loudspeaker R100 in parcel shelf

9 - Amplifier R12 behind luggage compartment right side trim

10 - CD Changer R41 / iPod Baseplate R192 in glove compartment

11 - Satellite Radio R146 behind left luggage compartment side trim

12 - Navigation System with CD Drive Control Module J401 in top of center console

13 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Scheme 136

1 - right rear FM3 window antennas

2 - FM2 rear window antennas

3 - left rear AM/FM1 window antennas

4 - Left Antenna Module R108 behind luggage compartment left side trim

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Inside Loudspeaker R70 in front center instrument panel

8 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

9 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

10 - Bass Loudspeaker R100 behind luggage compartment right side trim

11 - Amplifier R12 behind luggage compartment right side trim

12 - CD Changer R41 / iPod Baseplate R192 in glove compartment

13 - Satellite Radio R146 behind left luggage compartment side trim

14 - Navigation System with CD Drive Control Module J401 in top of center console

15 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Scheme 137

1 - AM/FM rear window antennas

2 - Antenna Selection Control Module J515 behind roof end trim

3 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

4 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

5 - Inside Loudspeaker R70 in front center instrument panel

6 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

7 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

8 - Bass Loudspeaker R100 in parcel shelf

9 - Amplifier R12 behind luggage compartment right side trim

10 - Inside Microphone R74 in Front Interior Light W1

11 - CD Changer R41 / iPod Baseplate R192 in glove compartment

12 - Satellite Radio R146 behind left luggage compartment side trim

13 - Navigation System with CD Drive Control Module J401 in top of center console

14 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Scheme 138

1 - right rear FM3 window antennas

2 - FM2 rear window antennas

3 - left rear AM/FM1 window antennas

4 - Left Antenna Module R108 behind luggage compartment left side trim

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 in front doors

7 - Inside Loudspeaker R70 in front center instrument panel

8 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

9 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

10 - Bass Loudspeaker R100 behind luggage compartment right side trim

11 - Amplifier R12 behind luggage compartment right side trim

12 - Inside Microphone R74 in Front Interior Light W1

13 - CD Changer R41 / iPod Baseplate R192 in glove compartment

14 - Satellite Radio R146 behind left luggage compartment side trim

15 - Navigation System with CD Drive Control Module J401 in top of center console

16 - Radio, Telephone, Navigation System Antenna R52 (Ter/Sat/GPS/GSM) roof antenna

Navigation System with CD Drive Control Module J401 , harness connectors

1 - 32-pin multi-pin connector, not used

2 - Radio, Telephone, Navigation System Antenna R52 GPS connection (blue) (Ter/Sat/GPS/GSM)

3 - Connection block with four multi-pin connectors and a fuse for unit

4 - IF connection (white) to Antenna Selection Control Module J515 / Left Antenna Module R108

5 - HF connection (white) to Antenna Selection Control Module J515 / Left Antenna Module R108

Note. Unlisted connector terminals are not assigned.

1 - 32-pin multi-pin connector

Connector not used

13 - Right audio input

15 - Video input sync.

16 - Green video input

27 - Screen ground

28 - Audio ground

29 - Left video input

30 - Video ground

31 - Blue video input

32 - Red video input

A - Brown 8-pin multi-pin connector (T8q)

2 - Right front speaker (+) (not with BOSE)

3 - Left front speaker (+) (not with BOSE)

6 - Right front speaker (-) (not with BOSE)

7 - Left front speaker (-) (not with BOSE)

B - Blue 12-pin multi-pin connector (T12n)

2 - Signal ground from CD Changer R41 / Satellite Radio R146

3 - Speed signal (not used)

4 - Permanent positive to CD Changer R41

5 - L-diagnostic

6 - CD data out to CD Changer R41

7 - BOSE coding to ground (only with BOSE)

8 - Left signal from CD Changer R41 / Satellite Radio R146

9 - Right signal from CD Changer R41 / Satellite Radio R146

10 - Positive switched to CD Changer R41

11 - CD data in from CD Changer R41

12 - CD CLK from CD Changer R41

C - Green 12-pin multi-pin connector (T12m)

1 - Microphone input (-) (not used)

2 - Signal from Back-Up Light Switch F4 (not used)

3 - Left front signal to Amplifier R12 (only with BOSE)

4 - Microphone output (-) (not used)

5 - Left rear signal to Amplifier R12

6 - NF (-) from Telephone Transceiver R36

7 - Microphone input (+) (not used)

8 - Signal ground to Radio R12

9 - Right front signal to Amplifier R12 (only with BOSE)

10 - Microphone output (+) (not used)

11 - Right rear signal to Amplifier R12

12 - NF (+) from Telephone Transceiver R36

D - Black 8-pin multi-pin connector D (T16j)

9 - CAN-Bus High (Infotainment)

10 - CAN-Bus Low (Infotainment)

11 - NF mute, not used

12 - Terminal 31

13 - Positive switched to Amplifier R12

14 - Anti-theft warning system ground from Comfort System Central Control Module J393

15 - Terminal 30

16 - Permanent positive (not used)

Scheme 139

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. only with BOSE
2. in Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

Telephone Microphone R38

1. in Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__radio-telephone-navigation-system-antenna-r52)

5 - Antenna Selection Control Module J515

1. behind roof end trim
2. Connections
3. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

6 - Digital Sound System Control Module R12

1. behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing)

7 - Bass Loudspeaker R100

1. in parcel shelf
2. Removing and installing --> «Bass Loudspeaker R100 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-sedan-removing)

8 - Satellite radio R146

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Satellite Radio R146 , removing and installing, activating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

9 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. in bottom of rear doors
2. Removing and installing

10 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. in top of rear doors
2. Removing and installing

11 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. in bottom of front doors
2. Removing and installing

12 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. in top of front doors
2. Removing and installing

13 - Navigation System with CD Drive Control Module J401

1. in center console, at top
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

Scheme 140

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

iPod Baseplate R192

1. Connections
2. Removing and installing --> «iPod Baseplate R192 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__ipod-baseplate-r192-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Navigation System with CD Drive Control Module J401

1. in center console, at top
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

4 - Inside Microphone R74

1. only with BOSE
2. in Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

Telephone Microphone R38

1. In Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

5 - Digital Sound System Control Module R12

1. Behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing)

6 - Right rear window antennas

1. FM3

7 - Bass Loudspeaker R100

1. behind luggage compartment right side trim
2. Removing and installing --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing)

8 - Radio, Telephone, Navigation System Antenna R52

1. Ter/Sat/GPS/GSM
2. Roof antenna
3. Removing and installing --> «Radio, Telephone, Navigation System Antenna R52 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__radio-telephone-navigation-system-antenna-r52)

9 - Rear window antennas

1. FM2

10 - Satellite radio R146

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Satellite Radio R146 , removing and installing, activating»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

11 - Left Antenna Module R108

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Left Antenna Module R108 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

12 - Left rear window antennas

1. AM/FM1

13 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. in bottom of rear doors
2. Removing and installing

14 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. in top of rear doors
2. Removing and installing

15 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. in bottom of front doors
2. Removing and installing

16 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. in top of front doors
2. Removing and installing

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL .

Description

The RNS-JP3 navigation system consists of the navigation unit in the top of the center console. A DVD and MD player is installed behind the tilting operating and display unit.

By evaluation data from the GPS system, an installed gyro-sensor and the speed signal, the RNS-JP3 determines the vehicle position in the scope of a map stored on a DVD.

Using these measured values, the system determines the vehicles direction and distance traveled. These values are compared with the street network saved on the navigation DVD.

When the vehicle is moving, the position is constantly updated (compound navigation). Plausibility comparisons increase the certainty of the position display. If the calculated position does not lie on the saved street network, it is corrected by the navigation computer.

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Scheme 141

1 - Navigation System Antenna R50 behind roof end trim

2 - CD Changer R41 in glove compartment

3 - Operating Electronics, Navigation Control Module J402 in top of center console

4 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

5 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

6 - Inside Loudspeaker R70 in front center instrument panel

7 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

8 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

9 - Amplifier R12 behind luggage compartment right side trim

10 - Bass Loudspeaker R100 in parcel shelf

11 - Rear window antennas AM/FM/TV

12 - Antenna Amplifier R24 behind roof end trim

13 - Antenna Selection Control Module J515 behind luggage compartment left side trim

Scheme 142

1 - Navigation System Antenna R50 roof antenna

2 - CD Changer R41 in glove compartment

3 - Operating Electronics, Navigation Control Module J402 in top of center console

4 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

5 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

6 - Inside Loudspeaker R70 in front center instrument panel

7 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

8 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

9 - Amplifier R12 behind luggage compartment right side trim

10 - Bass Loudspeaker R100 behind luggage compartment right side trim

11 - left rear AM/FM1/TV1 window antennas

12 - FM2/TV2 rear window antennas

13 - Right rear FM3/TV3/TV4 window antennas

14 - Right Antenna Module R109 behind luggage compartment right side trim

15 - Left Antenna Module R108 behind luggage compartment left side trim

16 - Antenna Selection Control Module J515 behind luggage compartment left side trim

Scheme 143

1 - Navigation System Antenna R50 behind roof end trim

2 - CD Changer R41 in glove compartment

3 - Operating Electronics, Navigation Control Module J402 in top of center console

4 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

5 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

6 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

7 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

8 - Inside Loudspeaker R70 in front center instrument panel

9 - Bass Loudspeaker R100 in parcel shelf

10 - Rear window antennas AM/FM/TV

11 - Antenna Amplifier R24 behind roof end trim

12 - Antenna Selection Control Module J515 behind luggage compartment left side trim

13 - Amplifier R12 behind luggage compartment right side trim

Scheme 144

1 - Navigation System Antenna R50 roof antenna

2 - CD Changer R41 in glove compartment

3 - Operating Electronics, Navigation Control Module J402

4 - Amplifier R12 behind luggage compartment right side trim

5 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

6 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

7 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

8 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

9 - Inside Loudspeaker R70 in front center instrument panel

10 - Bass Loudspeaker R100 behind luggage compartment left side trim

11 - Left rear FM3/TV3/TV4 window antennas

12 - FM2/TV2 rear window antennas

13 - Right rear AM/FM1/TV1 window antennas

14 - Right Antenna Module R109 behind luggage compartment right side trim

15 - Left Antenna Module R108 behind luggage compartment left side trim

16 - Antenna Selection Control Module J515 behind luggage compartment left side trim

17 - Inside Microphone R74 in Front Interior Light W1

Scheme 145

1 - GPS connection (blue) from Navigation System Antenna R50

2 - Black 32-pin multi-pin harness connector (T32f)

3 - Fan

4 - Connector block with three multi-pin connectors and device fuse

5 - Antenna Selection Control Module J515 TV connection (green)

6 - FM2 connector (white) from Antenna Amplifier R24 / Left Antenna Module R108

7 - FM1 connector (white) from Antenna Amplifier R24 / Left Antenna Module R108

Note. Connector assignments not listed are free or not used.

Scheme 146

2 - Black 32-pin multi-pin harness connector (T32f)

1 - Terminal 15

8 - Selection 1 to Antenna Selection Control Module J515

9 - Selection 2 to Antenna Selection Control Module J515

22 - Signal from Back-Up Light Switch F4

24 - Screen ground to Antenna Selection Control Module J515

25 - Antenna Selection Control Module J515 diagnostic

Scheme 147

C - Black 20-pin multi-pin harness connector (T20d)

1 - Left rear signal to Amplifier R12

2 - Right rear signal to Amplifier R12

3 - Signal ground to Radio R12

4 - Left front signal to Amplifier R12

5 - Right front signal to Amplifier R12

6 - Positive switched to Amplifier R12

8 - CAN-Bus High (Infotainment)

9 - CAN-Bus Low (Infotainment)

10 - CD ground to CD Changer R41

11 - CD mute to CD Changer R41

12 - Permanent positive to CD Changer R41

13 - CD-TX (+) from CD Changer R41

14 - CD-TX (-) from CD Changer R41

16 - Left signal (-) from CD Changer R41

17 - Positive switched to CD Changer R41

18 - Right signal (-) from CD Changer R41

19 - Left signal (+) from CD Changer R41

20 - Right signal (+) from CD Changer R41

B - Brown 8-pin multi-pin connector (T8a)

3 - Loudspeaker, right front (+)

4 - Loudspeaker, right front (-)

5 - Loudspeaker, left front (+)

6 - Loudspeaker, left front (-)

A - 8-pin multi-pin connector (T8h) black

1 - Speed signal

3 - K-wire

4 - Terminal 86s

7 - Terminal 30

8 - Terminal 31

Scheme 148

1 - Black 3-pin multi-pin harness connector (T3i)

2 - TV connection (green) to Operating Electronics, Navigation Control Module J402

3 - TV 4 connection (black) from Right Antenna Module R109

4 - TV 3 connection (black) from Right Antenna Module R109

5 - TV 2 connection (black) from Left Antenna Module R108

6 - TV 1 connection (black) from Left Antenna Module R108

Scheme 149

1 - Black 3-pin multi-pin harness connector (T3i)

1 - Selection 2 from Operating Electronics, Navigation Control Module J402

2 - Selection 1 from Operating Electronics, Navigation Control Module J402

3 - Operating Electronics, Navigation Control Module J402 diagnostic

Sedan

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. only with BOSE
2. in Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

Telephone Microphone R38

1. in Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Navigation System Antenna R50

1. behind roof end trim
2. Removing and installing --> «Navigation System Antenna R50 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-sedan)

5 - Antenna Amplifier R24

1. behind roof end trim
2. Connections
3. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

6 - Digital Sound System Control Module R12

1. behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-sedan-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-sedan-removing)

7 - Bass Loudspeaker R100

1. in parcel shelf
2. Removing and installing --> «Bass Loudspeaker R100 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-sedan-removing)

8 - Antenna Selection Control Module J515

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Antenna Selection Control Module J515 , sedan, removing and installing - sedan»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-selection-control-module-j515)

9 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. in bottom of rear doors
2. Removing and installing

10 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. in top of rear doors
2. Removing and installing

11 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. in bottom of front doors
2. Removing and installing

12 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. in top of front doors
2. Removing and installing

13 - Navigation System with CD Drive Control Module J401

1. in center console, at top
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

Avant

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. only with BOSE
2. in Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

Telephone Microphone R38

1. in Front Interior Light W1
2. Removing and installing --> «Telephone Microphone R38 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__telephone-microphone-r38-removing-and)

4 - Digital Sound System Control Module R12

1. behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__amplifier-r12-avant-removing-and)
4. BOSE connections

1. BOSE, removing and installing --> «BOSE Amplifier R12 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bose-amplifier-r12-avant-removing)

5 - Right rear window antennas

1. FM3TV3/TV4

6 - Right Antenna Module R109

1. behind luggage compartment right side trim
2. Connections
3. Removing and installing --> «Right Antenna Module R109 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__right-antenna-module-r109-avant)

7 - Bass Loudspeaker R100

1. behind luggage compartment right side trim
2. Removing and installing --> «Bass Loudspeaker R100 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__bass-loudspeaker-r100-avant-removing)

8 - Navigation System Antenna R50 roof antenna

1. Removing and installing --> «Navigation System Antenna R50 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-avant)

9 - Rear window antennas

1. FM2/TV2

10 - Antenna Selection Control Module J515

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Antenna Selection Control Module J515 , sedan, removing and installing - sedan»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-selection-control-module-j515)

11 - Left Antenna Module R108

1. Behind luggage compartment left side trim
2. Connections
3. Removing and installing --> «Left Antenna Module R108 , Avant, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

12 - Left rear window antennas

1. AM/FM1/TV1

13 - Left Rear Bass Speaker R15 and Right Rear Bass Speaker R17

1. in bottom of rear doors
2. Removing and installing

14 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35

1. in top of rear doors
2. Removing and installing

15 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23

1. in bottom of front doors
2. Removing and installing

16 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27

1. in top of front doors
2. Removing and installing

17 - Navigation System with CD Drive Control Module J401

1. in center console, at top
2. Connections --> «Navigation System with CD Drive Control Module J401 , harness connectors»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)
3. Removing and installing --> «Navigation System with CD Drive Control Module J401 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication)

Special tools, testers and auxiliary items required

1. Radio removal tool T10057

1. Turn off all electrical components.
2. If control module is replaced, select "Replacement" function for appropriate control module in "Guided Fault-Finding" routine.

Use the Vehicle Diagnosis, Testing and Information System VAS 5051 to do so.

Removing

1. Place Radio Release Tool T10057 - arrows - in release slits on Operating Electronics, Navigation Control Module J402 until they engage. Points on grip eyes face outward.
2. Remove Operating Electronics, Navigation Control Module J402 from instrument panel.
3. Release connectors on Operating Electronics, Navigation Control Module J402 and remove it.
4. Remove Radio Release Tool T10057 by pushing locking tabs on Operating Electronics, Navigation Control Module J402 to do so.

Installing

1. Connect all harness connectors.
2. Carefully slide Operating Electronics, Navigation Control Module J402 into instrument panel and allow it to engage in installation frame.

Antenna Selection Control Module J515 , sedan, removing and installing - sedan

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove left luggage compartment side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. Remove bolts - arrows - (14 Nm) and remove base mount - 1 -.

Scheme 150

1. Remove retainer - 3 - from base mount.
2. Remove bolts - 1 - (2 Nm).
3. Disconnect connectors on Antenna Selection Control Module J515 - 2 -.

Installing

1. Install in reverse order.

Antenna Selection Control Module J515 , Avant, removing and installing

1. Turn off all electrical components.
2. Remove ignition key.

Removing

1. Remove left luggage compartment side trim --> - «70 - INTERIOR TRIM»(/audi/a4/b7-2004-2009/remont/gauges-instrument-panels/#body-interior) .

1. Remove bolts - arrows - (14 Nm) and remove base mount - 1 -.

1. Remove retainer - 3 - from base mount.
2. Remove bolts - 1 - (2 Nm).
3. Disconnect connectors on Antenna Selection Control Module J515 - 2 -.

Installing

1. Install in reverse order.

If the Battery A is reconnected, follow the procedure for disconnecting and connecting the Battery A --> - 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL .

Description

The navigation system JP4 consists of an "aftermarket" RNS.

All connections necessary for the navigation unit are present in the vehicle. Sound system and antennas are installed.

In case of retrofitting, only the navigation unit (RNS) is installed.

Repairs on antenna wires --> - 97 WIRING .

Repair to CAN bus lines --> - 97 WIRING .

Scheme 151

1 - Window antenna

2 - Navigation System Antenna R50 behind roof end trim

3 - Black 4-pin multi-pin speaker connection

4 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

5 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

6 - Inside Loudspeaker R70 in front center instrument panel

7 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

8 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

9 - Bass Loudspeaker R100 in parcel shelf

10 - Amplifier R12 behind luggage compartment right side trim

11 - Black 12-pin multi-pin Amplifier R12 connection

12 - Black 12-pin multi-pin voltage supply connection

13 - Black 2-pin multi-pin CAN BUS (Infotainment) connection

14 - GPS connection (blue) from Navigation System Antenna R50

15 - TV3/TV3 connection (green) from Antenna Selection Control Module J515

16 - TV1/TV2 connection (brown) from Antenna Selection Control Module J515

17 - AM/FM connection (white) from Antenna Selection Control Module J515

18 - Antenna Selection Control Module J515 behind roof end trim

Scheme 152

1 - TV1/TV2 window antennas

2 - AM/FM rear window antennas

3 - TV3/TV4 window antennas

4 - Navigation System Antenna R50 roof antenna

5 - Black 4-pin multi-pin speaker connection

6 - Left Front Midrange Speaker R26 / Right Front Midrange Speaker R27 at top in front doors

7 - Left Front Bass Speaker R21 / Right Front Bass Speaker R23 at bottom in front doors

8 - Inside Loudspeaker R70 in front center instrument panel

9 - Left Rear Midrange Speaker R34 / Right Rear Midrange Speaker R35 at top in rear doors

10 - Left Rear Bass Speaker R15 / Right Rear Bass Speaker R17 at bottom in rear doors

11 - Bass Loudspeaker R100 behind luggage compartment right side trim

12 - Amplifier R12 behind luggage compartment right side trim

13 - Black 12-pin multi-pin Amplifier R12 connection

14 - Black 12-pin multi-pin voltage supply connection

15 - Black 2-pin multi-pin CAN BUS (Infotainment) connection

16 - GPS connection (blue) from Navigation System Antenna R50

17 - TV3/TV4 connection (green) from Right Antenna Module R109

18 - TV1/TV2 connection (brown) from Left Antenna Module R108

19 - AM/FM connection (white) from Left Antenna Module R108

20 - Left Antenna Module R108 behind luggage compartment left side trim

21 - Right Antenna Module R109 behind luggage compartment right side trim

Sound system

Note. Connector assignments not listed are free or not used.

Scheme 153

Black 4-pin multi-pin harness connector

3 - Speaker (+) front right

4 - Speaker (-) front right

5 - Speaker (+) front left

6 - Speaker (-) front left

Scheme 154

Black 12-pin multi-pin harness connector

1 - Left rear signal (+) to Amplifier/Woofer (in left rear luggage compartment) R44

4 - Positive switched to Amplifier/Woofer (in left rear luggage compartment) R44 /

7 - Right rear signal (+) to Amplifier/Woofer (in left rear luggage compartment) R44

10 - Signal (-) to Amplifier/Woofer (in left rear luggage compartment) R44

Scheme 155

Black 2-pin multi-pin harness connector

1 - CAN-Bus High (Infotainment)

2 - CAN-Bus Low (Infotainment)

Scheme 156

Black 2-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

Scheme 157

Connectors

1 - GPS connection (blue) from Navigation System Antenna R50

2 - AM/FM connection (white) from Antenna Amplifier R24 / Left Antenna Module R108

3 - TV3/TV4 connection (green) from Antenna Amplifier R24 / Right Antenna Module R109

4 - TV1/TV2 connection (brown) from Antenna Amplifier R24 / Left Antenna Module R108

Scheme 158

1 - CD Changer R41

1. In glove compartment
2. Connections
3. Removing and installing --> «CD Changer R41 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__cd-changer-r41-removing-and)

2 - Inside Loudspeaker R70

1. In front instrument panel, center
2. Removing and installing --> «Inside Loudspeaker R70 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-loudspeaker-r70-removing-and)

3 - Inside Microphone R74

1. only with BOSE
2. in Front Interior Light W1
3. Function test --> «Inside Microphone R74 , function test»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-function-test)
4. Removing and installing --> «Inside Microphone R74 , removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__inside-microphone-r74-removing-and)

4 - Navigation System Antenna R50

1. behind roof end trim
2. Removing and installing --> «Navigation System Antenna R50 , Sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__navigation-system-antenna-r50-sedan)

5 - Antenna Selection Control Module J515

1. behind roof end trim
2. Connections
3. Removing and installing --> «Antenna Amplifier R24 / Antenna Selection Control Module J515 , sedan, removing and installing»(/audi/a4/b7-2004-2009/remont/accessories-control-systems/#communication__antenna-amplifier-r24-antenna-selection)

6 - Digital Sound System Control Module R12
