Power window system wiring diagram (a4 circuit 1 of 2) for Audi A4 B5 (1994-1999)

Power window system wiring diagram (a4 circuit 1 of 2)

A4 Audi B5 (1994-1999): Power window system wiring diagram (a4 circuit 1 of 2)

Get access

BLK WIRE BLK/YEL WIRE BRN WIRE FUSE ASSEMBLY (BEHIND LEFT SIDE OF DASH) FUSE/ RELAY PANEL HOT AT ALL TIMES HOT IN ON OR ACC LEFT FRONT WINDOW SWITCH LEFT WINDOW MOTOR POWER SUNROOF CONTROL MODULE POWER WINDOW FUSE 37 RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE WHT/YEL WIRE WINDOW MOTOR YEL/BLU WIRE
