Exterior lamps circuit for Audi A3 8P facelift (2004-2008)

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM EMERGENCY FLASHER SWITCH EXTERIOR LIGHTS SYSTEM (BACK-UP LIGHTS CIRCUIT) FUSE 16 FUSE PANEL B (INTEGRATED IN ENGINE COMPARTMENT E-BOX) GRN/RED WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES LEFT HEADLIGHT ASSEMBLY LEFT PARKING LAMP LEFT SIDE TURN SIGNAL LAMP LEFT TAILLAMP ASSEMBLY 1 LEFT TAILLAMP ASSEMBLY 2 LIGHT SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/YEL WIRE REVERSE STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE STOP STOP STOP TURN TURN SIGNAL SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE

BLK WIRE BLK/GRN WIRE BLK/YEL WIRE BLU WIRE BRAKE LIGHT SWITCH BRN WIRE ENGINE CONTROL MODULE EXTERIOR LIGHTS SYSTEM (BACK-UP LIGHTS CIRCUIT) FUSE 2 FUSE PANEL C GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES LICENSE PLATE LIGHTS RED WIRE REVERSE STOP RIGHT HEADLIGHT ASSEMBLY RIGHT PARKING SIDE MARKER LAMP RIGHT SIDE TURN SIGNAL LAMP RIGHT TAILLAMP ASSEMBLY 1 RIGHT TAILLAMP ASSEMBLY 2 STOP TURN STOP TURN VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
