# Automatic a/c circuit

# Automatic a/c circuit (1 of 3)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (1 of 3). Audi A3 8P facelift (2004-2008)

Components on the diagram

# Automatic a/c circuit (2 of 3)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (2 of 3). Audi A3 8P facelift (2004-2008)

Components on the diagram

# Automatic a/c circuit (3 of 3)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (3 of 3). Audi A3 8P facelift (2004-2008)

Components on the diagram
