Contents Wiring diagrams Section: Sun Roof/t-Top/convertible Top All sections

Sunroof: Other Audi A3 8P facelift

Sun Roof/t-Top/convertible Top 32 illustrations ~1435 words

MINIMUM CURING TIMES

WARNINGFor safety reasons, use only electrically non-conductive 2C-adhesive when installing sunroof module using the materials listed below. The vehicle can only be used after the minimum curing time has elapsed.
Vehicle withAdhesive sealing materialMinimum curing time in hours
Sunroof moduleDA 004 600 A28

Scheme 23

Scheme 23: EXTERIOR ASSEMBLY PARTS
  1. Panel -1- Bonded to roof module. Cannot be removed undamaged without removing windshield.
  2. Panel -2- Removal, refer to «SUNROOF PANEL»(ref-496129-S08336870672012082100000)
  3. Panel -3- Bonded to roof module.
  4. Rear Sun Shade Removal, refer to «SUN SHADE»(ref-496129-S04128108022012082100000)
  5. Front Sunroof Shade
  6. Roof Module
  7. Sunroof Motor Removing and installing, refer to «SUNROOF MOTOR»(ref-496129-S11439215432012082100000)
  8. Combination Screw 3.5 Nm
  9. Wind Deflector Removal, refer to «WIND DEFLECTOR»(ref-496129-S11096911602012082100000)

Scheme 24

Scheme 24: WATER DRAIN HOSES ASSEMBLY OVERVIEW
  1. Front Water Drain Hose Route the front water drain hoses through the A-pillars and have them end in the wheel housing over the wheel house liner. Cleaning, refer to «WATER DRAIN HOSES, CLEANING»(ref-496129-S17588323352012082100000)
  2. Frame For sunroof operation
  3. Rear Water Drain Hose Rear water drain hoses are routed in -C- pillars and end in wheel housing above wheel housing liner Cleaning, refer to «WATER DRAIN HOSES, CLEANING»(ref-496129-S17588323352012082100000)

Removing and installing bonded cover

WARNINGKeep adhesive surface free of dirt and grease. Only cut back adhesive surface shortly before installation. Do not prime or use a cleaning solution on the adhesive surface. Make sure there is a slight overlap at adhesive joining points, otherwise there may be leaks in these areas. Bonded panel must be inserted in the vehicle within a maximum of 10 minutes after start of application, otherwise the bonding properties of adhesive sealant material will be impaired. Observe minimum curing times for bonded panel, refer to SUNROOF PANEL

Scheme 25

Scheme 25
  1. Adhesive Bead for Panel 1 Cut back only just before installing a new panel. Apply new adhesive onto residual bead on body.
  2. Panel 1 NOTE: It is not possible to remove the panel 1 without damaging it. Use two V.A.G 1351/1 and the cutting wire 357 853 999 A to remove panel 1 Remove the molding on the front of the panel as well as on both sides 1 using a sharp carpet knife. Open the panel 2 all the way to the rear. Place the cutting wire between the glass panel 1 and the sunroof. Seal the top of the roof frame with tape to protect the paint. Attach the ends of the wire to the handles and cut the adhesive all the way through. When installing, panel 2 must be installed and closed. Clean new panel in adhesion area and prime. Apply adhesive onto residual adhesive bead. Insert panel into roof cutout. Align panel and press it evenly into roof cutout to stop. Secure panel in roof cutout with adhesive tape.
  3. Panel 2 Removing and installing, refer to «SUNROOF PANEL»(ref-496129-S08336870672012082100000)
  4. Panel 3 Bonded to roof module. Panel 2 removed. Roof molding removed, refer to «SUNROOF»(ref-496129-S20845077042012082100000) CAUTION: Cover neighboring paint surfaces with fabric-reinforced adhesive tape to protect against damage. Cut through adhesive along side wall frames using V.A.G 1561A and V.A.G 1561/22. Cut through adhesive bead on rear edge of panel 2. Cut through adhesive bead on forward edge of panel 3 using V.A.G 1561A and V.A.G 1561/2. Lift panel out of roof cutout using a suction lifter. When installing, panel 2 must be installed and closed. Clean new panel in adhesion area and prime. Apply adhesive onto residual adhesive bead. Insert panel into roof cutout. Align panel and press it evenly into roof cutout to stop. Secure panel in roof cutout with adhesive tape.
  5. Adhesive Bead for Panel 3 Cut back only just before installing a new panel. Apply adhesive onto residual adhesive bead on body.
Vehicle withAdhesive sealing materialMinimum curing time in hours
Sunroof moduleDA 004 600 A23

Removing and installing moving panel

To remove, open sunroof completely.

Scheme 26

Scheme 26: Removing and installing moving panel

Pull off cover -1- on body side from sunroof module to the side toward vehicle center.

Scheme 27

Scheme 27

Tilt open sunroof and pull off cover -2- to the side from sunroof panel -1-.

When installing, slide panel -1- sideways into retaining rail -2- on panel.

Scheme 28

Scheme 28

Remove bolts -arrows- on both sides of guide plate -1-.

Scheme 29

Scheme 29

Remove panel upward out of cutout.

When installing, tighten bolts to 3.5 Nm.

Glass sunroof panel, adjusting

Perform height adjustment at front and rear according to illustration to prevent wind noise.

Scheme 30

Scheme 30

Check height adjustment at each point, left and right, where rounded portion of roof opening merges with straight portion.

Sunroof panel should not be higher than roof at any point at front or lower than roof at any point at rear.

When adjusting sunroof panel height, start by running sunroof from open position (not tilted open) into closed position.

Adjusting

Loosen bolts -1- ; -2- and -3- a few turns.

Scheme 31

Scheme 31

Adjust panel.

Scheme 32

Scheme 32: GUIDE AND CABLE
  1. Bolt 3.5 Nm.
  2. Sunroof Frame The rear guide rail is removed. Remove the bolts -1- from the front guide rail and then remove the guide rail.
  3. Guide with Cable Removal: Molded headliner removed, refer to «Removal and Installation»(ref-496058-S22585871132012082100000) . The sunroof motor is removed. Remove the retaining strip for the wind deflector. The sunroof panel is removed. -- Sunroof crossmember, removing, refer to «SUN SHADE»(ref-496129-S04128108022012082100000) -- Remove the rear guide rails. -- Remove the sun shade. Remove the bolts -6- and -7- from underneath and the bolt -9- «GUIDE AND CABLE»(ref-496129-S17896209252012082100000) from the top and then remove the entire cable guide. Install in reverse order of removal.
  4. Sunroof Motor Removing and installing, refer to «SUNROOF MOTOR»(ref-496129-S11439215432012082100000)
  5. Bolt 3.5 Nm.
  6. Bolt 3.5 Nm.
  7. Bolt 3.5 Nm.
  8. Wind Deflector Retaining Strip Removed, refer to «GUIDE AND CABLE»(ref-496129-S17896209252012082100000)
  9. Bolt 3.5 Nm.
  10. Roof Module
  11. Rear Guide Hinge Remove the screws -12- to remove.
  12. Bolt 3.5 Nm.

Scheme 33

Scheme 33: Remove the wind deflector retaining strip

Remove the center bolts -arrows- (2x) and then the left and right outer bolts -arrow- and then remove the retaining strip.

Front sun shade, removing

Headliner lowered.

Remove the sunroof crossmember.

Push the adjusting clip -1- with the pin for securing the spring through hose in the axle -2- in direction of arrow.

Scheme 34

Scheme 34: Front sun shade, removing
CAUTIONBe careful not to damage the paint when unlocking the gliding piece. Use adhesive tape in this area.

Remove the gliding piece -2- on both sides in -direction of arrow- from the sun shade arch -1- with a screwdriver.

Scheme 35

Scheme 35

Remove the sun shade arch -1- from the gliding piece -2- in -direction of arrow-.

Scheme 36

Scheme 36

Remove the sun shade arch -1- from the gliding piece -2- in direction of arrow.

Scheme 37

Scheme 37

Remove the clip -1- from the axle opposite direction of -arrow-.

Scheme 38

Scheme 38

Install the shade -arrow A - and align both holes -arrow B- in the axle and in the shaft.

Scheme 39

Scheme 39

Secure the shade from rotating with a wire pin as illustrated and remove the shade.

Scheme 40

Scheme 40

Installing the front sun shade

Insert the flat axle -arrow- on the shade into the roof.

Scheme 41

Scheme 41

Insert the other end in to the mount on the opposite side.

Scheme 42

Scheme 42

Install the clip on the axle with pliers after installing the shade.

The illustration show the clip in the correct position.

Scheme 43

Scheme 43

Note. It is now not possible to slide the shade -2- from side to side.

Position the sun shade arch -arrow- on the gliding piece.

Scheme 44

Scheme 44

Install the sun shade arch into the sun shade arch in direction of -arrow-.

Scheme 45

Scheme 45

When installing -arrow A-, the sun shade arch -1- must fit completely into the gliding piece -2- and lock -arrow B-.

Scheme 46

Scheme 46

Scheme 47

Scheme 47

Slide the sun shade arch to the rear and remove it from the guides after removing the sun shade arch.

Note. The illustration shows the gliding piece from inside the vehicle.

Rear sun shade, removing

Headliner lowered.

Remove the sunroof crossmember.

Push the adjusting clip -1- with the pin for securing the spring through hose in the axle in direction of -arrow-.

Remove the sun shade arch from the guides on the sunroof as illustrated.

Scheme 48

Scheme 48

Install the shade -arrow A - and align both holes -arrow B- in the axle and in the shaft.

Secure the shade from rotating with a wire pin as illustrated and remove the shade.

Installing the rear sun shade

To install, perform the steps used in removal in reverse order.

Install the clip on the axle with pliers after installing the sun shade.

The illustration show the clip in the correct position.

Note. It is now not possible to slide the shade -2- from side to side.

Scheme 49

Scheme 49: Sunroof crossmember
  1. Cross Member for Sunroof The headliner is just lowered and not removed. To remove, remove bolts -2-. Connecting parts at left -3- and right -5- remain in the vehicle.
  2. Bolts 7 Nm
  3. Left Connecting Part
  4. Bolt 3.5 Nm
  5. Right Connecting Part
  6. Headliner Lower but do not remove; refer to «Removal and Installation»(ref-496058-S22585871132012082100000)
  7. Rear Sun Shade Removal, refer to «SUN SHADE»(ref-496129-S04128108022012082100000)
  8. Front Sun Shade Removal, refer to «SUN SHADE»(ref-496129-S04128108022012082100000)

Special tools and workshop equipment required

Scheme 50

Scheme 50: SUNROOF MOTOR
  1. Special hook 3370

Removal

Note. Remove motor only in >>roof closed<< position.

Close glass sunroof, use emergency operation if necessary. Refer to SUNROOF PANEL

Remove the reading lamp cover carefully using special tool 3370.

Scheme 51

Scheme 51

If applicable, disconnect the connection -1- from the hands-free microphone.

Scheme 52

Scheme 52

Remove bolts -arrows-.

Scheme 53

Scheme 53

Tip front interior light/reading light down and remove it from vehicle headliner.

Disconnect electrical connectors.

Remove bolts -arrows-.

Scheme 54

Scheme 54

Remove sunroof motor -2- from opening in vehicle headliner.

Disconnect the connector -1-.

Installation

Installation is reverse of removal, noting the following

Install motor only in >>roof closed<< position.

Tightening Specifications

ComponentNm
Sunroof motor to body3.5
