UPPER A-PILLAR TRIM
Special tools and workshop equipment required
Scheme 131
- 80-200
Removing
| WARNING | Observe safety precautions for work on airbags. |
Remove A-pillar trim -3- from A-pillar by hand in area of rubber seal until 80-200 can be inserted at the upper clip -2-.
Scheme 132
Using 80-200, press clips -1- and -2- one after another out of A-pillar as far as catch.
Remove A-pillar trim -1- upward -arrow-.
- In this way, the clips are completely loosened from their guide in the A-pillar.
Disconnect speaker electrical connector.
Scheme 133
Installation
Scheme 134
Installation is reverse of removal, but note the following
Slide A-pillar trim into guide on instrument panel.
When positioning A-pillar trim, ensure guide pins -2- under upper clip -1- can be inserted in groove on A-pillar.
Note. If the guide pins cannot be inserted in the groove, the A-pillar trim cannot be pressed on completely. When installing trim, ensure seal is seated correctly.
