Interior Equipment: Overview Audi A3 8P facelift

INTERIOR REARVIEW MIRROR GENERAL INFORMATION

There are different versions of the interior rearview mirrors, each with different features

1. Manual dimming interior rearview mirror
2. Automatic Dimming Interior Rearview Mirror -Y7
3. Interior rearview mirror with digital compass
4. Interior rearview mirror with rain/light recognition sensor
5. Interior rearview mirror with Rain/Light Recognition Sensor -G397
6. Interior rearview mirror with Humidity Sensor -G355

Scheme 1

1. Center Console Removing and Installing, refer to «CENTER CONSOLE»(ref-496033-S13520963372012082100000)
2. Left Grab Handle Removing and Installing, refer to «LEFT AND RIGHT GRAB HANDLE»(ref-496033-S25898525712012082100000)
3. Center Console Net Only installed on passenger side Removing and installing, refer to «CENTER CONSOLE NET»(ref-496033-S07040037122012082100000)
4. Storage Compartment Cover Only installed in conjunction with front ashtray. Removing and Installing, refer to «STORAGE COMPARTMENTS, VERSION 1 WITH SMOKING PACKAGE»(ref-496033-S20941273462012082100000)
5. Front Ashtray Removing and installing, refer to «STORAGE COMPARTMENTS, VERSION 1 WITH SMOKING PACKAGE»(ref-496033-S20941273462012082100000) ; «STORAGE COMPARTMENTS, VERSION 2 WITH SMOKING PACKAGE»(ref-496033-S19770224302012082100000)
6. Lining Mat Only on vehicles with front ashtray. Removing and installing «STORAGE COMPARTMENTS, VERSION 1 WITH NON-SMOKING PACKAGE»(ref-496033-S31194830062012082100000) ; «STORAGE COMPARTMENTS, VERSION 2 WITH NON-SMOKING PACKAGE»(ref-496033-S40582135942012082100000)
7. Right Grab Handle Removing and Installing, refer to «LEFT AND RIGHT GRAB HANDLE»(ref-496033-S25898525712012082100000) Cigarette lighter, removing and installing, refer to «CIGARETTE LIGHTER»(ref-496033-S37626196852012082100000)
8. Securing Frame with Selector Lever Boot Removing and Installing, refer to «SHIFT MECHANISM COVER AND SECURING FRAME WITH SELECTOR LEVER BOOT»(ref-496033-S39013123732012082100000)
9. Shift Mechanism Cover Manual transmission, removing and installing, refer to «SHIFT MECHANISM COVER AND SECURING FRAME WITH SELECTOR LEVER BOOT»(ref-496033-S39013123732012082100000) Automatic transmission, removing and installing, refer to «SHIFT MECHANISM COVER AND SECURING FRAME WITH SELECTOR LEVER BOOT»(ref-496033-S39013123732012082100000)
10. Function Selector Switch II -E272- Removing and Installing, refer to «Removal and Installation»(ref-496064-S32204615902012082100000)
11. Mount with Cigarette Lighter and Cover Unit is not disassembled Removing and Installing, refer to «MOUNT WITH CIGARETTE LIGHTER AND COVER»(ref-496033-S27857360742012082100000) Socket, removing and installing, refer to «12 VOLT SOCKET»(ref-496033-S27881621342012082100000)
12. Cigarette Lighter with Mount Removing and Installing, refer to «CIGARETTE LIGHTER»(ref-496033-S37626196852012082100000)
13. Socket with Cover and Mount Only for vehicles without smoking package Removing and Installing, refer to «12 VOLT SOCKET»(ref-496033-S27881621342012082100000)
14. Lining Mat Placed in storage compartment
15. Storage Compartment Removing and Installing, refer to «STORAGE COMPARTMENT»(ref-496033-S38923819642012082100000)
16. Center Armrest Removing and Installing, refer to «CENTER ARMREST»(ref-496033-S34253209902012082100000) Disassembling and assembling, refer to «CENTER ARMREST»(ref-496033-S21600582842012082100000)
17. Rear Ashtray Removing and Installing, refer to «REAR ASHTRAY»(ref-496033-S02807559912012082100000)
18. Rear Storage Compartment Removing and Installing, refer to «REAR STORAGE COMPARTMENT»(ref-496033-S08184254592012082100000)
19. Mount with Left/Right Heated Rear Seat Control Module Removing and Installing, refer to «MOUNT WITH LEFT AND RIGHT REAR HEATED SEAT CONTROL MODULE»(ref-496033-S03791700552012082100000)
20. Cupholder Masking Panel Compartment Removing and Installing, refer to «MASKING PANEL COMPARTMENT»(ref-496033-S04753580602012082100000)
21. Cupholder
22. Parking Brake Cover Removing and Installing, refer to «PARKING BRAKE COVER»(ref-496033-S30092556772012082100000)

Scheme 2

1. Center Console Removing and Installing, refer to «CENTER CONSOLE»(ref-496033-S13520963372012082100000)
2. Front Ashtray Removing and installing, refer to «STORAGE COMPARTMENTS, VERSION 1 WITH SMOKING PACKAGE»(ref-496033-S20941273462012082100000) ; «STORAGE COMPARTMENTS, VERSION 2 WITH SMOKING PACKAGE»(ref-496033-S19770224302012082100000)
3. Storage Compartment Cover Only installed in conjunction with front ashtray. Removing and Installing, refer to «STORAGE COMPARTMENTS, VERSION 1 WITH SMOKING PACKAGE»(ref-496033-S20941273462012082100000)
4. Bolt 3.5 Nm
5. Retaining Clip
6. Mount with Cigarette Lighter and 12-volt Socket Unit is not disassembled Removing and Installing, refer to «CIGARETTE LIGHTER AND 12V OUTLET MOUNT»(ref-496033-S18500250962012082100000)
7. Front Center Armrest Removing and Installing, refer to «CENTER ARMREST»(ref-496033-S34253209902012082100000) Disassembling and assembling, refer to «CENTER ARMREST»(ref-496033-S21600582842012082100000)
8. Bolt 14 Nm
9. Rear Ashtray Removing and Installing, refer to «REAR ASHTRAY»(ref-496033-S02807559912012082100000)
10. Rear Central Locking Switch Mount Removing and Installing, refer to «REAR CENTRAL LOCKING SWITCH MOUNT»(ref-496033-S12470988082012082100000)
11. Masking Panel Compartment Removing and Installing, refer to «MASKING PANEL COMPARTMENT»(ref-496033-S04753580602012082100000)

Scheme 3

1. Glove Compartment with CD Changer -R41
2. Front Passenger's Airbag -Off- Key Switch -E224- Not available for North American market.
3. Glove Compartment Light Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] GLOVE COMPARTMENT LAMP»(ref-496056-S19024778222012082100000)
4. Glove Compartment Supply Wire/Wiring Harness Connector
5. Footwell Light Removing and Installing, refer to «[For engine(s) CBRA, BPY, CCTA, CBFA] FOOTWELL BULB»(ref-496056-S00653663112012082100000)
6. Glove Compartment Wiring Harness with CD Changer -R41- Secure glove compartment wiring harness -1- with clips -arrows-.
7. Lid Dampening Mechanism With Glove Compartment Lamp Switch -E26- Removing and Installing, refer to «GLOVE COMPARTMENT COVER BRAKE»(ref-496033-S04206685982012082100000)
8. Glove Compartment with Map Compartment
9. Glove Compartment Wiring Harness Secure glove compartment wiring harness -8- with clips -arrows-.
10. Glove Compartment without Map Compartment
11. Glove Compartment Wiring Harness Secure glove compartment wiring harness -11- with clips -arrows-.
