LEFT ANTENNA MODULE
Switch off all electrical consumers.
Remove the key.
Removing
Remove the rear lid lower trim panel. Refer to Removal and Installation .
Disconnect all the connectors from the left antenna module -R108-.
Pay attention to the connector leading to the rear window -arrow-.
Scheme 60
Loosen the nut -3- (6 Nm).
Remove the screws -1- and -2- (6 Nm).
Remove the left antenna module from the rear lid.
Installing
Install in reverse order of removal.
Pay attention to the connector leading to the rear window -arrow-.
