Fuses & Circuit Breakers Audi A3 8P рестайлинг 2

Fuses & Circuit Breakers 19 illustrations ~2605 words

IDENTIFICATION

WARNINGVehicles are equipped with air bag supplemental restraint system. Before attempting any repairs involving steering column, instrument panel or related components, see AIRBAG SAFETY PRECAUTIONS in RESTRAINS article.

ENGINE CODE

Engines are identified by a 3 or 4 letter code stamped onto the engine block, for engine identification see engine code on the vehicle data plate.

Engine DisplacementEngine Stamp Code
2.0L
2006-07BPY
2008BPY, CBFA, CCTA
2009CBFA, CCTA
3.2L
2006-07BUB
2008-09CBRA

1.1- Overview Of Fuses

Note. For relay identification within the relay and fuse holder panels, refer to Overview Of Relays under RELAYS.

Scheme 1

Scheme 1: 1.1- Overview Of Fuses
Scheme 1: 1.1- Overview Of Fuses
Location No.DescriptionRefer To Illustration
1Fuse Panel A -SA(Scheme 2), (Scheme 3), (Scheme 4)
2Relay / Fuse Panel B -SB(Scheme 5), (Scheme 6)
3Fuse Panel C -SC(Scheme 7)
4Fuse Panel D -SD(Scheme 8)
5Fuses Under Instrument Panel, Left(Scheme 9)

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

1 - Fuse Panel A -SA

For relay and fuse panel location and position, refer to appropriate information under 1.2- MAIN FUSE PANEL: A -SA- ON ELECTRONICS BOX LOW (FROM MODEL YEAR 2006) .

  1. Location Main Fuse Panel, Electronics Box Low, from model year 2006.
  2. Position of Fuses Main Fuse Panel, Electronics Box Low, from model year 2006.
  3. Position of Fuses Main Fuse Panel, Electronics Box Low, from model year 2007.
  4. Location Main Fuse Panel, Electronics Box Low, from November 2008.
  5. Position of Fuses Main Fuse Panel, Electronics Box Low, from November 2008.

For relay and fuse panel location and position, refer to appropriate information under 1.7- MAIN FUSE PANEL A -SA- ON ELECTRONICS BOX HIGH .

  1. Location Main Fuse Panel, Electronics Box High.
  2. Position of Fuses Main Fuse Panel, Electronics Box High, from model year 2006.

2 - Fuse Panel B -SB

For relay and fuse panel location and position, refer to appropriate information under 1.12- FUSE PANEL B -SB- ON ELECTRONICS BOX LOW, ENGINE COMPARTMENT, LEFT SIDE .

  1. Location Electronics Box Low.
  2. Fuse Arrangements Electronics Box Low, from model year 2006.
  3. Fuse Arrangements Electronics Box Low, from model year 2007.

For relay and fuse panel location and position, refer to appropriate information under 1.15 - FUSE PANEL B -SB- ON ELECTRONICS BOX HIGH, ENGINE COMPARTMENT, LEFT SIDE .

  1. Location Electronics Box High.
  2. Position of Fuses Electronics Box High, from model year 2006.
  3. Position of Fuses Electronics Box High, from model year 2007.

3 - Fuse Panel C -SC

For relay and fuse panel location and position, refer to appropriate information under 1.19- FUSE PANEL C -SC- INSTRUMENT PANEL - LEFT SIDE .

  1. Location.
  2. Position of Fuses from model year 2006.
  3. Position of Fuses, from model year 2007.

4 - Fuse Panel D -SD

For relay and fuse panel location and position, refer to appropriate information under 1.23 - MAIN FUSE PANEL D -SD- IN LUGGAGE COMPARTMENT, RIGHT REAR .

  1. Location Main Fuse Panel.
  2. Position of Fuses Main Fuse Panel, from model year 2006.

5 - Fuses Under Instrument Panel, Left

For relay and fuse panel location and position, refer to appropriate information under 1.26- FUSES UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006) .

  1. Component: -S37- , -S280- and -S131-.
  2. Position of Fuses, from model year 2006.

1.1- Overview Of Relays

Note. For fuse identification within the relay and fuse holder panels, refer to 1.1- Overview Of Fuses under fuses.

Scheme 10

Scheme 10: 1.1- Overview Of Relays
Scheme 10: 1.1- Overview Of Relays
Location No.DescriptionRefer To Illustration
1Relay Carrier on Electronics Box (In engine compartment, left side)(Scheme 11), (Scheme 12)
2Relay Arrangements (Under left instrument panel)(Scheme 15)
3Position of Relays on Main Fuse Panel (In luggage compartment, right rear side)(Scheme 18)
4Relay Carrier on Vehicle Electrical System Control Module (Under instrument panel, left side)(Scheme 13), (Scheme 14)
5Relay Carrier Under Electronics Box (In engine compartment, left side)(Scheme 16), (Scheme 17)

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

1 - Relay Carrier On Electronics Box, In Engine Compartment, Left Side

  1. Component:-J271-, -J317-, -J363-, -J757-, -J329.
  2. Position of Relays Electronics Box Low, from model year 2006. - Refer to «1.2- POSITION OF RELAYS ON ELECTRONICS BOX LOW, FROM MODEL YEAR 2006»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__12-position-of-relays-on-electronics) .
  3. Position of Relays Electronics Box High, from model year 2006. - Refer to «1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH, FROM MODEL YEAR 2006»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__14-position-of-relays-on-electronics) .

2 - Relay Arrangements, Under Left Instrument Panel

  1. Component: -J17-,-J49-,-J359-, J906-, -J907-, -J910
  2. Position of Relays, from model year 2006. - Refer to «1.7- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006)»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__17-position-of-relays-under-instrument) .
  3. Position of Relays, from model year 2009. - Refer to «1.8- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2009)»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__18-position-of-relays-under-instrument) .

3 - Position Of Relays On Main Fuse Panel, In Luggage Compartment, Right Rear

  1. Component: -J655-, -N253-.
  2. Position of Relays, from model year 2006. - Refer to «1.11- POSITION OF RELAYS ON MAIN FUSE PANEL, IN LUGGAGE COMPARTMENT - RIGHT REAR»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__111-position-of-relays-on-main) .

4 - Relay Carrier On Vehicle Electrical System Control Module, Under Instrument Panel, Left Side

  1. Component: -J681- , -J9- , -J413- , -J59- , -J729- , -J689- , -J730-.
  2. Position of Relays, from model year 2006. - Refer to «1.5- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE, FROM MODEL YEAR 2006»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__15-position-of-relays-relay-carrier) .
  3. Position of Relays, from model year 2010. - Refer to «1.6- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2010)»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__16-position-of-relays-relay-carrier) .

5 - Relay Carrier Under Electronics Box

  1. Component:-J179-, -J299-.
  2. Position of Relays, from model year 2006. - Refer to «1.9- POSITION OF RELAYS UNDER ELECTRONIC BOX»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers__19-position-of-relays-under-electronic) .

FUSES - CIRCUIT PROTECTION

WARNINGNever replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and possible cause a fire.

For access to instrument panel fuse box, refer to illustration below.

Scheme 19

Scheme 19
Scheme 19

The individual circuits are protected by fuses. The fuse panels with the fuses are located in the engine compartment, in the passenger compartment on the left front face of the instrument panel behind a cover and in the right storage area in the luggage compartment.

There is a plastic clip (fuse puller) in the cover on the left side of the instrument panel, which can be used to remove the fuses. The crank handle is used for emergency operation of the power roof (if equipped).

Two spare fuses and a sticker identifying the fuses are located on the inside of the fuse box cover.

Fuses with the proper ampere ratings are available at your Audi dealer.

Note. On no account should fuses be repaired (e.g. with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire. If a fuse blows repeatedly, do not keep replacing it. Proceed to diagnose and fix shorted or overloaded circuit.

AUTOMATIC CIRCUIT BREAKERS

The electric seat adjusters are protected with circuit breakers which reset automatically after the circuit overload has been corrected.

Fuse - Color Codes

Identifying fuse color and ampere rating, refer to table below.

WARNINGNever replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire.
Current Rating AmperesColor
1ABlack
3AViolet
5ALight Brown
7.5ABrown
10ARed
15ABlue
20AYellow
25AWhite or Natural
30AGreen
35AGreen-Blue
40AOrange
50ARed
60AYellow
100ABlue

IDENTIFYING FUSE BY COLOR

Replacing A Fuse

A problem in the electrical system may be caused by a blown fuse.

  1. Switch off the ignition and the electrical component affected.
  2. Carefully pry the face cover off the instrument panel using the ignition key or a screwdriver. (Scheme 19)
  3. Check the fuse index to find out which fuse belongs to the component which has failed. See «FUSE INDEX INFORMATION»(/audi/a3/8p-2-2008-2013/remont/fuses-circuit-breakers/#fuses-circuit-breakers).
  4. Remove the blown fuse with the plastic clip provided. The clip is located on the holder in the fuse box cover.
  5. Replace a blown fuse (recognizable by the melted metal strip inside) with a fuse of the same amperage.
  6. Firmly snap the cover back onto the instrument panel face.

1.2- MAIN FUSE PANEL: A -SA- ON ELECTRONICS BOX LOW (FROM MODEL YEAR 2006)

Note. The fuse panel A -SA- is located on the left side of the engine compartment, refer to illustration below.

For fuse identification and amperage rating refer to FUSE - COLOR CODES .

1.2.1 - MAIN SUPPLY CONNECTION

M - Threaded connection M (terminal 30). see scheme 20

1.3 - FUSE ARRANGEMENTS ELECTRONICS BOX LOW, FROM MODEL YEAR 2006

Location/ PositionRating (A)Function/ComponentWiring IDTerminal
1150AGenerator (GEN) -C- (70A) Generator (GEN) -C- (90A) Generator (GEN) -C- (110A) Generator (GEN) -C- (120A)SA130
1200AGenerator (GEN) -C- (140A)SA130
280APower Steering Control Module -J500SA230
350ACoolant Fan Control (FC) Control Module -J293- Coolant Fan Control (FC) Thermal Switch -F18- Coolant Fan -V7SA330
480AFuses Supply: -SC12- through -SC17- -SC19- -SC22- through -SC27- -SC28- -SC38- Not applicable from November 2005SA430
580AFuses Supply: -SC12- through -SC17- -SC19- -SC22- through -SC27- -SC28- -SC38- Not applicable from November 2005SA530
5100AAuxiliary Air Heater Control Module -J604- Not Applicable from November 2005SA530
6100AAuxiliary Air Heater Control Module -J604- Applicable from November 2005SA630
750ADoctor OptionSA730
80APolice OptionSA730

IDENTIFYING FUSES (MAIN FUSE PANEL A -SA- ELECTRONIC BOX LOW - FROM MODEL YEAR 2006)

1.4 - FUSE ARRANGEMENTS ELECTRONICS BOX LOW, FROM MODEL YEAR 2007

Location/ PositionRating (A)Function/ComponentWiring IDTerminal
1150AGenerator (GEN) -C- (70A) Generator (GEN) -C- (90A) Generator (GEN) -C- (110A) Generator (GEN) -C- (120A)SA130
1200AGenerator (GEN) -C- (140A)SA130
280APower Steering Control Module -J500SA230
350ACoolant Fan Control (FC) Control Module -J293- Coolant Fan Control (FC) Thermal Switch -F18- Coolant Fan -V7SA330
440APreheating Coolant, Low Heat Output Relay -J359- Applicable from November 2006SA430
580AB272 Plus Connection (30) (in main wiring harness) Fuses Supply: -SC12 through -SC 17-, -SC22- through -SC27-, -SC28-, -SC38-, -SC43SA530
6100AAuxiliary Air Heater Control Module -J604- Not Applicable from November 2006SA630
680APreheating Coolant, High Heat Output Relay -J360- Applicable from November 2006SA630
750ADoctor OptionSA730
780APolice OptionSA730
730AElectronic Damping Control Module -J250- Applicable from May 2008SA730

IDENTIFYING FUSES (MAIN FUSE PANEL A -SA- ELECTRONIC BOX LOW - FROM MODEL YEAR 2007)

1.5- MAIN FUSE PANEL: LOCATION FUSE PANEL A -SA- ON ELECTRONICS BOX LOW (FROM NOVEMBER 2008)

Note. The fuse panel A -SA- is located on the left side of the engine compartment, refer to illustration below.

For fuse identification and amperage rating refer to FUSE - COLOR CODES .

1.5.1 - MAIN SUPPLY CONNECTION

M - Threaded connection M (terminal 30). see scheme 21

1.6 - FUSE ARRANGEMENTS ELECTRONICS BOX LOW, FROM MODES YEAR 2007

Location/ PositionRating (A)Function/ComponentWiring IDTerminal
1150AGenerator (GEN) -C- (70A) Generator (GEN) -C- (90A) Generator (GEN) -C- (110A) Generator (GEN) -C- (120A)SA130
1200AGenerator (GEN) -C- (140A)SA130
280APower Steering Control Module -J500SA230
350ACoolant Fan Control (FC) Control Module -J293- Coolant Fan Control (FC) Thermal Switch -F18- Coolant Fan -V7SA330
480APreheating Coolant, High Heat Output Relay -J360SA430
580AB272 Plus Connection (30) (in main wiring harness) Fuses Supply: -SC12 through -SC 17-, -SC22- through -SC27- -SC28- -SC38- -SC43SA530
640APreheating Coolant, High Heat Output Relay -J359SA630
750ADoctor Option Not Applicable from May 2009SA730
750ADoctor or Police Option Applicable from May 2009SA730
780APolice Option Not Applicable from May 2009SA730
730AElectronic Damping Control Module -J250SA730

IDENTIFYING FUSES (MAIN FUSE PANEL A -SA- ELECTRONIC BOX LOW - FROM NOVEMBER 2008)

1.7- MAIN FUSE PANEL A -SA- ON ELECTRONICS BOX HIGH

Note. The fuse panel A -SA- is located on the left side of the engine compartment, refer to illustration below.

1.7.1 - MAIN SUPPLY CONNECTION

  1. Threaded connection A (terminal 30). see scheme 22
  2. Threaded connection M (terminal 30).
  3. Threaded connection L (terminal 30).

1.10 - ELECTRONICS BOX HIGH, ENGINE CODES AXX, BWA, BPY, BHZ, BZC, CDLA, CDLC, FROM MODEL YEAR 2006

Location/ PositionRating (A)Function/ComponentWiring IDTerminal
4150AGenerator (GEN) -C- (70A) Generator (GEN) -C- (90A) Generator (GEN) -C- (110A) Generator (GEN) -C- (120A)SA130
4200AGenerator (GEN) -C- (140A)SA130
580APower Steering Control Module -J500SA230
650ACoolant Fan Control (FC) Control Module -J293SA330
780AFuses Supply: -SC12- through -SC17-, -SC19-, -SC22- through -SC27-, -SC28-, -SC38- Not applicable from November 2005SA430
780AFuses Supply: -SC12- through -SC17-, -SC22- through -SC27-, -SC28-, -SC38-, -SC43- Applicable from May 2009SA430
880AFuses Supply: -SC12- through -SC17-, -SC19-, -SC22- through -SC27-, -SC28-, -SC38- Applicable from November 2005SA530
880AFuses Supply: -SCI2- through -SC17-, -SC22- through -SC27-, -SC28-, -SC38-, -SC43- Applicable from May 2006 Not applicable from May 2009SA530
9Not usedSA6
1050ADoctor Option Not Applicable from May 2009SA730
1050ADoctor or Police Option Applicable from May 2009SA730
1080APolice Option Not Applicable from May 2009SA730
1030AElectronic Damping Control Module -J250- Applicable from May 2008SA730

IDENTIFYING FUSES (MAIN FUSE PANEL A -SA- ELECTRONIC BOX HIGH - FROM MODEL YEAR 2006)

1.11 - ELECTRONICS BOX HIGH, ENGINE CODES BMJ, BUB, CBRA, FROM MODEL YEAR 2006

Location/ PositionRating (A)Function/ComponentWiring IDTerminal
4150AGenerator (GEN) -C- (70A) Generator (GEN) -C- (90A) Generator (GEN) -C- (110A) Generator (GEN) -C- (120A)SA130
4200AGenerator (GEN) -C- (140A)SA130
580APower Steering Control Module -J500SA230
650ACoolant Fan Control (FC) Control Module -J293SA330
780AFuses Supply: -SC22- through -SC27-, -SC2S-, -SC38- Applicable from May 2009SA430
880AFuses Supply: -SC22- through -SC27-, -SC28-, -SC38- Not applicable from May 2009SA530
950AFuses Supply: -SC12- through -SC17-, -SC19-, -SC44-, -SC45- Not applicable from November 2005SA630
950AFuses Supply: -SC44-, -SC45- Applicable from November 2005SA630
1050ADoctor Option Not Applicable from May 2009SA730
1050ADoctor or Police Option Applicable from May 2009SA730
1080APolice Option Not Applicable from May 2009SA730
1030AElectronic Damping Control Module -J250- Applicable from May 2008SA730

IDENTIFYING FUSES (MAIN FUSE PANEL A -SA- ELECTRONIC BOX HIGH - FROM MODEL YEAR 2006)

1.12- FUSE PANEL B -SB- ON ELECTRONICS BOX LOW, ENGINE COMPARTMENT, LEFT SIDE

Note. The relay and fuse panel B -SB- is located in electronic box on left side of the engine compartment, refer to illustration below. For relay identification related to relay and fuse panel B -SB- refer to appropriate POSITION OF RELAYS ON ELECTRONICS BOX under RELAY INDEX INFORMATION .

1.12.1 - FUSE COLOR: For fuse identification and amperage rating refer to FUSE - COLOR CODES .

1.13 - FUSE ARRANGEMENTS ELECTRONICS BOX LOW, FROM MODEL YEAR 2006

Fuse No.Rating (Amperage)Function/ComponentWiring ID.Terminal
F120AComfort System Central Control Module -J393SB130
F25ASteering Column Electronic Systems Control Module -J527SB230
F35AVehicle Electrical System Control Module -J519SB330
F430AABS Control Module -J104- ABS Hydraulic Unit -N55SB430
F515ADirect Shift Gearbox (DSG) Mechatronic -J743SB530
F65AInstrument Cluster Control Module -J285SB630
F7Not used
F815ARadio -R- Navigation System Operating Electronics Control Module -J402SB830
F95ANavigation System Control Module with CD drive -J401- Navigation System Tuner, TV -J415- Satellite Radio -R146- Telephone Transceiver -R36- Amplifier for telephone -R86SB930
F105AMotronic Engine Control Module (ECM) -J220- Motronic Engine Control Module (ECM) Power Supply Relay -J271- Power Supply Relay (terminal 30) -J317SB1030
F1120AAuxiliary Heater Control Module -J364SB1130
F125AData Bus On Board Diagnostic Interface -J533SB1230
F1330AEngine Control Module (ECM) -J623- Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248SB1387
F1325AMotronic Engine Control Module (ECM) -J220- Engine Control Module (ECM) -J623SB1387
F1420AIgnition Coil 1 with Power Output Stage -N- Ignition Coil 2 -N128- Ignition Coil 1 with Power Output Stage -N70- Ignition Coil 2 with Power Output Stage -N127- Ignition Coil 3 with Power Output Stage -N291- Ignition Coil 4 with Power Output Stage -N292SB1487
F1515AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z30- Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z64SB1587
F1510AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29SB1587
F155AAutomatic Glow Time Control Module -J179- Fuel Pump (FP) Relay -J17SB1587
F1630AABS Control Module -J104- ABS Hydraulic Pump -V64SB1630
F1715AHigh Tone Horn -H2- Low Tone Horn -H7SB1730
F1830AAmplifier -R12- Bass Speakers Amplifier, in luggage compartment, left -R44SB1830
F1930AWiper Motor Control Module -J400SB1930
F20
F2115AOxygen Sensor (O2S) Heater -Z19- Oxygen Sensor (O2S) Heater 2 -Z28- Oxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic ConverterSB2187
F2110AOxygen Sensor(O2S) Heater -Z19SB2187
F225ABrake Pedal Switch -F63- Clutch Position Sensor -G476SB2287
F2315AFuel Pressure Regulator Valve -N276SB2387
F2310AEGR Vacuum Regulator Solenoid Valve -N18- Wastegate Bypass Regulator Valve -N75- EGR Valve 2 -N213- Exhaust Gas Recirculation (EGR) Cooler Switch-Over Valve -N345SB2387
F235ASecondary Air Injection (AIR) Pump Relay -J299SB2387
F2410AMap Controlled Engine Cooling Thermostat -F265- Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- Intake Manifold Tuning (IMT) Valve -N156- Camshaft Adjustment Valve 1 -N205- Intake Flap Motor -V157SB2487
F2540AVehicle Electrical System Control Module -J519- (Right Parking Lamp, Right High Beam Lamp, Right Low Beam Lamp, Right Parking Lamp, Right Front Fog Lamp)SB2530
F2640AVehicle Electrical System Control Module -J519- (Left Parking Lamp, Left High Beam Lamp, Left Low Beam Lamp, Left Parking Lamp, Left Front Fog Lamp)SB2630
F2750AAutomatic Glow Time Control Module -J179- Glow Plug 1 -Q10- Glow Plug 2 -Q11- Glow Plug 3 -Q12- Glow Plug 4 -Q13SB2787
F2740ASecondary Air Injection (AIR) Pump Motor -V101SB2787
F2840APower Supply Relay 2 (terminal 15) -J681- Fuses Supply: -SC1- through -SC6-, -SC7- through -SC11-, -SC29- through -SC31-, - SC39-, -SC47-, -SC49SB2830
F2950AFuses Supply: -SC18-, -SC20-, -SC32-through-SC37-, -SC44-, -SC45-, -SC48-, -S131SB2930
F3050A (1)Load Reduction Relay -J59- Fuses Supply: -SC40-, -SC41-, -SC42-, -SC46SB3030
(1) Fuse was increased from 40A to 50A, applicable from November 2005.
(1)Fuse was increased from 40A to 50A, applicable from November 2005.

IDENTIFYING FUSES (ELECTRONICS BOX LOW - FROM MODEL YEAR 2006)

1.14 - FUSE ARRANGEMENTS ELECTRONICS BOX LOW, FROM MODEL YEAR 2007

Fuse No.Rating (Amps)Function/ComponentWiring ID.Terminal
F140AVoltage Stabilizer -J532- Fuses Supply: -SC7- through -SC11- (Only models with stop/start system, Applicable from model year 2010)SB130
F140AFuses Supply: (Only models without stop/start system, Applicable from model year 2010)SB130
F25ASteering Column Electronic Systems Control Module -J527- (Not applicable from model year 2009)SB230
F230ADirect Shift Gearbox (DSG) Mechatronic -J743- (7-Speed Direct Shift Gearbox OAM) Applicable from model year 2009SB230
F220AFuel Pressure Regulator Valve -N276- (CBFA) (From model year 2009)SB230
F35AVehicle Electrical System Control Module -J519SB330
F35ABattery Monitoring Control Module -J367- (Applicable from model year 2010)SB330
F430AABS Control Module -J104- (MK60 ESP-Valves) ABS Control Module -J104- (MK70 ABS-Valves) (Not applicable from model year 2009)SB430
F420AABS Control Module -J104- (MK60 ESP-Valves) (Applicable from model year 2009)SB430
F515ADirect Shift Gearbox (DSG) Mechatronic -J743SB530
F65AInstrument Cluster Control Module -J285- (Not applicable from model year 2010)SB630
F65ASteering Column Electronic Systems Control Module -J527- (Applicable from model year 2009)SB630
F720AFuel Pressure Regulator Valve -N276- (CBFA) (Not applicable from model year 2009)SB730
F815ANavigation System Operating Electronics Control Module -J402- Radio/Navigation Display Control Module -J503- Radio -R- (Not applicable from model year 2010)SB830
F825ARadio/Navigation Display Control Module -J503- (1) Only with radio/navigation system Japan (Not applicable from model year 2010)SB830
F95ANavigation System Control Module with CD drive -J401- (1) Navigation System Tuner, TV -J415 (1) Satellite Radio -R146- Telephone Transceiver -R36- Amplifier for telephone -R86- (1) 18-Pin Connector -T18a- (VDA-Interface) (1) (Not applicable from model year 2010)SB930
F105APower Supply Relay (terminal 30) -J317- (BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB, CAYC, CBFA)SB1030
F105AEngine Control Modules (ECM) -J- (CAXC, CBBB, CBAB, CBAA, CAYB, CAYC, CBFA) Motronic Engine Control Module (ECM) Power Supply Relay -J271- (CAXC)SB1030
F1010AEngine Control Modules (ECM) -J...- (BLF, BPT, BPU, BVZ, BVY, BZB, CAWB, CBFA, CCTA, CDAA, CCZA) Motronic Engine Control Module (ECM) Power Supply Relay -J271- (BLF, BPT, BPU, BVZ, BVY, BZB, CAWB, CBFA, CCTA, CDAA, CCZA)SB1030
F1120AAuxiliary Heater Control Module -J364- (1)SB1130
F125AData Bus On Board Diagnostic Interface -J533SB1230
F1330AEngine Control Modules (ECM) -J- (BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB, CAYC, CBFA)SB1387
F1325AEngine Control Modules (ECM) -J...- (BLF, BPT, BPU, B BVZ, BVY, BSE, BSF) Not applicable from May 2007, only models with engine codes BSE, BSFSB1387
F1315AEngine Control Modules (ECM) -J...- (CAXC, BZB, CAWB, CBFA, CCTA, CDAA, CCZA) Applicable from May 2007. only models with engine codes BSE, BSF, CCSASB1387
F1420AIgnition Coil 1 with Power Output Stage -N- (BSE, BSF, CCSA) Ignition Coil 2 -N128- (BSE, BSF, CCSA)SB1487
F1420AIgnition Coil 1 with Power Output Stage -N70- Ignition Coil 2 with Power Output Stage -N127- Ignition Coil 3 with Power Output Stage -N291- Ignition Coil 4 with Power Output Stage -N292- (Only models with engine codes BLF, BPT, BPU, BYT, BVZ, BVY, CAXC, BZB, CAWB, CBFA, CCTA, CD CCZA)SB1487
F1420AFuel Pressure Regulator Valve -N276- (CBBB, CBAB, CBAA, CAYB, CAYC, CBFA) Fuel Metering Valve -N290- (CBBB, CBAB, CBAA, CAYB, CAYC, CBFA)SB1487
F1515AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (BVY) Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z30- (BVY) Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z64- (BVY)SB1587
F1510AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (BVZ)SB1587
F1510AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (CAXC) Oxygen Sensor (O2S) Heater 1 -Z19- (CAXC)SB1587
F155ACamshaft Adjustment Valve 1 -N205- (BPT, BPU, BYT)SB1587
F155ARadiator Identification Sensor -G611- (CBFA) Leak Detection Pump (LDP) -V144- (CBFA, CCTA) Oxygen Sensor (O2S) Heater 1 -Z19- (CBFA)SB1587
F155AFuel Pump (FP) Relay -J17- Automatic Glow Time Control Module -J179- Only models with engine codes BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB, CAYC, CBEASB1587
F155APreheating Coolant, Low Heat Output Relay -J359- Preheating Coolant High Heat Output Relay -J360- Only models with engine codes BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB, CAYC, CBEA Applicable from November 2006, only models with auxiliary air heaterSB1587
F155AAuxiliary Fuel Pump Relay -J832- (CBBB, CBAB, CBAA, CBEA)SB1587
F1630AABS Control Module -J104- (ABS Pump) Not applicable from model year 2009SB1630
F1630AVehicle Electrical System Control Module -J519- Right Parking Lamp, Right High Beam Lamp, Right Low Beam Lamp, Right Parking Lamp, Right Front Fog Lamp Supply Applicable from model year 2009SB1630
F1715AHigh Tone Horn -H2- Low Tone Horn -H7SB1730
F1830AAmplifier -R12- Bass Speakers Amplifier, in luggage compartment, left -R44SB1830
F1830AVoltage Stabilizer -J532- Amplifier -R12- Bass Speakers Amplifier, in luggage compartment, left -R44- Only models with stop/start system Applicable from model year 2010SB1830
F1930AWiper Motor Control Module -J400SB1930
F2020AFuel Pressure Regulator Valve -N276- (BYT, BPT, BPU, BZB, CAWB, CCTA, CDAA, CCZA)SB2087
F2010ACoolant Pump -V50- (CAXC)SB2087
F2110AOxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z64- (CBFA)SB2187
F2110AOxygen Sensor (O2S) Heater -Z19- (BSE, BSF, BLF, BPT, BPU, BYT, BVZ, BVY, BLS, BMM, BUY, BMN, BZB, CAWB, CCTA, CCSA, CDAA, CCZA, CBBB, CBAB, CBAA, CAYB, CAYC, CBEA) Oxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (BSE, BSF, BLF, CCTA, CBFA, CCSA, CD CCZA, CBEA) Not applicable from May 2009, only models with engine codes BSE, CCSA, CCTA, CCZA, CDAASB2187
F2115AOxygen Sensor (O2S) Heater -Z19- (BSE, CCSA, CCTA, CCZA, CDAA) Oxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (BSE, CCSA, CCTA, CCZA, CDAA) Applicable from model year 2010SB2187
F2120AVacuum Pump Relay -J57- (CAXC) Brake System Vacuum Pump -V192- (CAXC)SB2187
F225AClutch Position Sensor -G476SB2287
F225ABrake Light Switch -F- Brake Pedal Switch -F63- Applicable from model year 2010SB2287
F235ACoolant Circulation Pump Relay -J151- (BPT, BPU, BYT, BZB, CAWB, CCTA, CBFA, CCZA, CDAA) Secondary Air Injection (AIR) Pump Relay -J299- (BSE, CBFA, CCSA) After-Run Coolant Pump -V51- (BPT, BPU, BYT, BZB, CAWB, CCTA)SB2387
F2310AEGR Vacuum Regulator Solenoid Valve -N18- (BKC, BXE, AZV, BKD) Wastegate Bypass Regulator Valve -N75- (BLS, BMM, BKC, BXE, AZV, BKD, BMN, BUY, CBBB, CBAB, CBAA, CAYB, CAYC, CBEA) EGR Valve 2 -N213- (BKC, BXE, AZV, BKD) Intake Manifold Runner Control (IMRC) Valve -N316- (BMN, BUY) Exhaust Gas Recirculation (EGR) Cooler Switch-Over Valve -N345- (BLS, BMM) Exhaust Gas Recirculation (EGR) Cooler Switch-Over Valve -N345- (BMN, BUY, CBBB, CBAB, CBAA, CAYB, CAYC)SB2387
F2310AMass Air Flow (MAF) Sensor -G70- (CBBB, CBAB, CBAA) Only models with stop/start system Applicable from model year 2010SB2387
F2315AFuel Pressure Regulator Valve -N276- (BLF, CAXC, BVY, BVZ)SB2387
F2410ACoolant Fan Control (FC) Control Module -J293- Engine Component Power Supply Relay -J757- (BPT, BPU, BYT, CAXC, CD CAWB, CCZA, CCTA) Control Valve Control Module -J808- (CBEA) Wastegate Bypass Regulator Valve -N75- (BPT, BPU, BYT, CAXC, CAWB, BZB, CCTA, CBFA, CDAA, CCZA) Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- (BPT, BPU, BYT, BSE, BSF, BLF, BVY, BVZ, CAXC, CAWB, BZB, CCTA, CBFA, CCSA, CDAA, CCZA) Secondary Air Injection (AIR) Solenoid Valve -N112- (CBFA) Intake Manifold Tuning (IMT) Valve -N 156- (BSE, BSF, BLF, BVY, BVZ, CCSA) Camshaft Adjustment Valve 1 -N205- (BLF, BVY, BVZ, C CAWB, BZB, CCTA, CBFA, CDAA, CCZA) Turbocharger Recirculating Valve -N249- (BPT, BPU, BYT, CAXC, CAWB BZB CCTA CBFA CDAA CCZA) Intake Manifold Runner Control (IMRC) Valve -N316- (BPT, BPU, BYT, CAWB, BZB, CCTA, CBFA, CDAA, CCZA) Oil Pressure Regulation Valve -N428- Intake Flap Motor -V157- (BKC, BXE, AZV, BKD) Exhaust Gas Recirculation (EGR) Cooler Pump -V400- (CBBB, CBAB, CBAA, CAYB, CAYC) Electrohydraulic Engine Mounting Regulator Valve -N398- (CAYB, CAYC)SB2487
F2530AVehicle Electrical System Control Module -J519- (Right Parking Lamp, Right High Beam Lamp, Right Low Beam Lamp, Right Parking Lamp, Right Front Fog Lamp) Not applicable from model year 2009SB2530
F2540AABS Control Module -J104- (MK60 ESP-Pump) ABS Control Module -J104- (MK70 ABS Pump -Valves) Applicable from model year 2009SB2530
F2630AVehicle Electrical System Control Module -J519- (Left Parking Lamp, Left High Beam Lamp, Left Low Beam Lamp, Left Parking Lamp, Left Front Fog Lamp)SB2630
F2750AAutomatic Glow Time Control Module -J179- Glow Plug 1 -Q10- Glow Plug 2 -Q11- Glow Plug 3 -Q12- Glow Plug 4 -Q13- Only models with engine codes: BKC, BXE, AZV, BKD, BLS, BMM, BMN, BUY, CBBB, CBAB, CBAA, CAYB, CAYC, CBEASB2730
F2740ASecondary Air Injection (AIR) Pump Motor -V101- (BSE, CBFA, CCSA)SB2787
F2840APower Supply Relay 2 (terminal 15) -J681- Fuses Supply: -SC1- through -SC6-, -SC29- through -SC31-, -SC46-, -SC47-, -SC49- Not applicable from model year 2009SB2830
F2950AB300 Plus Connection 4 (30) (in main wiring harness) Fuses Supply: -SC32- through -SC37-, -SC44-, -SC45-, -SC48-, -S30- Not applicable from model year 2009SB2930
F2950AB300 Plus Connection 4 (30) (in main wiring harness) Fuses Supply: -SC32- through -SC37-, -SC39-, -SC44-, -SC45-, -SC48-, -S131- Applicable from model year 2009SB2930
F3050ALoad Reduction Relay -J59- Fuses Supply: -SC40-, -SC41-, -SC42- Not applicable from model year 2009SB3030
F3050APower Supply Relay 2 (terminal 15) -J681- Fuses Supply: -SC1- through -SC6-, -SC19-, -SC20-, -SC29- through -SC31-, -SC40-, -SC41-, -SC42-, -SC46-, -SC47-, -SC49- Not applicable from model year 2009SB3030
(1) Not for models U.S. equipment.
(1)Not for models U.S. equipment.

IDENTIFYING FUSES (ELECTRONICS BOX LOW - FROM MODEL YEAR 2007)

1.15 - FUSE PANEL B -SB- ON ELECTRONICS BOX HIGH, ENGINE COMPARTMENT, LEFT SIDE

Note. The relay and fuse panel B -SB- is located in electronic box on left side of the engine compartment, refer to illustration below. For relay identification related to relay and fuse panel B -SB- refer to appropriate POSITION OF RELAYS ON ELECTRONICS BOX under RELAY INDEX INFORMATION .

1.15.1 - FUSE COLOR: For fuse identification and amperage rating refer to FUSE - COLOR CODES .

1.17 - FUSE ARRANGEMENTS ELECTRONICS BOX HIGH, FROM MODEL YEAR 2006

Fuse No.Rating (Amperage)Function/ComponentWiring ID.Terminal
F130AABS Control Module -J104- ABS Hydraulic Pump -V64SB430
F230AABS Control Module -J104- ABS Hydraulic Unit -N55SB430
F320AComfort System Central Control Module -J393SB130
F45AVehicle Electrical System Control Module -J519SB330
F515AHigh Tone Horn -H2- Low Tone Horn -H7SB1730
F615AFuel Pressure Regulator Valve -N276- Transfer Fuel Pump (FP) -G6SB2387
F7Not used
F8Not used
F910AWastegate Bypass Regulator Valve -N75- Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- Turbocharger Recirculating Valve -N249SB987
F1010AMass Air Flow (MAF) Sensor -G70- Leak Detection Pump (LDP) -V144SB1087
F1110AOxygen Sensor (O2S) Heater -Z19- Oxygen Sensor (O2S) Heater 2 -Z28SB1187
F1210AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z30SB1287
F1315ADirect Shift Gearbox (DSG) Mechatronic -J743SB1330
F14Not used
F1510AAfter-run Coolant Pump -V51SB1587
F165ASteering Column Electronic Systems Control Module -J527SB1630
F175AInstrument Cluster Control Module -J285SB1730
F1830AAmplifier -R12- Bass Speakers Amplifier, in luggage compartment, left -R44SB1830
F1915ARadio -R- Navigation System Operating Electronics Control Module -J402SB1930
F205ANavigation System Control Module with CD drive -J401- (1) Navigation System Tuner, TV -J415- (1) Satellite Radio -R146- Telephone Transceiver -R36- Amplifier for telephone -R86- (1)SB2030
F21Not used
F22Not used
F235AMotronic Engine Control Module (ECM) -J220- Motronic Engine Control Module (ECM) Power Supply Relay -J271SB2330
F245AData Bus On Board Diagnostic Interface -J533SB2430
F25Not used
F26Not used
F27Not used
F2825AMotronic Engine Control Module (ECM) -J220SB2887
F295ACoolant Circulation Pump Relay -J151- Secondary Air Injection (AIR) Pump Relay -J299SB2987
F3020AAuxiliary Heater Control Module -J364SB3030
F3130AWiper Motor Control Module -J400SB3130
F32Not used
F33Not used
F34Not used
F35Not used
F36Not used
F37Not used
F3810AEvaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- (1) Intake Manifold Tuning (IMT) Valve -N156- (1) Camshaft Adjustment Valve 1 -N205- Camshaft Adjustment Valve 1 (exhaust) -N318- (1) Coolant Fan Control (FC) Control Module -J293SB3887
F395ABrake Pedal Switch -F63- Clutch Position Sensor -G476SB3987
F4020AIgnition Coil 1 with Power Output Stage -N70- Ignition Coil 2 with Power Output Stage -N127- Ignition Coil 3 with Power Output Stage -N291- Ignition Coil 4 with Power Output Stage -N292SB4087
F41Not used
F425AEngine Component Power Supply Relay -J757SB4287
F4330AIgnition Coil 1 with Power Output Stage -N70- Ignition Coil 2 with Power Output Stage -N127- Ignition Coil 3 with Power Output Stage -N291- Ignition Coil 4 with Power Output Stage -N292- Ignition Coil 4 with Power Output Stage -N323- Ignition Coil 4 with Power Output Stage -N324SB4387
F44Not used
F45Not used
F46Not used
F4740AVehicle Electrical System Control Module -J519- (Left Parking Lamp, Left High Beam Lamp, Left Low Beam Lamp, Left Parking Lamp, Left Front Fog Lamp)SB4730
F4840AVehicle Electrical System Control Module -J519- Right Parking Lamp, Right High Beam Lamp, Right Low Beam Lamp, Right Parking Lamp, Right Front Fog Lamp SupplySB4830
F4940APower Supply Relay 2 (terminal 15) -J681- Fuses Supply: -SC1- through -SC6-, -SC7- through -SC11-, -SC29- through -SC31-, -SC47-, -SC49SB4930
F50Not usedSB5030
F5140ASecondary Air Injection (AIR) Pump Relay -J299- Secondary Air Injection (AIR) Pump Motor -V101SB5130
F5250A (2)Load Reduction Relay -J59- Fuses Supply: -SC40-, -SC41-, -SC42-, -SC46SB5230
F5350AFuses Supply: -SC18-, -SC20-, -SC32-through-SC37-, -SC44-, -SC45-, -SC48-, -S131SB5330
(1) Not for models with US equipment. (2) Fuse was increased from 40A to 50A, applicable from November 2005.
(1)Not for models with US equipment.
(2)Fuse was increased from 40A to 50A, applicable from November 2005.

IDENTIFYING FUSES (ELECTRONICS BOX HIGH - FROM MODEL YEAR 2006)

1.18 - FUSE ARRANGEMENTS ELECTRONICS BOX HIGH, FROM MODEL YEAR 2007

Fuse No.Rating (Amps)Function/ComponentWiring ID.Terminal
F130AABS Control Module -J104- (ABS Pump) Not applicable from model year 2009SB130
F130AVehicle Electrical System Control Module -J519- Right Parking Lamp, Right High Beam Lamp, Right Low Beam Lamp, Right Parking Lamp, Right Front Fog Lamp Supply, Applicable from model year 2009SB130
F230AABS Control Module -J104- (MK60 ESP-Valves) ABS Control Module -J104- (MK70 ABS-Valves) Not applicable from model year 2009SB230
F220AABS Control Module -J104- (MK60 ESP-Valves) Applicable from model year 2009SB230
F340AVoltage Stabilizer -J532- Fuses Supply: -SC7- through -SC11- (Only models with stop/start system) Applicable from model year 2010SB330
F340AFuses Supply: -SC7- through -SC10- (Only models without stop/start system) Applicable from model year 2010SB330
F45AVehicle Electrical System Control Module -J519SB430
F515AHigh Tone Horn -H2- Low Tone Horn -H7SB530
F615AFuel Pressure Regulator Valve -N276- (BPY, BWA, BHZ, BZC)SB687
F615ATransfer Fuel Pump (FP) -G6- -Cylinder No. 1 Fuel Injector -N30 -Cylinder No. 2 Fuel Injector -N31 -Cylinder No. 3 Fuel Injector -N32 -Cylinder No. 4 Fuel Injector -N33 -Cylinder No. 5 Fuel Injector -N83 -Cylinder No. 6 Fuel Injector -N84 Only models with engine code BUD Not applicable from model year 2009SB687
F715ATransfer Fuel Pump (FP) -G6- -Cylinder No. 1 Fuel Injector -N30 -Cylinder No. 2 Fuel Injector -N31 -Cylinder No. 3 Fuel Injector -N32 -Cylinder No. 4 Fuel Injector -N33 -Cylinder No. 5 Fuel Injector -N83 -Cylinder No. 6 Fuel Injector -N84 Only models with engine code BUD, CBRA, Applicable from model year 2009SB787
F715AFuel Pressure Regulator Valve -N276- (CDLA, CDLC, BPY) Applicable from model year 2009SB787
F8Not used
F910AWastegate Bypass Regulator Valve -N75- Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- Turbocharger Recirculating Valve -N249- Only models with eng. codes: BYP, BWA, BHZ, BZC, CDLA, CDLC, BZCSB987
F1010ALeak Detection Pump -V144- (BYP, BWA, BHZ, BZC, CDLA, CDLC, BZC)SB1087
F1010AMass Air Flow (MAF) Sensor -G70- (BUD, CBRA)SB1087
F1110AOxygen Sensor (O2S) Heater -Z19- (BYP, BWA, BHZ, BZC, CDLA, CDLC, BZC)SB1187
F1110AOxygen Sensor (O2S) Heater -Z19- (BUD, CBRA) Oxygen Sensor (O2S) Heater 2 -Z28- (BUD, CBRA)SB1187
F1210AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (BYP, BWA, BHZ, BZC, CDLA, CDLC, BZC)SB1287
F1210AOxygen Sensor (O2S) Heater 1 (behind Three Way Catalytic Converter (TWC) -Z29- (BUD, CBRA) Oxygen Sensor (O2S) Heater 2 (behind Three Way Catalytic Converter (TWC) -Z30- (BUD, CBRA)SB1287
F1315ADirect Shift Gearbox (DSG) Mechatronic -J743SB1330
F14Not used
F1510AAfter-run Coolant pump -V51SB1587
F165ASteering Column Electronic Systems Control Module -J527- (Not applicable from model year 2009)SB1630
F175AInstrument Cluster Control Module -J285- (Not applicable from model year 2010)SB1730
F175ASteering Column Electronic Systems Control Module -J527- (Applicable from model year 2009)SB1730
F1830AAmplifier -R12- Bass Speakers Amplifier, in luggage compartment, left -R44SB1830
F1830AVoltage Stabilizer -J532- Amplifier -R12- Bass Speakers Amplifier, in luggage compartment, left -R44- Only models with stop/start system Applicable from model year 2010SB1830
F1925ARadio/Navigation Display Control Module -J503- Only with radio/navigation system Japan (Not applicable from model year 2010)SB1930
F1915ANavigation System Operating Electronics Control Module -J402- Radio/Navigation Display Control Module -J503- Radio -R- (Not applicable from model year 2010)SB1930
F205ANavigation System Control Module with CD drive -J401- Navigation System Tuner, TV -J415- Telephone Transceiver -R36- Amplifier for telephone -R86- (Not applicable from model year 2010)SB2030
F205A18-Pin Connector -T18a- (VDA-Interface) (Not for models with US equipment) (Not applicable from model year 2010)SB2030
F205ASatellite Radio -R146- (Only models with US equipment) (Not applicable from model year 2010)SB2030
F205ATelephone Transceiver -R36- (Not applicable from model year 2010)SB2030
F21Not used
F22Not used
F2310AEngine Control Modules (ECM) -J...- Motronic Engine Control Module (ECM) Power Supply Relay -J271SB2330
F245AData Bus On Board Diagnostic Interface -J533SB2430
F25Not used
F26Not used
F275AExhaust Flap Valve -N220- (BHZ, CDLA, CDLC, BZC)SB2787
F2825AEngine Control Modules (ECM) -J... (BHZ, BUB, BWA, BPY, CDLA, BZC). Not applicable from May 2007, only models with engine codes: BUB, BHZ, BWA, BPY, CDLA, CDLC.SB2887
F2815AEngine Control Modules (ECM) -J... Applicable from May 2007, only models with engine codes: BUB, BHZ, BWA, BPY, CDLA, CDLC, CBRA, BZC.SB2887
F295ACoolant Circulation Pump Relay -J151- (BUB, BWA, BPY, CDLA, CDLC, CBRA) Secondary Air Injection (AIR) Pump Relay -J299- (BUB, CBRA)SB2987
F3020AAuxiliary Heater Control Module -J364SB3030
F3130AWiper Motor Control Module -J400SB3130
F32Not used
F33Not used
F34Not used
F35Not used
F36Not used
F37Not used
F3810ACoolant Fan Control (FC) Control Module -J293- (BPY, BWA, BHZ, BUB, CDLA, CDLC, CBRA, BZC). Evaporative Emission (EVAP) Canister Purge Regulator Valve 1 -N80- (BUB, CBRA). Secondary Air Injection (AIR) Solenoid Valve -N112- (BUB, CBRA). Intake Manifold Tuning (IMT) Valve -N156- (BUB, CBRA). Camshaft Adjustment Valve 1 -N205- (BPY, BWA, BHZ, BUB, CDLA, CDLC, CBRA, BZC). Secondary Air Injection (AIR) Solenoid Valve 2 -N320- (BUB, CBRA). Leak Detection Pump (LOP) -V144- (BUB, CBRA).SB3887
F395ACutch Position Sensor -G476SB3987
F395ABrake Light Switch -F- Brake Pedal Switch -F63- Applicable from model year 2010SB3987
F4020AIgnition Coil 1 with Power Output Stage -N70- Ignition Coil 2 with Power Output Stage -N127- Ignition Coil 3 with Power Output Stage -N291- Ignition Coil 4 with Power Output Stage -N292- (Only models with engine codes: BPY, BWA, BHZ, CDLA, CDLC, BZC)SB4087
F41Not used
F425AEngine Component Power Supply Relay -J757- (Only models with engine codes: BPY, BWA, BHZ, CDLA, CDLC, BZC)SB4287
F4330AIgnition Coil 1 with Power Output Stage -N70- Ignition Coil 2 with Power Output Stage -N127- Ignition Coil 3 with Power Output Stage -N291- Ignition Coil 4 with Power Output Stage -N292- Ignition Coil 5 with Power Output Stage -N323- Ignition Coil 6 with Power Output Stage -N324- Only models with engine codes: BUB, CBRA.SB4387
F44Not used
F45Not used
F46Not used
F4730AVehicle Electrical System Control Module J519- Left Parking Lamp, Left High Beam Lamp, Left Low Beam Lamp, Left Parking Lamp, Left Front Fog Lamp SupplySB4730
F4840AABS Control Module -J104- (MK60 ESP-Pump) ABS Control Module -J104- (MK70 ABS Pump and ABS Valves) Applicable from model year 2009SB4830
F4830AVehicle Electrical System Control Module J519- Right Parking Lamp, Right High Beam Lamp, Right Low Beam Lamp, Right Parking Lamp, Right Front Fog Lamp Supply Not applicable from model year 2009SB4830
F4940APower Supply Relay 2 (terminal 15) -J681- Fuses Supply: -SC1- through -SC6-, -SC29- through -SC31-, -SC46 , SC47-, -SC49SB4930
F50Not used
F5140ASecondary Air Injection (AIR) Pump Motor -V101- (BUB, CBRA)SB5130
F5250APower Supply Relay 2 (terminal 15) -J681- Fuses Supply: -SCI-through-SC6-, -SC19-, -SC20-, -SC29-through-SC31-, -SC40-, -SC42-, -SC46-, -SC47-, -SC49- Applicable from model year 2009SB5230
F5250ALoad Reduction Relay -J59- Fuses Supply: -SC40-, -SC41-, -SC42- Not applicable from model year 2009SB5230
F5350AB300 Plus Connection 4 (30) (in main wiring harness) Fuses Supply: -SC32- through -SC37-, -SC44-, -SC45-, -SC48-, -S131- (Only models with battery in engine compartment) Not applicable from model year 2009SB5330
F5350AB300 Plus Connection 4 (30) (in main wiring harness) Fuses Supply: -SC32- through -SC37-, -SC48-, -S131- (Only models with battery in engine compartment) Not applicable from model year 2009SB5330
F5350AB300 Plus Connection 4 (30) (in main wiring harness) Fuses Supply: -SC32-through-SC37-, -SC39-, SC44-, -SC45-, -SC48-, -S131- (Only models with battery in engine compartment) Applicable from model year 2009SB5330
F5350AB300 Plus Connection 4 (30) (in main wiring harness) Fuses Supply: -SC32-through-SC37-, -SC39-, -SC48-, -S131- (Only models with battery in engine compartment) Applicable from model year 2009SB5330

IDENTIFYING FUSES (ELECTRONICS BOX HIGH - FROM MODEL YEAR 2007)

1.19- FUSE PANEL C -SC- INSTRUMENT PANEL - LEFT SIDE

Note. The fuse panel C -SC- is located on the left side end of the dash panel (driver's side), refer to illustrations below.

1.19.1 - FUSE COLOR: For fuse identification and amperage rating refer to FUSE - COLOR CODES .

1.21 - POSITION OF FUSES ON FUSE PANEL, FROM MODEL YEAR 2006

Fuse No.Rating (Amperage)Function/ComponentWiring ID.Terminal
110ALight Switch -E1 -Fuel Pump (FP) Relay -J17 -Engine Control Module (ECM) -J623 (1) -Motronic Engine Control Module (ECM) -J220 -Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248 (1) -Fuel Pump (FP) Control Module -J538 -16-Pin Connector -T16- (Diagnostic Connector)SC115
25AABS Control Module -J104 -Brake Light Switch -F -Brake Pedal Switch -F63SC215
35AAirbag Control Module -J234 -Front Passenger Airbag Disabled Indicator Lamp -K145SC315
45ATire Pressure Monitoring Button -E226- (1) -ASR/ESP Button -E256 -Back-up Light Switch -F4 -High Pressure Sensor -G65 -Air Quality Sensor -G238 -Oil Level Thermal Sensor -G266 -Heater Control Module -J162- (1) -Left Rear Heated Seat Control Module -J215- (1) -Right Rear Heated Seat Control Module -J216- (1) -Drivers Heated Seat Control Module -J726- (1) -Front Passengers Heated Seat Control Module -J727- (1)SC415
55AHeadlamp Range Control Module -J431SC515
510AHeadlamp Adjuster -E102 -Left Headlamp Beam Adjustment Motor -V48- (1) -Right Headlamp Beam Adjustment Motor -V49- (1)SC515
65AFunction Selection Switch 2 -E272- (1) -Selector Lever -E313 -Tiptronic Switch -F189- (1) -Power Steering Control Module -J500 -Data Bus On Board Diagnostic Interface -J533 -Direct Shift Gearbox (DSG) Mechatronic -J743SC615
75AGarage Door Opener Control Head -E284 -Towing Recognition Control Module -J345- (1) -Navigation System Control Module with CD drive -J401- (1) -Navigation System Operating Electronics Control Module -J402 -Parking Aid Control Module -J446- (1) -Garage Door Opener Control Module -J530 -Automatic Day/Night Interior Mirror -Y7SC715
810ATrailer Socket -U10- (1)SC815
9Not used
105ASeat Occupied Recognition Control Module -J706SC1015
115ARight Headlamp Power Output Stage -J668SC1115
1210ADriver's Door Control Module -J386 -Front Passenger's Door Control Module -J387SC1230
1310ABrake Light Switch -F- (brake lights) -16-Pin Connector -T16- (Diagnostic Connector)SC1330
145ATransmission Control Module (TCM) -J217- (1)SC1430
1510AVehicle Electrical System Control Module -J519SC1530
1610ARain/Light Recognition Sensor -G397 -Heater Control Module -J162 -Climatronic Control Module -J255 -Auxiliary Heater RF Receiver -R64SC1630
175AComfort System Central Control Module -J393SC1730
185ASelector Lever -E313 -Tiptronic Switch -F189- (1) -Parking Aid Control Module -J446SC1830
1910ALeft Rear Door Control Module -J388 -Right Rear Door Control Module -J389SC1930
205AABS Control Module -J104- (1)SC2030
21Not used
2240AFresh Air Blower Control Module -J126SC2230
2330ADriver's Window Regulator Motor -V147SC2330
2420ACigarette Lighter -U1 -12V Socket -U5SC2430
2530AHeated Rear Window -Z1SC2530
2620ASocket -USC2630
2715AFuel Pump (FP) 2 Relay -J49 -Fuel Pump (FP) Control Module -J538SC2730
2830ALeft Rear Window Regulator Motor -V26 -Right Rear Window Regulator Motor -V27SC2830
2910AMass Air Flow (MAF) Sensor -G70 -Positive Crankcase Ventilation (PCV) Heating Element -N79SC2915
3010ACylinder No. 1 Fuel Injector -N30 -Cylinder No. 2 Fuel Injector -N31 -Cylinder No. 3 Fuel Injector -N32 -Cylinder No. 4 Fuel Injector -N33 -Cylinder No. 5 Fuel Injector -N83 -Cylinder No. 6 Fuel Injector -N84SC3015
315AAll-Wheel Drive Control Module -J492SC3115
3120AVacuum Pump Relay -J57- (1)SC3115
3230AHeadlamp Washer Pump -V11 -Headlamp Washer Relay -J39SC3215
3325APower Sunroof Control Module -J245SC3330
3420ALeft Rear Heated Seat Control Module -J215- (1) -Right Rear Heated Seat Control Module -J216- (1)SC3430
355AInterior Monitoring Sensor -G273 -Vehicle Inclination Sensor -G384 -Alarm Horn -H12SC3530
3610ADriver's Seat Lumbar Support Adjustment Switch -E176 -Front Passenger's Seat Lumbar Support Adjustment Switc -E177SC3630
3720AClimatronic Control Module -J255 -Driver's Heated Seat Control Module -J726- (1) -Front Passenger's Heated Seat Control Module -J727- (1) -Front Left Heated Seat -Z45 -Front Right Heated Seat -Z46SC3730
3830AFront Passengers Window Regulator Motor -V148SC3830
3920AMulti-Function Transmission Range (TR) Switch -F125- (1) -Transmission Control Module (TCM)-J217- (1)SC3915
40NAFresh Air Blower Switch -E9- (1) (Only models without A/C)SC4075
4115ARear Window Wiper Motor -V12SC4175
4215AWindshield and Rear Window Washer Pump -V59SC4275
43Not used
4420ATowing Recognition Control Module -J345- (1)SC4430
4515ATowing Recognition Control Module -J345- (1)SC4530
465AHeater Control Module -J162- (1) -Climatronic Control Module -J255 -Left Washer Nozzle Heater -Z20 -Right Washer Nozzle Heater -Z21SC4675
475ALeft Headlamp Power Output Stage -J667SC4715
4810ASocket -U- (1) (Only Driving School)SC4830
495ASpecial Purpose Vehicle Fuse 6 -S296- (1) -Footwell Illumination Switch -E295- (1) -Warning Buzzer Switch -S296- (1)SC4915
(1) Not for models with US equipment.
(1)Not for models with US equipment.

IDENTIFYING FUSES (INSTRUMENT PANEL - DRIVER'S SIDE - 2006)

1.22 - POSITION OF FUSES ON FUSE PANEL, FROM MODEL YEAR 2007

Fuse No.Rating (Amperage)Function/ComponentWiring ID.Terminal
110ALight Switch -E1 -Headlamp Adjuster -E102- (1) -Mass Air Flow (MAF) Sensor -G70- (BKC, BXE, AZV, BKD, BLS, BMM, BMN, BPU, BPT, BYZ, BWA, BPY, BHZ, BZB, CAWB, CBFA, BUY, CDAA, CCZA, CCTA, CDLA, CDLC, CAYB, CAYC, BZC, CBEA) -Towing Recognition Control Module -J345- (1) -Headlamp Range Control Module -J431 -Positive Crankcase Ventilation (PCV) Heating Element -N79- (BSE, BSF, BKC, BXE, AZV, BKD, BLS, BMM, BMN, BUB, BUY, CCSA, CBBB, CBAB, CBAA, CBRA, CAYB, CAYC, CBEA) -16 Pin Connector -T16-(Diagnostic Connector) -Left Headlamp Beam Adjustment Motor -V48- (1) -Right Headlamp Beam Adjustment Motor -V49- (1)SC115
110AMass Air Flow (MAF) Sensor -G70- (CBBB, CBAB, CBAA) Not applicable from model year 2010SC115
110AMass Air Flow (MAF) Sensor -G70- (CBBB, CBAB, CBAA) (Only models without stop/start system) Applicable from model year 2010SC115
110AStop/Start Mode Button -F416 (Only models with stop/start system) Applicable from model year 2010SC115
210AEngine Control Modules (ECM) -J... -Fuel Pump (FP) Relay -J17-(BSE, BSF, BUB, CCSA, CBRA) -ABS Control Module -J104 -SIMOS Control Module Power Supply Relay -J363-(BSE, BSF, CCSA)- (1) -Power Steering Control Module -J500 -Data Bus On Board Diagnostic Interface -J533 -Fuel Pump (FP) Control Module -J538-(BPU, BYT, BPT, BLF, BVY, BVZ, BPY, BWA, BHZ, CAXC, BZB, CAWB, CBFA, CDAA, CCZA, CCTA, CDLC, CDLA, BZC) -Selector Lever Sensors Control Module -J587 -Direct Shift Gearbox (DSG) Mechatronic -J743SC215
210ABrake Light Switch -F -Brake Pedal Switch -F63 Not applicable from model year 2010SC215
210ATiptronic Switch -F189- (1) -All Wheel Drive Control Module -J492 Not applicable from model year 2009SC215
210AStarter Relay 1 -J906 -Starter Relay 2 -J907 -Automatic Day/Night Interior Mirror Relay -J910 (Only models with stop/start system) Applicable from model year 2010SC215
35AAirbag Control Module -J234 -Front Passenger Airbag Disabled Indicator Lamp -K145SC315
45ALeft Rear Heated Seat Regulating Switch -E128- (1) -Right Rear Heated Seat Regulating Switch -E129- (1) -Tire Pressure Monitoring Button -E226- (1) -ASR/ESP Button -E256 -Garage Door Opener Control Head -E284 -Garage Door Opener Control Module -J530 -Back-up Light Switch -F4 -High Pressure Sensor -G65 -Air Quality Sensor -G238 -Oil Level Thermal Sensor -G266 -Heater Control Module -J162 -Climatronic Control Module -J255 -A/C Control Module -J301- (1) -Navigation System Control Module with CD drive -J401- (1) -Parking Aid Control Module -J446 -Seat Occupied Recognition Control Module -J706 -Drivers Heated Seat Control Module -J726- (1) -Front Passengers Heated Seat Control Module -J727- (1) -Left Washer Nozzle Heater -Z20 -Right Washer Nozzle Heater -Z21SC415
45AAutomatic Day/Night Interior Mirror -Y7 Not applicable from model year 2010SC415
45AAutomatic Day/Night Interior Mirror -Y7 (Only models without stop/start system) Applicable from model year 2010SC415
45AVoltage Stabilizer -J532 (Only models with stop/start system) Applicable from model year 2010SC415
55ALeft Headlamp Power Output Stage -J667SC515
65ARight Headlamp Power Output Stage -J668SC615
7Not used
85AInstrument Cluster Control Module -J285 Applicable from model year 2010SC830
915ANavigation System Operating Electronics Control Module -J402 -Radio/Navigation Display Control Module -J503 -Radio -R -8 Pin Connector -T8-(Preparation for Radio)- (1) Applicable from model year 2010SC930
107.5ANavigation System Tuner, TV -J415- (1) -Telephone Transceiver -R36 -Satellite Radio -R146- (2) -External Audio Source Connector -R199 -18 Pin Connector -T18a- (VDA-Interface) (1) Applicable from model year 2010SC1030
1110AAutomatic Day/Night Interior Mirror Relay -J910 -Automatic Day/Night Interior Mirror -Y7 (Only models with stop/start system) Applicable from model year 2010SC1130
1210ADriver's Door Control Module -J386 -Front Passenger's Door Control Module -J387SC1230
1310ALeft Rear Door Control Module -J388 -Right Rear Door Control Module -J389SC1330
1310AComfort System Central Control Module -J393 Not applicable from model year 2010SC1330
1410AABS Control Module -J104 -Selector Lever Sensors Control Module -J587SC1430
1410ATiptronic Switch -F189- (1) -Transmission Control Module (1CM) -J217- (1) -Parking Aid Control Module -J446 Not applicable from model year 2009SC1430
1510AFront Interior Light -W -Front Interior Light -W1 -Rear Interior Light -W43SC1530
1610ARain/Light Recognition Sensor -G397 -Heater Control Module -J162 -Climatronic Control Module -J255 -A/C Control Module -J301- (1) -Tire Pressure Monitoring Control Module -J502- (2) -Auxiliary Heater RF Receiver -R64- (1) -16 Pin Connector -T16-(Diagnostic Connector)SC1630
1610ALight Switch -E1 Applicable from model year 2010SC1630
175AInterior Monitoring Sensor -G273- (1) -Vehicle Inclination Sensor -G384- (1) -Alarm Horn -H12SC1730
185AEngine Control Module (ECM) -J623- (Diagnosis Wire) (Only models with engine code CBFA) Not applicable from model year 2010SC1850
185AVehicle Electrical System Control Module -J519- (Diagnosis Wire) -Voltage Stabilizer -J532-(Diagnosis Wire) -Engine Control Module (ECM) -J623-(Diagnosis Wire) (Only models with stop/start system) Applicable from model year 2010SC1850
1910AAll Wheel Drive Control Module -J492 Applicable from model year 2009SC1930
205AElectronic Damping Control Module -J250 Applicable from model year 2009SC2030
21Not used
2240AFresh Air Blower Control Module -J126 -Fresh Air Blower -V2SC2230
2330ADriver's Window Regulator Motor -V147SC2330
2420ACigarette Lighter -U1SC2430
2530AHeated Rear Window -Z1SC2530
2620ASocket -USC2630
2715AFuel Pump (FP) Relay -J17- (BSE, BSF, CCSA, CBBB, CBAB, CBAA, BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CAYB, CAYC, CBEA) -Fuel Pump (FP) Control Module -J538- (BPU, BYT, BPT, BWA, BPY, BHZ, CAXC, BZB, CAWB, CCTA, CBFA, BLF, BVY, BVZ, CDAA CCZA, CDLA, CDLC, BZC)SC2730
2715AFuel Pump (FP) 2 Relay -J49- (BSE, BSF. BUB, CCSA, CBRA) -Applicable from November 2006, only models with auxiliary heater, engine codes: BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB,CAYC.SC2730
2715AAuxiliary Fuel Pump Relay -J832- (CBBB, CBAB, CBAA, CBEA) -Auxiliary Fuel Pump -V393- (CBBB, CBAB, CBAA, CBEA)SC2730
2830ALeft Rear Window Regulator Motor -V26 -Right Rear Window Regulator Motor -V27SC2830
29Not used
3020AMulti-Function Transmission Range (TR) Switch -F125- (1) -Transmission Control Module (TCM) -J217- (1) Not applicable from model year 2009SC3015
3120ABrake System Vacuum Pump -V192 (CCSA, BSE, BSF) (1)SC3115
3230AHeadlamp Washer Pump -V11SC3230
3320APower Sunroof Control Module -J245SC3330
3420ALeft Rear Heated Seat Control Module -J215- (1) -Right Rear Heated Seat Control Module -J216- (1)SC3430
35Not used
3610ADriver's Seat Lumbar Support Adjustment Switch -E176 -Front Passenger's Seat Lumbar Support Adjustment Switc -E177SC3630
3720AClimatronic Control Module -J255 -Driver's Heated Seat Control Module -J726- (1) -Front Passenger's Heated Seat Control Module -J727- (1)SC3730
3830AFront Passengers Window Regulator Motor -V148SC3830
395AModels Location System Control Module Interface -J843 (Special Functions Interface)SC3930
3925ARadio/Navigation Display Control Module -J503- (1) Only with radio/navigation system Japan Applicable from model year 2010SC3930
4040AFresh Air Blower Switch -E9- (1) -Fresh Air Blower -V2- (1) Not applicable from model year 2009SC4075
4040AStarter -B Applicable from model year 2009SC4015
4115ARear Window Wiper Motor -V12 Not applicable from model year 2009SC4175
4115ARear Window Wiper Motor -V12 Applicable from model year 2009SC4115
4215AWindshield and Rear Window Washer Pump -V59 Not applicable from model year 2009SC4275
4215AWindshield and Rear Window Washer Pump -V59 Applicable from model year 2009 Not applicable from model year 2010SC4215
43Comfort System Central Control Module -J393 Not applicable from model year 2010
43Vehicle Electrical system Control Module -J519 Applicable from model year 2010
4420ATowing Recognition Control Module -J345- (1)SC4430
4520ATowing Recognition Control Module -J345- (1) Not applicable from November 2006SC4430
4515ATowing Recognition Control Module -J345- (1) Applicable from November 2006SC4530
465ATrailer Socket-U10 (1)SC4615
475A18 Pin Connector -T18a- (VDA-Interface) (1)SC4715
475AAmplifier for telephone -R86- (1) Applicable from model year 2010SC4715
4810ASocket -U- (1) (Only Driving School)SC4830
495AWarning Buzzer -H3- (Driving School) (1) -Special Purpose Vehicle Fuse 6 -S296- (Criminal Investigation/Doctor on Call Models) (1) -Driving School Footwell Illumination -W56- (1)SC4915
(1) Not for models with US equipment. (2) Only for models with US equipment.
(1)Not for models with US equipment.
(2)Only for models with US equipment.

IDENTIFYING FUSES (INSTRUMENT PANEL - DRIVER'S SIDE - 2007)

1.23 - MAIN FUSE PANEL D -SD- IN LUGGAGE COMPARTMENT, RIGHT REAR

Note. This luggage compartment relay/fuse panel is located behind the trim on the right side of trunk, refer to illustrations below. For relay identification, refer to 1.11- POSITION OF RELAYS ON MAIN FUSE PANEL, IN LUGGAGE COMPARTMENT - RIGHT REAR under RELAY INDEX INFORMATION. For fuse identification and amperage rating refer to FUSE - COLOR CODES .

1.23.1 - POSITION OF FUSES

Position/ LocationRating (Amperage)Function/ComponentWiring IDTerminal
15AVehicle Electrical System Control Module -J519SF130
2125AElectronics Box High Main Fuse Panel Supply, Relay and Fuse Carrier Electronics Box HighSF230
380AElectronics Box High Main Fuse Panel Supply, Relay and Fuse Carrier Electronics Box HighSF330
430AAmplifier -R12- Only models with BOSE system Not applicable from November 2005SF430
450ADoctor Option Not applicable from November 2005SF430
430AFuses Supply: -SCI2- through -SC17-, -SC19- Applicable from November 2005SF430
430AFuses Supply: SC12- through SC17-, -SC43- Applicable from May 2006SF430

IDENTIFYING FUSES (LUGGAGE COMPARTMENT - RIGHT SIDE - FROM MODEL YEAR 2006)

1.26- FUSES UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006)

Note. This relay/fuse panel is located below the instrument panel, driver's side, refer to illustrations below. For relay identification, refer to 1.7- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006) under RELAY INDEX INFORMATION. For fuse identification and amperage rating refer to FUSE - COLOR CODES .

POSITION OF FUSES, FROM MODEL YEAR 2006

Position/LocationRating (Amps)Function/Component
ANot used
BNot used
C30AFuse 1 -S131
DNot used

IDENTIFYING FUSES (UNDER INSTRUMENT PANEL, LEFT SIDE - FROM MODEL YEAR 2006)

1.2- POSITION OF RELAYS ON ELECTRONICS BOX LOW (FROM MODEL YEAR 2006)

Note. Located in engine compartment, left side.

Position/LocationFunction/Component
1Motronic Engine Control Module (ECM) Power Supply Relay -J271- Connection A1 Only models with engine codes ELF, BLR, BLY, BVY, BVZ, BPT, BPU, BYT, C BZB, CAWB, CBFA, CCTA, CDAA, CCZA.
1Power Supply Relay (Terminal 30) -J317- Connection A1 Only models with engine codes BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB, CAYC, CBEA.
1SIMOS Control Module Power Supply Relay -J363- Connection A1 Only models with engine codes BSE, BSF, CCSA.
2Connection Bridge, Automatic Glow Time Control Module Connection A2 Only models with engine codes BKC, BXE, AZV, BKD, BLS, BMM, BUY, BMN, CBBB, CBAB, CBAA, CAYB, CAYC.
2Secondary Air Injection (AIR) Pump Relay -J299- Connection A2 Only models with engine codes BSE, CBFA, CCSA.
2Engine Component Power Supply Relay -J757- Connection A2 Only models with engine codes BPT, BPU BYT, BZB, CAWB, CCTA, CAXC, CDAA, CCZA. Only models from model year 2008, with engine code CBFA (1) Only models from model year 2009, with engine code CBFA (2)
(1) Refer to Engine Component Power Supply Relay -J757- in 1.7- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006) . (2) Refer to Engine Component Power Supply Relay -J757- in 1.8- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2009)
(1)Refer to Engine Component Power Supply Relay -J757- in 1.7- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006) .
(2)Refer to Engine Component Power Supply Relay -J757- in 1.8- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2009)

IDENTIFYING RELAYS (ON ELECTRONICS BOX LOW - FROM MODEL YEAR 2006)

1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH (FROM MODEL YEAR 2006)

Note. Located in engine compartment, left side.

Position/LocationFunction/ComponentConnection
1Motronic Engine Control Module (ECM) Power Supply Relay -J271- Only models with engine codes AXX, BPY, BWA, BHZ, BUB, BMJ. CDLA, CDLC, CBRA, BZC.R1
2Coolant Circulation Pump Relay -J151- Only models with engine codes AXX, BPY, BWA, BHZ, BUB, BMJ, CDLA, CDLC, CBRA, BZC.R2
3Fuel Pump (FP) Relay -J17- Only models with engine codes BUB, BMJ, CBRA.R4
3Engine Component Power Supply Relay -J757- Only models with engine codes AXX, BPY, BWA, BHZ, CDLA, CDLC, BZC.R4
4Not used Only models with engine codes BSE, CBFA, CCSA.R3

IDENTIFYING RELAYS (ON ELECTRONICS BOX HIGH - FROM MODEL YEAR 2006)

1.5- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2006)

Note. Located under instrument panel, left side.

Position/LocationFunction/ComponentConnection
1Power Supply Relay 2 (terminal 15) -J681B1
2Not usedB2
3Rear Window Defogger Relay -J9B5
4Horn Relay -J413B6
5Load Reduction Relay -J59B9
6Dual Washer Pump Relay 1 -J729B8
7Dual Washer Pump Relay 2 -J730B7
8Not usedB3
9Power Supply Relay 2 (terminal 30) -J689B4

IDENTIFYING RELAYS (RELAY CARRIER - UNDER INSTRUMENT PANEL LEFT SIDE - FROM MODEL YEAR 2006)

1.6- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2010)

Note. Located under instrument panel, left side.

Position/LocationFunction/Component
1Power Supply Relay 2 (terminal 15) -J681
2Rear Window Defogger Relay -J9
3Horn Relay -J413- Headlamp Washer Relay -J39
4Load Reduction Relay -J59
5Preheating Coolant, High Heat Output Relay -J360- (1)
(1) Only models with auxiliary air heater.
(1)Only models with auxiliary air heater.

IDENTIFYING RELAYS (RELAY CARRIER - UNDER INSTRUMENT PANEL LEFT SIDE - FROM MODEL YEAR 2010)

1.7- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006)

Note. This relay and fuse holder is located below instrument panel on driver's side, refer to illustration below. For fuse identification, refer to 1.26- FUSES UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006) under FUSE INDEX INFORMATION.

Position/LocationFunction/ComponentConnection
1Headlamp Washer Relay -J39
2Fuel Pump (FR) Relay -J17- Only models with diesel engines Not applicable from model year 2006 Only models from model year 2006, engine codes BUB, BMJ (1)2.1
2Fuel Pump (FP) 2 Relay -J49- Only models with gasoline engine Not for models with FSI engine Not applicable from model year 20062.1
2Fuel Pump (FR) Relay -J17- Applicable from May 2005 Not applicable from August 2005 Only models with engine codes BSE, BSF2.1
2Fuel Pump (FP) 2 Relay -J49- Only models with gasoline engine Not for models with FSI engine Applicable from May 2005 Not applicable from August 20052.2
2Fuel Pump (FR) Relay -J17- Applicable from May 2005 Not applicable from August 2005 Only models with diesel engines2.2
2Preheating Coolant, Low Heat Output Relay -J359- Applicable from November 2006 (2) Only models with diesel engines
3Power Supply Relay (terminal 50) -J682- Applicable from May 2005 Not applicable from August 2005
3Preheating Coolant, High Heat Output Relay -J360- Applicable from November 2006 (2) Only models with diesel engines
4Power Supply Relay (terminal 50) -J682- Applicable from August 2005
4Engine Power Reduction Relay 2 -J663- Applicable from model year 2005 Not applicable from model year 2006
5Fuel Pump (FP) 2 Relay -J49- Not for models with US equipment Applicable from November 2006 (2) Only models with diesel engines5.1
5Coolant Circulation Pump Relay -J151- Applicable from model year 2007. Only models with engine codes BPT, BPU, BYT, BZB, CAWB, CBFA, CCTA. Only models from model year 2006, engine codes AXX, BPY, BWA, BHZ, BUB, BMJ (1)5.1
5Fuel Pump (FP) Relay -J17- Only models with engine codes BSE, CBFA, CCSA. Applicable from August 2005. Only models with engine codes BSE, BSF.5.1
5Engine Component Power Supply Relay -J757- Applicable from model year 2007. Only models with engine code CBFA.5.2
5Fuel Pump (FP) 2 Relay -J49- Applicable from August 2005 Only models with gasoline engine Not for models with FSI engine5.2
5Fuel Pump (FP) Relay -J17- Applicable from August 2005 Only models with diesel engines5.2
5Engine Power reduction Relay1 -J662- Applicable from model year 2005 Not applicable from model year 2006
(1) Refer to Fuel Pump (FR) Relay -J17- in 1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH (FROM MODEL YEAR 2006) (2) Only models with auxiliary heater.
(2)Only models with auxiliary heater.

IDENTIFYING RELAYS (UNDER INSTRUMENT PANEL, LEFT SIDE - FROM MODEL YEAR 2006)

1.8- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2009)

Note. This relay and fuse holder is located below instrument panel driver's side on relay / fuse panel with Vehicle Electrical System Control Module -J519- and threaded connection. Refer to illustration below. For fuse identification, refer to 1.26- FUSES UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006) under FUSE INDEX INFORMATION.

Position/ItemFunction/Component
1Preheating Coolant, Low Heat Output Relay -J359- Only models with auxiliary air heater
2Power Supply Relay (terminal 50) -J682- Only models without stop/start system
3Auxiliary Fuel Pump Relay -J832- Connection 3.1 Only models with engine codes CBAA, CBAB, CBBB Not applicable from model year 2010 Models, from model year 2010 (1)
3Starter Relay 1 -J906- Connection 3.1 Applicable from model year 2010 Only models with stop/start system
3Headlamp Washer Relay -J39- Connection 3.2 Not applicable from model year 2010 Models, from model year 2010 (2)
3Starter Relay 1 -J907- Connection 3.2 Applicable from model year 2010 Only models with stop/start system
4Fuel Pump (FR) Relay -J17- Connection 4.1 Only models with engine codes BSE, CCSA, BLS, BXE, CBBB, CBAB, CBAA, CAYB, CAYC Models with engine codes BUB, CBRA (3)
4Fuel Pump (FP) 2 Relay -J49- Connection 4.1 Only models with engine codes BUB, CBRA
4Coolant Circulation Pump Relay -J151- Connection 4.1 Only models with engine codes CDAA, CCZA, CAWB, CCTA, CBFA Models with engine codes BUB, CBRA (4)
4Fuel Pump (FP) 2 Relay -J49- Connection 4.2 Only models with engine codes BSE, CCSA or with auxiliary heater. engine codes BLS, BXE, CBBB, CBAB, CBAA, CAYB, CAYC
4Engine Component Power Supply Relay -J757- Connection 4.2 Only models with engine code CBFA
5Preheating Coolant, High Heat Output Relay -J360- Only models with auxiliary air heater Not applicable from model year 2010 Models, from model year 2010 (5)
5Automatic Day/Night Interior Mirror Relay -J910- Connection 5.1 Applicable from model year 2010
5Auxiliary Fuel Pump Relay -J832- Connection 5.2 Only models with engine codes CBAA, CBAB, CBBB, CBFA Applicable from model year 2010
(1) Refer to item 5 "Auxiliary Fuel Pump Relay -J832-" this table. (2) Refer to "Headlamp Washer Relay -J39-" under 1.6- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2010) . (3) Refer to "Fuel Pump (FR) Relay -J17-" under 1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH (FROM MODEL YEAR 2006) . (4) Refer to "Coolant Circulation Pump Relay -J151-" under 1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH (FROM MODEL YEAR 2006) . (5) Refer to "Preheating Coolant, High Heat Output Relay -J360-" under 1.6- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2010) .
(1)Refer to item 5 "Auxiliary Fuel Pump Relay -J832-" this table.
(3)Refer to "Fuel Pump (FR) Relay -J17-" under 1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH (FROM MODEL YEAR 2006) .
(4)Refer to "Coolant Circulation Pump Relay -J151-" under 1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH (FROM MODEL YEAR 2006) .
(5)Refer to "Preheating Coolant, High Heat Output Relay -J360-" under 1.6- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2010) .

IDENTIFYING RELAYS (UNDER INSTRUMENT PANEL, LEFT SIDE - FROM MODEL YEAR 2009)

1.9- POSITION OF RELAYS UNDER ELECTRONIC BOX (Up TO 2006)

Note. Relays carrier under electronic box in engine compartment left side. Refer to illustration below.

Position/LocationFunction/Component
1Not used
2Automatic Glow Time Control Module -J179- Connection R2 Not for models with US equipment Not applicable from model year 2006 Models, from model year 2006 (1)
3Not used
4Coolant Circulation Pump Relay -J151- Connection R6 Not applicable from model year 2006
5Secondary Air Injection (AIR) Pump Relay -J299- Applicable from model year 2004 Models with electronics box Low, from model year 2006 (2) Models with electronics box High, from model year 2009 (3)
6Not used
(1) For model year 2006 up, refer to "Automatic Glow Time Control Module -J179-" under 1.10- POSITION OF RELAYS UNDER ELECTRONIC BOX (2006 & Up) . (2) For model year 2006, refer to "Secondary Air Injection (AIR) Pump Relay -J299-" under 1.2- POSITION OF RELAYS ON ELECTRONICS BOX LOW (FROM MODEL YEAR 2006) . (3) For model year 2009 up, refer to "Secondary Air Injection (AIR) Pump Relay -J299-" under 1.10- POSITION OF RELAYS UNDER ELECTRONIC BOX (2006 & Up) .
(1)For model year 2006 up, refer to "Automatic Glow Time Control Module -J179-" under 1.10- POSITION OF RELAYS UNDER ELECTRONIC BOX (2006 & Up) .
(2)For model year 2006, refer to "Secondary Air Injection (AIR) Pump Relay -J299-" under 1.2- POSITION OF RELAYS ON ELECTRONICS BOX LOW (FROM MODEL YEAR 2006) .
(3)For model year 2009 up, refer to "Secondary Air Injection (AIR) Pump Relay -J299-" under 1.10- POSITION OF RELAYS UNDER ELECTRONIC BOX (2006 & Up) .

IDENTIFYING RELAYS (UNDER ELECTRONIC BOX - ENGINE COMPARTMENT - LEFT SIDE - UP TO 2006)

1.10- POSITION OF RELAYS UNDER ELECTRONIC BOX (2006 & Up)

Note. Relays carrier under electronic box in engine compartment left side. Refer to illustration below.

Note. Relay carrier is only visible when the electronics box is removed.

Position/LocationFunction/Component
1Relay Carrier under Electronics Box, in engine compartment left side
2Automatic Glow Time Control Module -J179
2Not used

IDENTIFYING RELAYS (UNDER ELECTRONICS BOX LOW - FROM MODEL YEAR 2006)

Position/LocationFunction/Component
1Relay Carrier under Electronics Box, in engine compartment, left side
2Not used
2Secondary Air Injection (AIR) Pump Relay -J299

IDENTIFYING RELAYS (UNDER ELECTRONICS BOX HIGH - FROM MODEL YEAR 2009)

1.11- POSITION OF RELAYS ON MAIN FUSE PANEL, IN LUGGAGE COMPARTMENT - RIGHT REAR

Note. This luggage compartment fuse holder is located behind the trim on the right side of trunk, refer to illustrations below. For fuse identification, refer to 1.23 - MAIN FUSE PANEL D -SD- IN LUGGAGE COMPARTMENT, RIGHT REAR under FUSE INDEX INFORMATION.

Position/LocationFunction/Component
5Battery Switch-Off Relay -J655
5Battery Interrupt Igniter -N253

IDENTIFYING RELAYS (ON MAIN FUSE PANEL, IN LUGGAGE COMPARTMENT - RIGHT REAR)

See also:
• Overview Of Relays
• 1.2- MAIN FUSE PANEL: A -SA- ON ELECTRONICS BOX LOW (FROM MODEL YEAR 2006)
• 1.7- MAIN FUSE PANEL A -SA- ON ELECTRONICS BOX HIGH
• 1.12- FUSE PANEL B -SB- ON ELECTRONICS BOX LOW, ENGINE COMPARTMENT, LEFT SIDE
• 1.15 - FUSE PANEL B -SB- ON ELECTRONICS BOX HIGH, ENGINE COMPARTMENT, LEFT SIDE
• 1.19- FUSE PANEL C -SC- INSTRUMENT PANEL - LEFT SIDE
• 1.23 - MAIN FUSE PANEL D -SD- IN LUGGAGE COMPARTMENT, RIGHT REAR
• 1.26- FUSES UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006)
• 1.1- Overview Of Fuses
• 1.2- POSITION OF RELAYS ON ELECTRONICS BOX LOW, FROM MODEL YEAR 2006
• 1.4- POSITION OF RELAYS ON ELECTRONICS BOX HIGH, FROM MODEL YEAR 2006
• 1.7- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2006)
• 1.8- POSITION OF RELAYS UNDER INSTRUMENT PANEL, LEFT SIDE (FROM MODEL YEAR 2009)
• 1.11- POSITION OF RELAYS ON MAIN FUSE PANEL, IN LUGGAGE COMPARTMENT - RIGHT REAR
• 1.5- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE, FROM MODEL YEAR 2006
• 1.6- POSITION OF RELAYS, RELAY CARRIER ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (FROM MODEL YEAR 2010)
• 1.9- POSITION OF RELAYS UNDER ELECTRONIC BOX
• FUSE INDEX INFORMATION
• FUSE - COLOR CODES
• 1.10- POSITION OF RELAYS UNDER ELECTRONIC BOX (2006 & Up)
