SELECTOR MECHANISM FUNCTION UNIT, CHECKING
Before maintenance or checking the connections, the cause of the damage should be determined through the Guided Fault Finding using vehicle tester.
Before inspection of the connections, all control devices in the vehicle should be checked for entries on their event log, if applicable, errors should be repaired see vehicle tester.
Checking the connections refer to appropriate SYSTEM WIRING DIAGRAM.
Scheme 173
- Electrical connector for the covering of the selector mechanism.
- Electrical connector for connections from the function unit of the switch mechanism to the transmission (with CAN lines) and to the shift lock solenoid -N110- and selector lever park position lock switch -F319
