Camber Adjustment. Scheme 1
Scheme 1: Camber Adjustment
Camber adjustment with special tool. Scheme 2
Scheme 2: Camber adjustment with special tool.
| Application | Specification |
|---|
| 4000CS Quattro |
| Front (1) |
| Camber in Degrees |
| Fraction | 3/4 +/- 1/2 |
| Decimal | .75 +/- .5 |
| Caster in Degrees |
| Fraction | +1 1/4 +/- 1/2 |
| Decimal | +1.25 +/- .5 |
| Toe-In in Inches |
| Fraction | +3/32 +/- 3/32 |
| Decimal | +.094 +/- .094 |
| Toe-In in Degrees |
| Fraction | +3/16 +/- 3/16 |
| Decimal | +.19 +/- .19 |
| Toe-Out in Turns |
| Inner | (2) |
| Outer | (2) |
| Steering Axis Inclination (SAI (2) |
| To VIN FA 095223 |
| Rear |
| Camber in Degrees |
| Fraction | 1/2 +/- 1/2 |
| Decimal | .5 +/- .5 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | +3/16 +/- 3/32 |
| Decimal | +.19 +/- .094 |
| Toe-In in Degrees |
| Fraction | +3/8 +/- 3/16 |
| Decimal | +.38 +/- .19 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| From VIN FA 095224 |
| Rear |
| Camber in Degrees |
| Fraction | 1 3/32 +/- 1/2 |
| Decimal | 1.094 +/- .5 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | +3/16 +/- 3/32 |
| Decimal | +.19 +/- .094 |
| Toe-In in Degrees |
| Fraction | +3/8 +/- 3/16 |
| Decimal | +.38 +/- .19 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| 5000 Series |
| Front (Scheme 1) (1) |
| Camber in Degrees |
| Fraction | 1/2 +/- 1/2 |
| Decimal | .5 +/- .5 |
| Caster in Degrees |
| Fraction | +13/16 +/- 11/16 |
| Decimal | .813 +/- .688 |
| Toe-In in Inches |
| Fraction | 1/64 +/- 1/16 |
| Decimal | .016 +/- .063 |
| Toe-In in Degrees |
| Fraction | 1/32 +/- 1/8 |
| Decimal | .031 +/- .13 |
| Toe-Out in Turns |
| Inner | (2) |
| Outer | (2) |
| Steering Axis Inclination (SAI) | (2) |
| To VIN EN 096669 |
| Rear |
| Camber in Degrees |
| Fraction | 1/2 +/- 5/16 |
| Decimal | .5 +/- .313 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | +1/8 +/- 1/16 |
| Decimal | +.13 +/- .063 |
| Toe-In in Degrees |
| Fraction | +1/4 +/- 1/8 |
| Decimal | +.25 +/- .13 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| From VIN EN 096670 |
| Rear |
| Camber in Degrees |
| Fraction | +1/2 +/- 5/16 |
| Decimal | +.5 +/- .313 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | +1/16 +/- 1/32 |
| Decimal | +.063 +/- .031 |
| Toe-In in Degrees |
| Fraction | +1/8 +/- 1/16 |
| Decimal | +.13 +/- .063 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| 4000S, Coupe GT |
| Front (Scheme 2) (1) |
| Camber in Degrees |
| Fraction | 9/16 +/- 1/2 |
| Decimal | .563 +/- .5 |
| Caster in Degrees |
| Fraction | +1/2 +/- 1/2 |
| Decimal | +.5 +/- .5 |
| Toe-In in Inches |
| Fraction | +5/32 +/- 5/32 |
| Decimal | +.16 +/- .16 |
| Toe-In in Degrees |
| Fraction | +5/16 +/- 5/16 |
| Decimal | +.31 +/- .31 |
| Toe-Out in Turns |
| Inner | (2) |
| Outer | (2) |
| Steering Axis Inclination (SAI) | (2) |
| Rear |
| Camber in Degrees |
| Fraction | 1 +/- 5/16 |
| Decimal | 1.0 +/- .313 |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | +5/32 +/- 5/16 |
| Decimal | +.16 +/- .31 |
| Toe-In in Degrees |
| Fraction | +5/16 +/- 5/8 |
| Decimal | +.31 +/- .63 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| (1) Caster and rear camber are not adjustable. (2) Information not available. |
| (1) | Caster and rear camber are not adjustable. |
| (2) | Information not available. |
WHEEL ALIGNMENT SPECIFICATIONS
