Interior Trim Acura ZDX I

Scheme 32

Trim Removal/Installation - Door Areas

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Front Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Release the hooks (A) and the tabs (B) from the kick panel (C) and the B-pillar lower trim (D). Pull up the front door sill trim (E) by hand to detach the clips, then remove the trim.
2. If necessary, pull up the front side outer trim (A) to detach the clips, then remove the trim.
3. Remove the kick panel (A). Pull out the front door opening seal (B) as needed from the kick panel hooks (C). Pull the kick panel back by hand to detach the clips (D, E). With BSI: Disconnect the BSI control unit connector (F). Driver's side Passenger's side
4. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ).
5. Pull out the front door opening seal (A) from the trim hooks (B) around the front door opening flange, then remove the seal.
6. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tabs into place securely.

Rear Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 38

Scheme 39

Scheme 40

1. Remove the rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats) ).
2. Release the hooks (A) and the tabs (B) from the B-pillar lower trim (C). Pull up the rear door sill trim (D) by hand to detach the clips, then remove the trim.
3. If necessary, pull up the rear side outer trim (A) to detach the clips, then remove the trim.
4. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ).
5. Pull out the rear door opening seal (A) from the trim hooks (B) around the rear door opening flange, then remove the seal.
6. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tabs into place securely.

Trim Removal/Installation - Pillar Areas

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

A-Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the A-pillar trim (B) consists of a plastic grommet (C) and a metal pin (D). The grommet expanded by the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Pull the front door opening seal away from the A-pillar as needed (see step 5 ).
2. Hit the upper clip (A) in the A-pillar trim (B) with a rubber mallet. Hitting the clip breaks the projections (C) on the pin (D) and pushes it into the grommet (E) on the body (F). NOTE: The upper clip must be replaced with a new one when the A-pillar trim is reinstalled.
3. Pull back the top of the A-pillar trim (A) by hand to remove the upper clip (B) from the body (C).
4. Pull out the A-pillar trim (A) by hand to detach the clip. Pull up the trim from the dashboard (B), and disconnect the tweeter connector (C), then remove the trim. NOTE: Be careful not to damage the tweeter connector when removing the A-pillar trim.
5. If the side curtain airbag has been deployed, replace the A-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
6. If the side curtain airbag has not deployed, check the A-pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the A-pillar trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the A-pillar trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the A-pillar trim, replace the upper clip (C) with a new one. If the clip (D) is damaged or stress-whitened, replace it with a new one.
7. Temporarily install the A-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
8. Carefully install the new upper clip (A) to the A-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown in illustration.
9. Reinstall the A-pillar trim (A). Insert the bottom of the trim into the dashboard (B), then reconnect the tweeter connector (C). -2 Place the trim over the A-pillar (D) and fit its upper clip (E) and the clip into the holes in the A-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked under the clips or the trim ribs. Do not push too hard on the A-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the A-pillar trim to verify that all clips are securely fastened.
10. Reinstall the front door opening seal (see step 5 ).

B-Pillar Upper/Lower Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the B-pillar upper trim (B) consists of a plastic grommet (C) and a metal pin (D). The grommet expanded by the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Remove these items: Front door sill trim (see «FRONT DOOR SILL AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) )
2. Slide the front seat forward fully.
3. Pull back the upper area of the B-pillar lower trim (A) to detach the clips, then release the hooks (B), and remove the trim.
4. Remove these items: Front seat belt lower anchor (see «FRONT SEAT BELT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/restraints-control-systems/#seat-belts) ) Front door opening seal, as needed (see step 5 ) Rear door opening seal, as needed (see step 5 )
5. Hit the upper clip (A) in the B-pillar upper trim (B) with a rubber mallet. Hitting the trim surface slides the projections (C) on the pin (D) and pushes it into the grommet (E) on the body (F). NOTE: The upper clip must be replaced with a new one when the B-pillar upper trim is reinstalled.
6. Pull back the top of the B-pillar upper trim (A) by hand to remove the upper clip (B) from the body (C).
7. Pull back the upper area of the B-pillar upper trim (A) by hand to release the hooks (B), then remove the trim.
8. If the side curtain airbag has deployed, replace the upper B-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
9. If the side curtain airbag has not deployed, check the B-pillar upper trim (A) and the B-pillar lower trim (B), and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the B-pillar trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the B-pillar upper trim Any cracks or deformations in the B-pillar lower trim, or any breakages in the area (C) that overlaps the B-pillar upper trim Any cracks or stress-whitening in the clip seating surface (D) After checking and adjusting the overlap between the headliner and the B-pillar upper trim, replace the upper clip (E) with a new one.
10. Temporarily install the B-pillar upper trim (without the upper dip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
11. Carefully install the new upper clip (A) to the B-pillar upper trim (B). Be sure that the grommet(C)is nearest to the top of the pin (D) as shown in illustration.
12. Reinstall the B-pillar upper trim (A). Insert the hooks (B) of the trim into the B-pillar hole (C). Place the trim over the B-pillar (D) and fit the upper clip (E) into the hole (F) in the B-pillar, then lightly push the trim into place. NOTE: Make sure the pin (G) on the front seat belt shoulder anchor adjuster (H) and the hole (I) on the back of the slider are engaged when installing the B-pillar upper trim. Make sure the side curtain airbag is not tucked under the clip or the trim ribs. Do not push too hard on the B-pillar upper trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the B-pillar trim to verify that all clip is securely fastened.
13. Reinstall all remaining removed parts. Make sure the seat belt is not twisted or kinked. Apply medium strength liquid thread lock to the upper anchor bolt to installation.

Quarter Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the quarter pillar trim (B) consists of a plastic grommet (C) and a metal pin (D). The grommet expanded by the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Remove the tailgate weatherstrip as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#tailgate) ).
2. Remove the roof end trim (A). Release the hooks (B) and the tabs (C) from the quarter pillar trim (D) on both sides. Pull down the trim by hand to detach the clips.
3. Remove these items: Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats) ) Rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/zdx/i-2009-2013/remont/seats/#seats__seat-side-bolster) ) Rear door opening seal, as needed (see step 5 ) Rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-area) ) Rear seat belt lower anchor (see «REAR SEAT BELT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/restraints-control-systems/#seat-belts) ) Left tailgate side trim (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-tailgate-area) )
4. Fold down the seat-back.
5. Hit the upper clip (A) in the quarter pillar trim (B) with a rubber mallet. Hitting the clip breaks the projections (C) on the pin (D) and pushes it into the grommet (E) on the body (F). NOTE: The upper clip must be replaced with a new one when the quarter pillar trim is reinstalled.
6. Pull back the top of the quarter pillar trim (A) by hand to remove the upper clip (B) from the body (C).
7. Remove the quarter pillar trim (A). Remove the pivot bracket mounting bolts (see step 2 under «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#tailgate) ), then push the power tailgate rod (B) in the trim. Pull the bottom of the trim back by hand to detach the clips (C, D). Pull the seat belt (E) out through the slit (F) in the trim. For some models: Disconnect the satellite speaker connector (G).
8. If the side curtain airbag has been deployed, replace the quarter pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
9. If the side curtain airbag has not deployed, check the quarter pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the quarter pillar trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the quarter pillar trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the quarter pillar trim, replace the upper clip (C) with a new one. If the clips (D) are damaged or stress-whitened, replace them with new ones.
10. Temporarily install the quarter pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
11. Carefully install the new upper clip (A) to the quarter pillar upper trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown in illustration.
12. Reinstall the quarter pillar trim (A). Insert the power tailgate rod (B) into the trim. For some models: Reconnect the satellite speaker connector (C). Place the trim over the quarter pillar (D) and fit the upper clip (E) into the hole (F) in the quarter pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked under the clips or the trim ribs. Do not push too hard on the quarter pillar trim. If you push too hard, the clip is damaged, and it will not hold the trim properly. Gently tug on the quarter pillar trim to verify that all clips (G, H) are securely fastened.
13. Reinstall all remaining removed parts. Make sure the seat belt is not twisted or kinked.

Trim Removal/Installation - Cargo Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Floor Lid

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Remove the front floor lid (A).
2. Open the rear floor lid (A). Pry out the clips (B) on both ends of the rear floor lid support struts (C), and then remove the support struts from the pivot bolts (D). Do not remove the clips from the struts. NOTE: Use eye protection when doing this procedure.
3. Close the rear floor lid (A). Remove the screws, then remove the rear floor lid.
4. If necessary, remove the tool box spacer (A).
5. Install the floor lid in the reverse order of removal.

Rear Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 65

1. Remove the tailgate weatherstrip near the rear trim panel as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#tailgate) ).
2. Remove the rear trim panel (A). Open the rear floor lid. Pry out the covers (B), and remove the screws (C), then remove the tie down hooks (D). Release the hooks (E) and the tabs (F) from the rear side trim panels. Pull up the rear trim panel by hand to detach the clips.
3. Install the trim and panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tabs into place securely.

Scheme 66

1. Remove the front floor lid and the tool box spacer.
2. Remove the screw, then pull up the seat flap assembly (A) by hand to detach the clips, and remove it.
3. Install the seat flap assembly in the reverse order of removal and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Scheme 67

1. Remove the floor lid.
2. Remove the screws, then remove the handle case (A) and the handle (B) from the floor lid.
3. Install the floor lid handle in the reverse order of removal.

Scheme 68

1. Remove the rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-area) ).
2. Detach the clips, then remove the rear under floor cover (A).
3. Install the rear under floor cover in the reverse order of removal and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Trim Removal/Installation - Rear Side Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Rear Side Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 69

Scheme 70

1. Remove the cargo area side lid (A).
2. Remove these items: Rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/zdx/i-2009-2013/remont/seats/#seats__seat-side-bolster) ) Front floor lid (see «FLOOR LID»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__floor-lid) ) Rear floor lid (see «FLOOR LID»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__floor-lid) ) Tailgate weatherstrip, as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#tailgate) ) Rear trim panel (see «REAR TRIM PANEL»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__rear-trim-panel) )
3. Fold down the seat-back.
4. Remove the rear side trim panel (A). Pry out the cover (B) and remove the screw (C), then remove the tie down hook (D). Detach the clips (E) from the front area of the trim panel. Pull back the upper edge of the trim panel to release the hooks (F) from the quarter pillar trim (G). Pull out the trim panel back by hand to detach the clips (H). Pull the front area of the trim panel inward to release it from the rear seat-back striker (I). Disconnect the cargo area light connector (J).
5. Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly. Push the clips, the hooks, and the tabs into place securely.

Trim Removal/Installation - Tailgate Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. Remove the tailgate upper trim (A). Release the hooks (B) and the tabs (C) from each tailgate side trim. Pull the tailgate upper trim back by hand to detach the clips.
2. Remove the left tailgate side trim (A) and the right tailgate side trim (B). Release the hooks (C) and the tabs (D) from the tailgate lower trim panel. Pull out the top of the side trim to detach the clips. Left side: Pass the power tailgate rod (E) through the slit (F).
3. Remove the power tailgate inside switch (see «POWER TAILGATE INSIDE SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#power-tailgate) ).
4. Remove the tailgate light (see «TAILGATE LIGHT TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/interiorillumination-lights/#interior-lights) ).
5. Detach the clips securing the tailgate lower trim panel (A).
6. Remove the tailgate pull pocket (A). Carefully pull the edge of the tailgate lower trim panel just beside the tailgate pull pocket by hand, and push out the inside hooks (B). Pull down the upper edge of the pocket, and release the lower tabs (C).
7. Pull the tailgate lower trim panel (A) back by hand, and detach the clips (B, C), then remove it.
8. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tabs into place securely.

Sunvisor Removal/Installation

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. Insert a flat-tip screwdriver through the hole in the front side of the bracket cover (A), and push the hook (B). Make sure the hook is unlocked.
2. While pushing in the hook (A) with a flat-tip screwdriver, release the sunvisor (B) from the holder (C), and rotate the sunvisor backward about 45 °. Make sure the hook slides into the bracket cover as you rotate the sunvisor.
3. Pull down the sunvisor (A) to release the pin (B) and the bracket (C) from the holes in the body. Then pull out the vanity mirror light connector (D) and disconnect it. NOTE: If the sunvisor cannot be pulled down, the hook has not rotated into the bracket cover. Repeat step 2 to rotate the hook.
4. Turn the holder (A) 45 ° counterclockwise, and pull it down to remove it from the holder grommet (B).
5. Pry out the holder grommet (A) from the body by pinching its hooks (B).
6. If the side curtain airbag has deployed, replace the sunvisor, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
7. If the side curtain airbag has not deployed, inspect the sunvisor for damage. A damaged sunvisor may cause the side curtain airbags to deploy improperly, possibly causing injury. Replace the sunvisor if it has any of the following damage: Any cracks in the sunvisor bracket (A) Any cracks in the sunvisor bracket cover (B) Any bends or cracks in the sunvisor stay shaft (C) Any cracks in the sunvisor base (D) Any cracks in the vanity mirror base (E)
8. If the holder grommet is damaged or stress-whitened, replace it with a new one.
9. Install the holder (A) into the holder grommet (B) by turning it 45 ° clockwise, and install them into the body as an assembly by pushing it until the hooks (C) snap into place securely.
10. Connect the vanity mirror light connector (A), and install the sunvisor (B) by inserting the bracket (C) and the pin (D) of the bracket cover (E) into the holes in the body.
11. While holding the bracket cover (A), rotate the sunvisor (B) forward until the hook (C) snaps into place. Gently pull down on the sunvisor to make sure it is properly secured in the body. Rotate the sunvisor into the holder (D).

Grab Handle Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. Lower the grab handle (A), then insert a small flat-tip screwdriver into the notch.
2. Pull on the small flat-tip screwdriver with the appropriate trim tool (A), and remove the cap (B).
3. Pinch the clips (A) to release the hooks (B), then remove the grab handle (C).
4. Pinch the hooks on the clips (A) with a pair of pliers, and pull out the clips of the bracket.
5. If the side curtain airbag has deployed, replace the grab handle, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
6. If the side curtain airbag has not deployed, inspect the grab handle for damage. A damaged grab handle may cause the side curtain airbags to deploy improperly, possibly causing injury. Replace the grab handle if it has any of the following damage: Any cracks or damage in the grab handle (A) Any cracks or stress-whitening in the caps (B)
7. Install the clips (A) on the grab handle (B), then insert the caps (C) fully into the clips.
8. Position the grab handle (A) on the mounting bracket (B), and push on the grab handle until the clips (C) snap into place securely.

Headliner Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner, the dashboard, or the other interior trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

1. Remove the front seat belt lower anchor from the seat (see «FRONT SEAT BELT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/restraints-control-systems/#seat-belts) ).
2. Slide both the front seats all the way back, and recline the seat-back fully.
3. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work.
4. Remove these items: A-pillar trims, both sides (see «A-PILLAR TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__a-pillar-trim) ) B-pillar upper/lower trims, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) Quarter pillar trims, both sides (see «QUARTER PILLAR TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ) Sunvisors, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__sunvisor-removalinstallation) ) Grab handles, four places (see «GRAB HANDLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__grab-handle-removalinstallation) ) Rear individual map light (see «REAR INDIVIDUAL MAP LIGHT INPUT TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/interiorillumination-lights/#interior-lights) )
5. Remove the roof console (A). Remove the screws, then pull down the roof console by detaching the clips. Disconnect the roof console connector (B), the panoramic glass roof/sunshade switch connector (C), and the HFL microphone connector (D) (if equipped).
6. If necessary, remove the remaining roof console clips (A) from the body (B).
7. Passenger's side: Disconnect the roof wire harness connector (A) and the antenna read connector (B), and remove the wire harness (C) from the A-pillar by detaching the harness clips (D).
8. From the right rear corner area, disconnect and detach the antenna lead connector (A).
9. Lower the headliner (A). Remove the front door opening seals (B) and the rear door opening seals (C) from each roof area. With the help of an assistant, detach the rear clips (D) by pulling the rear area of the headliner down. With the help of an assistant, gently pull down the headliner opening to detach the clips (E), and release the fasteners (F) and the magnet (G) and the dual lock (H) by lowering the headliner.
10. With the help of an assistant, pull the headliner (A) along with the wire harnesses out through the tailgate opening. NOTE: Do not bend the headliner. Bending the headliner will crease and damage it.
11. If necessary, remove the cushion tapes (A) fastening the roof subharness (B) to the headliner (C). Detach the harness clips (D, E), then remove them from the headliner.
12. If necessary, remove the front grab handle bracket (A) and the rear grab handle bracket (B). Take care not to damage the side curtain airbag. Remove the side curtain airbag mounting bolts (C, D) and the washer (E). Release the clips (F) holding the grab handle bracket to the side curtain airbag. Front Rear
13. Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the headliner and removed trim pieces, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ). Replace the grab handle bracket mounting 6 mm bolts with new ones if they were removed. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the headliner and all removed trim. Replace any pieces with the following damage: Any creases or tears in the headliner (A) Any cracks or breakage in the grab handle (B) Any damages around the grab handle holes (C) or the sunvisor holes (D) in the headliner Any cracks in the sunvisor stay base (E) Any cracks in the sunvisor bracket cover (F) Any bends or cracks in the sunvisor stay shaft (G) Any cracks in the sunvisor base (H) Any cracks or breakage in the vanity mirror base (I) Any stiffeners (J) which have come off the headliner Any cracks or stress-whitening in the seating surfaces (K) of the clips (L), the fasteners (M), the magnet (N), or the dual lock (0) If the clips, the fasteners, the magnet, or the dual lock are damaged or stress-whitened, replace them with new ones. Replace the removed cushion tapes with new ones. When reinstalling the headliner through the tailgate opening, be careful not to fold or bend it. Also, be careful not to scratch the body. Check that both sides of the headliner are securely attached to the body. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Push the clips and the hooks into place securely. When installing the grab handle, push on the handle against the bracket (P) until the clips (Q) snap into place securely. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ). Headliner Grab handle Sunvisor

Carpet Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to damage the dashboard or the other interior trim pieces. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. Remove the front seat belt lower anchor from the seat, and remove the seat mounting bolts (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-removalinstallation) ).
2. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work.
3. Remove these items: Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) B-pillar lower trims, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-removalinstallation) ) Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Steering joint cover (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/zdx/i-2009-2013/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) )
4. Remove the footrest (A) by pulling it to detach the clips.
5. Remove the carpet (A). Detach the clips fastening the carpet to both door sill areas. Release the Velcro fastener (B) on the front edge of the carpet, then pull back the carpet from under the dashboard. Pull the floor wire harnesses (C) out through the slits (D).
6. If necessary, release the hook (A) that is just under the arrow mark (B) on the floor mat holder (C) by prying up on the holder with a flat-tip screwdriver, and remove the holder through the slit (D) in the carpet (E).
7. If necessary, detach the clip, then remove the carpet spacer (A).
8. Install the carpet in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Take care not to damage, wrinkle, or twist the carpet. Make sure the seat harnesses are routed correctly. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/zdx/i-2009-2013/remont/body-electrical/#battery) ).

See also:
• REAR SEAT REMOVAL/INSTALLATION
• COMPONENT LOCATION INDEX
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• FRONT SEAT BELT REPLACEMENT
• TAILGATE WEATHERSTRIP REPLACEMENT
• SEAT SIDE BOLSTER
• POWER TAILGATE INSIDE SWITCH TEST/REPLACEMENT
• TAILGATE LIGHT TEST/REPLACEMENT
• BATTERY TERMINAL DISCONNECTION AND RECONNECTION
• FRONT SEAT REMOVAL/INSTALLATION
• CENTER CONSOLE REMOVAL/INSTALLATION
• STEERING COLUMN REMOVAL AND INSTALLATION
• B-PILLAR UPPER/LOWER TRIM
• FRONT DOOR SILL AREA
• REAR DOOR SILL AREA
• TRIM REMOVAL/INSTALLATION - REAR SIDE AREA
• TRIM REMOVAL/INSTALLATION - TAILGATE AREA
• FLOOR LID
• REAR TRIM PANEL
• A-PILLAR TRIM
• QUARTER PILLAR TRIM
• SUNVISOR REMOVAL/INSTALLATION
• GRAB HANDLE REMOVAL/INSTALLATION
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
