General Information Acura TSX I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Paint Code

PAINT CODE REFERENCE

Scheme 5

Scheme 6

Scheme 7

Scheme 8

PAINT CODE REFERENCE

Scheme 9

Scheme 10

Scheme 11

Scheme 12

PAINT CODE REFERENCE

Scheme 13

Scheme 14

Scheme 15

Scheme 16

PAINT CODE REFERENCE

Scheme 17

Scheme 18

Scheme 19

Scheme 20

PAINT CODE REFERENCE

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Emission Group Identification

Example

'04-07 Models

Scheme 26

'08 Model

Scheme 27

'04 Model

THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5 REGULATIONS APPLICABLE TO 2004 MODEL YEAR NEW PASSENGER CARS AND CALIFORNIA REGULATIONS APPLICABLE TO 2004 MODEL YEAR NEW LEV II LEV PASSENGER CARS.

'05 Model

THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5 AND CFV LEV REGULATIONS APPLICABLE TO 2005 MODEL YEAR NEW PASSENGER CARS AND CALIFORNIA REGULATIONS APPLICABLE TO 2005 MODEL YEAR NEW LEV II LEV PASSENGER CARS. EPA CERTIFICATION TEST FUEL FOR CFV: EPA UNLEADED GASOLINE.

'06 Model

THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5 REGULATIONS APPLICABLE TO 2006 MODEL YEAR NEW PASSENGER CARS AND CALIFORNIA REGULATIONS APPLICABLE TO 2006 MODEL YEAR NEW LEV II LEV PASSENGER CARS.

'07 Model

THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5 REGULATIONS APPLICABLE TO 2007 MODEL YEAR NEW PASSENGER CARS AND CALIFORNIA REGULATIONS APPLICABLE TO 2007 MODEL YEAR NEW LEV II LEV PASSENGER CARS.

Test Group and Evaporative Family

Test Group

Scheme 28

Evaporative Family

Scheme 29

Lift and Support Points

Note. If you are going to remove heavy components such as suspension or the fuel tank from the rear of the vehicle, first support the front of the vehicle with tall safety stands. When substantial weight is removed from the rear of the vehicle, the center of gravity can change, causing the vehicle to tip forward on the lift.

Scheme 30

1. Position the lift blocks (A) under the vehicle's front support points (B) and rear support points (C).
2. Raise the lift a few inches, and rock the vehicle gently to be sure it is firmly supported.
3. Raise the lift to its full height, and inspect the vehicle support points for solid contact with the lift blocks.

Safety Stands

To support the vehicle on safety stands, use the same support points (B and C) as for a vehicle lift. Always use safety stands when working on or under any vehicle that is supported only by a jack.

Scheme 31

1. When lifting the front of the vehicle, set the parking brake. When lifting the rear of the vehicle, put the shift lever in reverse for manual transmission, or in the P position for automatic transmission.
2. Block the wheels that are not being lifted.
3. Position the floor jack under the front jacking bracket (A) or the rear jacking bracket (B). Center the jacking bracket on the jack lift platform (C), and jack up the vehicle high enough to fit the safety stands under it.
4. Position the safety stands under the support points and adjust them so the vehicle is level.
5. Lower the vehicle onto the stands.

Towing

If the vehicle needs to be towed, call a professional towing service. Never tow the vehicle behind another vehicle with a rope or chain. It is very dangerous.

Emergency Towing

There are three popular methods of towing a vehicle.

Flat-bed Equipment - The operator loads the vehicle on the back of a truck. This is the best way of transporting the vehicle.

To accommodate flat-bed equipment, the vehicle is equipped with front towing hooks (A), front tie down hook slots (B), a rear towing hook (C), and rear tie down hook slots (D).

The towing hook can be used with a winch to pull the vehicle onto the truck, and the tie down hook slots can be used to secure the vehicle to the truck.

Front

Scheme 32

Rear

Scheme 33

Wheel Lift Equipment - The tow truck uses two pivoting arms that go under the tires (front or rear) and lift them off ground. The other two wheels remain on the ground. This is an acceptable way of towing the vehicle.

Sling-type Equipment - The tow truck uses metal cables with hooks on the ends. These hooks go around parts of the frame or suspension and the cables lift that end of the vehicle off the ground. The vehicle's suspension and body can be seriously damaged if this method of towing is attempted. This method of towing the vehicle is unacceptable.

If the vehicle cannot be transported by a flat-bed, it should be towed with the front wheels off the ground. If the vehicle is damaged, and must be towed with the front wheels on the ground, or if the vehicle is towed with all four wheels on the ground, do this

Manual Transmission

1. Release the parking brake.
2. Shift the transmission in neutral.
3. Leave the ignition switch in the ACCESSORY (I) position so the steering wheel does not lock.
4. Make sure all accessories are turned off to minimize battery current draw.

Automatic Transmission

1. Release the parking brake.
2. Start the engine.
3. Shift to the D position, then to the N position.
4. Turn off the engine.
5. Leave the ignition switch in the ACCESSORY (I) position so the steering wheel does not lock.
6. Make sure all accessories are turned off to minimize battery current draw.

It is best to tow the vehicle no farther than 50 miles (80 km), and keep the speed below 35 mph (55 km/h).

Note. Improper towing preparations will damage the transmission. Follow the above procedure exactly. If you cannot shift the transmission or start the engine (automatic transmission), the vehicle must be transported on a flat-bed. Trying to lift or tow the vehicle by the bumpers will cause serious damage. The bumpers are not designed to support the vehicle's weight.

Parts Marking

To deter vehicle theft, certain major components are marked with the vehicle identification number (VIN). Original parts have self-adhesive labels. Replacement body parts have generic self-adhesive labels. These labels should not be removed. The original engine or transmission VIN plates are not transferable to the replacement engine or transmission.

Note. Be careful not to damage the parts marking labels during body repair. Mask the labels before repairing the part.
