Engine Lubrication System Acura TSX I

Lubrication System 39 illustrations ~1909 words

Scheme 1

Scheme 1: Special Tools
Scheme 1: Special Tools

Scheme 2

Scheme 2: Component Location Index
Scheme 2: Component Location Index

Symptom Troubleshooting Index

SymptomDiagnostic procedureAlso check for
Excessive engine oil consumptionVerify the engine oil filler cap, oil drain bolt, and oil filter are tight. Check for oil leaks. Check for worn valve guide(s) (see VALVE SEAT RECONDITIONING ) or worn valve stem seal(s) (see VALVE SEAT RECONDITIONING ). Check for damaged or worn piston ring(s) (see BLOCK AND PISTON INSPECTION ). Check for damaged or worn engine internal parts (cylinder wall, pistons, etc.) (see BLOCK AND PISTON INSPECTION ).
Low oil pressure indicator does not come on with the ignition switch ON (II)Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ). Test the oil pressure switch (see OIL PRESSURE SWITCH TEST ).An open in the wire between the gauge control module and the oil pressure switch
Low oil pressure indicator stays onCheck the engine oil level. Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ). Test the oil pressure switch (see OIL PRESSURE SWITCH TEST ). Check the engine oil pressure (see OIL PRESSURE TEST ). Check the oil filter for clogging. Check the oil screen for clogging. Check the relief valve. Inspect the oil pump (see OIL PUMP INSPECTION ).A wire shorted to ground between the gauge control module and the oil pressure switch

SYMPTOM TROUBLESHOOTING CHART

Scheme 3

Scheme 3: Oil Pressure Switch Test
Scheme 3: Oil Pressure Switch Test
  1. Remove the YEL/RED wire (A) from the oil pressure switch (B).
  2. Check for continuity between the positive terminal (C) and the engine (ground). There should be continuity with the engine stopped. There should be no continuity with the engine running.
  3. If the switch fails to operate, check the engine oil level. If the engine oil level is OK, check the engine oil pressure. If the oil pressure is OK, replace the oil pressure switch (see «OIL PRESSURE SWITCH REPLACEMENT»(/acura/tsx/i-2003-2008/remont/lubrication-system/#engine-lubrication-system) ).

Scheme 4

Scheme 4: Oil Pressure Switch Replacement
Scheme 4: Oil Pressure Switch Replacement
  1. Disconnect the oil pressure switch connector, then remove the oil pressure switch.
  2. Remove all of the old liquid gasket from the switch and switch mounting hole.
  3. Apply a very small amount of liquid gasket to the new oil pressure switch threads, then install the oil pressure switch. NOTE: Using too much liquid gasket may cause liquid gasket to enter the oil passage or the end of the new oil pressure switch.

Oil Pressure Test

If the oil pressure warning indicator stays on with the engine running, check the engine oil level. If the oil level is correct

Scheme 5

Scheme 5: Oil Pressure Test
Scheme 5: Oil Pressure Test
  1. Remove the oil pressure switch, and install an oil pressure gauge (A).
  2. Start the engine. Shut it off immediately if the gauge registers no oil pressure, and repair the problem before continuing.
  3. Allow the engine to reach operating temperature (fan comes on at least twice). The pressure should be: Engine Oil Temperature: 176°F (80°C) Engine Oil Pressure: At Idle: 70 kPa (0.7 kgf/cm 2 , 10 psi) min. At 3,000 rpm: 300 kPa (3.1 kgf/cm 2 , 44 psi) min.
  4. If the oil pressure is not within specifications, inspect these items. Check the oil screen for clogging. Inspect the oil pump (see «OIL PUMP INSPECTION»(/acura/tsx/i-2003-2008/remont/lubrication-system/#engine-lubrication-system) ).

Scheme 6

Scheme 6: '04-05 models
Scheme 6: '04-05 models
  1. Warm up the engine.
  2. Remove the maintenance lid (A).
  3. Remove the drain bolt (B), and drain the engine oil.
  4. Reinstall the drain bolt with a new washer (C).
  5. Refill with the recommended oil (see «LUBRICANTS AND FLUIDS»(/acura/tsx/i-2003-2008/remont/reset-procedures/#maintenance__lubricants-and-fluids) ). Capacity At Oil Change: 4.0 L (4.2 US qt) At Oil Change including Filter: 4.2 L (4.4 US qt) After Engine Overhaul: 5.3 L (5.6 US qt)
  6. Run the engine for more than 3 minutes, then check for oil leakage.

Scheme 7

Scheme 7: '06-08 models
Scheme 7: '06-08 models
  1. Warm up the engine.
  2. Remove the maintenance lid (A).
  3. Remove the drain bolt (B), and drain the engine oil.
  4. Reinstall the drain bolt with a new washer (C).
  5. Refill with the recommended oil (see «LUBRICANTS AND FLUIDS»(/acura/tsx/i-2003-2008/remont/reset-procedures/#maintenance__lubricants-and-fluids) ). Capacity At Oil Change: 4.0 L (4.2 US qt) At Oil Change including Filter: 4.2 L (4.4 US qt) After Engine Overhaul: 5.3 L (5.6 US qt)
  6. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 of «HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)»(/acura/tsx/i-2003-2008/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__how-to-use-the-hds-honda) ).
  7. Turn the ignition switch ON (II).
  8. Make sure the HDS communicates with the vehicle and the engine control module (ECM)/powertrain control module (PCM). If it doesn't communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
  9. Select BODY ELECTICAL with the HDS.
  10. Select ADJUSTMENT in the GAUGES MENU with the HDS.
  11. Select RESET in the MAINTENANCE MINDER with the HDS.
  12. Select RESETTING THE ENGINE OIL LIFE with the HDS. NOTE: If you changed the ATF at the same time with the engine oil, select RESETTING THE ENGINE OIL LIFE AND ATF with the HDS instead.
  13. Run the engine for more than 3 minutes, then check for oil leakage.
  14. Reset the maintenance display (see «RESETTING THE MAINTENANCE INFORMATION DISPLAY»(/acura/tsx/i-2003-2008/remont/reset-procedures/#maintenance) ).

Engine Oil Filter Replacement

Special Tools Required

Oil filter wrench 07AAA-PLCA100

Scheme 8

Scheme 8: Engine Oil Filter Replacement
Scheme 8: Engine Oil Filter Replacement

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. Remove the oil filter with the oil filter wrench.
  2. Inspect the threads (A) and the rubber seal (B) on the new filter. Clean the seat on the engine block, then apply a light coat of oil to the new filter rubber seal. Use only filters with a built-in bypass system.
  3. Install the oil filter by hand.
  4. After the rubber seal seats, tighten the oil filter clockwise with the oil filter wrench (A). Tighten: 3/4 Turn Clockwise Tightening Torque: 12 N.m (1.2 kgf.m, 8.8 lbf.ft)
  5. If four numbers or triangle marks (1 to 4 or triangle marks) are printed around the outside of the filter, use the following procedure to tighten the filter. Spin the filter on until its seal lightly seats against the block, and note which number or mark is at the bottom. Tighten the filter by turning it clockwise three numbers or marks from the one you noted. For example, if number 2 is at the bottom when the seal is seated, tighten the filter until the number 1 comes around the bottom. (Scheme 11): Identifying Tightening Procedure Chart
  6. After installation, fill the engine with oil up to the specified level, run the engine for more than 3 minutes, then check for oil leakage.

Scheme 12

Scheme 12: Oil Filter Feed Pipe Replacement
Scheme 12: Oil Filter Feed Pipe Replacement

Scheme 13

Scheme 13
Scheme 13
  1. Remove the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/lubrication-system/#engine-lubrication-system__engine-oil-filter-replacement) ).
  2. Remove the oil filter feed pipe.
  3. Install the two 20 x 1.5 mm nuts (A) onto the new oil filter feed pipe. Hold the nut with a wrench, then tighten the other nut.
  4. Tighten the oil filter feed pipe to the block to 50 N.m (5.0 kgf.m, 37 lbf.ft), then remove the nuts from the oil filter feed pipe.

Scheme 14

Scheme 14: Oil Jet Inspection
Scheme 14: Oil Jet Inspection
  1. Remove the oil jet, and inspect it as follows. Make sure that a 1.1 mm (0.04 in.) diameter drill will go through the nozzle hole (A) (1.2 mm (0.05 in.) diameter). Insert the other end of a 1.1 mm (0.04 in.) drill into the oil intake (1.2 mm (0.05 in.) diameter). Make sure the check ball (B) moves smoothly and has a stroke of approximately 4.0 mm (0.16 in.). Check the oil jet operation with an air nozzle. It should take at least 200 kPa (2.0 kgf/cm 2 , 28 psi) to unseat the check ball. NOTE: Replace the oil jet assembly if the nozzle is damaged or bent.
  2. Carefully install the oil jet. The mounting torque is critical. Torque: 16 N.m (1.6 kgf.m, 12 lbf.ft)

Scheme 15

Scheme 15: Exploded View
Scheme 15: Exploded View

Scheme 16

Scheme 16: Oil Pump Removal
Scheme 16: Oil Pump Removal

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Turn the crankshaft pulley so its top dead center (TDC) mark lines up with the pointer (see step 4 of «CAM CHAIN REMOVAL»(/acura/tsx/i-2003-2008/remont/mechanical/#cylinder-head__cam-chain-removal) .
  2. Remove the oil pan (see «OIL PAN REMOVAL»(/acura/tsx/i-2003-2008/remont/mechanical/#engine-block__oil-pan-removal) ).
  3. Remove and discard the oil pump chain tensioner.
  4. To hold the rear balancer shaft, insert a 6 mm pin driver (A) into the maintenance hole in the lower balancer shaft holder and through the rear balancer shaft.
  5. Loosen the oil pump sprocket mounting bolt.
  6. Remove the oil pump sprocket (A), then remove the oil pump (B).

Scheme 19

Scheme 19: Oil Pump Inspection
Scheme 19: Oil Pump Inspection

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove the pump housing.
  2. Check the inner-to-outer rotor radial clearance between the inner rotor (A) and outer rotor (B). If the inner-to-outer rotor radial clearance exceeds the service limit, replace the oil pump. Inner Rotor-to-Outer Rotor Radial Clearance Standard (New): 0.06-0.16 mm (0.002-0.006 in.) Service Limit: 0.20 mm (0.008 in.)
  3. Check the housing-to-rotor axial clearance between the rotor (A) and pump housing (B). If the housing-to-rotor axial clearance exceeds the service limit, replace the oil pump. Housing-to-Rotor Axial Clearance Standard (New): 0.035-0.070 mm 0.0013-0.0028 in.) Service Limit: 0.12 mm (0.005 in.)
  4. Check the housing-to-outer rotor radial clearance between the outer rotor (A) and pump housing (B). If the housing-to-outer rotor radial clearance exceeds the service limit, replace the oil pump. Housing-to-Outer Rotor Radial Clearance Standard (New): 0.15-0.21 mm (0.006-0.008 in.) Service Limit: 0.23 mm (0.009 in.)
  5. Inspect both rotors and the pump housing for scoring or other damage. Replace the parts if necessary.

Scheme 23

Scheme 23: Balancer Shaft Inspection
Scheme 23: Balancer Shaft Inspection

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Seat the balancer shaft by pushing it away from the oil pump sprocket end of the oil pump.
  2. Zero the dial indicator against the end of the balancer shaft, then push the balancer shaft back and forth and read the end play. Balancer Shaft End Play Front Balancer Shaft: Standard (New): 0.063-0.108 mm (0.0025-0.0043 in.) Service Limit: 0.14 mm (0.0055 in.) Rear Balancer Shaft: Standard (New): 0.063-0.108 mm (0.0025-0.0043 in.) Service Limit: 0.14 mm (0.0055 in.)
  3. Remove the baffle plate (A) and upper balancer shaft holder (with bearings) (B), then remove the front balancer shaft (C) and rear balancer shaft (D).
  4. Measure the inner diameters of the No. 1 bearing for the front balancer shaft hole and the rear balancer shaft hole. Bearing Inner Diameter Front: Standard (New): 20.000-20.020 mm (0.7874-0.7882 in.) Service Limit: 20.03 mm (0.789 in.) Rear: Standard (New): 24.000-24.020 mm (0.9449-0.9457 in.) Service Limit: 24.03 mm (0.946 in.) Front:. Rear
  5. Measure the diameters of the No. 1 journal on the front balancer shaft and rear balancer shaft. Journal Diameter Front: Standard (New): 19.938-19.950 mm (0.7850-0.7854 in.) Service Limit: 19.92 mm (0.784 in.) Rear: Standard (New): 23.938-23.950 mm (0.9424-0.9429 in.) Service Limit: 23.92 mm (0.942 in.) Front: Rear
  6. Clean both balancer shaft No. 2 journals and bearing halves with a clean shop towel, then install the balancer shaft on the lower balancer shaft holder.
  7. Place one strip of plastigage across each No. 2 journal.
  8. Reinstall the bearings and upper balancer shaft holder, then torque the bolts. NOTE: Do not rotate the balancer shafts during inspection.
  9. Remove the upper balancer shaft holder and bearings, then measure the widest part with the plastigage. If the balancer shaft No. 2 journal oil clearance is out-of-tolerance, install new bearings, and recheck. If it is still out-of-tolerance, replace the balancer shafts. No. 2 Journal Oil Clearance Standard (New): 0.060-0.120 mm (0.0024-0.0047 in.) Service Limit: 0.15 mm (0.006 in.)
  10. Align the punch mark on the rear balancer shaft in the center of the two punch marks on the front balancer shaft, then install the balancer shafts on the lower balancer shaft holder.
  11. Apply new engine oil to the threads of the 8 mm bolts (A).
  12. Install the upper balancer shaft holder (B) and baffle plate (C).
  13. Install the pump housing.

Scheme 34

Scheme 34: Oil Pump Installation
Scheme 34: Oil Pump Installation

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Make sure the No. 1 piston is at TDC (see step 6 of «CAM CHAIN REMOVAL»(/acura/tsx/i-2003-2008/remont/mechanical/#cylinder-head__cam-chain-removal) ).
  2. Align the dowel pin (A) on the rear balancer shaft with the mark (B) on the oil pump.
  3. To hold the rear balancer shaft, insert a 6 mm pin driver (A) into the maintenance hole in the lower balancer shaft holder and through the rear balancer shaft.
  4. Apply new engine oil to the threads of the oil pump sprocket mounting bolt (A).
  5. Loosely install the oil pump (B), then install the oil pump sprocket (C).
  6. Remove the pin driver (D).
  7. Tighten the oil pump mounting bolts.
  8. Squeeze the new oil pump chain tensioner (A), then install the set clip (B) on it as shown. NOTE: The set clip is supplied with the oil pump chain tensioner.
  9. Install the new oil pump chain tensioner.
  10. Remove the set clip from the oil pump chain tensioner.
  11. Install the oil pan (see «OIL PAN INSTALLATION»(/acura/tsx/i-2003-2008/remont/mechanical/#engine-block__oil-pan-installation) ).
