Scheme 29: Component Location Index
Scheme 29: Component Location Index

Hood Opener Cable Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the body and related parts.

Scheme 30

Scheme 30: Hood Opener Cable Replacement
Scheme 30: Hood Opener Cable Replacement
  1. Remove these items: Front fender trim (see «FRONT FENDER TRIM REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#exterior-trim__front-fender-trim-replacement) ) Front grille cover (see «FRONT GRILLE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#exterior-trim__front-grille-replacement) ) Front Inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ) Kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) )
  2. Disconnect the hood opener cable (A) from the hood latch (B) (see «HOOD LATCH REPLACEMENT»(/acura/tsx/i-2003-2008/remont/door-locks-anti-theft-systems/#openers) ).
  3. Using a clip remover, detach the clips (C, D), and remove the grommet (E) from the body, then remove the hood opener cable from the vehicle. Take care not to kink the cable.
  4. Install the cable in the reverse order of removal, and note these items: Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Route the cable through the holes (F) in the body and front fender bulkhead correctly.

Trunk Lid Opener Cable/Fuel Fill Door Opener Cable Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to scratch the body and related parts.

Scheme 31

Scheme 31: Trunk Lid Opener Cable/Fuel Fill Door Opener Cable Replacement
Scheme 31: Trunk Lid Opener Cable/Fuel Fill Door Opener Cable Replacement

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Remove these items from the left side of the vehicle: Front door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__rear-seat-removalinstallation) ) Trunk lid trim (see «TRIM REMOVAL/INSTALLATION - TRUNK LID»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-lid) ) Trunk rear trim panel (see «TRIM REMOVAL/INSTALLATION - TRUNK AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-area) ) Trunk side trim panel, left side (see «TRIM REMOVAL/INSTALLATION - TRUNK AREA»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-area) ) Trunk lid hinge cover (see «TRIM REMOVAL/INSTALLATION - TRUNK LID»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-lid) )
  2. Pull the carpet back as necessary.
  3. Disconnect the trunk lid opener/fuel fill door opener cable (A) from the opener (B) (see «TRUNK LID OPENER/FUEL FILL DOOR OPENER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/door-locks-anti-theft-systems/#openers__trunk-lid-openerfuel-fill-door-opener) ).
  4. Release the opener cable from the clip (C). Remove the cushion tape (D).
  5. Remove the fuel fill door latch (A) by turning it 90°, and detach the opener cable junction box (B) from the body.
  6. Disconnect the trunk lid opener cable (C) from the trunk lid latch (D) (see «TRUNK LID LATCH REPLACEMENT»(/acura/tsx/i-2003-2008/remont/door-locks-anti-theft-systems/#openers) ).
  7. Using a clip remover. Release the trunk lid opener/ fuel fill door opener cable from the clips (E, F).
  8. Remove the trunk lid opener/fuel fill door opener cable from the vehicle. Take care not to kink the cable.
  9. Install the opener cable in the reverse order of removal, and note these items: Align the marks (A) on the opener cable (B) with the cable clips (C) and cushion tape (D) as shown. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.

Scheme 34

Scheme 34: Hood Latch Replacement
Scheme 34: Hood Latch Replacement

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. Remove the front grille cover (see «FRONT GRILLE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#exterior-trim__front-grille-replacement) ).
  2. Remove the bolts, then remove the hood latch cover (A) from the hood latch (B).
  3. Disconnect the hood latch switch connector (A).
  4. Remove the bolts, then remove the hood latch (A) from the body.
  5. Disconnect the hood opener cable (B) from the hood latch. Take care not to kink the cable.
  6. Install the latch in the reverse order of removal, and note these items: Apply multipurpose grease to each location of the hood latch indicated by the arrows. Make sure the hood opener cable is connected properly and hood latch switch connector is plugged in properly. Adjust the hood latch alignment (see «HOOD ADJUSTMENT»(/acura/tsx/i-2003-2008/remont/exterior-body-panels/#hood) ). Make sure the hood opens properly and locks securely.

Scheme 38

Scheme 38: Hood Release Handle Replacement
Scheme 38: Hood Release Handle Replacement
  1. Remove the kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ).
  2. Remove the bolts, then remove the hood release handle (A).
  3. Disconnect the hood opener cable (B) from the hood release handle. Take care not to kink the cable.
  4. Install the hood release handle in the reverse order of removal, and note there items: Make sure the hood opener cable is connected properly. Make sure the hood opens properly.

Trunk Lid Opener/Fuel Fill Door Opener Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 39

Scheme 39: Trunk Lid Opener/Fuel Fill Door Opener Replacement
Scheme 39: Trunk Lid Opener/Fuel Fill Door Opener Replacement

Scheme 40

Scheme 40
Scheme 40
  1. Using a trim tool, detach the hooks (A) by prying the front side cap (B), then remove it from the front door sill trim (C), and remove the opener lock cylinder (D).
  2. Remove the bolt.
  3. Remove the front door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ).
  4. Remove the screw, then remove the trunk lid opener/fuel fill door opener (A) from the front door sill trim (B).
  5. Install the opener in the reverse order of removal, and note these items: Make sure the opener cable is connected properly. Make sure the trunk lid and fuel fill door open properly and lock securely.

Trunk Lid Opener Switch Replacement

Note. Take care not to scratch the trunk lid. Put on gloves to protect your hands.

Scheme 41

Scheme 41: Trunk Lid Opener Switch Replacement
Scheme 41: Trunk Lid Opener Switch Replacement
  1. Remove these items: Trunk lid trim (see «TRIM REMOVAL/INSTALLATION - TRUNK LID»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-lid) ) Rear license trim (see «REAR LICENSE TRIM REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#exterior-trim) )
  2. Remove the bolts and disconnect the connector (A), then remove the trunk lid switch (B).
  3. Install the switch in the reverse order of removal, and note these items: Make sure the connector is plugged in properly. Make sure the trunk lid opens properly.

Scheme 42

Scheme 42: Trunk Lid Latch Replacement
Scheme 42: Trunk Lid Latch Replacement
  1. Disconnect the trunk lid opener cable (A) and trunk lid latch switch connector (B). Take care not to kink the opener cable. Fastener Locations
  2. Remove the bolts from the trunk lid latch (C), then remove the latch.
  3. Install the latch in the reverse order of removal, and note these items: Make sure the connector is plugged in properly and the opener cable is connected properly. Make sure the trunk lid opens properly and locks securely.
