SRS (supplemental Restraint System) Acura TSX I

Airbag 340 illustrations ~39927 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

Scheme 2

Scheme 2
Scheme 2

General Precautions

Please read the following precautions carefully before servicing the airbag system service. If the instructions described in this article are not properly followed the airbags could accidentally deploy and cause damage or injuries.

Scheme 3

Scheme 3: General Precautions
Scheme 3: General Precautions
  1. Except when doing electrical inspections, always turn the ignition switch OFF, disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work. NOTE: The SRS memory is not cleared even if the ignition switch is turned OFF or the battery cables are disconnected from the battery.
  2. Use replacement parts which are manufactured to the same standards and quality as the original parts. Do not install used SRS parts. Use only new parts when making SRS repairs.
  3. Carefully inspect any SRS part before you install it. Do not install any part that shows signs of being dropped or improperly handled, such as dents, cracks or deformation.
  4. Before removing any of the SRS parts (including the disconnection of the connectors), always disconnect the SRS connector.
  5. Use only a digital multimeter to check the system. If it is not a Honda multimeter, make sure its output is 10 mA (0.01 A) or less when switched to the lowest value in the ohmmeter range. A tester with a higher output could cause accidental deployment and possible injury.
  6. Do not put objects on the front passenger's airbag.
  7. The original audio and navigation system have a coded theft protection circuit. Make sure you have the anti-theft codes for the audio system and navigation system (if equipped), then write down the audio presets.
  8. Before returning the vehicle to the client, enter the anti-theft codes for the audio system and the navigation system (if equipped), then write down the audio presets. Set the clock (on vehicles without navigation).

Cable Reel Alignment

  1. Misalignment of the cable reel could cause an open in the wiring, make the SRS system remote steering wheel controls and the horn inoperative. Center the cable reel whenever the following is performed (see step 6 ). Installation of the steering wheel Installation of the cable reel Installation of the steering column Other steering-related adjustment or installation
  2. Do not disassemble the cable reel.
  3. Do not apply grease to the cable reel.
  4. If the cable reel shows any signs of damage, replace it with a new one. For example, if it does not rotate smoothly, replace the cable reel.

Airbag Handling and Storage

Do not disassemble an airbag. It has no serviceable parts. Once an airbag has been deployed, it cannot be repaired or reused.

For temporary storage of the airbag during service, please observe the following precautions.

Scheme 4

Scheme 4: Airbag Handling and Storage
Scheme 4: Airbag Handling and Storage

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Store the removed airbag with the deployment surface up. Never put anything on the removed airbag.
  2. To prevent damage to the airbag, keep it away from any oil, grease, detergent, or water.
  3. Store the removed airbag on a secure, flat surface away from any high heat source (exceeding 200°F/ 93°C).
  4. Never perform electrical inspections to the airbags, such as measuring resistance.
  5. Do not position yourself in front of the airbag assembly during removal, inspection, or replacement.
  6. For proper disposal of a damaged airbag, refer to «AIRBAG DISPOSAL»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__airbag-and-tensioner-disposal) .
  7. The side curtain airbag inflator assembly is a long, jointed part containing an inflator (A), a flexible bag (B), an adapter pipe (C), and a center bracket (D).
  8. When removing or installing the side curtain airbag inflator assembly, never handle the flexible bag (B) or the adapter pipe (C).

SRS Unit, Front and Side Impact Sensors, Driver's Seat Position Sensor, and Front Passenger's Weight Sensors ('06-08 Models)

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Turn the ignition switch OFF, disconnect the negative cable from the battery, and wait at least 3 minutes before beginning installation or replacement of the SRS unit or disconnecting the connectors from the SRS unit.
  2. Be careful not to bump or impact the SRS unit, front impact sensors, or side impact sensors when the ignition switch is ON (II), or for at least 3 minutes after the ignition switch is turned OFF.
  3. During installation or replacement, be careful not to bump (by impact wrench, hammer, etc.) the area around the SRS unit, front impact sensors, or side impact sensors. The airbags could accidentally deploy and cause damage or injury.
  4. After a collision where a front airbag, a side airbag, a side curtain airbag, or a seat belt tensioner deployed, go to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) . After a collision where the airbags or the side airbags did not deploy, inspect for any damage or any deformation on the SRS unit, front impact sensors, and side impact sensors. If there is any damage, replace the SRS unit and/or the sensors.
  5. Do not disassemble the SRS unit, front impact sensors, side impact sensors, driver's seat position sensor, and front passenger's weight sensors ('06-08 models).
  6. Be sure the SRS unit, front impact sensors, and side impact sensors are installed securely with the mounting bolts torqued to 9.8 N-m (1.0 kgf-m, 7.2 lbf.ft)
  7. Do not spill water or oil on the SRS unit or the side impact sensors, and keep them away from dust.
  8. Store the SRS unit, front impact sensors, and side impact sensors in a cool (less than 104 °F/40°C) and dry (less than 80 % relative humidity, no moisture) area.

Wiring Precautions

Some of the SRS wiring can be identified by special yellow outer covering, and the SRS connectors can be identified by their yellow color. Observe the instructions.

Scheme 11

Scheme 11: Wiring Precautions
Scheme 11: Wiring Precautions

Scheme 12

Scheme 12
Scheme 12
  1. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage in SRS wiring or terminals, replace the harness.
  2. Be sure to install the harness wires so they do not get pinched or interfere with other parts.
  3. Make sure all SRS ground locations are clean and securely fastened for optimum metal-to-metal contact. Poor grounds can cause intermittent problems that are difficult to diagnose.
  4. Do not use any silicone based cleaners or lubricants on any SRS connectors or terminals.

Scheme 13

Scheme 13: Precautions for Electrical Inspections
Scheme 13: Precautions for Electrical Inspections

Scheme 14

Scheme 14
Scheme 14
  1. When using electrical test equipment, insert the probe of the tester into the wire side of the connector. Do not insert the probe of the tester into the terminal side of the connector, and do not tamper with the connector.
  2. Use a U-shaped probe. Do not insert the probe forcibly.
  3. Use specified service connectors in troubleshooting. Using improper tools could cause an error in inspection due to poor metal-to-metal contact.

Spring-loaded Lock Connector

Some SRS system connectors have a spring-loaded lock.

Disconnecting

To release the lock, pull the spring-loaded sleeve (A) toward the stop (B) while holding the opposite half of the connector. Then pull the connector halves apart. Be sure to pull on the sleeve and not on the connector.

Scheme 15

Scheme 15: Disconnecting
Scheme 15: Disconnecting

Scheme 16

Scheme 16: Connecting
Scheme 16: Connecting

Scheme 17

Scheme 17
Scheme 17
  1. To reconnect, hold the pawl-side connector, and press on the back of the sleeve-side connector in the direction shown. As the two connector halves are pressed together, the sleeve (A) is pushed back by the pawl (B). Do not touch the sleeve.
  2. When the connector halves are completely connected, the pawl is released, and the spring-loaded sleeve locks the connector.

To release the lock, pull the spring-loaded sleeve (A) and the slider (B) while holding the opposite half of the connector. Then pull the connector halves apart. Be sure to pull on the sleeve and not on the connector half.

Scheme 18

Scheme 18: Disconnecting
Scheme 18: Disconnecting

Connecting

Hold both connector halves, and press them firmly together until the projection (A) of the sleeve-side connector clicks.

Scheme 19

Scheme 19: Connecting
Scheme 19: Connecting

Reopening the SRS Unit Circuit For Diagnosis

Special Tools Required

SRS short canceller 070AZ-SAA0100

Note. To prevent damaging the connector cavity, insert the SRS short canceller straight into the cavity from the terminal side. Before installing the short canceller, wash it with electrical contact cleaner, then dry it with compressed air. Do not use the special tool if it is damaged. Make sure to remove the special tool before reconnecting.

When SRS unit connectors A, B, or C are disconnected, a short circuit is created in the connector by its own function to prevent an airbag deployment. The circuit may need to be opened when diagnosis is done on the system. Insert the short canceller (No. 070AZ-SAA0100) in the specified cavities when it is necessary to keep the circuit open for diagnosis.

Scheme 20

Scheme 20: Reopening the SRS Unit Circuit For Diagnosis
Scheme 20: Reopening the SRS Unit Circuit For Diagnosis

Terminal numbers are shown from the wire side of the female terminals. Insert the short canceller(s) into the cavities on the terminal side of the connector.

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Backprobing Spring-loaded Lock Connectors

When checking voltage or resistance on this type of connector the first time, you must remove the retainer to insert the tester probe from the wire side.

Note. It is not necessary to reinstall the removed retainer; the terminals will stay locked in the connector housing.

To remove the retainer (A), insert a flat-tip screwdriver (B) between the connector body and the retainer, then carefully pry out the retainer. Take care not to break the connector.

Scheme 24

Scheme 24: Backprobing Spring-loaded Lock Connectors
Scheme 24: Backprobing Spring-loaded Lock Connectors

Seats with Side Airbags

Seats with side airbags have a "SIDE AIRBAG" label on the seat-back.

Scheme 25

Scheme 25: Seats with Side Airbags
Scheme 25: Seats with Side Airbags
  1. When cleaning, use a damp cloth to clean the seat. Do not soak the seat with liquid. Do not spray steam on the seat.
  2. Do not repair a torn or frayed seat-back cover. Replace the seat-back cover.
  3. After a collision where the side airbag was deployed, replace the side airbag with new parts. If the seat-back cushion is split, it must be replaced. If the seat-back frame is deformed, it must be replaced.
  4. Never put aftermarket accessories on the seat (covers, pads, seat heaters, lights, etc.).

Disconnecting System Connectors

Turn the ignition switch OFF and disconnect the negative cable from the battery, then wait for 3 minutes before starting work.

Scheme 26

Scheme 26: Disconnecting System Connectors
Scheme 26: Disconnecting System Connectors
  1. Before disconnecting the cable reel 4P connector (1), disconnect the driver's airbag 4P connector (2).
  2. Before disconnecting SRS unit connector B from the SRS unit, disconnect both seat belt tensioner 4P connectors (3, 4).

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work. Driver's Airbag
  2. Remove the access panel (A) from the steering wheel, then disconnect the driver's airbag 4P connector (B) from the cable reel. Front Passenger's Airbag
  3. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) ), then disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness. Side Airbag
  4. Disconnect both side airbag 2P connectors (A) from the floor wire harness. Driver's seat shown; passenger's seat is similar. Side Curtain Airbag
  5. Remove the C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) ), then disconnect both side curtain airbag harness 2P connectors (A) from the side curtain airbags. Seat Belt Tensioner
  6. Remove the B-pillar trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ). Disconnect both floor wire harness 4P connectors (A) from the seat belt tensioners. SRS Unit
  7. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ). Remove the rear vent ducts (see step 4 on «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ). Disconnect SRS unit connector A (28P), and/ or SRS unit connector B (28P), and/or SRS unit connector C (16P) from the SRS unit.

DTC (Diagnostic Trouble Codes)

The self-diagnostic function of the SRS system allows it to locate the causes of system problems and then store this information in memory. For easier troubleshooting, this data can be retrieved via a data link circuit.

  1. When you turn the ignition switch ON (II), the SRS indicator comes on. If it goes off after 6 seconds, the system is normal, and is not currently detecting any abnormality.
  2. If there is an abnormality, the system locates and defines the problem, stores this information in memory, and turns the SRS indicator on. The data remains in the memory even when the ignition switch is turned off or if the battery is disconnected.
  3. The data is stored in memory as a diagnostic trouble code (DTC).
  4. The "x" at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that is display on the HDS.
  5. DTCs are either latching or resetting depending on the malfunction. With resetting DTCs, the SRS indicator goes off the next time the ignition switch is turned ON and the system is normal, but the DTC is still stored. With latching DTCs the SRS indicator does not turn OFF until the malfunction is repaired and the DTC is cleared.
  6. When you connect the HDS to the data link connector (DLC), you can retrieve a more detailed DTC in the Honda Systems "SRS" menu.
  7. After reading and recording the DTC, proceed with the troubleshooting procedure for that code.

Precautions

  1. Use only a digital multimeter to check the system. If it's not a Honda multimeter, make sure its output is 10 mA (0.01 A) or less when switched to the smallest value in the ohmmeter range. A tester with a higher output could damage the airbag circuit or cause accidental airbag deployment and possible injury.
  2. Whenever the ignition switch is ON (II), or has been turned OFF for less than 3 minutes, be careful not to bump the SRS unit; the airbags could accidentally deploy and cause damage or injuries.
  3. Before you remove the dashboard wire harness, floor wire harness, or the side curtain wire harness, disconnect the driver's airbag connector, the front passenger's airbag connector, both side airbag connectors, both side curtain airbag connectors, and both seat belt tensioner connectors.
  4. Make sure the battery is fully charged. If the battery is dead or low, measuring values won't be correct.
  5. Do not touch a tester probe to the terminals in the SRS unit or harness connectors, and do not connect the SRS unit terminals or the sensor terminals with a jumper wire. Use only the backprobe set and the HDS. Backprobe spring-loaded lock type connectors correctly.

Scheme 33

Scheme 33: Reading the DTC
Scheme 33: Reading the DTC
  1. Make sure the ignition switch is OFF.
  2. Connect the HDS to the data link connector (DLC) (A).
  3. Turn the ignition switch ON (II).
  4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  5. Use the HDS to check for DTCs.
  6. Read and record the DTC.
  7. Turn the ignition switch OFF, then wait for 10 seconds.
  8. Disconnect the HDS from the DLC.
  9. Do the troubleshooting procedure for the DTC.

Clear the DTC Memory With the HDS

Note. Make sure the battery is fully charged before you begin.

Scheme 34

Scheme 34: Clear the DTC Memory With the HDS
Scheme 34: Clear the DTC Memory With the HDS
  1. Make sure the ignition switch is OFF.
  2. Connect the HDS to the data link connector (DLC) (A).
  3. Turn the ignition switch ON (II).
  4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  5. In the SRS MENU of the HDS, select SRS, then DTC to clear DTC(s).
  6. Turn the ignition switch OFF, and wait for 10 seconds.
  7. Disconnect the HDS from the DLC.

Clear the DTC Memory Using MES Connector Without the HDS

Special Tools Required

SCS service connector 07PAZ-001010A

Note. Make sure the battery is fully charged before you begin.

To clear the DTC(s) from the SRS unit, use the HDS, or the following procedure.

Scheme 35

Scheme 35: Clear the DTC Memory Using MES Connector Without the HDS
Scheme 35: Clear the DTC Memory Using MES Connector Without the HDS
  1. Make sure the ignition switch is OFF.
  2. Connect the SCS service connector (A) to the yellow MES 2P connector (B). Do not use a jumper wire.
  3. Turn the ignition switch ON (II).
  4. The SRS indicator comes on for about 6 seconds, and then goes off. Remove the SCS service connector from the MES connector (2P) within 4 seconds after the indicator goes off.
  5. The SRS indicator comes on again. Reconnect the SCS service connector to the MES connector (2P) within 4 seconds after the indicator comes on.
  6. When the SRS indicator goes off, remove the SCS service connector from the MES connector (2P) within 4 seconds.
  7. The SRS indicator blinks two times indicating that the memory has been cleared.
  8. Turn the ignition switch OFF, then wait for 10 seconds.
  9. Turn the ignition switch ON (II) again. If the SRS indicator comes on for 6 seconds, and then goes off, the system is OK.

Troubleshooting Intermittent Failures

If there was a malfunction, but it does not recur, it will be stored in the memory as an intermittent failure, and the SRS indicator may come on depending on this malfunction detected.

Note. Check the condition of the battery (see BATTERY TEST ) and the charging system (see ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING ). Low battery voltage may cause some intermittent failures.

After checking the DTC, troubleshoot as follows

  1. Make sure the ignition switch is OFF.
  2. Connect the HDS to the data link connector (DLC) (A).
  3. Turn the ignition switch ON (II).
  4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  5. In the SRS MENU on the HDS, select SRS, then DTC to clear DTCs.
  6. Read the DTC (see " «READING THE DTC»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ").
  7. Clear the DTC memory (see " «CLEAR THE DTC MEMORY»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ").
  8. Set the parking brake, then start the engine, and let it idle.
  9. The SRS indicator comes on for about 6 seconds and then goes off.
  10. Shake the related wire harnesses and the connectors, and look for loose connections, poor pinfits, and poor grounds.
  11. Take a test-drive (quick acceleration, quick braking, and cornering), turn the steering wheel fully left and right, and hold it there for 5 to 10 seconds. If the problem recurs, the SRS indicator will come on. NOTE: A faulty cable reel can cause intermittent connections related to the driver's airbag inflator DTCs.
  12. If you can not duplicate the concern, ask the customer about the conditions when it occurred, or ask the customer to demonstrate the concern.
  13. If you cannot duplicate the intermittent failure, the system is OK at this time.

Scheme 36

Scheme 36: Checking Front Passenger's Weight Sensors After a Vehicle Collision ('06-08 Models)
Scheme 36: Checking Front Passenger's Weight Sensors After a Vehicle Collision ('06-08 Models)
  1. Position the front passenger's seat to the rear most position, adjust the recliner to the forward most position. Do not move it from this position.
  2. Drive the vehicle, accelerate to 20 mph (36 km/h), then stop on level ground.
  3. Make sure the ignition switch is OFF.
  4. Connect the HDS to the data link connector (DLC) (A).
  5. Turn the ignition switch ON (II).
  6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  7. From the SRS inspection menu, select Seat Weight Sensor, then Misc test, then "SEAT OUTPUT CHK" and follow the prompts until the front passenger's weight sensor operation check is complete.

OPDS/ODS Unit Initialization

When a seat-back cover, seat-back cushion, and/or OPDS/ODS unit is replaced, initialize the OPDS/ODS by doing this procedure.

Note. A new (uninitialized) OPDS/ODS unit installed with a faulty OPDS sensor can cause DTC 85-71.

Scheme 37

Scheme 37: OPDS/ODS Unit Initialization
Scheme 37: OPDS/ODS Unit Initialization
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Make sure the front passenger's seat is dry. Set the seat-back in a normal position, and make sure there is nothing on the seat.
  3. Make sure the ignition switch is OFF and the MES connector is not shorted.
  4. Connect the HDS to the data link connector (DLC) (A).
  5. Turn the ignition switch ON (II).
  6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  7. From the HDS Main Menu, select SRS, then SRS, then Calibration. In the Calibration Menu, select ODS INIT. Follow the screen prompts to initialize the OPDS/ODS unit.
  8. Turn the ignition switch OFF.
  9. Disconnect the HDS from the DLC. NOTE: If the OPDS/ODS fails to initialize after several attempts, replace the OPDS sensor/seat-back and retry. If the OPDS/ODS continues to fail to initialize, replace the OPDS/ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ).

'06-08 models

When you replace the SRS unit, front passenger's weight sensors or ODS unit, calibrate the ODS unit.

While calibrating the ODS unit, observe these precautions

  1. Make sure all components of the front passenger's seat are correctly installed.
  2. Make sure nothing is on or under the front passenger's seat.
  3. Make sure there is nothing in the front passenger's seat-back pocket.
  4. Keep the windows closed.
  5. Do all calibration procedures except, test driving, in the service bay.
  6. Make sure the vehicle is on level ground.
  7. Keep the A/C and the heater off.
  8. Do not touch the front passenger's seat until you are prompted to or when you have completed the calibration.
  9. Do not expose the front passenger's seat to sudden temperature changes.

Scheme 38

Scheme 38
Scheme 38
  1. Position the front passenger's seat to the rearmost position, and adjust the recliner to the forward most position. Do not move the seat from this position.
  2. Make sure the ignition switch is OFF.
  3. Connect the HDS to the data link connector (DLC) (A).
  4. Turn the ignition switch ON (II).
  5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  6. Drive the vehicle, and accelerate to 20 mph (36 km/h), then stop on level ground.
  7. From the Main Menu, select SRS, then Calibration, then Misc Test, then select "SWS INITIALIZATION," and follow the prompts until the calibration has been completed.

Check the ODS operation after any of these actions.

  1. Replacement of front passenger's seat component(s) (except ODS unit and/or front passenger's weight sensors)
  2. After a vehicle collision
  3. SRS unit replacement

Pre-operation Check Set-up

  1. Make sure all the components of the front passenger's seat are correctly installed.
  2. Position the front passenger's seat to the rearmost position.
  3. Adjust the seat recline to the forward most position.
  4. Do not move the seat from this position.
  5. Make sure nothing is on or under the front passenger's seat.
  6. Make sure there is nothing in the front passenger's seat-back pocket.
  7. Keep the windows closed.
  8. Do all calibration procedures, except test-driving, in the service bay.
  9. Make sure the vehicle is on level ground.
  10. Keep the A/C and heater off.
  11. Do not touch the passenger's seat during the operation check.
  12. Do not expose the front passenger's seat to sudden temperature changes.
  13. Make sure all aftermarket devices such as amplifiers, fluorescent lights, air purifiers, CB or HAM radios, etc. are turned off.

Scheme 39

Scheme 39: After Replacing Front Passenger's Seat Component(s)
Scheme 39: After Replacing Front Passenger's Seat Component(s)
  1. Make sure the ignition switch is OFF.
  2. Connect the HDS to the data link connector (DLC) (A).
  3. Turn the ignition switch ON (II).
  4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  5. Drive the vehicle, accelerate to 20 mph (36 km/h), then stop on level ground.
  6. From the HDS Main Menu, select SRS, then Inspection. In the HDS Inspection Menu, select "SEAT OUTPUT CHK" and follow the prompts until the ODS unit operation check has been completed.

Check the driver's seat position after any of these actions.

  1. Driver's seat position sensor replacement
  2. Cover plate (front side of driver's seat slide rail) replacement

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Make sure the driver's seat is at its full forward position.
  2. Make sure the ignition switch is OFF (0).
  3. Connect the HDS to the data link connector (DLC) (A).
  4. Turn the ignition switch ON (II).
  5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, troubleshoot the DLC circuit: '04-06 models (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ) '07-08 models (see «'07-08 MODELS»(/acura/tsx/i-2003-2008/remont/testing-diagnostics/#pgm-fi-system) )
  6. From the HDS Main Menu, select SRS, then Parameter Information, then Buckle Switch, Seat Position Sensor.
  7. Using a piece of tape (A), mark the location on the seat's outer cover (B) where the front riser cover meets the seat riser (C). The driver's seat position sensor should read "NEAR."
  8. Move the seat back in small increments (about 0.2 in., 5 mm) until the driver's seat position sensor reads "NOT NEAR." The seat should be about 1 in. (25 mm) from the front. NOTE: It takes a few seconds for the HDS to display changes, so wait about 5 seconds between each move. If the driver's seat position sensor data does not work as described above, check the driver's seat position sensor or the cover plate for damage, and replace parts as needed.
  9. Turn the ignition switch OFF, and disconnect the HDS from the DLC.

DTC Troubleshooting Index

'04-05 models

DTCLatch (1)Reset (2)Detection Item
11-1XOOpen in driver's airbag first inflator
11-3XShort to another wire or decreased resistance in driver's airbag first inflator
11-4XOpen in driver's airbag second inflator
11-6XShort to another wire or decreased resistance in driver's airbag second inflator
11-8XOShort to power in driver's airbag first inflator
11-9XShort to ground in driver's airbag first inflator
11-AXShort to power in driver's airbag second inflator
11-BXShort to ground in driver's airbag second inflator
12-1XOOpen in front passenger's airbag first inflator
12-3XShort to another wire or decreased resistance in front passenger's airbag first inflator
12-4XOpen in front passenger's airbag second inflator
12-6XShort to another wire or decreased resistance in front passenger's airbag second inflator
12-8XOShort to power in front passenger's airbag first inflator
12-9XShort to ground in front passenger's airbag first inflator
12-AXShort to power in front passenger's airbag second inflator
12-BXShort to ground in front passenger's airbag second inflator
21-1XOOpen in driver's seat belt tensioner
21-3XShort to another wire or decreased resistance in driver's seat belt tensioner
21-8XOShort to power in driver's seat belt tensioner
21-9XShort to ground in driver's seat belt tensioner
22-1XOOpen in front passenger's seat belt tensioner
22-3XShort to another wire or decreased resistance in front passenger's seat belt tensioner
22-8XOShort to power in front passenger's seat belt tensioner
22-9XShort to ground in front passenger's seat belt tensioner
31-1XOOpen in driver's side airbag inflator
31-3XShort to another wire or decreased resistance in driver's side airbag inflator
31-8XOShort to power in driver's side airbag inflator
31-9XShort to ground in driver's side airbag inflator
32-1XOOpen in front passenger's side airbag inflator
32-3XShort to another wire or decreased resistance in front passenger's side airbag inflator
32-8XOShort to power in front passenger's side airbag inflator
32-9XShort to ground in front passenger's side airbag inflator
33-1XOOpen in left side curtain airbag first inflator
33-3XShort to another wire or decreased resistance in left side curtain airbag first inflator
33-8XOShort to power in left side curtain airbag first inflator
33-9XShort to ground in left side curtain airbag first inflator
34-1XOOpen in right side curtain airbag first inflator
34-3XShort to another wire or decreased resistance in right side curtain airbag first inflator
34-8XOShort to power in right side curtain airbag first inflator
34-9XShort to ground in right side curtain airbag first inflator
NOTE: The "x" at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that you will see on the HDS display. The character is unrelated to your troubleshooting; it designates the SRS unit manufacturer and other details used for product analysis.
(1) The SRS indicator turns on and stays on whenever the ignition switch is in the ON (II) position, or until the DTC is cleared. (2) The SRS indicator turns on when the DTC is set. The SRS indicator will not turn on after the ignition switch is cycled from ON (II) to OFF (0), but the DTC is stored in the SRS unit.
NOTE
The "x" at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that you will see on the HDS display. The character is unrelated to your troubleshooting; it designates the SRS unit manufacturer and other details used for product analysis.
(1)The SRS indicator turns on and stays on whenever the ignition switch is in the ON (II) position, or until the DTC is cleared.
(2)The SRS indicator turns on when the DTC is set. The SRS indicator will not turn on after the ignition switch is cycled from ON (II) to OFF (0), but the DTC is stored in the SRS unit.

DTC TROUBLESHOOTING CHART

'04-05 models

DTCLatch *1Reset *2Detection Item
41-1XONo signal from the left front impact sensor
41-2XInternal failure of the left front impact sensor
41-3x
41-BxO
42-1XONo signal from the right front impact sensor
42-2XInternal failure of the right front impact sensor
42-3x
42-BxO
43-1XONo signal from the left side impact sensor (first)
43-2XInternal failure of the left side impact sensor (first)
43-3x
43-BxO
44-1XONo signal from the right side impact sensor (first)
44-2XInternal failure of the right side impact sensor (first)
44-3x
44-BxO
45-1XONo signal from the left side impact sensor (second)
45-2XInternal failure of the left side impact sensor (second)
45-3x
45-BxO
46-1XONo signal from the right side impact sensor (second)
46-2XOOInternal failure of the right side impact sensor (second)
46-3x
46-BxO
51-XXOInternal failure of the SRS unit
52-xxO
53-xxO
54-xx
55-xx
61-1XOOpen in driver's seat belt buckle switch
61-2XShort in driver's seat belt buckle switch
62-1XOpen in front passenger's seat belt buckle switch
62-2XShort in front passenger's seat belt buckle switch
85-4XInternal failure of the OPDS unit
85-5x
85-61No signal from the OPDS unit
85-62Response data error from the OPDS unit
85-63Internal failure of the OPDS unit
85-64
85-71OPDS unit not initialized
85-78
85-79OPDS sensor initial check failure
86-1XFaulty OPDS sensor
86-2X
87-3XSide airbag cutoff indicator stays on/off
91-1XShort to ground in SRS indicator circuit
A1-1XOFaulty power supply (VA line)
A2-1XFaulty power supply (VB line)
EX-XXOControl operation recorded
FX-XXAirbags and/or tensioners deployment recorded

DTC TROUBLESHOOTING CHART (CONT.)

'06-08 models

DTCLatch *1Reset *2Detection Item
11-1XOOpen in driver's airbag first inflator
11-3XShort to another wire or decreased resistance in driver's airbag first inflator
11-4XOpen in driver's airbag second inflator
11-6XShort to another wire or decreased resistance in driver's airbag second inflator
11-8XOShort to power in driver's airbag first inflator
11-9XShort to ground in driver's airbag first inflator
11-AXShort to power in driver's airbag second inflator
11-BXShort to ground in driver's airbag second inflator
12-1XOOpen in front passenger's airbag first inflator
12-3XShort to another wire or decreased resistance in front passenger's airbag first inflator
12-4XOpen in front passenger's airbag second inflator
12-6XShort to another wire or decreased resistance in front passenger's airbag second inflator
12-8XOShort to power in front passenger's airbag first inflator
12-9XShort to ground in front passenger's airbag first inflator
12-AXShort to power in front passenger's airbag second inflator
12-BXShort to ground in front passenger's airbag second inflator
21-1XOOpen in driver's seat belt tensioner
21-3XShort to another wire or decreased resistance in driver's seat belt tensioner
21-8XOShort to power in driver's seat belt tensioner
21-9XShort to ground in driver's seat belt tensioner
22-1XOOpen in front passenger's seat belt tensioner
22-3XShort to another wire or decreased resistance in front passenger's seat belt tensioner
22-8XOShort to power in front passenger's seat belt tensioner
22-9XShort to ground in front passenger's seat belt tensioner
31-1XOOpen in driver's side airbag inflator
31-3XShort to another wire or decreased resistance in driver's side airbag inflator
31-8XOShort to power in driver's side airbag inflator
31-9XShort to ground in driver's side airbag inflator
32-1XOOpen in front passenger's side airbag inflator
32-3XShort to another wire or decreased resistance in front passenger's side airbag inflator
32-8XOShort to power in front passenger's side airbag inflator
32-9XShort to ground in front passenger's side airbag inflator
33-1XOOpen in left side curtain airbag first inflator
33-3XShort to another wire or decreased resistance in left side curtain airbag first inflator
33-8XOShort to power in left side curtain airbag first inflator
33-9XShort to ground in left side curtain airbag first inflator
34-1XOOpen in right side curtain airbag first inflator
34-3XShort to another wire or decreased resistance in right side curtain airbag first inflator
34-8XOShort to power in right side curtain airbag first inflator
34-9XShort to ground in right side curtain airbag first inflator

DTC TROUBLESHOOTING CHART

'06-08 models

DTCLatch (1)Reset (2)Detection Item
41-1XONo signal from the left front impact sensor
41-2XInternal failure of the left front impact sensor
41-3x
41-BxO
42-1XONo signal from the right front impact sensor
42-2XInternal failure of the right front impact sensor
42-3x
42-BxO
43-1XONo signal from the left side impact sensor (first)
43-2XInternal failure of the left side impact sensor (first)
43-3x
43-BxO
44-1XONo signal from the right side impact sensor (first)
44-2XInternal failure of the right side impact sensor (first)
44-3x
44-BxO
45-1XONo signal from left side impact sensor (second)
45-2XInternal failure of the left side impact sensor (second)
45-3x
45-BxO
46-1XONo signal from the right side impact sensor (second)
46-2XInternal failure of the right side impact sensor (second)
46-3x
46-BxO
51-XXOInternal failure of the SRS unit
52-xxO
53-xxO
54-xx
55-xx
NOTE: The "x" at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that you will see on the HDS display. The character is unrelated to your troubleshooting; it designates the SRS unit manufacturer and other details used for product analysis.
(1) The SRS indicator turns on and stays on whenever the ignition switch is in the ON (II) position, or until the DTC is cleared. (2) The SRS indicator turn son when the DTC is set. The SRS indicator will not turn on after the ignition switch is cycled from ON (II) to OFF (0), but the DTC is stored in the SRS unit.
NOTE
The "x" at the end of each DTC denotes a numeric character (0 thru 9) or an alpha character (A thru F) that you will see on the HDS display. The character is unrelated to your troubleshooting; it designates the SRS unit manufacturer and other details used for product analysis.
(1)The SRS indicator turns on and stays on whenever the ignition switch is in the ON (II) position, or until the DTC is cleared.
(2)The SRS indicator turn son when the DTC is set. The SRS indicator will not turn on after the ignition switch is cycled from ON (II) to OFF (0), but the DTC is stored in the SRS unit.

DTC TROUBLESHOOTING CHART (CONT.)

'06-08 models

DTCLatch *1Reset *2Detection Item
61-1XOOpen in driver's seat belt buckle switch
61-2XShort in driver's seat belt buckle switch
62-1XOpen in front passenger's seat belt buckle switch
62-2XShort in front passenger's seat belt buckle switch
71-1XOpen in driver's seat position sensor
71-2XShort in driver's seat position sensor
81-4XInternal failure of the ODS unit
81-5x
81-61No signal from the ODS unit
81-62Response data error from the ODS unit
81-63Internal failure of the ODS unit
81-64
81-71ODS unit does not calibrate
81-78
81-79Front passenger's weight sensors initial check failure
82-1XNo signal from the inner side front passenger's weight sensor
83-2XNo signal from the outer side front passenger's weight sensor
85-4XInternal failure of the ODS unit
85-5x
85-61No signal from the ODS unit
85-62Response data error form the ODS unit
85-63Internal failure of the ODS unit
85-64
85-71ODS unit not initialized
85-78
85-79ODS sensor initial check failure
86-1XFaulty OPDS sensor
86-2X
87-3XSide airbag cutoff indicator stays on/off
91-1XShort to ground in the SRS indicator circuit
92-1XOpen in the passenger's airbag cutoff indicator
92-2XOpen or short to ground in the passenger's airbag cutoff indicator
A1-1XOFaulty power supply (VA line)
A2-1XFaulty power supply (VB line)
EX-XXOControl operation recorded
Fx-xxAirbags and/or tensioners deployment recorded

DTC TROUBLESHOOTING CHART (CONT.)

Symptom Troubleshooting Index

SymptomDiagnostic procedureAlso check for
SRS indicator does not come onSRS Indicator Troubleshooting (see SRS INDICATOR DOES NOT COME ON )
SRS indicator stays on, but no DTCs are storedSRS Indicator Troubleshooting (see SRS INDICATOR STAYS ON, BUT NO DTCS ARE STORED )Charging system for under or overcharging
Side airbag cutoff indicator stays on after bulb check, and no DTCs are stored, or side airbag cutoff indicator is flashingMake sure nothing is on the front passenger's seat. If the side airbag cutoff indicator stays on after the ignition switch is turned ON (II), initialize the OPDS/ODS unit (see OPDS/ODS UNIT INITIALIZATION ). If the side airbag cutoff indicator operates normally, the system is OK.DTC 87-32 troubleshooting (see DTC 87-3X ("X" CAN BE 0 THRU 9 OR A THRU F): SIDE AIRBAG CUTOFF INDICATOR STAYS ON/OFF )
Side airbag cutoff indicator is flashingMake sure nothing is on the front passenger's seat. If the side airbag cutoff indicator stays on after the ignition switch is turned ON (II), initialize the OPDS/ODS unit (see OPDS/ODS UNIT INITIALIZATION ). If the side airbag cutoff indicator operates normally, the system is OK.DTC 87-32 troubleshooting (see DTC 87-3X ("X" CAN BE 0 THRU 9 OR A THRU F): SIDE AIRBAG CUTOFF INDICATOR STAYS ON/OFF )
HDS does not communicate with the SRS unit or the vehicleTroubleshoot the DLC circuit: '04-06 models (see DLC CIRCUIT TROUBLESHOOTING ) '07-08 models (see '07-08 MODELS )Communication with HDS

SYMPTOM TROUBLESHOOTING CHART

Airbags

The SRS is a safety device which, when used with the seat belt, is designed to help protect the driver and front passenger in a frontal impact exceeding a certain set limit. The system consists of the SRS unit, including safing sensor and impact sensor (A), the cable reel (B), the driver's airbag (C), the front passenger's airbag (D), side airbags (E), side curtain airbags (F), seat belt tensioners (G), front impact sensors (H), side impact sensors (first) (I) and side impact sensors (second) (J).

Since the driver's and front passenger's airbags use the same sensors, both normally inflate at the same time. However, it is possible for only one airbag to inflate. This can occur when the severity of a collision is at the margin, or threshold, that the SRS unit determines whether or not the airbags will deploy. In such cases, the seat belt will provide sufficient protection, and the supplemental protection offered by the airbag would be minimal.

Front Passenger's Weight Sensors ('06-08 models)

The front passenger's weight sensors (K) are part of the seat base. The weight sensors detect the weight on the seat, and send the information to the ODS unit. If the total weight is about 65 lbs (30 kg) or less, the ODS unit sends a signal to the SRS unit to prevent the passenger's airbag from deploying. When the passenger's airbag is disabled, the passenger airbag cutoff indicator on the center panel comes on to alert the driver that the front passenger's airbag will not deploy in a front-end collision.

Driver's Seat Position Sensor ('06-08 models)

The driver's seat position sensor (L) is under the driver's seat on the left side. When the driver's seat is moved to its full forward position, the deployment of the driver's airbag is moderated to decrease its force of impact during a front-end collision.

OPDS/ODS

The side airbag system also includes an occupant position detection system (OPDS). This system consists of sensors (M) and a OPDS/ODS unit (N) in the front passenger's seat-back. The OPDS/ODS unit sends occupant height and position data to the SRS unit. If the OPDS/ODS unit determines that the front passenger is of small stature (for example, a child) or the front passenger is leaning into the side airbag deployment path, the SRS unit will automatically disable the passenger's side airbag. The SRS unit will also disable the airbag when the OPDS detects certain objects on the seat. When the side airbag is disabled, the side airbag cutoff indicator on the instrument panel alerts the driver that the passenger's side airbag will not deploy in a side impact. When the object is removed, or the passenger sits upright, the side airbag cutoff indicator will go off after a few seconds, alerting the driver that the passenger's side airbag will deploy in a side impact.

'04-05 models

Scheme 42

Scheme 42: OPDS/ODS
Scheme 42: OPDS/ODS

'06-08 models

Scheme 43

Scheme 43
Scheme 43

Side Airbag Cutoff Indicator/OPDS/ODS Operation

The indicator comes on if the front passenger's seat is occupied by a small adult or child who is leaning into the deployment path, or an object (grocery bag, briefcase, purse, etc.) is in the seat. This indicates the passenger's side airbag is off and will not deploy; there is no problem with the side airbag. If the passenger sits upright or moves to another seat, or you remove the object from the seat, the light should go off. There will be some delay between the occupant's repositioning and when the indicator will turn on or off.

Passenger Airbag Cutoff Indicator ('06-08 models)

The indicator comes on if the weight of the front passenger is about 65 lbs (30 kg) or less. This indicates the passenger's front airbag is off and will not deploy. The front airbag is shut off to reduce the chance of airbag-caused injuries.

SRS Operation

The main circuit in the SRS unit senses and judges the force of impact and, if necessary, ignites the inflator charges. If battery voltage is too low or power is disconnected due to the impact, the voltage regulator and the back-up power circuit, respectively, will keep voltage at a constant level.

For the SRS to operate

Seat Belt Tensioners

  1. A front impact sensor must activate and send electric signals to the microprocessor.
  2. The microprocessor must compute the signals and send them to the tensioners.
  3. The charges must ignite and deploy the tensioners.

Driver's and Front Passenger's Airbag(s)

  1. A front impact sensor must activate and send electric signals to the microprocessor.
  2. The microprocessor must compute the signals and send them to the airbag inflator(s).
  3. The inflators that receives signals must ignite and deploy the airbags.

Side Airbag(s)

  1. Aside impact sensor must activate and send electric signals to the microprocessor.
  2. The microprocessor must compute the signals and send them to the side airbag inflator(s). However, the microprocessor cuts off the signals to the front passenger's side airbag if the SRS unit determines that the front passenger's head is in the deployment path of the side airbag.
  3. The inflator that receives the signal must ignite and deploy the side airbag.

Side Curtain Airbag(s)

  1. Side impact sensors must activate and send electrical signals to the microprocessor.
  2. The microprocessor must compute the signals and send them to the side curtain airbag and side airbag inflator(s).
  3. The inflator that receives the signals must ignite and deploy the side curtain airbag and side airbag at the same time.

Scheme 44

Scheme 44
Scheme 44

Self-diagnostic System

A self-diagnostic circuit is built into the SRS unit; when the ignition switch is turned ON (II), the SRS indicator comes on and goes off after about 6 seconds if the system is operating normally. If the indicator does not come on, or does not go off after 6 seconds, or if it comes on while driving, it indicates an abnormality in the system. The system must be inspected and repaired as soon as possible.

For better serviceability, the SRS unit memory stores a DTC that relates to the cause of the malfunction, and the unit is connected to the data link connector (DLC). This information can be read with the HDS when it is connected to the DLC (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Note. Before you disconnect the negative cable from the battery for troubleshooting, make sure you have the anti-theft code for the audio system and the navigation system (if equipped).

SRS Unit Inputs and Outputs at Connector A (28P)

'06-08 models

Scheme 45

Scheme 45: SRS Unit Inputs and Outputs at Connector A (28P)
Scheme 45: SRS Unit Inputs and Outputs at Connector A (28P)
Terminal NumberWire ColorTerminal NameDescription
1GRN/YELLA2+Power source for driver's airbag second inflator
2GRN/WHTLA2Ground for driver's airbag second inflator
3BLU/BLKRA2+Power source for front passenger's airbag second inflator
4BLU/REDRA2Ground for front passenger's airbag second inflator
7GRN/BLKLA1 +Power source for driver's airbag first inflator
8GRN/REDLA1Ground for driver's airbag first inflator
9YELRA1+Power source for front passenger's airbag first inflator
10BLU/YELRA1Ground for front passenger's airbag first inflator
15BRN/YELLFSGround for left front impact sensor
16BRNRFSGround for right front impact sensor
17WHTVASRS system sub power (common with OPDS/ODS)
18WHT/REDVBSRS dedicated power (dedicated booster circuit)
19PNKIDCSRS warning indicator output line
20BLU/REDPTTPassenger's airbag cutoff indicator output line
21YELCDSFront passenger's occupant detection signal output line
22BLKSRS GND (1)Ground circuit for the SRS
23BLKSRS GND (2)Ground circuit for the SRS
24BLUK-LINESends and receives scan tool signal
25LT GRN/ BLKMESMemory erase signal input
26BRNSCSService check signal input
27REDLFS+Power source for left front impact sensor
28GRNRFS+Power source for right front impact sensor

SRS UNIT CONNECTOR TERMINALS REFERENCE

SRS Unit Inputs and Outputs at Connector B (28P)

'06-08 models

Scheme 46

Scheme 46: SRS Unit Inputs and Outputs at Connector B (28P)
Scheme 46: SRS Unit Inputs and Outputs at Connector B (28P)
Terminal NumberWire ColorTerminal NameDescription
1RED/BLULRP+Power source for driver's seat belt tensioner
2RED/WHTLRPGround for driver's seat belt tensioner
3RED/BLKRRP+Power source for front passenger's seat belt tensioner
4RED/YELRRPGround for front passenger's seat belt tensioner
11BLU/REDLBSCDriver's seat belt buckle switch un-buckled signal
12BLURBSCFront passenger's seat belt buckle switch un-buckled signal
16GRN/WHTSS+Power source for driver's seat position sensor
17LT GRNLBSODriver's seat belt buckle switch buckled signal
18ORNRBSOFront passenger's seat belt buckle switch buckled signal
19PNK/BLULBSI+Power source for left side impact sensor (first)
20GRY/REDLBSIGround for left side impact sensor (first)
21WHT/GRNLSA+Power source for driver's side airbag inflator
22WHT/REDLSAGround for driver's side airbag inflator
23WHT/BLKRSA+Power source for front passenger's side airbag inflator
24WHT/BLURSAGround for front passenger's side airbag inflator
25BRN/YELRBSI+Power source for right side impact sensor (first)
26LT GRN/ REDRBSIGround for right side impact sensor (first)
27GRN/ORNOPDS/ODSSends and receives communication signal
28GRN/REDSSGround for driver's seat position sensor

SRS UNIT CONNECTOR TERMINALS REFERENCE

SRS Unit Inputs and Outputs at Connector C (16P)

'06-08 models

Scheme 47

Scheme 47: SRS Unit Inputs and Outputs at Connector C (16P)
Scheme 47: SRS Unit Inputs and Outputs at Connector C (16P)
Terminal NumberWire ColorTerminal NameDescription
9GRN/BLKLCSI+Power source for left side impact sensor (second)
10ORNLCSIGround for left side impact sensor (second)
11BLU/BLKLCA+Power source for left side curtain airbag inflator
12BLULCAGround for left side curtain airbag inflator
13RED/YELRCA+Power source for right side curtain airbag inflator
14REDRCAGround for right side curtain airbag inflator
15YEL/BLKRCSI+Power source for right side impact sensor (second)
16YELRCSIGround for right side impact sensor (second)

SRS UNIT CONNECTOR TERMINALS REFERENCE

Circuit Diagram

'04-05 models

Scheme 48

Scheme 48: Circuit Diagram
Scheme 48: Circuit Diagram

Scheme 49

Scheme 49
Scheme 49

'06-08 models

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

DTC 11-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Airbag First Inflator; DTC 11-4x ("x" can be 0 thru 9 or A thru F): Open in Driver's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-1x or 11-4x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the cable reel.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-1x or 11-4x indicated? YES -Go to step 9. NO -Open in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
  11. Connect the SRS inflator simulator (2 ohms connectors) and the simulator lead to the dashboard wire harness.
  12. Reconnect the negative cable to the battery.
  13. Clear the DTC memory.
  14. Read the DTC. Is DTC 11-1x or 11-4x indicated? YES -Go to step 15. NO -Open in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  15. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  17. Disconnect the SRS inflator simulator from SRS simulator lead F. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  18. Measure the resistance between the terminals of both SRS simulator leads. There should be 1 ohms or less. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the dashboard wire harness; replace the dashboard wire harness.

DTC 11-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Airbag First Inflator; DTC 11-6x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100
  3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-3x or 11-6x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the cable reel.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-3x or 11-6x indicated? YES -Go to step 9. NO -Short in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
  11. Connect the SRS inflator simulator (2 ohms connectors) and the simulator lead to the dashboard wire harness.
  12. Reconnect the negative cable to the battery.
  13. Clear the DTC memory.
  14. Read the DTC. Is DTC 11-3x or 11-6x indicated? YES -Go to step 15. NO -Short in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  15. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  18. Connect SRS short cancellers (070AZ-SAA0100) to the No. 7 and No. 8 terminals and No. 1 and No. 2 terminals of the SRS unit connector A (28P) (see «REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__reopening-the-srs-unit-circuit-for) ).
  19. Measure the resistance between the terminals of both SRS simulator leads. There should be an open circuit (ohmmeter reads OL) or at least 1 M ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the dashboard wire harness; replace the dashboard wire harness.

DTC 11-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Airbag First Inflator; DTC 11-Ax ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-8x or 11-Ax indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the cable reel.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-8x or 11-Ax indicated? YES -Go to step 9. NO -Short to power in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
  11. Connect the SRS inflator simulator (2 ohms connectors) and the simulator lead to the dashboard wire harness.
  12. Reconnect the negative cable to the battery.
  13. Clear the DTC memory.
  14. Read the DTC. Is DTC 11-8x or 11-Ax indicated? YES -Go to step 15. NO -Short to power in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  15. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  18. Reconnect the negative cable to the battery.
  19. Turn the ignition switch ON (II).
  20. Measure the voltage between each terminal of both SRS simulator leads and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the dashboard wire harness; replace the dashboard wire harness.

DTC 11-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Airbag First Inflator; DTC 11-Bx ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 11-9x or 11-Bx indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's airbag 4P connector (A) from the cable reel.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the cable reel.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 11-9x or 11-Bx indicated? YES -Go to step 9. NO -Short to ground in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the dashboard wire harness 4P connector (A) from the cable reel.
  11. Connect the SRS inflator simulator (2 ohms connectors) and the simulator lead to the dashboard wire harness.
  12. Reconnect the negative cable to the battery.
  13. Clear the DTC memory.
  14. Read the DTC. Is DTC 11-9x or 11-Bx indicated? YES -Go to step 15. NO -Short to ground in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  15. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  16. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  17. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  18. Measure the resistance between each terminal of both SRS simulator leads and body ground. There should be an open circuit (ohmmeter reads OL) or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Airbag First Inflator; DTC 12-4x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-1x or 12-4x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the dashboard wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-1x or 12-4x indicated? YES -Go to step 9. NO -Open in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  12. Measure the resistance between the terminals of both SRS simulator leads. There should be 1 ohms or less. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P). Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Airbag First Inflator; DTC 12-6x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100
  3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, arid is DTC 12-3x or 12-6x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the dashboard wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-3x or 12-6x indicated? YES -Go to step 9. NO -Short in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  12. Connect SRS short cancellers (070AZ-SAA0100) to the No. 9 and No. 10 terminals and the No. 3 and No. 4 terminal of the SRS unit connector A (28P) (see «REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__reopening-the-srs-unit-circuit-for) ).
  13. Measure the resistance between the terminals of both SRS simulator leads. There should be an open circuit (ohmmeter reads OL) or at least 1 Mohms. Is the resistance as specified ? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Airbag First Inflator; DTC 12-Ax ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-8x or 12-Ax indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the dashboard wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-8x or 12-Ax indicated? YES -Go to step 9. NO -Short to power in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  12. Reconnect the negative cable to the battery.
  13. Turn the ignition switch ON (II).
  14. Measure the voltage between each terminal of both SRS simulator leads and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the dashboard wire harness; replace the dashboard wire harness.

DTC 12-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Airbag First Inflator; DTC 12-Bx ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Airbag Second Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 12-9x or 12-Bx indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the dashboard wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 12-9x or 12-Bx indicated? YES -Go to step 9. NO -Short to ground in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the dashboard wire harness 4P connector.
  12. Measure the resistance between each terminal of both SRS simulator leads and body ground. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the dashboard wire harness; replace the dashboard wire harness.

DTC 21-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-U indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-1x indicated? YES -Go to step 9. NO -Open in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the front passenger's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 1 and the No. 2 terminals of SRS unit connector B (28P). There should be 2.0-3.0 ohms. Is resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness; replace the floor wire harness.

DTC 21-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-3x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-3x indicated? YES -Go to step 9. NO -Short in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the front passenger's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the simulator lead from the floor wire harness.
  13. Measure the resistance between the No. 1 and the No. 2 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the floor wire harness; replace the floor wire harness.

DTC 21-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 76

Scheme 76
Scheme 76
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-8x indicated? YES -Go to step 9. NO -Short to power in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the front passenger's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the simulator lead from the floor wire harness.
  13. Reconnect the negative cable to the battery.
  14. Turn the ignition switch ON (II).
  15. Measure the voltage between the No. 1 terminal of SRS unit connector B (28P) and body ground, and between the No. 2 terminal and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the floor wire harness; replace the floor wire harness.

DTC 21-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-9x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 21-9x indicated? YES -Go to step 9. NO -Short to ground in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the front passenger's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the simulator lead from the floor wire harness.
  13. Measure the resistance between the No. 1 terminals of SRS unit connector B (28P) and body ground, and between the No. 2 terminal and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the floor wire harness; replace the floor wire harness.

DTC 22-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Sea+ Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-1 x indicated? YES -Go to step 9. NO -Open in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the driver's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 3 and the No. 4 terminal of SRS unit connector B (28P). There should be 2.0-3.0 ohms. Is resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness; replace the floor wire harness.

DTC 22-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-3x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-3x indicated? YES -Go to step 9. NO -Short in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the driver's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the simulator lead from the floor wire harness.
  13. Measure the resistance between the No. 3 and the No. 4 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the floor wire harness; replace the floor wire harness.

DTC 22-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-8x indicated? YES -Go to step 9. NO -Short to power in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the driver's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the simulator lead from the floor wire harness.
  13. Reconnect the negative cable to the battery.
  14. Turn the ignition switch ON (II).
  15. Measure the voltage between the No. 3 terminal of SRS unit connector B (28P) and body ground, and between the No. 4 terminal and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the floor wire harness; replace the floor wire harness.

DTC 22-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Seat Belt Tensioner

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead F 07XAZ-SZ30100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 22-9x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the front passenger's seat belt tensioner 4P connector (A) from the floor wire harness.
  5. Connect the SRS inflator simulator (2 ohms connectors) and simulator lead F to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 22-9x indicated? YES -Go to step 9. NO -Short to ground in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the driver's seat belt tensioner connector (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the simulator lead from the floor wire harness.
  13. Measure the resistance between the No. 3 terminal of SRS unit connector B (28P) and body ground, and between the No. 4 terminal and body ground. There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the floor wire harness; replace the floor wire harness.

DTC 31-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the driver's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-1x indicated? YES -Go to step 9. NO -Open in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Measure the resistance between the terminals of the SRS simulator lead. There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness; replace the floor wire harness.

DTC 31-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Driver's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200
  3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 89

Scheme 89
Scheme 89

Scheme 90

Scheme 90
Scheme 90
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-3x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the driver's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-3x indicated? YES -Go to step 9. NO -Short to another wire in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Connect the SRS short canceller (070AZ-SAA0100) to the No. 21 and No. 22 terminals of SRS unit connector B (28P) (see «REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__reopening-the-srs-unit-circuit-for) ).
  14. Measure the resistance between the terminals of the SRS simulator lead. There should be an open circuit (ohmmeter reads OL) or at least 1 M ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the floor wire harness; replace the floor wire harness.

DTC 31-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Driver's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the driver's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-8x indicated? YES -Go to step 9. NO -Short to power in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Reconnect the negative cable to the battery.
  14. Turn the ignition switch ON (II).
  15. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the floor wire harness; replace the floor wire harness.

DTC 31-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Driver's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 31-9x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the driver's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 31-9x indicated? YES -Go to step 9. NO -Short to ground in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Measure the resistance between each terminal of the SRS simulator lead and body ground. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the floor wire harness; replace the floor wire harness.

DTC 32-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the front passenger's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-1x indicated? YES -Go to step 9. NO -Open in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Measure the resistance between the terminals of the SRS simulator lead. There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness; replace the floor wire harness.

DTC 32-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Front Passenger's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200
  3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-3x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the front passenger's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-3x indicated? YES -Go to step 9. NO -Short to another wire in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Connect the SRS short canceller (070AZ-SAA0100) to the No. 23 and No. 24 terminals of SRS unit connector B (28P) (see «REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__reopening-the-srs-unit-circuit-for) ).
  14. Measure the resistance between the terminals of the SRS simulator lead. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the floor wire harness; replace the floor wire harness.

DTC 32-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Front Passenger's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the front passenger's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-8x indicated? YES -Go to step 9. NO -Short to power in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Reconnect the negative cable to the battery.
  14. Turn the ignition switch ON (II).
  15. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the floor wire harness; replace the floor wire harness.

DTC 32-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Front Passenger's Side Airbag Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 32-9x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the floor wire harness 2P connector (A) from the front passenger's side airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the floor wire harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 32-9x indicated? YES -Go to step 9. NO -Short to ground in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the floor wire harness 2P connector.
  13. Measure the resistance between each terminal of the SRS simulator lead and body ground. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the floor wire harness; replace the floor wire harness.

DTC 33-1x ("x" can be 0 thru 9 or A thru F): Open in Left Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the left side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-1x indicated? YES -Go to step 9. NO -Open in the left side curtain airbag; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Measure the resistance between the terminals of the SRS simulator lead. There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty SRS unit or poor connection at the SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 33-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Left Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200
  3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-3x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the left side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-3x indicated? YES -Go to step 9. NO -Short to another wire in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Connect the SRS short canceller (070AZ-SAA0100) to the No. 11 and No. 12 terminals of SRS unit connector C (16P) (see «REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__reopening-the-srs-unit-circuit-for) ).
  13. Measure the resistance between the terminals of the SRS simulator lead. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to another wire in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 33-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Left Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the left side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-8x indicated? YES -Go to step 9. NO -Short to power in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect the SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Reconnect the negative cable to the battery.
  13. Turn the ignition switch ON (II).
  14. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 33-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Left Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 109

Scheme 109
Scheme 109

Scheme 110

Scheme 110
Scheme 110
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 33-9x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the left side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 33-9x indicated? YES -Go to step 9. NO -Short to ground in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Measure the resistance between each terminal of the SRS simulator lead and body ground. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 34-1x ("x" can be 0 thru 9 or A thru F): Open in Right Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 111

Scheme 111
Scheme 111

Scheme 112

Scheme 112
Scheme 112
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the right side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-1x indicated? YES -Go to step 9. NO -Open in the right side curtain airbag inflator, replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Measure the resistance between the terminals of the SRS simulator lead. There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 34-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in Right Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200
  3. SRS short canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 113

Scheme 113
Scheme 113

Scheme 114

Scheme 114
Scheme 114
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-3x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the right side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-3x indicated? YES -Go to step 9. NO -Short to another wire in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Connect the SRS short canceller (070AZ-SAA0100) to the No. 13 and No. 14 terminals of SRS unit connector C (16P) (see «REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__reopening-the-srs-unit-circuit-for) ).
  13. Measure the resistance between the terminals of the SRS simulator lead. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 34-8x ("x" can be 0 thru 9 or A thru F): Short to Power in Right Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the right side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-8x indicated? YES -Go to step 9. NO -Short to power in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Reconnect the negative cable to the battery.
  13. Turn the ignition switch ON (II).
  14. Measure the voltage between each terminal of the SRS simulator lead and body ground. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 34-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in Right Side Curtain Airbag First Inflator

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead E 07XAZ-S1A0200

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 117

Scheme 117
Scheme 117

Scheme 118

Scheme 118
Scheme 118
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 34-9x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the side curtain airbag harness 2P connector (A) from the right side curtain airbag.
  5. Connect the SRS inflator simulator (2 ohms connector) and simulator lead E to the side curtain airbag harness.
  6. Reconnect the negative cable to the battery.
  7. Clear the DTC memory.
  8. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 34-9x indicated? YES -Go to step 9. NO -Short to ground in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Turn the ignition switch OFF. Disconnect the negative cable from the battery/ then wait for 3 minutes.
  10. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  11. Disconnect the SRS inflator simulator from the SRS simulator lead. Do not disconnect the simulator lead from the side curtain airbag harness 2P connector.
  12. Measure the resistance between each terminal of the SRS simulator lead and body ground. There should be an open circuit (ohmmeter reads OL) or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector C (16P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 41-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Left Front Impact Sensor

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead H 07YAZ-S3AA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120

Scheme 121

Scheme 121
Scheme 121

Scheme 122

Scheme 122
Scheme 122

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124
Scheme 124
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 41-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF.
  4. Disconnect the negative cable from the battery, then wait for 3 minutes.
  5. Check the connections between SRS unit connector A (28P) and the SRS unit, between the engine compartment wire harness 2P connector and the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ), and at connector C403. Are the connections OK? YES -Go to step 6. NO -Repair the poor connections and retest. If DTC 41-1x is still present, go to step 6.
  6. Disconnect the engine compartment wire harness 2P connector (A) from the left front impact sensor.
  7. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  8. Measure the resistance between the No. 15 and No. 27 terminals of SRS unit connector A (28P). There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Go to step 9. NO -Short in the engine compartment wire harness or dashboard wire harness; replace the faulty harness.
  9. Measure the resistance between the No. 15 terminal of SRS unit connector A (28P) and body ground, and between the No. 27 terminal and body ground. There should be an open circuit or at lest 1 Mohms. Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the dashboard wire harness or engine compartment wire harness; replace the faulty harness.
  10. Reconnect the negative cable to the battery.
  11. Turn the ignition switch ON (II).
  12. Measure the voltage between the No. 15 terminal of SRS unit connector A (28P) and body ground, and between the No. 27 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES -Go to step 13. NO -Short to power in the engine compartment wire harness or the dashboard wire harness; replace the faulty harness.
  13. Turn the ignition switch OFF.
  14. Connect the SRS inflator simulator (jumper connector) and simulator lead H to the engine compartment wire harness 2P connector (A).
  15. Measure the resistance between the No. 15 and No. 27 terminals of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Faulty left front impact sensor or SRS unit; replace the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Poor connection at C403, faulty engine compartment wire harness, or faulty dashboard wire harness. Inspect C403 (see «ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__engine-compartment-wire-harness-left-branch) ). If it is OK, replace the faulty harness.

DTC 42-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Right Front Impact Sensor

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead H 07YAZ-S3AA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 125

Scheme 125
Scheme 125

Scheme 126

Scheme 126
Scheme 126

Scheme 127

Scheme 127
Scheme 127

Scheme 128

Scheme 128
Scheme 128

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 42-1 x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF.
  4. Disconnect the negative cable from the battery, then wait for 3 minutes.
  5. Check the connections between SRS unit connector A (28P) and the SRS unit, between the engine compartment wire harness 2P connector and the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ), and at connector C403. Are the connections OK? YES -Go to step 6. NO -Repair the poor connections and retest. If DTC 42-1x is still present, go to step 6.
  6. Disconnect the engine compartment wire harness 2P connector (A) from the right front impact sensor.
  7. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  8. Measure the resistance between the No. 16 and No. 28 terminals of SRS unit connector A (28P). There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Go to step 9. NO -Short in the engine compartment wire harness or dashboard wire harness; replace the faulty harness.
  9. Measure the resistance between the No. 16 terminal of SRS unit connector A (28P) and body ground, and between the No. 28 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the dashboard wire harness or engine compartment wire harness; replace the faulty harness.
  10. Reconnect the negative cable to the battery.
  11. Turn the ignition switch ON (II).
  12. Measure the voltage between the No. 16 terminal of SRS unit connector A (28P) and body ground, and between the No. 28 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES -Go to step 13. NO -Short to power in the engine compartment wire harness or dashboard wire harness; replace the faulty harness.
  13. Turn the ignition switch OFF.
  14. Connect the SRS inflator simulator (jumper connector) and simulator lead H to the engine compartment wire harness 2P connector (A).
  15. Measure the resistance between the No. 16 and No. 28 terminals of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Faulty right front impact sensor or SRS unit; replace the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Poor connection at C403, faulty engine compartment wire harness, or faulty dashboard wire harness. Inspect C403 (see «ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__engine-compartment-wire-harness-left-branch) ). If it is OK, replace the faulty harness.

DTC 41-2x, 41-3x, 41-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Front Impact Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 41-2x, 41-3x, or 41-Bx indicated? YES -Replace the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 42-2x, 42-3x, 42-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Front Impact Sensor

Note. Before doing this troubleshooting, procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 42-2x, 42-3x, or 42-Bx indicated? YES -Replace the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 43-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Left Side Impact Sensor (first)

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead H 07YAZ-S3AA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 131

Scheme 131
Scheme 131

Scheme 132

Scheme 132
Scheme 132

Scheme 133

Scheme 133
Scheme 133

Scheme 134

Scheme 134
Scheme 134

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 43-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Check the connection between the floor wire harness 2P connector and the left side impact sensor (first). Is the connection OK? YES -Go to step 5. NO -Repair the poor connections and retest. If DTC 43-1x is still present, go to step 5.
  5. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  6. Disconnect the floor wire harness 2P connector (A) from the left side impact sensor (first).
  7. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  8. Measure the resistance between the No. 19 and No. 20 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES -Go to step 9. NO -Short in the floor wire harness; replace the floor wire harness.
  9. Measure the resistance between the No. 19 terminal of SRS unit connector B (28P) and body ground, and between the No. 20 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the floor wire harness; replace the floor wire harness.
  10. Reconnect the negative cable to the battery.
  11. Turn the ignition switch ON (II).
  12. Measure the voltage between the No. 19 terminal of SRS unit connector B (28P) and body ground, and between the No. 20 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES -Go to step 13. NO -Short to power in the floor wire harness; replace the floor wire harness.
  13. Turn the ignition switch OFF.
  14. Connect the SRS inflator simulator (jumper connector) and simulator lead H to the floor wire harness 2P connector (A).
  15. Measure the resistance between the No. 19 and No. 20 terminals of SRS unit connector B (28P). There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty left side impact sensor (first) or SRS unit; replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-impact-sensor-first-replacement) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness; replace the floor wire harness.

DTC 44-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Right Side Impact Sensor (first)

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead H 07YAZ-S3AA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 137

Scheme 137
Scheme 137

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 44-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Check the connection between the floor wire harness 2P connector and the right side impact sensor (first). Is the connection OK? YES -Go to step 5. NO -Repair the poor connections and retest. If the DTC 44-1x is still present, go to step 5.
  5. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  6. Disconnect the floor wire harness 2P connector (A) from the right side impact sensor (first).
  7. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  8. Measure the resistance between the No. 25 and No. 26 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES -Go to step 9. NO -Short in the floor wire harness; replace the floor wire harness.
  9. Measure the resistance between the No. 25 terminal of SRS unit connector B (28P) and body ground, and between the No. 26 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the floor wire harness; replace the floor wire harness.
  10. Reconnect the negative cable to the battery.
  11. Turn the ignition switch ON (II).
  12. Measure the voltage between the No. 25 terminal of SRS unit connector B (28P) and body ground, and between the No. 26 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES -Go to step 13. NO -Short to power in the floor wire harness; replace the floor wire harness.
  13. Turn the ignition switch OFF.
  14. Connect the SRS inflator simulator (jumper connector) and simulator lead H to the floor wire harness 2P connector (A).
  15. Measure the resistance between the No. 25 and No. 26 terminals of SRS unit connector B (28P). There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty right side impact sensor (first) or SRS unit; replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-impact-sensor-first-replacement) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness; replace the floor wire harness.

DTC 43-2x, 43-3x, 43-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Side Impact Sensor (first)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 43-2x, 43-3x, or 43-Bx indicated? YES -Replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-impact-sensor-first-replacement) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 44-2x, 44-3x, 44-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Side Impact Sensor (first)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 44-2x, 44-3x, or 44-Bx indicated? YES -Replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-impact-sensor-first-replacement) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 45-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Left Side Impact Sensor (second)

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead H 07YAZ-S3AA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144

Scheme 145

Scheme 145
Scheme 145

Scheme 146

Scheme 146
Scheme 146

Scheme 147

Scheme 147
Scheme 147

Scheme 148

Scheme 148
Scheme 148
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 45-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Check the connection between the side curtain airbag harness 2P connector and the left side impact sensor (second). Is the connection OK? YES -Go to step 5. NO -Repair the poor connections and retest. If the DTC 45-1 x is still present, go to step 5.
  5. Disconnect the side curtain airbag harness 2P connector from the left side curtain airbag (see step 5 ).
  6. Disconnect the side curtain airbag harness 2P connector (A) from the left side impact sensor (second).
  7. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  8. Measure the resistance between the No. 9 and No. 10 terminals of SRS unit connector C (16P). There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES -Go to step 9. NO -Short in the side curtain airbag harness; replace the side curtain airbag harness.
  9. Measure the resistance between the No. 9 terminal of SRS unit connector C (16P) and body ground, and between the No. 10 terminal and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the side curtain airbag harness; replace the side curtain airbag harness.
  10. Reconnect the negative cable to the battery.
  11. Turn the ignition switch ON (II).
  12. Measure the voltage between the No. 9 terminal of SRS unit connector C (16P) and body ground, and between the No. 10 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES -Go to step 13. NO -Short to power in the side curtain airbag harness; replace the side curtain airbag harness.
  13. Turn the ignition switch OFF.
  14. Connect the SRS inflator simulator (jumper connector) and simulator lead H to the side curtain airbag harness 2P connector (A).
  15. Measure the resistance between the No. 9 and No. 10 terminals of SRS unit connector C (16P). There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty left side impact sensor (second) or SRS unit; replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 46-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Right Side Impact Sensor (second)

Special Tools Required

  1. SRS inflator simulator 07SAZ-TB4011A
  2. SRS simulator lead H 07YAZ-S3AA100

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 149

Scheme 149
Scheme 149

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151

Scheme 152

Scheme 152
Scheme 152

Scheme 153

Scheme 153
Scheme 153

Scheme 154

Scheme 154
Scheme 154
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 46-1 x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Check the connection between the side curtain airbag harness 2P connector and the right side impact sensor (second). Is the connection OK? YES -Go to step 5. NO -Repair the poor connections and retest. If the DTC 46-1x is still present, go to step 5.
  5. Disconnect the side curtain airbag harness 2P connector from the right side curtain airbag (see step 5 ).
  6. Disconnect the side curtain airbag harness 2P connector (A) from the right side impact sensor (second).
  7. Disconnect SRS unit connector C (16P) from the SRS unit (see step 7 ).
  8. Measure the resistance between the No. 15 and No. 16 terminals of SRS unit connector C (16P). There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Go to step 9. NO -Short in the side curtain airbag harness; replace the side curtain airbag harness.
  9. Measure the resistance between the No. 15 terminal of SRS unit connector C (16P) and body ground, and between the No. 16 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the side curtain airbag harness; replace the side curtain airbag harness.
  10. Reconnect the negative cable to the battery.
  11. Turn the ignition switch ON (II).
  12. Measure the voltage between the No. 15 terminal of SRS unit connector C (16P) and body ground, and between the No. 16 terminal and body ground. There should be 1 V or less. Is the voltage as specified? YES -Go to step 13. NO -Short to power in the side curtain airbag harness; replace the side curtain airbag harness.
  13. Turn the ignition switch OFF.
  14. Connect the SRS inflator simulator (jumper connector) and simulator lead H to the side curtain airbag harness 2P connector (A).
  15. Measure the resistance between the No. 15 and No. 16 terminals of SRS unit connector C (16P). There should be 1.0 ohms or less. Is the resistance as specified? YES -Faulty right side impact sensor (second) or SRS unit; replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the side curtain airbag harness; replace the side curtain airbag harness.

DTC 45-2x, 45-3x, 45-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Side Impact Sensor (second)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 45-2x, 45-3x, or 45-Bx indicated? YES -Replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 46-2x, 46-3x, 46-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Side Impact Sensor (second)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 46-2x, 46-3x, or 46-Bx indicated? YES -Replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC returns, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 51-xx, 52-xx, 53-xx, 54-xx, 55-xx ("x" can be 0 thru 9 or A thru F): Internal Failure of the SRS Unit

Note. Before troubleshooting any of these DTCs, check the battery/system voltage and battery cable connections. If the voltage is low, repair the charging system or replace the battery before troubleshooting the SRS. If the battery/system voltage is now OK, ask the customer if the battery ever went dead or if the engine was started and run with the battery in a low state of charge. A dead battery may trigger one of these DTCs. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 51-xx, 52-xx, 53-xx, 54-xx, or 55-xx indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC Ex-xx ("x" can be 0 thru 9 or A thru F): Control Operation Recorded; DTC Fx-xx ("x" can be 0 thru 9 or A thru F): Airbags and/or Tensioners Deployment Recorded

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ). DTC E2-11: Front passenger's airbag did not deploy by SWS operation. DTC E4-11: Front passenger's side airbag did not deploy by OPDS operation. DTC F1-11: Driver's airbag and/or driver's seat belt tensioner deployed. DTC F2-11: Front passenger's airbag and/or front passenger's seat belt tensioner deployed. DTC F3-11: Driver's side airbag, left side curtain airbag, and/or driver's seat belt tensioner deployed. DTC F4-11: Front passenger's side airbag, right side curtain airbag, and/or front passenger's seat belt tensioner deployed.

The SRS unit must be replaced after any airbags and/or tensioners have deployed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ).

Note. DTC E2-11 is set if the system triggered airbag deployment but the front passenger's airbag was prevented from deploying because of the front passenger's weight sensor. DTC E4-11 is set if the system triggered a passenger's side airbag deployment but the airbag was prevented from deploying by the ODS. Replace the right side impact sensor (first) (see SIDE IMPACT SENSOR (FIRST) REPLACEMENT ).

DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch ('04-05 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 155

Scheme 155: DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch ('04-05 models
Scheme 155: DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch ('04-05 models

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157

Scheme 158

Scheme 158
Scheme 158

Scheme 159

Scheme 159
Scheme 159

Scheme 160

Scheme 160
Scheme 160
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the driver's seat belt several times.
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 61-1x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the driver's seat wire harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
  6. Buckle the driver's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 2 and No. 3 terminals of the same connector. There should be an open circuit or at least 1 Mohms. Are the resistances as specified? YES -Go to step 7. NO -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  7. Unbuckle the driver's seat belt. Measure the resistance between the No. 2 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistances as specified? YES -Go to step 8. NO -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Measure the resistance between the No. 3 terminal of the driver's seat wire harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 9. NO -Open in the driver's seat wire harness or floor wire harness, or poor ground connection at G601 (see «FLOOR WIRE HARNESS (LEFT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-left-branch) ). If G601 is OK, replace the faulty harness.
  9. Disconnect the negative cable from the battery.
  10. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 17 terminal of SRS unit connector B (28P) and the No. 1 terminal of the driver's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 13. NO -Open in the driver's seat wire harness or floor wire harness; replace the faulty harness.
  13. Measure the resistance between the No. 11 terminal of SRS unit connector B (28P) and the No. 2 terminal of the driver's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the driver's seat wire harness, or floor wire harness, or poor connection at the floor wire harness. Check the connection at the floor wire harness and the MICU/under-dash fuse/relay box. If the connection is OK, replace the faulty harness or part.

DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 161

Scheme 161: DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch ('06-08 models
Scheme 161: DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Belt Buckle Switch ('06-08 models

Scheme 162

Scheme 162
Scheme 162

Scheme 163

Scheme 163
Scheme 163

Scheme 164

Scheme 164
Scheme 164

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the driver's seat belt several times.
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 61-1x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the driver's seat wire harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
  6. Buckle the driver's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 2 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistance as specified? YES -Go to step 7. NO -Replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ), then clear the DTC.
  7. Unbuckle the driver's seat belt. Measure the resistance between the No. 1 and No. 2 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistance as specified? YES -Go to step 8. NO -Replace the driver's seat belt buckle assembly (See «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then erase the DTC.
  8. Measure the resistance between the No. 1 terminal of the driver's seat wire harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 9. NO -Open in the driver's seat wire harness or floor wire harness, or poor ground connection at G601 (see «FLOOR WIRE HARNESS (LEFT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-left-branch) ). If G601 is OK, replace the faulty harness.
  9. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 17 terminal of SRS unit connector B (28P) and the No. 1 terminal of the driver's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 13. NO -Open in the driver's seat wire harness or floor wire harness; replace the faulty harness.
  13. Measure the resistance between the No. 11 terminal of SRS unit connector B (28P) and the No. 2 terminal of the driver's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the driver's seat wire harness or floor wire harness, or poor connection at the floor wire harness. Check the connections at the floor wire harness, connector F (14P), and connector H (14P) at the under-dash fuse/relay box. If the connections are OK, replace the faulty harness or part.

DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch ('04-05 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 167

Scheme 167: DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch ('04-05 model
Scheme 167: DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch ('04-05 model

Scheme 168

Scheme 168
Scheme 168

Scheme 169

Scheme 169
Scheme 169

Scheme 170

Scheme 170
Scheme 170

Scheme 171

Scheme 171
Scheme 171

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the driver's seat belt several times.
  3. Read the DTC. Is DTC 61-2x indicated ? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the driver's seat harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
  6. Measure the continuity between the No. 1 terminal of the driver's seat belt buckle switch 3P connector and body ground, and between the No. 2 terminal and body ground. There should be no continuity. Is there continuity? YES -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ). NO -Go to step 7.
  7. Buckle the driver's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 2 and No. 3 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistances as specified? YES -Go to step 8. NO -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Unbuckle the driver's seat belt. Measure the resistance between the No. 2 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistances as specified? YES -Go to step 9. NO -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  9. Measure the resistance between the No. 3 terminal of the driver's seat wire harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 10. NO -Open in the driver's seat wire harness or floor wire harness, or poor ground connection at G601 (see «FLOOR WIRE HARNESS (LEFT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-left-branch) ). If G601 is OK, replace the faulty harness.
  10. Disconnect the negative cable from the battery, then wait for 3 minutes.
  11. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  12. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  13. Measure the resistance between the No. 2 terminal of the driver's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1 M ohms. Is the resistance as specified? YES -Go to step 14. NO -Short to ground in the driver's seat wire harness, floor wire harness, or multiplex integrated control unit. Replace the faulty harness or part.
  14. Measure the resistance between the No. 1 terminal of the driver's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the driver's seat wire harness or floor wire harness; replace the faulty harness.

DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 174

Scheme 174: DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch ('06-08 model
Scheme 174: DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Belt Buckle Switch ('06-08 model

Scheme 175

Scheme 175
Scheme 175

Scheme 176

Scheme 176
Scheme 176

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179
Scheme 179

Scheme 180

Scheme 180
Scheme 180
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the driver's seat belt several times.
  3. Read the DTC. Is DTC 61-2x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the driver's seat harness 3P connector from the driver's seat belt buckle switch 3P connector (A).
  6. Measure the continuity between the No. 2 terminal of the driver's seat belt buckle switch 3P connector and body ground, and between the No. 3 terminal and body ground. There should be no continuity. Is there continuity? YES -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ). NO -Go to step 7.
  7. Buckle the driver's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 2 terminals of the same connector. There should be an open circuit or at least 1 M ohms. Are the resistances as specified? YES -Go to step 8. NO -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Unbuckle the driver's seat belt. Measure the resistance between the No. 1 and No. 2 terminals of the driver's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1 M ohms. Are the resistances as specified? YES -Go to step 9. NO -Replace the driver's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  9. Measure the resistance between the No. 1 terminal of the driver's seat wire harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 10. NO -Open in the driver's seat wire harness or floor wire harness, or poor ground connection at G601 (see «FLOOR WIRE HARNESS (LEFT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-left-branch) ). If G601 is OK, replace the faulty harness.
  10. Disconnect the negative cable from the battery, then wait for 3 minutes.
  11. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  12. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  13. Measure the resistance between the No. 2 terminal of the driver's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Go to step 14. NO -Short to ground in the driver's seat wire harness, floor wire harness, or multiplex integrated control unit. Replace the faulty harness or part.
  14. Measure the resistance between the No. 3 terminal of the driver's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the driver's seat wire harness or floor wire harness; replace the faulty harness.

DTC 62-1 x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch ('04-05 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 181

Scheme 181: DTC 62-1 x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch ('04
Scheme 181: DTC 62-1 x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch ('04

Scheme 182

Scheme 182
Scheme 182

Scheme 183

Scheme 183
Scheme 183

Scheme 184

Scheme 184
Scheme 184

Scheme 185

Scheme 185
Scheme 185

Scheme 186

Scheme 186
Scheme 186

Scheme 187

Scheme 187
Scheme 187

Scheme 188

Scheme 188
Scheme 188

Scheme 189

Scheme 189
Scheme 189

Scheme 190

Scheme 190
Scheme 190
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the front passenger's seat belt several times.
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 62-1x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the front passenger's seat belt buckle switch 3P connector (A) from the floor wire harness ('04 model) or front passenger's seat wire harness ('05 model).
  6. Buckle the front passenger's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 [No. 2] and No. 2 [No. 3] terminals of the same connector. There should be an open circuit or at least 1Mohms. :'05 model Are the resistances as specified? YES -Go to step 7. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  7. Unbuckle the front passenger's seat belt. Measure the resistance between the No. 1 [No. 2] and No. 2 [No. 3] terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. :'05 model Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistances as specified? YES -Go to step 8. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Measure the resistance between the No. 1 [No. 3] terminal of the floor wire harness 3P connector and body ground. There should be 0-1 ohms. [ ] : '05 model Is the resistance as specified? YES -Go to step 9. NO -Open in the floor wire harness, front passenger's seat wire harness ('05 model) or poor ground connection at G602 (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-right-branch) ). If G602 is OK, replace the faulty harness.
  9. Disconnect the negative cable from the battery, then wait for 3 minutes.
  10. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 18 terminal of SRS unit connector B (28P) and the No. 3 [No. 1] terminal of the floor wire harness 3P connector. There should be 0-1 ohms. [ ] : '05 model Is the resistance as specified? YES -Go to step 13. NO -Open in the floor wire harness or front passenger's seat wire harness ('05 model); replace the faulty harness.
  13. Measure the resistance between the No. 12 terminal of SRS unit connector B (28P) and the No. 2 terminal of the floor wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness or front passenger's seat wire harness ('05 model); replace the faulty harness.

DTC 62-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 191

Scheme 191: DTC 62-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch ('06-
Scheme 191: DTC 62-1x ("x" can be 0 thru 9 or A thru F): Open in Front Passenger's Seat Belt Buckle Switch ('06-

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the front passenger's seat belt several times.
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 62-1x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the front passenger's seat belt buckle switch 3P connector (A) from the front passenger's seat wire harness.
  6. Buckle the front passenger's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 2 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistances as specified? YES -Go to step 7. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  7. Unbuckle the front passenger's seat belt. Measure the resistance between the No. 1 and No. 2 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1 Mohms. Are the resistances as specified? YES -Go to step 8. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Measure the resistance between the No. 1 terminal of the front passenger's seat wire harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 9. NO -Open in the front passenger's seat wire harness, front passenger's seat wire harness or poor ground connection at G602 (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-right-branch) ). If G602 is OK, replace the faulty harness.
  9. Disconnect the negative cable from the battery.
  10. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  11. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 18 terminal of SRS unit connector B (28P) and the No. 3 terminal of the front passenger's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 13. NO -Open in the front passenger's seat wire harness; replace the faulty harness.
  13. Measure the resistance between the No. 12 terminal of SRS unit connector B (28P) and the No. 2 terminal of the front passenger's seat wire harness 3P connector. There should be 0-1 ohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the front passenger's seat wire harness; replace the faulty harness.

DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch ('04-05 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 197

Scheme 197: DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch ('04
Scheme 197: DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch ('04

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199
Scheme 199

Scheme 200

Scheme 200
Scheme 200

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202

Scheme 203

Scheme 203
Scheme 203

Scheme 204

Scheme 204
Scheme 204

Scheme 205

Scheme 205
Scheme 205
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the front passenger's seat belt several times.
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 62-2x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the front passenger's seat belt buckle switch 3P connector (A) from the floor wire harness ('04 model) or front passenger's seat wire harness ('05 model).
  6. Measure the continuity between the No. 2 [No. 1] terminal of the front passenger's seat belt buckle switch 3P connector and body ground, and between the No. 3 [No. 2] terminal and body ground. There should be no continuity. :'05 model Is there continuity? YES -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ). NO -Go to step 7.
  7. Buckle the front passenger's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 [No. 2] and No. 2 [No. 3] terminals of the same connector. There should be an open circuit or at least 1Mohms. [ ] : '05 model Are the resistances as specified? YES -Go to step 8. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Unbuckle the front passenger's seat belt. Measure the resistance between the No. 1 [No. 2] and No. 2 [No. 3] terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. :'05 model Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1 Mohms. Are the resistances as specified? YES -Go to step 9. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  9. Measure the resistance between the No. 1 [No. 3] terminal of the floor wire harness 3P connector and body ground. There should be 0-1 ohms. : '05 model Is the resistance as specified? YES -Go to step 10. NO -Open in the floor wire harness, front passenger's seat wire harness ('05 model) or poor ground connection at G602 (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-right-branch) ). If G602 is OK, replace the floor wire harness.
  10. Disconnect the negative cable from the battery, then wait for 3 minutes.
  11. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  12. Disconnect SRS unit connector B (28P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  13. Measure the resistance between the No. 2 terminal of the floor wire harness 3P connector and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 14. NO -Short to ground in the floor wire harness, or front passenger's seat wire harness ('05 model); replace the faulty harness.
  14. Measure the resistance between the No. 3 [No. 1] terminal of the floor wire harness 3P connector and body ground. There should be an open circuit or at least 1Mohms. :'05 model Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the floor wire harness, or front passenger's seat wire harness ('05 model); replace the faulty harness.

DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 206

Scheme 206: DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch ('06
Scheme 206: DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in Front Passenger's Seat Belt Buckle Switch ('06

Scheme 207

Scheme 207
Scheme 207

Scheme 208

Scheme 208
Scheme 208

Scheme 209

Scheme 209
Scheme 209

Scheme 210

Scheme 210
Scheme 210

Scheme 211

Scheme 211
Scheme 211

Scheme 212

Scheme 212
Scheme 212
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), then buckle and unbuckle the front passenger's seat belt several times.
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 62-2x indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Turn the ignition switch OFF.
  5. Disconnect the front passenger's seat belt buckle switch 3P connector (A) from the front passenger's seat wire harness.
  6. Measure the continuity between the No. 2 terminal of the front passenger's seat belt buckle switch 3P connector and body ground, and between the No. 3 terminal and body ground. There should be no continuity. Is there continuity? YES -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ). NO -Go to step 7.
  7. Buckle the front passenger's seat belt. Measure the resistance between the No. 1 and No. 3 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 2 terminals of the same connector. There should be an open circuit or at least 1 Mohms. Are the resistances as specified? YES -Go to step 8. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  8. Unbuckle the front passenger's seat belt. Measure the resistance between the No. 1 and No. 2 terminals of the front passenger's seat belt buckle switch 3P connector. There should be 0-1 ohms. Measure the resistance between the No. 1 and No. 3 terminals of the same connector. There should be an open circuit or at least 1Mohms. Are the resistances as specified? YES -Go to step 9. NO -Replace the front passenger's seat belt buckle assembly (see «SEAT BELT BUCKLE»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system) ), then clear the DTC.
  9. Measure the resistance between the No. 1 terminal of the front passenger's seat wire harness 3P connector and body ground. There should be 0-1 ohms. Is the resistance as specified? YES -Go to step 10. NO -Open in the front passenger's seat wire harness or poor ground connection at G602 (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-right-branch) ). If G602 is OK, replace the floor wire harness.
  10. Disconnect the negative cable from the battery, then wait for 3 minutes.
  11. Disconnect both seat belt tensioner 4P connectors from the floor wire harness (see step 6 ).
  12. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  13. Measure the resistance between the No. 2 terminal of the front passenger's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1M ohms. Is the resistance as specified? YES -Go to step 14. NO -Short to ground in the front passenger's seat wire harness; replace the faulty harness.
  14. Measure the resistance between the No. 3 terminal of the front passenger's seat wire harness 3P connector and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the front passenger's seat wire harness; replace the faulty harness.

DTC 71-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Position Sensor ('06-08 models)

Special Tools Required

SRS inflator simulator 07SAZ-TB4011A

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 213

Scheme 213: DTC 71-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Position Sensor ('06-08 models)
Scheme 213: DTC 71-1x ("x" can be 0 thru 9 or A thru F): Open in Driver's Seat Position Sensor ('06-08 models)

Scheme 214

Scheme 214
Scheme 214
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 71-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Check the connection between the seat position sensor harness 2P connector and the driver's seat position sensor.
  4. Clear the DTC memory.
  5. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 71-1x indicated? YES -Go to step 6. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  6. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  7. Disconnect the driver's seat wire harness 2P connector from the driver's seat position sensor (A).
  8. Connect the No. 1 and No. 2 terminals of the driver's seat wire harness 2P connector with a jumper wire.
  9. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  10. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  11. Measure the resistance between the No. 16 and No. 28 terminals of SRS unit connector B (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Faulty driver's seat position sensor or SRS unit; replace the driver's seat position sensor (see «DRIVER'S SEAT POSITION SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the floor wire harness or seat position sensor harness; replace the faulty harness.

DTC 71-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Position Sensor ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 215

Scheme 215: DTC 71-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Position Sensor ('06-08 models)
Scheme 215: DTC 71-2x ("x" can be 0 thru 9 or A thru F): Short in Driver's Seat Position Sensor ('06-08 models)

Scheme 216

Scheme 216
Scheme 216

Scheme 217

Scheme 217
Scheme 217
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 71-2x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect the driver's seat wire harness 2P connector from the driver's seat position sensor (A).
  5. Reconnect the negative cable to the battery.
  6. Clear the DTC memory.
  7. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 71-2x indicated? YES -Go to step 8. NO -Faulty driver's seat position sensor; replace the driver's seat position sensor.
  8. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  9. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  10. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  11. Measure the resistance between the No. 16 and No. 28 terminals of SRS unit connector B (28P). There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Go to step 12. NO -Short in the floor wire harness; replace the floor wire harness.
  12. Measure the resistance between the No. 16 terminal of SRS unit connector B (28P) and body ground, and between the No. 28 terminal and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty driver's seat position sensor or SRS unit; replace the driver's seat position sensor (see «DRIVER'S SEAT POSITION SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short in the floor wire harness; replace the floor wire harness.

DTC 81-79: Front Passenger's Weight Sensors Initial Check Failure ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 81-79 indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF.
  4. Make sure nothing is on the front passenger's seat.
  5. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Remove the seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ) and front passenger's weight sensors, then reinstall them. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). Retry the troubleshooting.

DTC 81-71,81-78: ODS Unit Does Not Calibrate ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 81-71, or 81-78 indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds, and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Go to step 5.
  5. Replace the ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ).
  6. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds, and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).

DTC 82-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Inner Side Front Passenger's Weight Sensor ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 82-1 x indicated? YES -Faulty front passenger's weight sensor; replace the inner side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 83-2x ("x" can be 0 thru 9 or A thru F): No Signal From the Outer Side Front Passenger's Weight Sensor ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 83-2x indicated? YES -Faulty front passenger's weight sensor; replace the outer side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 81-4x, 81-5x, 85-4x, 85-5x ("x" can be 0 thru 9 or A thru F): internal Failure of the OPDS/ODS Unit; DTC 81-63,81-64,85-63,85-64: Internal Failure of the OPDS/ODS Unit

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 81-4x, 81-5x, 81-63, 81-64, 85-4x, 85-5x, 85-63, or 85-64 indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Initialize the OPDS/ODS unit (see «OPDS/ODS UNIT INITIALIZATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-initialization) ).
  4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES -The system is OK at this time. NO -Go to step 5.
  5. Replace the OPDS/ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ).
  6. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). If the DTC is still present, replace the SRS unit.

DTC 85-79: OPDS Sensor Initial Check Failure

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 85-79 indicated? YES -Turn the ignition switch OFF, and go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Make sure nothing is on the front passenger's seat.
  4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Go to step 5.
  5. Initialize the OPDS/ODS unit (see «OPDS/ODS UNIT INITIALIZATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-initialization) ).
  6. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Replace the OPDS/ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ), and retest. If the problem is still present, replace the OPDS sensor/seat-back (see «FRONT SEAT COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-cover-replacement) ). If the DTC is still present, replace the SRS unit. B

DTC 85-61: No Signal From the OPDS Unit ('04-05 models); DTC 85-62: Response Data Error From the OPDS Unit ('04-05 models)

Note. An incorrect OPDS unit can cause DTC 85-63. A new (uninitialized) OPDS unit installed with a faulty sensor can also cause DTC 85-71. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 218

Scheme 218: DTC 85-61: No Signal From the OPDS Unit ('04-05 models); DTC 85-62: Response Data Error From the OPD
Scheme 218: DTC 85-61: No Signal From the OPDS Unit ('04-05 models); DTC 85-62: Response Data Error From the OPD

Scheme 219

Scheme 219
Scheme 219

Scheme 220

Scheme 220
Scheme 220

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228
  1. Make sure nothing is on the front passenger's seat.
  2. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 85-61 or 85-62 indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Check the connection between OPDS unit harness 8P connector D and the OPDS unit. Is the connection OK? YES -Go to step 5. NO -Repair the poor connection and retest. If DTC 85-61 or 85-62 is still present, go to step 5.
  5. Turn the ignition switch OFF.
  6. Check the No. 10 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 7. NO -Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 10 (7.5 A) fuse circuit (dashboard wire harness, floor wire harness, or OPDS unit harness).
  7. Disconnect OPDS unit 8P connector D from the OPDS unit.
  8. Turn the ignition switch ON (II).
  9. Measure the voltage between the No. 4 terminal of OPDS unit 8P connector D and body ground. There should be battery voltage. Is there battery voltage? YES -Go to step 14 . NO -Go to step 10.
  10. Turn the ignition switch OFF.
  11. Disconnect dashboard wire harness 24P connector C501 (A) from the floor wire harness C501 (B).
  12. Turn the ignition switch ON (II).
  13. Measure the voltage between the No. 19 terminal of dashboard wire harness 24P connector and body ground. There should be battery voltage. Is there battery voltage? YES -Open in the WHT wire of the floor wire harness or OPDS unit harness; replace the faulty harness. NO -Open in the WHT wire of the dashboard wire harness; replace the dashboard wire harness.
  14. Turn the ignition switch OFF.
  15. Measure the resistance between the No. 8 terminal of OPDS unit 8P connector D and body ground. There should be 0-1.0 ohms. Is the resistance as specified? YES -Go to step 16. NO -Open in the OPDS unit harness or floor wire harness; check the connection at G602 (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-right-branch) ). If the connection is OK, replace the faulty harness.
  16. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  17. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  18. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  19. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 20. NO -Go to step 23 .
  20. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and the No. 7 terminal of OPDS unit 8P connector D. There should be 0-1.0 ohms. Is the resistance as specified? YES -Faulty OPDS unit or SRS unit; replace the OPDS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ). If the problem is still present, replace the OPDS sensor/seat-back (see «FRONT SEAT COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-cover-replacement) ). If problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Go to step 21.
  21. Disconnect the floor wire harness 4P connector C801 from the OPDS unit harness.
  22. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and the No. 4 terminal of floor wire harness 4P connector C801. There should be 0-1.0 ohms. Is the resistance as specified? YES -Open in the OPDS unit harness; replace the OPDS unit harness. NO -Open in the dashboard wire harness or floor wire harness; replace the faulty harness.
  23. Disconnect floor wire harness 4P connector C801 from the OPDS unit harness.
  24. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Short to ground in the OPDS unit harness; replace the OPDS unit harness. NO -Short to ground in the dashboard wire harness or floor wire harness; replace the faulty harness.

DTC 81-61,85-61: No Signal From the ODS Unit ('06-08 models); DTC 81-62,85-62: Response Data Error From the OPDS Unit ('06-08 models)

Note. An incorrect ODS unit can cause DTC 85-63. A new (uninitialized) ODS unit installed with a faulty sensor can also cause DTC 85-71. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 229

Scheme 229: DTC 81-61,85-61: No Signal From the ODS Unit ('06-08 models); DTC 81-62,85-62: Response Data Error F
Scheme 229: DTC 81-61,85-61: No Signal From the ODS Unit ('06-08 models); DTC 81-62,85-62: Response Data Error F

Scheme 230

Scheme 230
Scheme 230

Scheme 231

Scheme 231
Scheme 231

Scheme 232

Scheme 232
Scheme 232

Scheme 233

Scheme 233
Scheme 233

Scheme 234

Scheme 234
Scheme 234

Scheme 235

Scheme 235
Scheme 235

Scheme 236

Scheme 236
Scheme 236

Scheme 237

Scheme 237
Scheme 237

Scheme 238

Scheme 238
Scheme 238

Scheme 239

Scheme 239
Scheme 239
  1. Make sure nothing is on the front passenger's seat.
  2. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  3. Read the DTC (see «DTC (DIAGNOSTIC TROUBLE CODES)»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__dtc-diagnostic-trouble-codes) ). Is DTC 81-61, 85-61, 81-62, or 85-62 indicated? YES -Go to step 4. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  4. Check the connection between ODS unit harness 18P connector D and the ODS unit. Is the connection OK? YES -Go to step 5. NO -Repair the poor connection and retest. If DTC 81-61, 85-61,81-62, or 85-62 is still present, go to step 5.
  5. Turn the ignition switch OFF.
  6. Check the No. 10 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 7. NO -Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 10 (7.5 A) fuse circuit (dashboard wire harness, floor wire harness, or ODS unit harness).
  7. Disconnect ODS unit 18P connector D from the ODS unit.
  8. Turn the ignition switch ON (II).
  9. Measure the voltage between the No. 1 terminal of ODS unit 18P connector D and body ground. There should battery voltage. Is there battery voltage? YES -Go to step 14 . NO -Go to step 10.
  10. Turn the ignition switch OFF.
  11. Disconnect dashboard wire harness 24P connector C501 (A) from the floor wire harness C501 (B).
  12. Turn the ignition switch ON (II).
  13. Measure the voltage between the No. 19 terminal of dashboard wire harness 24P connector and body ground. There should be battery voltage. Is there battery voltage? YES -Open in the WHT wire of the floor wire harness or ODS unit harness; replace the faulty harness. NO -Open in the WHT wire of the dashboard wire harness; replace the dashboard wire harness.
  14. Turn the ignition switch OFF.
  15. Measure the resistance between the No. 12 terminal of the ODS unit 18P connector D and body ground. There should be 0-1.0 ohms. Is the resistance as specified? YES -Go to step 16. NO -Open in the ODS unit harness or floor wire harness; check the connection at G602 (see «FLOOR WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__floor-wire-harness-right-branch) ). If the connection is OK, replace the faulty harness.
  16. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  17. Disconnect both seat belt tensioner 4P connectors (see step 6 ).
  18. Disconnect SRS unit connector B (28P) from the SRS unit (see step 7 ).
  19. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 20. NO -Go to step 23 .
  20. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and the No. 7 terminal of ODS unit 18P connector D. There should be 0-1.0 ohms. Is the resistance as specified? YES -Faulty ODS unit or SRS unit; replace the ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ). If the problem is still present, replace the OPDS sensor/seat-back (see «FRONT SEAT COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-cover-replacement) ). If problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Go to step 21.
  21. Disconnect the floor wire harness 4P connector C801 from the ODS unit harness.
  22. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and the No. 4 terminal of floor wire harness 4P connector C801. There should be 0-1.0 ohms. Is the resistance as specified? YES -Open in the ODS unit harness; replace the ODS unit harness. NO -Open in the floor wire harness; replace the floor wire harness.
  23. Disconnect floor wire harness 4P connector C801 from the ODS unit harness.
  24. Measure the resistance between the No. 27 terminal of SRS unit connector B (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Short to ground in the ODS unit harness; replace the ODS unit harness. NO -Short to ground in the floor wire harness; replace the floor wire harness.

DTC 85-71,85-78: OPDS/ODS Unit Not Initialized

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 85-71, or 85-78 indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Initialize the OPDS/ODS unit (see «OPDS/ODS UNIT INITIALIZATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-initialization) ).
  4. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 second and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Go to step 5.
  5. Replace the OPDS/ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ).
  6. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator go off? YES -The system is OK. NO -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).

DTC 86-1x, 86-2x ("x" can be 0 thru 9 or A thru F): Faulty OPDS Sensor

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC. NOTE: Aftermarket devices (fluorescent lights, laptop computers, etc.) used near the front passenger's seat-back can interfere with the seat-back sensors and cause a false DTC 86-1x or 86-2x. If one of these devices was used, clear the DTC, operate the device near the seat-back, and recheck for DTCs. If DTC 86-1x or 86-2x is reset, clear it, and do not use the device near the seat-back.
  3. Check the connection at the OPDS sensor harness connector and the OPDS/ODS unit connector. Are the connections OK? YES -Go to step 4. NO -Reconnect the OPDS sensor harness connector, and clear the DTC.
  4. Replace the OPDS sensor/seat-back foam (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system) ), and initialize the OPDS/ODS unit (see «OPDS/ODS UNIT INITIALIZATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-initialization) ).
  5. Clear the DTC memory, then check for DTC 86-1x or 86-2x. Is DTC 86-1 x or 86-2x indicated? YES -Replace the OPDS/ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ). NO -The system is OK.

DTC 87-3x ("x" can be 0 thru 9 or A thru F): Side Airbag Cutoff Indicator Stays On/Off

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 240

Scheme 240: DTC 87-3x ("x" can be 0 thru 9 or A thru F): Side Airbag Cutoff Indicator Stays On/Off
Scheme 240: DTC 87-3x ("x" can be 0 thru 9 or A thru F): Side Airbag Cutoff Indicator Stays On/Off

Scheme 241

Scheme 241
Scheme 241

Scheme 242

Scheme 242
Scheme 242

Scheme 243

Scheme 243
Scheme 243

Scheme 244

Scheme 244
Scheme 244

Scheme 245

Scheme 245
Scheme 245

Scheme 246

Scheme 246
Scheme 246

Scheme 247

Scheme 247
Scheme 247

Scheme 248

Scheme 248
Scheme 248

Scheme 249

Scheme 249
Scheme 249

Scheme 250

Scheme 250
Scheme 250
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Make sure nothing is on the front passenger's seat.
  4. Disconnect OPDS unit harness 8P connector ('04-05 models) or ODS unit harness 18P connector ('06-08 models) (A) from the OPDS/ODS unit.
  5. Turn the ignition switch ON (II).
  6. Measure the voltage between the No. 3 terminal of OPDS unit harness 8P connector ('04-05 models) or No. 18 terminal of ODS unit harness 18P connector ('06-08 models) and body ground. There should be battery voltage. '04-05 models '06-08 models Is there battery voltage? YES -Go to step 11 . NO -Go to step 7.
  7. Turn the ignition switch OFF.
  8. Remove the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ). Disconnect gauge control module connector A (22P) from the gauge control module.
  9. Measure the resistance between the No. 3 terminal of OPDS unit harness 8P connector ('04-05 models) or No. 18 terminal of ODS unit harness 18P connector ('06-08 models) and body ground. There should be an open circuit or at least 1Mohms. '04-05 models '06-08 models Is the resistance as specified? YES -Go to step 10. NO -Short to ground in the OPDS/ODS unit harness, floor wire harness or dashboard wire harness; replace the faulty harness.
  10. Measure the resistance between the No. 3 terminal of OPDS unit harness 8P connector ('04-05 models) or No. 18 terminal of CDS unit harness 18P connector ('06-08 models) and No. 10 terminal of gauge control module connector A (22P). There should be 0-1.0 ohms. '04-05 models '06-08 models Is the resistance as specified? YES -Replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ). NO -Open in the OPDS/ODS unit harness, floor wire harness or dashboard wire harness; replace the faulty harness.
  11. Turn the ignition switch OFF.
  12. Remove the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ). Disconnect gauge control module connector A (22P) from the gauge control module.
  13. Measure the voltage between the No. 3 terminal of OPDS unit harness 8P connector ('04-05 models) or No. 18 terminal of ODS unit harness 18P connector ('06-08 models) and body ground. There should be 0.5 V or less. '04-05 models '06-08 models Is there voltage as specified? YES -Faulty OPDS/ODS unit; replace the OPDS/ ODS unit (see «OPDS/ODS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-replacement) ). NO -Short to power in the OPDS/ODS unit harness, floor wire harness or dashboard wire harness; replace the faulty harness.

DTC 91-1x ("x" can be 0 thru 9 or A thru F): Short to Ground in the SRS Indicator Circuit

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 251

Scheme 251: DTC 91-1x ("x" can be 0 thru 9 or A thru F): Short to Ground in the SRS Indicator Circuit
Scheme 251: DTC 91-1x ("x" can be 0 thru 9 or A thru F): Short to Ground in the SRS Indicator Circuit

Scheme 252

Scheme 252
Scheme 252

Scheme 253

Scheme 253
Scheme 253

Scheme 254

Scheme 254
Scheme 254
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 91-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  4. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  5. Remove the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ). Disconnect the gauge control module connector B (18P) from the gauge control module.
  6. Measure the resistance between the No. 19 terminal of SRS unit connector A (28P) and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 7. NO -Short to ground in the dashboard wire harness; replace the dashboard wire harness.
  7. Reconnect the gauge control module connector B (18P).
  8. Measure the resistance between the No. 19 terminal of SRS unit connector A (28P) and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to ground in the SRS indicator circuit of the gauge control module; replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ).

DTC 92-1x ("x" can be 0 thru 9 or A thru F): Open in the Passenger's Airbag Cutoff Indicator ('06-08 models)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 255

Scheme 255: DTC 92-1x ("x" can be 0 thru 9 or A thru F): Open in the Passenger's Airbag Cutoff Indicator ('06-08
Scheme 255: DTC 92-1x ("x" can be 0 thru 9 or A thru F): Open in the Passenger's Airbag Cutoff Indicator ('06-08

Scheme 256

Scheme 256
Scheme 256

Scheme 257

Scheme 257
Scheme 257
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 92-1x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Check the connection between the dashboard wire harness 7P connector and the passenger's airbag cutoff indicator.
  4. Clear the DTC memory.
  5. Check for a DTC. Is DTC 92-1x indicated? YES -Go to step 6. NO -Repair the poor connections and retest. If DTC 92-1x is still present, go to step 6.
  6. Check the No. 21 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 7. NO -Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 21 (7.5 A) fuse circuit (dashboard wire harness).
  7. Disconnect the passenger's airbag cutoff indicator 7P connector.
  8. Turn the ignition switch ON (II).
  9. Check for voltage between the No. 7 terminal of the passenger's airbag cutoff indicator 7P connector and body ground. There should be battery voltage. Is there battery voltage? YES -Go to step 10. NO -Open in the dashboard wire harness; replace the dashboard wire harness.
  10. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  11. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 )
  12. Check resistance between the No. 3 terminal of the passenger's airbag cutoff indicator 7P connector and the No. 20 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or passenger's airbag cutoff indicator; replace the passenger's airbag cutoff indicator. If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Open in the dashboard wire harness; replace the dashboard wire harness.

DTC 92-2x ("x" can be 0 thru 9 or A thru F): Open or Short to Ground in the Passenger's Airbag Cutoff Indicator ('06-08 models)

Note. This DTC can be set if the key is turned on when the passenger's airbag cutoff indicator is unplugged. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 258

Scheme 258: DTC 92-2x ("x" can be 0 thru 9 or A thru F): Open or Short to Ground in the Passenger's Airbag Cutof
Scheme 258: DTC 92-2x ("x" can be 0 thru 9 or A thru F): Open or Short to Ground in the Passenger's Airbag Cutof

Scheme 259

Scheme 259
Scheme 259

Scheme 260

Scheme 260
Scheme 260

Scheme 261

Scheme 261
Scheme 261
  1. Clear the DTC memory (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off/; Does the SRS indicator stay on, and is DTC 92-2x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
  3. Check the connection between the dashboard wire harness 7P connector and the passenger's airbag cutoff indicator.
  4. Clear the DTC memory.
  5. Check for a DTC. Is DTC 92-2x indicated? YES -Go to step 6. NO -Repair the poor connections and retest. If DTC 92-2x is still present, go to step 6.
  6. Check the No. 21 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 7. NO -Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 21 (7.5 A) fuse circuit (dashboard wire harness).
  7. Disconnect the passenger's airbag cutoff indicator 7P connector.
  8. Turn the ignition switch ON (II).
  9. Measure the voltage between the No. 7 terminal of the passenger's airbag cutoff indicator 7P connector and body ground. There should be battery voltage. Is there battery voltage? YES -Go to step 10. NO -Open in the dashboard wire harness; replace the dashboard wire harness.
  10. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  11. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  12. Measure the resistance between the No. 3 terminal of the passenger's airbag cutoff indicator 7P connector and the No. 20 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Go to step 13. NO -Open in the dashboard wire harness; replace the dashboard wire harness.
  13. Measure the resistance between the No. 20 terminal of SRS unit connector A (28P) and body ground. There should be an open circuit or at least 1Mohms. Is the resistance as specified? YES -Check for a faulty SRS unit or passenger's airbag cutoff indicator; replace the passenger's airbag cutoff indicator. If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).l NO -Short to ground in the dashboard wire harness; replace the dashboard wire harness.

DTC A1-1x ("x" can be 0 thru 9 or A thru F); Faulty Power Supply (VA Line)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 262

Scheme 262: DTC A1-1x ("x" can be 0 thru 9 or A thru F); Faulty Power Supply (VA Line)
Scheme 262: DTC A1-1x ("x" can be 0 thru 9 or A thru F); Faulty Power Supply (VA Line)

Scheme 263

Scheme 263
Scheme 263

Scheme 264

Scheme 264
Scheme 264
  1. Check the No. 10 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 2. NO -Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short in the No. 10 (7.5 A) fuse circuit (dashboard wire harness, floor wire harness, or OPDS/ODS unit harness).
  2. Disconnect the negative cable from the battery, then wait for 3 minutes.
  3. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  4. Reconnect the negative cable to the battery.
  5. Connect a voltmeter between the No. 17 terminal of SRS unit connector A (28P) and body ground. Turn the ignition switch ON (II), and measure the voltage. There should be battery voltage. Is there battery voltage? YES -Faulty SRS unit or poor connection at SRS unit connector A (28P) and the SRS unit; check the connection. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Go to step 6.
  6. Turn the ignition switch OFF.
  7. Disconnect under-dash fuse/relay box connector S (2P).
  8. Measure the resistance between the No. 1 terminal of under-dash fuse/relay box connector S (2P) and the No. 17 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Open in the under-dash fuse/relay box or poor contact between connector S (2P) and the under-dash fuse/relay box; check the connection. If the connection is OK, replace the under-dash fuse/ relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/i-2003-2008/remont/body-electrical/#under-dash-fuserelay-box__removal-and-installation) ). NO -Open in the dashboard wire harness; replace the dashboard wire harness.

DTC A2-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VB Line)

Note. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Scheme 265

Scheme 265: DTC A2-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VB Line)
Scheme 265: DTC A2-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VB Line)

Scheme 266

Scheme 266
Scheme 266

Scheme 267

Scheme 267
Scheme 267
  1. Check the No. 22 (10 A) fuse in the under-dash fuse/relay box. Is the fuse OK? YES -Go to step 2. NO -Replace the fuse, then turn the ignition switch ON (II). If the fuse blows again, check for a short to ground in the under-dash fuse/relay box No. 22 (10 A) fuse line, in dashboard wire harness; replace the under-dash fuse/relay box.
  2. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  3. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  4. Reconnect the negative cable to the battery.
  5. Connect a voltmeter between the No. 18 terminal of SRS unit connector A (28P) and body ground. Turn the ignition switch ON (II), and measure the voltage. There should be battery voltage. Is there battery voltage? YES -Faulty SRS unit or poor contact at SRS unit connector A (28P) and the SRS unit; check the connection. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Go to step 6.
  6. Turn the ignition switch OFF.
  7. Disconnect under-dash fuse/relay box connector S (2P).
  8. Measure the resistance between the No. 2 terminal of the under-dash fuse/relay box connector S (2P) and the No. 18 terminal of SRS unit connector A (28P). There should be 0-1.0 ohms. Is the resistance as specified? YES -Open in the under-dash fuse/relay box or poor contact between connector S (2P) and the under-dash fuse/relay box; check the connection. If the connection is OK, replace the under-dash fuse/ relay box (see «REMOVAL AND INSTALLATION»(/acura/tsx/i-2003-2008/remont/body-electrical/#under-dash-fuserelay-box__removal-and-installation) ). NO -Open in the dashboard wire harness; replace the dashboard wire harness.

SRS indicator does not come on

Note. Perform the gauge self test before beginning troubleshooting (see SELF-DIAGNOSTIC FUNCTION ).

Scheme 268

Scheme 268: SRS indicator does not come on
Scheme 268: SRS indicator does not come on

Scheme 269

Scheme 269
Scheme 269

Scheme 270

Scheme 270
Scheme 270

Scheme 271

Scheme 271
Scheme 271

Scheme 272

Scheme 272
Scheme 272
  1. Turn the ignition switch ON (II), and see if the other indicators come on (brake system, etc.). Do the other indicators come on? YES -Go to step 2. NO -Go to step 9 .
  2. Turn the ignition switch OFF, then remove the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ). Disconnect gauge control module connectors A and B from the gauge control module.
  3. Measure the resistance between the No. 18 terminal of gauge control module connector B (18P) and body ground. There should be 0-1.0 ohms. Is the resistance as specified? YES -Go to step 4. NO -Open in the dashboard wire harness or junction connector, or faulty body ground terminal (G503) (see «DASHBOARD WIRE HARNESS (RIGHT BRANCH)»(/acura/tsx/i-2003-2008/remont/body-electrical/#connectors-and-harnesses__dashboard-wire-harness-right-branch) ). If the body ground terminal is OK, replace the dashboard wire harness.
  4. Measure the voltage between the No. 7 terminal of gauge control module connector B (18P) and body ground within the first 6 seconds after turning the ignition switch ON (II). There should be about 1.0 V for 6 seconds and then about 11 V. Is the voltage as specified? YES -Faulty SRS indicator circuit in the gauge control module; replace the gauge control module. NO -Go to step 5.
  5. Turn the ignition switch OFF. Disconnect the negative cable from the battery, then wait for 3 minutes.
  6. Disconnect SRS unit connector A (28P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  7. Reconnect the negative cable to the battery.
  8. Connect a voltmeter between the No. 7 terminal of gauge control module connector B (18P) and body ground. Turn the ignition switch ON (II), and measure the voltage. There should be 0.5 V or less. Is the voltage as specified? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Short to power in the dashboard wire harness or junction connector; replace the dashboard wire harness.
  9. Turn the ignition switch OFF. Check the No. 21 (7.5 A) fuse in the under-dash fuse/relay box. Is the fuse blown? YES -Go to step 11 . NO -Go to step 10.
  10. Connect a voltmeter between the No. 10 terminal of the gauge control module connector B (18P) and body ground. Turn the ignition switch ON (II), and measure the voltage. There should be battery voltage. Is there battery voltage? YES -Faulty SRS indicator circuit in the gauge control module or poor contact at gauge control module connector B (18P) and the gauge control module; if the connection is OK, replace the gauge control module. NO -Open in the under-dash fuse/relay box No. 21 (7.5 A) fuse circuit, or open in the YEL wire of the dashboard wire harness or junction connector. If the under-dash fuse/relay box is OK, replace the dashboard wire harness.
  11. Replace the No. 21 (7.5 A) fuse, then check to see if the indicators comes on. Do the indicators come on? YES -The system is OK at this time. NO -Repair the short to ground in the under-dash fuse/relay box No. 21 (7.5 A) fuse circuit.

SRS indicator stays on, but no DTCs are stored

Note. If you cannot retrieve DTCs with the HDS using the SRS menu method, retrieve flash codes with the HDS in SCS mode. A new SRS unit must sense the entire system is OK before completing its initial self-test. The most common cause of an incomplete self-test is the failure to replace all deployed parts after a collision, in particular seat belt tensioners (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). A battery/system voltage above 15.2 V can cause the SRS indicator to come on without storing any DTCs.

Scheme 273

Scheme 273: SRS indicator stays on, but no DTCs are stored
Scheme 273: SRS indicator stays on, but no DTCs are stored

Scheme 274

Scheme 274
Scheme 274

Scheme 275

Scheme 275
Scheme 275
  1. Disconnect the negative cable from the battery, then wait for 3 minutes.
  2. Disconnect SRS unit connector A (28P) from the SRS unit (see step 7 ).
  3. Remove the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/i-2003-2008/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ). Disconnect gauge control module connector B (18P) from the gauge control module.
  4. Measure the resistance between the No. 7 terminal of gauge control module connector B (18P) and the No. 19 terminal of SRS unit connector A (28P). There should be 1 ohms or less. Is the resistance as specified? YES -Go to step 5. NO -Open in the dashboard wire harness; replace the dashboard wire harness.
  5. Reconnect the negative cable to the battery.
  6. Reconnect gauge control module connector A (18P) to the gauge control module.
  7. Turn the ignition switch ON (II).
  8. Install a jumper wire between the No. 7 terminal and the No. 10 terminal of the gauge control module connector B (18P). The SRS indicator should go off. Does the SRS indicator go off? YES -Faulty SRS unit or poor connection at SRS unit connector A (18P) and the SRS unit; check the connection. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ). NO -Faulty SRS indicator circuit in the gauge control module or poor connection at gauge control module connector A (18P); check the connection. If the connection is OK, replace the gauge control module.

Component Replacement/Inspection After Deployment

Note. Before doing any SRS repairs, use the HDS SRS menu method to check for DTCs; refer to the DTC TROUBLESHOOTING INDEX for the less obvious deployed parts (seat belt tensioners, front impact sensors, side impact sensors, etc.). Do not replace the OPDS/ODS unit unless it is physically damaged or a specific fault was found during DTC troubleshooting.

After a collision where the seat belt tensioners deployed, replace these items

  1. SRS unit
  2. Seat belt tensioners
  3. Front impact sensors

After a collision where the front airbag(s) deployed, replace these items

  1. SRS unit
  2. Deployed airbag(s)
  3. Seat belt tensioners
  4. Front impact sensors

After a collision where the side airbag(s) deployed, replace these items

  1. SRS unit
  2. Deployed side airbag(s)
  3. Reinforcing cloth rear hooks
  4. Side impact sensor(s) (first) for the side(s) that deployed

After a collision where a side curtain airbag has deployed, replace the items for the side(s) that deployed

  1. SRS unit
  2. Deployed side curtain airbag(s)
  3. Side impact sensor(s) (first)
  4. Side impact sensor(s) (second)
  5. Roof trim
  6. A-pillar trim
  7. B-pillar trim
  8. C-pillar trim
  9. Front grab handle
  10. Sunvisor
  11. Any related trim clips

After a moderate to severe side or rear collision, inspect for damage on the side curtain airbag or other related components. Replace the components as needed.

A-pillar trim

Scheme 276

Scheme 276
Scheme 276

B-pillar trim

Scheme 277

Scheme 277
Scheme 277

C-pillar trim

Scheme 278

Scheme 278
Scheme 278

During the repair process, inspect these areas

  1. Inspect all the SRS wire harnesses. Replace, do not repair, any damaged harnesses.
  2. Inspect the cable reel for heat damage. If there is any damage, replace the cable reel.

After the vehicle is completely repaired, turn the ignition switch ON (II). If the SRS indicator comes on for about 6 seconds and then goes off, the SRS is OK. If the indicator does not function properly, use the HDS SRS Menu Method to read the DTC (see DTC (DIAGNOSTIC TROUBLE CODES) ).

Checking and Adjusting the Headliner/Pillar Trim Overlap

To prevent the side curtain airbag from deploying and damaging the pillar trim, the overlap between the headliner and pillar trim must be less then 15 mm (0.6 in.). To check the overlap, do this

Scheme 279

Scheme 279: Checking and Adjusting the Headliner/Pillar Trim Overlap
Scheme 279: Checking and Adjusting the Headliner/Pillar Trim Overlap

Scheme 280

Scheme 280
Scheme 280

Scheme 281

Scheme 281
Scheme 281

Scheme 282

Scheme 282
Scheme 282
  1. Install the headliner (A) and the pillar trim (B).
  2. Using masking tape on the headliner, mark the upper edge of each pillar trim.
  3. Remove the pillar trim, and measure the headliner overlap. If the overlap is less than 15 mm (0.6 in.), remove the tape, and install the pillar trim. If the overlap is more than 15 mm (0.6 in.), go to step 4.
  4. Carefully trim the headliner with a utility knife, reducing the overlap to less than 15 mm (0.6 in.).
  5. Remove the tape, and install the pillar trim.

Scheme 283

Scheme 283: Removal
Scheme 283: Removal

Scheme 284

Scheme 284
Scheme 284
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Remove the access panel (A) from the steering wheel, then disconnect the driver's airbag 4P connector (B) from the cable reel.
  3. Using a TORX T30 bit, remove the two TORX bolts (A).
  4. Disconnect the horn switch connector (1P), then remove the driver's airbag (B).

Scheme 285

Scheme 285: Installation
Scheme 285: Installation

Scheme 286

Scheme 286
Scheme 286
  1. Connect the horn switch connector (1P) (A) to the driver's airbag.
  2. Place the new driver's airbag (B) in the steering wheel, and secure it with new TORX bolts (C).
  3. Connect the cable reel 4P connector (A) to the driver's airbag 4P connector, then install the access panel (B) on the steering wheel.
  4. Reconnect the negative cable to the battery.
  5. After installing the airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off. Make sure the horn works.

Front Passenger's Airbag Replacement

Special Tools Required

Airbag protector 070AG-SEA0100

Removal

Note. If the front passenger's airbag has been deployed, refer to REPLACEMENT FOR AFTER A COLLISION WHERE THE FRONT PASSENGER'S AIRBAG DEPLOYED .

Scheme 287

Scheme 287: Removal
Scheme 287: Removal

Scheme 288

Scheme 288
Scheme 288
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Remove the glove box and dashboard lower cover (see «PASSENGER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ), striker bracket, and front passenger's air conditioning duct (see «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  3. Disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness.
  4. Remove the mounting nuts (A) and bolts (B) from the bracket. Remove the front passenger's airbag (C).

Installation

Note. Some new airbags come equipped with an airbag protector. Do not remove the protector before installation. Install the front passenger's airbag with the airbag protector cover as an assembly. Make sure the fabric of the airbag is not twisted or sticking out of the inflator. Keep the airbag clean, and do not unfold or tamper with the airbag fabric. If the fabric is twisted or sticking out of the inflator, do not use the airbag; replace it with a new one.

Scheme 289

Scheme 289: Installation
Scheme 289: Installation

Scheme 290

Scheme 290
Scheme 290

Scheme 291

Scheme 291
Scheme 291

Scheme 292

Scheme 292
Scheme 292

Scheme 293

Scheme 293
Scheme 293

Scheme 294

Scheme 294
Scheme 294
  1. If you are re-using the existing front passenger's airbag, or your new airbag did not come with an airbag protector, go to step 2. If your new airbag has an airbag protector, go to step 4 .
  2. Install the airbag protector slots (A) onto the airbag clips (B).
  3. Wrap the airbag protector over the airbag, and slide the slots (A) of the protector around the tabs on the airbag frame. Align the two pins (B) on the airbag frame into the two holes in the airbag protector.
  4. Place the new front passenger's airbag with the airbag protector (A) into the mounting bracket on the dashboard, and install the center nut (B) by hand. Do not fully tighten it.
  5. Remove the lower hooks of the airbag protector (A) from the front passenger's airbag (B), and pull out the protector.
  6. Tighten the front passenger's airbag mounting nuts (A) and bolts (B) to the specified torque.
  7. Connect the front passenger's airbag 4P connector (A) to the dashboard wire harness, then reinstall the glove box and dashboard lower cover.
  8. Reconnect the negative cable to the battery.
  9. Connect the HDS, and clear the DTCs.
  10. After installing the airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Scheme 295

Scheme 295: Replacement for after a collision where the front passenger's airbag deployed
Scheme 295: Replacement for after a collision where the front passenger's airbag deployed

Scheme 296

Scheme 296
Scheme 296

Scheme 297

Scheme 297
Scheme 297

Scheme 298

Scheme 298
Scheme 298

Scheme 299

Scheme 299
Scheme 299
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Remove the dashboard assembly out of the vehicle (see «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ), then remove the glove box striker and front passenger's air conditioning duct (see «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  3. Remove the dashboard upper panel from the lower panel (see «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  4. Install the new dashboard upper panel to the lower panel (see «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  5. With the dashboard upside-down, remove the protective cover from the new dashboard upper panel.
  6. Place the new front passenger's airbag with the airbag protector (A) into the mounting bracket on the dashboard, and install the center nut (B) by hand. Do not fully tighten it. NOTE: Be sure to use the airbag protector when installing the front passenger's airbag. Be sure to install the front passenger's airbag so it does not interfere with other parts. Be careful not to damage the airbag. Be sure to keep the new airbag clean, and do not unfold or tamper with the cloth cover on the airbag.
  7. Remove the lower hooks of the airbag protector (A) from the front passenger's airbag (B), and pull out the protector.
  8. Tighten the front passenger's airbag mounting nuts (A) and bolts (B) to the specified torque.
  9. Install the dashboard assembly (see «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  10. Connect the front passenger's airbag 4P connector (A) to the dashboard wire harness, then install all removed parts in the reverse order of removal.
  11. Reconnect the negative cable to the battery.
  12. Connect the HDS and clear the DTCs.
  13. After installing the airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Side Airbag Replacement

Note. Review the seat replacement procedure (see FRONT SEAT REMOVAL/INSTALLATION ) before performing repairs or service.

Scheme 300

Scheme 300: Removal
Scheme 300: Removal

Scheme 301

Scheme 301
Scheme 301
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Disconnect the side airbag harness 2P connectors (A).
  3. Remove the seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ) and seat-back cover (see «FRONT SEAT COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-cover-replacement) ). NOTE: If you are replacing a deployed airbag, replace the reinforcing cloth rear hooks (A).
  4. Remove the mounting nut (B) and the side airbag (C).

Note. If the side airbag lid is secured by a tape, remove the tape. Do not open the lid of the side airbag cover. Use a new mounting nut tightened to the specified torque. Make sure that the seat-back cover is installed properly. Improper installation may prevent proper deployment. Be sure to install the harness wires so that they are not pinched or interfering with other parts.

Scheme 302

Scheme 302: Installation
Scheme 302: Installation
  1. Place the new side airbag on the seat-back frame (A). Tighten the new side airbag mounting nut (B).
  2. Install the seat-back cover in the reverse order of removal (see «FRONT SEAT COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-cover-replacement) ). NOTE: If you are replacing a deployed airbag, replace the reinforcing cloth rear hooks.
  3. Install the seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ), then connect the side airbag harness 2P connector.
  4. Move the front seat and the seat-back through their full ranges of movement, making sure the harness wires are not pinched or interfering with other parts.
  5. Reconnect the negative cable to the battery.
  6. Connect the HDS and clear the DTCs (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  7. After installing the side airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Note. Review the interior trim replacement procedure before doing repair or service. Removal of the side curtain airbag must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). The side curtain airbag system consists of many components. When the side curtain airbag has been deployed, go to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT , and replace all of the parts listed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ).

Scheme 303

Scheme 303: Removal
Scheme 303: Removal

Scheme 304

Scheme 304
Scheme 304
  1. Disconnect the negative cable from the battery, then wait for 3 minutes starting work.
  2. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
  3. For left side curtain airbag replacement, remove the AM/FM antenna amplifier/defogger coil (see «AM/FM ANTENNA AMPLIFIER-REAR WINDOW DEFOGGER COIL REPLACEMENT»(/acura/tsx/i-2003-2008/remont/entertainment-systems/#audio-system) ).
  4. Disconnect the side curtain airbag harness 2P connector (A) from the side curtain airbag. Left side shown; right side is similar.
  5. Remove the mounting bolts (A) from the brackets. Left side shown; right side is similar.
  6. Remove the side curtain airbag assembly.

Note. Installation of the side curtain airbag must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). If the airbag is frayed, or has only other visible damage, replace it. Do not attempt to repair an airbag. When you install the airbag, make sure it is not twisted, and that it is not caught between the inflator bracket by the bracket bolts. Make sure that the side curtain airbag inflator retainer is installed properly, otherwise the airbag could deploy improperly and cause damage or injuries. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.

Scheme 305

Scheme 305: Installation
Scheme 305: Installation

Scheme 306

Scheme 306
Scheme 306
  1. Place the new side curtain airbag assembly on the side of the roof. Tighten the side curtain airbag mounting bolts (A). Left side shown; right side is similar.
  2. Connect the side curtain airbag harness 2P connector (A) to the side curtain airbag. Left side shown; right side is similar.
  3. Reconnect the negative cable to the battery.
  4. Connect the HDS to the DLC, and clear the DTCs (see «CLEAR THE DTC MEMORY WITH THE HDS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__clear-the-dtc-memory-with-the) ).
  5. After installing the side curtain airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.
  6. Install all removed parts.
  7. Confirm proper headliner/pillar trim overlap (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ).

Airbag and Tensioner Disposal

Special Tools Required

Deployment tool 07HAZ-SG00500

Before scrapping any airbags, side airbags, side curtain airbags, or seat belt tensioners (including those in a whole vehicle to be scrapped), the part(s) must be deployed. If the vehicle is still within the warranty period, the Acura District Parts and Service Manager must give approval and/or special instruction before deploying the part(s). Only after the part(s) have been deployed (as the result of vehicle collision, for example), can they be scrapped.

If the parts appear intact (not deployed), treat them with extreme caution. Follow this procedure.

Deploying Airbags in the Vehicle

If an SRS equipped vehicle is to be entirely scrapped, its airbags, side airbags, side curtain airbags, and seat belt tensioners should be deployed while still in the vehicle. These parts should not be considered as salvageable parts and should never be installed in another vehicle.

Scheme 307

Scheme 307: Deploying Airbags in the Vehicle
Scheme 307: Deploying Airbags in the Vehicle

Scheme 308

Scheme 308
Scheme 308

Scheme 309

Scheme 309
Scheme 309

Scheme 310

Scheme 310
Scheme 310

Scheme 311

Scheme 311
Scheme 311

Scheme 312

Scheme 312
Scheme 312

Scheme 313

Scheme 313
Scheme 313
  1. Turn the ignition switch OFF, then disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Confirm that each airbag, side airbag, side curtain airbags, or seat belt tensioner is securely mounted.
  3. Confirm that the deployment tool is functioning properly by following the check procedure on the tool label. Driver's Airbag
  4. Remove the access panel (A) from the steering wheel then disconnect the driver's airbag 4P connector (B) from the cable reel. Front Passenger's Airbag
  5. Remove the glove box, then disconnect the front passenger's airbag 4P connector (A) from the dashboard wire harness. Side Airbag
  6. Disconnect the side airbag 2P connector (A) from the floor wire harness. Side Curtain Airbag
  7. Disconnect the side curtain airbag harness 2P connector (A) from the side curtain airbag. Seat Belt Tensioner
  8. Disconnect the floor wire harness 4P connector (A) from the seat belt tensioner. Pull the seat belt out all the way and cut it.
  9. Cut off each connector, strip the ends of the wires. Twist each pair of unlike colored wires together, and clip an alligator clips (A) to each pair. Place the deployment tool at least 30 feet (10 meters) away from the vehicle. NOTE: The driver's and front passenger's airbags have dual inflators. The like colored wires go to the individual inflators.
  10. Connect a 12 volt battery to the deployment tool. If the green light on the tool comes on, the igniter circuit is defective and cannot deploy the component. Go to «DISPOSAL OF DAMAGED COMPONENTS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disposal-of-damaged-components) . If the red light on the tool comes on, the component is ready to be deployed.
  11. Push the tool's deployment switch. The airbags and tensioners should deploy (deployment is both highly audible and visible: a loud noise and rapid inflation of the bag, followed by slow deflation). If the components deploy and the green light on the tool comes on, continue with this procedure. If a component does not deploy, and the green light comes ON, its igniter is defective. Go to «DISPOSAL OF DAMAGED COMPONENTS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disposal-of-damaged-components) . During deployment, the airbags can become hot enough to burn you. Wait for 30 minutes after deployment before touching the airbags.
  12. Dispose of the complete airbag. No part of it can be reused. Place it in a sturdy plastic bag (A), and seal it securely. Dispose of the deployed airbag according to your local regulations.

Deploying Components Out of the Vehicle

If an intact airbag or tensioner has been removed from a scrapped vehicle, or has been found defective or damaged during transit, storage, or service, it should be deployed as follows

Scheme 314

Scheme 314: Deploying Components Out of the Vehicle
Scheme 314: Deploying Components Out of the Vehicle
  1. Confirm that the deployment tool is functioning properly by following the check procedure on the tool label.
  2. Position the airbag face up, outdoors, on flat ground, at least 30 feet (10 meters) from any obstacles or people.
  3. Follow steps 9 through 12 of Deploying Airbags in the vehicle. NOTE: The driver's and front passenger's airbags have dual inflators. The like colored wires go to the individual inflators.

Disposal of Damaged Components

  1. If installed in a vehicle, follow the removal procedure for the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ), front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ), side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__side-airbag-replacement) ), side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ), and seat belt tensioner (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/i-2003-2008/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ).
  2. In all cases, make a short circuit by cutting, stripping, and twisting together the two inflator wires. NOTE: The driver's and front passenger's airbags have dual inflators. The like colored wires go to the individual inflators.
  3. Package the component in exactly the same packaging that the new replacement part came in.
  4. Mark the outside of the box "DAMAGED AIRBAG NOT DEPLOYED," "DAMAGED SIDE AIRBAG NOT DEPLOYED," "DAMAGED SIDE CURTAIN AIRBAG NOT DEPLOYED," and "DAMAGED SEAT BELT TENSIONER NOT DEPLOYED," so it does not get confused with your parts stock.
  5. Contact your Acura District Parts and Service Manager for how and where to return it for disposal.

Deployment Tool Check

  1. Connect the yellow clips to both switch protector handles on the tool.
  2. Then connect the red lead to the positive battery post and the black lead to the negative battery post.
  3. Push the operation switch: The green light should come on, indicating that the tool is operating properly and is ready for use. If the red light stays on, the tool is faulty, and another one must be used for the procedure.
  4. Disconnect the tool clips and connectors from the protector handles and the battery.

Scheme 315

Scheme 315: Removal
Scheme 315: Removal

Scheme 316

Scheme 316
Scheme 316

Scheme 317

Scheme 317
Scheme 317

Scheme 318

Scheme 318
Scheme 318

Scheme 319

Scheme 319
Scheme 319
  1. Make sure the front wheels are aligned straight ahead.
  2. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  4. Disconnect the connector (A) from the cable reel, then remove the steering wheel bolt (B).
  5. Confirm that the front wheels point straight ahead, then remove the steering wheel with a steering wheel puller (see step 6 on «STEERING WHEEL REMOVAL»(/acura/tsx/i-2003-2008/remont/manual-power-steering/#power-steering-system__steering-wheel-removal) ). Do not tap on the steering wheel or steering column shaft when removing the steering wheel.
  6. Remove the dashboard lower cover (A).
  7. Remove the column cover screws (A), then remove the column covers (B, G).
  8. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector (B), then disconnect the dashboard wire harness 13P connector (C) from the cable reel (D).
  9. Release the lock tab (A) under the cable reel connector with a 90° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 320

Scheme 320: Installation
Scheme 320: Installation

Scheme 321

Scheme 321
Scheme 321

Scheme 322

Scheme 322
Scheme 322

Scheme 323

Scheme 323
Scheme 323
  1. Before installing the steering wheel, align the front wheels straight ahead.
  2. If not already done, disconnect the negative cable from the battery, and wait at least 3 minutes.
  3. Set the turn signal canceling sleeve (A) so that the projections (B) are aligned vertically.
  4. Carefully install the cable reel (A) on the steering column shaft. Then connect 13P connector (B) to the cable reel, and connect the 4P connector (C) to the dashboard wire harness 4P connector (D).
  5. Install the steering column covers.
  6. If necessary, center the cable reel (New replacement cable reels come centered.). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise (about 2 1/2-3 turns) until the arrow mark (A) on the cable reel label points straight up.
  7. Align the projections on the cable reel with the holes on the steering wheel (see step 3 on «STEERING WHEEL REMOVAL»(/acura/tsx/i-2003-2008/remont/manual-power-steering/#power-steering-system__steering-wheel-removal) ). Install the steering wheel with a new steering wheel bolt (A), then reconnect the connector (B).
  8. Install the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  9. Reconnect the negative cable to the battery.
  10. Connect the HDS to the DLC, and clear the DTCs.
  11. After installing the cable reel, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off. After the SRS indicator has turned off, turn the steering wheel fully left and right to confirm the SRS indicator does not come on. Make sure the horn and turn signal switches work properly. Make sure the steering wheel switches work properly. Make sure the steering wheel is centered. Make sure there are no DTCs.

Note. If you are disconnecting only SRS unit connector A, skip step 2 .

Scheme 324

Scheme 324: Removal
Scheme 324: Removal
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Disconnect both seat belt tensioner connectors (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  3. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
  4. Remove the rear vent ducts (see step 4 on «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  5. Disconnect SRS unit connector A (28P), SRS unit connector B (28P), SRS unit connector C (16P), and remove the TORX bolts (D), then pull out the SRS unit.

Scheme 325

Scheme 325: Installation
Scheme 325: Installation
  1. Install the new SRS unit (A) with TORX bolts (B), then connect the connectors (C) to the SRS unit; push them into position until they click. NOTE: Be sure the SRS unit is sitting squarely against its bracket before torquing the TORX bolts.
  2. Reconnect both seat belt tensioner connectors (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  3. Reconnect the negative cable to the battery.
  4. Initialize the OPDS unit (see «OPDS/ODS UNIT INITIALIZATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-initialization) ). NOTE: This is necessary for registration of serial IDs.
  5. Install all removed parts.
  6. After installing the SRS unit, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Side Impact Sensor (First) Replacement

Note. Review the seat replacement procedure before doing repairs or service.

Scheme 326

Scheme 326: Removal
Scheme 326: Removal
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Disconnect the appropriate side airbag 2P connector (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  3. Remove the seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  4. Remove the front door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) and the B-pillar lower trim panel (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ).
  5. Disconnect the floor wire harness 2P connector from the side impact sensor (first).
  6. Using a TORX T30 bit, remove the TORX bolts (A), then remove the side impact sensor (first) (B).

Scheme 327

Scheme 327: Installation
Scheme 327: Installation
  1. Install the new side impact sensor (first) (A) with the TORX bolts (B), then connect the floor wire harness 2P connector (C) to the side impact sensor (first).
  2. Reconnect the negative cable to the battery.
  3. Install all removed parts.
  4. After installing the side impact sensor (first), confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Scheme 328

Scheme 328: Removal
Scheme 328: Removal
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Disconnect the appropriate side curtain airbag 2P connector (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  3. Disconnect the side impact sensor (second) 2P connector (A) from the side curtain airbag harness.
  4. Using a TORX T30 bit, remove the TORX bolts (B), then remove the side impact sensor (second) (C).

Scheme 329

Scheme 329: Installation
Scheme 329: Installation
  1. Install the new side impact sensor (second) (A) with the TORX bolts (B), then connect the side curtain airbag harness 2P connector (C) to the side impact sensor (second).
  2. Reconnect the negative cable to the battery.
  3. Install all removed parts.
  4. After installing the side impact sensor (second), confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

OPDS/ODS Unit Replacement

Note. Review the seat replacement procedure (see FRONT SEAT REMOVAL/INSTALLATION ) before doing repairs or service.

Scheme 330

Scheme 330: Removal
Scheme 330: Removal
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Disconnect the front passenger's side airbag harness 2P connector (see step 3 ).
  3. Remove the front passenger's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ) and seat-back cover (see «FRONT SEAT COVER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-cover-replacement) ).
  4. Remove the cover (A), then disconnect the OPDS unit 8P/ODS unit 18P connector (B) and sensor connectors (C) from the OPDS/ODS unit (D).
  5. Remove the two screws (E) and the OPDS/ODS unit.

Scheme 331

Scheme 331: Installation
Scheme 331: Installation
  1. Place the new OPDS/ODS unit (A) on the seat-back frame. Tighten the two screws (B), and connect the OPDS unit harness 8P/ODS unit harness 18P connector (C) and sensor connectors (D) to the OPDS/ODS unit. Reinstall the cover (E).
  2. Install the seat-back cover in the reverse order of removal.
  3. Install the front passenger's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ), then connect the side airbag harness 2P connector.
  4. Reconnect the negative cable to the battery.
  5. Set the seat-back in the normal position, and make sure there is nothing on the front passenger's seat.
  6. Initialize the OPDS/ODS unit (see «OPDS/ODS UNIT INITIALIZATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__opdsods-unit-initialization) ).
  7. Calibrate the ODS unit ('06-08 models) (see «ODS UNIT CALIBRATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  8. After installing the OPDS/ODS unit, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Scheme 332

Scheme 332: Removal
Scheme 332: Removal

Scheme 333

Scheme 333
Scheme 333
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Disconnect the driver's airbag 4P connector (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ), the front passenger's airbag 4P connector (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ), and both seat belt tensioner 4P connectors (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  3. Remove the front inner fender ('04-05 models) (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ) or the splash shield ('06-08 models) (see «SPLASH SHIELD REPLACEMENT»(/acura/tsx/i-2003-2008/remont/exterior-body-panels/#fenderwell__splash-shield-replacement) ).
  4. Disconnect the engine compartment wire harness 2P connector (A), and using a TORX T30 bit remove the two TORX bolts (B), then remove the front impact sensor (C). '04-05 models '06-08 models

Scheme 334

Scheme 334: Installation
Scheme 334: Installation

Scheme 335

Scheme 335
Scheme 335
  1. Install the new front impact sensor with new TORX bolts (A), then connect the engine compartment wire harness 2P connector (B) to the front impact sensor (C). '04-05 models '06-08 models
  2. Reconnect the driver's airbag 4P connector (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ), the front passenger's airbag 4P connector (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ), and both seat belt tensioner 4P connectors (see «DISCONNECTING SYSTEM CONNECTORS»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system__disconnecting-system-connectors) ).
  3. Reconnect the negative cable to the battery.
  4. Install all removed parts.
  5. After installing the front impact sensor, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come on for about 6 seconds and then go off.

Removal ('06-08 models)

Note. Removal of the front passenger's weight sensors must be done according to Precautions and Procedures.

Scheme 336

Scheme 336: Removal ('06-08 models)
Scheme 336: Removal ('06-08 models)
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Remove the front passenger's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  3. Remove the cushion cover/pad from the seat cushion frame (see «SEAT CUSHION COVER»(/acura/tsx/i-2003-2008/remont/seats/#seat-system) ).
  4. Using the TORX T30 bit and T40 bit, remove the tamper-resistant TORX bolts (A) attaching the seat track (B) to the weight sensors (C).
  5. Disconnect the sensor connectors (D) (3P), E (2P) from the ODS unit harness, then remove the front passenger's weight sensors.

Installation ('06-08 models)

Note. Be sure to install the harness wires so they are not pinched or interfere with other parts. Make sure both of the rivets (A) on the seat track are properly secured to the front bracket (B). If the hooks are not properly secured, the front passenger's weight sensors will not function properly.

Scheme 337

Scheme 337: Installation ('06-08 models)
Scheme 337: Installation ('06-08 models)
  1. Install the new front passenger's weight sensors with 6 mm TORX bolts (C) and 8 mm TORX bolts (D) under the seat track.
  2. Tightening the TORX bolts, begin with the (1) and tighten them in criss-cross pattern in two or more steps.
  3. Reassemble the front passenger's seat cushion cover/pad (see «SEAT CUSHION COVER»(/acura/tsx/i-2003-2008/remont/seats/#seat-system) ).
  4. Reinstall the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  5. Reconnect the negative cable to the battery.
  6. Calibrate the ODS unit (see «ODS UNIT CALIBRATION»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).
  7. After installing the front passenger's weight sensors, confirm proper system operation: Turn the ignition switch ON (II); the SRS indicator should come for about 6 seconds and then go off.

Note. Removal of the driver's seat position sensor must be performed according to the precautions/procedures described at the beginning of SRS (see PRECAUTIONS AND PROCEDURES ). Before disconnecting the driver's seat position sensor 2P connector, disconnect the driver's airbag 4P connector. Do not turn the ignition switch ON (II), and do not connect the battery negative cable while removing the driver's seat position sensor.

Scheme 338

Scheme 338: Removal ('06-08 models)
Scheme 338: Removal ('06-08 models)
  1. Disconnect the negative cable from the battery, then wait for 3 minutes before starting work.
  2. Remove the driver's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  3. Disconnect the floor wire harness or seat position sensor harness 2P connector (A) from the driver's seat position sensor.
  4. Remove the TORX bolt (B), then remove the driver's seat position sensor.

Note. Be sure to install the harness wires so they are not pinched or interfering with other parts. Do not turn the ignition switch ON (II), and do not connect the battery negative cable while installing the driver's seat position sensor. After installing the driver's seat position sensor, make sure it is clean. Keep it away from dust.

Scheme 339

Scheme 339: Installation ('06-08 models)
Scheme 339: Installation ('06-08 models)
  1. Install the new driver's seat position sensor with a TORX bolt (A), then connect the floor wire harness or seat position sensor harness 2P connector (B) to the driver's seat position sensor.
  2. Install the driver's seat assembly (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/seats/#seat-system__front-seat-removalinstallation) ).
  3. Reconnect the negative cable to the battery.
  4. Check the operation of the driver's seat position sensor with the HDS (see «DRIVER'S SEAT POSITION SENSOR OPERATION CHECK»(/acura/tsx/i-2003-2008/remont/airbag/#srs-supplemental-restraint-system) ).

Scheme 340

Scheme 340: '06-08 models
Scheme 340: '06-08 models
  1. Remove the upper panel (see «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(/acura/tsx/i-2003-2008/remont/exteriorinterior-trim/#dashboard) ).
  2. Push out the passenger's airbag cutoff indicator (A) from behind the dashboard center vent.
  3. Disconnect the 7P connector (B) from the passenger's airbag cutoff indicator.
  4. Check for continuity between the No. 1 and No. 6 terminals of the indicator. If there is no continuity, replace the bulbs (C). NOTE: Both illumination bulbs are connected in parallel. If there is continuity, remove the lower hazard switch illumination bulb, and recheck for continuity. If there is no continuity, replace the passenger's airbag cutoff indicator illumination bulb.
  5. Install the parts in the reverse order of removal.

See also:
• GLOVE BOX REMOVAL/INSTALLATION
• C-PILLAR TRIM
• B-PILLAR UPPER/LOWER TRIM
• CENTER CONSOLE REMOVAL/INSTALLATION
• DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION
• DLC CIRCUIT TROUBLESHOOTING
• '07-08 MODELS
• BATTERY TEST
• ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING
• FRONT SEAT BELT REPLACEMENT
• ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH)
• SEAT BELT BUCKLE
• FLOOR WIRE HARNESS (LEFT BRANCH)
• FLOOR WIRE HARNESS (RIGHT BRANCH)
• FRONT SEAT REMOVAL/INSTALLATION
• FRONT SEAT COVER REPLACEMENT
• FRONT SEAT RECLINE MOTOR REPLACEMENT
• GAUGE CONTROL MODULE REPLACEMENT
• REMOVAL AND INSTALLATION
• SELF-DIAGNOSTIC FUNCTION
• DASHBOARD WIRE HARNESS (RIGHT BRANCH)
• HEADLINER REMOVAL/INSTALLATION
• AM/FM ANTENNA AMPLIFIER-REAR WINDOW DEFOGGER COIL REPLACEMENT
• STEERING WHEEL REMOVAL
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• FRONT INNER FENDER REPLACEMENT
• SPLASH SHIELD REPLACEMENT
• AIRBAG DISPOSAL
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• READING THE DTC
• CLEAR THE DTC MEMORY
• OPDS/ODS UNIT REPLACEMENT
• 11-1X
• 11-3X
• 11-8X
• 11-9X
• 12-1X
• 12-3X
• 12-8X
• 12-9X
• 21-1X
• 21-3X
• 21-8X
• 21-9X
• 22-1X
• 22-3X
• 22-8X
• 22-9X
• 31-1X
• 31-3X
• 31-8X
• 31-9X
• 32-1X
• 32-3X
• 32-8X
• 32-9X
• 33-1X
• 33-3X
• 33-8X
• 33-9X
• 34-1X
• 34-3X
• 34-8X
• 34-9X
• 41-1X
• 41-2X
• 42-1X
• 42-2X
• 43-1X
• 43-2X
• 44-1X
• 44-2X
• 45-1X
• 45-2X
• 46-1X
• 46-2X
• 51-XX
• 61-1X
• 61-2X
• 62-1X
• 62-2X
• 85-4X
• 85-61
• 85-71
• 85-79
• 86-1X
• 87-3X
• 91-1X
• A1-1X
• A2-1X
• EX-XX
• 71-1X
• 71-2X
• 81-61
• 81-71
• 81-79
• 82-1X
• 83-2X
• 92-1X
• 92-2X
• SRS INDICATOR DOES NOT COME ON
• SRS INDICATOR STAYS ON, BUT NO DTCS ARE STORED
• OPDS/ODS UNIT INITIALIZATION
• DTC (DIAGNOSTIC TROUBLE CODES)
• TROUBLESHOOTING INTERMITTENT FAILURES
• REOPENING THE SRS UNIT CIRCUIT FOR DIAGNOSIS
• FRONT PASSENGER'S AIRBAG REPLACEMENT
• SIDE AIRBAG REPLACEMENT
• SIDE IMPACT SENSOR (FIRST) REPLACEMENT
• DISCONNECTING SYSTEM CONNECTORS
• DTC TROUBLESHOOTING INDEX
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• DISPOSAL OF DAMAGED COMPONENTS

More articles — Restraints
