Driver Position Memory System (dpms) Acura TL IV

Scheme 1

Scheme 2

Scheme 3

System Description

The driver's seat and the power mirrors have a memory feature All the adjustments can be memorized by pressing the SET button on the driving position memory switch, and then pressing one of two position buttons within 5 seconds Pressing the appropriate position button will move the seat and the mirrors to the memorized positions This system is integrated with the multiplex integrated control system, and has 9 wake-up and sleep modes All digital signals are sent via shared B-CAN and UART communication lines For more information about communication line and wake-up/sleep mode, refer to the Multiplex Integrated Control System Description (see SYSTEM DESCRIPTION ) Disconnecting the battery will cancel the memorized positions

Memorizing a Seat and Mirror Position

Move the seat and the mirrors to the desired position Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode

Press and hold the SET button on the driver's position memory switch A single beep will be heard and both of the green LED will begin to flash Press No 1 or No 2 to match the remote that is to be used There will be two more beeps confirming that the seat and mirror positions have been memorized The LED will remain lit, unless the seat and the mirrors are moved from the memorized position

Memorized Position Recall with the Remotes

After the seat and mirror positions have been memorized, the seat and mirror will move to the position when the appropriate remote UNLOCK is pressed and the driver's door is opened When the seat and mirrors move to the memorized position, the green LED corresponding with that remote will stay lit until the position is changed or the key is turned to LOCK (0), or engine start/stop button is pressed to select the OFF mode

Without keyless access system

Scheme 4

With keyless access system

Scheme 5

Power Seat Position Sensors

Each motor has a sensor that detects motor rotation and sends a pulse to the power seat control unit when the motor rotates The control unit stores the number of pulses in its memory, and the seat position is memorized

Power Mirror Position Sensors

By means of a tilt position sensor and swing position sensor, the power mirror control circuit in the power mirror control unit detects the voltage changes caused by the movements of the mirrors These voltage changes are stored in memory, and the power mirror positions are memorized for each stored driving position

Reverse Mirror Control

When the vehicle is shifted to Reverse (shift lever in R position) with the power mirror selector switch in Left (or Right) position, the driver's (or passenger's) side mirror tilts down automatically to help the driver's view The mirror will return to the previous position when the shift lever is shifted out of R position The reverse mirror control is cancelled if the power mirror selector switch is in the center position

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

DTC B1802: Power Seat Control Unit Failure

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Wait for at least 6 seconds
4. Check for DTCs with the HDS Is DTC B1802 indicated? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Intermittent failure, the system is OK at this time

DTC B1825: Power Seat Slide Motor Pulse Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the power seat adjustment switch in all directions for more than 1 second each NOTE: DTC B1825 is stored when the slide switch is operated more than 1 second after the seat moves to the most forward or most backward position, even when the system is OK
4. Check for the DTCs with the HDS Is DTC B1825 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Clear the DTCs with the HDS Is DTC B1836 also indicated? YES -Go to the «DTC B1836: POWER SEAT POSITION SENSOR CIRCUIT SHORT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__dtc-b1836-power-seat-position-sensor) NO -Go to step 6
6. Clear the DTCs with the HDS Are DTCs B1826, B1827, and/or B1828 also indicated? YES -Go to step 17 NO -Go to step 7
7. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
8. Operate the slide switch for 2 seconds, and check the slide motor operation Does the slide motor run smoothly? YES -Go to step 9 NO -Go to step 27
9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
10. Disconnect power seat control unit connector B (40P)
11. Disconnect the slide motor/position sensor 5P connector
12. Check for continuity between power seat control unit connector B (40P) terminals No 29 and No 11 and slide motor/position sensor 5P connector terminals No 3 and No 4 respectively Is there continuity? YES -Go to step 13 NO -Repair open in the wire
13. Check for continuity between body ground and power seat control unit connector B (40P) terminal No 11 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 14
14. Reconnect power seat control unit connector B (40P)
15. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
16. Measure the voltage between slide motor/position sensor 5P connector terminals No 4(+) and No 3 (-) Is there about 5 V YES -Replace the slide motor/position sensor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-slide-motor-replacement) ) NO -If there is no voltage, replace the power seat control unit If there is battery voltage, repair a short in the wire (sensor line)
17. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
18. Disconnect power seat control unit connector B (40P)
19. Disconnect the slide motor/position sensor 5P connector
20. Check for continuity between power seat control unit connector B (40P) terminals No 15 and No 29 and slide motor/position sensor 5P connector terminals No 2 and No 3 respectively Is there continuity? YES -Go to step 21 NO -Repair an open or high resistance in the wire
21. Reconnect power seat control unit connector B (40P)
22. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
23. Measure the voltage between power seat control unit connector B (40P) terminals No 15 and No 29 Is there battery voltage when the slide switch is operated? YES -Replace the slide motor/position sensor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-slide-motor-replacement) ) NO -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )
24. Check the No. 19 (20 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 25 NO -Replace the fuse. If the fuse blows again, repair the short to ground on the No. 19 (20 A) fuse circuit
25. Measure the voltage between body ground and power seat control unit connector A (18P) terminal No. 8. Is there battery voltyage OK? YES -Go to step 26 NO -Repair an open or high resistance in the wire between the driver's under-dash fuse/relay box and the power seat control unit.
26. Measure the voltage between body ground at power seat control unit connector A (18P) terminal No. 18 when operating the slide switch. Is there 0.2 V or more? YES -Repair an open or high resistance in the wire between the power seat control unit and G701. NO -Go to step 27
27. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
28. Disconnect power seat control unit connector A (18P)
29. Disconnect the slide motor/position sensor 5P connector
30. Check for continuity between power seat control unit connector A (18P) terminals No 7 and No 17 and slide motor/position sensor 5P connector terminals No 1 and No 5 respectively Is there continuity? YES -Go to step 31 NO -Repair an open or high resistance in the wire
31. Check for continuity between body ground and slide motor/position sensor 5P connector terminals No 1 and No 5 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 32
32. Test the slide motor (see «DRIVER'S POWER SEAT MOTOR TEST»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms) ) Is the motor OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Replace the slide motor/position sensor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-slide-motor-replacement) )

DTC B1826: Power Seat Front Up-Down Motor Pulse Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the power seat adjustment switch in all directions for more than 1 second each NOTE: DTC B1826 is stored when the front up-down switch is operated more than 1 second after the seat moves to the most up or most down position, even when the system is OK
4. Check for the DTCs with the HDS Is DTC B1826 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Clear the DTCs with the HDS Is DTC B1836 also indicated? YES -Go to the «DTC B1836: POWER SEAT POSITION SENSOR CIRCUIT SHORT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__dtc-b1836-power-seat-position-sensor) NO -Go to step 6
6. Clear the DTCs with the HDS Are DTCs B1825, B1827, and/or B1828 also indicated? YES -Go to step 17 NO -Go to step 7
7. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
8. Operate the front up-down switch for 2 seconds, and check the front up-down motor operation Does the front up-down motor run smoothly? YES -Go to step 9 NO -Go to step 24
9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
10. Disconnect power seat control unit connector B (40P)
11. Disconnect the front up-down motor/position sensor 5P connector
12. Check for continuity between power seat control unit connector B (40P) terminals No 12 and No 29 and front up-down motor/position sensor 5P connector terminals No 5 and No 4 respectively Is there continuity? YES -Go to step 13 NO -Repair open in the wire
13. Check for continuity between body ground and power seat control unit connector B (40P) terminal No 12 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 14
14. Reconnect power seat control unit connector B (40P)
15. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
16. Measure the voltage between front up-down motor/position sensor 5P connector terminals No 5 (+) and No 4 (-) Is there about 5 V? YES -Faulty the front up-down motor/position sensor, replace the seat frame assembly (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) ) NO -If there is no voltage, replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) If there is battery voltage, repair a short in the wire (sensor line)
17. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
18. Disconnect power seat control unit connector B (40P)
19. Disconnect the front up-down motor/position sensor 5P connector
20. Check for continuity between power seat control unit connector B (40P) terminals No 15 and No 29 and front up-down motor/position sensor 5P connector terminals No 3 and No 4 respectively Is there continuity? YES -Go to step 21 NO -Repair an open or high resistance in the wire
21. Reconnect power seat control unit connector B (40P)
22. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
23. Measure the voltage between power seat control unit connector B (40P) terminals No 15 and No 29 Is there battery voltage when the front up-down switch is operated? YES -Faulty the front up-down motor/position sensor, replace the seat frame assembly (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) ) NO -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )
24. Check the No. 19 (20 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 25 NO -Replace the fuse. If the fuse blows again, repair the short to ground on the No. 19 (20 A) fuse circuit.
25. Measure the voltage between body ground and power seat control unit connector A (18P) terminal No. 8. Is there battery voltyage OK? YES -Go to step 26 NO -Repair an open or high resistance in the wire between the driver's under-dash fuse/relay box and the power seat control unit.
26. Measure the voltage between body ground at power seat control unit connector A (18P) terminal No. 18 when operating the slide switch. Is there 0.2 V or more? YES -Repair an open or high resistance in the wire between the power seat control unit and G701. NO -Go to step 27
27. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
28. Disconnect power seat control unit connector A (18P)
29. Disconnect the slide motor/position sensor 5P connector
30. Check for continuity between power seat control unit connector A (18P) terminals No 6 and No 16 and front up-down motor/position sensor 5P connector terminals No 2 and No 1 respectively Is there continuity? YES -Go to step 31 NO -Repair an open or high resistance in the wire
31. Check for continuity between body ground and front up-down motor/position sensor 5P connector terminals No 1 and No 2 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 32
32. Test the front up-down motor (see «DRIVER'S POWER SEAT MOTOR TEST»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms) ) Is the motor OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Faulty the front up-down motor/position sensor, replace the seat frame assembly (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) )

DTC B1827: Power Seat Rear Up-Down Motor Pulse Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the power seat adjustment switch in all directions for more than 1 second each NOTE: DTC B1827 is stored when the rear up-down switch is operated more than 1 second after the seat moves to the most up or most down position, even when the system is OK
4. Check for the DTCs with the HDS Is DTC B1827 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Clear the DTCs with the HDS Is DTC B1836 also indicated? YES -Go to the «DTC B1836: POWER SEAT POSITION SENSOR CIRCUIT SHORT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__dtc-b1836-power-seat-position-sensor) NO -Go to step 6
6. Clear the DTCs with the HDS Are DTCs B1825, B1826, and/or B1828 also indicated? YES -Go to step 17 NO -Go to step 7
7. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
8. Operate the rear up-down switch for 2 seconds, and check the rear up-down motor operation Does the rear up-down motor run smoothly? YES -Go to step 9 NO -Go to step 24
9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
10. Disconnect power seat control unit connector B (40P)
11. Disconnect the rear up-down motor/position sensor 5P connector
12. Check for continuity between power seat control unit connector B(40P) terminals No 13 and No 29 and rear up-down motor/position sensor 5P connector terminals No 5 and No 4 respectively Is there continuity? YES -Go to step 13 NO -Repair open in the wire
13. Check for continuity between body ground and power seat control unit connector B (40P) terminal No 13 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 14
14. Reconnect power seat control unit connector B (40P)
15. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
16. Measure the voltage between rear up-down motor/position sensor 5P connector terminals No 5 (+) and No 4(-) Is there about 5V? YES -Faulty the rear up-down motor/position sensor, replace the seat frame assembly (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) ) NO -If there is no voltage, replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) If there is battery voltage, repair a short in the wire (sensor line)
17. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
18. Disconnect power seat control unit connector B (40P)
19. Disconnect the rear up-down motor/position sensor 5P connector
20. Check for continuity between power seat control unit connector B (40P) terminals No 15 and No 29 and rear up-down motor/position sensor 5P connector terminals No 3 and No 4 respectively Is there continuity? YES -Go to step 21 NO -Repair open in the wire
21. Reconnect power seat control unit connector B (40P)
22. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
23. Measure the voltage between power seat control unit connector B (40P) terminals No 15 and No 29 Is there battery voltage when the rear up-down switch is operated? YES -Faulty the rear up-down motor/position sensor, replace the seat frame assembly (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) ) NO -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )
24. Check the No. 19 (20 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 25 NO -Replace the fuse. If the fuse blows again, repair the short to ground on the No. 19 (20 A) fuse circuit.
25. Measure the voltage between body ground and power seat control unit connector A (18P) terminal No. 1. Is there battery voltage? YES -Go to step 26 NO -Repair an open or high resistance in the wire between the driver's under-dash fuse/relay box and the power seat control unit.
26. Measure the voltage between body ground at power seat control unit connector A (18P) terminal No. 4 when operating the rear up-down switch. Is there 0.2 V or more? YES -Repair an open or high resistance in the wire between the power seat control unit and G701. NO -Go to step 27
27. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
28. Disconnect power seat control unit connector A (18P)
29. Disconnect the rear up-down motor/position sensor 5P connector
30. Check for continuity between power seat control unit connector A (18P) terminals No 2 and No 10 and rear up-down motor/position sensor 5P connector terminals No 2 and No 1 respectively Is there continuity? YES -Go to step 31 NO -Repair open or high resistance in the wire
31. Check for continuity between body ground and year up-down motor/position sensor 5P connector terminals No 1 and No 2 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 32
32. Test the rear up-down motor (see «DRIVER'S POWER SEAT MOTOR TEST»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms) ) Is the motor OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Faulty the rear up-down motor/position sensor, replace the seat frame assembly (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) )

DTC B1828: Power Seat Recline Motor Pulse Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the power seat adjustment switch in all directions for more than 1 second each NOTE: DTC B1828 is stored when the recline switch is operated more than 1 second after the seat moves to the most forward or most backward position, even when the system is OK
4. Check for the DTCs with the HDS Is DTC B1828 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Clear the DTCs with the HDS Is DTC B1836 also indicated? YES -Go to the «DTC B1836: POWER SEAT POSITION SENSOR CIRCUIT SHORT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__dtc-b1836-power-seat-position-sensor) NO -Go to step 6
6. Clear the DTCs with the HDS Are DTCs B1825, B1826, and/or B1827 also indicated? YES -Go to step 17 NO -Go to step 7
7. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
8. Operate the recline switch for 2 seconds, and check the recline motor operation Does the recline motor run smoothly? YES -Go to step 9 NO -Go to step 24
9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
10. Disconnect power seat control unit connector B (40P)
11. Disconnect the recline motor/position sensor 5P connector
12. Check for continuity between power seat control unit connector B (40P) terminals No 10 and No 29 and recline motor/position sensor 5P connector terminals No 4 and No 5 respectively Is there continuity? YES -Go to step 13 NO -Repair open in the wire
13. Check for continuity between body ground and power seat control unit connector B (40P) terminal No 10 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 14
14. Reconnect power seat control unit connector B (40P)
15. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
16. Measure the voltage between recline motor/position sensor 5P connector terminals No 5 (+) and No 4(-) Is there about 5V? YES -Replace the recline motor/position sensor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-recline-motor-replacement) ) NO -If there is no voltage, replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) If there is battery voltage, repair a short in the wire (sensor line)
17. Disconnect power seat control unit connector B (40P)
18. Turn the igintion switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
19. Disconnect the recline motor/position sensor 5P connector
20. Check for continuity between power seat control unit connector B (40P) terminals No 15 and No 29 and recline motor/position sensor 5P connector terminals No 3 and No 4 respectively Is there continuity? YES -Go to step 21 NO -Repair open in the wire
21. Reconnect power seat control unit connector B (40P)
22. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
23. Measure the voltage between power seat control unit connector B (40P) terminals No 15 and No 29 Is there battery voltage when the recline switch is operated? YES -Replace the recline motor/position sensor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-recline-motor-replacement) ) NO -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )
24. Check the No. 19 (20 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 25 NO -Replace the fuse. If the fuse blows again, repair the short to ground on the No. 19 (20 A) fuse circuit.
25. Measure the voltage between body ground and power seat control unit connector A (18P) terminal No. 1. Is there battery voltage? YES -Go to step 26 NO -Repair an open or high resistance in the wire between the driver's under-dash fuse/relay box and the power seat control unit.
26. Measure the voltage between body ground at power seat control unit connector A (18P) terminal No. 4 when operating the rear up-down switch. Is there 0.2 V or more? YES -Repair an open or high resistance in the wire between the power seat control unit and G701. NO -Go to step 27
27. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
28. Disconnect power seat control unit connector A (18P)
29. Disconnect the recline motor/position sensor 5P connector
30. Check for continuity between power seat control unit connector A (18P) terminals No 9 and No 11 and recline motor/position sensor 5P connector terminals No 1 and No 2 respectively Is there continuity? YES -Go to step 31 NO -Repair open or high resistance in the wire
31. Check for continuity between body ground and recline motor/position sensor 5P connector terminals No 1 and No 2 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 32
32. Test the recline motor (see «DRIVER'S POWER SEAT MOTOR TEST»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms) ) Is the motor OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Replace the recline motor/position sensor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-recline-motor-replacement) )

DTC B1829: A/T P Signal and VSP Signal Have an Illegal Combination

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ) Check for DTCs with the HDS

1. Clear the DTCs with the HDS
2. Start the engine
3. Test drive at 6 mph (10 km/h) for 10 seconds
4. Check for the DTCs with the HDS Is DTC B1829 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Check the P shift position indicator and the MIL Does the P indicator and MIL come on? YES -Troubleshoot the automatic transmission system NO -Go to step 6
6. Check for the gauge control module DTCs with the HDS Are any DTCs indicated? YES -Go to the indicated DTC's troubleshooting NO -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )

DTC B1830: Left Mirror Position Sensor Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Clear the DTC with the HDS
2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the left power mirror in each direction with the power mirror switch
4. Check for DTCs with the HDS Is DTC B1830 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__front-door-panel-removalinstallation) )
7. Disconnect the power mirror control unit 24P connector
8. Disconnect the left power mirror 16P connectors
9. Check for continuity between body ground and left power mirror connector (16P) terminal No 6 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 10
10. Connect power mirror control unit connector (24P) terminal No 7 to body ground with a jumper wire
11. Check for continuity between body ground and left power mirror connector (16P) terminal No 6 Is there continuity? YES -Go to step 12 NO -Repair open in the wire
12. Check for continuity between body ground and left power mirror connector (16P) terminals No 8 and No 13 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 13
13. Connect power mirror control unit connector (24P) terminals No 4 and No 5 to body ground with a jumper wire
14. Check for continuity between body ground and left power mirror connector (16P) terminals No 8 and No 13 Is there continuity? YES -Go to step 15 NO -Repair open in the wire
15. Check for continuity between body ground and power mirror control unit connector (24P) terminal No 6 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 16
16. Connect power mirror control unit connector (24P) terminal No 6 to body ground with a jumper wire
17. Check for continuity between body ground and left power mirror connector (16P) terminal No 7 Is there continuity? YES -Go to step 18 NO -Repair open in the wire
18. Reconnect the power mirror control unit connector (24P)
19. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
20. Measure the voltage between power mirror control unit connector (24P) terminals No 6 and No 7 Is there about 5 V? YES -Faulty left power mirror position sensor, replace the power mirror actuator (see «POWER MIRROR ACTUATOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/mirrors/#power-mirrors__power-mirror-actuator-replacement) ) NO -Substitute a known-good power mirror control unit, and recheck If DTC is gone, the original power mirror control unit is faulty, replace it (see «POWER MIRROR CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-mirror-control-unit-input-testreplacement) )

DTC B1832: Right Mirror Position Sensor Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Clear the DTC with the HDS
2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the right power mirror in each direction with the power mirror switch
4. Check for DTCs with the HDS Is DTC B1832 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Remove the front passenger's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__front-door-panel-removalinstallation) )
7. Disconnect the power mirror control unit 24P connector
8. Disconnect the right power mirror 16P connectors
9. Check for continuity between body ground and right power mirror connector (16P) terminal No 6 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 10
10. Connect power mirror control unit connector (24P) terminal No 7 to body ground with a jumper wire
11. Check for continuity between body ground and right power mirror connector (16P) terminal No 6 Is there continuity? YES -Go to step 12 NO -Repair open in the wire
12. Check for continuity between body ground and right power mirror connector (16P) terminals No 8 and No 13 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 13
13. Connect power mirror control unit connector (24P) terminals No 19 and No 20 to body ground with a jumper wire
14. Check for continuity between body ground and right power mirror connector (16P) terminals No 8 and No 13 Is there continuity? YES -Go to step 15 NO -Repair open in the wire
15. Check for continuity between power mirror control unit connector (24P) terminal No 6 and body ground Is there continuity? YES -Repair short to ground in the wire NO -Go to step 16
16. Connect power mirror control unit connector (24P) terminal No 6 to body ground with a jumper wire
17. Check for continuity between body ground and right power mirror connector (16P) terminal No 7 Is there continuity? YES -Go to step 18 NO -Repair open in the wire
18. Reconnect the power mirror control unit connector (24P)
19. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode
20. Measure the voltage between power mirror control unit connector (24P) terminals No 6 and No 7 Is there about 5 V? YES -Faulty right power mirror position sensor, replace the power mirror actuator (see «POWER MIRROR ACTUATOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/mirrors/#power-mirrors__power-mirror-actuator-replacement) ) NO -Substitute a known-good power mirror control unit, and recheck If DTC is gone, the original power mirror control unit is faulty, replace it (see «POWER MIRROR CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-mirror-control-unit-input-testreplacement) )

DTC B1836: Power Seat Position Sensor Circuit Short

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 64

Scheme 65

Scheme 66

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the power seat adjustment switch in all directions for more than 1 second each
4. Check for DTCs with the HDS Is DTC B1836 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Disconnect power seat control unit connector B (40P)
7. Disconnect the 5P connector from each motor
8. Check for continuity between body ground and power seat control unit connector B (40P) terminal No 15 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 9
9. Check for continuity between body ground (motor body) and terminal No 2 of the slide motor/position sensor Is there continuity? YES -Repair or replace the slide motor/position sensor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-slide-motor-replacement) ) NO -Go to step 10
10. Check for continuity between body ground (motor body) and terminal No 3 of the front up-down motor/position sensor, rear up-down motor/position sensor, and recline motor/position sensor Is there continuity? YES -If the front or rear up-down motor/position sensor is faulty, replace the seat frame assembly If the recline motor/position sensor is faulty, replace the recline motor/position sensor NO -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )

DTC B1837: Memory Position Delay

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

1. Clear the DTC with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Move the power seat to the full front up and full rear up positions, then slide the seat all the way back and completely recline the seat-back backward with the power seat adjustment switch
4. Put this seating position into memory with the driving position memory switch (see «SYSTEM DESCRIPTION»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__system-description) )
5. Using the power seat switches, move the seat away from the position just memorized
6. Recall the memory position with the driving position memory switch
7. Wait for 3 minutes
8. Check for DTCs with the HDS Are any DTCs indicated? YES -Go to step 9 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
9. Check for DTCs with the HDS Are any DTCs other than B1837 indicated? YES -Go to the indicated DTC's troubleshooting NO -Go to step 10
10. Clear the DTCs with the HDS
11. Wait for 6 seconds
12. Move each power seat motor one at a time, and check the operation time Does any motor fail to run smoothly? YES -Go to the power seat motor test (see «DRIVER'S POWER SEAT MOTOR TEST»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms) ) If the motor is OK, check the engagement of the motor gear NO -Go to the power seat control unit input test (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) )

DTC B1843: UART Communication Error

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Clear the DTC with the HDS
2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the power seat with the driving position memory switch
4. Check for DTCs with the HDS Is DTC B1843 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Disconnect the power seat control unit connectors and power mirror control unit connector (24P)
7. Check for continuity between power seat control unit connector B (40P) terminal No 38 and power mirror control unit connector (24P) terminal No 13 Is there continuity? YES -Go to step 8 NO -Repair open in the wire between the power mirror control unit connector (24P) and power seat control unit connector B (40P)
8. Check for continuity between body ground and power seat control unit connector B (40P) terminal No 38 Is there continuity? YES -Repair short to ground in the wire NO -Go to step 9
9. Disconnect the power seat control unit connectors (24P)
10. Measure the voltage between body ground and power mirror control unit connector (24P) terminal No 24 Is there battery voltage? YES -Go to step 11 NO -Check No 15 (10 A) fuse in the under-hood fuse/relay box If the fuse is OK, repair open in the wire
11. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
12. Measure the voltage between body ground and power mirror control unit connector (24P) terminal No. 22. Is there less than 0.2 V? YES -Replace the power mirror control unit (see «POWER MIRROR CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-mirror-control-unit-input-testreplacement) ) NO -Repair an open or high resistance in the wire between the power mirror control unit and G401. If the wire is OK, repair G401.

DTC B1844: Power Seat Slide Switch Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 71

Scheme 72

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the slide switch in each direction for more than 1 second
4. Check for DTCs with the HDS Is DTC B1844 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Disconnect power seat control unit connector B (40P)
7. Disconnect the power seat adjustment switch 12P connector
8. Check for continuity between body ground and power seat control unit connector B (40P) terminals No 1, No 7, and No 24 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 9
9. Check for continuity between these power seat control unit connector B (40P) terminals No 1 and No 7 No 1 and No 24 No 7 and No 24 Is there continuity? YES -Repair short in the wire(s) NO -Go to step 10
10. Test the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) ) Is the switch OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Replace the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) )

DTC B1845: Power Seat Recline Switch Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 73

Scheme 74

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the recline switch in each direction for more than 1 second
4. Check for DTCs with the HDS Is DTC B1845 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Disconnect power seat control unit connector B (40P)
7. Disconnect the power seat adjustment switch 12P connector
8. Check for continuity between body ground and power seat control unit connector B (40P) terminals No 1, No 6, and No 23 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 9
9. Check for continuity between these power seat control unit connector B (40P) terminals No 1 and No 6 No 1 and No 23 No 6 and No 23 Is there continuity? YES -Repair short in the wire NO -Go to step 10
10. Test the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) ) Is the switch OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Replace the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) )

DTC B1846: Power Seat Front Up-Down Switch Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 75

Scheme 76

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the front up-down switch in each direction for more than 1 second
4. Check for DTCs with the HDS Is DTC B1846 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Disconnect power seat control unit connector B (40P)
7. Disconnect the power seat adjustment switch 12P connector
8. Check for continuity between body ground and power seat control unit connector B (40P) terminals No 1, No 4, and No 5 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 9
9. Check for continuity between these power seat control unit connector B (40P) terminals No 1 and No 4 No 1 and No 5 No 4 and No 5 Is Mere continuity? YES -Repair short in the wire NO -Go to step 10
10. Test the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) ) Is the switch OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Replace the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) )

DTC B1847: Power Seat Rear Up-Down Switch Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 77

Scheme 78

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Operate the rear up-down switch in each direction for more than 1 second
4. Check for DTCs with the HDS Is DTC B1847 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections
5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
6. Disconnect power seat control unit connector B (40P)
7. Disconnect the power seat adjustment switch 12P connector
8. Check for continuity between body ground and power seat control unit connector B (40P) terminals No 1, No 3, and No 22 individually Is there continuity? YES -Repair short to ground in the wire NO -Go to step 9
9. Check for continuity between these power seat control unit connector B (40P) terminals No 1 and No 3 No 1 and No 22 No 3 and No 22 Is there continuity? YES -Repair short in the wire NO -Go to step 10
10. Test the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) ) Is the switch OK? YES -Replace the power seat control unit (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Replace the power seat adjustment switch (see «POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-adjustment-switch-testreplacement) )

DTC U0155: Lost Communication with Gauge Control Module (VSP/NE Frame)

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 79

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Wait for 6 seconds or more
4. Check for DTCs with the HDS Is DTC U0155 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections between the power seat control unit and the gauge control module
5. From the BODY ELECTRICAL system select menu, select UNIT INFORMATION, and then select CONNECTED UNIT Is the gauge control module detected? YES -Go to the power seat control unit input test (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Go to step 6
6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
7. Disconnect the gauge control module 32P connector
8. Disconnect power seat control unit connector B (40P)
9. Check for continuity between power seat control unit connector B (40P) terminals No 39 and No 40 and gauge control module 32P connector terminals No 25 and No 26 individually Is there continuity? YES -Replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ) NO -Open or poor connection in the wire between the gauge control module and the power seat control unit

DTC U0199: Lost Communication with P/W (DR Lock SW Frame)

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 80

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Wait for 6 seconds or more
4. Check for DTCs with the HDS Is DTC U0199 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time Check for loose or poor connections between the power seat control unit and the door multiplex control unit
5. From the BODY ELECTRICAL system select menu, select UNIT INFORMATION, and then select CONNECTED UNIT Is the power window master switch (door multiplex control unit) detected? YES -Go to the power seat control unit input test (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Go to step 6
6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
7. Disconnect the door multiplex control unit 37P connector
8. Disconnect power seat control unit connector B (40P)
9. Check for continuity between power seat control unit connector B (40P) terminals No 39 and No 40 and door multiplex control unit 37P connector terminals No 33 and No 35 individually Is there continuity? YES -Replace the door multiplex control unit (see «REAR POWER WINDOW SWITCH TEST»(/acura/tl/iv-2008-2011/remont/windows/#power-window-system) ) NO -Open or poor connection in the wire between the door multiplex control unit and the power seat control unit

DTC U1282: Lost Communication with Driver's MICU

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

1. Clear the DTCs with the HDS
2. Turn the ignition switch to LOCK (0) and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode
3. Wait for 6 seconds or more
4. Check for DTCs with the HDS Is DTC U1282 indicated? YES -Go to the power seat control unit input test (see «POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/memory-modules/#driver-position-memory-system-dpms__power-seat-control-unit-input-testreplacement) ) NO -Intermittent failure, the system is OK at this time Check for loose or poor connections between the power seat control unit and the driver's MICU

Power Seat Control Unit Input Test/Replacement

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 81

1. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
2. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-removalinstallation) ) NOTE: Be careful not to scratch the interior trim
3. Disconnect the 18P connector (A) and 40P connector (B) from the power seat control unit (C)
4. Inspect the connector and socket terminals to be sure they are all making good contact If the terminals are bent, loose or corroded, repair them as necessary and recheck the system If the terminals look OK, go to step 5
5. Reconnect the connectors to the power seat control unit, and do these input tests at the following connectors If any test indicates a problem, find and correct the cause, then recheck the system If all the input tests prove OK, go to step 6 TEST CONDITION INPUT CHART Cavity Wire Test condition Test Desired result Possible cause if desired result is not obtained B9 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2V Poor ground (G701) An open or high resistance in the wire A4 BRN Under all conditions Measure the voltage to ground: There should be less than 0.2V Poor ground (G701) An open or high resistance in the wire A18 BRN Under all conditions Measure the voltage to ground: There should be less than 0.2V Poor ground (G701) An open or high resistance in the wire B34 BRN Ignition switch ON (II), or power mode ON Measure the voltage to ground: There should be battery voltage Blown No 12 (7 5 A) fuse in the driver's under-dash fuse/relay box An open in the wire B36 WHT Under all conditions Measure the voltage to ground: There should be battery voltage Blown No 15 (10 A) fuse in the under-hood fuse/relay box An open or high resistance in the wire A1 RED Under all conditions Measure the voltage to ground: There should be battery voltage Blown No 3-4 (DR F/B) (60 A) fuse in the under-hood fuse/relay box Blown No 21 (20 A) fuse in the driver's under-dash fuse/relay box An open or high resistance in the wire A8 LT BLU Under all conditions Measure the voltage to ground: There should be battery voltage Blown No 3-4 (DR F/B) (60 A) fuse in the under-hood fuse/relay box Blown No 19 (20 A) fuse in the driver's under-dash fuse/relay box An open or high resistance in the wire B26 (A/T) GRN Shift lever in P position Measure the voltage to ground: There should be less than 0.2V Poor ground (G101) Faulty transmission range switch An open or high resistance in the wire Shift lever in any other position than P Measure the voltage to ground: There should be about 5 V Faulty transmission range switch A short to ground in the wire B26 (M/T) GRN Ignition switch ON (III), or power mode ON, parking brake lever pulled Measure the voltage to ground: There should be less than 0.2V Faulty parking brake switch An open or high resistance in the wire Ignition switch ON (III), or power mode ON, parking brake lever released Measure the voltage to ground: There should be about 5 V Faulty parking brake switch A short to ground in the wire B15 BLU Run the power seat motors Measure the voltage to ground: There should be at least about 10V Faulty position sensor A short to ground in the wire B10 B29 GRN ORN Run the recline motor Measure the voltage between terminals B10 (+) and B29 (-): There should be about 2.5V average Faulty position sensor An open ior high resistance in the wire A short to ground in the wire B11 B29 WHT ORN Run the slide motor Measure the voltage between terminals B11 (+) and B29 (-): There should be about 2.5V average Faulty position sensor An or high resistance open in the wire A short to ground in the wire B12 B29 RED ORN Run the front up-down motor Measure the voltage between terminals B12 (+) and B29 (-): There should be about 2.5V average Faulty position sensor An open or high resistance in the wire A short to ground in the wire B13 B29 YEL ORN Run the rear up-down motor Measure the voltage between terminals B13 (+) and B29 (-): There should be about 2.5V average Faulty position sensor An open or high resistance in the wire A short to ground in the wire B1 B7 BLU GRY Slide switch in FORWARD position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B24 BLU LT GRN Slide switch in BACKWARD position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B6 BLU LT BLU Recline switch in FORWARD position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B23 BLU GRN Recline switch in BACKWARD position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B5 BLU ORN Front up-down switch in UP position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B4 BLU RED Front up-down switch in DOWN position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B22 BLU PNK Rear up-down switch in UP position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire B1 B3 BLU WHT Rear up-down switch in DOWN position Measure the voltage between the terminals: There should be less then 0.2V Faulty driver's power seat adjustment switch An open or high resistance in the wire
6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode, then disconnect the connectors from the power seat control unit, and do these input tests at the following connectors If any test indicates a problem, find and correct the cause, then recheck the system If all the input tests prove OK, the control unit must be faulty, replace it TEST CONDITION INPUT CHART Cavity Wire Test condition Test Desired result Possible cause if desired result is not obtained B39 BLU Under all conditions (disconnect the door multiplex control unit 37P connector) Check for continuity between terminal B39 and door multiplex control unit 37P connector terminal No 33: There should be continuity An open in the B-CAN wire Under all conditions (disconnect the immobilizer-keyless control unit 7P connector) Check for continuity between terminal B39 and immobilizer-keyless control unit 7P connector terminal No 3: There should be continuity An open in the B-CAN wire B40 PNK Under all conditions (disconnect the door multiplex control unit 37P connector) Check for continuity between terminal B40 and door multiplex control unit 37P connector terminal No 35: There should be continuity An open in the B-CAN wire Under all conditions (disconnect the immobilizer-keyless control unit 7P connector) Check for continuity between terminal B40 and immobilizer-keyless control unit 7P connector terminal No 4: There should be continuity An open in the B-CAN wire B38 PUR Disconnect the power mirror control unit 24P connector Check for continuity between terminal B38 and power mirror control unit 24P connector terminal No 13: There should be continuity An open in the UART wire A7 A17 GRY BLU Under all conditions Connect terminals A1 and A7, and terminals A17 and A4: The seat should slide backward Faulty slide motor An open or high resistance in the wire Connect terminals A1 and A17, and terminals A7 and A4 The seat should slide forward A9 A11 YEL LT GRN Under all conditions Connect terminals A1 and A9, and terminals A11 and A4: The seat should recline forward Faulty recline motor An open or high resistance in the wire Connect terminals A1 and A11, and terminals A9 and A4: The seat should recline backward A6 A16 BRN PUR Under all conditions Connect terminals A1 and A6, and terminals A16 and A4: The front of seat should move down Faulty front up-down motor An open or high resistance in the wire Connect terminals A1 and A16, and terminals A6 and A4: The front of seat should move up A2 A10 GRN PNK Under all conditions Connect terminals A1 and A2, and terminals A10 and A4: The rear of seat should move up Faulty rear up-down motor An open or high resistance in the wire Connect terminals A1 and A10, and terminals A2 and A4: The rear of seat should move down

Power Mirror Control Unit Input Test/Replacement

Note. Before troubleshooting the DPMS, troubleshoot the multiplex integrated control system first using B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A )

Scheme 82

1. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
2. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__front-door-panel-removalinstallation) )
3. Disconnect the 24P connector (A) from the power mirror control unit (B)
4. Inspect the connector and socket terminals to be sure they are all making good contact If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system If the terminals look OK, go to step 5
5. Reconnect the connector to the power mirror control unit, and do these input tests at the following connector If any test indicates a problem, find and correct the cause, then recheck the system If all the input tests prove OK, go to step 6 TEST CONDITION INPUT CHART Cavity Wire Test condition Test Desired result Possible cause if desired result is not obtained 22 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2V Poor ground (G401) an open in the ground wire An open or high resistance in the wire 11 BRN Ignition switch ON (II), or power mode ON Measure the voltage to ground: There should be battery voltage Blown No 12 (7.5 A) fuse in the driver's under-dash fuse/relay box An open or high resistance in the wire 24 WHT Under all conditions Measure the voltage to ground: There should be battery voltage Blown No 15 (10 A) fuse in the under-hood fuse/relay box An open or high resistance in the wire 1 2 PNK BLU Ignition switch ON (II), or power mode ON, and mirror select switch in LEFT, then mirror down switch pressed Measure the voltage to ground: There should be battery voltage Blown No 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty power mirror switch An open or high resistance in the wire 8 9 LT BLU GRY Ignition switch ON (II), or power mode ON, and mirror select switch in RIGHT, then mirror down switch pressed Measure the voltage to ground: There should be battery voltage Blown No 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty power mirror switch An open or high resistance in the wire 10 ORN Ignition switch ON (II), or power mode ON, and mirror select switch in LEFT or RIGHT, then mirror up switch pressed Measure the voltage to ground: There should be battery voltage Blown No 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty power mirror switch An open or high resistance in the wire 7 LT BLU Move left or right mirrors Measure the voltage to ground: There should be about 5 V Faulty mirror position sensor A short to ground in the wire 4 6 YEL GRN Swing the left mirror from full left to full right Measure the voltage between terminals No 4 and No 6: There should be about 0.5 V to 4.5V (about 2.5V) Faulty left mirror position sensor An open in the wire A short to ground in the wire 5 6 PUR GRN Move the left mirror from full up to full down Measure the voltage between terminals No 5 and No 6: There should be about 0.5 V to 4.5V (about 2.5 V) Faulty left mirror position sensor An open in the wire A short to ground in the wire 20 6 BLU GRN Swing the right mirror from full left to full right Measure the voltage between terminals No 20 and No 6: There should be about 0.5 V to 4.5V (about 2.5 V) Faulty right mirror position sensor An open or high resistance in the wire A short to ground in the wire 19 6 ORN GRN Move the right mirror from full up to full down Measure the voltage between terminals No 19 and No 6: There should be about 0.5 V to 4.5V (about 2.5 V) Faulty right mirror position sensor An open or high resistance in the wire A short to ground in the wire
6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode, then disconnect the connectors from the power mirror control unit, and do these input tests at the following connectors If any test indicates a problem, find and correct the cause, then recheck the system If all the input tests prove OK, the control unit must be faulty, replace it TEST CONDITION INPUT CHART Cavity Wire Test condition Test Desired result Possible cause if desired result is not obtained 13 LT GRN Disconnect power seat control unit B (40P) connector Check for continuity between terminal No 13(LT GRN)and power seat control unit B (40P) connector terminal No 38 (PUR): There should be continuity An open or high resistance in the wire 14 15 RED BRN Under all conditions Connect terminals No 14 and No 24, and terminals No 15 and No 22: The left mirror should move up Faulty left mirror actuator An open or high resistance in the wire Connect terminals No 15 and No 24, and terminals No Hand No 22: The left mirror should move down 15 16 GRN PNK Under all conditions Connect terminals No 15 and No 24, and terminals No 16 and No 22: The left mirror should swing left Faulty left mirror actuator An open or high resistance in the wire Connect terminals No 16 and No 24, and terminals No 15 and No 22: The left mirror should swing right 3 17 BRN WHT Under all conditions Connect terminals No 3 and No 24, and terminals No 17 and No 22: The right mirror should move up Faulty right mirror actuator An open or high resistance in the wire Connect terminals No 17 and No 24, and terminals No 3 and No 22: The right mirror should move down 17 18 WHT PUR Under all conditions Connect terminals No 17 and No 24, and terminals No 18 and No 22: The right mirror should swing left Faulty right mirror actuator An open or high resistance in the wire Connect terminals No 18 and No 24, and terminals No 17 and No 22: The right mirror should swing right

Scheme 83

1. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode
2. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__front-door-panel-removalinstallation) )
3. Disconnect the 37P connector (A) from the power window master switch (B)
4. Inspect the connector and socket terminals to be sure they are all making good contact If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system If the terminals look OK, go to step 5
5. Reconnect the connector to the power window master switch, and do these input tests at the following connector If any test indicates a problem, find and correct the cause, then recheck the system If all the input tests prove OK, go to step 6 TEST CONDITION INPUT CHART Cavity Wire Test condition Test Desired result Possible cause if desired result is not obtained 32 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2V Poor ground (G401) or an open in the ground wire An open or high resistance in the wire 37 BLK Under all conditions Measure the voltage to ground: There should be less than 0.2V Poor ground (G402) or an open in the ground wire An open or high resistance in the wire 13 WHT Under all conditions Measure the voltage to ground: There should be battery voltage Blown No 15 (10 A) fuse in the under-hood fuse/relay box An open or high resistance in the wire 14 LT GRN Ignition switch ON (II), or ignition mode ON Measure the voltage to ground: There should be battery voltage Blown No 16 (7.5 A) fuse in the driver's under-dash fuse/relay box An open or high resistance in the wire 25 WHT Under all conditions Measure the voltage to ground: There should be battery voltage Blown No 3-4(DR F/B) (60A) fuse in the under-hood fuse/relay box Blown No 24 (20 A) fuse in the driver's under-dash fuse/relay box An open or high resistance in the wire 16 RED Ignition switch ON (III), or ignition mode ON, position 2 switch pressed Measure the voltage to ground: There should be less than 0.2V Poor ground (G401) or an open in the ground wire Faulty driving position memory switch An open or high resistance in the wire Ignition switch ON (III), or ignition mode ON, position 2 switch released Measure the voltage to ground: There should be about 5 V Faulty driving position memory switch A short to ground in the wire 17 LT GRN Ignition switch ON (III), or ignition mode ON, position 1 switch pressed Measure the voltage to ground: There should be less than 0.2V Poor ground (G401) or an open in the ground wire Faulty driving position memory switch An open or high resistance in the wire Ignition switch ON (III), or ignition mode ON, position 1 switch released Measure the voltage to ground: There should be about 5 V Faulty driving position memory switch A short to ground in the wire 19 ORN Ignition switch ON (III), or ignition mode ON, SET switch pressed Measure the voltage to ground: There should be less than 0.2V Poor ground (G401) or an open in the ground wire Faulty driving position memory switch An open or high resistance in the wire Ignition switch ON (III), or ignition mode ON, SET switch released Measure the voltage to ground: There should be about 5 V Faulty driving position memory switch A short to ground in the wire
6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode, then disconnect the connector from the power window master switch, and do these input tests at the following connector If any test indicates a problem, find and correct the cause, then recheck the system If all the input tests prove OK, the door multiplex control unit must be faulty, replace the power window master switch NOTE: After replacing the power window master switch, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tl/iv-2008-2011/remont/windows/#power-window-system__resetting-the-power-window-control-unit) ) TEST CONDITION INPUT CHART Cavity Wire Test condition Test Desired result Possible cause if desired result is not obtained 4 BLU Under all conditions Connect terminals No 13 and No 4: The driving position memory switch indicator 2 should come on Faulty driving position memory switch Faulty LED Poor ground (G401) or an open in the ground wire An open or high resistance in the wire 6 GRN Under all conditions Connect terminals No 13 and No 6: The driving position memory switch indicator 1 should come on Faulty driving position memory switch Faulty LED Poor ground (G401) or an open in the ground wire An open or high resistance in the wire 26 YEL Under all conditions Connect terminals No 13 and No 26: The driving position memory switch lights should come on Faulty driving position memory switch Faulty LED Poor ground (G401) or an open in the ground wire An open or high resistance in the wire 33 BLU Under all conditions (disconnect the power seat control unit connector B (40P)) Check for continuity between terminal No 33 and power seat control unit connector B (40P) terminal No 39: There should be continuity An open or high resistance in the wire 35 PNK Under all conditions (disconnect the power seat control unit connector B (40P)) Check for continuity between terminal No 35 and power seat control unit connector B (40P) terminal No 40: There should be continuity An open or high resistance in the wire

Scheme 84

Scheme 85

1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#door-system__front-door-panel-removalinstallation) )
2. Disconnect the 7P connector (A) from the driver's position memory switch (B)
3. Remove the two screws, then remove the switch from the door panel
4. Check for continuity between the terminals in each switch position according to the table
5. If the continuity is not as specified, replace the switch

Power Seat Adjustment Switch Test/Replacement

Note. SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 86

Scheme 87

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-removalinstallation) )
2. Remove the power seat adjustment switch knobs (A) and the recline cover from the driver's seat (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-recline-cover-removalinstallation) ), then remove the two screws and the power seat adjustment switch (B)
3. Disconnect the 12P connector from the power seat adjustment switch
4. Reinstall the adjustment switch knobs to the switch
5. Check for continuity between the terminals in each position according to the table
6. If the continuity is not as specified, replace the switch

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-removalinstallation) )
2. Disconnect the connector from each power seat motor NOTE: For the recline motor, remove the seat-back cover (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-back-cover-replacement) ) All connectors are terminal side of male terminals
3. Test each motor by connecting power and ground according to the table When the motor stops running, disconnect battery power immediately
4. If the motor does not run or fails to run smoothly, replace Slide motor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-slide-motor-replacement) ) Front up-down motor (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) ) Rear up-down motor (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-frame-replacement) ) Recline motor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-recline-motor-replacement) ) NOTE: The front and rear up-down motors are part of the seat frame

See also:
• SYSTEM DESCRIPTION
• TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A
• FRONT SEAT SLIDE MOTOR REPLACEMENT
• FRONT SEAT FRAME REPLACEMENT
• FRONT SEAT RECLINE MOTOR REPLACEMENT
• FRONT DOOR PANEL REMOVAL/INSTALLATION
• POWER MIRROR ACTUATOR REPLACEMENT
• GAUGE CONTROL MODULE REPLACEMENT
• REAR POWER WINDOW SWITCH TEST
• FRONT SEAT REMOVAL/INSTALLATION
• RESETTING THE POWER WINDOW CONTROL UNIT
• COMPONENT LOCATION INDEX
• FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION
• FRONT SEAT-BACK COVER REPLACEMENT
• POWER SEAT CONTROL UNIT INPUT TEST/REPLACEMENT
• DTC B1836: POWER SEAT POSITION SENSOR CIRCUIT SHORT
• DRIVER'S POWER SEAT MOTOR TEST
• POWER MIRROR CONTROL UNIT INPUT TEST/REPLACEMENT
• SYSTEM DESCRIPTION
• POWER SEAT ADJUSTMENT SWITCH TEST/REPLACEMENT
