Power Window System: Other Acura TL III facelift

Driver's Power Window

The driver's power window motor incorporates a pulser which generates pulses during the motor's operation and sends the pulses to the driver's power window control unit. As soon as the power window control unit detects no pulses from the pulser, the driver's power window control unit makes the power window motor stop and reverse. This is to prevent pinching your hand or fingers during auto-up operation. The anti-pinch is not active when the switch is held in the up position.

Front Passenger's Power Window

The front passenger's power window motor incorporates a pulser which generates pulses during the motor's operation and sends the pulses to the front passenger's power window control unit. As soon as the power window control unit detects no pulses from the pulser, the front passenger's power window control unit makes the power window motor stop and reverse. This is to prevent pinching your hand or fingers during auto-up operation. The anti-pinch is not active when the switch is held in the up position.

Scheme 10

Using the HDS

1. Connect the Honda Diagnostic System (HDS) to the vehicle's DLC.
2. Turn the ignition switch ON (II), then enter the vehicle's VIN and mileage at the prompts.
3. Select "Body Electrical" from the "System Selection" menu.
4. From the "Body Electrical System Select" menu, select "Power Windows".
5. From the "Mode" menu, select "Adjustment".
6. From the "Adjustment" menu, select "Window P Reset" for driver's side (passenger's side) power window.
7. Follow the prompts on the screen.
8. Confirm that the power window control unit is reset by using the driver's (passenger's) power window AUTO UP and AUTO DOWN function.

Scheme 11

1. Turn the ignition switch ON (II).
2. Move the driver's (passenger's) power window all the way down by using the driver's (passenger's) power window DOWN switch.
3. Open the driver's (passenger's) door. NOTE: Steps 4-7 must be done within 5 seconds of each other.
4. Turn the ignition switch OFF.
5. Push and hold the driver's (passenger's) power window DOWN switch.
6. Turn the ignition switch ON (II).
7. Release the driver's (passenger's) power window DOWN switch.
8. Repeat step 4-7 three more times.
9. Wait 1 second.
10. Confirm that AUTO UP and AUTO DOWN do not work. If AUTO UP and DOWN work, go back to step 1.
11. Move the driver's (passenger's) power window all the way down by using the driver's (passenger's) power window DOWN switch.
12. Pull up and hold the driver's (passenger's) power window UP switch until the power window reaches the fully closed position, then continue to hold the switch for 1 second.
13. Confirm that the power window control unit is reset by using the driver's (passenger's) power window AUTO UP and AUTO DOWN function. If the power window still does not work in AUTO, repeat the procedure several times, paying close attention to the 5 second time limit between steps. If it still does not work, go to B-CAN System Diagnosis Test Mode A (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A»(ref-291548-S06167950512008072900000) ).

Scheme 12

Scheme 13

Scheme 14

Front Passenger's

Note. To test the front passenger's power window switch, refer to the input test (see FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST ).

Scheme 15

1. Remove the front passenger's door panel and arm rest (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(ref-291563-S03686430832008072900000) ).
2. Remove the screw and disconnect the connector (A) from the front passenger's power window switch (B), then remove the switch assembly from the door panel.
3. Remove the three mounting screws, then remove the front passenger's power window switch from the switch panel (C).
4. Install in the reverse order of removal.
5. Reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(ref-291564-S33371150022008072900000) ).

Scheme 16

1. Remove the rear door panel and arm rest (see «FRONT DOOR WEATHERSTRIP REPLACEMENT»(ref-291563-S06768391282008072900000) ).
2. Remove the screw and disconnect the connector (A) from the rear power window switch (B), then remove the switch assembly from the door panel.
3. Remove the three mounting screws, then remove the rear power window switch from the switch panel (C).
4. Swap the rear power window switch with another known-good switch and test. If the original rear power window switch is faulty; replace it.
5. Install in the reverse order of removal.
