Clock Acura TL III facelift

Gauges & Instrument Panels 2 illustrations
Fig. 1: Clock - Circuit Diagram (Without Navigation)
Scheme 1: Clock - Circuit Diagram (Without Navigation)

Without Navigation

Note. Vehicles with navigation; refer to audio-HVAC subdisplay unit removal/installation (see AUDIO UNIT REMOVAL/INSTALLATION ).

Scheme 69

Scheme 69: Without Navigation
Scheme 69: Without Navigation
  1. Remove the dashboard center vent (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(ref-291501-S38703897532008072900000) ).
  2. Disconnect the 5P connector (A) from the clock. (Scheme 69): Identifying 5P Connector From Clock
  3. Remove the two mounting screws, and remove the clock (B). Terminals TESTING CONDITION CHART Cavity Wire Connect to 1 WHT/RED Constant power 2 YEL IG1 (Main clock power supply) 3 - Not used 4 BLK Ground (G503, G601) 5 RED/BLU Lights-on signal (-)
  4. Install in the reverse order of removal.
