Electronic Throttle Control System: Diagnosis Acura TL III facelift

APP Sensor Signal Inspection

Note. This procedure checks the APP sensor in its fully closed position. In any other position, the APP sensor stores DTCs which are covered in other troubleshooting procedures. Check for Temporary DTCs or DTCs with the HDS before doing this procedure. If any DTCs are indicated, troubleshoot them first, then do this procedure. Press the accelerator pedal several times to check its operation. If it does not operate smoothly, check the pedal, the throttle cable, and the APP sensor individually. If you find a problem in one of them, replace the faulty part(s).

Scheme 77

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch ON (II).
3. Make sure the HDS communicates with the ECM/PCM and the other vehicle systems. If it does not, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING (PART 2)»(ref-291526-S28484839382008072900000) ).
4. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2 %, the APP sensor is OK. If it is above 2 %, adjust the throttle cable (see «THROTTLE CABLE ADJUSTMENT»(ref-291515-S07251852712008072900000) ), then go to step 4.
5. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2 %, the APP sensor is OK. If it is above 2 %, update the ECM/PCM if it does not have the latest software (see «UPDATING THE ECM/PCM»(ref-291525-S06490175862008072900000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-291525-S00620566452008072900000) ), then go to step 5.
6. Make sure the accelerator pedal is not pressed, then check the APP SENSOR in the DATA LIST with the HDS. If it is below 2 %, the APP sensor is OK. If it is above 2 %, replace the APP sensor (see «APP SENSOR REPLACEMENT»(ref-291542-S23535966782008072900000) ), then go to step 1 .

Scheme 78

1. Remove the throttle cable (see «THROTTLE CABLE REMOVAL/INSTALLATION»(ref-291515-S07366073272008072900000) ).
2. Disconnect the accelerator pedal position (APP) sensor 6P connector (A).
3. Remove the bolts (B), and the APP sensor (C).
4. Install the parts in the reverse order of removal.

Scheme 79

1. Remove the glove box and panel (see «GLOVE BOX REMOVAL/INSTALLATION»(ref-291501-S34342810532008072900000) ).
2. Disconnect the throttle actuator control module 16P connector (A).
3. Remove the bolts (B), and the throttle actuator control module (C).
4. Install the parts in the reverse order of removal.
