VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 1
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Vehicle maintenance is based on mileage and operating conditions. Service schedules are based on the following primary operating conditions
Normal Service
- Driven More Than 10 Miles Daily
- No Operating Conditions From Severe Service Schedule
Severe Service (Unique Driving Conditions)
- Repeated Short Trips (Less Than 10 Miles)
- Severe Dust
- Severe Cold Weather
- Areas Using Road Salt (Or Similar Materials)
- Driving On Rough And/Or Muddy Roads
- Towing A Trailer
CAMSHAFT TIMING BELT
| CAUTION | Failure to replace a faulty camshaft timing belt may result in serious engine damage. |
The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".
Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.
Belts or components should be inspected and replaced if any of the following conditions exist
- Cracks Or Tears In Belt Surface
- Missing, Damaged, Cracked Or Rounded Teeth
- Oil Contamination
- Damaged Or Faulty Tensioners
- Incorrect Tension Adjustment
Replace camshaft timing belt every 90,000 miles.
WHEEL & TIRE SPECIFICATIONS
Wheel and tire information can be found on the label attached to the left side of the instrument panel, visible when the driver's door is open.
WHEEL TIGHTENING
Tighten wheel lug nuts to 80 ft. lbs. (110 N.m).
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
ANTI-LOCK BRAKE SYSTEM (ABS)
| CAUTION | Never mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors. |
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below. |
REPLACING BLOWN FUSES
| CAUTION | Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload. |
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
| CAUTION | Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle. |
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C); Ethylene-Glycol -35° F (-37°C) - 263° F (128°C). |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
NEW CAR LIMITED WARRANTY
Manufacturer will repair, or replace, at its option, any factory-installed part that is defective in material or workmanship under normal use. Coverage is for 3 years or 36,000 miles from date of first use, whichever occurs first.
REPLACEMENT PARTS WARRANTY
Acura replacement parts, when installed by an Acura dealer, are covered for 12 months or 12,000 miles. Parts purchased from, but not installed by, an Acura dealer are covered for 12 months only.
REPLACEMENT MUFFLER LIFETIME LIMITED WARRANTY
Covers replacement mufflers against defects in material or workmanship for as long as the original purchaser of the replacement muffler owns the vehicle on which the muffler is installed.
ORIGINAL EQUIPMENT BATTERY LIMITED WARRANTY
Covers a defective original battery completely for the first 24 months. If the battery fails after the first 24 months and before 36 months, a 50% credit will be given toward the purchase of a new battery.
REPLACEMENT BATTERY LIMITED WARRANTY
Covers a defective replacement battery completely for the first 6 months, if purchased from an Acura dealer. If battery fails after the first 6 months and before 36 months, a pro-rated credit will be given towards the purchase of a new battery. On 1991-93 models, replacement batteries are covered completely during the first 12 months of service. If battery fails after 12 months and before 36 months of service, a pro-rated credit will be given.
ACCESSORY LIMITED WARRANTY
Covers accessories installed prior to retail sale for defects in material or workmanship in normal use. Air conditioning and audio systems are covered for 36 months or 36,000 miles, whichever occurs first. All other dealer-installed accessories are covered for 12 months or 12,000 miles, whichever occurs first. Accessories installed after retail sale are covered from the date of purchase and installation of the accessory by an authorized dealer for 12 months or 12,000 miles.
RUST PERFORATION LIMITED WARRANTY
Covers any original body parts that are rusted completely through for 36 months with no mileage limit. Rust without perforation is covered under the New Car Limited Warranty.
SEAT BELT LIMITED WARRANTY
Manufacturer will repair, or replace, at its option, free of charge, any seat belt that fails to function properly during normal use for the useful life of the vehicle. This includes all parts and labor charges.
EMISSION SYSTEM WARRANTY (EXCEPT CALIFORNIA)
Vehicle is warranted against defects in material or workmanship which would cause it to fail to conform with all applicable Environmental Protection Agency (EPA) regulations as determined by a State Inspection and Maintenance Test. This warranty coverage lasts for 5 years or 50,000 miles, whichever occurs first.
EMISSION SYSTEM DEFECT WARRANTY (CALIFORNIA)
If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer for a period of 3 years or 50,000 miles, whichever occurs first. Certain emission-related parts are covered for 7 years or 70,000 miles, whichever occurs first. See copy of warranty for specific components covered.
EMISSION SYSTEM PERFORMANCE WARRANTY (CALIFORNIA)
If vehicle fails to pass a smog test performed by a licensed Smog Check station within 3 years or 50,000 miles, whichever occurs first, an authorized dealer will perform any repairs necessary for the vehicle to pass the smog test. Covers adjustments, diagnosis, repairs and replacements needed to bring vehicle into compliance with California emission requirements.
FUSE PANEL LOCATION
The interior fuse panel is located under the dashboard to the left of the steering column, the underhood fuse panel is located in the engine compartment next to the battery. The circuits protected by each fuse are listed on the plastic sheet inside the fuse panel cover.
Fuse & Circuit Breaker Identification
- C1 - 10 Amp Starter Relay
- C2 - 15 Amp Seat Heater
- C3 - 7.5 Amp Rear Window Defogger Relay, Cooling Fan Relay
- C4 - 10 Amp Electronic Ignition
- C5 - 15 Amp Front Wiper/Washer
- C6 - 10 Amp Rear Wiper/Washer
- C7 - 10 Amp Headlight Wiper
- C8 - 15 Amp Engine
- C9 - 15 Amp Ignition Coil
- C10 - 10 Amp Meter, Gauge
- C11 - 10 Amp Audio, Mirror
- C12 - 20 Amp Cigarette Lighter
- C13 - 10 Amp Anti-Theft
- C14 - 15 Amp Stop Light, Hight-Mount Stop Light, A/T Electronic Control Unit
- C15 - 20 Amp Audio (B)
- C16 - 10 Amp Clock (B), Room
- C17 - 25 Amp Rear Defogger
- C18 - 20 Amp Door Lock
- C19 - 25 Amp Blower
- C20 - 10 Amp Air Conditioning
- C21 - 10 Amp SRS-1
- C22 - 10 Amp SRS-2
- C23 - Not Used
- C24 - Not Used
- CIRCUIT BRAKER - 30 Amp Power Windows, Sunroof, Power Seat
UNDERHOOD MAIN FUSE PANEL IDENTIFICATION
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- F1 - Not Used
- F2 - 20 Amp O2 Sensor, Heater
- F3 - 15 Amp Horn, Hazard
- F4 - 15 Amp Left Headlight
- F5 - 15 Amp Right Headlight
- F6 - Not Used
- F7 - Not Used
- F8 - 15 Amp Front Fog Light
- F9 - 20 Amp Antilock Brake System
- F10 - 15 Amp Fuel Pump
- F11 - Not Used
- F12 - 15 Amp Tail Light
