Power Mirrors: Overview Acura RSX I facelift

Mirrors 3 illustrations

Scheme 7

Scheme 7: Component Location Index
Scheme 7: Component Location Index

Scheme 8

Scheme 8: Circuit Diagram
Scheme 8: Circuit Diagram

Scheme 9

Scheme 9: Function Test
Scheme 9: Function Test
  1. Carefully pry out the driver's switch panel (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(ref-218810-S00037846832006021000000) ).
  2. Disconnect the 13P connector (A) from the power mirror switch (B).
  3. Remove the two screws and the power mirror switch.
  4. Choose the appropriate test based on the symptom: Both mirrors don't work, go to step 5. Left mirror doesn't work, go to step 7 . Right mirror doesn't work, go to step 8 . Defogger doesn't work, go to step 9 .
