Engine Block: Other Acura RSX I facelift

Rod Bearing Selection

1. Inspect each connecting rod for cracks and heat damage.

Scheme 241

1. 2. Each rod has a tolerance range from 0 to 0.024 mm (0.0009 in.), in 0.006 mm (0.0002 in.) increments, depending on the size of its big end bore. It's then stamped with a number or bar (1, 2, 3 or 4/I, II, III, or IIII) indicating the range. You may find any combination of numbers and bars in any engine, (Half the number or bar is stamped on the bearing cap, the other half on the rod). If you can't read the code because of an accumulation of oil and varnish, do not scrub it with a wire brush or scraper. Clean it only with solvent or detergent. Normal Bore Size K20A3 Engine: 48.0 mm (1.89 in.) K20A2, K20Z1 Engines: 51.0 mm (2.01 in.)

Scheme 242

Scheme 243

Scheme 244

1. 3. The connecting rod journal codes are stamped on the crankshaft. Connecting Rod Journal Code Location (Letters or Bars)
2. 4. Use the big end bore codes and rod journal codes to select appropriate replacement bearings from the following table. NOTE: Color code is on the edge of the bearing. When using bearing halves of different colors, it does not matter which color is used in the top or bottom. K20A3 engine: K20A2, K20Z1 engines

Scheme 245

Scheme 246

1. If the engine is still in the vehicle, remove the subframe. 1 Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-218779-S36700053362006021000000) ). 2 Attach the chain hoist to the engine (see step 41 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 3 Disconnect the suspension lower arm ball joints (see step 10 on «KNUCKLE/HUB/WHEEL BEARING REPLACEMENT»(ref-218799-S39724779852006021000000) ). 4 Remove the rear mount mounting bolts (see step 45 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 5 Remove the front mount mounting bolt (see step 46 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 6 Remove the automatic transmission (ATF) filter mounting bolt (A/T) (see step 36 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 7 Use a marker to make alignment marks on the reference lines that align with the centers of the rear subframe mounting bolts. Remove the front subframe (see step 48 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ).
2. Remove the bolts/nuts securing the oil pan.
3. Drive an oil pan seal cutter between the oil pan and engine block.
4. Cut the oil pan seal by striking the side of the cutter to slide the cutter along the oil pan.
5. Remove the oil pan.

Scheme 247

Scheme 248

1. If the engine is still in the vehicle, remove the subframe. 1 Drain the engine oil (see «ENGINE OIL REPLACEMENT»(ref-218779-S36700053362006021000000) ). 2 Attach the chain hoist to the engine (see step 41 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 3 Disconnect the suspension lower arm ball joints (see step 10 on «KNUCKLE/HUB/WHEEL BEARING REPLACEMENT»(ref-218799-S39724779852006021000000) ). 4 Remove the rear mount mounting bolts (see step 45 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 5 Remove the front mount mounting bolt (see step 46 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ). 6 Use a marker to make alignment marks on the reference lines that align with the centers of the rear subframe mounting bolts. Remove the front subframe (see step 48 on «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ).
2. Remove the clutch cover (A), and remove the two bolts (B) securing the transmission.
3. Remove the bolts/nuts securing the oil pan.
4. Insert a flat tip screwdriver where shown, and separate the oil pan from the block.
5. Remove the oil pan.

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

1. Remove the engine assembly (see «ENGINE INSTALLATION»(ref-218775-S00985765942006021000000) ).
2. A/T model: Remove the transmission (see «TRANSMISSION REMOVAL»(ref-218795-S36453150732006021000000) ), then remove the drive plate (see «DRIVE PLATE REMOVAL AND INSTALLATION»(ref-218795-S23423725222006021000000) ).
3. M/T model: Remove the transmission (see «TRANSMISSION REMOVAL»(ref-218795-S36453150732006021000000) ). Remove the pressure plate and clutch disc (see «CLUTCH REPLACEMENT»(ref-218793-S28126012432006021000000) ), then remove the flywheel (see «FLYWHEEL REPLACEMENT»(ref-218793-S16256751842006021000000) ).
4. Remove the oil pan (see «OIL PAN REMOVAL»(ref-218777-S14135968772006021000000) ).
5. Remove the oil pump (see «OIL PUMP REMOVAL»(ref-218779-S09454865332006021000000) ).
6. Remove the cylinder head (see «CYLINDER HEAD REMOVAL»(ref-218776-S19098136512006021000000) ).
7. Remove the baffle plate.
8. If you can feel a ridge of metal or hard carbon around the top of each cylinder, remove it with a ridge reamer (A). Follow the reamer manufacturer's instructions. If the ridge is not removed, it may damage the pistons as they are pushed out.
9. Remove the 8 mm bolts.
10. Remove the bearing cap bolts. To prevent warpage, unscrew the bolts in sequence 1/3 turn at a time: repeat the sequence until all bolts are loosened.
11. Remove the lower block and bearings. Keep all bearings in order.
12. Remove the rod caps/bearings. Keep all caps/bearings in order.
13. Lift the crankshaft out of the engine, being careful not to damage the journals.
14. Remove the upper bearing halves from the connecting rods, and set them aside with their respective caps.
15. Use the wooden handle of a hammer (A) to drive out the pistons (B).
16. Reinstall the lower block and bearings on the engine in the proper order.
17. Reinstall the connecting rod bearings and caps after removing each piston/connecting rod assembly.
18. To avoid mix-up on reassembly, mark each piston/connecting rod assembly with its cylinder number. NOTE: The existing number on the connecting rod does not indicate its position in the engine, it indicates the rod bore size.

Scheme 256

1. Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-218777-S40031569512006021000000) ).
2. Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
3. Clean the keyway and threads.
4. Measure out-of-round at the middle of each rod and main journal in two places. The difference between measurements on each journal must not be more than the service limit. Journal Out-of-Round Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)
5. Measure taper at the edges of each rod and main journal. The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.0002 in.) max. Service Limit: 0.010 mm (0.0004 in.)

Scheme 257

1. 6. Place the engine block on the surface plate.
2. 7. Clean and install the bearings on the No. 1 and No. 5 journal of the engine block.
3. 8. Lower the crankshaft into the block.
4. 9. Measure runout on all main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit. Crankshaft Total Runout K20A3 Engine: Standard (New): 0.03 mm (0.0012 in.) max. Service Limit: 0.04 mm (0.0016 in.) K20A2, K20Z1 Engines: Standard (New): 0.02 mm (0.0008 in.) max. Service Limit: 0.03 mm (0.0012 in.)

Scheme 258

Scheme 259

Scheme 260

Scheme 261

1. Remove the crankshaft and pistons (see «CRANKSHAFT AND PISTON REMOVAL»(ref-218777-S40031569512006021000000) ).
2. Check the piston for distortion or cracks.
3. Measure the piston diameter at a point 11 mm (0.4 in.) from the bottom of the skirt. There are two standard-size pistons (No Letter or A, and B). The letter is stamped on the top of the piston. Letters are also stamped on the block as cylinder bore sizes. Piston Diameter Standard (New): No Letter (or A): 85.980-85.990 mm (3.3850-3.3854 in.) B: 85.970-85.980 mm (3.3846-3.3850 in.) Service Limit: No Letter (or A): 85.930 mm (3.3831 in.) B: 85.920 mm (3.3827 in.) Oversize Piston Diameter 0.25: 86.230-86.240 mm (3.3949-3.3953 in.)
4. Measure wear and taper in direction X and Y at three levels in each cylinder as shown. If measurements in any cylinder are beyond the oversize bore service limit, replace the block. If the block is to be rebored, refer to step 7 . after reboring. Cylinder Bore Size Standard (New): A or I: 86.010-86.020 mm (3.3862-3.3866 in.) B or II: 86.000-86.010 mm (3.3858-3.3862 in.) Service Limit: 86.070 mm (3.3886 in.) Oversize 0.25: 86.250-86.260 mm (3.3957-3.3961 in.) Reboring Limit: 0.25 mm (0.01 in.) max. Bore Taper: Limit: (Difference between first and third measurement) 0.05 mm (0.002 in.)
5. Scored or scratched cylinder bores must be honed.
6. Check the top of the block for warpage. Measure along the edges and across the center as shown. Engine Block Warpage Standard (New): 0.07 mm (0.003 in.) max. Service Limit: 0.10 mm (0.004 in.)
7. Calculate the difference between the cylinder bore diameter and the piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and engine block for excessive wear. Piston-to-Cylinder Bore Clearance Standard (New): 0.020-0.040 mm (0.0008-0.0016 in.) Service Limit: 0.05 mm (0.002 in.)

Cylinder Bore Honing

Only a scored or scratched cylinder bore must be honed.

Scheme 262

1. Measure the cylinder bores (see «BLOCK AND PISTON INSPECTION»(ref-218777-S09430537382006021000000) ). If the block is to be reused, hone the cylinders and remeasure the bores.
2. Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree cross-hatch pattern (A). Use only a rigid hone with 400 grit or finer stone such as Sunnen, AMMCO, or equivalent. Do not use stones that are worn or broken.
3. When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. Never use solvent, it will only redistribute the grit on the cylinder walls.
4. If scoring or scratches are still present in the cylinder bores after honing to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail and does not run the full length of the bore.

Scheme 263

Scheme 264

Scheme 265

1. Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(ref-218777-S40031569512006021000000) ).
2. Apply new engine oil to the piston pin snap rings (A), and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
3. Remove both snap rings (A). Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
4. Heat the piston and connecting rod assembly to about 158°F (70°C), then remove the piston pin.
