Blower Unit Component Replacement Acura RSX I рестайлинг

Climate Control System 4 illustrations ~265 words

Blower Unit Component Replacement

Note these items when overhauling the blower unit

Scheme 96

Scheme 96: Blower Unit Component Replacement
Scheme 96: Blower Unit Component Replacement
  1. The recirculation control motor (A), the power transistor (B), the blower motor (C), and the dust and pollen filters (D) can be replaced without removing the blower unit.
  2. Before reassembly, make sure that the recirculation control linkage and doors move smoothly without binding.
  3. After reassembly, make sure the recirculation control motor runs smoothly (see «RECIRCULATION CONTROL MOTOR TEST»(/acura/rsx/i-2004-2006/remont/automatic-hvac-system/#climate-control-system) ).

Scheme 97

Scheme 97: Evaporator Core Replacement
Scheme 97: Evaporator Core Replacement

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99
  1. Recover the refrigerant with a recovery/recycling/charging station (see «REFRIGERANT RECOVERY»(/acura/rsx/i-2004-2006/remont/automatic-hvac-system/#climate-control-system__refrigerant-recovery) ).
  2. Remove the bolt, then disconnect the suction line (A) and the receiver line (B) from the evaporator core.
  3. Remove the blower unit (see «BLOWER UNIT REMOVAL AND INSTALLATION»(/acura/rsx/i-2004-2006/remont/automatic-hvac-system/#climate-control-system) ).
  4. Remove the self-tapping screws and the expansion valve cover.
  5. Carefully pull out the evaporator core without bending the pipes.
  6. Install the core in the reverse order of removal, and note these items: If you're installing a new evaporator core, add refrigerant oil (KEIHIN SP-10) (see «A/C SERVICE TIPS AND PRECAUTIONS»(/acura/rsx/i-2004-2006/remont/automatic-hvac-system/#climate-control-system__ac-service-tips-and-precautions) ). Replace the O-rings with new ones at each fitting, and apply a thin coat of refrigerant oil before installing them. Be sure to use the correct O-rings for HFC-134a (R-134a) to avoid leakage. Immediately after using the oil, reinstall the cap on the container, and seal it to avoid moisture absorption. Do not spill the refrigerant oil on the vehicle; it may damage the paint. If the refrigerant oil contacts the paint, wash it off immediately. Make sure that there is no air leakage. Charge the system (see «SYSTEM CHARGING»(/acura/rsx/i-2004-2006/remont/automatic-hvac-system/#climate-control-system__system-charging) ).
