Engine Removal and Installation Acura RSX I

Mechanical 60 illustrations ~1872 words

Note. Use fender covers to avoid damaging painted surfaces. To avoid damaging the wire and terminals, unplug the wiring connectors carefully while holding the connector portion. Mark all wiring and hoses to avoid misconnection. Also, be sure that they do not contact other wiring or hoses, or interfere with other parts.

Scheme 1

Scheme 1: Engine Removal
Scheme 1: Engine Removal

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30
  1. Secure the hood in the wide open position (support rod in the lower hole).
  2. Make sure you have the anti-theft code for the radio, then write down the customer's audio presets.
  3. Relieve fuel pressure (see «FUEL PRESSURE RELIEVING»(/acura/rsx/i-2001-2004/remont/fuel-system/#fuel-supply-system__fuel-pressure-relieving) ).
  4. Disconnect the negative cable from the battery first, then disconnect the positive cable.
  5. Remove the battery.
  6. Remove the intake manifold cover.
  7. Disconnect the intake air temperature (IAT) sensor connector (A), and remove the breather hose (B), then remove the air cleaner housing (C).
  8. Remove the air intake duct.
  9. Remove the battery cable (A) from the underhood fuse/relay box, then remove the harness clamps (B) and ground cable (C).
  10. K20A3 engine: Remove the throttle cover (A). Fully open the throttle link and cruise control link by hand, then remove the throttle cable (B) and cruise control actuator cable (C) from the links. Loosen the locknuts (D), and remove the cables from the bracket.
  11. K20A2, K20Z1 engines: Fully open the throttle link and cruise control link by hand, then remove the throttle cable (A) and cruise control actuator cable (B) from the links. Loosen the locknuts (C), and remove the cables from the bracket.
  12. Disconnect the engine control module (ECM)/powertrain control module (PCM) connectors (A) and main wire harness connector (B).
  13. Remove the harness clamps (A) and grommet (B), then pull the engine wire harness through the bulkhead.
  14. Remove the fuel feed line (see «FUEL LINE/QUICK-CONNECT FITTING REMOVAL»(/acura/rsx/i-2001-2004/remont/fuel-system/#fuel-supply-system__fuel-linequick-connect-fitting-removal) ).
  15. Remove the evaporative emission (EVAP) canister hose (A) and brake booster vacuum hose (B).
  16. Remove the clutch slave cylinder (A) and clutch line bracket mounting bolt (B) (M/T).
  17. Remove the shift cable (A) and select cable (B) (M/T).
  18. Remove the drive belt (see «DRIVE BELT REPLACEMENT»(/acura/rsx/i-2001-2004/remont/charging-system/#charging-system__drive-belt-replacement) ).
  19. Remove the power steering (P/S) pump without disconnecting the P/S hoses.
  20. Remove the bolt securing the P/S hose bracket.
  21. Remove the radiator cap.
  22. Raise the vehicle on the hoist to full height.
  23. Remove the front wheels.
  24. Remove the splash shield.
  25. Loosen the drain plug in the radiator, and drain the engine coolant (see «COOLANT CHECK»(/acura/rsx/i-2001-2004/remont/cooling-system-mechanical/#cooling-system) ).
  26. Drain the transmission fluid: Manual transmission (see «TRANSMISSION FLUID INSPECTION AND REPLACEMENT»(/acura/rsx/i-2001-2004/remont/manual-trans/#manual-transmission) ). Automatic transmission (see «ATF REPLACEMENT»(/acura/rsx/i-2001-2004/remont/automatic-trans/#automatic-transmission) ).
  27. Drain the engine oil (see «ENGINE OIL REPLACEMENT»(/acura/rsx/i-2001-2004/remont/lubrication-system/#engine-lubrication) ).
  28. Disconnect the air fuel ratio (A/F) sensor connector (A) and secondary heated oxygen sensor (secondary HO2S) connector (B).
  29. Remove the three way catalytic converter (TWO assembly (C).
  30. 2005-2006 models: Check the flexible joint gasket (D) for damage. If the flexible joint gasket is damaged, replace the flexible joint gasket (see «FLEXIBLE JOINT GASKET REPLACEMENT»(/acura/rsx/i-2001-2004/remont/exhaust/#intake-manifold-and-exhaust-system) ). NOTE: Do not reuse the flexible joint gasket, when removing it.
  31. Disconnect the suspension lower arm ball joints (see «BALL JOINT REMOVAL»(/acura/rsx/i-2001-2004/remont/wheel-alignment/#front-suspension-and-rear-suspension__ball-joint-removal) ) and the stabilizer links (see «STABILIZER LINK REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/suspension-front/#front-suspension) ).
  32. Remove the driveshaft (see «DRIVESHAFT REMOVAL»(/acura/rsx/i-2001-2004/remont/axle-shafts/#drivelineaxle) ). Coat all precision finished surfaces with clean engine oil. Tie plastic bags over the driveshaft ends.
  33. Remove the shift cable holder (A), then remove the shift cable cover (B). To prevent damage to the control lever joint, be sure to remove the bolts securing the shift cable cover (A/T).
  34. Remove the spring clip (C) and control pin (D), then separate the shift cable (E) from the control lever (F) (A/T).
  35. Remove the lower hose.
  36. Remove the automatic transmission fluid (ATF) filter mounting bolt (A) (A/T).
  37. Remove the ATF cooler hoses (B), then plug the ATF cooler hoses and lines (A/T).
  38. Lower the vehicle on the hoist.
  39. Remove the upper hose (A) and heater hoses (B).
  40. Remove the radiator (see «RADIATOR AND FAN REPLACEMENT»(/acura/rsx/i-2001-2004/remont/cooling-system-mechanical/#cooling-system) ).
  41. Attach the chain hoist to the engine as shown.
  42. Remove the transmission mount bracket support bolt/nuts. M/T 2002-2003 Models: 2004-2006 Models: A/T 2002-2003 Models: 2004-2006 Models
  43. Remove the upper bracket mounting bolt and nut.
  44. Make sure the hoist brackets are positioned properly. Raise the hoist to full height.
  45. Remove the rear mount mounting bolts. Except 2005-2006 TYPE S Models: 2005-2006 TYPE S Models
  46. Remove the front mount bracket mounting bolt.
  47. Use a marker to make alignment marks on the reference lines (A) that align with the centers of the rear subframe mounting bolts (B).
  48. Remove the front subframe (C).
  49. Disconnect the compressor clutch connector (A), then remove the A/C compressor (B) without disconnecting the A/C hoses.
  50. Check that the engine/transmission is completely free of vacuum hoses, fuel and coolant hoses, and electrical wiring.
  51. Slowly lower the engine about 150 mm (6 in.). Check once again that all hoses and wires are disconnected from the engine/transmission.
  52. Lower the engine all the way. Remove the chain hoist from the engine.
  53. Remove the engine from under the vehicle.

Scheme 31

Scheme 31: Engine Installation
Scheme 31: Engine Installation

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59
  1. Install the accessory brackets, and tighten their bolts to the specified torques.
  2. Position the engine under the vehicle. Attach the chain hoist to the engine, then lift the engine into position in the vehicle. NOTE: Reinstall the mounting bolts/support nuts in the sequence given. Failure to follow this sequence may cause excessive noise and vibration, and reduce bushing life.
  3. Install the A/C compressor (A), and connect the compressor clutch connector (B).
  4. Install the subframe (A). Align the reference lines (B) on the subframe with the bolt head center, then tighten the bolts.
  5. Tighten the rear mount mounting bolts. Except 2005-2006 TYPE S Models: 2005-2006 TYPE S Models
  6. Loosely tighten the new front mount bracket mounting bolt.
  7. Lower the vehicle on the hoist.
  8. Tighten the upper bracket mounting bolt and nut.
  9. Tighten the support bolt/nuts. M/T 2002-2003 Models: 2004-2006 Models: A/T 2002-2003 Models: 2004-2006 Models
  10. Raise the vehicle on the hoist to full height.
  11. Loosen the front engine mount bracket mounting bolt, then tighten it to the specified torque.
  12. Lower the hoist.
  13. Remove the chain hoist from the engine.
  14. Raise the vehicle on the hoist to full height.
  15. Install the shift control cable (A) (A/T).
  16. Install the shift cable cover (B), then install the shift control cable bracket (C) (A/T).
  17. Install a new spring clip on the end of each driveshaft, then install the driveshaft. Make sure each clip "clicks" into place in the differential and intermediate shaft.
  18. Connect the suspension lower arm ball joints (see step 10 on «KNUCKLE/HUB/WHEEL BEARING REPLACEMENT»(/acura/rsx/i-2001-2004/remont/suspension-front/#front-suspension) ) and stabilizer links (see «STABILIZER LINK REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/suspension-front/#front-suspension) ).
  19. 2002-2004 models: Install the new flexible joint gasket (A). 2005-2006 models: Check the flexible joint gasket (A) for damage. If the flexible joint gasket is damaged, replace the flexible joint gasket (see «FLEXIBLE JOINT GASKET REPLACEMENT»(/acura/rsx/i-2001-2004/remont/exhaust/#intake-manifold-and-exhaust-system) ). NOTE: Do not reuse the flexible joint gasket, when removing it.
  20. Install the three way catalytic converter (TWO assembly (B); use new gasket (C) and new self locking nuts (D).
  21. Connect the air fuel ratio (A/F) sensor connector (E) and secondary heated oxygen sensor (secondary HO2S) connector (F).
  22. Install the radiator (see «RADIATOR AND FAN REPLACEMENT»(/acura/rsx/i-2001-2004/remont/cooling-system-mechanical/#cooling-system) ).
  23. Install the lower radiator hose.
  24. Tighten the automatic transmission fluid (ATF) filter mounting bolt (A), and install the ATF cooler hoses (B) (A/T).
  25. Install the splash shield.
  26. Lower the vehicle on the hoist.
  27. Install the upper radiator hose (A) and heater hose (B).
  28. Install the P/S pump.
  29. Install the bolt securing the power steering (P/S) hose bracket.
  30. Install the drive belt (see «DRIVE BELT REPLACEMENT»(/acura/rsx/i-2001-2004/remont/charging-system/#charging-system__drive-belt-replacement) ).
  31. Push the engine control module (ECM)/powertrain control module (PCM) connectors through the bulkhead, then install the grommet (A).
  32. Install the harness clamps (B).
  33. Connect the ECM/PCM connectors (A) and main wire harness connector (B).
  34. Install the throttle cable (see «THROTTLE CABLE REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/testing-diagnostics/#intake-air-system) ), then adjust the cable (see «THROTTLE CABLE ADJUSTMENT»(/acura/rsx/i-2001-2004/remont/testing-diagnostics/#intake-air-system) ).
  35. Install the cruise control actuator cable, then adjust the cable (see «CRUISE CONTROL ACTUATOR/CABLE REPLACEMENT»(/acura/rsx/i-2001-2004/remont/cruise-control-systems/#cruise-control) ).
  36. Install the brake booster vacuum hose (A) and the evaporative emission (EVAP) canister hose (B).
  37. Install the fuel feed line (see «FUEL LINE/QUICK-CONNECT FITTING INSTALLATION»(/acura/rsx/i-2001-2004/remont/fuel-system/#fuel-supply-system__fuel-linequick-connect-fitting-installation) ).
  38. Install the select cable (A) and shift cable (B) using the plastic washers (C), washers (D), and new cotter pins (E) (M/T).
  39. Install the clutch slave cylinder (A) and clutch line bracket mounting bolt (B) (M/T).
  40. Install the battery cable (A) on the underhood fuse/relay box, then install the harness clamps (B).
  41. Install the ground cable (C).
  42. Install the air intake duct.
  43. Install the air cleaner housing (A) and connect the intake air temperature (IAT) sensor connector (B).
  44. Install the breather hose (C).
  45. Install the intake manifold cover.
  46. Install the battery. Clean the battery posts and cable terminals with sandpaper, then assemble them and apply grease to prevent corrosion.
  47. Move the shift lever to each gear, and verify that the A/T gear position indicator follows the transmission range switch (A/T).
  48. Check that the transmission shifts into gear smoothly (M/T).
  49. Inspect for fuel leaks. Turn the ignition switch ON (II) (do not operate the starter) so the fuel pump runs for about 2 seconds and pressurizes the fuel line. Repeat this operation two or three times, then check for fuel leakage at any point in the fuel line.
  50. Refill the engine with engine oil (see step 3 on «ENGINE OIL REPLACEMENT»(/acura/rsx/i-2001-2004/remont/lubrication-system/#engine-lubrication) ).
  51. Refill the transmission with fluid: Manual transmission (see «TRANSMISSION FLUID INSPECTION AND REPLACEMENT»(/acura/rsx/i-2001-2004/remont/manual-trans/#manual-transmission) ). Automatic transmission (see «ATF REPLACEMENT»(/acura/rsx/i-2001-2004/remont/automatic-trans/#automatic-transmission) ).
  52. Refill the radiator with engine coolant, and bleed air from the cooling system with the heater valve open (see step 7 on «COOLANT REPLACEMENT»(/acura/rsx/i-2001-2004/remont/cooling-system-mechanical/#cooling-system) ).
  53. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(/acura/rsx/i-2001-2004/remont/testing-diagnostics/#idle-control-system) ).
  54. 2005-2006 models: Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure (see «ECM/PCM RESET (2005-2006 MODELS)»(/acura/rsx/i-2001-2004/remont/auxiliary-emission-control-systems/#fuel-system-emissions-systems__ecmpcm-reset-2005-2006-models) ).
  55. Inspect the idle speed (see «IDLE SPEED INSPECTION»(/acura/rsx/i-2001-2004/remont/testing-diagnostics/#idle-control-system__idle-speed-inspection) ).
  56. Inspect the ignition timing (see «IGNITION TIMING INSPECTION»(/acura/rsx/i-2001-2004/remont/ignition-system/#ignition-system) ).
  57. Check the wheel alignment (see «WHEEL ALIGNMENT»(/acura/rsx/i-2001-2004/remont/wheel-alignment/#front-suspension-and-rear-suspension__wheel-alignment) ).
  58. Enter the anti-theft code for the radio, then enter the customer's audio presets.
  59. Do the power window control unit reset procedure (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/rsx/i-2001-2004/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).
  60. Set the clock.

Scheme 60

Scheme 60: Engine Mount Replacement
Scheme 60: Engine Mount Replacement
