Interior Lights Acura RSX I

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Turn the light switch OFF.
2. Carefully pry off the lenses (A) with a small screwdriver. Spotlight: 8 W x 2
3. Remove the two mounting screws.
4. Disconnect the 2P connector (B) from the housing (C).
5. Check for continuity between the terminals in each switch position according to the table.
6. If the continuity check is not as specified, check the bulb(s). If the bulb is OK, replace the housing.

Scheme 10

Scheme 11

1. Turn the light switch OFF.
2. Carefully pry off the lens (A) with a small screwdriver. Ceiling Light: 8 W
3. Remove the two mounting screws.
4. Disconnect the 3P connector (B) from the housing (C).
5. Check for continuity between the terminals in each switch position according to the table.
6. If the continuity check is not as specified, check the bulb(s). If the bulb is OK, replace the housing.

Scheme 12

1. Open the hatch.
2. Carefully pry out the cargo area light (A). Cargo Area Light: 5 W
3. Disconnect the 2P connector (B) from the light.
4. Check for continuity between the No. 1 (+) and No. 2 (-) terminals. There should be continuity.
5. If there is no continuity, check the bulb (C). If the bulb is OK, replace the cargo area light.

Scheme 13

1. Open the hatch.
2. Remove the hatch trim panel (see «TRIM REMOVAL/INSTALLATION - HATCH AREA»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-hatch-area) ).
3. Disconnect the 2P connector (A) from the hatch latch (B).
4. Check for continuity between the No. 1 and No. 2 terminals. There should be continuity with the hatch open. There should be no continuity with the hatch closed.
5. If the continuity check is not as specified, replace the switch.

Scheme 14

1. Remove the dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/exteriorinterior-trim/#dashboard) ).
2. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/rsx/i-2001-2004/remont/entertainment-systems/#audio-system) ).
3. Disconnect the 2P connector (A) from the beverage holder light (B), then remove the beverage holder light from the dashboard. Beverage Holder Light: 1.4 W
4. Install in the reverse order of removal.

Scheme 15

1. Open the glove box.
2. Disconnect the 2P connector from the glove box light (A). Glove Box Light: 3.4 W
3. Check for continuity between the No. 1 and No. 2 terminals. There should be continuity with the switch released. There should be no continuity with the switch pushed.
4. If the continuity check is not as specified, replace the glove box light.
