BLEEDING COOLING SYSTEM
Always bleed air from cooling system after replacing coolant. Set heater for maximum heat. Remove radiator cap. Drain coolant reservoir. Fill coolant reservoir to MAX mark with 50/50 water-coolant mixture. Loosen bleed bolt and fill radiator to base of filler neck. Close bleed bolt when coolant flows out without bubbles. Tighten bleed bolt. With radiator cap removed, start and operate engine to normal operating temperature. Add coolant if necessary and check for leaks.
Scheme 1
Scheme 1: DRIVE BELT ROUTING (MDX, 3.2CL & 3.2TL)
Scheme 2
Scheme 2: DRIVE BELT ROUTING (RSX)
Scheme 3
Scheme 3: DRIVE BELT ROUTING (3.5RL)
Scheme 4
Scheme 5
Note. For information of electric cooling fans (if equipped), see ELECTRIC COOLING FANS article.
BELT ADJUSTMENT
| Application | (1) Deflection - In. (mm) |
|---|
| A/C Compressor |
| MDX, RSX, 3.2CL & 3.2CL | (2) |
| 3.5RL | .31-.43 (8.0-11.0) |
| Generator |
| MDX, RSX, 3.2CL & 3.2TL | (2) |
| 3.5RL | .37-.45 (9.5-11.5) |
| Power Steering |
| RSX | (2) |
| MDX, 3.2CL & 3.2TL | .51-.65 (13.0-16.5) |
| 3.5RL | .41-.49 (10.5-12.5) |
| (1) Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run, after 5 minutes of belt operation. (2) Equipped with automatic belt tensioner. |
| (1) | Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run, after 5 minutes of belt operation. |
| (2) | Equipped with automatic belt tensioner. |
COOLING SYSTEM SPECIFICATIONS
| Model | Specification |
|---|
| Coolant Replacement Interval |
| Except MDX, RSX & 3.2TL | (1) 45,000 Miles |
| MDX, RSX & 3.2TL | (2) 120,000 Miles |
| Coolant Capacity (3) |
| RSX |
| A/T | 5.3 Qts. (5.0L) |
| M/T | 5.7 Qts. (5.4L) |
| MDX | 8.0 (7.6) |
| 3.2 CL & 3.2TL | (4) 5.9 Qts. (5.6L) |
| 3.5RL | (5) 6.4 Qts. (6.1L) |
| Pressure Cap Opens | 14.0-18.0 psi |
| Thermostat Opens |
| Starts | 169-176°F (76-80°C) |
| Fully Open | 194°F (90°C) |
| (1) Replace after 2 years, and every 30,000 miles thereafter. (2) Replace after 10 years, and every 60,000 miles thereafter. (3) Specification is for coolant change. Add 1.2-2.0 qts. (1.1-1.9L) for system overhaul. (4) Specification includes .60-.80 qts. (.60-.80L) for reservoir capacity. (5) Specification is for coolant change. For system overhaul, coolant capacity is 9.1 qts. (8.6L) |
| (1) | Replace after 2 years, and every 30,000 miles thereafter. |
| (2) | Replace after 10 years, and every 60,000 miles thereafter. |
| (3) | Specification is for coolant change. Add 1.2-2.0 qts. (1.1-1.9L) for system overhaul. |
| (4) | Specification includes .60-.80 qts. (.60-.80L) for reservoir capacity. |
| (5) | Specification is for coolant change. For system overhaul, coolant capacity is 9.1 qts. (8.6L) |
