Ignition Switch Acura RL II facelift

Steering Column Switches 5 illustrations ~274 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

Scheme 2

Scheme 2: Circuit Diagram
Scheme 2: Circuit Diagram

Note. For key and shift interlock information, see A/T INTERLOCK SYSTEM .

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or servicing.

Scheme 3

Scheme 3: Ignition Switch Test
Scheme 3: Ignition Switch Test

Scheme 4

Scheme 4
Scheme 4
  1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-348526-S32567287482009112400000) ).
  2. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rl/ii-facelift-2008-2012/remont/exteriorinterior-trim/#dashboard) ). Remove the steering column covers (see step 7 under «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-348511-S08332992362009112400000) ).
  3. Disconnect the 7P connector (A) from ignition switch (B).
  4. Check for continuity between the terminals in each switch position according to the table.
  5. If the continuity checks do not agree with the table, replace the ignition switch (see «IGNITION SWITCH REPLACEMENT»(/acura/rl/ii-facelift-2008-2012/remont/steering-column-switches/#ignition-switch) ).
  6. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-348526-S32567287482009112400000) ).

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or servicing.

Scheme 5

Scheme 5: Ignition Switch Replacement
Scheme 5: Ignition Switch Replacement
  1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-348526-S32567287482009112400000) ).
  2. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rl/ii-facelift-2008-2012/remont/exteriorinterior-trim/#dashboard) ). Remove the steering column covers (see step 7 under «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-348511-S08332992362009112400000) ).
  3. Disconnect the 7P connector (A) from ignition switch (B).
  4. Remove the two screws and the ignition switch.
  5. Install the ignition switch in the reverse order of removal.
  6. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(ref-348526-S32567287482009112400000) ).
