Compass type

There are two ways to enter the diagnostic mode

Mode 1

Connect the SCS connector (see FORCED STARTING OF DISPLAY ) to the navigation service connector located in the trunk. Turn the ignition switch to the ON (II) position. The display goes directly to the diagnostic menu screen shown below.

Note. When finished troubleshooting, make sure to remove the SCS connector.

Mode 2

Turn the ignition switch ON (II). Use the navigation display hard buttons as described below

Press and hold the MENU, MAP/GUIDE, and CANCEL buttons for about 5 seconds. The display screen goes directly to the Select Diagnosis Items menu shown below.

Scheme 103

Scheme 103: Compass type

After the display changes to the Select Diagnosis Items menu, select the item you want to check and the diagnostic will start. To return to the previous screen, select RETURN.

  1. Navi System (Link)
  2. Monitor Check
  3. Unit Check
  4. Car Status
  5. F-CAN (System link)
  6. GPS Information
  7. Yaw Rate
  8. Tire Calibrate
  9. Functional Setup
  10. Version
  1. This diagnostic tests the cables connecting the navigation components. Ensure that the ignition switch is in the ON (II) position. When the diagnostic begins you hear a bong sound. The system is in a Detecting mode, and is waiting for all items in white to be tested. This includes the navigation voice control (navigation TALK/BACK) buttons, and microphone. Press the navigation TALK button on the steering wheel, and in a normal voice, say "testing." The Talk indicator on the screen should turn green, and the voice level indicator should move to at least the 6th bar to pass. Next, press the navigation BACK button. The Cancel indicator should turn green.
  2. If all of the communication lines connecting the system components, and the navigation TALK/BACK buttons/microphone check out OK (all block diagram items green), then the OK indicator turns green.
  3. If there is a problem with the system, the faulty system component item turns to red, and the screen shows NG in red. Use the troubleshooting index, and other diagnostic screens to help locate the problem.
  4. The indication on the screen may not change until you cycle the ignition switch. After repairing the affected cable or system, repeat this diagnostic.

Note. Green boxes and a green OK indicate that the communications lines (cables) are intact. This diagnostic does not necessarily imply that the individual components are functioning properly. For instance, the GPS antenna wire may be crushed, but still show as green. A road test, or other diagnostic may be necessary to find the problem. Compass type is not equipped with TALK/BACK buttons or the microphone. Select Return to return to the Diagnosis Menu.

USA models

Scheme 104

Scheme 104

Alaska models

Scheme 105

Scheme 105

Note. The mic level indicator must reach the 6th bar or greater to pass the test. If the XM link is red or flashing red, go to audio system symptom troubleshooting, or see XM (HIP) diagnostic screen.
