Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).
Scheme 97
Scheme 98
Scheme 99
Scheme 100
- Clear the DTCs with the HDS.
- Turn the ignition switch to LOCK (0), and then back to ON (II).
- Move the left power mirror in each direction with the power mirror switch.
- Check for DTCs with the HDS. Is DTC B2183 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections.
- Select POWER SEAT/POWER MIRROR from the BODY ELECTRICAL SYSTEM SELECT menu, and enter the DATA LIST.
- Check the NORMAL/ABNORMAL information of the DRIVER DOOR MIRROR VERTICAL SENSOR in the DATA LIST. Is the information indicator ABNORMAL? YES -Go to step 7. NO -Replace the driver's MPCS unit.
- Turn the ignition switch to LOCK (0).
- Disconnect driver's MPCS unit connector A (40P).
- Disconnect the left power mirror 16P connector.
- Check for continuity between driver's MPCS unit connector A (40P) terminal No. 9 and left power mirror 16P connector terminal No. 11. Is there continuity? YES -Go to step 11. NO -Repair open in the wire.
- Check for continuity between the left power mirror 16P connector terminal No. 11 and body ground. Is there continuity? YES -Repair short to ground in the wire. NO -Go to step 12.
- Check for continuity between the left power mirror 16P connector terminals No. 11 and No. 12. Is there continuity? YES -Repair short in the wires. NO -Go to step 13.
- Reconnect driver's MPCS unit connector A (40P).
- Turn the ignition switch to ON (II).
- Measure the voltage between the left power mirror 16P connector terminal No. 11 and body ground. Is there about 5 V? YES -Replace the left power mirror. NO -Replace the driver's MPCS unit.
