SH-AWD Differential Clutch Torque Memorization

Whenever the side clutch set is replaced, the differential clutch torque memorization must be done.

Scheme 1: SH-AWD Differential Clutch Torque Memorization

With the ignition switch to LOCK (0), connect the HDS to the 16P DLC (A) behind the driver's dashboard lower cover.
Turn the ignition switch to ON (II).
Make sure the HDS communicates with vehicle and the SH-AWD control unit. If it doesn't troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(ref-348508-S35625078472009112400000) ).
From the mode menu, select MISCELLANEOUS TEST, then select NEUTRAL MENU with the HDS and follow the screen prompts. NOTE: See the HDS help menu for specific instructions.
