Under-hood Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| A/C compressor clutch relay | 2 | 4 | |
| A (ELD) | 9 | 3 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| B | 11 | 1 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Blower motor relay | 1 | 4 | |
| C | 12 | 2 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| D | 8 | 9 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| E | 13 | 16 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| F | 14 | 20 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Fog lights relay | 4 | 4 | |
| G | 10 | 2 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| H | 15 | 14 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| J | 17 | 10 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| K | 16 | 5 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Rear window defogger relay | 3 | 4 | |
| Windshield wiper relay | 5 | 4 | |
| T1 | 7 | | Starter cable (see CONNECTOR TO HARNESS INDEX ) |
| T101 | 6 | | Engine wire harness (see ENGINE WIRE HARNESS (FRONT BRANCH) ) |
UNDER-HOOD FUSE/RELAY BOX REFERENCE CHART
Scheme 59
Auxiliary Under-hood Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| Daytime running lights relay (1) | 1 | 5 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Adaptive cruise control (ACC) relay | 3 | 5 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Radiator fan control (RFC) unit relay | 2 | 4 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| (1) Canada models |
AUXILIARY UNDER-HOOD RELAY BOX REFERENCE CHART
Scheme 60
Driver's Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| A | 6 | 6 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Accessory power socket relay | 19 | 4 | |
| A/F sensor relay | 20 | 4 | |
| B | 12 | 6 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASH BRANCH) ) |
| C | 11 | 12 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASH BRANCH) ) |
| D | 13 | 17 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASH BRANCH) ) |
| E | 8 | 16 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| F | 9 | 14 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| G | 14 | 6 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| H | 15 | 14 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| Ignition coil relay | 23 | 4 | |
| J | 27 | 21 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| K | 26 | 12 | Driver's door subharness (see DRIVER'S DOOR WIRE HARNESS A ) |
| M | 25 | 3 | MICU service check connector |
| N | 2 | 45 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| P (MICU) | 17 | 30 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| PGM-FI main relay 1 (Fl MAIN) | 21 | 4 | |
| PGM-FI main relay 2 (FUEL PUMP) | 24 | 4 | |
| 22 | | Not used |
| Q (MICU) | 16 | 14 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| R (MES connector) | 3 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| S | 5 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Starter cut relay 2 | 18 | 4 | |
| T | 7 | 6 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Turn signal/hazard relay 1 | 4 | 6 | |
| W | 10 | 5 | Left side wire harness (see LEFT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| X | 1 | 39 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
DRIVER'S UNDER-DASH FUSE/RELAY BOX REFERENCE CHART
Scheme 61
Passenger's Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| A | 1 | 1 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| B | 2 | 10 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| C | 9 | 5 | Right side wire harness (see RIGHT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| D | 6 | 17 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| E | 11 | 14 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| Fuel fill door open relay | 5 | 4 | |
| F | 7 | 8 | Right side wire harness (see RIGHT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| G | 8 | 14 | Right side wire harness (see RIGHT SIDE WIRE HARNESS (FRONT BRANCH) ) |
| H | 10 | 3 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| J | 3 | 13 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| Headlight washer relay (1) | 12 | 4 | |
| Seat heater relay | 4 | 4 | |
| Throttle actuator control module relay | 13 | 4 | |
| (1) Canada models |
PASSENGER'S UNDER-DASH FUSE/RELAY BOX REFERENCE CHART
Scheme 62
Auxiliary Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| Starter cut relay 1 | 1 | 4 | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASH BRANCH) ) |
AUXILIARY UNDER-DASH FUSE/RELAY BOX REFERENCE CHART
Scheme 63
Driver's Auxiliary Under-dash Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| ACC cut relay | 3 | 5 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (AROUND THE STEERING COLUMN) ) |
| IG2 cut relay | 2 | 5 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (AROUND THE STEERING COLUMN) ) |
DRIVER'S AUXILIARY UNDER-DASH RELAY BOX REFERENCE CHART
Scheme 64
Passenger's Auxiliary Under-dash Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| Rear seat heater relay | 4 | 4 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
PASSENGER'S AUXILIARY UNDER-DASH RELAY BOX REFERENCE CHART
Scheme 65
