Mode Control Motor Test Acura RL II

Mode Control Motor Test

Note. Before testing, check for HVAC DTCs (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 108

1. Disconnect the 5P connector from the mode control motor. NOTE: Incorrectly applying power and ground to the mode control motor will damage it. Follow the instructions carefully.
2. Connect battery power to the No. 1 terminal of the mode control motor, and ground the No. 2 terminal; the mode control motor should run smoothly, and stop at Vent. If it doesn't, reverse the connections; the mode control motor should run smoothly, and stop at Defrost. When the mode control motor stops running, disconnect battery power immediately.
3. If the mode control motor did not run in step 2 , remove it, then check the mode control linkage and doors for smooth movement. If the linkage and doors move smoothly, replace the mode control motor (see «MODE CONTROL MOTOR REPLACEMENT»(/acura/rl/ii-2004-2008/remont/automatic-hvac-system/#hvac) ). If the linkage or doors stick or bind, repair them as needed.

Scheme 109

Scheme 110

1. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#dashboard) ).
2. Disconnect the connectors (A) from the power tilt/ telescopic steering control unit, the adaptive front lighting control unit, the electronically controlled power steering control unit, and the daytime running lights control unit. Remove the relay (B) and the power tilt/telescopic steering control unit (C), then remove the self-tapping screws and the bracket (D).
3. Disconnect the 5P connector (A) from the mode control motor. Remove the harness clips (B). Remove the self-tapping screws and the mode control motor (C).
4. Install the motor in the reverse order of removal. Make sure the pin on the motor is properly engaged with the linkage. After installation, make sure the motor runs smoothly.
