Collision Mitigation Brake System (cmbs) Acura RL II

Collision/avoidance 13 illustrations ~2744 words

Scheme 1

Scheme 1: Component Location Index

Scheme 2

Scheme 2

CMBS Indicator

If the system is OK, the CMBS indicator goes off 2 seconds after turning the ignition switch ON (II). The CMBS indicator comes on when the adaptive cruise control (ACC) unit detects a problem in the system.

Note. The ACC indicator indicates problems related with the ACC system and the CMBS. The CMBS indicator only indicates its system problems. The CMBS works with related systems such as the VSA system. If these related systems have a problem, the CMBS does not operate. In this case, the CMBS indicator and the related system indicator come on.

When a problem is detected by the self-diagnostic function, the CMBS stops operating, turns on the CMBS indicator, indicates the problem on the MID, and stores the DTC.

CMBS OFF Switch

Press and hold the CMBS OFF switch for at least a second to turn the CMBS off and on.

CMBS Indication

  1. If the system is OK, the CMBS indicator comes on for 5 seconds after turning the ignition switch ON (II) with the CMBS OFF switch on.
  2. When the system is activated, the word "BRAKE" is indicated on the MID and the warning buzzer sounds. First stage, BRAKE indicator and buzzer Second stage, BRAKE indicator, buzzer, light braking, and light seat belt tension Third stage, BRAKE indicator, buzzer, strong braking, and strong seat belt tension
  3. If the system stops operating because of a problem, the MID indicates the problem.

Adaptive Cruise Control (ACC) Unit

The ACC unit controls the brake and warning when the system recognizes the danger of a collision. The ACC unit has a self-diagnostic function. If the system detects a problem, it stops the CMBS, and turns on the CMBS indicator.

CMBS Initial Check

The ACC unit turns on the CMBS indicator if the CMBS initial check is not completed.

Note. For proper CMBS operation, if the ACC unit or the VSA modulator-control unit is replaced, do the CMBS initial check incomplete troubleshooting (DTC 100) (see DTC 100: CMBS INITIAL CHECK INCOMPLETE ).

Millimeter Wave Radar Unit

The millimeter wave radar unit recognizes the position of the vehicle running ahead and detects the two vehicles speed differential.

The ACC unit receives this information from the millimeter wave radar unit.

The millimeter wave radar unit also has an error detect function, and sends a signal to the ACC unit if an error is detected.

How to Troubleshoot DTCs

Check and clear the DTCs with the HDS.

Note. When both the ACC and CMBS indicators come on, do the ACC system troubleshooting first (except DTC 100).

Before troubleshooting, check and note these items

  1. Ask the client about the conditions when the problem occurred, and try to reproduce the same conditions for troubleshooting.
  2. If the symptom does not appear and the CMBS indicator does not come on during the test-drive, but troubleshooting is done based on the DTC, check for poor connections or loose terminals at all connectors related to the circuit that you are troubleshooting.
  3. After the troubleshooting or repairs are done, clear the DTCs, and test-drive the vehicle under the same conditions as when the DTC was originally.
  4. The ACC system and the CMBS may sometimes stop working because of the environment (weather, road conditions, driving conditions, etc.). A DTC may be stored in these cases.

DTCs that may be stored even when the system is normal

DTC 88: ACC indicator does not come on, CMBS indicator comes on

The millimeter wave radar unit overheats, the power supply voltage for the millimeter wave radar unit is low, or there is a communication error between the ACC unit and the millimeter wave radar unit.

DTC 95: ACC indicator does not come on, CMBS indicator comes on

Battery voltage is too high.

DTC 96: ACC indicator does not come on, CMBS indicator comes on

Battery voltage is too low.

DTC 97: ACC indicator does not come on, CMBS indicator comes on

Extensive driving on a rough road or the ignition switch is turned ON (ID/OFF.

DTC 102: ACC indicator does not come on, CMBS indicator comes on

Parking brake not fully released, or driving with the parking brake stuck.

Scheme 3

Scheme 3: How to Retrieve DTCs
  1. With the ignition switch OFF, connect the HDS to the data link connector (DLC) (A) under the left side of the dashboard.
  2. Turn the ignition switch ON (II).
  3. Make sure the HDS communicates with the vehicle and the ACC unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2004-2008/remont/testing-diagnostics/#pgm-fi-system) ).
  4. Follow the prompts on the HDS to display the DTC(s) on the screen. After determining the DTC, refer to the «DTC TROUBLESHOOTING»(/acura/rl/ii-2004-2008/remont/collisionavoidance/#collision-mitigation-brake-system-cmbs) . NOTE: See the HDS Help menu for specific instructions.

How to Clear DTCs

Note. You cannot clear the DTCs manually.

  1. With the ignition switch OFF, connect the HDS to the data link connector (DLC) (A) under the left side of the dashboard.
  2. Turn the ignition switch ON (II).
  3. Make sure the HDS communicates with the vehicle and the ACC unit. If it does not communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2004-2008/remont/testing-diagnostics/#pgm-fi-system) ).
  4. Clear the DTC(s) by following the screen prompts on the HDS. NOTE: See the HDS Help menu for specific instructions. Some DTCs cannot be cleared until the radar aiming is complete.

DTC Troubleshooting Index

DTCDetection ItemAdaptive Cruise Control (ACC) IndicatorCMBS Indicator
11Left rear wheel sensor problemOO
12Right rear wheel sensor problemOO
13Left front wheel sensor problemOO
14Right front wheel sensor problemOO
20Steering angle sensor malfunctionO
21Yaw rate-lateral/longitudinal acceleration sensor malfunctionOO
22Yaw rate-lateral/longitudinal acceleration sensor center position revision value errorOO
23Yaw rate-lateral/longitudinal acceleration sensor gain errorOO
25Yaw rate-lateral/longitudinal acceleration sensor stabilizing malfunctionOO
30Adaptive cruise control (ACC) relay circuit malfunctionOO
34Master cylinder brake fluid pressure sensor circuit open/shortO
35Master cylinder brake fluid pressure sensor center position errorO
36Master cylinder brake fluid pressure sensor shift errorO
60Communication line errorOO
61Millimeter wave radar unit communication errorOO
62Millimeter wave radar sensor errorOO
63Millimeter wave radar unit aiming errorOO
64CMBS operation error (excessive operation)O
88Millimeter wave radar out of detection areaO
90A/T system and/or PGM-FI system malfunctionO
95Power supply voltage too highO
96Power supply voltage too lowO
97CMBS offset cancel timeoutO
100CMBS initial check incompleteOO
102CMBS parking brake incomplete releasingO
103CMBS brake control prohibitionO
105Dust or dirt on the millimeter wave radar unitO
107Millimeter wave radar unit aiming incompleteOO
110Lost communication with the PCM (PGM-FI system)O
111Lost communication with the PCM (A/T system)O
112Lost communication with the VSA modulator-control unitO
113Lost communication with the gauge control moduleO
115Lost communication with the SH-AWD control unitO
NOTE: When both the ACC and CMBS indicators come on, do the ACC system troubleshooting first (except DTC 100).
NOTE
When both the ACC and CMBS indicators come on, do the ACC system troubleshooting first (except DTC 100).

DTC TROUBLESHOOTING INDEX

Symptom Troubleshooting Index

SymptomDiagnostic procedureAlso check for
CMBS OFF switch does not turn on/turn off (CMBS indicator does not change)Adaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Test the CMBS OFF switch (see CMBS OFF SWITCH TEST/REPLACEMENT ). Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ).An open in the wire A short in the wire
The MID does not indicate when the CMBS OFF switch is operatedAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Test the CMBS OFF switch (see CMBS OFF SWITCH TEST/REPLACEMENT ). Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ).An open in the wire A short in the wire
The buzzer does not soundAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ).
The buzzer does not sound when the CMBS OFF switch is operatedAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ).
The MID does not indicate with the CMBS operatingAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Do the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION ).
The CMBS system operates frequentlyAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Check the millimeter wave radar unit. Check the front emblem for warpage. Check the wheel alignment.Driving condition, weather, environmental influence
The CMBS system operated without danger of collisionAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Check the millimeter wave radar unit. Check the front emblem for warpage. Check the wheel alignment.Driving condition, weather, environmental influence
The CMBS system didn't operateAdaptive cruise control (ACC) system troubleshooting (No DTC Indication) (see ADAPTIVE CRUISE CONTROL (ACC) SYSTEM TROUBLESHOOTING (NO DTC INDICATION) ). Check the millimeter wave radar unit. Check the front emblem for warpage. Check the wheel alignment.Driving conditions, weather, environmental influences Undetectable environment
CMBS indicator does not come onDo the gauge control module self-diagnostic function (see SELF-DIAGNOSTIC FUNCTION )
CMBS indicator does not go offSymptom troubleshooting (see CMBS INDICATOR DOES NOT GO OFF )
HDS does not communicate with the adaptive cruise control (ACC) unit or the vehicleTroubleshoot the DLC circuit (see DLC CIRCUIT TROUBLESHOOTING )

TROUBLESHOOTING CHART

System Description

The collision mitigation brake system (CMBS), anticipates rear-end collisions and assists brake operation to reduce the impact on occupants and vehicle damage. The system works in combination with the e-pretensioners, which retract the seat belts in anticipation of impact.

Scheme 4

Scheme 4: CMBS Operation
  1. Warnings are both audible (warning buzzer) and visual (MID)
  2. Evasive action support and collision-speed reduction by brake control

Main Functions of CMBS

  1. When a collision with a vehicle ahead is about to happen at a vehicle speed greater than 9 mph (15 km/h) and the relative speed (the speed difference from the vehicle ahead) is greater than 9 mph (15 km/h), the system provides warnings (audible and visual) and brake control.
  2. When approaching a vehicle ahead and the distance to the vehicle ahead is very close, the system provides the collision warning (1st stage) by the MID indication and buzzer sound.
  3. When the closing distance continues to decrease and there is a high risk of collision, the system applies light braking (2nd stage) with the 1st stage warning.
  4. When the system judges that a collision is imminent, the system activates emergency brake control.

CMBS Control

The CMBS is operated by the ACC unit. The CMBS has these functions

Obstacle determination function

The system determines the potential for collision by the distance from the vehicle ahead and the relative speed based on the millimeter wave radar unit and the predictable course calculated by the driving conditions (wheel speed and yaw rate).

Warning function

When there is a high risk of collision, the system sends warning directions to the gauge control module and warns by both audible and visual means.

Brake control function

When there is a high risk of collision, the system sends brake directions to the VSA modulator-control unit and controls braking action.

CMBS Activation Conditions

The system can activate (warn the driver, apply the brakes) when it detects or encounters these situations

  1. Metallic projections on the road
  2. Metallic manhole and drain covers
  3. Signs and guardrails ahead
  4. Low overpasses and narrow gates
  5. Approaching vehicles that are turning left or right
  6. Passing slower vehicles ahead

The system does not activate (no warning or intervention) when it detects or encounters these situations

  1. Low-speed, heavy traffic (such as in a traffic jam)
  2. Being cut-off by a slower vehicle
  3. Approaching a vehicle stopped at an angle
  4. Driving on curves
  5. Approaching a bicycle or moped
  6. Dirt or snow stuck on the emblem
  7. Heavy rain or snow

When the CMBS activates, it sounds and feels just like ABS activation.

Scheme 5

Scheme 5

Gauge Control Module

When a problem or malfunction is detected, the CMBS indicator comes on. With some problems or malfunctions, the condition is displayed on the MID.

When the CMBS is turned off by the CMBS OFF switch, the CMBS indicator comes on, and the MID indicates that the CMBS is off.

Scheme 6

Scheme 6: Gauge Control Module

The CMBS can be turned off by the CMBS OFF switch on the left side of the dashboard next to the gauge control module. (Press and hold the switch for more than a second.)

Scheme 7

Scheme 7: CMBS OFF Switch

Scheme 8

Scheme 8: Adaptive Cruise Control (ACC) System Inputs and Outputs
Terminal numberWire colorTerminal signTerminal nameDescriptionSignal
1REDBRK DIAGBrake diagnosisDetects ACC relayACC system brake operated or brake pedal pressed: battery voltage
2BLUIG1Ignition signalDetects ignition signalIgnition switch ON (II): battery voltage Ignition switch OFF: about 0 V
3GRNSGSensor groundSensor ground
5REDVCCVoltage constant currentProvides sensor voltageIgnition switch ON (II): about 5 V Ignition switch OFF: about 0 V
6BLUPRESS FRPressure front rightDetects the brake fluid pressure signal of the right front brake caliperIgnition switch ON (II): about 0.5 - 4.5 V Ignition switch OFF: about 0 V
8BLUK-LINEData linkSends and receives scan tool signal
9BLKPGPower groundGround circuit for the ACC system
10WHTCANHCAN High lineF-CAN communication (high) circuit
11BLKLG1Logic ground 1Ground circuit for the ACC system
12BLKLG2Logic ground 2Ground circuit for the ACC system
13WHTVBUBack-up voltageProvides DTC memory voltageBattery voltage
14PNKPRESS FLPressure front leftDetects the brake fluid pressure signal of the left front brake caliperIgnition switch ON (II): about 0.5 - 4.5 V Ignition switch OFF: about 0 V
16BLUBRK LAMPBrake lightDrives the ACC relayIgnition switch ON (II): battery voltage Ignition switch OFF: about 0 V
17WHTIWR TRXMillimeter wave radar data linkCommunicates with the millimeter wave radar unitIgnition switch ON (II): battery voltage Ignition switch OFF: about 0 V
20BLKCANLCAN Low lineF-CAN communication (low) circuit

TERMINAL DESCRIPTION CHART

Scheme 9

Scheme 9: Circuit Diagram

Scheme 10

Scheme 10

DTC 20: Steering Angle Sensor Malfunction

  1. Turn the ignition switch ON (II).
  2. Check for VSA system DTCs with the HDS. Are any DTCs indicated? YES - Troubleshoot the indicated VSA system DTC(s). NO - Go to step 3.
  3. Clear the DTCs with the HDS.
  4. Turn the adaptive cruise control (ACC) switch ON.
  5. Turn the steering wheel left and right several times.
  6. Watch the CMBS indicator. Does the CMBS indicator come on? YES - Go to step 7. NO - Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  7. Check for DTCs with the HDS. Is DTC 20 indicated? YES - Check for loose or poor connections. If OK, replace the ACC unit (see «ADAPTIVE CRUISE CONTROL (ACC) UNIT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/cruise-control-systems/#adaptive-cruise-control-system) ). NO - Troubleshoot the indicated DTC.

DTC 34: Master Cylinder Brake Fluid Pressure Sensor Circuit Open/Short; DTC 35: Master Cylinder Brake Fluid Pressure Sensor Center Position Error; DTC 36: Master Cylinder Brake Fluid Pressure Sensor Shift Error

  1. Turn the ignition switch ON (II).
  2. Clear the DTCs with the HDS.
  3. Watch the adaptive cruise control (ACC) indicator. Does the ACC indicator stay off? YES - Intermittent failure, the system is OK at this time. Check for loose or poor connections. NO - Go to step 4.
  4. Press the brake pedal.
  5. Watch the ACC indicator. Does the ACC indicator stay off? YES - Intermittent failure, the system is OK at this time. Check for loose or poor connections. NO - Go to step 6.
  6. Check for DTCs with the HDS. Is DTC 34, 35, or 36 indicated? YES - Go to step 7. NO - Troubleshoot the indicated DTC.
  7. With the brake pedal released, check the master cylinder brake fluid pressure voltage (BRAKE P) with the HDS. Is there about 0.5 V? YES - Go to step 8. NO - Check the VSA system.
  8. Test the brake booster (see «BRAKE BOOSTER TEST»(/acura/rl/ii-2004-2008/remont/mechanical-hydraulic/#conventional-brake-components) ).
  9. Press the brake pedal with about 314 N (32 kgf, 70.6 lbf) pressure.
  10. Check the master cylinder brake fluid pressure voltage (BRAKE P) with the HDS. Is there about 2.5 V? YES - Go to step 11. NO - Check the VSA system.
  11. Check the brake switch signal (BRAKE SW (N.O.)) with the HDS. Does the indication show ON when the brake pedal is pressed, and show OFF when the brake pedal is released? YES - Check for loose or poor connections. If OK, replace the ACC unit (see «ADAPTIVE CRUISE CONTROL (ACC) UNIT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/cruise-control-systems/#adaptive-cruise-control-system) ). NO - Go to step 12.
  12. Check for DTCs with the HDS. Is DTC 60, 110 or 111 indicated? YES - Troubleshoot the indicated DTC(s). NO - Troubleshoot the brake pedal position switch circuit (see «BRAKE PEDAL POSITION SWITCH SIGNAL CIRCUIT TROUBLESHOOTING»(/acura/rl/ii-2004-2008/remont/engine-control-systems/#idle-control-system) ).

DTC 64: CMBS Operation Error (Excessive Operation)

Note. If the CMBS operates frequently, DTC 64 is stored.

  1. Remove the upper grille (see «UPPER GRILLE REPLACEMENT»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#exterior-trim__upper-grille-replacement) ).
  2. Inspect the frame for warpage, and check the installation of the millimeter wave radar unit and the main bracket. Is the installation and the frame OK? YES - Go to step 3. NO - Reinstall the components correctly, or replace if damaged, then go to step 3.
  3. Turn the ignition switch ON (II).
  4. Aim the millimeter wave radar unit (see «MILLIMETER WAVE RADAR UNIT AIMING»(/acura/rl/ii-2004-2008/remont/cruise-control-systems/#adaptive-cruise-control-system__millimeter-wave-radar-unit-aiming) ).
  5. Clear the DTCs with the HDS.
  6. Turn the adaptive cruise control (ACC) switch ON.
  7. Watch the ACC and CMBS indicators. Do both indicators come on? YES - Go to step 8. NO - Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  8. Clear the DTCs with the HDS.
  9. Watch the CMBS indicator. Does the CMBS indicator come on? YES - Go to step 10. NO - Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  10. Check for DTCs with the HDS. Is DTC 64 indicated? YES - Check for loose or poor connections. If OK, replace the ACC unit (see «ADAPTIVE CRUISE CONTROL (ACC) UNIT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/cruise-control-systems/#adaptive-cruise-control-system) ). NO - Troubleshoot the indicated DTC.

DTC 100: CMBS Initial Check Incomplete

Note. The CMBS initial check function checks the communication between the adaptive cruise control (ACC) unit and VSA modulator-control unit. If the CMBS initial check is incomplete, the ACC and CMBS indicators come on. For the CMBS to operate properly, always do the CMBS initial check after replacing the ACC unit or the VSA modulator-control unit.

  1. Turn the ignition switch ON (II).
  2. Watch the VSA indicator. Does the VSA indicator come on? YES - Troubleshoot the indicated VSA system DTC(s). NO - Go to step 3.
  3. Check for VSA system DTCs with the HDS. Are any DTCs indicated? YES - Troubleshoot the indicated VSA system DTC(s). NO - Go to step 4.
  4. Start the engine.
  5. Select CMBS from the DRIVING SUPPORT menu, then enter the MISCELLANEOUS TEST.
  6. Do the CMBS brake forced operation.
  7. Watch the ACC and CMBS indicators. Do both indicators come on? YES - Go to step 8. NO - The system is OK at this time. The CMBS initial check is complete.
  8. Check for ACC system DTCs with the HDS. Are any DTCs except DTC 100 indicated? YES - Troubleshoot the indicated DTC(s). NO - Check for loose or poor connections. If OK, replace the ACC unit (see «ADAPTIVE CRUISE CONTROL (ACC) UNIT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/cruise-control-systems/#adaptive-cruise-control-system) ).

DTC 103: CMBS Brake Control Prohibition

  1. Turn the ignition switch ON (II).
  2. Check for VSA system DTCs with the HDS. Are any DTCs indicated? YES - Troubleshoot the indicated VSA system DTC(s). NO - Go to step 3.
  3. Clear the DTCs with the HDS.
  4. Watch the CMBS indicator. Does the CMBS indicator come on? YES - Go to step 5. NO - The system is OK at this time.
  5. Check for adaptive cruise control (ACC) system DTCs with the HDS. Is DTC 103 indicated? YES - Check for loose or poor connections. If OK, replace the ACC unit (see «ADAPTIVE CRUISE CONTROL (ACC) UNIT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/cruise-control-systems/#adaptive-cruise-control-system) ). NO - Troubleshoot the indicated DTC.

CMBS indicator does not go off

  1. Turn the ignition switch ON (II).
  2. Press and hold the CMBS OFF switch for a second or more to turn off the system.
  3. Watch the CMBS indicator. Does the CMBS indicator go off? YES - The system is OK at this time. NO - Go to step 4.
  4. Turn the ignition switch OFF.
  5. Connect the HDS to the data link connector.
  6. Clear the DTCs with the HDS.
  7. Turn the ignition switch ON (II).
  8. Check for the adaptive cruise control (ACC) system, VSA, and PCM DTCs with the HDS. Are any DTCs indicated? YES - Troubleshoot the indicated DTC(s). NO - Go to step 9.
  9. Start the engine, and wait for 2 seconds.
  10. Watch the CMBS indicator. Does the CMBS indicator stay off? YES - The system is OK at this time. NO - Go to step 11.
  11. Stop the engine.
  12. Check for ACC system DTCs with the HDS. Are any DTCs indicated? YES - Troubleshoot the indicated DTC(s). NO - Test the CMBS OFF switch (see «CMBS OFF SWITCH TEST/REPLACEMENT»(/acura/rl/ii-2004-2008/remont/collisionavoidance/#collision-mitigation-brake-system-cmbs) ). If the switch is OK, do the gauge control module self-diagnostic function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/rl/ii-2004-2008/remont/gauges-instrument-panels/#gauges__self-diagnostic-function) ).

Scheme 11

Scheme 11: CMBS OFF Switch Test/Replacement

Scheme 12

Scheme 12

Scheme 13

Scheme 13
  1. Remove the instrument fascia (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#dashboard__drivers-switch-panel-removalinstallation) ).
  2. Remove the screws and the multi-switch (A).
  3. Check for continuity between the terminals in each CMBS OFF switch position according to the table.
  4. If the continuity is not as specified, replace the switch.
