# Automatic a/c circuit

# Automatic a/c circuit (1 of 3)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (1 of 3). Acura RDX II facelift (2015-2018)

Components on the diagram

# Automatic a/c circuit (2 of 3)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (2 of 3). Acura RDX II facelift (2015-2018)

Components on the diagram

# Automatic a/c circuit (3 of 3)

Air conditioning — Automatic a/c circuit — Automatic a/c circuit (3 of 3). Acura RDX II facelift (2015-2018)

Components on the diagram

Components on these wiring diagrams 37

Click a component to highlight it on every diagram it appears on.
