Acura RDX II (2013-2015) Tire pressure monitoring circuit

AREA NETWORK CONTROLLER BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 2 COMPUTER DATA LINES SYSTEM F-CAN F-CAN H F-CAN L FUSE FUSE 29 GAUGE CONTROL MODULE GRN WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR HOT IN ON OR START INDICATOR DRIVE CIRCUIT LEFT FRONT TPMS INITIATOR (AT LEFT FRONT WHEEL WELL) LEFT REAR TPMS INITIATOR (AT LEFT REAR WHEEL WELL) LOW TIRE PRESSURE IND LT BLU WIRE MULTI-INFORMATION DISPLAY OF ENGINE COMPT) ORG/ WIRE PNK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 WIRE PNK WIRE POWER SUPPLY CIRCUIT/CONTROLLER PPL PPL PNK WIRE RED WIRE RIGHT FRONT TPMS INITIATOR (AT RIGHT FRONT WHEEL WELL) RIGHT REAR TPMS INITIATOR (AT RIGHT REAR WHEEL WELL) SYSTEM MESSAGE IND TPMS CONTROL UNIT (BELOW LEFT SIDE OF DASH) TRANSCEIVER/ UNDER-DASH MICU FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) WHT WIRE
