Lubricants and Fluids

For details of the lubrication points and type of lubricants to be applied, refer to the illustrated index and various work procedures (such as Assembly/Reassembly, Replacement, Overhaul, Installation, etc.) contained in each section.

Application		Lubricant or Fluid
A	Engine	Motor Oil: American Honda: Always use Mobil 1® P/N 5W-30-MB1-000 or an equivalent oil that meets the Acura HTO-06 standard. Not all synthetic oils will meet this standard. Honda Canada: Acura 5W-30 Full Synthetic P/N CA67007 or an equivalent oil that meets the Acura HTO-06 standard. Not all synthetic oils will meet this standard.
B	Automatic transmission	Acura Automatic Transmission Fluid (ATF-Z1): American Honda P/N 08200-9001A Honda Canada P/N CA66689 Always use Acura ATF-Z1. Using a non-ACURA ATF can affect shift quality.
C	Transfer assembly	Hypoid Gear Oil GL4 or GL5 Use a SAE 90 or SAE 80W-90 viscosity hypoid gear oil, API classified GL 4 or GL5 only. Viscosity SAE 90: above 0°F(-18°C) SAE 80W-90: below 0°F (-18°C)
D	Rear differential	Acura Automatic Transmission Fluid (ATF-Z1): American Honda P/N 08200-9001A Honda Canada P/N CA66689
E	Brake system (including VSA lines)	Acura DOT 3 Brake Fluid: P/N 08798-9008A Always use Acura DOT 3 Brake Fluid. Using a non-Acura brake fluid can cause corrosion and decrease the life of the system.
F	Brake booster clevis pin	Multipurpose Grease
G	Battery terminals
H	Fuel fill door
I	Hood hinges and hood latch
J	Tailgate hinges
K	Caliper piston boot, caliper pins, and boots	Honda Silicone Grease: P/N 08C30-B0234M
L	Power steering system	Acura Power Steering Fluid: P/N 08206-9002A Always use Acura Power Steering Fluid. Using any other type of power steering fluid or automatic transmission fluid can cause increased wear and poor steering in cold weather.
M	Air conditioning compressor	Compressor Oil: ND-OIL 8 (P/N 38897-PR7-A01AH or 38899-P13-A01) for refrigerant HFC-134a (R-134a)
N	Cooling System	Acura Long Life Antifreeze/coolant type 2: P/N OL999-9011A Honda Extreme Cold Weather Antifreeze/Coolant Type 2:P/N OL999-9020

LUBRICANTS INDEX

Scheme 4

Scheme 5

The maintenance minder is an important feature of the information display (RDX model). The RDX's onboard computer (PCM) calculates the remaining engine oil and automatic transmission fluid life. The system also displays the code for other scheduled maintenance items needing service.

Scheme 6

Scheme 6: Maintenance Display

Scheme 7

Scheme 7: Service Information

Scheme 8

Scheme 9

Scheme 10

Scheme 11

The remaining engine oil life (A) is shown as a percentage in the information display. To see the current engine oil life, turn the ignition switch to the ON (II) position, then push and release the Select/Reset knob repeatedly until the engine oil life displays.
When the ignition switch is in the ON (II) position, and the remaining engine oil life (A) is 6 % to 15 %, the remaining engine oil life and other scheduled maintenance item(s) needing service are displayed. The maintenance minder indicator (B) also comes on when the engine oil life is 15 % or less. To cancel the display and the indicator, press the Select/Reset knob. Complete list of maintenance main items (C) (see «MAINTENANCE MAIN ITEMS»(/acura/rdx/i-2006-2009/remont/reset-procedures/#maintenance) ). Complete list of maintenance sub items (D) (see «MAINTENANCE SUB ITEMS»(/acura/rdx/i-2006-2009/remont/reset-procedures/#maintenance) ).
When the ignition switch is in the ON (II) position, and the remaining engine oil life is 1 % to 5 %, the message "SERVICE" (A) is displayed along with engine oil life and the same maintenance item code(s).
When the ignition switch is in the ON (II) position, and the remaining engine oil life is 0 %, the engine oil life indicator (A) blinks. Pressing the Select/Reset knob cancels the display, but the maintenance minder indicator stays on.
If the indicated maintenance is not done, the engine oil life indicator shows a negative mileage, for example "-10," on the display. If The negative mileage is between 0 and -9, the indicator is displayed for only a few seconds when the ignition switch is turned to the ON (II) position. The negative mileage (A) remains displayed after the vehicle is driven more than 10 miles (for USA models) or 10 km (for Canada models) after 0 % oil life is reached life is reached, and the display cannot be cancelled. This means the indicated maintenance item(s) should have been done more than 10 miles (or 10 km) ago.

Note. The vehicle must be stopped to reset the display. If a required service is done and the display is not reset, or if the maintenance display is reset without doing the service, the system will not show the proper maintenance timing. This can lead to serious mechanical problems because there will be no accurate record of when the required maintenance is needed. The engine oil life and the maintenance items can be reset independently only with the HDS.

Turn the ignition switch ON (II) position.
Push and release the Select/Reset knob repeatedly until the engine oil life indicator is displayed.
Press and hold the Select/Reset knob for about 10 seconds. The engine oil life indicator and the maintenance item code(s) will blink. NOTE: If you are resetting the display when the engine oil life is more than 15 %, make sure the maintenance item(s) requiring service are done before resetting the display.
Press and hold the Select/Reset knob for another 5 seconds. The maintenance item code(s) will disappear, and the engine oil life will reset to "100."

Scheme 12

Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ).
Turn the ignition switch to ON (II).
Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
Select BODY ELECTRICAL with the HDS.
Select ADJUSTMENT in the GAUGES MENU with the HDS.
Select RESET in the MAINTENANCE MINDER with the HDS.
Select the individual maintenance item you wish to reset.

The maintenance minder is an important feature of the multi-information display (RDX with Technology Package). Based on engine operating conditions and accumulated engine revolutions, the RDX's onboard computer (PCM) calculates the remaining engine oil and automatic transmission fluid life. The system also displays the codes for other scheduled maintenance items needing service.

Scheme 13

Scheme 13: Maintenance Display

Scheme 14

Scheme 14: Service Information

Scheme 15

Scheme 16

Scheme 17

The remaining engine oil life (A) is shown as a percentage on the multi-information display. To see the current engine oil life, turn the ignition switch to the ON (II) position, then push and release the Sel/Reset switch repeatedly until the engine oil life displays.
When the ignition switch is in the ON (II) position, and the remaining engine oil life is 6 % to 15 %, the remaining engine oil life and other scheduled maintenance item(s) needing service are displayed. The maintenance system message "SERVICE DUE SOON" (A) also come on. To cancel the message, press the Info Button. The display continues to show the remaining engine oil life (B) and the message indicator (C) until it is reset. Complete list of maintenance main items (D) (see «MAINTENANCE MAIN ITEMS»(/acura/rdx/i-2006-2009/remont/reset-procedures/#maintenance) ). Complete list of maintenance sub items (E) (see «MAINTENANCE SUB ITEMS»(/acura/rdx/i-2006-2009/remont/reset-procedures/#maintenance) ).
When the ignition switch is in the ON (II) position, and the remaining engine oil life is 1 % to 5 %, the maintenance system message "SERVICE DUE NOW" is displayed along with the same maintenance item code(s). If the maintenance system message display is cancelled, a "SERVICE" message appears.
When the ignition switch is in the ON (II) position, and the remaining engine oil life is 0 %, the maintenance system message "SERVICE PAST DUE" is displayed along with the same maintenance item code(s).
If the indicated maintenance is not done, the "SERVICE PAST DUE" message shows a negative mileage, for example "-10," on the display. If the negative mileage is between 0 and -9, the message is displayed for only a few seconds when the ignition switch is turned to the ON (II) position. The negative mileage (A) remains displayed after the vehicle is driven more than 10 miles (for USA models) or 10 km (for Canada models) after 0 % oil life is reached, and the display cannot be cancelled. This means the indicated maintenance item(s) should have been done more than 10 miles (or 10 km) ago.

Scheme 18

Scheme 19

Scheme 19: Resetting the Maintenance-Information Display

Scheme 20

Turn the ignition switch to ON (II) position.
If system message(s) are displayed, press the Info Button to cancel the display.
Push and release the Sel/Reset switch repeatedly until the engine oil life indicator is displayed.
Press and hold the Sel/Reset switch for about 10 seconds, the "OIL LIFE RESET" mode display appears. NOTE: If you are resetting the display when the engine oil life is more than 15 %, make sure any maintenance item(s) requiring service are done before resetting the display. To cancel the "OIL LIFE RESET" mode, press the Info switch repeatedly until the "CANCEL" indicator displayed, then press the Sel/Reset switch.
Press Info switch repeatedly until the "RESET" indicator is displayed, then press the Sel/Reset switch. The maintenance item code(s) will disappear, and the engine oil life will reset to "100."

Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ).
Turn the ignition switch to ON (II).
Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't communicate, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
Select BODY ELECTRICAL with the HDS.
Select ADJUSTMENT in the GAUGES MENU with the HDS.
Select RESET in the MAINTENANCE MINDER with the HDS.
Select the individual maintenance item you wish to reset.

If the message "SERVICE" or "SERVICE DUE NOW" does not appear more than 12 months after the display is reset, change the engine oil every year.

Note. Replace the brake fluid every 3 years. Independent of the maintenance messages in the information display. Inspect idle speed every 160,000 miles (256,000 km). Adjust the valves during services A, B, 1, 2 or 3, only if they are noisy.

Symbol	Maintenance Main Items
A	Replace engine oil (see ENGINE OIL REPLACEMENT ). Engine oil capacity without oil filter: 4.5 L (4.8 US qt).
B	Replace engine oil and oil filter (see ENGINE OIL FILTER REPLACEMENT ). Engine oil capacity with oil filter: 4.7 L (5.0 US qt).
	Check front and rear brakes (see BRAKE SYSTEM INSPECTION AND TEST ). Check pads and discs for wear (thickness), damage, and cracks. Check calipers for damage, leaks, and tightness of mounting bolts.
	Check parking brake adjustment (see PEDAL FREE PLAY ). Check the number of clicks (6 to 7) when the parking brake pedal is pressed with 294 N (30 kgf, 66 lbf) of force.
	Inspect tie-rod ends, steering gearbox, and gearbox boots (see STEERING LINKAGE AND GEARBOX INSPECTION ). Check rack grease and steering linkage. Check boots for damage or leaking grease. Check fluid lines for damage or leaks.
	Inspect suspension components (see COMPONENT LOCATION INDEX ). Check bolts for tightness. Check condition of ball joint boots for deterioration and damage.
	Inspect driveshaft boots (see DRIVESHAFT INSPECTION ). Check boots for cracks and boot bands for tightness.
	Inspect brake hoses and lines including VSA lines (see BRAKE HOSE AND LINE INSPECTION ). Check the master cylinder and VSA modulator-control unit for damage and leakage.
	Inspect all fluid levels and condition of fluids. Engine coolant (see COOLANT CHECK ) Automatic transmission fluid (see ATF LEVEL CHECK ) Transfer fluid (see TRANSFER ASSEMBLY FLUID REPLACEMENT ) Rear differential fluid (see REAR DIFFERENTIAL FLUID INSPECTION AND REPLACEMENT ) Power steering fluid (see FLUID REPLACEMENT ) Brake fluid (see PARKING BRAKE SWITCH TEST ) Windshield washer fluid (see REAR WINDOW WIPER MOTOR REPLACEMENT )
	Inspect exhaust system" (see EXHAUST PIPE AND MUFFLER REPLACEMENT ). Check catalytic converter heat shields, exhaust pipes, and muffler for damage, leaks, and tightness.
	Inspect fuel lines* (1) (see FUEL LINE INSPECTION ) and connections* (1) (see FUEL LINE/QUICK-CONNECT FITTING PRECAUTIONS ). Check for loose connections, cracks, and deterioration; retighten loose connections and replace damaged parts.
(1) NOTE: According to state and federal regulations, failure to do the maintenance items marked with an asterisk ( * ) will not void the client's emissions warranties. However, Acura recommends that all maintenance services be done at the recommended interval, to ensure long-term reliability.

(1)	NOTE: According to state and federal regulations, failure to do the maintenance items marked with an asterisk ( * ) will not void the client's emissions warranties. However, Acura recommends that all maintenance services be done at the recommended interval, to ensure long-term reliability.

MAINTENANCE MAIN ITEMS

Number	Maintenance Sub Items
1	Rotate tires, and check tire inflation and condition. Follow the pattern shown in the Owner's Manual.
2	Replace air cleaner element (see COMPONENT LOCATION INDEX ). If the vehicle is regularly driven in dusty conditions, replace the element every 15,000 miles (24,000 km).
	Replace dust and pollen filter (see RECIRCULATION CONTROL MOTOR REPLACEMENT ). If the vehicle is driven in areas that have high concentrations of dust, pollen, or soot in the air, replace every 15,000 miles (24,000 km). Replace the filter whenever airflow from the heating and air conditioning system is less than normal.
	Inspect drive belt (see DRIVE BELT INSPECTION ). Look for cracks and damage, then check the position of the drive belt auto-tensioner indicator.
3	Replace automatic transmission fluid (see ATF REPLACEMENT ) and transfer (see TRANSFER ASSEMBLY FLUID REPLACEMENT ) fluid. Driving in mountainous areas at very low vehicle speeds or trailer towing results in higher transmission and transfer fluid temperatures. This requires transmission fluid changes more frequently than recommended by the Maintenance Minder. If the vehicle is regularly driven in these conditions, change the transmission and transfer fluid at 60,000 miles (100,000 km), then every 30,000 miles (48,000 km). Automatic transmission fluid capacity 3.3 L (3.5 US qt), use Acura automatic transmission fluid (ATF-Z1). Transfer fluid capacity: 0.43 L (0.45 US qt), use Hypoid Gear Oil GL4 or GL5.
4	Replace spark plugs (see SPARK PLUG INSPECTION ). Use SILKR8A-S (NGK)
4	Inspect the valve clearance (cold) (see VALVE CLEARANCE ADJUSTMENT ). Intake: 0.21-0.25 mm (0.008-0.010 in.), Exhaust: 0.28-0.32 mm (0.011-0.013 in.).
5	Replace engine coolant (see COOLANT CHECK ). Capacity (including the reservoir): 6.5 L (1.72 US gal), use Acura Long Life Antifreeze/Coolant Type 2.
6	Replace rear differential fluid (see REAR DIFFERENTIAL FLUID INSPECTION AND REPLACEMENT ). Driving in mountainous areas at very low vehicle speeds or trailer towing results in higher level of mechanicals (shear) stress to fluid. This requires differential fluid changes more frequently than recommended by the Maintenance Minder. If the vehicle is regularly driven under these conditions, change the differential fluid at 7,500 miles (12,000 km), then every 15,000 miles (24,000 km). Capacity: 2.53 L (2.67 US qt), use Acura automatic transmission fluid (ATF-21)

MAINTENANCE SUB ITEMS
