Power Steering System Acura RDX I

Scheme 1

Scheme 2

Scheme 3

1. Turn the front wheels to the straight ahead position.
2. Measure how far you can turn the steering wheel left and right without moving the front wheels. If the play is within the limit, the gearbox and linkages are OK. If the play exceeds the limit, adjust the rack guide (see «RACK GUIDE ADJUSTMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__rack-guide-adjustment) ). If the play is still excessive after rack guide adjustment, inspect the steering linkage and gearbox (see «STEERING LINKAGE AND GEARBOX INSPECTION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ). Rotational play: 0-10 mm (0-0.39 in.)

Power Assist Check

Note. This test should be done with original equipment tires and wheels at the correct tire pressure.

Scheme 4

1. Check the power steering fluid level (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
2. Start the engine, let it idle, and turn the steering wheel from lock-to-lock several times to warm up the fluid.
3. Attach a commercially available spring scale to the steering wheel. With the engine idling and the vehicle on a clean, dry floor, pull the scale as shown and read it as soon as the tires begin to turn. If the scale reads no more than the specification, the gearbox and pump are OK. If the scale reads more than the specification, troubleshoot the steering system (see «SYMPTOM TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ). Initial turning load: 29 N (3.0 kgf, 6.6 lbf)

Scheme 5

Steering Wheel Removal

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 6

Scheme 7

Scheme 8

1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ).
2. Align the front wheels straight ahead, then remove the driver's airbag from the steering wheel (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
3. Disconnect the cable reel subharness connector (A).
4. Loosen the steering wheel bolt (B).
5. Install a commercially available steering wheel puller (A) on the steering wheel (B). Free the steering wheel from the steering column shaft by turning the pressure bolt (C) of the puller. Note these items when removing the steering wheel: Do not tap on the steering wheel or the steering column shaft when removing the steering wheel. If you thread the puller bolts (D) into the wheel hub more than five threads, the bolts will hit the cable reel and damage it. To prevent this, install a pair of jam nuts five threads upon each puller bolt.
6. Remove the steering wheel puller, then remove the steering wheel bolt and steering wheel from the steering column.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Before installing the steering wheel, make sure the front wheels are aligned straight ahead, then center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise about three full turns. The arrow mark (B) on the cable reel label should point straight up.
2. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown. Install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
3. Install the steering wheel bolt (A), and tighten it to the specified torque. Connect the cable reel subharness connector (B). Make sure the wire harness is routed and fastened properly.
4. Install the driver's airbag, and confirm that the system is operating properly (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/rdx/i-2006-2009/remont/airbag/#srs-supplemental-restraint-system) ).
5. Finish the installation, and note these items: Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ). Turn the ignition switch to ON (II); the SRS indicator should come on for about 6 seconds and then go off. Verify cruise control, audio remote, navigation and HFL voice controls, horn and turn signal switch operation. Make sure the steering wheel is centered.

Steering Column Removal and Installation

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Removal

Note. Be careful not to pull the bracket (A) on the front side of steering column out of its normal position. If the bracket accidentally comes out, replace the steering column as an assembly.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ).
2. Remove the driver's airbag assembly and the steering wheel (see «STEERING WHEEL REMOVAL»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-wheel-removal) ).
3. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ).
4. Remove the column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__column-cover-removalinstallation) ).
5. Remove the steering joint cover (A).
6. Release the tilt/telescopic lock lever, and adjust the steering column to the full tilt up position, and to the full telescopic in position.
7. Tighten the tilt/telescopic lock lever.
8. Hold the lower slide shaft (A) on the column with a piece of wire (B) between the joint yoke (C) of the lower slide shaft and joint yoke (D) of the upper shaft to prevent the slider shaft from pulling out.
9. Release the tilt/telescopic lock lever, and adjust the steering column to the full telescopic out position, then tighten the tilt/telescopic lock lever. NOTE: Do not release the tilt/telescopic lock lever when removing the steering column from the frame.
10. Disconnect the wire harness connectors from the combination switch assembly and cable reel (A).
11. Remove the combination switch assembly from the steering column shaft by removing the three screws (B).
12. Disconnect the connectors from the ignition switch, and release the wire harness clips from the steering column.
13. Remove the steering joint bolt (C), then disconnect the steering joint (D) from the pinion shaft.
14. Remove the steering column (E) by removing the attaching nuts and bolts. If the lower slide shaft (F) is removed, slip it into the upper shaft (G) by aligning the paint or stamped marks (H).

Scheme 17

Scheme 18

Scheme 19

1. Install the steering column in the reverse order of removal, and note these items: Make sure the wires are not caught or pinched by any parts. Take care not to let the sliding capsules fall out of position during column installation.
2. Center the steering rack within its stroke in the steering joint connection.
3. Slip the lower end of the steering joint (A) on to the pinion shaft (B). NOTE: Pinion shaft with center guide; install steering joint by aligning the center guide. Pinion shaft without center guide; position the steering column by aligning the gap (C) within the angle.
4. Align the bolt hole (A) on the steering joint with the groove (B) around the pinion shaft, and loosely install the joint bolt (C). Be sure that the joint bolt is securely in the groove in the pinion shaft. Pull on the steering joint to make sure that the steering joint is fully seated. Tighten the steering joint bolt to the specified torque.
5. Install the steering joint cover (A).
6. Install the steering wheel (see «STEERING WHEEL INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ).
7. Install the column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__column-cover-removalinstallation) ).
8. Install the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ).
9. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ), and note these items: Turn the ignition switch to ON (II); the SRS indicator should come on for about 6 seconds and then go off. Verify cruise control, audio remote, navigation guide, and turn signal switch operation. Make sure the steering wheel is centered.
10. After installation, do these checks: Check the steering wheel spoke angle. If steering spoke angles to the right and left are not equal (steering wheel and rack are not centered), correct the engagement of the joint/ pinion shaft serrations. Set the steering column to the center tilt position, and to the center telescopic position, then do the front toe inspection/adjustment (see «FRONT TOE INSPECTION/ADJUSTMENT»(/acura/rdx/i-2006-2009/remont/wheel-alignment/#front-suspension-and-rear-suspension-alignment__front-toe-inspectionadjustment) ).

Scheme 20

1. Check the steering column ball bearing (A) and the steering joint bearings (B) for play and proper movement. If any bearing is noisy or has excessive play, replace the steering column as an assembly.
2. Check the lower slide shaft (C) for smooth movement in and out. If the lower slide shaft is removed, slip it into the upper shaft by aligning the paint or stamped marks (D). If it sticks or binds, replace the steering column as an assembly.
3. Check the sliding capsules (E) for distortion or breakage. If there is distortion or breakage, replace the steering column as an assembly.
4. Check the tilt mechanism and telescopic mechanism for movement and damage.
5. Check the absorbing plates (F) for distortion or breakage. If there is distortion or breakage, replace the steering column as an assembly.

Scheme 21

Scheme 22

1. Remove the steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) ).
2. Center-punch each of the two shear bolts, and drill the heads of the bolts off with a 5 mm (3/16 in.) drill bit. Be careful not to damage the switch body when removing the shear bolts.
3. Remove the shear bolts from the switch body.
4. Install the switch body without the key inserted.
5. Loosely tighten the new shear bolts.
6. Insert the ignition key, and check for proper operation of the steering wheel lock and that the ignition key turns freely.
7. Tighten the shear bolts (A) until the hex heads (B) twist off.
8. Register the immobilizer control unit-receiver (see «IMMOBILIZER KEY REGISTRATION»(/acura/rdx/i-2006-2009/remont/door-locks-anti-theft-systems/#immobilizer-system__immobilizer-key-registration) ), and make sure the immobilizer system works properly.

Rack Guide Adjustment

Special Tools Required

Locknut wrench, 40 mm 07MAA-SL00100

Scheme 23

Scheme 24

Scheme 25

1. Set the wheels in the straight ahead position.
2. Loosen the rack guide screw locknut (A) with the locknut wrench, then remove the rack guide screw (B).
3. Remove the old sealant from the rack guide screw (A), and apply new sealant (Three Bond 1215 or Loctite 5699) to the middle of the threads (B). Loosely install the rack guide screw on the steering gearbox. NOTE: If more than 5 minutes has passed after applying the sealant, remove the old sealant and residue and reapply new sealant.
4. Tighten the rack guide screw (A) to 25 N.m (2.5 kgf.m, 18 lbf.ft), then loosen it.
5. Retighten the rack guide screw to 8 N.m (0.8 kgf.m, 6 lbf-ft), then back it off to the specified angle. Specified return angle: 15° ± 5°
6. Hold the rack guide screw stationary with a wrench, and tighten the locknut (B) by hand until it's fully seated.
7. Install the locknut wrench on the locknut, continue to hold the rack guide screw stationary with a wrench. Tighten the locknut to the specified torque.
8. Check for unusual steering effort through the complete turning range.
9. Check the steering wheel rotational play (see «STEERING WHEEL ROTATIONAL PLAY CHECK»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ) and the power assist (see «POWER ASSIST CHECK»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__power-assist-check) ).

Tie-rod Ball Joint Boot Replacement

Special Tools Required

Bushing base 07JAF-SH20330

Scheme 26

Scheme 27

1. Remove the tie-rod ball joint from the knuckle (see step 10 ).
2. Remove the tie-rod end from the rack end.
3. Remove the boot from the tie-rod end, and wipe the old grease off the ball pin.
4. Pack the lower area of the ball pin (A) with fresh multipurpose grease.
5. Pack the interior of the new boot (B) and lip (C) with fresh multipurpose grease. Note these items when installing new grease: Keep grease off the boot mounting area (D) and the tapered section (E) of the ball pin. Do not allow dust, dirt, or other foreign materials to enter the boot.
6. Install the new boot (A) using the bushing base. The boot must not have a gap at the boot installation sections (B). After installing the boot, check the ball pin tapered section for grease contamination, and wipe it if necessary.
7. Install the tie-rod end to the rack end.
8. Install the tie-rod ball joint to the knuckle (see step 23 ).
9. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/rdx/i-2006-2009/remont/wheel-alignment/#front-suspension-and-rear-suspension-alignment__wheel-alignment) ).

Scheme 28

Scheme 29

1. Remove the steering gearbox (see «STEERING GEARBOX REMOVAL»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-gearbox-removal) ).
2. Position the 34 mm socket wrench (A) on the flange part of the gearbox housing with a washer (B), 10 x 105 mm flange bolt (C) and the 10 mm nut (D) as shown.
3. Hold the nut with a wrench, and tighten the flange bolt with another wrench. Remove the gearbox mount cushion (E).
4. Apply a mild soap and water solution to the new gearbox mount cushion surface (A), then place it on the gearbox mounting cushion hole.
5. Position the 34 mm socket wrench on the flange part of the gearbox housing with the washer, flange bolt, and the nut as shown.
6. Install the gearbox mount cushion by tightening the flange bolt until the mount cushion edges (B) properly fit on the gearbox flange surface.
7. Install the steering gearbox (see «STEERING GEARBOX INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ).

Scheme 30

Symptom Troubleshooting Index

Find the symptom in the chart below, and do the related procedures in the order listed until you find the cause.

SYMPTOM TROUBLESHOOTING INDEX

Hard Steering

1. Check the power assist (see «STEERING WHEEL ROTATIONAL PLAY CHECK»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ). Is the initial turning load more than 29 N (3.0 kgf, 6.6 lbf)? YES- Go to step 2. NO- Power assist is OK.
2. Connect the P/S joint adapter (pump), P/S joint adapter (hose), and P/S pressure gauge T/N 07406-0010001 (see «PUMP PRESSURE TEST WITH T/N 07406-0010001»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__pump-pressure-test-with-tn-07406-0010001) ), or T/N 07406-001000A or T/N 07406-001A101 (see «PUMP PRESSURE TEST WITH T/N 07406-001000A OR T/N 07406-001A101»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__pump-pressure-test-with-tn-07406-001000a) ) to the pump.
3. Measure steady-state fluid pressure from the pump at idle. Is the pressure 1,470 kPa (15 kgf/cm 2 , 213 psi) or less? YES- Go to step 4. NO- Go to step 8 .
4. Measure the pump relief pressure at idle. Is the pressure 8,150-8,850 kPa (83-90 kgf/cm 2 , 1,180-1,280 psi) or more? YES- Go to step 5. NO- Go to step 9 .
5. With a spring scale, measure the power assist in both directions, to the left and to the right. Are the two measurements within 5.0 N (0.51 kgf, 1.12 lbf) of each other? YES- Go to step 6. NO- Go to step 11 .
6. Measure the fluid pressure with both pressure gauge valves open (if so equipped), while turning the steering wheel fully to the left and fully to the right. Is the pressure 8,150-8,850 kPa (83-90 kgf/cm 2 , 1,180-1,280 psi) or more? YES- Go to step 7. NO- Faulty steering gearbox.
7. Adjust the rack guide (see «RACK GUIDE ADJUSTMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__rack-guide-adjustment) ), and retest. Is the steering OK? YES- Repair is completed. NO- Faulty steering gearbox.
8. Check the outlet and return hoses and lines between the pump and the steering gearbox for clogging and deformation. Are the lines clogged or deformed? YES- Repair or replace the lines. NO- Faulty valve body unit.
9. Disassemble the pump (see «PUMP OVERHAUL»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ).
10. Check the pressure control valve for smooth movement and leaks (see step 16 ). Is the pressure control valve OK? YES- Faulty pump assembly. NO- Faulty pressure control valve.
11. Check the cylinder lines for deformation (see «POWER STEERING HOSE, LINE, AND PRESSURE SWITCH REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__power-steering-hose-line-and-pressure) ). Are any of the lines deformed? YES- Replace the deformed line. NO- Go to step 12.
12. Check for a bent rack shaft or misadjusted rack guide (too tight). Is the rack shaft bent or the rack guide adjusted too tight? YES- Replace the rack shaft, or readjust the rack guide. NO- Faulty valve body unit.

Pump Pressure Test with T/N 07406-0010001

Special Tools Required

1. P/S joint adapter (pump) 07ZAK-S7CA100
2. P/S joint adapter (hose) 07ZAK-S7CA200
3. P/S pressure gauge 07406-0010001

Check the fluid pressure as follows to determine whether the trouble is in the pump or gearbox.

Scheme 31

Scheme 32

1. Check the power steering fluid level (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
2. Disconnect the pump outlet hose (A) from the pump outlet with care so as not to spill the power steering fluid on the frame and other parts, then install the P/S joint adapter (pump) on the pump outlet (B) with the P/S joint outlet plate.
3. Connect the P/S joint adapter (hose) to the P/S pressure gauge, then connect the pump outlet hose to the P/S joint adapter (hose).
4. Install the P/S pressure gauge to the P/S joint adapter (pump).
5. Fully open the shut-off valve (A).
6. Fully open the pressure control valve (B).
7. Start the engine and let it idle.
8. Turn the steering wheel from lock-to-lock several times to warm the fluid to an operating temperature of 158°F (70°C).
9. Measure steady-state fluid pressure while the engine is idling. If the pump is in good condition, the gauge should read no more than 1,470 kPa (15kgf/cm 2 , 213 psi). If it reads high, check for: Clogged or deformed feed or return line between the pump and the gearbox. Clogged valve body unit.
10. Close the shut-off valve, then close the pressure control valve gradually until the pressure gauge needle is stable. Read the pressure. NOTE: Do not keep the shut-off valve closed more than 5 seconds or the pump could be damaged by overheating.
11. Immediately open the shut-off valve fully. If the pump is in good condition, the gauge should read at least 8,150-8,850 kPa (83-90 kgf/cm 2 , 1,180-1,280 psi). A low reading means pump output is too low for full assist. Repair or replace the pump.

Pump Pressure Test with T/N 07406-001000A or T/N 07406-001A101

Special Tools Required

1. P/S joint adapter (pump) 07ZAK-S7CA100
2. P/S joint adapter (hose) 07ZAK-S7CA200
3. P/S pressure gauge 07406-001000A or 07406-001A101

Check the fluid pressure as follows to determine whether the trouble is in the pump or gearbox.

Scheme 33

Scheme 34

1. Check the power steering fluid level (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
2. Disconnect the pump outlet hose (A) from the pump outlet with care so as not to spill the power steering fluid on the frame and other parts, then install the P/S joint adapter (pump) on the pump outlet (B) with the P/S joint outlet plate.
3. Connect the P/S joint adapter (hose) to the P/S pressure gauge, then connect the pump outlet hose to the P/S joint adapter (hose).
4. Install the P/S pressure gauge to the P/S joint adapter (pump).
5. Open the shut-off valve (A) fully. A
6. Start the engine and let it idle.
7. Turn the steering wheel from lock-to-lock several times to warm the fluid to an operating temperature of 158°F (70°C).
8. Measure steady-state fluid pressure while the engine is idling. If the pump is in good condition, the gauge should read no more than 1,470 kPa (15kgf/cm 2 , 213 psi). If it reads high, check for: Clogged or deformed feed or return line between the pump and the gearbox. Clogged valve body unit.
9. Close the shut-off valve gradually and read the pressure. NOTE: Do not keep the shut-off valve closed more than 5 seconds or the pump could be damaged by overheating.
10. Immediately open the shut-off valve fully. If the pump is in good condition, the gauge should read at least 8,150-8,850 kPa (83-90 kgf/cm 2 , 1,180-1,280 psi). A low reading means pump output is too low for full assist. Repair or replace the pump.

Scheme 35

Fluid Replacement

Check the reservoir (A) at regular intervals, and add the recommended fluid as necessary. Always use Acura Power Steering Fluid. Using any other type of power steering fluid or automatic transmission fluid can cause increased wear and poor steering in cold weather.

Note. If the fluid is contaminated, the screen in the reservoir may be partially blocked. Replace the reservoir if necessary.

System capacity

0.9 L (0.96 US. qt) at disassembly

Reservoir capacity

0.30 L (0.32 US. qt)

Scheme 36

Scheme 37

1. Remove the reservoir from its holder. Raise the reservoir, then disconnect the return hose (A) to drain the reservoir. Take care not to spill the fluid on the body and parts. Wipe off any spilled fluid at once. NOTE: Inspect the reservoir screen for any debris. If the reservoir screen is clogged, replace the reservoir.
2. Connect a hose (B) of suitable diameter to the disconnected return hose, and put the hose end in a suitable container.
3. Start the engine, let it run at idle, and turn the steering wheel from lock-to-lock several times. When fluid stops running out of the hose, shut off the engine. Discard the fluid.
4. Reinstall the return hose on the reservoir.
5. Fill the reservoir to the upper level line (C).
6. Start the engine and run it at fast idle, then turn the steering from lock-to-lock several times to bleed air from the system.
7. Recheck the fluid level and add some if necessary. Do not fill the reservoir beyond the upper level line.
8. If the fluid is contaminated, dark, or discolored, repeat the procedure as necessary.

Power Steering Hose, Line, and Pressure Switch Replacement

Note these items during installation

Scheme 38

1. Connect each hose to the corresponding line securely until it contacts the stop on the line. Install the clamp or adjustable clamp at the specified distance from the hose end as shown.
2. Check all clamps for deterioration or deformation; replace the clamps with new ones if necessary.
3. Add the recommended power steering fluid to the specified level on the reservoir and check for leaks.

Scheme 39

Scheme 40

1. Place a suitable container under the vehicle.
2. Drain the power steering fluid from the reservoir (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
3. Remove the drive belt (A) from the pump pulley (see «DRIVE BELT INSPECTION»(/acura/rdx/i-2006-2009/remont/charging-system/#charging-system) ).
4. Cover the auto-tensioner, alternator, and the A/C compressor with several shop towels to protect them from spilled power steering fluid. Disconnect the pump inlet hose (B) and pump outlet hose (C) from the pump (D), and plug them. Take care not to spill the fluid on the body or parts. Wipe off any spilled fluid at once. Do not turn the steering wheel with the pump removed.
5. Remove the pump mounting bolts (E).
6. Cover the opening of the pump with a piece of tape to prevent foreign material from entering the pump.
7. Connect the pump inlet hose and pump outlet hose onto the new pump with new O-ring (F).
8. Loosely install the pump in the pump bracket with the mounting bolts, then tighten the pump fittings securely.
9. Tighten the pump mounting bolts to the specified torque.
10. Install the drive belt (A). Note these items during belt installation: Make sure that the belt is properly positioned on the pulleys (B). Do not get power steering fluid or grease on any parts around the power steering pump, drive belt, or pulley faces. Clean off any fluid or grease before installation.
11. Fill the reservoir to the upper level line (see «PUMP PRESSURE TEST WITH T/N 07406-001000A OR T/N 07406-001A101»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__pump-pressure-test-with-tn-07406-001000a) ).

Exploded View

Replace the pump as an assembly if the parts indicated with an asterisk (*) are worn or damaged.

Scheme 41

Special Tools Required

1. Attachment, 28 x 30 mm 07946-1870100
2. Driver 07749-0010000
3. Pulley holder 07ZAB-S5A0100

Disassembly

Note. Refer to the Exploded View as needed during the following procedure.

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Drain the fluid from the pump (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
2. Remove the power steering pump (see «PUMP REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ).
3. Hold the steering pump (A) in a vise with soft jaws (B), hold the pulley (C) with the pulley holder (D), and remove the pulley nut (E) and pulley. Be careful not to damage the pump housing with the jaws of the vise.
4. Remove the inlet joint and the O-ring.
5. Remove the pressure control valve cap, O-ring, valve spring, and the pressure control valve.
6. Remove the pump housing cap, O-ring, and the pump preload spring.
7. Remove the pump cover, O-ring, and the pump cover seals.
8. Pull out the roll pin.
9. Remove the outer case, cam ring, rotor, vanes, and the side plate.
10. Remove the rubber seal and the slipper seal from the outer case.
11. Remove the O-rings from the bottom of the housing.
12. Remove the 40 mm internal snap ring, then remove the driveshaft by tapping the shaft end with a plastic hammer.
13. Remove the seal from the pump housing. Inspection
14. Check the pressure control valve for wear, burrs, and other damage to the edges of the grooves in the valve.
15. Inspect the bore of the pressure control valve on the pump housing for scratches and wear.
16. Slip the pressure control valve back in the pump housing, and check that it moves in and out smoothly. If OK, go to step 17; if not, replace the pump as an assembly. The pressure control valve is not available separately.
17. Attach a hose (A) to the end of the pressure control valve (B) as shown. Then submerge the pressure control valve in a container of power steering fluid or solvent (C), and blow in the hose. If air bubbles leak through the valve at less than 98 kPa (1.0 kgf/cm 2 , 14.2 psi), replace the pump as an assembly. The pressure control valve is not available separately. If the pressure control valve is OK, set it aside for reassembly later.
18. Inspect the ball bearing by rotating the outer race slowly. If you feel any play (axial or radial) or roughness, remove the faulty ball bearing (A), and install a new one (B).
19. Inspect each part shown with an asterisk in the Exploded View; if any of them are worn or damaged, replace the pump as an assembly. Reassembly
20. Install a new pump seal (A) (with its grooved side facing in) into the pump housing (B) by hand, then drive it in using the driver until the seal is fully seated in the pump housing. Do not apply more than 1,370 N (140 kgf, 308 lbf) of pressure.
21. Position the pump driveshaft (A) in the pump housing, then press it in with the appropriate size socket wrench (B) as shown.
22. Install the 40 mm internal snap ring (C) with its radiused edge facing out.
23. Coat a new 23.8 mm O-ring (A) with power steering fluid, then position it on the bottom (B) of the pump housing.
24. Coat new cover seals (A) and a new 13.0 mm O-ring (B) with power steering fluid, then position them into the grooves on the cover (C). NOTE: Be careful not to install the inlet joint O-ring because they are the same size.
25. Install the outer case (A) by aligning the slot (B) inside the outer case with the cover roll pin hole (C). Be sure that the tapered side (D) of outer case is facing up.
26. Apply power steering fluid to the rubber seal (E) (black), and install it in the slot (F) of the outer case.
27. Apply power steering fluid to the slipper seal (G) (white), and install it on top of the rubber seal you just installed.
28. Install the cam ring (A) by aligning the slot (B) with the slot (C) in the outer case.
29. Insert the roll pin (D) into the slots between the cam ring and the outer case, then push the roll pin into the set hole (E).
30. Install the rotor (A) in the cam ring (B).
31. Set the 11 vanes (C) in the grooves in the rotor. Make sure that the gold color ends (D) of the vanes are in contact with the sliding surface of the cam ring.
32. Place the side plate (A) on the cam ring, and align the roll pin set hole (B) with the roll pin (C).
33. Coat a new O-ring (D) with power steering fluid, then position it into the groove on the side plate.
34. Install the pump housing (A) over the cover assembly (B).
35. Align the bolt holes in the cover (A) with the threaded holes in the pump housing. Install the flange bolts loosely first, then torque the flange bolts in a criss-cross pattern in two or more steps.
36. Push in the cam ring (A) from the pump housing cap hole (B) with a flat-tip screwdriver to make sure the cam ring is fully seated against the outer case.
37. Install the pump preload spring (A) in the pump housing.
38. Coat a new 12.7 mm O-ring (B) with power steering fluid, and install it on the pump housing cap (C).
39. Install the pump housing cap on the pump housing, and tighten it to the specified torque.
40. Install the pressure control valve spring (A) in the pump housing.
41. Coat the pressure control valve (B) with power steering fluid, and install it in the pump housing.
42. Coat a new 16.7 mm O-ring (C) with power steering fluid, and install it on the pressure control valve cap (D).
43. Install the pressure control valve cap on the pump housing, and tighten it to the specified torque.
44. Coat a new O-ring (A) with power steering fluid, and install it on the inlet joint (B).
45. Install the inlet joint on the pump housing.
46. Install the pulley (A), then loosely install the pulley nut (B). Hold the steering pump in a vise with soft jaws (C). Be careful not to damage the pump housing with the jaws of the vise.
47. Hold the pulley with the pulley holder, and tighten the pulley nut to the specified torque.
48. Check that the pump turns smoothly by turning the pulley. If it turns hard, loosen the four flange bolts on the cover, then retighten them as in step 35 , and check the pump again.

Steering Gearbox Removal

Special Tools Required

Ball joint remover, 28 mm 07MAC-SL0A202

Note these items during removal

1. Using solvent and a brush, wash any oil and dirt off the valve body unit, its lines, and the end of the gearbox. Blow dry with compressed air.
2. Be sure to remove the steering wheel before disconnecting the steering joint. Damage to the cable reel can occur.

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. Drain the power steering fluid (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
2. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ).
3. Raise the front of vehicle, and support it with safety stands in the proper locations (see «LIFT AND SUPPORT POINTS»(/acura/rdx/i-2006-2009/remont/paintcoatings/#general-information__lift-and-support-points) ).
4. Remove the front wheels.
5. Remove the steering wheel (see «STEERING WHEEL REMOVAL»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-wheel-removal) ).
6. Remove the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ).
7. Remove the steering joint cover (A).
8. Remove the steering joint bolt (A), and disconnect the steering joint by moving the steering joint (B) toward the column. Hold the lower slide shaft (C) on the column with a piece of wire (D) between the joint yoke (E) on the lower slide shaft to the joint yoke on the upper shaft (see step 9 ).
9. Remove the center guide (A) (if equipped), and discard it. The center guide is for factory assembly only.
10. Remove the cotter pin (A) from the 12 mm nut (B), and loosen the nut.
11. Separate the tie-rod ball joint and knuckle using the ball joint remover (see «BALL JOINT REMOVAL»(/acura/rdx/i-2006-2009/remont/wheel-alignment/#front-suspension-and-rear-suspension-alignment__ball-joint-removal) ).
12. Remove the air cleaner housing (A) (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ).
13. Remove the under-hood fuse/relay box (B) (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-hood-fuserelay-box) ).
14. Loosen the adjustable hose clamp (A), and disconnect the return hose (B).
15. Remove the inlet line clamp bolt (C).
16. Loosen the 18 mm flare nut (D), and disconnect the inlet line (E).
17. Remove the 10 mm flange bolt (A) from the driver's side of the steering gearbox.
18. Disconnect the return line holder (A), and remove the return line clamp bolt (B).
19. Remove the pump outlet hose clamp (A) from the steering gearbox.
20. Disconnect the return hose clips (B).
21. Remove the P/S heat shield (A).
22. Remove the 10 mm flange bolt (A) and washer (B) from the driver's side of the steering gearbox.
23. Remove the flange bolts (C), then remove the stabilizer bar bushing holder (D) (see «STABILIZER BAR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/wheel-hubs/#front-suspension) ).
24. Remove the 10 mm flange bolts (A) and washer (B) from the passenger's side of the steering gearbox.
25. Remove the flange bolts (C), then remove the stabilizer bar bushing holder (D) (see «STABILIZER BAR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/wheel-hubs/#front-suspension) ).
26. Remove the steering gearbox bracket mounting bolts (A) from both sides of the subframe.
27. Remove the gearbox brackets (A).
28. Move the steering gearbox toward the front, and remove the pinion shaft grommet (A) from the top of the valve housing.
29. Apply vinyl tape (B) to the splines on the pinion shaft.
30. Carefully move the steering gearbox and tie-rods as an assembly toward the front side until the pinion shaft (A) clears the wheelwell opening on the frame.
31. Remove the steering gearbox (A) through the wheelwell opening on the driver's side.
32. After removing the steering gearbox, make sure that no power steering fluid gets on the gearbox mount cushions, gearbox housing, or the surface of the front subframe. Wipe off any spilled fluid at once.

Scheme 79

Special Tools Required

1. Cylinder end seal remover attachment 07TAF-SZ50100
2. Valve seal ring sizing tool 07NAG-SR3090A
3. Sleeve seal ring guide 07YAG-S2X0100
4. Sleeve seal ring sizing tool, 36 mm 07ZAG-S5A0100
5. Attachment, 28 x 30 mm 07946-1870100
6. Driver 07749-0010000
7. Piston seal ring guide 07LAG-SM40100
8. Piston seal ring sizing tool 07HAG-SF1020A or 07HAG-SF10200
9. Cylinder end seal slider 07LAG-SM40300
10. Pincers Oetiker 1098 or equivalent, commercially available NOTE: Refer to the Exploded View as needed during this procedure.

Removal

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. Remove the steering gearbox (see «STEERING GEARBOX REMOVAL»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__steering-gearbox-removal) ). Disassembly
2. Remove the boot bands (A) and tie-rod clips (B). Pull the boot away from the ends of the steering gearbox.
3. Unbend the lock washers (A).
4. Hold the flat surface sections (A) of the steering rack (B) with a wrench, and unscrew both rack ends (C) with another wrench. Be careful not to damage the rack surface with the wrench.
5. Remove the lock washer (D) and stop rubber (E).
6. Loosen the locknut (A), then remove the rack guide screw (B).
7. Remove the spring (C), disc washer (D) and the rack guide (E) from the gearbox housing.
8. Remove the cylinder lines (A) and return line joint (B) from the gearbox.
9. Drain the fluid from the cylinder fittings by slowly moving the steering rack back and forth.
10. Remove the two flange bolts, then remove the valve body unit (A) from the gearbox (B). Remove the O-ring (C).
11. Wrap vinyl tape (A) around the rack end and cylinder end to prevent metal shavings from entering the cylinder side on the gearbox housing.
12. Drill a 4 mm (0.16 in.) diameter hole about 2.5-3.0 mm (0.10-0.12 in.) in depth in the staked point (B) on the cylinder. Do not allow metal shavings to enter the cylinder side of the gearbox housing. After removing the cylinder end, remove any burrs at the staked point.
13. Hold the gearbox housing using a C-clamp (commercially available) (A) and wooden blocks (B) as shown. Do not clamp the cylinder part of the gearbox housing in the vise. Then remove the cylinder end (C).
14. Install a commercially available bearing separator (A) in the gearbox housing as shown.
15. Place an appropriate size deep socket wrench (B) on the steering rack (C).
16. Set the steering gearbox in a press so the gearbox housing side points upward, then press the cylinder end seal (D) and steering rack out of the gearbox. Hold the steering rack to keep it from falling when pressed clear. Be careful not to damage the inner surface of the cylinder side on the gearbox housing with the tool.
17. Carefully pry the piston seal ring (A) and O-ring (B) off the rack piston. Be careful not to damage the inside of the seal ring groove and piston edges when removing the seal ring.
18. Turn the cylinder end seal remover attachment so it will fit through the rack guide hole of the steering gearbox, then position the seal remover on the cylinder end seal (A). Make sure that the seal remover is securely positioned on the seal edges.
19. Insert 24" long, 3/8" drive extension (A), on the cylinder end seal remover attachment. Place the steering gearbox in a press, then remove the cylinder end seal (B) from the gearbox by pressing on the 24" long 3/8" drive extension. Note these items when pressing the cylinder end seal: Keep the tool straight to avoid damaging the cylinder wall. Check the tool angle, and correct it if necessary, when removing the cylinder end seal. Use a press to remove the cylinder end seal. Do not try to remove the seal by striking the tool; striking the tool would break the cylinder end seal, and the seal would remain in the gearbox.
20. Before removing the valve housing (A), apply vinyl tape (B) to the splines on the pinion shaft.
21. Separate the valve housing from the pinion shaft/ valve using a press.
22. With your finger, check the inner wall of the valve housing where the seal ring slides. If there is a step in the wall, the housing is worn. Replace it. NOTE: There may be sliding marks from the seal ring on the wall of the valve housing. Replace the valve housing only if the wall is stepped.
23. Check for wear, burrs, and other damage to the edges of the grooves in the sleeve. NOTE: The pinion shaft and sleeve are a precision matched set. If either the pinion shaft or sleeve must be replaced, replace both parts as a set.
24. Remove the snap ring (A) and sleeve (B) from the pinion shaft.
25. Using a cutter or an equivalent tool, cut and remove the four seal rings from the sleeve. Be careful not to damage the edges of the sleeve grooves and outer surface when removing the seal rings.
26. Using a cutter or an equivalent tool, cut the valve seal ring (A) and the O-ring (B) at the cutting groove position (C) in the pinion shaft. Remove the valve seal ring and the O-ring. Be careful not to damage the edges of the pinion shaft groove and outer surface when removing the valve seal ring and the O-ring.
27. Remove the valve oil seal (A) and the wave washer (B) from the pinion shaft. Note these items during disassembly: Inspect the ball bearing (C) by rotating the outer race slowly. If there is any excessive play or wear, replace the pinion shaft and sleeve as an assembly. The pinion shaft and sleeve are a precise fit; do not intermix old and new pinion shafts and sleeves.
28. Remove the valve oil seal (A) and the roller bearing (B) out of the valve housing using a hydraulic press and an appropriate size socket wrench.
29. Clean the disassembled parts with solvent, and dry them with compressed air. Do not dip rubber parts in the solvent. Reassembly
30. Apply vinyl tape (A) to the stepped portion of the pinion shaft, and coat the surface of the vinyl tape with power steering fluid.
31. Install the wave washer (B).
32. Coat the inside surface of a new valve oil seal (C) with power steering fluid, and install the seal with its grooved side facing opposite the bearing, then slide it over the pinion shaft, being careful not to damage its sealing lip (D). Remove the vinyl tape.
33. Apply vinyl tape (A) to the splines and stepped portion of the shaft, and coat the surface of the vinyl tape with power steering fluid.
34. Fit a new O-ring (B) in the groove of the pinion shaft. Then slide a new valve seal ring (C) over the shaft and in the groove on the pinion shaft.
35. Remove the tape, and apply power steering fluid to the surface of the valve seal ring (A).
36. Apply power steering fluid to the inside of the valve seal ring sizing tool. Set the larger diameter end of the sizing tool over the valve seal ring, and move the sizing tool up and down several times to make the valve seal ring fit in the pinion shaft groove.
37. Remove the sizing tool, turn it over, slide the smaller diameter end over the valve seal ring. Move it up and down several times to make the valve seal ring fit snugly in the pinion shaft groove.
38. Apply power steering fluid to the surface of the sleeve seal ring guide. Slip two new seal rings (A) over the ring guide from the smaller diameter end, and expand them. Install only two rings at a time from each end of the pinion shaft sleeve (B). Note these items when installing the seal ring: Do not over-expand the seal ring. Install the resin seal rings with care so as not to damage them. After installation, make sure you contract the seal rings using the sizing tool. There are two types of sleeve seal rings; black and brown. Do not mix the different types of rings as they are not compatible.
39. Align the ring guide with each groove in the sleeve, and slide a sleeve seal ring into each groove. After installation, compress the seal rings with your fingers temporarily.
40. Apply power steering fluid to the seal rings on the sleeve, and to the entire inside surface of the sleeve seal ring sizing tool, then slowly insert the sleeve into the sizing tool.
41. Move the sleeve back and forth several times to make the seal rings fit snugly in the sleeve. Make sure the seal rings are not twisted.
42. Apply power steering fluid to the surface of the pinion shaft (A). Slide the sleeve (B) onto the pinion shaft by aligning the locating pin (C) on the inside of the sleeve with the cutout (D) in the shaft. Then install the new snap ring (E) securely in the pinion shaft groove. Be careful not to damage the valve seal ring when inserting the sleeve.
43. Apply power steering fluid to the seal ring lip of the new valve oil seal (A), then install the seal in the valve housing (B) using a hydraulic press and driver. Install the seal with its grooved side facing the tool.
44. Press the roller bearing (C) into the valve housing with a hydraulic press and attachment.
45. Apply vinyl tape (A) to the pinion shaft, then coat the vinyl tape with power steering fluid.
46. Insert the pinion shaft into the valve housing (B). Be careful not to damage the valve seal rings (C).
47. Remove the vinyl tape from the pinion shaft, then remove any residue from the tape adhesive.
48. Press the pinion shaft/sleeve into the valve housing with a hydraulic press. Check that the pinion shaft/ sleeve turns smoothly by hand after installing it.
49. Coat the piston seal ring guide with power steering fluid, then slide it onto the rack, big end first.
50. Position a new O-ring (A) and a new piston seal ring (B) on the ring guide, then slide them down toward the big end of the tool. Note these items during reassembly: Do not over expand the resin seal rings. Install the resin seal rings with care so as not to damage them. After installation, make sure you contract the seal ring using the sizing tool. Replace piston's O-ring and seal ring as a set.
51. Pull the O-ring off into the piston groove, then pull the piston seal ring off into the piston groove on top of the O-ring. Remove the piston seal ring guide.
52. Coat the piston seal ring (A) and the inside of the piston seal ring sizing tool with power steering fluid, then carefully slide the tool onto the rack and over the piston seal ring.
53. Move the sizing tool back and forth several times to make the piston seal ring fit snugly in the piston.
54. Coat the sliding surface of the cylinder end seal slider (A) and new cylinder end seal (B) with power steering fluid. Place the seal on the special tool With its grooved side (C) facing opposite the special tool.
55. Coat the surface of the steering rack (A) with power steering fluid.
56. Install the cylinder end seal (B) onto the steering rack with its grooved side (C) toward the piston (D).
57. Separate the cylinder end seal from the cylinder end seal slider, then remove the seal slider.
58. Install the new backup ring (A) on the steering rack, then place the backup ring and cylinder end seal (B) against the piston (C).
59. Apply steering grease to the steering rack teeth, then insert the steering rack into the gearbox housing. Be careful not to damage the inner surface of the cylinder wall with the rack edges.
60. Insert an appropriate size socket wrench (A) onto the steering rack as shown.
61. Install the cylinder end seal (B) into the bottom of the cylinder by pressing on the tool with a press. Do not push on the tool with excessive force as it may damage the cylinder end seal.
62. Remove the tool, and center the steering rack.
63. Coat the sliding surface of the cylinder end seal slider (A) and a new cylinder end seal (B) with power steering fluid. Place the seal on the seal slider with its grooved side (C) facing opposite the seal slider.
64. Coat the inside surface of the cylinder end seal slider and steering rack with power steering fluid, then install the cylinder end seal (A) onto the steering rack with its grooved side toward the cylinder.
65. Separate the cylinder end seal from the seal slider, then remove the seal slider.
66. Push in the cylinder end seal with your finger. Be careful not to damage the face of the seal with the threads and burrs at the staked position of the cylinder housing.
67. Hold the gearbox housing using a C-clamp (commercially available) (A) and wooden blocks (B). Do not clamp the cylinder part of the gearbox housing in the vise.
68. Coat the inside surface of the cylinder end (A) with power steering fluid.
69. Install the cylinder end by screwing it into the cylinder (A). Tighten the cylinder end to the specified torque.
70. Stake the point of the cylinder shown (opposite from where the stake was removed during disassembly).
71. Coat a new O-ring (A) with steering grease, and carefully fit it on the valve housing.
72. Apply steering grease to the needle bearing (B) in the gearbox housing, then install the valve body unit (C) by engaging the gears. Note the valve body unit installation position (direction of the line connections).
73. Tighten the flange bolts (D) to the specified torque.
74. Install the cylinder lines (A) and return line joint (B). Note these items during reassembly: Thoroughly clean the joints of the cylinder lines. The joints must be free of foreign material. Install the cylinder lines by tightening the flare nuts by hand first, then tighten the flare nuts to the specified torque.
75. Apply steering grease to the sliding surface of the rack guide (A), and install it onto the gearbox housing.
76. Remove the old sealant from the rack guide screw (B), then apply new sealant (Three Bond 1215 or Loctite 5699) to the middle of the threads. Install the disc washer (C) with its convex side facing the rack guide, the spring (D), the rack guide screw and the locknut (E).
77. Adjust the rack guide screw (see «RACK GUIDE ADJUSTMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__rack-guide-adjustment) ). After adjusting, check that the rack moves smoothly by sliding it right and left.
78. Install a new stop rubber (A) and a new lock washer (B). Align the lock washer tabs (C) with the slots (D) on the rack end (E) while holding the lock washer in place. Repeat this step for the other side of the rack.
79. Hold the flat surface sections (F) of the steering rack with a wrench, and tighten both rack ends. Be careful not to damages the rack surface with the wrench.
80. Bend the lock washer (A) back against the flat spots on the rack end joint housing.
81. Apply multipurpose grease to the circumference of the rack end joint housing (A).
82. Apply a light coat of silicone grease (P/N 08798-9013) to the boot grooves (B) on the rack end.
83. Center the steering rack within its stroke.
84. Clean off any grease or contamination from the boot installation grooves (A) around on the gearbox housing. Install the boots (B) on the rack ends with the tie-rod clips (C), and fit the boot end in the installation grooves in the housing properly.
85. After installing the boots, wipe the grease off the threaded section (D) of the rack end.
86. Install a new boot bands by aligning the tabs (A) with the holes (B) on the band.
87. Close the ear portion (A) of the band (B) with commercially available pincers, Oetiker 1098 or equivalent (C).
88. Slide the rack right and left to be certain that the boots are not deformed or twisted.
89. Reinstall the steering gearbox (see «STEERING GEARBOX INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ).

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

1. Before installing the steering gearbox, make sure that no power steering fluid is on the mating surface of the gearbox and the front subframe. To prevent the gearbox mounting bolts from loosening after the installation, remove the power steering fluid from the mount cushions and bolt holes.
2. Slide the steering gearbox (A) between the front subframe and the body from the driver's side. Place the gearbox in position on the front subframe.
3. Rotate the steering gearbox so the pinion shaft (A) points downward.
4. Continue moving the gearbox toward the passenger's side until the steering gearbox is in position. Make sure the power steering return line and feed line are routed above the gearbox.
5. Remove the vinyl tape from pinion shaft, and install the pinion shaft grommet (A). Align the slot in the pinion shaft grommet with the lug portion (B) on the valve housing.
6. Install the gearbox brackets (A).
7. Tighten the steering gearbox bracket mounting bolts (A) to the specified torque.
8. Loosely install the passenger's side gearbox mounting bolts (A) and washer (B).
9. Install the passenger's side stabilizer bar bushing holder (C) (see «STABILIZER BAR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/wheel-hubs/#front-suspension) ).
10. Loosely install the driver's side gearbox mounting bolt (A) and washer (B).
11. Install the driver's side stabilizer bar bushing holder (C) (see «STABILIZER BAR REPLACEMENT»(/acura/rdx/i-2006-2009/remont/wheel-hubs/#front-suspension) ).
12. Install the P/S heat shield (A).
13. Install the pump outlet hose clamp (A) on the steering gearbox.
14. Connect the return hose clips (B).
15. Connect the return line holder (A), and install the return line clamp bolt (B).
16. Loosely install the remaining gearbox mounting bolt (A).
17. Tighten the gearbox mounting bolts to the specified torque in the sequence shown.
18. Connect the inlet line (A), and tighten the 18 mm flare nut to the specified torque.
19. Connect the return hose (B) securely, and tighten the adjustable hose clamp (C) (see «POWER STEERING HOSE, LINE, AND PRESSURE SWITCH REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__power-steering-hose-line-and-pressure) ).
20. Install the inlet line clamp bolt (D).
21. Install the under-hood fuse/relay box (A) (see «REMOVAL AND INSTALLATION»(/acura/rdx/i-2006-2009/remont/body-electrical/#under-hood-fuserelay-box) ).
22. Install the air cleaner housing (B) (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#intake-air-system) ).
23. Wipe off any grease contamination from the ball joint tapered section and threads. Reconnect the tie-rod ends (A) to the steering knuckles. Install the 12 mm nut (B), and tighten it.
24. Install a new cotter pin (C), and bend it as shown.
25. Center the steering rack within its stroke in steering joint connection.
26. With the rack in the straight ahead driving position, cut the wire (A) and slip the lower end of the steering joint onto the pinion shaft (B) in the range shown.
27. Align the bolt hole (A) on the steering joint with the groove (B) around the pinion shaft, then loosely install the joint bolt (C). Be sure that the joint bolt is securely in the groove in the pinion shaft. Pull on the steering joint to make sure that the steering joint is fully seated. Tighten the steering joint bolt to the specified torque.
28. Install the steering joint cover (A).
29. Install the driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#dashboard-instrument-panel__drivers-dashboard-undercover-removalinstallation) ).
30. Install the front wheel, then set the wheels in the straight ahead position.
31. Install the steering wheel (see «STEERING WHEEL INSTALLATION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ).
32. Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/rdx/i-2006-2009/remont/body-electrical/#battery) ), and do these tasks. Verify cruise control, audio remote, navigation and HFL voice controls, horn, and turn signal switch operation. Make sure the steering wheel is centered.
33. Fill the system with power steering fluid, and bleed air from the system (see «FLUID REPLACEMENT»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system__fluid-replacement) ).
34. After installation, do the following checks: Start the engine, allow it to idle, and turn the steering wheel from lock-to-lock several times to warm up the fluid. Check the gearbox for leaks (see «FLUID LEAKAGE INSPECTION»(/acura/rdx/i-2006-2009/remont/manual-power-steering/#power-steering-system) ). Check the steering wheel spoke angle. If steering spoke angles to the right and left are not equal (steering wheel and rack are not centered), correct the engagement of the joint/ pinion shaft serrations. Set the steering column to the center tilt position, and to the center telescopic position, then do the front toe inspection/adjustment (see «FRONT TOE INSPECTION/ADJUSTMENT»(/acura/rdx/i-2006-2009/remont/wheel-alignment/#front-suspension-and-rear-suspension-alignment__front-toe-inspectionadjustment) ).

See also:
• COMPONENT LOCATION INDEX
• BATTERY TERMINAL DISCONNECTION AND RECONNECTION
• DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• COLUMN COVER REMOVAL/INSTALLATION
• FRONT TOE INSPECTION/ADJUSTMENT
• IMMOBILIZER KEY REGISTRATION
• WHEEL ALIGNMENT
• DRIVE BELT INSPECTION
• IDLE SPEED INSPECTION
• LIFT AND SUPPORT POINTS
• BALL JOINT REMOVAL
• AIR CLEANER REMOVAL/INSTALLATION
• REMOVAL AND INSTALLATION
• STABILIZER BAR REPLACEMENT
• RACK GUIDE ADJUSTMENT
• STEERING LINKAGE AND GEARBOX INSPECTION
• FLUID REPLACEMENT
• STEERING WHEEL REMOVAL
• STEERING COLUMN REMOVAL AND INSTALLATION
• POWER ASSIST CHECK
• STEERING GEARBOX REMOVAL
• PUMP PRESSURE TEST WITH T/N 07406-0010001
• PUMP PRESSURE TEST WITH T/N 07406-001000A OR T/N 07406-001A101
• POWER STEERING HOSE, LINE, AND PRESSURE SWITCH REPLACEMENT
