Engine Lubrication Acura RDX I

Scheme 1

Scheme 2

Symptom Troubleshooting Index

SYMPTOM TROUBLESHOOTING INDEX

Scheme 3

Scheme 4

1. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 under «HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ).
2. Turn the ignition switch ON (II).
3. Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
4. Check for DTCs (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ). If a DTC is present, diagnose and repair the cause before continuing with this test.
5. Turn the ignition switch ON (II), select PGM-FI, and check the OIL PRESSURE SWITCH in the DATA LIST with the HDS. Is "ON" indicated? YES -Replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ). NO -Go to step 6.
6. Check the oil pressure switch (see «OIL PRESSURE SWITCH TEST»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ). Is the oil pressure switch OK? YES -Go to step 7. NO -Replace the oil pressure switch (see «OIL PRESSURE SWITCH TEST»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ).
7. Turn the ignition switch ON (II) and jump the SCS line with the HDS, then turn the ignition switch OFF. NOTE: This step must be done to protect the PCM from damage.
8. Disconnect PCM connector B (44P) and the oil pressure switch connector.
9. Check for continuity between PCM connector terminal B7 and the oil pressure switch connector. Is there continuity? YES -Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ). NO -Repair open in the wire between the oil pressure switch and the PCM.

Scheme 5

1. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 under «HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ).
2. Turn the ignition switch ON (II).
3. Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
4. Check for DTCs (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ). If a DTC is present, diagnose and repair the cause before continuing with this test.
5. Start the engine, select PGM-FI, and check the OIL PRESSURE SWITCH in the DATA LIST with the HDS. Is "OFF" indicated? YES -Replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/rdx/i-2006-2009/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ). NO -Go to step 6.
6. Turn the ignition switch OFF.
7. Disconnect the oil pressure switch connector.
8. Start the engine and check the OIL PRESSURE SWITCH in the DATA LIST with the HDS. Is "OFF" indicated? YES -Go to step 9. NO -Go to step 10 .
9. Check the oil pressure switch (see «OIL PRESSURE SWITCH TEST»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ). Is the oil pressure switch OK? YES -Do the «OIL PRESSURE TEST»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication__oil-pressure-test) . NO -Replace the oil pressure switch (see «OIL PRESSURE SWITCH TEST»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ).
10. Turn the ignition switch ON (II) and jump the SCS line with the HDS, then turn the ignition switch OFF. NOTE: This step must be done to protect the PCM from damage.
11. Disconnect PCM connector B (44P) and the oil pressure switch connector.
12. Check for continuity between the oil pressure switch connector and body ground. Is there continuity? YES -Repair short in the wire between the oil pressure switch and the PCM. NO -Update the PCM if it does not have the latest software (see «PCM UPDATE»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ) or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems__substituting-the-pcm) ), then recheck. If the symptom/indication goes away with a known-good PCM, replace the original PCM (see «PCM REPLACEMENT»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__pcm-replacement) ).

Scheme 6

1. Remove the oil pressure switch connector (A) from the engine oil pressure switch (B).
2. Check for continuity between the pressure switch terminal and the engine (ground). There should be continuity with the engine stopped. There should be no continuity with the engine running.

Scheme 7

1. Disconnect the oil pressure switch connector, then remove the oil pressure switch.
2. Remove any old liquid gasket from the switch and switch mounting hole.
3. Apply a very small amount of liquid gasket to the oil pressure switch threads, then install the oil pressure switch.

Note. Using too much liquid gasket may cause liquid gasket to enter the oil passage or the end of the new oil pressure switch.

Oil Pressure Test

Note. If the oil pressure warning light stays on with the engine running, check the engine oil level. If the oil level is correct

Scheme 8

1. Remove the engine oil pressure switch, and install an oil pressure gauge (A).
2. Start the engine. Shut it off immediately if the gauge registers no oil pressure. Repair the problem before continuing.
3. Allow the engine to reach operating temperature (fan comes on at least twice). The pressure should be: Engine Oil Temperature: 176°F (80°C) Engine Oil Pressure: At Idle: 70 kPa (0.7 kgf/cm 2 , 10 psi) min. At 3,000 rpm: 300 kPa (3.1 kgf/cm 2 , 44 psi) min.
4. If the oil pressure is out of specifications, inspect these items: Replace the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication__engine-oil-filter-replacement) ). Inspect the oil pressure relief valve (see «OIL PUMP OVERHAUL»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ). Check the oil screen for clogging. Check the oil pump (see «OIL PUMP INSPECTION»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ).

Scheme 9

Scheme 10

1. Warm up the engine.
2. Remove the drain bolt (A), and drain the engine oil.
3. Reinstall the drain bolt with a new washer (B).
4. Refill the engine with the recommended oil (see «LUBRICANTS ABD FLUIDS»(/acura/rdx/i-2006-2009/remont/reset-procedures/#maintenance__lubricants-and-fluids) ). NOTE: Always use Mobil 1® P/N 5W-30-MB1-000 or an equivalent oil that meets the ACURA HT0-06 standard. Not all synthetic oil will meet this standard. Capacity At Oil Change: 4.5 L (4.8 US qt) At Oil Change including Filter: 4.7 L (5.0 US qt) After Engine Overhaul: 5.8 L (6.1 US qt)
5. If the maintenance minder required to replace the engine oil, reset the maintenance minder (see «GENERAL INFORMATION (INFORMATION DISPLAY)»(/acura/rdx/i-2006-2009/remont/reset-procedures/#maintenance) ) and this procedure is complete. If the maintenance minder did not require replacement of the engine oil, go to step 6.
6. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (see step 2 under «HOW TO USE THE HDS (HONDA DIAGNOSTIC SYSTEM)»(/acura/rdx/i-2006-2009/remont/auxiliary-emission-control-systems/#fuel-and-emissions-systems) ).
7. Turn the ignition switch ON (II).
8. Make sure the HDS communicates with the vehicle and the powertrain control module (PCM). If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/rdx/i-2006-2009/remont/testing-diagnostics/#pgm-fi-system__dlc-circuit-troubleshooting) ).
9. Select the BODY ELECTRICAL with the HDS.
10. Select the ADJUSTMENT in GAUGE MENU with the HDS.
11. Select the RESET in the MAINTENANCE MINDER with the HDS.
12. Select the RESETTING THE ENGINE OIL LIFE with the HDS.
13. Run the engine for more than 3 minutes, then check for oil leaks.

Engine Oil Filter Replacement

Special Tools Required

Oil filter wrench 07AAA-PLCA100

Scheme 11

Scheme 12

1. Remove the oil filter with the oil filter wrench.
2. Inspect oil filter sealing surface and be sure all of the rubber seal is removed.
3. Inspect the threads (A) and rubber seal (B) on the new filter. Clean the seat on the filter base, then apply a light coat of new engine oil to the filter rubber seal. Use only filters with a built-in bypass system.
4. Install the oil filter by hand.
5. After the rubber seal seats, tighten the oil filter to 12 N.m (1.2 kgf.m, 8.8 lbf.ft).
6. After installation, fill the engine with oil up to the specified level, run the engine for more than 3 minutes, then check for oil leakage.

Scheme 13

1. Remove the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication__engine-oil-filter-replacement) ).
2. Remove the oil filter base (A).
3. Clean the O-ring grooves and mating surfaces with the filter base, then install the oil filter base with new O-rings (B).
4. Install the oil filter (see «ENGINE OIL FILTER REPLACEMENT»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication__engine-oil-filter-replacement) ).

Scheme 14

1. Remove the oil pump (see «OIL PUMP REMOVAL»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ).
2. Remove the baffle plate (see step 7 under «CRANKSHAFT AND PISTON REMOVAL»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-block) ).
3. Remove the oil jet bolt (A), then remove the oil jet (B).
4. Carefully install the oil jet, and tighten the oil jet bolt.
5. Install the baffle plate (see step 23 under «CRANKSHAFT INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-block__crankshaft-installation) ).
6. Install the oil pump (see «OIL PUMP INSTALLATION»(/acura/rdx/i-2006-2009/remont/lubrication-system/#engine-lubrication) ).

Scheme 15

1. Remove the oil jet, and inspect it as follows. Make sure that a 1.1 mm (0.04 in.) diameter drill will go through the nozzle hole (A) (1.2 mm (0.05 in.) diameter). Insert the other end of a 1.1 mm (0.04 in.) drill into the oil intake (1.2 mm (0.05 in.) diameter). Make sure the check ball (B) moves smoothly and has a stroke of approximately 4.0 mm (0.16 in.). Check the oil jet operation with an air nozzle. It should take at least 200 kPa (2.0 kgf/cm 2 , 28 psi) to unseat the check ball. NOTE: Replace the oil jet assembly if the nozzle is damaged or bent.
2. Carefully install the oil jet. The mounting torque is critical. Torque: 16 N.m (1.6 kgf.m, 12 lbf.ft)

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Turn the crankshaft pulley so its top dead center (TDC) mark (A) lines up with the pointer (B).
2. Remove the oil pan (see «OIL PAN REMOVAL»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-block__oil-pan-removal) ).
3. Loosely install the crankshaft pulley.
4. To hold the rear balancer shaft, insert a 6 mm pin punch (A) into the maintenance hole in the balancer shaft holder and through the rear balancer shaft.
5. Turn the crankshaft counterclockwise to compress the oil pump chain auto-tensioner.
6. Align the holes on the lock (A) and the oil pump chain auto-tensioner (B), then insert a 1.5 mm (0.06 in.) diameter pin (C) into the holes. Turn the crankshaft clockwise to secure the pin.
7. Remove the oil pump chain auto-tensioner.
8. Loosen the oil pump sprocket mounting bolt.
9. Remove the oil pump sprocket (A), then remove the oil pump (B).

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Remove the pump housing.
2. Check the inner-to-outer rotor radial clearance between the inner rotor (A) and outer rotor (B). If the inner-to-outer rotor radial clearance exceeds the service limit, replace the oil pump. Inner Rotor-to-Outer Rotor Radial Clearance Standard (New): 0.10-0.17 mm (0.004-0.007 in.) Service Limit: 0.2 mm (0.008 in.)
3. Check the housing-to-rotor axial clearance between the rotor (A) and lower balancer shaft holder (B). If the housing-to-rotor axial clearance exceeds the service limit, replace the oil pump. Housing-to-Rotor Axial Clearance Standard (New): 0.030-0.075 mm (0.0012-0.0030 in.) Service Limit: 0.12 mm (0.005 in.)
4. Check the housing-to-outer rotor radial clearance between the outer rotor (A) and lower balancer shaft holder (B). If the housing-to-outer rotor radial clearance exceeds the service limit, replace the oil pump. Housing-to-Outer Rotor Radial Clearance Standard (New): 0.035-0.090 mm (0.0014-0.0035 in.) Service Limit: 0.23 mm (0.009 in.)

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Seat the balancer shaft by pushing it away from the oil pump sprocket end of the oil pump.
2. Zero the dial indicator against the end of the balancer shaft, then push the balancer shaft back and forth and read the end play. Balancer Shaft End Play Standard (New): 0.060-0.140 mm (0.0024-0.0055 in.) Service Limit: 0.15 mm (0.006 in.)
3. Remove the upper balancer shaft holder (with bearings) (A), then remove the front balancer shaft (B) and rear balancer shaft (C).
4. Measure the inner diameter of the No. 1 bearing for the front balancer shaft hole and the rear balancer shaft hole. Bearing Inner Diameter Front: Standard (New): 20.000-20.020 mm (0.7874-0.7882 in.) Service Limit: 20.03 mm (0.789 in.) Rear: Standard (New): 24.000-24.020 mm (0.9449-0.9457 in.) Service Limit: 24.03 mm (0.946 in.) Front Rear
5. Measure the diameters of the No. 1 journals on the front balancer shaft and rear balancer shaft. Journal Diameter Front: Standard (New): 19.938-19.950 mm (0.7850-0.7854 in.) Service Limit: 19.92 mm (0.784 in.) Rear: Standard (New): 23.938-23.950 mm (0.9424-0.9429 in.) Service Limit: 23.92 mm (0.942 in.) Front Rear
6. Clean both balancer shaft No. 2 journals and bearing halves with a clean shop towel.
7. Place one strip of plastigage across each No. 2 journal.
8. Reinstall the bearings and upper balancer shaft holder, then torque the bolts. NOTE: Do not rotate the balancer shafts during inspection.
9. Remove the upper balancer shaft holder and bearings again, and measure the widest part with the plastigage. If the balancer shaft No. 2 journal oil clearance is out-of-tolerance, install new bearings, and recheck. If it is still out-of-tolerance, replace the balancer shafts. No. 2 Journal Oil Clearance Standard (New): 0.060-0.120 mm (0.0024-0.0047 in.) Service Limit: 0.15 mm (0.006 in.)
10. Align the punch mark on the rear balancer shaft in the center of the two punch marks on the front balancer shaft, then install the balancer shafts on the lower balancer shaft holder.
11. Apply engine oil to the threads of the 8 mm bolts (A).
12. Install the upper balancer shaft holder (B).
13. Install the pump housing.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Make sure the No. 1 piston top dead center (TDC) mark (A) lines up with the pointer (B).
2. Align the dowel pin (A) on the rear balancer shaft with the mark (B) on the oil pump.
3. To hold the rear balancer shaft, insert a 6 mm pin driver (A) into the maintenance hole in the lower balancer shaft holder and through the rear balancer shaft.
4. Apply engine oil to the threads of the 10 x 1.25 mm oil pump mounting bolts (A).
5. Loosely install the oil pump (B), then install the oil pump sprocket (C).
6. Remove the pin driver (D).
7. Tighten the oil pump mounting bolts.
8. Install the oil pump chain auto-tensioner.
9. Remove the pin from the oil pump chain auto-tensioner.
10. Install the oil pan (see «OIL PAN INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-block) ).

Oil Pump Chain Replacement

Special Tools Required

1. RDX engine support mount pads 07AAK-STKA120
2. Engine support hanger, A and Reds AAR-T-12566 * * Available through the Honda Tool and Equipment Program, 1-888-424-6857.

Note. Keep the oil pump chain away from magnetic fields.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. Remove the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
2. Remove the cam chain (see «CAM CHAIN REMOVAL»(/acura/rdx/i-2006-2009/remont/mechanical/#cylinder-head__cam-chain-removal) ).
3. Remove the power steering (P/S) pump. Do not disconnect the P/S hoses from the pump (see step 21 under «ENGINE REMOVAL»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-removal-and-installation) ).
4. Attach the universal eyelet to the drive belt auto-tensioner (see step 54 under «ENGINE REMOVAL»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-removal-and-installation) ).
5. Remove the top corner clip (A) from the front grill on both sides. Place the engine support mount pads over the hood edge cushions (B), and align the pins with the clip hole (C). Remove the lids from both side of the cowl cover. Install the engine support hanger (AAR-T-12566), then attach the hook to the universal eyelet. Tighten the wing nut (D) by hand to lift and support the engine/ transmission assembly.
6. Remove the oil pan (see «OIL PAN REMOVAL»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-block__oil-pan-removal) ).
7. Install the crankshaft pulley.
8. To hold the rear balancer shaft, insert the 6 mm pin punch (A) into the maintenance hole in the balancer shaft holder and through the rear balancer shaft.
9. Turn the crankshaft counterclockwise to compress the oil pump chain auto-tensioner.
10. Align the holes on the lock (A) and the oil pump chain auto-tensioner (B), then insert a 1.5 mm (0.06 in.) diameter pin (C) into the holes. Turn the crankshaft clockwise to secure the pin.
11. Remove the oil pump chain auto-tensioner.
12. Remove the crankshaft pulley.
13. Remove the oil pump chain guide.
14. Loosen the oil pump sprocket mounting bolt.
15. Remove the oil pump chain.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Set the crankshaft to top dead center (TDC). Align the TDC mark (A) on the crankshaft sprocket with the pointer (B) on the cylinder block.
2. Install the oil pump chain on the crankshaft sprocket with the center of the two colored link plates (A) aligned with the TDC mark (B) on the oil crankshaft sprocket.
3. Install the oil pump chain on the oil pump chain sprocket with the punch mark (A) aligned with the center of the three colored link plates (B).
4. To hold the rear balancer shaft, insert the 6 mm pin punch (A) into the maintenance hole in the balancer shaft holder and through the rear balancer shaft, then tighten the oil pump sprocket mounting bolt (B).
5. Install the oil pump chain guide.
6. Install the oil pump chain auto-tensioner.
7. Remove the pin from the oil pump chain auto-tensioner.
8. Install the oil pan (see «OIL PAN INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-block) ).
9. Support the engine with a jack and a wood block under the oil pan.
10. Remove the special tools from the engine and vehicle.
11. Install the cam chain (see «CAM CHAIN INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#cylinder-head__cam-chain-installation) ).
12. Install the P/S pump (see step 38 under «ENGINE INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#engine-removal-and-installation__engine-installation) ).
13. Install the crankshaft pulley (see «INSTALLATION»(/acura/rdx/i-2006-2009/remont/mechanical/#cylinder-head) ).
14. Install the drive belt (see «DRIVE BELT REMOVAL/INSTALLATION»(/acura/rdx/i-2006-2009/remont/charging-system/#charging-system__drive-belt-removalinstallation) ).
