Slide motor, Front up-down motor. Rear up-down motor

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 268

Scheme 269

Scheme 270

Scheme 271

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-510487-S39925743902012102300000) ).
2. Disconnect the 2P connector from each power seat motor. NOTE: All connectors are terminal side of male terminals.
3. Test each motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately.
4. If the front up-down motor or rear up-down motor does not run or fails to run smoothly, replace the faulty motor (see «FRONT SEAT LINKAGE DISASSEMBLY/REASSEMBLY»(ref-510487-S42282690802012102300000) ).

If the slide motor does not run or fails to run smoothly, replace the left seat track/slide motor (see FRONT SEAT LINKAGE DISASSEMBLY/REASSEMBLY ).

Note. The slide motor is not available separately because it is assembled into the left seat track, refer to the seat linkage disassembly/reassembly (see FRONT SEAT LINKAGE DISASSEMBLY/REASSEMBLY ).

Recline motor

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 272

Scheme 273

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(ref-510487-S39925743902012102300000) ).
2. Disconnect the driver's seat wire harness 8P [14p] connector from the driver's seat subharness. []: With seat ventilation
3. Test the motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately. []: With seat ventilation
4. If the motor does not run or fails to run smoothly, check for an open in the wire between the 8P [14P] connector and recline motor. If the harness is OK, replace the recline motor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(ref-510487-S18177212622012102300000) ).

[]: With seat ventilation

Scheme 274

Scheme 275

1. Remove the steering column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(ref-510494-S27373242142012102300000) ).
2. Disconnect the 13P connector (A) from the power tilt/telescopic steering switch (B).
3. Check for continuity between the terminals in each switch position according to the table.
4. If the continuity is not as specified, replace the switch.

Scheme 276

Scheme 277

Scheme 278

1. Remove the steering column covers (see «COLUMN COVER REMOVAL/INSTALLATION»(ref-510494-S27373242142012102300000) ).
2. Disconnect the 6P connector and 8P connector from the power tilt/telescopic steering motors.
3. Check each motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately. TILT MOTOR: TELESCOPIC MOTOR
4. If the motor does not run or fails to run smoothly; replace the steering column assembly (see «STEERING COLUMN REMOVAL AND INSTALLATION»(ref-510435-S23199861522012102300000) ).
