Audio System: Specifications Acura MDX II facelift

Display Specifications

Note. Any other diagnostic screens shown are for audio manufacturer's use only.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Bus line indication (TITLE button)

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. Turn the ignition switch to ON (II).
2. Make sure the audio system is turned off.
3. Push and hold the No. 1 and No. 3 buttons. While holding the buttons, push the VOL PUSH PWR knob to ON. Release the buttons and the speaker check mode begins. A tone should sound from one speaker.
4. Each time you press the SKIP or CH button, the speaker outputs a beep sound in the listed order. Display Specifications With navigation ( ) is pressed: (1)-->(2)-->(3)-->(4)-->(5)-->(6)-->(7)-->(8)-->(9) ( ) is pressed: (1)-->(9)-->(8)-->(7)-->(6)-->(5)-->(4)-->(3)-->(2) Without navigation ( ) is pressed: (1)-->(2)-->3-->4-->5-->6-->7 ( ) is pressed: (1)-->(7)-->6-->5-->4-->3-->2 WITH NAVIGATION Speaker Displayed Segments Remarks (1) Driver's door speaker and left tweeter SPKR FR-L You should hear a tone corresponding to the speaker (2) Center speaker SPKR CENTER You should hear a tone corresponding to the speaker (3) Front Passenger's door speaker and right tweeter SPKR FR-R You should hear a tone corresponding to the speaker (4) Right rear door speaker SPKR RR-R You should hear a tone corresponding to the speaker (5) Right satellite speaker SPKR SURROUND-R You should hear a tone corresponding to the speaker (6) Subwoofer SPKR SUBWOOFER You should hear a tone corresponding to the speaker (7) Left rear door speaker SPKR RR-L You should hear a tone corresponding to the speaker (8) Left satellite speaker SPKR SURROUND-L You should hear a tone corresponding to the speaker (9) All Speakers SPKR ALL You should hear a tone corresponding to the speaker The subwoofer does not sound atone WITHOUT NAVIGATION Speaker Displayed Segments Remarks (1) Driver's door speaker and left tweeter SPKR FR-L You should hear a tone corresponding to the speaker (2) Center speaker SPKR CENTER You should hear a tone corresponding to the speaker (3) Front Passenger's door speaker and right tweeter SPKR FR-R You should hear a tone corresponding to the speaker (4) Right rear door speaker SPKR RR-R You should hear a tone corresponding to the speaker (5) Subwoofer SPKR SUBWOOFER You should hear a tone corresponding to the speaker (6) Left rear door speaker SPKR RR-L You should hear a tone corresponding to the speaker (7) All Speakers SPKR ALL You should hear a tone corresponding to the speaker The subwoofer does not sound atone NOTE: Any other diagnostic screens are for factory use only.
5. The speaker check mode ends when you turn the audio system off, or turn the ignition switch to LOCK (0).
