Engine Controls - Specifications - Gs-R Acura Integra III

Specifications 2 illustrations ~219 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article to use when you are familiar with an adjustment procedure and only need a specification.

CAPACITIES

ApplicationAmp Hr. Rating
GS-R36

BATTERY SPECIFICATIONS

ApplicationQuantity
Auto. Transaxle (Dexron-II)
Fluid Change2.9 Qts. (2.7L)
Overhaul6.2 Qts. (5.9L)
Cooling System (1) (Includes Heater)5.0 Qts. (4.7L)
Crankcase (Includes Filter)4.2 Qts. (4.0L)
Manual Transaxle2.3 Qts. (2.2L)
(1) Drain and refill capacity.
(1)Drain and refill capacity.

FLUID CAPACITIES

SERVICE INTERVALS & SPECIFICATIONS

ComponentMiles
Air Filter30,000
Automatic Transmission Fluid90,000
Brake Fluid45,000
Camshaft Timing Belt105,000
Coolant(1)
Engine Oil7500
Engine Oil Filter15,000
Fuel Filter(2)
Manual Transmission Oil90,000
Spark Plugs105,000
Valve Clearance(3) 30,000
(1) First service interval is 45,000 miles. Service every 30,000 miles thereafter. (2) Fuel filter should be replaced when fuel pressure drops below specification with fuel pressure regulator vacuum hose disconnected. See REGULATED FUEL PRESSURE under FUEL SYSTEM. Ensure fuel pump and fuel pressure regulator are okay. (3) Inspect valve clearance at interval and adjust as necessary with engine cold.
(1)First service interval is 45,000 miles. Service every 30,000 miles thereafter.
(2)Fuel filter should be replaced when fuel pressure drops below specification with fuel pressure regulator vacuum hose disconnected. See REGULATED FUEL PRESSURE under FUEL SYSTEM. Ensure fuel pump and fuel pressure regulator are okay.
(3)Inspect valve clearance at interval and adjust as necessary with engine cold.

REPLACEMENT INTERVALS

Application(1) Deflection - In. (mm)
A/C Compressor
New Belt(2) 3/16-9/32 (5.0-7.0)
Used Belt(3) 11/32-13/32 (8.5-10.5)
Alternator
New Belt(2) 7/32-5/16 (6.0-8.0)
Used Belt11/32-7/16 (9.0-11.0)
Power Steering
New Belt(2) 5/16-13/32 (8.0-10.0)
Used Belt7/16-17/32 (11.5-13.5)
(1) Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run. (2) Install new belt to new specification. Run for 5 min. and readjust to used belt specification. (3) Specification is for a used belt. Belt is considered used when it has been run for 5 minutes or more.
(1)Deflection is with 22 lbs. (10 kg) pressure applied midway on longest belt run.
(2)Install new belt to new specification. Run for 5 min. and readjust to used belt specification.
(3)Specification is for a used belt. Belt is considered used when it has been run for 5 minutes or more.

BELT ADJUSTMENT

ENGINE COMPRESSION

ApplicationSpecification
Compression Ratio10.0:1
Compression Pressure At 250 RPM & WOT
Standard270 (19.0 kg/cm 2 )
Minimum135 psi (9.5 kg/cm 2 )
(1) Max. variation between cylinders is 28 psi (2 kg/cm 2 ).
(1)Max. variation between cylinders is 28 psi (2 kg/cm 2 ).

ENGINE COMPRESSION (1)

VALVE CLEARANCE

ApplicationIn. (mm)
Intake.006-.007 (.15-.19)
Exhaust.007-.008 (.17-.20)
(1) Adjust valves when engine is cold. Measured between camshaft and rocker arm.
(1)Adjust valves when engine is cold. Measured between camshaft and rocker arm.

VALVE CLEARANCE ADJUSTMENT (1)

IGNITION COIL

ApplicationPrimarySecondary
GS-R.60-.8012,800-19,200

IGNITION COIL RESISTANCE - Ohms @ 77°F (25°C)

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
GS-R25,000 Maximum

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNGKNippondenso
GS-RPFR6G-13PK20PR-L13

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
Non-Platinum.039-.043 (1.0-1.1)13 (18)
Platinum.047-.051 (1.2-1.3)13 (18)

SPARK PLUG SPECIFICATIONS

Scheme 1

Scheme 1: FIRING ORDER & TIMING MARKS
Scheme 1: FIRING ORDER & TIMING MARKS

IGNITION TIMING

Application(2) Man. Trans.(3) Auto. Trans.
GS-R14-18 @ 700-80014-18 @ 700-800
(1) Install Service Check Connector Tool (07PAZ-0010100 ) to service check connector before checking timing. (2) Manual transmission in Neutral. (3) Automatic transmission in Neutral or Park.
(1)Install Service Check Connector Tool (07PAZ-0010100 ) to service check connector before checking timing.
(2)Manual transmission in Neutral.
(3)Automatic transmission in Neutral or Park.

IGNITION TIMING (1) (Degrees BTDC - RED MARK @ RPM)

Scheme 2

Scheme 2
Scheme 2

FUEL PUMP

ApplicationSpecification
At Idle Without Vacuum48-55 psi (3.4-3.9 kg/cm 2 )
At Idle With Vacuum39-46 psi (2.7-3.2 kg/cm 2 )
(1) Pressure measured at fuel filter with vacuum hose connected or disconnected from fuel pressure regulator.
(1)Pressure measured at fuel filter with vacuum hose connected or disconnected from fuel pressure regulator.

REGULATED FUEL PRESSURE (1)

IDLE SPEED & MIXTURE

Note. Before setting idle speed ensure MIL has/is not been on, ignition timing is correct, spark plugs and air cleaner are okay, and PCV system is operating properly.

Note. On models equipped with Daytime Running Lights (DRL), apply parking brake, and with engine running, ensure headlights are off.

Application(1) Base Idle RPM(2) Curb Idle RPM(3) Load Idle RPM
GS-R430-530700-800(4) 700-800
(1) Transmission in "N" or "P" and IAC valve disconnected and no accessory loads. (2) Transmission in "N" or "P", IAC valve connected and no accessory loads. (3) Transmission in "N" or "P", IAC valve connected and headlights on low. (4) Transmission in "N" or "P", IAC valve connected, headlights off, blower motor switch set to high and A/C on. Idle speed should be 800-900 RPM.
(1)Transmission in "N" or "P" and IAC valve disconnected and no accessory loads.
(2)Transmission in "N" or "P", IAC valve connected and no accessory loads.
(3)Transmission in "N" or "P", IAC valve connected and headlights on low.
(4)Transmission in "N" or "P", IAC valve connected, headlights off, blower motor switch set to high and A/C on. Idle speed should be 800-900 RPM.

IDLE SPEED SPECIFICATIONS

ApplicationCO Level
GS-R.1%

IDLE CO LEVEL

FAST IDLE SPEED

ApplicationRPM
GS-R1400-1800

FAST IDLE SPEED SPECIFICATIONS

THROTTLE POSITION SENSOR

Note. Throttle position sensor is not adjustable. For testing procedures, refer to the TESTS W/CODES - GS-R or SYSTEM/COMPONENT TESTS - GS-R article.
