Acura ILX I facelift (2015-2018) Cruise control circuit

APP SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) APP SENSOR A APP SENSOR B BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM ETCS CONTROL RELAY FUSE 21 FUSE 22 GRN WIRE GRY WIRE HOT AT ALL TIMES LINES SYSTEM LT BLU WIRE LT GRN WIRE MILLIMETER WAVE RADAR MULTIPURPOSE CAMERA UNIT ORG/ WIRE OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR PCM PGM-FI MAIN RELAY 1 PNK WIRE PPL RED WIRE TAN WIRE THERMAL JOINT 3 THROTTLE ACTUATOR THROTTLE BODY (INLET TO INTAKE MANIFOLD) THROTTLE OPEN SENSOR TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX W/ CMBS WHT WIRE YEL WIRE

BLU WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE CABLE REEL CANCEL SWITCH CIRCUIT COMPUTER DATA LINES SYSTEM CRUISE CONTROL COMBINATION SWITCH CRUISE CONTROL INDICATOR CRUISE CONTROL MAIN SWITCH INDICATOR CRUISE LIGHT DIMMING CIRCUIT DISPLAY DISTANCE SWITCH F-CAN F-CAN H F-CAN L FUSE 18 FUSE 2 FUSE 29 FUSE 5 FUSE 6 GAUGE CONTROL MODULE (TFT) GRN WIRE GRY WIRE HOT AT ALL TIMES INFO/DOWN SWITCH INFO/UP SWITCH LKAS SWITCH LT BLU WIRE LT GRN WIRE MAIN SWITCH MICU MULTI-INFORMATION RED WIRE RELAY ENERGIZED RESUME + SWITCH SET SWITCH SET/ RESET SWITCH TAN WIRE TRANSCEIVER/ UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX W/ CMBS W/ COLOR MULTI-INFORMATION DISPLAY W/O COLOR MULTI-INFORMATION DISPLAY WARNING DRIVE CIRCUIT WHT WIRE YEL WIRE
